MECHATRONICS MECHATRONICS ELECTRONIC CONTROL SYSTEMS IN MECHANICAL ELECTRONIC CONTROL SYSTEMS IN MECHANICAL AND ELECTRICAL ENGINEERING AND ELECTRICAL ENGINEERING

WILLIAM BOLTON WILLIAM BOLTON

SEVENTH EDITION SEVENTH EDITION

M E C H AT RO N I C S

F01 Mechatronics 50977 Contents.indd 1

30/08/2018 07:09

At Pearson, we have a simple mission: to help people make more of their lives through learning.

We combine innovative learning technology with trusted content and educational expertise to provide engaging and effective learning experiences that serve people wherever and whenever they are learning.

From classroom to boardroom, our curriculum materials, digital learning tools and testing programmes help to educate millions of people worldwide – more than any other private enterprise.

Every day our work helps learning flourish, and wherever learning flourishes, so do people.

To learn more, please visit us at www.pearson.com/uk

F01 Mechatronics 50977 Contents.indd 2

30/08/2018 07:09

MECHATRONICS ELECTRONIC CONTROL SYSTEMS IN MECHANICAL AND ELECTRICAL ENGINEERING

Seventh Edition

William Bolton

Harlow, England • London • New York • Boston • San Francisco • Toronto • Sydney Dubai • Singapore • Hong Kong • Tokyo • Seoul • Taipei • New Delhi Cape Town • São Paulo • Mexico City • Madrid • Amsterdam • Munich • Paris • Milan

F01 Mechatronics 50977 Contents.indd 3

30/08/2018 07:09

Pearson Education Limited KAO Two KAO Park Harlow CM17 9NA United Kingdom Tel: +44 (0)1279 623623 Web: www.pearson.com/uk First published 1995 (print) Second edition published 1999 (print) Third edition published 2003 (print) Fourth edition published 2008 (print) Fifth edition published 2011 (print and electronic) Sixth edition published 2015 (print and electronic) Seventh edition published 2019 (print and electronic) © Pearson Education Limited 2015, 2019 (print and electronic) The right of William Bolton to be identified as author of this work has been asserted by him in accordance with the Copyright, Designs and Patents Act 1988.

The print publication is protected by copyright. Prior to any prohibited reproduction, storage in a retrieval system, distribution or transmission in any form or by any means, electronic, mechanical, recording or otherwise, permission should be obtained from the publisher or, where applicable, a licence permitting restricted copying in the United Kingdom should be obtained from the Copyright Licensing Agency Ltd, Barnard’s Inn, 86 Fetter Lane, London EC4A 1EN. The ePublication is protected by copyright and must not be copied, reproduced, transferred, distributed, leased, licensed or publicly performed or used in any way except as specifically permitted in writing by the publishers, as allowed under the terms and conditions under which it was purchased, or as strictly permitted by applicable copyright law. Any unauthorised distribution or use of this text may be a direct infringement of the author’s and the publisher’s rights and those responsible may be liable in law accordingly.

All trademarks used herein are the property of their respective owners. The use of any trademark in this text does not vest in the author or publisher any trademark ownership rights in such trademarks, nor does the use of such trademarks imply any affiliation with or endorsement of this book by such owners.

Pearson Education is not responsible for the content of third-party internet sites.

ISBN:

978-1-292-25097-7 (print) 978-1-292-25100-4 (PDF) 978-1-292-25099-1 (ePub)

British Library Cataloguing-in-Publication Data A catalogue record for the print edition is available from the British Library Library of Congress Cataloging-in-Publication Data Names: Bolton, W. (William), 1933- author.

Title: Mechatronics : electronic control systems in mechanical and electrical engineering / William Bolton.

Description: Seventh edition. | Harlow, England ; New York : Pearson Education Limited, 2019. | Includes bibliographical references and index.

Identifiers: LCCN 2018029322| ISBN 9781292250977 (print) | ISBN 9781292251004 (pdf) | ISBN 9781292250991 (epub) Subjects: LCSH: Mechatronics.

Classification: LCC TJ163.12 .B65 2019 | DDC 621—dc23 LC record available at https://urldefense.proofpoint.com/v2/url?u=https-3A__lccn.loc.gov_2018029322&d=DwIFAg&c=0YLnzTkW OdJlub_y7qAx8Q&r=eK0q0-QqUPIJD1OLTc7YiWdHxmNowNBMcvK9N3XeA-U&m=KkECpIRxvUd6hHO4IgYQ39O8Wnj16yu FhTNaAb0czTk&s=d_M15Lwv7uWaxVKsm14kfkQ5Quu9-ZHwFQvuouRdve8&e= 10 23

9 8 7 6 5 4 22 21 20 19

3

2

1

Print edition typeset in 10/11 pt Ehrhardt MT Pro by Pearson CSC Printed and bound in Malaysia NOTE THAT ANY PAGE CROSS REFERENCES REFER TO THE PRINT EDITION

F01 Mechatronics 50977 Contents.indd 4

30/08/2018 07:09

Contents

Preface

xi

3. Signal conditioning

I. Introduction

1

1. Introducing mechatronics

3

3.1 3.2 3.3 3.4 3.5 3.6 3.7 3.8

Chapter objectives What is mechatronics?

