TVSS for Broadcast Facilities The author is owner of Rural Florida Communications Cooperative. He is a retired AT&T employee who has a great deal of experience protecting communications facilities from lightning and surges. He saw Mark Persons’ recent account in Radio World of a lightning strike to the pole supporting the KRJM STL antenna and was inspired, first, to provide some tips for John Bisset’s Workbench column in the Dec. 9 issue, then

RADIOWORLD.COM

an old myth. I have heard from a number of engineers that “If you take a direct hit, it’s all over; there is nothing you can do to prevent that.”

Such a statement is patently false.

The tier one carrier I retired from has tens of thousands of cell sites and switching offices all over the U.S., and they take thousands of direct hits annually without sustaining any damage at all.

Why? Because we engineer layered lightning protection into each site. Be it standalone, collocated on a broadcast tower or on a rooftop, proper protection equals greatly lowered losses and greatly increased uptime.

So how is this done? Well, let’s use the example of KRJM(FM), which Mark Persons wrote about in “What Happens When Lightning Hits? A Case Study,” which appeared in Radio World in October, and whi ch you can find at radioworld.com by searching for keyword KRJM. Beginning with the improperly protected and grounded pole and

It’s not impossible to protect your facility from damage from a direct lightning hit

BY WAYNE ECKERT

|

offer the following in-depth article for readers of RW Engineering Extra. We in turn are inspired to share it with you.

A wise man who invented the air terminal, Benjamin Franklin, once stated, “An ounce of prevention is worth a pound of cure,” and the lightning damage at KRJM bears witness to that.

Now, let me start with dispelling

(continued on page 4) Getty Images/Dnes Mszros / 500px

Antenna Z out

Xa Z in From Transmission Line

Xb R Xc jX

OK Everybody It’s Tee Time!

Dave Dybas offers a primer for calculating 90-degree T networks.

Page 14

ACCESS studio codecs, now with AES67 compatibility.

ACCESS NX Rack and ACCESS MultiRack, now shipping.

Contact us today to learn more: www.comrex.com | +1 978 784 1776

3

ENGINEERING EXTRA Vol. 45 No. 4

FROM THE TECH EDITOR

February 10, 2021

www.radioworld.com FOLLOW US www.twitter.com/radioworld_news www.facebook.com/RadioWorldMagazine CONTENT Managing Director, Content Paul J. McLane, paul.mclane@futurenet.com, 845-414-6105 Senior Content Producer — Technology Brett Moss, brett.moss@futurenet.com Technical Advisors Thomas R. McGinley, Doug Irwin Technical Editor, RWEE W.C. “Cris” Alexander Contributors: Susan Ashworth, John Bisset, James Careless, Ken Deutsch, Mark Durenberger, Charles Fitch, Travis Gilmour, Donna Halper, Craig Johnston, Alan Jurison, Paul Kaminski, John Kean, Peter King, Larry Langford, Mark Lapidus, Jim Peck, Mark Persons, Stephen M. Poole, James O’Neal, Rich Rarey, Jeremy Ruck, John Schneider, Randy Stine, Tom Vernon, Jennifer Waits, Chris Wygal Production Manager Nicole Schilling Managing Design Director Nicole Cobban Senior Design Director Lisa McIntosh and Will Shum ADVERTISING SALES Senior Business Director & Publisher, Radio World John Casey, john.casey@futurenet.com, 845-678-3839 Publisher, Radio World International Raffaella Calabrese, raffaella.calabrese@futurenet.com, +39-320-891-1938 SUBSCRIBER CUSTOMER SERVICE To subscribe, change your address, or check on your current account status, go to www.radioworld.com and click on Subscribe, email futureplc@computerfulfillment.com, call 888-266-5828, or write P.O. Box 282, Lowell, MA 01853.

LICENSING/REPRINTS/PERMISSIONS Radio World is available for licensing. Contact the Licensing team to discuss partnership opportunities.

Head of Print Licensing Rachel Shaw licensing@futurenet.com MANAGEMENT Senior Vice President, B2B Rick Stamberger Chief Revenue Officer Mike Peralta Vice President, Sales & Publishing, B2B Aaron Kern Vice President, B2B Tech Group Carmel King Vice President, Sales, B2B Tech Group Adam Goldstein Head of Production US & UK Mark Constance Head of Design Rodney Dive FUTURE US, INC. 11 West 42nd Street, 15th Floor, New York, NY 10036

All contents ©Future US, Inc. or published under licence. All rights reserved. No part of this magazine may be used, stored, transmitted or reproduced in any way without the prior written permission of the publisher. Future Publishing Limited (company number 02008885) is registered in England and Wales. Registered office: Quay House, The Ambury, Bath BA1 1UA. All information contained in this publication is for information only and is, as far as we are aware, correct at the time of going to press.

Future cannot accept any responsibility for errors or inaccuracies in such information.

You are advised to contact manufacturers and retailers directly with regard to the price of products/services referred to in this publication. Apps and websites mentioned in this publication are not under our control. We are not responsible for their contents or any other changes or updates to them. This magazine is fully independent and not affiliated in any way with the companies mentioned herein.

