High Precision Chucks

High Precision Chucks 0.001 mm repeatability for extreme precision performance

Tens of thousands of EROWA Chucks are in daily operation worldwide with their guaranteed precision, quality and reliability.

In some special applications it may be important to apply the utmost accuracy as far as the work holding system is concerned. For these cases EROWA developed the High Precision Chucks.

In order to assure the best results, we propose to apply the corresponding alignment elements for checking the position and alignment of the chucks.

High Precision ITS products

ER‑097362

Version Clamping power Connections Application

ER‑097363

Version Application

HP ITS Chuck with base plate

High precision. Repeatability within 0.001 mm.

2’500 N. Laterally on base plate. Use of control unit is recom‑ mended.

To accommodate electrode holders, holders ø 72 and pallets ø 115 / ø 148. Titan‑nitride coated base plate for best performance and easy recognition.

HP Gauging pin

High precision. Stainless, hardened and ground.

For alignment and checking of position and repeatability of EROWA High precision ITS Chucks.

High Precision PM products

ER‑143343

Version Clamping power Operation Application

ER‑071890

Version Application

HP Die‑plate Chuck PM128 Precise with base plate

High precision. Repeatability within 0.001 mm.

20’000 N (reclamped at 6 bar).

Laterally on base plate. Use of control unit is recom‑ mended.

To accommodate die‑plate pallets PM128 Precise and Multi. Titan‑nitride coated base plate for best performance and easy recognition.

Alignment pallet PM128 Precise for die‑plate chuck PM128 AirDock / HP

Hardened steel, corrosion‑resisitant. With ground align‑ ment surface and ø 122. Including M50 x 1.5 threaded insert.

For tool‑ and mold‑making. To align angle position and determine the center of die‑plate chucks PM128 AirDock and High precision.

Are you looking for best accuracy?

Use the EROWA High Presicion Chucks!

THE FACTS

• Repeatability ≤ 0.001 mm • Ensures highest precision • For significant reduction of setup times