The design process Systems Measurement systems Control systems Programmable logic controller Examples of mechatronic systems Summary Problems

3 3 5 6 8 9 21 22 26 27

II. Sensors and signal conditioning

29

2. Sensors and transducers

31

Chapter objectives 2.1 Sensors and transducers 2.2 Performance terminology 2.3 Displacement, position and proximity 2.4 Velocity and motion 2.5 Force 2.6 Fluid pressure 2.7 Liquid flow 2.8 Liquid level 2.9 Temperature 2.10 Light sensors 2.11 Selection of sensors 2.12 Inputting data by switches Summary Problems

31 31 32 37 54 57 57 61 62 63 69 70 71 74 75

1.1 1.2 1.3 1.4 1.5 1.6 1.7

F01 Mechatronics 50977 Contents.indd 5

Chapter objectives Signal conditioning The operational amplifier Protection Filtering Wheatstone bridge Pulse modulation Problems with signals Power transfer Summary Problems

4. Digital signals Chapter objectives 4.1 Digital signals 4.2 Analogue and digital signals 4.3 Digital-to-analogue and analogue-to-digital converters 4.4 Multiplexers 4.5 Data acquisition 4.6 Digital signal processing 4.7 Digital signal communications Summary Problems

5. Digital logic

5.1 5.2 5.3 5.4

Chapter objectives Digital logic Logic gates Applications of logic gates Sequential logic Summary Problems

78 78 78 79 90 91 92 97 98 100 101 101

103 103 103 103 107 113 114 116 118 119 120

121 121 121 122 130 135 143 143

30/08/2018 07:09

vi

CONTENTS

6. Data presentation systems

146

Chapter objectives Displays Data presentation elements Magnetic recording Optical recording Displays Data acquisition systems Measurement systems Testing and calibration Summary Problems

146 146 147 152 157 157 162 166 169 171 172

6.1 6.2 6.3 6.4 6.5 6.6 6.7 6.8

III. Actuation

175

7. Pneumatic and hydraulic actuation systems

177

Chapter objectives Actuation systems Pneumatic and hydraulic systems Directional control valves Pressure control valves Cylinders Servo and proportional control valves Process control valves Summary Problems

177 177 177 181 186 188 192 193 198 198

7.1 7.2 7.3 7.4 7.5 7.6 7.7

8. Mechanical actuation systems

201

Chapter objectives Mechanical systems Types of motion Kinematic chains Cams Gears Ratchet and pawl Belt and chain drives Bearings Electromechanical linear actuators Summary Problems

201 201 202 204 208 210 214 214 216 218 219 220

8.1 8.2 8.3 8.4 8.5 8.6 8.7 8.8 8.9

F01 Mechatronics 50977 Contents.indd 6

9. Electrical actuation systems

222

Chapter objectives Electrical systems Mechanical switches Solid-state switches Solenoids Direct current motors Alternating current motors Stepper motors Direct current servomotors Motor selection Summary Problems

222 222 222 224 231 232 241 243 250 251 255 255

IV. Microprocessor systems

257

10. Microprocessors and microcontrollers

259

9.1 9.2 9.3 9.4 9.5 9.6 9.7 9.8 9.9

Chapter objectives 10.1 Control 10.2 Microprocessor systems 10.3 Microcontrollers 10.4 Applications 10.5 Programming Summary Problems

259 259 259 270 296 297 300 300

11. Assembly language

301

Chapter objectives 11.1 Languages 11.2 Assembly language programs 11.3 Instruction sets 11.4 Subroutines 11.5 Look-up tables 11.6 Embedded systems Summary Problems

12. C language Chapter objectives 12.1 Why C? 12.2 Program structure

301 301 302 304 317 321 324 327 328

329 329 329 329

30/08/2018 07:09

vii

CONTENTS

12.3 12.4 12.5 12.6 12.7 12.8

Branches and loops Arrays Pointers Program development Examples of programs Arduino programs Summary Problems

336 340 342 343 345 348 352 352

13. Input/output systems

354

Chapter objectives Interfacing Input/output addressing Interface requirements Peripheral interface adapters Serial communications interface Examples of interfacing Summary Problems

354 354 355 357 364 369 372 380 380

14. Programmable logic controllers

382

13.1 13.2 13.3 13.4 13.5 13.6

Chapter objectives 14.1 Programmable logic controller 14.2 Basic PLC structure 14.3 Input/output processing 14.4 Ladder programming 14.5 Instruction lists 14.6 Latching and internal relays 14.7 Sequencing 14.8 Timers and counters 14.9 Shift registers 14.10 Master and jump controls 14.11 Data handling 14.12 Analogue input/output Summary Problems

15. Communication systems Chapter objectives Digital communications Centralised, hierarchical and distributed control 15.3 Networks 15.4 Protocols

15.1 15.2

F01 Mechatronics 50977 Contents.indd 7

382 382 382 386 387 391 394 396 397 400 401 402 404 406 407

409 409 409 409 412 414

15.5 Open Systems Interconnection communication model 15.6 Serial communication interfaces 15.7 Parallel communication interfaces 15.8 Wireless communications Summary Problems

16. Fault finding Chapter objectives 16.1 Fault-detection techniques 16.2 Watchdog timer 16.3 Parity and error coding checks 16.4 Common hardware faults 16.5 Microprocessor systems 16.6 Evaluation and simulation 16.7 PLC systems Summary Problems

415 418 427 430 431 432

433 433 433 434 435 437 438 441 442 445 445

V. System models

447

17. Basic system models

449

Chapter objectives 17.1 Mathematical models 17.2 Mechanical system building blocks 17.3 Electrical system building blocks 17.4 Fluid system building blocks 17.5 Thermal system building blocks Summary Problems

18. System models Chapter objectives 18.1 Engineering systems 18.2 Rotational–translational systems 18.3 Electromechanical systems 18.4 Linearity 18.5 Hydraulic–mechanical systems Summary Problems

449 449 450 458 462 469 472 473

475 475 475 475 476 479 481 484 484

30/08/2018 07:09

viii

CONTENTS

19. Dynamic responses of systems

485

Chapter objectives 19.1 Modelling dynamic systems 19.2 Terminology 19.3 First-order systems 19.4 Second-order systems 19.5 Performance measures for second-order systems 19.6 System identification Summary Problems

20. System transfer functions Chapter objectives 20.1 The transfer function 20.2 First-order systems 20.3 Second-order systems 20.4 Systems in series 20.5 Systems with feedback loops 20.6 Effect of pole location on transient response Summary Problems

485 485 486 488 494 501 504 505 506

509 509 509 512 514 516 517 519 522 522

21. Frequency response

524

Chapter objectives 21.1 Sinusoidal input 21.2 Phasors 21.3 Frequency response 21.4 Bode plots 21.5 Performance specifications 21.6 Stability Summary Problems

