Element Designs Inspiration Catalog v.7.19

® 1

ABOUT US “The details are not the details. They make the design.” - Charles Eames

Our Company

Element Designs was founded in 2003 by a group of American and Swiss individuals with a drive for innovation and healthy dose of entrepreneurship. We recognized the contemporary European trends in the casework industry and foresaw the need for a reliable supplier to the product demand that was positioned to arrive in North America. We are a trusted partner and supplier of aluminum, glass and acrylic casework components and surfacing materials to the leading kitchen, office and closet manufacturers in the industry.

Our Products

We began our company by manufacturing aluminum frame glass doors with a selection of design forward frame styles and glass inserts which naturally complemented a variety of residential and commercial interiors.

Over the years our product offering has expanded to include high gloss solid surface acrylic doors, backpainted glass products and aluminum frame base systems to meet the demands of our customers and to introduce new products which were well suited for the contemporary trends that were to come. We are proud to say that our products are made in the USA.

Our Passion

We are passionate about contemporary design and believe great design starts with great products. The difference is always in the details. We are driven to bring the best trends in casework and architectural design to the North American market based on European trends, but catered especially for North American preferences. We invest in research and development to create products and solutions to help drive innovative design in our industry.

Our Team

Our employees are our most important asset. Many companies may say it, but we live it every day. With the implementation of an inclusive management style, we count on our employees to provide constant feedback related to products and processes which continuously improve our quality and product offerings. Our dedication to our team has enabled us to build a world class group of team members whose primary focus is to make our customers happy. Our love for what we do translates into the best products and service in the industry.

Our Promise

We promise to always strive to exceed our customers’ expectations. We understand the importance of quality products and quick lead times, but we also realize that the true value of being a trusted partner of any manufacturer is to provide an excellent customer experience by listening to our customers’ needs and going above and beyond expectations to make sure we provide products and service that always add value to your projects and designs.

2

CONTENTS inspiration gallery

4

application gallery KITCHEN CLOSET BATHROOM RESIDENTIAL OFFICE COMMERCIAL

12 12 16 18 20 22 24

aluminum frame doors PROFILES FINISHES INSERTS

28 30 32 33

sliding doors SLIDING DOOR OPTIONS

36 38

high gloss solid acrylic COLOR & EDGE OPTIONS

40 42

backpainted glass & markerboards BACKPAINTED GLASS OPTIONS MARKERBOARD OPTIONS

44 46 50

aluminum frame base systems BASE SYSTEM OPTIONS

52 54

frameless glass doors GLASS OPTIONS

56 58

hardware DECORATIVE HARDWARE FUNCTIONAL HARDWARE

60 62 64

sustainability

66

3

4

MODERN LUXURY with Aluminum Frame Cabinet Doors

Featured Products: AF002 Profile Doors, Brushed Stainless Finish, Low Iron Clear Glass Inserts AF002 Profile Doors, Brushed Stainless Finish, Metal Laminate Inserts

Image courtesy of Paramount Woodworking.

Image courtesy of MasterBrand Cabinets.

5

6

Kitchen design by Sarah Robertson, Studio Dearborn, and Nancy Davilman, ND Interiors. Cabinetry by Schrock’s of Walnut Creek. Photo by Timothy Lenz.

CLASSIC CONTEMPORARY with Aluminum Frame Cabinet Doors & Backpainted Glass Backsplash

Featured Products: AF011 Profile Doors, Oil Rubbed Bronze Finish, Bronze Reflective Glass Inserts Mocha Gloss Backpainted Glass Backsplash

Image courtesy of M. Lahr Homes and Ted Maines Interiors.

7

8

POLISHED PROFESSIONAL with Aluminum Frame Cabinet Door & Magnetic Glass Markerboard

Featured Products: AF010 Profile Door, Natural Aluminum Finish, Sand Matte Glass Insert Sand Matte Writable Backpainted Glass Markerboard

Image courtesy of GEIGER. Photography credit: NIcholas Calcott

9

10

SOPHISTICATED STYLE with Aluminum Frame Cabinet Doors & Backpainted Glass

Featured Products: AF004 Profile Doors, Natural Aluminum Finish, Clear Glass Inserts AF006 Profile Drawer Fronts, Sand Gloss Backpainted Glass Inserts

Image courtesy of California Closets. All rights reserved.

