HAMM HC Series Compact Rollers
Page 54 • September 7, 2022 • www.constructionequipmentguide.com • Paving Section • Construction Equipment Guide With the HC series, Hamm is launching a new generation of compactors on the market. With operating weights of 24,251 to 55,115.6 lbs. and a wide range of equipment variants, they can comply with an extremely wide range of requirements.
HC Series: New Generation of Compactors for Earthworks
Hamm is attending bauma 2022, where it will present the HC series — a new generation of earthwork rollers for all markets.
The compactors achieve a high level of compaction power while simultaneously achieving a reduction in CO2 emissions. The communication capabilities are new: All models in the HC series are “digital-ready” since they can be equipped with various interfaces for the digital construction site.
One Platform for All Markets
The manufacturer is bringing together the two previous compactor series from Hamm — the 3000 series (Tier 3) and the H series (EPA Tier 4/EU Stage V) — with the HC series on one platform together with models with an operating weight of 24,251 to 55,115.6 lbs.
The diesel engines comply with the regional requirements, and their power varies between 85 and 160 kW, depending on the weight. On all models, the drum width is 84.3 in.
In addition to the previously known sales variants, in future there will be CR machines with reinforced components for applications on difficult terrain and special equipment for applications on rocky ground. New Design
The HC series is recognizable from the new, athletic design and the view channel in the engine hood. A new frame concept also guarantees increased tank volume; in particular, in future, the heavy compactors will be delivered to the construction site with an 88.8 gal. fuel tank.
Impressive Compaction Parameters
In comparison to the predecessor models, Hamm has increased the compaction power. The manufacturer has increased the centrifugal force by up to 15 percent; and the static linear load is as high as 451.6 lbs/in.
There are even innovations when it comes to the steering: A new cast articulated joint with articulated joint lock allows for a greater steering and swing angle with improved kinematics. Due to the optimized weight distribution in combination with the traction control, the gradeability also has been further improved. Furthermore, the front vehicle and the scraper have been redesigned. This has resulted in significantly increased clearance on the drum, meaning that no material can accumulate there, which eliminates cleaning work.
Great Power, Economical in Continuous Operation
Due to new approaches in machine management, the HC series achieves increased overall performance. The integrated ECO mode supports the operator so that they can work in the economical partial-load range as often as possible, which reduces the need for cooling. The speed is reduced for this — but, due to a large travel pump, without compromising the power.
This concept saves fuel and reduces the noise and exhaust gas emissions. With the optional engine stop system, the energy consumption can be reduced even further.
Comfortable Workstation Hamm also has again increased the operator comfort: The cab offers the operator over 20 percent more tread, around 30 percent increased space and numerous storage compartments. Furthermore, the vibrations and the noise level in the cab are significantly reduced due to the materials and design.
A comfortable heating and air-conditioning system, the Easy Drive operating concept, the innovative seat operating unit, the comfortable steering as well as modern ventilation round off the comfort.
Great Visibility During Day, Night
In the dark, the standard LED lights light up the environment in all working situations. At day and night, due to the view channel in the hood, the roller meets the requirements for the field of vision in accordance with DIN EN 474.
On the cab, a large additional mirror with proximity detection improves the view of the immediate environment, and design tricks guarantee low-vibration mirrors. Furthermore, the mirrors can be easily adjusted from the cab. Equipped for Digital Construction Site
The HC series is well prepared for the quality and communication requirements of the future. The “Smart Doc” app, which was developed by Hamm, graphically displays all of the key compaction parameters as well as the compaction progress, and logs the measured rigidity as well as the position data. In the Smart Doc app, even inexperienced drivers can immediately see which areas have been sufficiently compacted and which areas still require compaction. Furthermore, the compactors can communicate, even with digital applications from third parties, via a standardized interface.
For more information, visit www.wirtgengroup.com.
Large slope angles and powerful drives guarantee that the compactors in the HC series achieve excellent compaction on uneven and steep terrain — even on inclines over 60 percent.
Page 58 • September 7, 2022 • www.constructionequipmentguide.com • Paving Section • Construction Equipment Guide GOMACO Appoints Harper District Manager of Southeast United States
Rodney Harper has been named GOMACO’s district manager of the southeast United States. The appointment was made by Kent Godbersen, GOMACO’s vice president of worldwide sales and marketing.
Harper replaces Vinnie Miller, who had managed the territory since 1975 and will be retiring from GOMACO.
Harper’s sales territory will include the states of Louisiana, Mississippi, Alabama, Georgia, Florida, North Carolina, South Carolina, Tennessee, Kentucky, Virginia, West Virginia, southern Illinois and eastern Missouri. He will be responsible for the sales and support of GOMACO’s full line of concrete construction equipment and managing the distributor network within his territory.
Harper has been with GOMACO since 2015, working as a 3D Machine Control Support Engineer in the 3D Controls Department. He has been traveling around the United States setting up 3D stringless guidance systems on GOMACO equipment as well as working trade shows as a member of the GOMACO booth staff.