524 524 525 527 530 539 541 543 544

22. Closed-loop controllers

546

Chapter objectives 22.1 Control processes 22.2 Two-step or on/off mode 22.3 Proportional mode of control 22.4 Integral mode of control 22.5 Derivative mode of control 22.6 PID controller 22.7 Digital control systems

546 546 548 550 552 555 557 559

F01 Mechatronics 50977 Contents.indd 8

22.8 Controller tuning 22.9 Velocity control 22.10 Adaptive control Summary Problems

23. Artificial intelligence Chapter objectives 23.1 What is meant by artificial intelligence?

23.2 Perception and cognition 23.3 Fuzzy logic Summary Problems

564 566 567 569 569

571 571 571 572 575 585 586

VI. Conclusion

587

24. Mechatronic systems

589

Chapter objectives 24.1 Mechatronic designs 24.2 Robotics 24.3 Case studies Summary Problems Research assignments Design assignments

589 589 600 606 625 625 625 625

Appendices

627

A The Laplace transform

629

A.1 A.2 A.3 A.4

The Laplace transform Unit steps and impulses Standard Laplace transforms The inverse transform Problems

B Number systems B.1 B.2 B.3 B.4

Number systems Binary mathematics Floating numbers Gray code Problems

629 630 632 636 638

639 639 640 643 643 644

30/08/2018 07:09

ix

CONTENTS

C Boolean algebra C.1 Laws of Boolean algebra C.2 De Morgan’s laws C.3 Boolean function generation from truth tables

F01 Mechatronics 50977 Contents.indd 9

645 645 646 647

C.4 Karnaugh maps Problems

649 652

Answers Index

654 669

30/08/2018 07:09

F01 Mechatronics 50977 Contents.indd 10

30/08/2018 07:09

Preface

The term mechatronics was ‘invented’ by a Japanese engineer in 1969, as a combination of ‘mecha’ from mechanisms and ‘tronics’ from electronics. The word now has a wider meaning, being used to describe a philosophy in engineering technology in which there is a co-ordinated, and concurrently developed, integration of mechanical engineering with electronics and intelligent computer control in the design and manufacture of products and processes.

As a result, many products which used to have mechanical functions have had many replaced with ones involving microprocessors. This has resulted in much greater flexibility, easier redesign and reprogramming, and the ability to carry out automated data collection and reporting.

A consequence of this approach is the need for engineers and technicians to adopt an interdisciplinary and integrated approach to engineering. Thus engineers and technicians need skills and knowledge that are not confined to a single subject area. They need to be capable of operating and communicating across a range of engineering disciplines and linking with those having more specialised skills. This book is an attempt to provide a basic background to mechatronics and provide links through to more specialised skills.

The first edition was designed to cover the Business and Technology Education Council (BTEC) Mechatronics units for Higher National Certificate/ Diploma courses for technicians and designed to fit alongside more specialist units such as those for design, manufacture and maintenance determined by the application area of the course. The book was widely used for such courses and has also found use in undergraduate courses in both Britain and the United States. Following feedback from lecturers in both Britain and the United States, the second edition was considerably extended and with its extra depth it was not only still relevant for its original readership, but also suitable for undergraduate courses. The third edition involved refinements of some explanations, more discussion of microcontrollers and programming, increased use of models for mechatronic systems, and the grouping together of key facts in the Appendices. The fourth edition was a complete reconsideration of all aspects of the text, both layout and content, with some regrouping of topics, movement of more material into Appendices to avoid disrupting the flow of the text, new material – in particular an introduction to artificial intelligence – more case studies and a refinement of some topics to improve clarity.

Also, objectives and key point summaries were included with each chapter.

The fifth edition kept the same structure but, after consultation with many users of the book, many aspects had extra detail and refinement added.

The sixth edition involved a restructuring of the constituent parts of the book as some users felt that the chapter sequencing did not match the general teaching sequence. Other changes included the inclusion of material on

F01 Mechatronics 50977 Contents.indd 11

30/08/2018 07:09

xii

PREFACE

Arduino and the addition of more topics in the Mechatronic systems chapter.

The seventh edition has continued the evolution of the book with updating of mechatronic system components, clarification of some aspects so they read more easily, the inclusion of information on the Atmega microcontrollers, a discussion and examples of fuzzy logic and neural control systems, and yet more applications and case studies. The number of Appendices has been reduced as they had grown over previous editions and it was felt that some were now little used. A revised and extended version of the Appendix concerning electrical circuit analysis has ben moved to the Instructor’s Guide as Supporting material: Electrical components and circuits, and so is available to an instructor for issue to students if required.

The overall aim of the book is to give a comprehensive coverage of mechatronics which can be used with courses for both technicians and undergraduates in engineering and, hence, to help the reader: • acquire a mix of skills in mechanical engineering, electronics and computing which is necessary if he/she is to be able to comprehend and design mechatronic systems; • become capable of operating and communicating across the range of engineering disciplines necessary in mechatronics; • be capable of designing mechatronic systems.

Each chapter of the book includes objectives and a summary, is copiously illustrated and contains problems, answers to which are supplied at the end of the book. Chapter 24 comprises research and design assignments together with clues as to their possible answers.

The structure of the book is as follows: • • • • • •

Chapter 1 is a general introduction to mechatronics.

Chapters 2–6 form a coherent block on sensors and signal conditioning.

Chapters 7–9 cover actuators.

Chapters 10–16 discuss microprocessor/microcontroller systems.

Chapters 17–23 are concerned with system models.

Chapter 24 provides an overall conclusion in considering the design of mechatronic systems.

An Instructor’s Guide, test material and PowerPoint slides are available for lecturers to download at: www.pearsoned.co.uk/bolton.

A large debt is owed to the publications of the manufacturers of the equipment referred to in the text. I would also like to thank those reviewers who painstakingly read through through the sixth edition and my proposals for this new edition and made suggestions for improvement.

