Sico Dance Floors

Portable Dance Floors Superior Craftsmanship, World Class Recognition.

| www.sicoinc.com |

SICO QUALITY

We invented the first professional portable dance floors in 1964, and continue to be the leading manufacturer and innovator in this product category throughout the world! Each SICO® dance floor is manufactured with the superior craftsmanship, stunning aesthetics, close attention to detail and value-added features that have become our trademark.

®

A Safer Dance Floor

Low-Profile Trim

Fast & Easy Setup

Positive locking floor means less separation between panels and a safer dance floor. Easily replaceable if damaged.

Wide trim creates and 11 degree transition slope. Easier transition means reduced liability. Available in silver, black and gold.

No specific order for setup or training required. Change the ­configuration without dismantling entire floor.

Dance Floor Features High-Pressure Laminate Surface Anodized Low-Profile Trim Cam-Lock Positive Locking System Innovative Core Construction Tongue & Groove Edge Design 4’x4’ Standard Panels (122cm x 122cm)

Starlight II* (Waterproof) Laminate Aluminum Structural Foam Sealed Backer

Cam-Lam* Laminate MDF Balsa Laminate

*Patented |

www.sicoinc.com

|

SICO® Cam-Lam Portable Dance Floors An extremely durable laminate surfaced portable dance floor with positive lock cam-locking system for indoor and temporary outdoor use.

Features, Advantages & Benefits Large 4'x4' Square Panels - Spacious 4'x4' (122cm squares), or 16 sq. ft. panels are almost twice the area compared to conventional 3'x3’ (91cm squares) or 9 sq. ft. panels.

Solid Floor Contact - All panels make 100% floor contact so there is no possibility of breakthrough. Eliminates the flexing of panels.



Precision Tongue & Groove Design – Allows dance floor panels to easily assemble and disassemble.

Fewer panels mean less storage space, and combined with the cam-lock, setting-up and taking down can be done in almost half the time of smaller panels.



Manufactured square panels guarantee's a perfect fit every time.



Panels weigh 48lbs. (22kg) each. Panels are shipped two per carton.

Balsa Wood Core - High strength, low-density balsa wood is sandwiched between tempered hardboard and high grade laminates for a fully-balanced and lightweight design.

High Grade Laminate Surface - Resists chipping, scratching and fading. Eliminate the costly re-finishing costs of wood.

Cam-lock Positive Locking System - A proven locking system for over 15 years. Self-Aligning pins perfectly squares this floor for an easy and fast set-up.

Continuous Planking Design - Provides a beautiful floor that will enhance your decor.

Anodized Border Trim - Each section of border trim provides a modest 11° slope and a broad 6.25" width allowing for easy access to every floor. Each trim piece is grooved for a slip resistant surface. Available in black, silver or gold.

Low Profile Design - At only ¾" (2cm) thick, SICO's lower profile floor allows easier access and egress.

Transport/Storage Caddies - Easily load and un-load up to 24 panels and all matching trim from both sides. Convenient slots protect and neatly organize panels and trim components during transport.

Serial Number - Provides easy product identification.

Warranty – Protected by a 3-Year Warranty against manufacturer’s defects and 10-Year Cam-Lock system warranty.

Laminate Color Options

Amber Cherry

Cherry Rose

Northern Birch

Black

White

OPTIONS Choose Indoor or Outdoor Choose from the indoor-only Cam-Lam or upgrade to the Starlight II so that you can bring the party outside under the starlight.

Indoor

Outdoor

Choose Laminate Choose from 13 standard high-wear laminate patterns. Many other patterns available at Wilsonart.com.

Colombian Walnut

7943K

Neowalnut

7991

Buka Bark

7982

Sterling Ash

7995

Boardwalk Oak

7983

White Driftwood

8200K

Pasadena Oak

7986

Portico Teak

8210K

Amber Cherry

7919

Cherry Rose

2013

Northern Birch

2040

Black

1595

White

1570

Choose Trim Color Choose from three standard color options to frame your dance floor.

Match your current decor with ease.

Silver

Black

Gold

*All colors are representative only

DANCE FLOOR LAMINATE OPTIONS

High-Pressure Laminate

Colombian Walnut 7943K

Neowalnut

7991

Buka Bark

7982

Sterling Ash

7995

Boardwalk Oak

7983

White Driftwood 8200K

Pasadena Oak

7986

Portico Teak

8210K

Amber Cherry

7919

Cherry Rose

2013

Northern Birch

2040

Black

1595

White

1570

(High-Wear)

View larger size images at Wilsonart.com.

(Except Cherry Rose & Northern Birch)

Laminate options subject to change.

Always check to ensure a specific pattern is available as availability and finish may change without notice.

Colors are representative only.

Many other laminate patterns available.

7525 Cahill Road, Minneapolis MN 55439

|

1.800.328.6138

|

www.sicoinc.com

|

©SICO Incorporated

Dance Floor Laminate Options - 2/18 - R2 IPG 1K

Specifications Assume that only one-third of your guests will dance, so the number of dancers shown in these graphs is only 33% of your total guests.