11

Image courtesy of Simmons & Company.

Image courtesy of Design-Craft, an ACPI brand..

12

Image courtesy of MasterBrand Cabinets.

KITCHEN

The kitchen is often the heart of the home and therefore a true reflection of personal style and preferences.

Element Designs’ aluminum, glass and acrylic products add custom design details that are completely customizable to fit any environment. Our products complement a variety of styles including modern, contemporary, transitional, industrial and more. Our wide variety of frame styles, inserts, metal finishes and hardware solutions help create exceptional spaces.

Image courtesy of Bellmont Cabinetry

13

Image courtesy of Cabico Elmwood Series.

Image courtesy of Paramount Woodworking.

Image courtesy EuroCraft Cabinets.

Image courtesy of of Wellborn Cabinet Inc.

Image courtesy of Plain & Fancy.

14

Image courtesy of Bellmont Cabinet Co.

KITCHEN

Element Designs’ aluminum, glass and acrylic products can be used in a variety of ways in kitchen designs.

Aluminum doors with transparent inserts are an ideal focal point and combine form and function in an aesthetically pleasing way. Our backpainted glass and high gloss solid acrylic products create sleek surfaces for entire kitchens or sections of the room such as islands and base cabinets. Our aluminum frame base systems are a unique structural element that can be easily integrated into islands, cabinet bases and tables.

15

Image courtesy of MasterBrand Cabinets.

Image courtesy of Wellborn Cabinet.

Image courtesy of California Closets. All rights reserved.

16

Image courtesy courtesy of of California California Closets.

Closets. All All rights rights reserved. reserved.


CLOSET

Closets continue to grow in popularity and Element Designs’ cabinet doors, sliding door systems and backpainted glass solutions can help turn an ordinary space into an extraordinary one. A closet is a space where personal style and individuality can really shine through. The addition of quality aluminum glass doors and panels, high gloss solid acrylic doors and drawer fronts and backpainted glass countertops in a variety of colors, finishes and combinations are always the perfect accessory.

17

Image courtesy of of California Closets.

All All rights reserved.

Image courtesy California Closets. rights reserved.

Image courtesy of M. Lahr Homes and Ted Maines Interiors

Image courtesy of Wellborn Cabinet.

18

BATHROOM

Element Designs’ products add beauty and durability to bathrooms. Environments prone to heat and humidity benefit from the waterproof and warp resistant qualities of anodized aluminum, glass and high gloss solid acrylic. Our cabinet doors, backpainted glass surfaces and aluminum frame base systems add design details while providing functional storage and support solutions.

19

Image courtesy of MasterBrand Cabinets.

Image courtesy of California Closets. All rights reserved.

20

Image courtesy of Design-Craft, an ACPI brand..

RESIDENTIAL

Aluminum,

glass

and

acrylic

components

add

contemporary design details to more than just kitchens and bathrooms. Areas which incorporate storage solutions such as living rooms, drop zones, garages and more benefit from the stylish details and durability of our aluminum, glass and acrylic products.

21

Image courtesy of California Closets. All rights reserved.

Image courtesy of GEIGER.

Image courtesy of Halcon.

22

Image courtesy of GEIGER.

OFFICE

Office environments embrace contemporary lines and sleek surfaces. Element Designs’ aluminum doors, backpainted glass and glass markerboard products are the perfect way to integrate simple design elements that help define a space while keeping a minimalist feel. Our backpainted glass custom color matching option is an excellent way to incorporate a specific color scheme into functional products with a long life span and ultimate durability.

23 Image courtesy of OFS, an OFS Brands Company.

24

COMMERCIAL

Element Designs’ products add style and sophistication to commercial environements while providing durable solutions that withstand constant daily use. High gloss solid acrylic doors and drawer fronts are UV resistant so that the vibrant colors will not fade over time in harsh lighting environments. Our glass doors are an obvious choice for display areas where full visibility is needed but added protection is just as important. Custom color matching and etching capabilities are also available to enhance branded retail interiors where details matter.

