Roping & Re-Roping
the
way
the
way
rope brake & ACCESSORIES The Wurtec Rope Brake is a durable roping tool used to lower wire rope down the hoistway at controlled speeds. It is equipped with reversible brake pads that allow for multiple uses before requiring replacement. A variety of accessories are available to adapt the rope brake to different environments and enhance efficiency. Used for roping or re-roping an elevator, the rope brake can greatly reduce the time required to install ropes in long hoistways.
rope brake • • • • • •
60-200 Increases safety and improves control over the roping and re-roping process Only lowers the rope when the operator pulls back on the handle Extra stopping force can be generated by pushing the handle forward Compression die springs ensure safe, repeatable braking force Usable on a wide range of applications Reversible brake pads allow multiple uses
rope descent safety tool 60-10051663 • Allows user to control descent speed of the spool without wearing down the brake pads on the rope brake • Uses 4 x 4 blocks of hard red oak for a high lifespan • Blocks may be turned and reattached once wear reaches an unacceptable level
Roping & Re-Roping 2:1 rope change-out tool
aluminum shortening clamps
60-8XX
60-1005XXX
This tool enables you to replace up to 9 wire ropes safely and efficiently. Each kits comes with complete installation instructions to guide you through the process of rope replacement.
Allows the user to lift the elevator car by clamping onto the hoist ropes right above the hitch plate. Once the clamp is in place, a hoist can be attached between it and the crosshead. Slack can then be created in the hoist ropes, allowing easy shortening of the rope at the hitch plate.
HYDRAULIC ROPE CUTTER
reeving splices
60-140
16-2XX
For 3/4” wire rope. Compact, lightweight, and portable for use in the tightest spaces. Proven and tested to last under the toughest conditions. Made of highgrade steel, fitted with posi-grip rubber handles, and coated with black zinc oxide. Head rotates up to 180 degrees for easy position and optimum leverage.
Save up to 30 minutes per application by simplifying the marrying of wire ropes during elevator re-roping operations. These economical, disposable tools permit easy passage of wire ropes over or under sheaves.
magna® lever hoist
rail blocks
LH-X
11-180, 11-181, 11-183, 11-190-M, 11-191-M, 11-193-M
Magna® lever chain hoists offer many construction and industrial applications with their ability to operate horizontally, vertically, or at any angle.
Wurtec’s rail blocks are used to rest your car or counterweight frame at any location in the hoistway. Painted for rust protection. Available with or without clevis.
• Load-tested to 125% of rated capacity • High-quality European chain load meets all international safety standards • Single-hand control of free-wheel function with load brake • Parts and service available
