hoisting ♦ MATERIAL HANDLING ♦ WIRE ROPE hydraulic tools ♦ rail AliGnment ♦ test and measure ♦ and more
WORK FASTER WORK SMARTER WORK the WURTEC WAY `
Another year in the bag. Another notch in the toolbelt. It was an out-of-the ordinary one, to be sure. But for you, it was the same old routine: dizzying heights, late-night service calls, dangerous environments demanding laser focus and razor-sharp skills. Because you’re an essential worker. Because even when the world is going off the rails - elevators have to stay on them. And while you’re duking it out on the front lines, we’re working tirelessly behind the scenes to keep hoistway warriors like you armed to the teeth with the best gear available. So pour a tall glass of your favorite holiday beverage, pull up a chair, and fill out your wish list with this ELEVATOR MECHANIC’S HOLIDAY CATALOG. Then, get on the phone with your favorite elevator products company, WURTEC INC., and tool up. With seven branches across the continent, you’re sure to find one close to your turf. Let’s have a heck of a holiday season and reach new heights in 2022. Cheers,
blake pilgrim president wurtec inc
HOISTING T-RAIL LIFTER Hoisting rails has never been easier. Latch the T-rail lifter over the fishplate, then lift and secure the rail into position. Then slide the lifter back down to the bottom and easily unlatch and disengage it. P/N 11-294 11-295 11-296
Rail Size(s) T89 T114, T125, T127-1, T127-2, T140-1 T140-2, T140-3
Wt. / Ft. 6-8 12-18 22-30
Retail $449.96 $456.55 $532.63
RATCHET BEAM CLAMPS Just open the clamp till it latches, position it on the end of our telescopic attaching rod, and lift toward the beam. When it bumps the bottom flange of the beam, the jaws snap shut into a closed and locked position. P/N 11-115 11-125
Description Telescopic Attaching Rod 3-Ton Beam Clamp
Retail $521.53 $1185.72
RAIL BLOCKS Use in pairs to rest your car or counterweight frame anywhere in the hoistway. Or, suspend the load from a shackle with our CLEVIS rail blocks. CLEVIS
STANDARD P/N 11-180 11-181 11-183
Blade Width 5/8” 3/4” 1-1/8" to 1-1/4"
Retail $238.74 $330.31 $360.99
P/N Blade Width 11-190 5/8”
Retail $292.45
11-191
$445.05
3/4”
11-193 1-1/8" to 1-1/4" $457.03
lean 2 beam The quickest, easiest way to create a hoisting point in an elevator shaft. Mounts between the entrance sill and the back wall of the hoistway. Starting at $1,905.75. Contact us for the complete list. P/N 11-225T
hoist bar This tough tool straddles blockout openings up to 3" wide and holds up to 10,000 lbs. Clips on each end let you anchor it to the floor. P/N 11-105
Description 10,000-lb Hoisting Bar
Retail $78.59
rail alignment RAIL POINTER SETS
RE-ALIGNMENT RAIL POINTER SET
For accurate alignment of elevator guide rails. Fasten to EMT conduit to establish DBG. As you move through the hoistway, set DBG while you set rail faces in correct relationship. Includes adjustable steel gauge. Made from lightweight aluminum.
For use when the car is in the hoistway. Conduit is offset 8” from rail center line, allowing it to clear the elevator ropes. Plumb line gauges are built-in and adjustable, designed for use with our ADJUSTABLE PLUMB LINE CLAMPS (#10-180).
P/N 10-100 10-105
Description Standard Set Heavy-Duty Set
Retail $119.81 $326.73
P/N 10-110
Retail $496.63
JOINT ALIGNMENT TOOL
rail alignment gauge
Bad joint alignment = a rough elevator ride. This tool achieves a smooth, proper joint quicker than ever. Just clamp to the rail using the cam handles, tighten the fishplate, and remove the tool.
Use this tool to align rails to target lines dropped via our DUAL-LINE RATCHET BRACKET (#10-182). Includes seethrough gauge for easy viewing of the line and springaction clamp for securing to the rail.
P/N 10-740
P/N 10-117 10-118 10-119W 10-120
Retail $886.60
Rail Size 5/8" 3/4" 1-1/8" 1-1/4"
Retail $120.96 $116.30 $129.48 $135.96
LASER ALIGNMENT KIT Align your rails without having to drop a line. This kit includes a selfleveling KLEIN® LASER, accurate to within 3/32” per 33’. Mounts directly to a rail using our specially designed MOUNTING BRACKET ASSEMBLY. Plumbing is accomplished with our UNIVERSAL LASER TARGET GAUGE. P/N 10-124-SBL2 10051218 10-10051059 10-10051211
Description Laser Alignment Kit Klein® Laser Universal Laser Target Gauge Laser Mounting Kit
Retail $1656.27 $289.77 $279.89 $319.61
wire rope products aluminum rope clamp
huskie® hydraulic rope cutter
A higher-capacity alternative to cast-iron Roebling clamps. These feature grip-enhancing internal grooves and range in capacity from 1250 to 2000 lbs. All P/Ns are $142.50.
