SINGLE FAMILY MASONRY SCHOLARSHIP SUBMISSION

Summer 2022

THIS IS THE HOUSE I GREW UP MY WHOLE LIFE. IT’S A RESIDENTIAL SINGLE-FAMILY HOUSE IN AN URBAN AREA IN ILLINOIS. MY INTENTION IS TO MAKE A PATIO DESIGN AND PLACED IN FURNITURE, BUT TO MAKE THAT, I BUILT A REPLICA OF MY PARENTS HOME. THE WALL EXTERIOR IS BRICK. I DESIGNED A PATIO FOR MY PARENTS TO USE IN THE FUTURE.

NORTH ELEVATION SHOWING FRONT ENTRANCE

THE MARTINEZ HOUSE

THIS IS THE HOUSE I GREW UP MY WHOLE LIFE. IT’S A RESIDENTIAL SINGLE-FAMILY HOUSE IN AN URBAN AREA IN ILLINOIS. MY INTENTION IS TO MAKE A PATIO DESIGN, BUT TO MAKE THAT I BUILT A REPLICA OF MY PARENTS HOME, BUT WITH THE EXTERIOR BEING A BRICK WALL. I DESIGNED A PATIO FOR MY PARENTS TO USE IN THE FUTURE.

North Perspective The Martinez House

NORTH ELEVATION SHOWING FRONT ENTRANCE

THIS IS THE HOUSE I GREW UP MY WHOLE LIFE. IT’S A

South Perspective

THE SIDE THAT GETS THE MOST SUN IS THE SOUTH OF THE BUILDING, WHICH IS SHOWN IN THE SOUTH PERSPECTIVE.

THE ENTRY TO THE BACKYARD ARE THROUGH THE BACK SLIDING DOOR OR THE WEST FENCE BY THE SINGLE FAMILY HOME.

West Perspective

AERIAL VIEWS SHOWING FULL HOUSE AND BACKYARD WITH FURNITURE PLACEMENT AND SOCIAL INTERACTIONS.

Fall 2021

COMMERCIAL DESIGN: COMMUNITY CENTER

THE USE OF VENDORS/FOOD TRUCKS AND HAVING OUTDOOR SEATING IN FRONT OF THE BUILDING AND ON THE TERRACE ALLOWS PEOPLE TO INTERACT WITH EACH OTHER, WHICH GIVES PEOPLE RELAXATION. THERE ARE ALSO SPACES IN THE BUILDING THAT HAVE MIXED USE, SUCH AS A SPACE THAT CAN CHANGE INTO A KITCHEN CLASS OR A VENDOR RETAIL AREA. AN AUDITORIUM THAT CAN CHANGE TO A BIGGER VENDOR RETAIL AREA FOR MORE PEDESTRIANS TO INTERACT WITH.

AXON DIAGRAM RESPONDING TO SOCIAL INTERACTION AND VENDORS/ FOOD TRUCKS

AUDITORIUM OR RETAIL AREA

KITCHEN OR RETAIL

GARDEN ROOM

OUTDOOR SEATING AREA

Ground Floor Plan

FACADE DEVELOPMENT DIAGRAM/ NORTH ELEVATION

OAK WOOD- EGRESS DOORS, MAIN DOOR, AND COLUMNS

GLASS- WINDOWS, KITCHEN SLIDING DOOR, TERRACE DOOR, TERRACE RAILINGS

BRICK- EXTERIOR WALLS

FIBER CEMENT- JOIST ON FLOOR LEVEL, AND MULLIONS

STEEL- GARAGE DOORS

2ND FLOOR PLAN

Longitudinal North Section

3RD FLOOR PLAN
