CLAF POWER: Power Supplies Selector Guide
3W Input: 85-305VAC/100-430VDC
DIP Isolation: 4000VAC Dims: 25.40x25.40x17.60
APS10 Flexible Type
Power: 10W
Input: 85-305VAC/100-430VDC* Package: SIP Isolation: 3600VAC Dims: 32.00x17.20x15.05
APD10
Miniaturized Type
Power: 10W
Input: 85-305VAC/100-430VDC Package: DIP
Isolation: 4200VAC Dims: 40.00x25.40x21.00
APD05
Miniaturized Type
Power: 5W
Input: 85-305VAC/100-430VDC
Package: DIP
Isolation: 4000VAC Dims: 25.40x25.40x17.60
Power: 5W
Input: 85-305VAC/100-430VDC Package: DIP Isolation: 4000VAC Dims: 45.70x25.40x21.50
APH10 High Reliable
Power: 10W
Input: 85-305VAC/100-403VDC
Package: DIP
Isolation: 4200VAC Dims: 55.00x45.00x21.00
APS15-15D Flexible Type
Power: 15W
Input: 85-305VAC/100-430VDC* Vout: 15VDC
Package: SIP
Isolation: 4000VAC Dims: 33.34x21.50x9.72
APSW15 Flexible Type
Power: 15W
Input: 176-528VAC/248-745VDC* Package: SIP
Isolation: 3600VAC Dims: 40.04x20.00x15.25
APD15-M
Miniaturized Type
Power: 15W
Input: 85-305VAC/100-430VDC Package: DIP
Isolation: 4000VAC Dims: 52.40x27.20x24.00
PCB & CHASSIS MOUNT: 10W TO 15W
APS10-P Flexible Type
Power: 10W
Input: 85-305VAC/90-430VDC* Package: SIP
Isolation: 3600VAC Dims: 28.84x17.20x14.05
APD10-M
Miniaturized Type
Power: 10W
Input: 85-305VAC/100-403VDC Package: DIP
Isolation: 4000VAC Dims: 47.60x26.80x23.50
AE15 Standard
Power: 15W
Input: 85-305VAC/100-430VDC* Package: Enclosed
Isolation: 4000VAC Dims: 65.00x55.00x25.00
APS15-D Flexible Type
Power: 15W
Input: 85-305VAC/100-430VDC* Package: SIP
Isolation: 4000VAC Dims: 33.34x21.50x9.72
APD15
Miniaturized Type
Power: 15W
Input: 85-305VAC/100-430VDC Package: DIP
Isolation: 4200VAC
Dims: 47.60x26.80x23.50
APH15
Miniaturized Type
Power: 15W
Input: 85-305VAC/100-430VDC
Package: DIP
Isolation: 4200VAC
Dims: 62.00x45.00x22.50
APSW10
Flexible Type
Power: 10W
Input: 85-528VAC/100-705VDC* Package: SIP
Isolation: 4000VAC Dims: 38.00x20.00x15.25
APDW10 Miniaturized Type
Power: 10W
Input: 90-528VAC/100-745VDC Package: DIP
Isolation: 4000VAC Dims: 62.00x45.00x30.00
APS15-12D Flexible Type
Power: 15W
Input: 85-305VAC/100-430VDC* Vout: 12VDC
Package: SIP
Isolation: 4000VAC Dims: 33.34x21.50x9.72
APS15-V0 Flexible Type
Power: 15W
Input: 90-528VAC Package: SIP Isolation: 3000VAC Dims: 44.50x24.00x15.00
APD15-4B
Miniaturized Type
Power: 15W
Input: 176-418VAC/248-591VDC Package: DIP
Isolation: 4000VAC Dims: 52.40x27.20x24.00
AO15-2B-M Economical
Power: 15W
PCB & CHASSIS MOUNT: 20W TO 30W
APD20 Miniaturized Type
Power: 20W
Input: 85-305VAC/100-430VDC Package: DIP Isolation: 4200VAC Dims: 52.40x27.20x24.00
APDW20
Miniaturized Type
Power: 20W
Input: 90-528VAC/100-745VDC Package: DIP
Isolation: 4000VAC Dims: 70.00x48.00x30.00
APH25 High Reliable
Power: 25W
Input: 85-305VAC/100-430VDC Package: DIP
Isolation: 4200VAC