W. Bolton

F01 Mechatronics 50977 Contents.indd 12

30/08/2018 07:09

Part I Introduction

M01 Mechatronics 50977.indd 1

30/08/2018 10:55

M01 Mechatronics 50977.indd 2

30/08/2018 10:55

Chapter one

Introducing mechatronics

Objectives The objectives of this chapter are that, after studying it, the reader should be able to: • Explain what is meant by mechatronics and appreciate its relevance in engineering design.

• Explain what is meant by a system and define the elements of measurement systems.

• Describe the various forms and elements of open-loop and closed-loop control systems.

• Recognise the need for models of systems in order to predict their behaviour.

1.1

M01 Mechatronics 50977.indd 3

What is mechatronics?

The term mechatronics was ‘invented’ by a Japanese engineer in 1969, as a combination of ‘mecha’ from mechanisms and ‘tronics’ from electronics. The word now has a wider meaning, being used to describe a philosophy in engineering technology in which there is a co-ordinated, and concurrently developed, integration of mechanical engineering with electronics and intelligent computer control in the design and manufacture of products and processes. As a result, mechatronic products have many mechanical functions replaced with electronic ones. This results in much greater flexibility, easy redesign and reprogramming, and the ability to carry out automated data collection and reporting.

A mechatronic system is not just a marriage of electrical and mechanical systems and is more than just a control system; it is a complete integration of all of them in which there is a concurrent approach to the design. In the design of cars, robots, machine tools, washing machines, cameras and very many other machines, such an integrated and interdisciplinary approach to engineering design is increasingly being adopted. The integration across the traditional boundaries of mechanical engineering, electrical engineering, electronics and control engineering has to occur at the earliest stages of the design process if cheaper, more reliable, more flexible systems are to be developed. Mechatronics has to involve a concurrent approach to these disciplines rather than a sequential approach of developing, say, a mechanical system, then designing the electrical part and the microprocessor part. Thus mechatronics is a design philosophy, an integrating approach to engineering.

Mechatronics brings together areas of technology involving sensors and measurement systems, drive and actuation systems, and microprocessor systems (Figure 1.1), together with the analysis of the behaviour of systems and control systems. That essentially is a summary of this book. This chapter is an introduction to the topic, developing some of the basic concepts in order to give a framework for the rest of the book in which the details will be developed.

30/08/2018 10:55

4

CHAPTER 1 INTRODUCING MECHATRONICS

Figure 1.1 The basic elements

Digital actuators

of a mechatronic system.

Digital sensors Mechanical system

Analogue actuators

Analogue sensors

Microprocessor system for control

1.1.1

Examples of mechatronic systems

Consider the modern autofocus, auto-exposure camera. To use the camera all you need to do is point it at the subject and press the button to take the picture.

The camera can automatically adjust the focus so that the subject is in focus and automatically adjust the aperture and shutter speed so that the correct exposure is given. You do not have to manually adjust focusing and the aperture or shutter speed controls. Consider a truck’s smart suspension. Such a suspension adjusts to uneven loading to maintain a level platform, adjusts to cornering, moving across rough ground, etc., to maintain a smooth ride. Consider an automated production line. Such a line may involve a number of production processes which are all automatically carried out in the correct sequence and in the correct way with a reporting of the outcomes at each stage in the process. The automatic camera, the truck suspension and the automatic production line are examples of a marriage between electronics, control systems and mechanical engineering.

1.1.2

Embedded systems

The term embedded system is used where microprocessors are embedded into systems and it is this type of system we are generally concerned with in mechatronics. A microprocessor may be considered as being essentially a collection of logic gates and memory elements that are not wired up as individual components but whose logical functions are implemented by means of software. As an illustration of what is meant by a logic gate, we might want an output if input A AND input B are both giving on signals. This could be implemented by what is termed an AND logic gate. An OR logic gate would give an output when either input A OR input B is on. A microprocessor is thus concerned with looking at inputs to see if they are on or off, processing the results of such an interrogation according to how it is programmed, and then giving outputs which are either on or off. See Chapter 10 for a more detailed discussion of microprocessors.

For a microprocessor to be used in a control system, it needs additional chips to give memory for data storage and for input/output ports to enable it to process signals from and to the outside world. Microcontrollers are microprocessors with these extra facilities all integrated together on a single chip.

An embedded system is a microprocessor-based system that is designed to control a range of functions and is not designed to be programmed by the end user in the same way that a computer is. Thus, with an embedded system, the user cannot change what the system does by adding or replacing software.

M01 Mechatronics 50977.indd 4

30/08/2018 10:55

1.2 THE DESIGN PROCESS

5

As an illustration of the use of microcontrollers in a control system, a modern washing machine will have a microprocessor-based control system to control the washing cycle, pumps, motor and water temperature. A modern car will have microprocessors controlling such functions as anti-lock brakes and engine management. Other examples of embedded systems are digital cameras, smart cards (credit-card-sized plastic cards embedded with a microprocessor able to store and process data), mobile phones (their SIM cards are just smart cards able to manage the rights of a subscriber on a network), printers, televisions, temperature controllers and indeed almost all the modern devices we have grown so accustomed to use to exercise control over situations.

1.2

The design process

The design process for any system can be considered as involving a number of stages.

1 The need The design process begins with a need from, perhaps, a customer or client.

This may be identified by market research being used to establish the needs of potential customers.

2 Analysis of the problem The first stage in developing a design is to find out the true nature of the problem, i.e. analysing it. This is an important stage in that not defining the problem accurately can lead to wasted time on designs that will not fulfil the need.

3 Preparation of a specification Following the analysis, a specification of the requirements can be prepared. This will state the problem, any constraints placed on the solution, and the criteria which may be used to judge the quality of the design. In stating the problem, all the functions required of the design, together with any desirable features, should be specified. Thus there might be a statement of mass, dimensions, types and range of motion required, accuracy, input and output requirements of elements, interfaces, power requirements, operating environment, relevant standards and codes of practice, etc.

4 Generation of possible solutions This is often termed the conceptual stage. Outline solutions are prepared which are worked out in sufficient detail to indicate the means of obtaining each of the required functions, e.g. approximate sizes, shapes, materials and costs. It also means finding out what has been done before for similar problems; there is no sense in reinventing the wheel.