25

26

COMMERCIAL

Commercial applications often call for designer finishes as well as durability for high traffic areas including conference rooms, healthcare environments and more. Our aluminum, glass and acrylic products are ideal for special applications such as glass markerboards,

customized

backpainted

panels,

unique wall sliding systems, cabinet doors and drawer fronts for commercial spaces. The design possibilities are limitless.

27

.

ยบ 28 28

Aluminum Frame Doors

• Fourteen profile options in twelve finishes • Over fifty insert options • No minimum order quantities • Short lead times • Expedite programs available upon request • Doors arrive fully assembled and ready to install • High quality anodized aluminum • Tempered safety glass • Unlimited design potential • Limited lifetime warranty • Made in the USA

29

aluminum frame doors PROFILE OPTIONS

AF001

AF002

AF003

2 1/8” (54mm)

3/4” (19mm)

AF004 1 3/4” (45mm)

2 1/8” (54mm)

9/16” (14mm)

5/16” (8mm)

13/16” (20.5mm)

13/16” (20.5mm)

Max Dimension: 48” (1219mm)

Max Dimension: 96” (2438mm)

Max Dimension: 96” (2438mm)

Max Dimension: 96” (2438mm)

Min Dimension: 5.5” (140mm)

Min Dimension: 5.5” (140mm)

Min Dimension: 5.5” (140mm)

Min Dimension: 5.5” (140mm)

13/16” (20.5mm)

13/16” (20.5mm)

AF008

AF009

AF010

2 1/2” (63.5mm)

AF011

2 1/8” (54mm)

2 1/4” (57.2mm)

3/4” (19mm) 3/8” (9.5mm)

13/16” (20.5mm)

13/16” (20.5mm)

13/16” (20.5mm)

Max Dimension: 96” (2438mm)

Max Dimension: 96” (2438mm)

Max Dimension: 96” (2438mm)

Max Dimension: 96” (2438mm)

Min Dimension: 5.5” (140mm)

Min Dimension: 6.25” (159mm)

Min Dimension: 5.5” (140mm)

Min Dimension: 5.5” (140mm)

*Only available with opaque

30

Backpainted Glass & Mirror inserts

3/4” (19.05mm)

aluminum frame doors PROFILE OPTIONS Finishes Anodized Natural (N)

Brushed Stainless (S)

Brushed Black (BB)*

AF005

AF006

*Only available in AF003

AF007

Chrome (C)*

2 1/8” (54mm)

1 3/4” (45mm)

*Only available in AF003 & AF010

2 3/4” (70mm)

Coated 13/16” (20.5mm)

13/16” (20.5mm)

13/16” (20.5mm)

Max Dimension: 96” (2438mm)

Max Dimension: 96” (2438mm)

Max Height: 96” (2438mm)

Min Dimension: 5.5” (140mm)

Min Dimension: 5.5” (140mm)

Max Width: 6.75” (171mm)

Onyx (X)

*Only available with opaque Backpainted Glass & Mirror inserts

Black (B)

White (W)

Oil Rubbed Bronze (ORB)

Arctic Silver (AS)

Copper (CP)

AF012*

AF013*

AF014 Luxe Bronze (LB) 2 1/8” (54mm)

Modern Brass (MB) 5/32” (4mm)

Max Dimension: 84” (2134mm)

Max Dimension: 84” (2134mm)

13/16” (20.5mm)

Min Dimension: 5.5” (140mm)

Min Dimension: 5.5” (140mm)

Max Dimension: 96” (2438mm) Min Dimension: 5.5” (140mm)

* Integrated Hinge profile utilizing Salice Air hinges.

31

aluminum frame doors FINISH OPTIONS

Finish Options

Anodized natural aluminum (N)

brushed stainless (S)

chrome* (C)

brushed black (BB)

black (B)

onyx (matte) (X)

white (W)

oil rubbed bronze (ORB)

arctic silver (AS)

copper (CP)

luxe bronze (LB)

modern brass (MB)

Coated

32

aluminum frame doors INSERT OPTIONS

Standard Glass

low-iron clear

low-iron satin

listral d

grey clear (smoked)

bronze clear

clear

satin

reeded

grey reflective

bronze reflective

Element Designs offers over 50 different insert options, all of which are not represented in this catalog, but can be found on our website. Please contact Element Designs for information about additional insert options including high gloss solid acrylic, metal laminates and other custom inserts. For additional non-standard backpainted glass color options see page 47. All inserts can also be purchased as cut-to-size pieces. mirror