Dims: 70.00x48.00x23.50
AO25-2B-M Economical
Power: 25W
Input: 80-264VAC/120-370VDC* Package: Open Frame
Isolation: 4000VAC Dims: 76.20x50.80x27.00
APDW30 Miniaturized Type
Power: 30W
Input: 176-528VAC/248-746VDC Package: DIP
Isolation: 4000VAC
Dims: 70.00x48.00x30.00
Input: 80-264VAC/100-370VDC* Package: Open Frame
Isolation: 4000VAC Dims: 63.50x45.70x22.00
APD20-RC Miniaturized Type
Power: 20W
Input: 85-305VAC/100-430VDC Package: DIP
Isolation: 4200VAC Dims: 52.40x27.20x24.00
APH20 High Reliable
Power: 20.4W
Input: 85-305VAC/100-430VDC Package: DIP
Isolation: 4200VAC Dims: 62.00x45.00x22.50
AE25 Standard
Power: 25W
Input: 85-305VAC/100-430VDC Package: Enclosed Isolation: 4000VAC Dims: 80.00x55.00x25.00
APD30 Miniaturized Type
Power: 30W
Input: 85-305VAC/120-430VDC Package: DIP
Isolation: 4200VAC Dims: 69.50x39.00x24.00
AE35-2B Standard
Power: 35W
Input: 85-264VAC/120-370VDC* Package: Enclosed
Isolation: 4000VAC Dims: 99.00x82.00x30.00
80-264VAC/120-370VDC*
Open Frame
4000VAC Dims: 76.20x50.80x27.00
AE50-2B Standard
Power: 50W
Input: 85-264VAC/120-370VDC*
Package: Enclosed
Isolation: 4000VAC
Dims: 99.00x82.00x30.00
AE50-V2 Standard
Power: 50W
Input: 80-305VAC/100-430VDC*
Package: Enclosed
Isolation: 4000VAC
Dims: 99.00x65.00x30.00
AE60-2A
Enclosed
99.00x97.00x30.00
APD60
Miniaturized Type
Power: 60W
Input: 85-305VAC/100-430VDC Package: DIP
Isolation: 4200VAC Dims: 70.00x48.00x27.00
CLAF POWER:
PCB & CHASSIS MOUNT: 225W TO 501.6W
AEF75 Standard Power: 75W
Input: 85-305VAC/120-430VDC* Package: Enclosed Isolation: 4000VAC Dims: 159.00x97.00x30.00
Power: 100W Input: 85-264VAC/120-370VDC* Package: Enclosed Isolation: 4000VAC Dims: 129.00x97.00x30.00
AOF120-2B High Power Density
Power: 120W
Input: 85-264VAC/120-370VDC
Package: Open Frame
Isolation: 4000VAC Dims: 76.20x50.80x31.00
AEF150 Standard
Power: 150W
Input: 85-305VAC/120-430VDC* Package: Enclosed Isolation: 4000VAC Dims: 179.00x99.00x30.00
AE200-2B Standard Power: 200W Input: 90-132/180-264VAC Package: Enclosed Isolation: 3000VAC Dims: 179.00x99.00x30.00
AE100-V2 Standard
Power: 100W
Power: 90W Input: 80-305VAC/110-430VDC Package: DIP Isolation: 4200VAC Dims: 87.00x52.00x29.50
Input: 85-305VAC/100-430VDC* Package: Enclosed Isolation: 4000VAC Dims: 99.00x97.00x30.00
AE150-2B Standard
Power: 150W
Input: 85-264VAC/120-370VDC* Package: Enclosed Isolation: 4000VAC Dims: 159.00x97.00x30.00
AEF200 Standard
Power: 200W
Input: 85-305VAC/120-430VDC* Package: Enclosed Isolation: 4000VAC Dims: 179.00x99.00x30.00
AEF100 Standard
Power: 100W
Input: 85-305VAC/120-430VDC* Package: Enclosed Isolation: 4000VAC Dims: 179.00x99.00x30.00
AE150-V2 Standard
Power: 150W
Input: 85-305VAC/100-430VDC*
Package: Enclosed
Isolation: 4000VAC Dims: 99.00x97.00x30.00
AEFUH200 Standard
Power: 200W