Bring some serious bite to your next wire rope job. This Huskie® hand-pumped hydraulic cutter packs real cutting power into a compact, lightweight design. For up to 3/4" wire rope.
P/N 60-052 60-053 60-054 60-055 60-056 60-057 60-058
Rope Size 7/16" 7/8" 3/8" 1/2" - 9/16" 5/16" 3/4" 5/8" - 11/16"
P/N Retail 16-140 $1348.97
baudat flat belt cutter
wedge-style rope clamps
You're guaranteed a clean edge with this tough, easy-touse hydraulic belt cutter. Accommodates polymer flat belts with integrated wire ropes up to 3mm high x 60mm wide.
Come-along clamps used for tensioning or bracing ropes. These clamps are self-tensioning, meaning that the holding force increases as tensile force increases.
P/N 60-151
Retail $1284.36
P/N KSP10V KSP14V KSP21V
Rope Size 3/16" - 3/8" 7/16" - 9/16" 5/8" - 13/16"
Retail $1041.11 $1168.19 $1366.91
From leading suppliers cut to length ships fast anywhere in n. america
hydraulic tools ROLL GROOVER
FILTER CART
Get in the groove with this mobile, lightduty machine from VICTAULIC®. Integral motor, safety foot switch, and power plug. Grooves 1-1/4”-6” pipe up to Schedule 40.
Self-contained dual-filter system for transferring oil from drum to tank and cleansing oil in existing systems. 2-stage system ready to use on 100V service. Filters at 10 gal/min.
P/N VE106
Retail $12228.43
P/N 10-400
Retail $3876.20
HEAVY-DUTY JACK CLAMP
halo light kit
Metallic muscle for hoisting hydro jacks into place. Tough steel construction fits cylinders 3”-9” in diameter and lets you lift up to 1800 lbs.
Plumb cylinders with more speed and accuracy than ever. Mechanically center this device with the spider assembly at the top of the casing, then lower the lighted centering disk down the full length. The even "HALO" around the centering disk shows you when plumb is achieved.
P/N 11-526
Retail $885.28
P/N 10-510
Retail $1017.36
safety safety flexpack
TIME-OUT JUMPER
Contains all the PPE you need to stay safe on the job in one convenient bundle.
Times out after a user-defined period to prevent the elevator from running with circuits mistakenly jumped out.
P/N Retail FP-200 $669.91
Hardhat (#473284) Safety Glasses (#S1600)
P/N 15-500
Retail $57.25
Safety Harness (#850) Work Gloves (#H15-05-X) And more!
Check out our video about safety GeAR::
cust fully cont omiz act us f able or d etai
ls
test and measure TEST WEIGHT CARTS
governor overspeed wheel
The tried and true method for elevator testing. Come with interchangeable weights, rubber tires with roller bearings, a locking bar, a padlock, and (2) keys.
Just chuck this handy tool in a drill and use it to spin the governor wheel till it trips (up to 4000 FPM).
P/N Description Retail 10-915 250-lb Cart w/ Weights $759.50 10-900 500-lb Cart w/ Weights $1391.70
P/N 30-200
Retail $252.00
door pressure gauge
door gap gauge
Use this gauge to set proper door closing pressure. Also great for checking belt tension on hydro pumps, or for checking car balance.
Wedge-style measuring tool with a sliding indicator that displays the door gap. Quick, objective, and accurate.
P/N 10-700
P/N 30-110
Retail $39.09
Retail $39.31
henning Donut sensors These "DONUT" load sensors from Henning are a sweet alternative to traditional methods of weighing elevators. These sensors measure absolute weight at each rope or belt, eliminating the need to calibrate with physical weights. The Plug 'n Play sensors permanently install directly at the hitch point, under the springs/bushing assembly, and are ready for use after connection with the evaluation unit AE12 and the elevator controller. You'll be on a roll when you switch to Henning Donut Sensors as a permanent solution for elevator load weighing. P/N 455250 455255 455260 455265
Application Range 0 - 660 lbs 0 - 1100 lbs 0 - 2200 lbs 0 - 7700 lbs
Retail $112.50 $118.19 $154.11 $225.00