33

aluminum frame doors INSERT OPTIONS

Backpainted Glass

white gloss

sand gloss

blush gloss

aqua gloss

slate gloss

white matte

sand matte

blush matte

aqua matte

slate matte

black gloss

arctic silver gloss

bronze gloss

navy gloss

mineral gloss

black matte

acrtic silver matte

bronze matte

navy matte

mineral matte

* See page 47 for Non Standard colors. Custom color matches also available.

34

aluminum frame doors INSERT OPTIONS

3formÂŽ Architectural Resin

struck pure

starcrossed shadow

swept gold

swept silver

strand iron

wisp silver

quattro carbon

thatch

fossil leaf

linea ivory

ensign

mari seamless

weld silver

kathali greys

glint gold

antique brown walrus

grey thunder buffalo

°elusion Backpainted Glass

black BPG with grey clear

white BPG with low-iron satin

dECOLeather

coal buffalo

35

36

Sliding Door Systems

• Sliding door systems for closets, pantries, cabinets and more • Bottom sliding and top hanging systems for variety of large door applications • Available as aluminum frame or high gloss solid acrylic sliding doors • Sliding hardware pre-installed on panels when possible • Sliding door rails and guides available cut-to-length • Twelve aluminum frame styles in twelve finishes • Over fifty insert options • Divider rail in 3/4” profile available • Quick lead times • No minimum orders • Made in the USA

37

sliding doors SYSTEM OPTIONS

CD 50 E Design Guidelines: - Floor Sliding System, top guide and bottom track - Floor to ceiling and inset casework applications - Multiple planes of travel, inset or surface mount track - Accommodates doors weighing up to 110 lbs - Soft close mechanisms available

SH 7035 Design Guidelines: - Small Sliding System, top and bottom track - Multiple planes of travel, inset track only - Compatible with narrow frame profiles

38

sliding doors SYSTEM OPTIONS

DN 80 CF Design Guidelines: - Top Sliding System, top track with floor guides - Floor to ceiling, inset casework, & barn door applications - Recommended for use with one or two planes of travel - Doors weighing up to 176 lbs - Soft close mechanisms available

CD 30 CX Design Guidelines: - Small to medium Sliding System, top and bottom track - Single or by-pass sliding doors, surface mount or inset track.

- Doors weighing up to 66 lbs

39

ยบ 40 40

High Gloss Solid Acrylic Doors

• Mirror-like high gloss finish • Available in a variety of brilliant colors • UV and fade resistant • Impervious to water • Ideal for exterior and harsh weather applications • Easy to maintain and repairable • Environmentally friendly - no VOCs • Free of formaldehyde and plasticizers • Made with recycled material and fully recyclable • Doors arrive fully fabricated and ready to install • 4mm sheets also available (1m x 3m sheet size) • Quick lead times • No minimum order quantities • Proudly made in the USA

41

High Gloss GlossÂŽSolid Solid Acrylic PARAPAN High HighAcrylic Gloss Acrylic

COLOR OPTIONS

alpine white 5910

white 5907

opal white 5196

mint * 5421

kiwi ** 5440

orange * 5570

bordeaux 5600

turquoise 5471

cobalt blue 5380 * Only available in 18mm ** Only available in 4mm

black 5299

42

anthracite * 5297

latte 5772

cappuccino 5773

signal red ** 5655

oxide red 5771

light grey 5290

stone grey 5295

High® PARAPAN

Edge Radius Options Straight Edge

1mm Radius

Gloss Solid Acrylic High Gloss EDGE & PULL OPTIONS

Integrated Pull Option 2mm Radius

3mm Radius

Straight 3 mm

R

=

15 m m

3 mm

18 mm

18 mm

18 mm

18 mm

18 mm

18 mm

• All six surfaces have high gloss finish and are available as finished doors and panels • Functional and decorative hardware borings will be pre-drilled per specification • 4mm solid acrylic panels available in full sheets or cut to size pieces for cabinet cladding and appliance applications (*Anthracite, mint and orange only available in 18mm) • High gloss solid acrylic doors are available with a standard integrated pull option • Please contact Element Designs for material samples, images may not be exact representations of color.