Input: 85-305VAC/120-430VDC* Package: Enclosed Isolation: 4000VAC Dims: 194.00x55.00x26.00
AOF225-2B High Power Density
Power: 225W
Input: 85-264VAC/120-370VDC
Package: Open Frame
Isolation: 4000VAC
Dims: 101.60x50.80x25.40
AOF350-2B High Power Density
Power: 350W
Input: 90-264VAC/127-370VDC*
Package: Open Frame
Isolation: 4000VAC
Dims: 127.00x76.20x25.40
AE350-V2 Standard
Power: 350W
Input: 90-132/180-264VAC
Input: 240-370VDC
Package: Enclosed
Isolation: 4000VAC Dims: 179.00x106.00x30.00
AEFUH350 Slim & Fanless
Power: 351W
Input: 85-305VAC/120-430VDC*
Package: Enclosed
Isolation: 4000VAC Dims: 220.00x62.00x31.00
AE450-2B Standard
Power: 450W
Input: 90-132/180-264VAC* Input: 255-370VDC
Package: Enclosed
Isolation: 4000VAC
Dims: 225.00x124.00x35.00
AEFUH750
Slim & Fanless
AEF320 Standard
Power: 320W
Input: 85-305VAC/120-430VDC* Package: Enclosed
Isolation: 4000VAC Dims: 215.00x115.00x30.00
AE350-2B Standard
Power: 350W
Input: 90-132/180-264VAC
Input: 240-370VDC
Package: Enclosed
Isolation: 3000VAC
Dims: 215.00x115.00x30.00
AES350-G12B CRPS - Server
Power: 350W
Input: 90-264VAC Package: Enclosed Isolation: 3000VAC Dims: 73.50x185.00x40.00
AOF450-2B High Power Density
Power: 450W
Input: 90-264VAC/127-370VDC*
Package: Open Frame
Isolation: 4000VAC Dims: 127.00x76.20x38.50
AEF500-2B Standard
Power: 500W
Input: 80-264VAC/110-370VDC* Package: Enclosed
Isolation: 4000VAC
Dims: 203.10x101.60x40.60
AOF550-2B High Power Density
Power: 550W
PCB & CHASSIS MOUNT: 550W TO 1000W
Input: 90-264VAC/127-370VDC Package: Open Frame Isolation: 4000VAC Dims: 127.00x76.20x40.50
AES550-P12F CRPS - Server
Power: 550W
Input: 90-264VAC/180-320VDC Package: Enclosed
Isolation: 3000VAC Dims: 73.50x185.00x40.00
AEF600-2B Standard
Power: 600W
Input: 80-277VAC/110-390VDC* Package: Enclosed Isolation: 4000VAC Dims: 101.60x203.10x40.60
AEFUH500 Slim & Fanless
Power: 501.6W
Input: 85-305VAC/120-430VDC* Package: Enclosed
Isolation: 4000VAC Dims: 232.00x81.00x31.00
AES800-P12F CRPS - Server
Power: 800W
Input: 90-264VAC/120-430VDC Package: Enclosed
Isolation: 3000VAC Dims: 73.50x185.00x40.00
AEF1000-2B Standard
Power: 1000W
Power: 750W
Input: 85-305VAC/120-430VDC* Package: Enclosed
Isolation: 4000VAC Dims: 237.00x100.00x41.00
AES550-P12B CRPS - Server
Power: 550W
Input: 90-264VAC/180-320VDC
Package: Enclosed
Isolation: 3000VAC Dims: 73.50x185.00x40.00
AE600-2B Standard
Power: 600W
Input: 90-132/180-264VAC Input: 255-370VDC* Package: Enclosed Isolation: 4000VAC Dims: 225.00x124.00x4 1.00
AOF750-2B High Power Density
Power: 750W
Input: 90-264VAC/127-370VDC
Package: Open Frame
Isolation: 4000VAC Dims: 127.00x72.60x43.00
AES800-P12B CRPS - Server
Power: 800W
Input: 90-264VAC
Package: Enclosed
Isolation: 3000VAC Dims: 73.50x185.00x40.00
AE1000-2B Standard
Power: 1000W
