InSight Flight Deck for the Falcon 900B

Universal Avionics’ InSight flight deck upgrade for the Falcon 900B features a fully integrated display system with substantial capabilities, including Data Communications (Data Comm), Satellite-Based Augmentation System (SBAS) Localizer Performance with Vertical Guidance (LPV), and Automatic Dependent Surveillance- Broadcast (ADS-B) Out.

The retrofit package positions the aircraft for today's avionics technologies as well as future growth, allowing for future add-ons like the ClearVision™ Enhanced Flight Vision System (EFVS) with SkyLens™ Head-Wearable Display (HWD), which provides a cost-effective and modern alternative to a traditional fixed Head-Up Display (HUD).

Key Features & Benefits

The InSight Display System is designed as an integrated flight deck solution for the Falcon 900B, featuring:

! Embedded Synthetic Vision (SVS) with advanced mapping capability and 3D Terrain.

! Electronic charts.

! Radio control.

! Broadcast weather.

! Terrain Awareness Warning System (TAWS).

The InSight avionics modernization package includes LPV Approach capability, enabling more direct routes provided by the SBAS-Flight Management System (FMS) leading to fuel savings and decreased flight time.

You will benefit from less maintenance costs and increased Mean Time Between Failure (MTBF) with four new 10.4” diagonal electronic flat panel displays to replace your older analog flight instruments.

Reversionary modes between the Primary Flight Display (PFD) and Multi- Function Display (MFD) guarantee redundant capabilities, offering the safest flight deck operating environment.

The InSight PFD presents flight critical data such as flight guidance, air data, vertical and lateral deviation indicators,

navigation data, radio altimeter, attitude, heading, flight director, Horizontal Situation Indicator (HSI), airspeed, altitude, vertical speed, and turn coordination instruments.

The InSight MFD presents map data such as flight plan, Navigational Aids (NAVAID), airports, airways, controlled airspace, charts, terrain, traffic, weather, and lightning depiction. The MFD may also display SVS terrain maps, enhanced multi-layered moving maps with own-ship position, and an SVS 3D map for increased situational awa-reness.

Both the PFD and MFD can be pilot configured to display desired flight critical information during various phases of flight.

The optional UniLink™ Communications Management Unit (CMU) imagery such as wind, weather, and ground communication information may also be displayed on the MFD.

Your aircraft will lose up to 200 lbs. of weight with this installation, and your flight deck will be refreshed with a cleaner pedestal and flight panel since the InSight Display System is primarily controlled through the Touch EFIS Control Display Unit (ECDU), minimizing knobs and buttons.

Required databases can be uploaded via a SolidState Data Transfer Unit (SSDTU)

or a secure disk card scanner optimizing the fastest database upload times for databases; no more sitting in a hot flight deck waiting for your databases to upload.

All new installations carry our standard two-year warranty with optional extended warranty plans available.
