Anti Vibration Precision Metrology Table for Zeiss Surfcom Nex (13)P-60

ANTI VIBRATION PRECISION METROLOGY TABLES

1 2 3

4 Custom Design Integrated Components

Vibration Isolation Aesthetic Integration

Specifications Specifications

Granite base of size: L-900 B-600 T-50 mm

60 mm Tubular Structure with cross member Wrap Around Construction

Swiveling bracket for monitor at Rear Left Side; with tilting facility

65 X 65 mm AV pads at 9 places between structure and granite base

4 No’s DLP3 (AV disc with adjustable pointed screws) at Ground Level

4 No’s – 3” Wheel

Front keyboard panel for keyboard and mouse with laser cut joystick

Pocket, top rim and Z-plates at bottom with support plate to fix joystick

Power Strip in Rear; controller, CPU and UPS inside structure

ANTI-VIBRATION

Drawing Pouch L.H Side, cable manager at rear side

Front double door with handles and lock ; Side sheet, door & Key board panel

Leveling Ball, Spanner 24/27

Powder Coat, structure RAL 9002, side sheets and doors – graphite gray

Instrument sticker

Execution in wooden box

Precision Anti Vibration Table for contour and surface measuring machines

ANTI-VIBRATION

TABLES FOR METROLOGY INSTRUMENTS