43

44

Backpainted Glass & Markerboards

Backpainted Glass • Custom manufactured to your specifications • Specially formulated water based paint with low VOC content • Furniture quality paint finish with total opacity • Ten standard colors and 177 non-standard colors • Custom colors and metallic colors available • Low-iron glass in 4mm, 6mm, 10mm & 12mm thickness • Available in gloss and matte (acid-etch) finishes • Edge work options include flat edge polish and seamed edges • Tempered glass for safety and strength • Custom etching available • Proudly made in the USA

Glass Markerboards • Magnetic backer option available • Non-staining and non-porous glass surface • Low-iron glass for optimal color clarity • Gloss and writable matte finishes • Durable and safe 4mm or 6mm tempered glass • Easy to maintain and scratch resistant • Easy to install with integrated Z-Clip mounting system • Magnetic glass can be used as inserts in aluminum frame doors • Custom logo and digital image printing available • Proudly made in the USA

45

backpainted glass COLOR, THICKNESS & EDGE OPTIONS

white gloss

sand gloss

blush gloss

aqua gloss

slate gloss

white matte

sand matte

blush matte

aqua matte

slate matte

black gloss

arctic silver gloss

bronze gloss

navy gloss

mineral gloss

black matte

arctic silver matte

bronze matte

navy matte

mineral matte

Edge Finish Options

Flat Edge Polish

Seamed

(unpolioshed edge recommended for concealed edge applications ONLY)

46

Thickness Options

12mm (1/2”)

All thicknesses available in gloss and matte finish

10mm (3/8”)

6mm (1/4”)

4mm (5/32”)

backpainted glass NON-STANDARD COLOR OPTIONS * Previous standard backpainted glass colors *

*

*

*

Printed color swatches may not be an exact color representation. Please order a physical sample for color accuracy.

*

47

backpainted glass NON-STANDARD COLOR OPTIONS

48

Printed color swatches may not be an exact color representation. Please order a physical sample for color accuracy.

backpainted glass NON-STANDARD COLOR OPTIONS

Technical specifications and color availability are subject to change * Custom colors, specialty metallic colors to match aluminum finishes, and other metallic colors also available.

Contact Element Designs for color options.

Printed color swatches may not be an exact color representation. Please order a physical sample for color accuracy.

49

markerboards GLASS OPTIONS

Colors

Finishes

Glass markerboards are available with all of our standard and non-standard colors. Custom color match also available.

Backer Options Markerboards can be manufactured with magnetic or non-magnetic backer option.

Z-clip mounting system is pre-installed on all boards.

MMB Clip

Wall

50

Wall Clip (z-clip)

Metal Backer

4mm BPG Panel

markerboads ACCESSORIES

Accessories Magnetic markerboard accessory kit includes eight rare earth magnets, magnetic pen holder and magnetic eraser in white finish.

Only rare earth magnets should be used with magnetic markerboards to ensure strong magnetic attraction through the glass.

Image courtesy of Geiger.

Image courtesy of Geiger.

51

ยบ 52 52

Aluminum Frame Base Systems

• High quality anodized aluminum base systems • Finishes identical to aluminum frame door program • Structurally rigid construction using 50mm or 30mm extrusion • Simple assembly (arrives fully or partially assembled) • All required assembly tools ship with base systems • Numerous configurations available • No minimum order quantities • Quick lead times • Proudly made in the USA

53

aluminum frame base systems PROFILE & FINISH OPTIONS

Profile Options

BS001

BS002

50mm (1 31/32”)

30mm (1 3/16”)

System Configurations Base systems can be built in standard configurations (below) or custom configurations. Contact Element Designs for details.

Image courtesy of Wellborn Cabinet Inc.