If you submit material to us, you warrant that you own the material and/or have the necessary rights/permissions to supply the material and you automatically grant Future and its licensees a licence to publish your submission in whole or in part in any/all issues and/or editions of publications, in any format published worldwide and on associated websites, social media channels and associated products. Any material you submit is sent at your own risk and, although every care is taken, neither Future nor its employees, agents, subcontractors or licensees shall be liable for loss or damage.

We assume all unsolicited material is for publication unless otherwise stated, and reserve the right to edit, amend, adapt all submissions.

Are You Prepared for Lightning?

It can strike anywhere, in any month of the year

BY CRIS ALEXANDER

The worst lightning damage I ever saw happened in the month of February; and it was, in more than one sense, a perfect storm.

We were in the process of upgrading our Detroit FM facility, replacing a 1985-vintage Continental 27.5 kW transmitter with a much newer version of the same transmitter. The aux had long been an RCA BTF20, and our chief engineer had pulled it out of service in preparation for installing the new rig.

The new transmitter was at the site and still on the skid and wrapped in plastic. In other words, we had no working auxiliary transmitter.

In February in Michigan, we’re usually much more concerned about snowstorms and antenna icing than lightning; but this particular year, a warm weather system moved through and fired off a line of severe thunderstorms.

VAPORIZED At that time I had been with the company for about a decade, and I was well acquainted with the propensity of that particular tower, a 500-foot Pirod free-standing Detroit landmark, to take “grand mal” lightning hits.

I had done everything I knew at the time to mitigate that. I had an array of ground rods at the tower base, and all transmission lines were bonded to that array where they departed the tower. It had been a good while since we’d taken a hit that produced damage.

When the storm system came through, BOOM! The tower took one of those grand mal hits, and the station was knocked off the air.

The air staff called the engineer, who took one look at the situation and called me. I caught the next flight from Dallas to Detroit.

Looking at the Continental transmitter, I couldn’t believe my eyes.

Those familiar with that design know that it has two rows of seven panel-mount fuse holders in the middle of the front panel of the rightmost (power supply) cabinet. Every one of those fuse holders was … gone!

Vaporized!

Looking behind the panel, the wires, some not in too good a shape, were still there, the ends turned into beads where the copper strands had melted.

It didn’t take me long to make an executive decision.

There was no telling what other damage there was inside that transmitter, so for the moment I forgot about it and focused on getting the new-on-the-skid transmitter connected and running.

Make it part of your routine to check ground connections like this UFER ground.

That took a few hours, and it wasn’t the prettiest installation, but it got the station back on the air.

Thankfully there was no other significant damage to studio equipment, although as I recall, a good bit of ancillary equipment in the transmitter room was blasted to smithereens and had to be replaced or bypassed.

MISSING CONNECTION With that done, I started doing a post-mortem of sorts to try to figure out what had happened. After all, if it happened once, it could happen again.

I found that the strap connecting the main 3-1/8(continued on page 4)

THIS ISSUE FEBRUARY 10, 2021 TVSS for Broadcast Facilities . . . . . . . . . . . . . . . . . . . . . . . . 1 Are You Prepared for Lightning? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 Broadcast Frequency Measurement Methodology. . . . . . . . . . . . . . . . . . . . . 10 OK, Everybody, It’s Tee Time!. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14 The Natural Progression of Virtualization. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17 Using the SNMP Protocol in Broadcast Monitoring . . . . . . . . . . . . . . . . . . . . . . . . 18 Reader’s Forum. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

I found pieces of those fuse holders on the floor several feet from the front of the transmitter.

We are committed to only using magazine paper which is derived from responsibly managed, certified forestry and chlorine-free manufacture.

The paper in this magazine was sourced and produced from sustainable managed forests, conforming to strict environmental and socioeconomic standards. The manufacturing paper mill and printer hold full FSC and PEFC certification and accreditation.

Radio World (ISSN: 0274-8541) is published bi-weekly with additional issues in February, April, June, August, October and December by Future US, Inc., 11 West 42nd Street, 15th Floor, New York, NY 10036-8002. Phone: (703) 852-4600, Fax: (703) 852-4583. Periodicals postage rates are paid at New York, NY and additional mailing offices. POSTMASTER: Send address changes to Radio World, P.O. Box 282, Lowell, MA 01853.

4

RADIOWORLD ENGINEERING EXTRA |

@radioworld_news

TVSS (continued from page 1)

ending at the last burned-out device, this is a perfect example of where an ounce of prevention could have prevented a lot of heartburn.

Let’s start with the pole. When I see a pole shelled out from lightning, the first thing I look for is a down conductor. I could be incorrect, but I didn’t see one on that pole.

A down conductor is a simple lightning protection device. Before the pole is placed, an AWG #6 hard-drawn copper conductor is placed on it using fencing staples, attaching it from the top of the pole to the butt. The installer leaves six or so inches of the conductor standing above the top of the pole and coils up a few feet of it on the butt, starting in the center, and where the conductor crosses over itself, places a staple diagonally to connect the two conductors to each other.

The goal is to produce a low-resistance, low-impedance grounding electrode on the butt of the pole. When the pole is placed in the mounting hole, it will make good contact with the earth, producing a good solid grounding electrode.

