Precision Levelling Mounts- Achieve Perfect Stability for Heavy Machinery, Series VHS

The VHS Series of levelling mounts provides a secure, high-precision connection between the ground and the machine. In case of large and long bedded machinery, Dynemech Festofix VHS Series provide strong, stable foundations, vibration reduction and accurate alignments of all allied elements.

The precision levelling mounts when equipped with vibration isolation plates, unique design absorbs impulses and shocks in high-speed machinery, where vibration damping is especially critical.

The VHS series levelling feet include an integral locking device that prevents movement during installation and relocation of the machine. Includes a horizontal deviation / vertical deviation preventing mechanism. The machined top spherical seat that compensates for misalignment between the machine base and the foundation.

Benefits of Festofix Precision Levelling Machinery Mounts :

 Compact and robust design to effectively anchor machinery within the space constraints. Each part is designed to incorporate thickness to adjust to abrupt loads

 Built-in compensation for uneven areas in foundations and machine bases.

 Additional spherical washers, to compensate for uneven support surfaces and floors, wherein the displacement value in relation to the load is very small too.

 Spherical top machined for maximum contact.

 Precision and accurate alignment for machines

 Rigid support to achieve maximum machine-foundation stiffness

 Low overall height to ensure a low machine centre of gravity.

 Horizontal & Vertical deviations are contained.

 Facility to carry out subsequent alignment readjustments with low torque requirements.

 Quick and easy installation for large and long bedded high precision machinery

 Designed for vibration reduction along with levelling adjustment

 Options of both on and bolt thru mechanisms

 Elastomeric Anti Vibration Plates are customizable based on thickness , surface profile and natural frequency desired.

Applications: For the Levelling, Adjustment & Fixation of Large Machinery and other Heavy Machine Tools / Equipment in industries like industrial machining, production machinery , packaging, power generation, etc.

 Machine tools like Long-bedded Lathes

 Roll Grinders, Plano-millers and Grinders,

 Die-casting and Plastic Injection Moulding Machines

 Generators

 Automotive transfer lines

 Turbines

 Horizontal and Vertical Machining Centres

 Compressor units

 High-Speed Boring and Milling Machines

 Boilers

 Large Process machinery

 Printing machinery