54

aluminum frame base systems SUPPORT OPTIONS & CONFIGURATIONS

Support Options

none unfinished hollow tubing

end cap standard with all base systems

leveling foot 2” diameter metal base with up to 2” height adjustability

caster wheel caster with brake, 2 3/8” diameter nonmarking nylon wheels

Finish Options Anodized

Coated

natural aluminum (N)

black (B)

onyx (matte) (X)

white (W)

oil rubbed bronze (ORB)

brushed stainless (S)

arctic silver (AS)

copper (CP)

luxe bronze (LB)

modern brass (MB)

55

ยบ 56 56

Frameless Glass Doors

• Exclusive U.S. door integration partner for Blum’s CRISTALLO hinge system • CRISTALLO door plates are permanently adhered to glass • Do not require continual adjustment unlike other glass panel hinge systems • 6mm (1/4”) thick glass with flat edge polish • Tempered glass for safety and durability • Additional glass fabrication available • Several transparent glass inserts available • No minimum order quantities • Proudly made in the USA

57

frameless glass doors GLASS OPTIONS

Glass Options

low-iron clear

low-iron satin

clear

satin

grey clear (smoked)

bronze clear

grey reflective

bronze reflective

Image courtesy of California Closets. All rights reserved.

58

frameless glass doors HINGE OPTIONS

Hinge Options • Only available adhered to Element Designs frameless glass doors

• CRISTALLO Hinge with BLUMOTION Soft Close • 110° hinge opening • Hinge restrictor clip also available • TIP-ON for doors also available

Image courtesy of Phil Kean Design Group.

59

60

Decorative & Functional Hardware

Decorative Hardware

• Contemporary decorative hardware • Anodized aluminum knobs and pulls

• Several finishes complement aluminum frame door finishes

GOLA Aluminum Channels • Channels eliminate surface mounted decorative hardware • Several finishes complement standard aluminum frame finishes • Horizontal or vertical applications

Functional Hardware • AVENTOS lift systems by Blum • Aluminum door hinges by Blum and Salice • Soft close technology • TIP-ON for doors by Blum

61

decorative hardware KNOBS & PULLS Knobs not available in stainless finish K001

K005

K006

K007

Bar Pulls

K008

K009

available in all finishes below available in lengths ranging from 5 5/16” to 37”

P1 Series

see website for part numbers and details

Finger Pulls

23/32” (18mm)

1 21/32” (42 mm)

available finishes: - chrome 1 5/8” (41 mm)

Recessed Pulls

flush mount

Length: 3” (2” c. to c.)

19/32” (15mm)

available in all finishes below

Length: 3” (2” c. to c.)

P2-42

surface mount

available in all finishes below

R1-96

Length = 102.5mm (4 1/32”) Width = 37mm (1 15/32”) Depth = 11.5mm (29/64”)

R1-160 Length = 166.5mm (6 9/16”) Width = 37mm (1 15/32”) Depth = 11.5mm (29/64”)

Pull Finishes Anodized Aluminum

natural anodized (N)

62

brushed stainless (S)

Coated

onyx (matte) (X)

black (B)

white (W)

oil rubbed bronze (ORB)

arctic silver (AS)

copper (CP)

luxe bronze (LB)

modern brass (MB)

decorative decorative hardware hardware GOLA CHANNELS Horizontal Channels

8006 J-Channel

8007 C-Channel

1730 Upper

1 1/32” (26 mm)

1 5/64” (27.2mm)

19.6 mm 25/32”

18 mm 45/64”

2 7/8” (73 mm)

2 7/32” (56.5 mm)

20.8 mm 13/16”

3 mm 1/8”

8 mm 5/16”

Visit our website to see GOLA end caps and connectors for J & C-Channels

Vertical Channels

8059 Double Channel

8074 Single Channel

1/2” (12 mm)

1 29/64” (37 mm)

1/2” (12 mm)

1 29/64” (37 mm)

1 29/32” (48.3 mm)

2 5/8” (66.2 mm)

GOLA Finishes Anodized Aluminum

stainless nickel (SN)

Coated

stainless bronze (SB)

onyx (matte) (X)

clear anodized (N)

arctic silver (AS)

black (B)

white (W)

oil rubbed bronze (ORB)

copper (CP)

luxe bronze (LB)

modern brass (MB)

63

functional functional hardware hardware AVENTOS LIFT SYSTEMS

System Options

AVENTOS HF - Bi-Fold Two part door front that folds in the center when opening

AVENTOS HK - Stay Lift Single door front that lifts upward; uses cabinet side lift mechanism