Input: 90-264VAC/130-390VDC
Package: Enclosed
Isolation: 4000VAC
Dims: 187.50x127.00x40.50
AEFUH1000 Slim & Fanless
Power: 1008W
Input: 90-264VAC/120-370VDC* Package: Enclosed
Isolation: 4000VAC Dims: 190.00x127.00x40.50
AES1300-P12B CRPS - Server
Power: 1300W
Input: 90-264VAC
Package: Enclosed
Isolation: 3000VAC Dims: 73.50x185.00x40.00
AE1500-1B Standard
Power: 1500W
Input: 180-277VAC/250-380VDC*
Package: Enclosed
Isolation: 4000VAC Dims: 250.00x127.00x40.50
AEF1500-2B Standard
Power: 1510W
Input: 85-264VAC/120-370VDC* Package: Enclosed
Isolation: 4000VAC Dims: 250.00x127.00x40.50
AEF2000-2B Standard
Power: 2027W Input: 85-277VAC/120-390VDC* Package: Enclosed
Isolation: 4000VAC
Dims: 290.00x127.00x40.50
AEF3000-1B Standard
Power: 3000W
Input: 180-277AC/254-390VDC* Package: Enclosed Isolation: 4000VAC Dims: 279.40x177.80x63.50
AEF3000-2B Standard
Input: 85-305VAC/180-430VDC* Package: Enclosed Isolation: 4000VAC Dims: 240.00x115.00x41.00
AOMU30-2B Medical Power: 30W Input: 80-264VAC/100-370VDC Package: Open Frame Isolation: 4000VAC Dims: 76.20x50.80x24.00
AOMU65-2B Medical Power: 65W Input: 85-264VAC/100-370VDC Package: Open Frame Isolation: 4000VAC Dims: 76.20x50.80x26.50
AOMU75-2B
75W
AOMU120-2B Medical
Power: 120W
Input: 80-264VAC/100-370VDC Package: Open Frame Isolation: 4000VAC
Power: 3000W
Input: 85-277VAC/120-390VDC* Package: Enclosed
Isolation: 4000VAC Dims: 279.40x177.80x63.50
CLAF POWER:
ADL15-2B
Plastic Case
Power: 15W
Input: 85-264VAC/120-370VDC* Package: DIN-Rail
Isolation: 4000VAC Dims: 90.00x58.00x17.50
ADL60-2B
Plastic Case
Power: 60W
Input: 85-264VAC/120-370VDC* Package: DIN-Rail Isolation: 4000VAC Dims: 92.66x52.00x58.00
ADW60 Metal Case, Two-phase
Power: 60W
Input: 90-264VAC/250-850VDC Package: DIN-Rail Isolation: 4700VAC Dims: 124.00x32.00x102.00
AD75-V2
Metal Case, Single-phase
Power: 75W
Input: 85-305VAC/120-430VDC* Package: DIN-Rail Isolation: 4000VAC Dims: 110.00x87.50x32.00
ADL30-2B Plastic Case
Power: 30W
Input: 85-264VAC/120-370VDC* Package: DIN-Rail
Isolation: 4000VAC Dims: 92.66x35.00x58.00
ADP60-2B Plastic Case
Power: 60W
Input: 85-264VAC/120-370VDC* Package: DIN-Rail
Isolation: 4000VAC Dims: 100.00x36.50x90.00
AD75-2B-S
Metal Case, Single-phase
Power: 75W
Input: 90-264VAC/120-370VDC* Package: DIN-Rail Isolation: 4000VAC
Dims: 32.00x125.00x87.50
ADL100-2B Plastic Case
Power: 100W
Input: 85-264VAC/120-370VDC* Package: DIN-Rail Isolation: 4000VAC Dims: 70.00x92.66x58.00
ADF120-2B Metal Case, Single-phase
Power: 120W
Input: 85-264VAC/120-370VDC*
Package: DIN-Rail Isolation: 3000VAC Dims: 110.00x32.00x124.00
ADL150-2B Plastic Case
Power: 150W
Input: 85-264VAC/120-370VDC Package: DIN-Rail Isolation: 4000VAC Dims: 105.00x90.00x55.40
ADWF240
Metal Case, Two-phase
Power: 240W
Input: 180-550VAC/254-780VDC