5 Selections of a suitable solution The various solutions are evaluated and the most suitable one selected.

Evaluation will often involve the representation of a system by a model and then simulation to establish how it might react to inputs.

6 Production of a detailed design The detail of the selected design has now to be worked out. This might require the production of prototypes or mock-ups in order to determine the optimum details of a design.

M01 Mechatronics 50977.indd 5

30/08/2018 10:55

6

CHAPTER 1 INTRODUCING MECHATRONICS

7 Production of working drawings The selected design is then translated into working drawings, circuit diagrams, etc., so that the item can be made.

It should not be considered that each stage of the design process just flows on stage by stage. There will often be the need to return to an earlier stage and give it further consideration. Thus, at the stage of generating possible solutions there might be a need to go back and reconsider the analysis of the problem.

1.2.1

Traditional and mechatronic designs

Engineering design is a complex process involving interactions between many skills and disciplines. With traditional design, the approach was for the mechanical engineer to design the mechanical elements, then the control engineer to come along and design the control system. This gives what might be termed a sequential approach to the design. However, the basis of the mechatronics approach is considered to lie in the concurrent inclusion of the disciplines of mechanical engineering, electronics, computer technology and control engineering in the approach to design. The inherent concurrency of this approach depends very much on system modelling and then simulation of how the model reacts to inputs and hence how the actual system might react to inputs.

As an illustration of how a multidisciplinary approach can aid in the solution of a problem, consider the design of bathroom scales. Such scales might be considered only in terms of the compression of springs and a mechanism used to convert the motion into rotation of a shaft and hence movement of a pointer across a scale; a problem that has to be taken into account in the design is that the weight indicated should not depend on the person’s position on the scales.

However, other possibilities can be considered if we look beyond a purely mechanical design. For example, the springs might be replaced by load cells with strain gauges and the output from them used with a microprocessor to provide a digital readout of the weight on an light-emitting diode (LED) display. The resulting scales might be mechanically simpler, involving fewer components and moving parts. The complexity has, however, been transferred to the software.

As a further illustration, the traditional design of the temperature control for a domestic central heating system has been the bimetallic thermostat in a closed-loop control system. The bending of the bimetallic strip changes as the temperature changes and is used to operate an on/off switch for the heating system. However, a multidisciplinary solution to the problem might be to use a microprocessor-controlled system employing perhaps a thermistor as the sensor. Such a system has many advantages over the bimetallic thermostat system. The bimetallic thermostat is comparatively crude and the temperature is not accurately controlled; also, devising a method for having different temperatures at different times of the day is complex and not easily achieved. The microprocessor-controlled system can, however, cope easily with giving precision and programmed control. The system is much more flexible. This improvement in flexibility is a common characteristic of mechatronic systems when compared with traditional systems.

1.3

M01 Mechatronics 50977.indd 6

Systems

In designing mechatronic systems, one of the steps involved is the creation of a model of the system so that predictions can be made regarding its behaviour when inputs occur. Such models involve drawing block diagrams to represent

30/08/2018 10:55

7

1.3 SYSTEMS Figure 1.2 Examples of

systems: (a) spring, (b) motor, (c) thermometer.

Input: force

Spring

Output:

Input:

extension

electric power

(a)

Input: temp.

Thermometer

Motor

Output: rotation

(b)

Output: number on a scale

(c)

systems. A system can be thought of as a box or block diagram which has an input and an output and where we are concerned not with what goes on inside the box, but with only the relationship between the output and the input. The term modelling is used when we represent the behaviour of a real system by mathematical equations, such equations representing the relationship between the inputs and outputs from the system. For example, a spring can be considered as a system to have an input of a force F and an output of an extension x (Figure 1.2(a)). The equation used to model the relationship between the input and output might be F = kx, where k is a constant. As another example, a motor may be thought of as a system which has as its input electric power and as output the rotation of a shaft (Figure 1.2(b)).

A measurement system can be thought of as a box which is used for making measurements. It has as its input the quantity being measured and its output the value of that quantity. For example, a temperature measurement system, i.e. a thermometer, has an input of temperature and an output of a number on a scale (Figure 1.2(c)).

1.3.1

Modelling systems

The response of any system to an input is not instantaneous. For example, for the spring system described by Figure 1.2(a), though the relationship between the input, force F, and output, extension x, was given as F = kx, this only describes the relationship when steady-state conditions occur. When the force is applied it is likely that oscillations will occur before the spring settles down to its steady-state extension value (Figure 1.3). The responses of systems are functions of time. Thus, in order to know how systems behave when there are inputs to them, we need to devise models for systems which relate the output to the input so that we can work out, for a given input, how the output will vary with time and what it will settle down to.

As another example, if you switch on a kettle it takes some time for the water in the kettle to reach boiling point (Figure 1.4). Likewise, when a Figure 1.3 The response to an Input: force at time 0

Spring

Output: extension which changes with time

Extension

input for a spring.

Final reading

0

M01 Mechatronics 50977.indd 7

Time

30/08/2018 10:55

8

CHAPTER 1 INTRODUCING MECHATRONICS

Figure 1.4 The response to an

input for a kettle system.

electricity

1008C Kettle

Output: temperature of water

Temperature

Input:

208C

0

2 min Time

Figure 1.5 An automobile

driving system.

Input: force on pedal

Accelerator pedal

Fuel

Automobile engine

Output: speed along road

microprocessor controller gives a signal to, say, move the lens for focusing in an automatic camera, then it takes time before the lens reaches its position for correct focusing.

Often the relationship between the input and output for a system is described by a differential equation. Such equations and systems are discussed in Chapter 17.

1.3.2

Connected systems

In other than the simplest system, it is generally useful to consider the system as a series of interconnected blocks, each such block having a specific function.

