Shock Resistant /Vibration Isolated Platform with Self Levelling Pneumatic Vibration Control -Series

Shock Resistant /Vibration Isolated Platform with Self Levelling Pneumatic Vibration Control -Series VIP-AM-WA Dynemech hi-tech vibration isolation platforms are designed and manufactured meticulously to achieve the highest levels of performance optimized for balances, measuring and testing equipments, microscopy and other sensitive precision instruments.

Vibration Isolated Platform , Series VIP-AM-WA provide top-notch compact table top vibration isolation solution for vibration sensitive systems such as measurement equipment, high-precision machineries that require pneumatic suspension with self-levelling arrangement, especially for difficult to suppress low frequency vibrations.

The unique Membrane Air Springs incorporated allows the platform to have superior load sensing and height controlling element.

It provides a stable support to the precision measuring machines while minimizing the effects of shock and vibrations, ultimately enhancing the performance of the equipment.

Membrane Air Spring used exhibits a low natural frequency in the range of 1-1.5Hz. The machine payload is suspended on the air through the flexible elastomeric membrane and damps most of the incoming vibrations.

The self-levelling arrangement ensures that the top platform always remains levelled during the load changes on top of the platform. The supplied air pressure may be varied depending upon the weight of the equipment.

A continuous air supply (not included) will be needed to compensate for the load difference on the platform. The air is either added or removed from the air spring to maintain the level of the top surface.

Applications: Dynemech Vibration Isolated Platforms enhance the performance of precision tabletop equipment.

Ideal for all types of precision measuring and testing equipments which needs to be installed in the high vibration zones including laboratories, manufacturing facilities, recording studios and research environments Ideal for microscopes, balances, Atomic Force Microscopes, Microhardness Testers, Profilometers, and analytical/inspection instruments, Audio equipment, photonics and optical equipments and other lightweight vibration sensitive equipment.

Granite and stainless-steel top surface versions find use in cleanrooms and honeycomb top in optical labs Best for Biology, food testing pathology, and IVF & life sciences labs.

Features :        

Low-profile design for limited space 90-95% vibration isolation at 2 Hz Maximum Load Capacity: 800 kg We offer a choice of active and passive platform versions.

Customised top surface - Granite surface plate, Low Carbon Steel, Stainless Steel or Honeycomb Top depending upon the requirement of the application.

Can be customized to accommodate a range of different types and sizes of the measuring equipment’s.

Table top optimized for easy cleaning making it ideal for use in general purpose microscopy, cleanrooms , laboratories etc.

Comfortable, clean ergonomic design – adaptable to any working environment