Package: DIN-Rail Isolation: 4000VAC
Dims: 124.00x54.00x110.00
ADMF240-2B High-end Series
Power: 240W
Input: 85-277VAC/120-390VDC Package: DIN-Rail
Isolation: 4000VAC Dims: 124.00x121.00x48.00
DIN-RAIL: 100W TO 240W
AD120-2B-S Metal Case, Single-phase
Power: 120W
Input: 90-264VAC/127-370VDC* Package: DIN-Rail Isolation: 4000VAC Dims: 36.00x125.00x100.00
ADW120
Metal Case, Two-phase
Power: 120W
Input: 180-600VAC/254-848VDC* Package: DIN-Rail Isolation: 4000VAC Dims: 124.00x41.00x110.00
ADF240-2B Metal Case, Single-phase
Power: 240W
Input: 85-264VAC/120-370VDC* Package: DIN-Rail Isolation: 3000VAC Dims: 124.00x41.00x110.00
ADT240 Metal Case, 3-phase
Power: 240W
Input: 3x320-600VAC Input: 450-850VDC
Package: DIN-Rail
Isolation: 4000VAC
Dims: 124.00x54.00x110.00
AD120-V2
Metal Case, Single-phase
Power: 120W
Input: 85-305VAC/120-430VDC* Package: DIN-Rail
Isolation: 4000VAC
Dims: 36.00x125.00x100.00
AD120-V2 High-end Series
Power: 120W
Input: 85-277VAC/120-430VDC* Package: DIN-Rail Isolation: 4000VAC Dims: 125.00x87.50x32.00
ADF240-2B-S
Metal Case, Single-phase
Power: 240W
Input: 85-264VAC/120-370VDC*
Package: DIN-Rail
Isolation: 3000VAC Dims: 124.00x54.00x110.00
ADTF240
Metal Case, 3-phase
Power: 240W
Input: 3x320-600VAC
Input: 450-800VDC Package: DIN-Rail
Isolation: 4000VAC Dims: 52.00x124.00x127.00
ADF480-2B Metal Case, Single-phase
Power: 480W
DIN-RAIL: 480W TO 90W
Input: 85-264VAC/120-370VDC* Package: DIN-Rail
Isolation: 3000VAC Dims: 131.50x48.00x125.00
ADTF480 Metal Case, 3-phase
Power: 480W
Input: 3x320-600VAC Input: 450-800VDC Package: DIN-Rail Isolation: 4000VAC Dims: 80.00x124.00x127.00
ADMF480-2B High-end Series
Power: 480W
Input: 85-277VAC/120-390VDC Package: DIN-Rail
Isolation: 4000VAC Dims: 124.00x55.00x127.00
ADTF960 Metal Case, 3-phase
Power: 960W
Input: 3x320-600VAC
Input: 450-800VDC Package: DIN-Rail
Isolation: 4000VAC Dims: 110.00x124.00x127.00
ADWF480 Metal Case, Two-phase
Power: 480W
Input: 180-600VAC/250-850VDC Package: DIN-Rail Isolation: 4000VAC Dims: 80.00x124.00x127.00
ADTF480-S Metal Case, 3-Phase
Power: 480W
Input: 3x 320-550VAC Input: 450-800VDC Package: DIN-Rail Isolation: 4000VAC Dims: 80.00x124.00x127.00
ADF960-1B Metal Case, Single-phase
Power: 960W
Input: 180-264VAC/254-370VDC* Package: DIN-Rail Isolation: 4000VAC Dims: 110.00x124.00x127.00
ADTF960-S Metal Case, 3-phase
Power: 960W
Input: 3x320-575VAC Input: 450-820VDC Package: DIN-Rail
Isolation: 4000VAC Dims: 110.00x124.00x127.00
DDR20
Redundant Module
Power: N/A
Input: 22-60VDC
Package: DIN-Rail
Isolation: 1500VAC
Dims: 35.00x125.00x112.70
DDR40
Redundant Module
Power: N/A
Input: 9-60VDC
Package: DIN-Rail
Isolation: 1500VAC
Dims: 124.00x54.00x110.00
Power: 480W
Input: 22.5-30VDC
Package: DIN-Rail
Isolation: N/A Dims: 124.00x46.00x124.00
DDUPS20-F-N UPS Module
