3D LIT LETTERS
Push Through
ACRYLICA SERIES
FACE
Face Lit
High-end is the word that comes to mind to describe this product. This is the solution for providing a colored return in an acrylic letter. The manufacturing process provides a clean finishing that enhances any application. There is no transition between the edge and illumination.
Advantages:
Illumination Diagram
Face Lit Face Lit
• The best solution for traditional acrylic letters
• Serviceable structure design available
• Flat or beveled return shape
• Painted return surface
Attributes:
• 1” standard return depth*
• Different letter height options*
• Stroke starting size at 0.4” or 10mm*
• Flushed or Projected mounting options
*May vary depending on selected font.
Return Options
We provide multiple options in terms of the return of the letter. When it comes to the shape, the letter can be either a flat or beveled surface. Beveled surfaces provide an angled edge that accents both the shape and illumination of the product. When it comes to colors, don’t forget to add paint!
ACRYLICA SERIES
FACE AND RETURN LIT
Face & Return Lit
Our solution for providing a 3D illumination letter can be fully customized in terms of font and color. Because of its versatility, it is the best fit for high-end luxury applications. effect. Routed from a single acrylic block, this
Return Lit
This product is built through a process that allows two separate acrylic layers to combine seamlessly. Both Face and Return Lit, it enhances any application, giving it a modern look and finish. The top layer can be flat or curved and color possibilities are endless.
Advantages:
• Surface material provides uniform and even look
• The only option that provides a full return lit
• Flat or curved surface options available
• Serviceable structure design available
• Acrylic or vinyl for face color options
• Even light distribution
Attributes:
• Letter height up to 24”*
• 1” standard return depth*
• Stroke starting size at 1.8” or 30mm*
• Flushed mounting option available
*May vary depending on selected font.
Face & Return Lit
Face & Return Lit
Multi-Layer
Return Lit
Illumination Diagram
Multi-Layer
Return Lit
Acrylica Series
CHROMATYC SERIES
TOP RETURN LIT
Top Return Lit
Many colors, many possibilities. The acrylic in the Face of the letter provides multiple looks depending on the desired final product. All the way from flat to thick, this letter is able illuminate the edges. to achieve different thickness levels that
Advantages:
• Surface material provides uniform and even look
• Serviceable or not serviceable options available
• Acrylic or vinyl for face colors
• No trim cap
Attributes:
• 0.16” standard return depth*
• Different letter height options*
• Stroke starting size at 0.6” or 15mm*
• Wet and dry rated options available
• Flushed or Projected mounting options
*May vary depending on selected font.
Top Return Lit
Top Return Lit
Trimless
Illumination Diagram
Trimless
Thickness of Acrylic Flat Thin Thick
CHROMATYC SERIES
BOTTOM RETURN LIT
Bottom Return Lit
High-end look and feel. The acrylic in the Back of the letter is able to isolate the illumination
pure halo to thick, it illuminates the edges. by achieving different thickness levels, from
Advantages:
• Painted, metallic, anodized, powder coat options available
• Surface material provides uniform and even look
• Serviceable or not serviceable options available
• High-end look for metal surface options
Attributes:
• Letter height starting at 6”*
• 1.5” standard return depth*
• Stroke starting size at 0.31” or 8mm*
• Wet and dry rated options available
• Flushed or Projected mounting options
*May vary depending on selected font.
Metal Halo Lit
Metal Halo Lit
Bottom Return Lit
Illumination Diagram
Bottom Return Lit
Thickness of Acrylic
Pure Halo Thin Thick
CHROMATYC SERIES
PRISM
Prism
Shine to impress. This product adds dimension to the Bottom Return Lit Channel Letter and has many finishing options. There is no need to have two letters alike since there is no mold required to manufacture this product.
Advantages:
• Surface material provides uniform and even look
• Serviceable or not serviceable options available
• High-end look for metal surface options
• Paint and oxidize options
Attributes:
• 0.16” standard return depth*
• Different letter height options*
• Stroke starting size at 0.6” or 15mm*
• Wet and dry rated options available
• Flushed or Projected mounting options
*May vary depending on selected font.
Illumination Diagram
Bottom Return Lit
CHROMATYC SERIES
PUSH-THROUGH
Illumination Diagram
Metal Trim Push-Through
Different thickness, different levels. All the way from Metal Trim to Push-Through, the thickness of the acrylic is the determining factor of what this letter becomes. If you do not like to use the plastic trim cap retainer, then this is the best solution for that application. The way this letter is manufactured provides even lighting and a clean look.
Thickness of Acrylic
Advantages:
• Recessed or Push-Through acrylic surface
• Reliable letter for high rise applications
• Day/Night option available only for flat surfaces
• Serviceable and not serviceable options available
• Custom features for thickness of acrylic, Halo, Top or Bottom Return, and lighting effect.
Attributes:
• 0.2” or 5mm stroke*
• Different letter height options*
• 1.5” or 38mm standard return depth*
• Wet and dry rated options available
• Copper and Brass finishing available
• Flushed or Projected mounting options
*May vary depending on selected font.
INNOTRIM SERIES
ALUMINUM RETURN
Diagram
Aluminum Return
Introducing liquid acrylic technology. This patent-pending product is our best seller for applications that require an even face color and no illumination in the return. The Aluminum return provides impeccable painted surface color with incredibly detailed finishing. The best solution for matching colors between the face and return of the letter.