AVENTOS HK-S - Stay Lift Single door front that lifts smaller doors upward; uses cabinet side lift mechanism

64

AVENTOS HL - Lift Up Single door front that lifts up parallel to the cabinet

AVENTOS HS - Up and Over Single door front that swings over the top of the cabinet

AVENTOS HK-Top - Stay Lift Single door front that lifts upward; uses easy install cabinet side lift mechanism

Blum AVENTOS lift hardware offers a wide variety of door opening options to suit many design needs. The HK systems lift the door up and open with ease. The HK Top hardware makes installation quick and easy by lining up the lift hardware with the top of the cabinet box, no measuring needed.

AVENTOS HK-XS - Stay Lift Single door front that lifts upward; uses hinges and cabinet side lift mechanism

Element Designs also provides support for ordering AVENTOS hardware through our online ordering portal, to ensure correct parts are included with each order and doors are drilled correctly depending on your cabinet construction and overlay.

functional hardware HINGES & LOCKS

Narrow Frame Hinges

BLUMOTION Blum® narrow frame hinge straight arm, 95°, 15mm overlay, soft close with deactivation switch

Blum® narrow frame hinge straight arm, 120°, 15mm overlay, self close

Blum® narrow frame hinge straight arm, 95°, 17mm overlay, self close

Blum® 35mm cup hinge: straight arm, 120°, self close

Blum® 35mm cup hinge: onyx finish, straight arm, 120°, soft close

Wide Frame Hinges

BLUMOTION Blum® 35mm cup hinge: straight arm, 110°, soft close with deactivation switch

Salice AIR Hinges

Salice AIR Hinge push-to-open, free-swing Nickel (Shown) or Titanium Finish *Magnetic push hardware included with push-to-open hinges

Locks

Salice AIR Hinge soft-close Nickel or Titanium (Shown) Finish

Cam Lock standard keyed cam lock Contact Element Designs for additional lock availability.

65

sustainability “Aluminum’s inherently sustainable characteristics combined with the extrusion process make extruded aluminum the green building industry’s material choice for now and the future.”

Reprinted with permission from the Aluminum Extruders Council Recycled Content All of our glass inserts contain at least 20% post industrial recycled content and the architectural resin uses a high percentage of post industrial material.

Regional Suppliers Our products are manufactured with materials from regional suppliers thus reducing our carbon footprint.

Exceptional Durability Our aluminum products have an extremely long life time and are virtually maintenance free.

No VOCs Our aluminum, glass and acrylic products do not contain VOCs. Because no chemicals or toxins are released from our products, there is zero effect on indoor air quality. Our backpainted glass utilizes water based paint which is low in VOCs and is safe for the environment.

Post Industrial Waste Recycling All of the waste generated during our manufacturing operations (primary materials such as aluminum and glass) is recycled. The aluminum extrusion is taken to a local metal recycling facility. Unusable glass is reused in asphalt production.

Recyclability and Reusability Our aluminum, glass and acrylic materials are completely recyclable. Our aluminum doors can be reused rather than discarded by simply replacing components (new inserts for existing doors).

Reclamation We offer a recycling service for all of our products once their useful life expires. Send your product back to us to be completely and properly recycled.

Packaging Materials Our corrugated edge wrapping, which protects our products in transit, is made of 100% recycled cardboard and our corrugated boxes have a high recycled content.

Company Recycling Both our company and our employees divert waste from our landfills whenever possible.

We recycle all cans, glass and plastic bottles, office paper, paper products and cardboard at our manufacturing facility in Charlotte, NC, thus reducing our carbon footprint. We actively promote the importance of environmental responsibility and are proud to sponsor a recycling center for our industrial park.

66

photography credits

We would like to thank our customers for use of their images :

Please visit our website for additional design details and product information:

www.element-designs.com Samples may be obtained from our online sample store:

http://store.element-designs.com Element Designs 235 Crompton St. Charlotte, NC 28273 Ph: 877-332-3396 info@element-designs.com

Proudly Made in the USA

67

v. 7.19

ÂŽ

www.element-designs.com
