ISIONANTI ONTABLEFOR RANDSURFACE INGMACHINES
ANTI VIBRATION PRECISION METROLOGY TABLES
1 2
3
4 Custom Design Integrated C t Vibration I l ti Aesthetic Integration
ANTI-VIBRATION TABLES FOR METROLOGY INSTRUMENTS Precision Anti Vibration Table for Measuring Station for Contour Measurements sales@dynemech.com www.vibrationmountsindia.com
ANTI-VIBRATION TABLES FOR METROLOGY INSTRUMENTS sales@dynemech.com www.vibrationmountsindia.com Precision Anti Vibration Table for Measuring Station for Contour Measurements
ANTI-VIBRATION TABLES FOR METROLOGY INSTRUMENTS sales@dynemech.com www.vibrationmountsindia.com Precision Anti Vibration Table for Measuring Station for Contour Measurements
Specifications Specifications
Granite base of size L 1100 X B 550 X T 50 mm
60 mm Tubular Structure with cross member
Wrap Around Construction
Swiveling bracket for monitor with tilting facility
65 X 65 mm AV pads at 9 places between structure and granite base
4 No’s DLP3 (AV disc with adjustable screws) at Ground Level
4 No’s – 3” Wheel
Front keyboard panel for keyboard and mouse Power Strip in Rear; CPU and UPS inside structure
Drawing Pouch LH Side, cable manager at rear side
Front double door with handles and lock
Precision Anti Vibration Table for contour and surface measuring machines
www.vibrationmountsindia.com
ANTI-VIBRATION TABLES FOR METROLOGY INSTRUMENTS
sales@dynemech.com
External enclosure for control unit fixed on RH side
Leveling Ball, Spanner 24/27
Powder Coat, structure RAL 9002, side sheets and doors – graphite gray
Instrument sticker Execution in wooden box
Precision Anti Vibration Table for contour and surface measuring machines
ANTI-VIBRATION
TABLES FOR METROLOGY INSTRUMENTS
sales@dynemech.com www.vibrationmountsindia.com Specifications Specifications
ANTI VIBRATION TABLE FOR
CONTOURECORD C1600 -14, P-66
PRECISIONANTI RATIONTABLEFOR TOURANDSURFACE ASURINGMACHINES