The down conductor provides a

PREPARED? (continued from page 3)

inch rigid transmission line to the station reference ground (that array of rods I mentioned earlier) had been severed.

Lightning evidently had hit the main antenna, which is on a pole on the top of the tower, and the current travelled down the rigid line right to the older Continental transmitter.

Some of the current no doubt flowed through the tower structure to ground, but evidently the path to ground through the transmitter cabinet had a much lower impedance.

The transmitter cabinet was connected to a safety ground that was eventually tied to the service entrance ground and whatever ground Edison provided. And evidently, enough potential was developed across the Bakelite (or whatever the material) panel-mount fuse holders that they vaporized. I found pieces of those fuse holders on the floor several feet from the front of the transmitter.

One side of most if not all those fuses was connected directly to the incoming AC power phases, and (again, evidently) those phase conductors, which were shunted to ground with an LEADynatech lightning suppressor, present-

RadioWorldMagazine

bypass for the lightning energy to earth, sparing the pole and any attachments from damage. See Fig. 1.

If the pole is already placed, a down conductor can be added by placing a ground rod with a minimum length of eight feet into the earth.

One important note: Always call for a utility locate before driving a ground rod or doing any digging. In most states, the number is 811. Failure to do so can get you killed, or if you survive hitting a buried utility line, the least you’ll get is a substantial bill from the utility for the underground damage you caused.

The installer then installs the down conductor in the same manner as a new pole, minus the below-grade work, connecting the down conductor to the grounding electrode.

All that protects the pole, but what about attachments?

February 10, 2021

The first step is to bond all attachments to the down ground lead with an AWG #6 copper conductor. That’s your first layer of protection.

The next step is surge protection, commonly referred to as Transient Voltage Surge Suppression.

A TVSS can be installed in one of two locations. The best location is where the cables coming off the tower or pole enter the building. However, if the building is metal, it is better to deploy a primary TVSS near the base of the pole or tower.

If the TVSS is rated for outdoor installation, a cabinet is not required.

However, most of the time you will want to keep the TVSS in a dry location and out of sight.

Either way, the TVSS should be installed on a common insulated buss (continued on page 6)

I have heard from a number of engineers that “If you take a direct hit, it’s all over; there is nothing you can do to prevent that.” Such a statement is patently false.

Fig. 1: A properly installed pole with down lead.

ed a lower impedance to ground than the safety ground on the transmitter cabinet.

All the grounds were at one time tied together, but in the process of uninstalling the old RCA aux, somehow one critical ground conductor was disconnected.

We wasted no time repairing the broken strap that gave lightning current a place to jump off transmission lines before entering the building, and we brought in an electrician and had him bond all the grounds together so that the tower ground, station reference ground, service entrance ground and lightning suppressor ground were all at the same potential.

I can’t remember what all was blasted in that Continental transmitter, but we did fix it and it saw many years in auxiliary service.

NOW IS THE TIME The point of this sordid account … well, there are a couple of points.

First, a lightning hit can happen at any time, during just about any month of the year.

In Colorado where I live, we sometimes experience a phenomenon called “thundersnow,” where we get lightning and thunder during snowstorms. I’ve never experienced that anywhere else, but my guess is that it’s not uncommon

anywhere it snows. Everywhere else, a passing weather system can fire off lightning just about anytime.

Next, the best way to prevent lightning damage is to give lightning a place to go other than into or through your equipment.

That means a jumping-off point where transmission lines, power conductors and control cables leave the tower.

It also means a low-impedance ground, which is more easily achieved in some locations than others. Some soil types may require chemical rods (which you have to maintain). And it means keeping all grounds at the same potential, with heavy-gauge wire used to connect rods and bond everything together.

There are a lot of good resources out there dealing with lightning protection, including NFPA780, which is the National Fire Protection Association’s “Standard for the Installation of Lightning Protection Systems.”

Radio World has an excellent ebook available titled “Is Your Transmitter Ready for Lightning Season?” Find it at radioworld.com/ebooks and scroll down to the 2019 issues.

Broadcast Engineering Conference papers have been presented on the topic.

And of course there’s an excellent chapter on the topic in the 11th Edition of the

NAB Engineering Handbook. A search of the internet will turn up numerous other resources.

Whether or not you get lightning in your area outside the usual thunderstorm season, now is the time to inspect your facilities and prepare. Forewarned is forearmed.

We still get the occasional lightning strike on that Detroit tower — we have experienced two in the past 12 months — but we seldom see any direct damage. Our excellent engineering staff in Detroit is well aware of the potential (no pun intended) for damage and makes a visual inspection of the entire ground system, including transmission line bonds, part of their routine.

That kind of thing should be part of every broadcast engineer’s routine, especially as we head into thunderstorm season.

In this issue, Wayne Eckert, who spent many years protecting AT&T sites from lightning damage, offers tips so that you can apply some of his techniques to broadcast studio and transmitter facilities. We would do well to pay attention to what he has to say.

Cris Alexander, CPBE, AMD, DRB, is director of engineering for Crawford Broadcasting. Email him at rweetech@ gmail.com.