Dimensions

Number of Panels

Number of Dancers

Number of Caddies

8'x 8' (244cm x 244cm)

4

16

1

8'x12' (244cm x 366cm)

6

24

1

8'x16' (244cm x 488cm)

8

32

1

12'x16' (366cm x 488cm)

12

48

1

12'x20' (366cm x 610cm)

15

60

1

16'x16' (488cm x 488cm)

16

64

1

16'x20' (488cm x 610cm)

20

80

1

16'x24' (488cm x 732cm)

24

96

1

16'x28' (488cm x 853cm)

28

112

2

16'x32' (488cm x 975cm)

32

128

2

20'x20' (610cm x 610cm)

25

100

1

20'x24' (610cm x 732cm)

30

120

2

20'x28' (610cm x 853cm)

35

140

2

20'x32' (610cm x 975cm)

40

160

2

24'x32' (732cm x 975cm)

48

192

2

24'x36' (732cm x 1097cm)

54

216

3

28'x32' (853cm x 975cm)

56

224

3

32'x32' (975cm x 975cm)

64

256

3

32'x36' (975cm x 1097cm)

72

288

3

36'x36' (1097cm x 1097cm)

81

324

4

36'x40' (1097cm x 1219cm)

90

360

4

40'x40' (1219cm x 1219cm)

100

400

4

SICO® Cam-Lam Dance Floor Dimensions

For More Information Visit: http://www.sicoinc.com/camlam_dance_floor.php 7525 Cahill Road, Minneapolis MN 55439 1.800.533.7426

SPECIFICATIONS Ordering Information

Floor Size

Description

Model No.

Weight

Cam-Lam

DLP24?

45 lbs. (21kg)

Starlight II

DSP54?

43 lbs. (19kg)

In-Use Dimensions

? = Customization Option

Description

Length

Width

Height

Cam-Lam

4’ (122cm)

4’ (122cm)

0.75” (1.9cm)

Starlight II

4’ (122cm)

4’ (122cm)

0.75” (1.9cm)

Storage Dimensions Description

A - Length B - Width

C - Height

Cam-Lam

30” (76cm)

65.5” (166cm) 63.5” (161cm)

Starlight II

30” (76cm)

65.5” (166cm) 63.5” (161cm)

B A

C

Panels

Dancers

Caddies

8’x 8’ (244cm x 244cm)

4

16

1

8'x12' (244cm x 366cm)

6

24

1

8’x16’ (244cm x 488cm)

8

32

1

12’x16’ (366cm x 488cm)

12

48

1

12’x20’ (366cm x 610cm)

15

60

1

16’x16’ (488cm x 488cm)

16

64

1

16’x20’ (488cm x 610cm)

20

80

1

16’x24’ (488cm x 732cm)

24

96

1

16’x28’ (488cm x 853cm)

28

112

2

16’x32’ (488cm x 975cm)

32

128

2

20’x20’ (610cm x 610cm)

25

100

2

20’x24’ (610cm x 732cm)

30

120

2

20’x28’ (610cm x 853cm)

35

140

2

24’x24’ (732cm x 732cm)

36

144

2

20’x32’ (610cm x 975cm)

40

160

2

24’x28’ (732cm x 853cm)

42

168

2

24’x32’ (732cm x 975cm)

48

192

2

24’x36’ (732cm x 1097cm)

54

216

3

28’x32’ (853cm x 975cm)

56

224

3

32'x32' (975cm x 975cm)

64

256

3

32’x36’ (975cm x 1097cm)

72

288

3

36’x36’ (1097cm x 1097cm)

81

324

4

36’x40’ (1097cm x 1219cm)

90

360

4

40’x40’ (1219cm x 1219cm)

100

400

4

Assume that only one-third of your guests will dance, so the number of dancers shown in these graphs is only 33% of your total guests.

Storage Caddy Walk-in design makes loading/unloading easy and safe. Securely holds 24 panels and trim in a 65.5”x30” (166x76cm) footprint.

|

www.sicoinc.com

|

3

FEATURES & BENEFITS Panel Sizing

Construction

Large 4’x4’ Square Panels: Spacious 4’x4’ (122cm squares), or 16 sq. ft. panels are almost twice the area compared to conventional 3’x3’ (91cm squares) or 9 sq. ft. panels.

• Fewer panels mean less storage space, and combined with the cam-lock, setting-up and taking down can be done in almost half the time of smaller panels.

• Manufactured square panels guarantee’s a perfect fit every time.

Cam-Lock Positive Locking System: A proven locking system for over 20 years. Self-Aligning pins perfectly squares this floor for an easy and fast set-up.

Dance Surface High-Wear Laminate: More than 7X the abrasion and scuff resistance of traditional laminate. Resists chipping, scratching and fading. Eliminate the re-finishing costs of wood.

Anodized Border Trim: Each section of border trim provides a modest 11° slope and a broad 6.25” (16cm) width, 5” (13cm) width for Original, allowing for easy access to every floor.

Each trim piece is grooved for a slip resistant surface. Available in black, silver or gold.

Low Profile Design: Allows easier access and egress.

All floor profiles are less than 1” (2.5cm).

Protective Backer: All floors are manufactured with a protective backer which resists moisture.

Indoor/Outdoor Use: Panel is 100% waterproof and can be used under any weather conditions without having to worry about warping or delamination.

(Starlight II Only) Precision Tongue & Groove Design: Allows dance floor panels to easily assemble and disassemble without a panel sequence.

Solid Floor Contact: All panels have 100% floor contact so there is no possibility of breakthrough. Eliminates the flexing of panels and keeps parquet from coming loose.

Transport & Storage Transport/Storage Caddies: Each caddy holds 24 panels and all matching trim. Easy loading feature allows loading and un-loading of panel and trim from both sides. Each unit comes with convenient slots that protect panels and keeps your components neatly organized.

Limited Warranty 10-Year Cam-Lock system warranty.

3-year limited warranty on dance floor system. Visit www.sicoinc.com for warranty details.

Serial Number: Dance floor panels are permanently marked for easy identification.

Space Design Take advantage of our FREE space design service to determine the optimal layout and number of products for your space.

T-6 Aluminum Metal Edge: Panels are joined together by utilizing a tongue and groove, T-6 aluminum feature edge that protects the perimeter of each panel.

|