We then have the output from one block becoming the input to the next block in the system. In drawing a system in this way, it is necessary to recognise that lines drawn to connect boxes indicate a flow of information in the direction indicated by an arrow and not necessarily physical connections. An example of such a connected system is the driving system of an automobile. We can think of there being two interconnected blocks: the accelerator pedal which has an input of force applied by a foot to the accelerator pedal system and controls an output of fuel, and the engine system which has an input of fuel and controls an output of speed along a road (Figure 1.5). Another example of such a set of connected blocks is given in the next section on measurement systems.

1.4

Measurement systems

Of particular importance in any discussion of mechatronics are measurement systems. Measurement systems can, in general, be considered to be made up of three basic elements (as illustrated in Figure 1.6): 1 A sensor responds to the quantity being measured by giving as its output a signal which is related to the quantity. For example, a thermocouple is a temperature sensor. The input to the sensor is a temperature and the output is an e.m.f., which is related to the temperature value.

2 A signal conditioner takes the signal from the sensor and manipulates it into a condition which is suitable either for display or, in the case of a control system, for use to exercise control. Thus, for example, the output from a

M01 Mechatronics 50977.indd 8

30/08/2018 10:55

9

1.5 CONTROL SYSTEMS Figure 1.6 A measurement

system and its constituent elements.

Figure 1.7 A digital thermometer

system.

Quantity being measured

Quantity being measured: temperature

Sensor

Sensor

Signal related to quantity measured

Signal related to quantity measured: potential difference

Signal conditioner

Amplifier

Signal in suitable form for display

Signal in suitable form for display: bigger voltage

Display

Display

Value of the quantity

Value of the quantity

thermocouple is a rather small e.m.f. and might be fed through an amplifier to obtain a bigger signal. The amplifier is the signal conditioner.

3 A display system displays the output from the signal conditioner. This might, for example, be a pointer moving across a scale or a digital readout.

As an example, consider a digital thermometer (Figure 1.7). This has an input of temperature to a sensor, probably a semiconductor diode. The potential difference across the sensor is, at constant current, a measure of the temperature. This potential difference is then amplified by an operational amplifier to give a voltage which can directly drive a display. The sensor and operational amplifier may be incorporated on the same silicon chip.

Sensors are discussed in Chapter 2 and signal conditioners in Chapter 3.

Measurement systems involving all elements are discussed in Chapter 6.

1.5

Control systems

A control system can be thought of as a system which can be used to: 1 control some variable to some particular value, e.g. a central heating system where the temperature is controlled to a particular value; 2 control the sequence of events, e.g. a washing machine where when the dials are set to, say, ‘white’ and the machine is then controlled to a particular washing cycle, i.e. sequence of events, appropriate to that type of clothing; 3 control whether an event occurs or not, e.g. a safety lock on a machine where it cannot be operated until a guard is in position.

1.5.1

Feedback

Consider an example of a control system with which we are all individually involved. Your body temperature, unless you are ill, remains almost constant regardless of whether you are in a cold or hot environment. To maintain this constancy your body has a temperature control system. If your temperature begins to increase above the normal you sweat; if it decreases you shiver. Both these are mechanisms which are used to restore the body temperature back to its normal value. The control system is maintaining constancy of temperature. The system has an input from sensors which tell it what the temperature is and then compare this data with what the temperature should be and provide the appropriate response in order to obtain the required temperature. This is an example of feedback control: signals are fed back from the output, i.e. the actual

M01 Mechatronics 50977.indd 9

30/08/2018 10:55

10

CHAPTER 1 INTRODUCING MECHATRONICS

Figure 1.8 Feedback control:

Required temperature

(a) human body temperature, (b) room temperature with central heating, (c) picking up a pencil.

Body temperature control system

Required temperature

Body temperature

Furnace and its control system

Room temperature

Feedback of data about actual temperature

Feedback of data about actual temperature

(a)

(b) The required hand position

Control system for hand position and movement

Hand moving towards the pencil

Feedback of data about actual position (c)

temperature, in order to modify the reaction of the body to enable it to restore the temperature to the ‘normal’ value. Feedback control is exercised by the control system comparing the fed-back actual output of the system with what is required and adjusting its output accordingly. Figure 1.8(a) illustrates this feedback control system.

One way to control the temperature of a centrally heated house is for a human to stand near the furnace on/off switch with a thermometer and switch the furnace on or off according to the thermometer reading. That is a crude form of feedback control using a human as a control element. The term feedback is used because signals are fed back from the output in order to modify the input. The more usual feedback control system has a thermostat or controller which automatically switches the furnace on or off according to the difference between the set temperature and the actual temperature (Figure 1.8(b)).

This control system is maintaining constancy of temperature.

If you go to pick up a pencil from a bench there is a need for you to use a control system to ensure that your hand actually ends up at the pencil. This is done by your observing the position of your hand relative to the pencil and making adjustments in its position as it moves towards the pencil. There is a feedback of information about your actual hand position so that you can modify your reactions to give the required hand position and movement (Figure 1.8(c)).

This control system is controlling the positioning and movement of your hand.

Feedback control systems are widespread, not only in nature and the home but also in industry. There are many industrial processes and machines where control, whether by humans or automatically, is required. For example, there is process control where such things as temperature, liquid level, fluid flow, pressure, etc., are maintained constant. Thus in a chemical process there may be a need to maintain the level of a liquid in a tank to a particular level or to a particular temperature. There are also control systems which involve consistently and accurately positioning a moving part or maintaining a constant speed. This might be, for example, a motor designed to run at a constant speed or perhaps a machining operation in which the position, speed and operation of a tool are automatically controlled.