“Rodney has all of the qualifications necessary to transition into his new role as a GOMACO district manager,” Godbersen said. “He is very knowledgeable on GOMACO’s concrete slipform paving equipment and enjoys working with customers to help meet their project needs. Rodney will be based near Atlanta, Georgia, which will put him in the heart of his new territory to serve our customers.”
For more information, visit www.gomaco.com.
Rodney Harper
Cemen Tech Signs Beard Equipment as Authorized Dealer in Northern Florida
Cemen Tech has signed Beard Equipment Company as the exclusive dealer of Cemen Tech volumetric concrete mixers in northern Florida.
Beard Equipment Company has focused its road building product inventory on paving and compaction equipment. Now, by partnering with Cemen Tech, the company is expanding its offerings to include concrete mixing technology to better serve contractors in Florida.
“We are focused on products that offer solutions to our customers by helping them grow their businesses and profitability. We believe Cemen Tech to be a great fit for our customers and will complement our John Deere construction and Wirtgen Group road building products,” said Drew DeLaney, President at Beard Equipment Company.
“For more than 50 years, Cemen Tech has been the worldwide volumetric concrete leader due to their innovation and high-quality products. Their customer focus and support will ensure an excellent partnership with Beard Equipment.”
Volumetric concrete mixers are known for the ability to increase concrete production efficiency and reduce waste by allowing concrete to be mixed on the job site for the exact quantity needed every time. As today’s construction projects become more specialized and the demand for contractors to be more nimble increases, Beard and Cemen Tech know there is a growing need for precision technology in concrete equipment like that of the C60.
“We partner with companies that value relationships with their customers and employees as much as we do at Cemen Tech,” said Connor Deering, CEO and president at Cemen Tech.
“Beard operates with similar core values and has an excellent reputation in northern Florida. Through the best customer service and best volumetric concrete mixer in the market, I have no doubt contractors in their area will be able to confidently do more and grow their business.”
For more information, visit www.CemenTech.com and www.beardequipment.com.
Columbia,SC 803-791-7100 Florence,SC 843-678-8520 Rock Hill,SC 803-324-9600 Simpsonville,SC 864-963-3645 Myrtle Beach,SC 843-399-2074 Summerville,SC 843-871-2000 Hilton Head,SC 843-784-6766
Kelly Tractor
kellytractor.com
Miami, FL 305-592-5360 Davie, FL 954-581-8181 West Palm Beach, FL 561-683-1231 Clewiston, FL 863-983-8177 Ft. Myers, FL 239-693-9233
Gregory Poole Equipment Company
gregorypoole.com
Fayetteville, NC 910-424-4400 Mebane, NC 919-568-7500 Raleigh, NC 919-828-0641 Washington, NC 252-946-1081 Wilmington, NC 910-371-6301
Carolina Cat
carolinacat.com
Charlotte, NC 704-596-6700 Asheville, NC 828-251-2500 Greensboro, NC 336-294-5240 Hickory, NC 828-464-7045 Monroe, NC 704-292-1555 Boone, NC 828-268-9992
roll wit h t he lea a de rs.
When y p g big and small. Industr q y p , y g
y-ex lusic ve et hnologies lic ke our 8-amplitude drums a y alnd the real-time density v
all jobs lues of
Compact A ss ist with Density Direct™ ma ek remarkable precision an everyday o cc urren e.c
oolvour nearest VContact y Construction Equipment de ation and staraler loc t boost our productivity and proing y .odayofits t
RICHMOND MACHINERY & EQUIPMENT
Wirtgen’s New Paving Train Makes Debut at bauma 2022
WIRTGEN from page 47
The concrete is poured evenly over the pre-placed steel rebar in front of the slipform paver and distributed across the entire working width. The SP 94(i) slipform paver then compacts and paves the concrete mix.
The paver at the show, which has a maximum working width of 32 ft., is fitted with a TeleMold system. It enables fast and convenient alteration of the working width by up to 3 ft. on each side, resulting in an overall increase of 6 ft. This increases the flexibility and productive utilization time of the machine by the reduction of down times.
The final link in the process chain is the TCM 180(i). This field-proven texture curing machine applies the desired finish to the surface of the freshly paved concrete. It enables the realization of lengthwise and crosswise textures and pre-defined surface roughness in accordance with project specifications. It also allows the application of a range of different curing agents to the concrete surface, for example a concrete surface retarder. year’s Bauma is the SP 124(i). The 4-track paver can be configured for paving at a working width of 39 ft. and fits seamlessly into the fleet-wide operating concept of slipform pavers from WIRTGEN.
The machine is fitted with the latest generation of the integrated dowel bar inserter. The dowel bars are extracted from the magazine by a chain feed system with an endless chain and automatically transported to the insertion location.
“Smart” cylinders with displacement sensors precisely position the dowel bar inserter at the desired locations. The high degree of automation reduces the proportion of manual work required, increases process reliability, and, ultimately, the cost-effectiveness of the process.
AutoPilot 2.0: Stringless
Control for Concrete Paving
Developed in-house by Wirtgen, AutoPilot 2.0 is a control system for stringless paving that serves as an alternative to the conventional method of mechanically scanning a stringline. The system, which precisely controls both the height adjustment and steering of the machine, is available for all offset pavers and placer/spreaders.