Advantages:
• Serviceable structure design available
• Does not yellow from normal use
• Multiple surface color options
• Day/Night option available
• Super lightweight
Attributes:
• Dry location only
• 0.43” or 11mm stroke*
• Different letter height options
• Flushed mounting option available
• 1.5” or 38mm standard return depth*
• Working temperature above -20°F or -28°C
Face & Return Color
*May vary depending on selected font.
Face Lit
Face & Halo Lit
Face & Bottom Return Lit
Lit
Face & Halo Lit
Face& Bottom Return Lit Illumination
INNOTRIM SERIES
STAINLESS STEEL RETURN
Stainless Steel Return
Introducing liquid acrylic technology. This patent-pending product is our best seller for applications that require an even face color and no illumination in the return. The Stainless Steel return provides an impeccable metal look for surface color. This option provides many finishing possibilities.
Illumination Diagram
Advantages:
• Serviceable structure design available
• Face + Halo illumination available
• Does not yellow from normal use
• Multiple surface effects options
• Day/Night option available
• Super lightweight
Attributes:
• Dry location only
• 0.43” or 11mm stroke*
• Different letter height options
• Flushed mounting option available
• 1.5” or 38mm standard return depth*
• Working temperature above -20°F or -28°C
*May vary depending on selected font.
Return Finishing Options
Face Lit
Face Lit
Brass Copper Polished Brushed
ALPHANEON SERIES
FACE LIT
AlphaNeon Series
Smooth, reliable, flexible. This product provides a traditional neon looking letter that is energy
efficient. It achieves corners and shapes that
other LED neon replacement products cannot. The ideal solution for a 3D version of any possible handwritten text.
Product Options
Illumination Diagram
Advantages:
• Paint for return color options
• Acrylic for face color options
• Versatile material and surface
• Serviceable structure design available
Attributes:
• Available in 8mm, 12mm, or 15mm stroke*
• 1” or 25.4mm standard return depth*
• Different letter height options*
• Open face letter available
• Wet and dry rated options available
• Flushed or Projected mounting options
*May vary depending on selected font.
Face Lit
Open Face Channel Letter
Face Lit
Face & Halo Lit
Color Face and Return
With Open Face Channel Letter
White Face and Return
Quality Assurance
Product Warranty
Alpha letter backs up their products with a 3 year warranty period.
Lead Time
After the quotation is approved by the customer, it takes 21 days to obtain the final product.
Customer Service
We provide weekly updates to our customers with pictures about their order.
Quality Control
Quality matters, which is why we have rigorous control checks before the product arrives at the destination.
Our products are certified as UL Listed and come with the trusted UL-Label.
Finishing
Including a wide variety of options, we provide finishings that are idyllic for applications that include luxury brands and refined modern look. Our Chromatyc and Innotrim letters can provide these beautiful effects.
Color Consistency Matters
We offer a wide variety of acrylic
options that will enhance the looks and performance of the product. In addition to the three main categories of acrylic, we also offer vinyl and paint solutions.
Everylite is our preferred vendor for illumination and power, providing many options for LED products and multiple choices of wattages for power supplies.
Powered by
Brushed Stainless Steel
Polished Stainless Steel
Brushed Black
Polished Black Brushed Brass
Polished Brass
Brushed Copper
Polished Copper Bronze Satin Stainless Steel
Mounting Hardware
We offer the traditional system for the product to be mounted on a wall, installation are included with every shipment.
cabinet, or plates. All the required mounting hardware and templates for
Studs
Spacers
Letter with studs
Letter with studs and spacers
This is our internal process that is broken down into four major steps. Quotation ensures accuracy for the order. Production time begins after all details are finalized and approved. We have two Quality Control checkpoints before final delivery because quality matters, period. Finally, we partner with reliable logistic companies that will deliver our product on time wherever you need it.
Order
We receive your inquiry and provide an initial quotation.
Production
We decide on final measurements and pricing. Your project begins production.
Quality Control
We receive your product and test it before the final shipment.
Shipping
We deliver the product to our customer’s address or installation site.
These are the options we provide to our customers to determine all the requirements and details of the letters. This information is essential to provide an accurate quotation that will exceed expectations.
Requirements
• All sign measurements: height, length, depth
• Total sign length
• We accept only AI files
Applications
We can create signs that are in compliance with Indoor or Outdoor applications
Illumination and Colors
• White 2500K-6500K
• Red, Green, Blue, Amber
• RGB
• Customized
Material Colors
Customers should provide the color they want to use for:
• Vinyl
• Acrylic
• Paint
We accept CYMK or Pantone code
Finishing
Acrylic:
• Clear or Frosted
Stainless Steel and Aluminum:
• Painted, Brushed, Polished, Brass, Copper
Mounting Specs
We can provide the proper materials for our product to be mounted:
•Top, Bottom, Wall mount, Stand off/Flushed
Customer can provide us with their mounting template in AI format, or we can provide the mounting template
Hardware Requirements
We provide the following hardware for mounting options:
• Riv-nuts, screw-nuts, spacers, studs, mounting holes
Special Instructions
We provide additional customizing features such as:
• Cable length: standard is 2ft, but if requested we can increase it