M01 Mechatronics 50977.indd 10

30/08/2018 10:55

11

1.5 CONTROL SYSTEMS

1.5.2

Open- and closed-loop systems

There are two basic forms of control system, one being called open loop and the other closed loop. The difference between these can be illustrated by a simple example. Consider an electric fire which has a selection switch which allows a 1 kW or a 2 kW heating element to be selected. If a person used the heating element to heat a room, they might just switch on the 1 kW element if the room is not required to be at too high a temperature. The room will heat up and reach a temperature which is only determined by the fact that the 1 kW element was switched on and not the 2 kW element. If there are changes in the conditions, perhaps someone opening a window, there is no way the heat output is adjusted to compensate. This is an example of open-loop control in that there is no information fed back to the element to adjust it and maintain a constant temperature. The heating system with the heating element could be made a closed-loop system if the person has a thermometer and switches the 1 kW and 2 kW elements on or off, according to the difference between the actual temperature and the required temperature, to maintain the temperature of the room constant. In this situation there is feedback, the input to the system being adjusted according to whether its output is the required temperature. This means that the input to the switch depends on the deviation of the actual temperature from the required temperature, the difference between them being determined by a comparison element – the person in this case. Figure 1.9 illustrates these two types of system.

An example of an everyday open-loop control system is the domestic toaster. Control is exercised by setting a timer which determines the length of time for which the bread is toasted. The brownness of the resulting toast is determined solely by this preset time. There is no feedback to control the degree of browning to a required brownness.

To illustrate further the differences between open- and closed-loop systems, consider a motor. With an open-loop system the speed of rotation of the shaft might be determined solely by the initial setting of a knob which affects the voltage applied to the motor. Any changes in the supply voltage, the characteristics of the motor as a result of temperature changes, or the shaft load

Input: decision to switch on or off

Controller, i.e. person

Switch

Hand activated

Electric power

Electric fire

Output: a temperature change

(a)

Input:

Comparison element

required temperature

Deviation signal

Controller, i.e. person

Switch

Hand activated

Electric power

Feedback of temperature-related signal

Electric fire

Output: a constant temperature

Measuring device

(b)

Figure 1.9 Heating a room: (a) an open-loop system, (b) a closed-loop system.

M01 Mechatronics 50977.indd 11

30/08/2018 10:55

12

CHAPTER 1 INTRODUCING MECHATRONICS

will change the shaft speed but not be compensated for. There is no feedback loop. With a closed-loop system, however, the initial setting of the control knob will be for a particular shaft speed and this will be maintained by feedback, regardless of any changes in supply voltage, motor characteristics or load. In an open-loop control system the output from the system has no effect on the input signal. In a closed-loop control system the output does have an effect on the input signal, modifying it to maintain an output signal at the required value.

Open-loop systems have the advantage of being relatively simple and consequently low cost with generally good reliability. However, they are often inaccurate since there is no correction for error. Closed-loop systems have the advantage of being relatively accurate in matching the actual to the required values. They are, however, more complex and so more costly with a greater chance of breakdown as a consequence of the greater number of components.

1.5.3

Basic elements of a closed-loop system

Figure 1.10 shows the general form of a basic closed-loop system. It consists of five elements: 1 Comparison element This compares the required or reference value of the variable condition being controlled with the measured value of what is being achieved and produces an error signal. It can be regarded as adding the reference signal, which is positive, to the measured value signal, which is negative in this case: error signal = reference value signal - measured value signal The symbol used, in general, for an element at which signals are summed is a segmented circle, inputs going into segments. The inputs are all added, hence the feedback input is marked as negative and the reference signal positive so that the sum gives the difference between the signals. A feedback loop is a means whereby a signal related to the actual condition being achieved is fed back to modify the input signal to a process. The feedback is said to be negative feedback when the signal which is fed back subtracts from the input value. It is negative feedback that is required to control a system.

Positive feedback occurs when the signal fed back adds to the input signal.

2 Control element This decides what action to take when it receives an error signal. It may be, for example, a signal to operate a switch or open a valve. The control Comparison element Reference value

+

-

Error signal

Control unit

Correction unit

Measured value

Measuring device

Process

Controlled variable

Figure 1.10 The elements of a closed-loop control system.

M01 Mechatronics 50977.indd 12

30/08/2018 10:55

13

1.5 CONTROL SYSTEMS

plan being used by the element may be just to supply a signal which switches on or off when there is an error, as in a room thermostat, or perhaps a signal which proportionally opens or closes a valve according to the size of the error. Control plans may be hard-wired systems in which the control plan is permanently fixed by the way the elements are connected together, or programmable systems where the control plan is stored within a memory unit and may be altered by reprogramming it. Controllers are discussed in Chapter 10.

3 Correction element The correction element produces a change in the process to correct or change the controlled condition. Thus it might be a switch which switches on a heater and so increases the temperature of the process or a valve which opens and allows more liquid to enter the process. The term actuator is used for the element of a correction unit that provides the power to carry out the control action. Correction units are discussed in Chapters 7, 8 and 9.

4 Process element The process is what is being controlled. It could be a room in a house with its temperature being controlled or a tank of water with its level being controlled.

5 Measurement element The measurement element produces a signal related to the variable condition of the process that is being controlled. It might be, for example, a switch which is switched on when a particular position is reached or a thermocouple which gives an e.m.f. related to the temperature.

With the closed-loop system illustrated in Figure 1.10 for a person controlling the temperature of a room, the various elements are: Controlled variable Reference value Comparison element

– – –

Error signal

–

Control unit Correction unit Process Measuring device

– – – –

the room temperature the required room temperature the person comparing the measured value with the required value of temperature the difference between the measured and required temperatures the person the switch on the fire the heating by the fire a thermometer

An automatic control system for the control of the room temperature could involve a thermostatic element which is sensitive to temperature and switches on when the temperature falls below the set value and off when it reaches it (Figure 1.11). This temperature-sensitive switch is then used to switch on the heater. The thermostatic element has the combined functions of comparing the required temperature value with that occurring and then controlling the operation of a switch. It is often the case that elements in control systems are able to combine a number of functions.

Figure 1.12 shows an example of a simple control system used to maintain a constant water level in a tank. The reference value is the initial setting of the lever arm arrangement so that it just cuts off the water supply at the required

M01 Mechatronics 50977.indd 13

30/08/2018 10:55

14

CHAPTER 1 INTRODUCING MECHATRONICS Thermostatic element

Input:

Comparison element

required temperature

Deviation signal

Controller

Switch

Heater

Electric power

Output: required temperature

Measuring device

Feedback of temperature-related signal

Figure 1.11 Heating a room: a closed-loop system.