A GNSS signal and, depending on the configuration, various local sensors (e.g. an ultrasonic sensor on the machine), serve as a reference. The time and effort otherwise required for setting up and removing the stringline is eliminated. It also enables fast and precise paving of tight radii and complex geometries.
The system is conveniently operable from a tablet PC, which also supports the generation and editing of terrain models. Wirtgen AutoPilot 2.0 offers machine control and stringless control for concrete paving in one.
For more information, visit wirtgengroup.com.
Page 62 • September 7, 2022 • www.constructionequipmentguide.com • Paving Section • Construction Equipment Guide Robert Mendenall, Former Sr. Vice President of Volvo CE, Passes Away
Robert “Bob” Mendenall passed away peacefully Aug. 16, 2022, at his home in Lexington, S.C., surrounded by his children and his wife, due to complications from cancer.
Mr. Mendenall was born Oct. 30, 1943, at his parents’ home in Bridgman, Mich. He was a 1961 graduate of Bridgman High School and graduated Lake Michigan College in 1963 with an associate degree in Mechanical Engineering. Mr. Mendenall did not believe in wasting any time, he started working at Clark Equipment the very next day. He retired 37 years later as senior vice president of product support of Volvo Construction Equipment.
Mr. Mendenall loved his family. He enjoyed coaching his son’s ball teams and working to provide his special needs son with everything life had to offer. He would rise before dawn to get his daughter to the ice skating rink before school for practice sessions. A proud supporter of his grandkids, it was a rare game, recital, competition or performance that Papa missed.
Mr. Mendenall loved playing golf, fishing, riding his
motorcycle or just spending time with his wife, Nancy. Where you found one, you found the other. He loved helping people, working on projects and solving problems. He was known as someone that could fix anything, whether it was something you needed built, or a broken heart you needed mended. He always knew just what to do. He never raised his voice or expected anything in return. He was the rock for his family, a humble friend, and will be dearly missed by all. He is survived by his wife Nancy Mendenall; his sons, Greggory Mendenall and Robert Mendenall (Lisa); his daughter, Rebecca Lancaster (Kevin); and his grandchildren, Zachary and Blake Mendenall, and Olivia and Alaina Lancaster. Mr. Mendenall was preceded Robert “Bob” Mendenall in death by his mother and father, Elownzo Mendenall and Viola Birmingham; his brothers, Melvin and Elvin Mendenall; and his sisters, Lorene Gipson and Irma Taylor. In lieu of flowers, the family is asking for donations to be made to the American Cancer Society, P.O. Box 6704, Hagerstown, MD 21741.
BLANCHARD MACHINERY www.blanchardmachinery.com/paving
Columbia, SC 803-791-7100 Florence, SC 843.678.8520 Rock Hill, SC 803.324.9600 Simpsonville, SC 864.963.3645 Myrtle Beach, SC 843-399-2074 Summerville, SC 843.871.2001 Hilton Head, SC 843-784-6766
GREGORY POOLE EQUIPMENT COMPANY www.gregorypoole.com
Fayetteville, NC 910-424-4400 Mebane, NC 919-568-7500 Raleigh, NC 919-828-0641
OSHA’s New Directive Only Revises Its Existing Operator-in-Training Section
OSHA from page 32
The evaluation must be conducted by an individual who has the knowledge, training and experience necessary to assess equipment operators. This knowledge, training and experience is not necessarily the same as the knowledge, training and experience to perform the particular construction operations or processes themself. Additionally, the evaluator must be an employee or agent of the employer.
Within the flowchart for crane operator evaluation, the key elements are: • “Has the operator been evaluated on the assigned equipment” • “Did the employer determine the evaluator is competent?” (If yes, please document) • “Did the evaluator determine the operator is competent to operate a crane which is similar to that assigned, and for a task similar to that assigned?” • “Does the required evaluation documentation include at least the six pieces of information specified?”
If the employer has not conducted the required evaluation(s) of the operator that serves as the basis for the operation of particular equipment for the particular task, then the operator is considered as an operator-in-training with respect to that equipment or task (see requirements for operators-intraining).
Multi-Employer Work Sites
For multi-employer work sites, OSHA states that “controlling contractors must exercise reasonable care to prevent and detect violations of the crane standard at the construction site.” OSHA goes on to say, “Controlling contractors assume a heightened duty to monitor an operator who is allowed on the site without providing evidence that the operator has been certified/licensed and evaluated in accordance with the crane standard… If the controlling contractor informs the other employers on the site that the crane operator has not provided evidence of certification/licensing, each employer could then take appropriate measures to ensure the safety of its own employees to fulfill its duties as an exposing employer.”
Additional Resources
OSHA also will be releasing the revised Small Entity Compliance Guide and Frequently Asked Questions related to this final part of the rule. In the last cycle these documents were released within a few months of the Compliance Directive.
Avoiding OSHA Citations
The best way to avoid citations by OSHA is to know and understand how the rule affects you, ensure that your operators and those around equipment are properly qualified, and that documentation is in order before OSHA asks. CCO will continue to monitor information released and assist in creating resources to assist the industry in compliance.