Lever Water input Pivot

Hollow ball

Comparison element: the lever + Reference value: the initial setting

Error signal

Pivoted lever

The flap

Water level in tank

Control unit

Correction unit

Process

Measured value

Measuring device

Controlled variable: water level

The floating ball and lever

Figure 1.12 The automatic control of water level.

level. When water is drawn from the tank the float moves downwards with the water level. This causes the lever arrangement to rotate and so allows water to enter the tank. This flow continues until the ball has risen to such a height that it has moved the lever arrangement to cut off the water supply.

The system is a closed-loop control system with the elements being: Controlled variable Reference value Comparison element Error signal

– – – –

Control unit Correction unit

– –

Process Measuring device

– –

water level in tank initial setting of the float and lever position the lever the difference between the actual and initial settings of the lever positions the pivoted lever the flap opening or closing the water supply the water level in the tank the floating ball and lever

The above is an example of a closed-loop control system involving just mechanical elements. We could, however, have controlled the liquid level by means of an electronic control system. We thus might have had a level sensor

M01 Mechatronics 50977.indd 14

30/08/2018 10:55

15

1.5 CONTROL SYSTEMS Potentiometer for setting reference value

Amplifies difference between reference and feedback values

Bevel gear

Differential amplifier

D.C. supply

Rotating shaft

Motor

Speed measurement

Tachogenerator

Differential amplifier

Reference value

Amplifier

Motor

Process, rotating shaft

Output: constant speed shaft

Measurement tachogenerator

Figure 1.13 Shaft speed control.

supplying an electrical signal which is used, after suitable signal conditioning, as an input to a computer where it is compared with a set value signal and the difference between them, the error signal, then used to give an appropriate response from the computer output. This is then, after suitable signal conditioning, used to control the movement of an actuator in a flow control valve and so determine the amount of water fed into the tank.

Figure 1.13 shows a simple automatic control system for the speed of rotation of a shaft. A potentiometer is used to set the reference value, i.e. what voltage is supplied to the differential amplifier as the reference value for the required speed of rotation. The differential amplifier is used both to compare and amplify the difference between the reference and feedback values, i.e. it amplifies the error signal. The amplified error signal is then fed to a motor which in turn adjusts the speed of the rotating shaft. The speed of the rotating shaft is measured using a tachogenerator, connected to the rotating shaft by means of a pair of bevel gears. The signal from the tachogenerator is then fed back to the differential amplifier:

M01 Mechatronics 50977.indd 15

Controlled variable Reference value Comparison element Error signal

– – – –

Control unit Correction unit Process Measuring device

– – – –

speed of rotation of shaft setting of slider on potentiometer differential amplifier the difference between the output from the potentiometer and that from the tachogenerator system the differential amplifier the motor the rotating shaft the tachogenerator

30/08/2018 10:55

16

CHAPTER 1 INTRODUCING MECHATRONICS

1.5.4

Analogue and digital control systems

Analogue systems are ones where all the signals are continuous functions of time and it is the size of the signal which is a measure of the variable (Figure 1.14(a)).

The examples so far discussed in this chapter are such systems. Digital signals can be considered to be a sequence of on/off signals, the value of the variable being represented by the sequence of on/off pulses (Figure 1.14(b)).

Where a digital signal is used to represent a continuous analogue signal, the analogue signal is sampled at particular instants of time and the sample values each then converted into effectively a digital number, i.e. a particular sequence of digital signals. For example, we might have for a three-digit signal the digital sequence of: no pulse, no pulse, no pulse representing an analogue signal of 0 V; no pulse, no pulse, a pulse representing 1 V; no pulse, pulse, no pulse representing 2 V; no pulse, pulse, pulse representing 3 V; pulse, no pulse, no pulse representing 4 V; pulse, no pulse, pulse representing 5 V; pulse, pulse, no pulse representing 6 V; pulse, pulse, pulse representing 7 V.

Signal

Because most of the situations being controlled are analogue in nature and it is these that are the inputs and outputs of control systems, e.g. an input of temperature and an output from a heater, a necessary feature of a digital control system is that the real-world analogue inputs have to be converted to digital forms and the digital outputs back to real-world analogue forms. This involves the uses of analogue-to-digital converters (ADCs) for inputs and digital-to-analogue converters (DACs) for the outputs.

Figure 1.15(a) shows the basic elements of a digital closed-loop control system; compare it with the analogue closed-loop system in Figure 1.10.

The reference value, or set point, might be an input from a keyboard. ADC and DAC elements are included in the loop in order that the digital controller can be supplied with digital signals from analogue measurement systems

(a)

0

Time Analogue 7 V

Analogue 6 V

Analogue 4 V

Signal

Analogue 7 V

(b)

0

Time

Figure 1.14 Signals: (a) analogue and (b) the digital version of the analogue signal showing the

stream of sampled signals.

M01 Mechatronics 50977.indd 16

30/08/2018 10:55

17

1.5 CONTROL SYSTEMS Comparison element + Reference value

-

Error signal

Digital controller

DAC

Controlled variable

Correction unit

Process

Measured value Measuring device

ADC (a) Microcontroller Comparison element + Reference value

-

Error signal

Digital controller

DAC

Controlled variable

Correction unit

Process

Measuring device

ADC Measured value

Reference value Microcontroller

Controlled variable

Correction unit

Process

Measured value Measuring device (b)

Figure 1.15 (a) The basic elements of a digital closed-loop control system, (b) a microcontroller control

system.

and its output of digital signals can be converted to analogue form to operate the correction units. It might seem to be adding a degree of complexity to the control system to have this ADC and DAC, but there are some very important advantages: digital operations can be controlled by a program, i.e. a set of stored instructions; information storage is easier; accuracy can be greater; and digital circuits are less affected by noise and also generally easier to design.

The digital controller could be a digital computer which is running a program, i.e. a piece of software, to implement the required actions. The term control algorithm is used to describe the sequence of steps needed to solve
