CONSTRUCTION EQUIPMENT GUIDE’S COMPACT TRACK DUMPS CHARTS
Compact Track Carriers, Dumpers & Trucks
MODEL PAYLOAD EMPTY WEIGHT TRACK ENGINE ENGINE LBS. (KG) LBS. (KG) IN. (CM) HP (kW) MFG MOROOKA
MST-300VD 5,200 (2,359) 6,000 (2,722) 13.75 (34.9) wide 67 (50) Caterpillar 2.2 MST-660VD 8,378 (3,800) 8,800 (3,992) 20 (50.8) wide 74 (55.2) Kubota V3307 MST-880VD 10,000 (4,536) 14,200 (6,441) 23.6 (60) wide 120 (89.5) Caterpillar C3.6 MST-1000VD 12,584 (5,708) 16,800 (7,620) 24 (61) wide 148 (110.4) Caterpillar C4.4 MST-1500VD 15,435 (7,001) 24,720 (11,213) 28 (71.1) wide 225 (137.8) Caterpillar C7.1 MST-2200VD 24,255 11,002) 31,820 (14,433) 30 (76.2) wide 250 (186.4) Caterpillar C7.1 MST-3000VD 33,016 (14,976) 33,140 (15,032) 31.5 (80) wide 300 (223.7) Caterpillar C7.1 MST-4000VD 40,422 (18,335) 43,960 (19,940) 33 (83.8) wide 375 (279.6) Caterpillar C9.3 MST-200VDR 4,400 (1,996) 4,500 (2,041) 12 (30.5) wide 24 (17.9) Kubota V1505 MST-700VDR 8,819 (4,000) 10,869 (4,930) 20 (50.8) wide 70 (52.2) Kubtoa V3307 MST-1000VDR 12,125 (5,500) 20,150 (9,140) 28 (71.1) wide 124 (92.5) Caterpillar C4.4 MST-1500VDR 15,435 (7,001) 28,100 (12,746) 28 (71.1) wide 225 (137.8) Caterpillar C7.1 MST-2200VDR 24,255 (11,002) 35,273 (16,000) 31.5 (80) wide 250 (186.4) Caterpillar C7.1 MST-3000VDR/MST-3000VDR+34,171 (15,500) 36,920 (16,747) 31.5 (80) wide 300 (223.7) Caterpillar C7.1 MST-4000VDR 44,092 (20,000) 54,895 (24,900) 33.5 (85.1) wide 416 (310.2) Caterpillar C9.3
MODEL TILTING PAYLOAD EMPTY WEIGHT STRUCK CAPACITY HEAPED CAPACITY DIRECTION LBS. (KG) LBS. (KG) CU YDS. (CU M) CU YDS. (CU M) BERGMANN
Compact Dumpers
C805s Swivel Tip 9,921 (4,500) 7,606 (3,450) 2.5 (1.9) 3.4 (2.6) C807s Swivel Tip 13,228 (6,000) 9,480 (4,300) 3.3 (2.5) 4.7 (3.6) C810s Swivel Tip 19,842 (9,000) 13,669 (6,200) 4.7 (3.6) 6.0 (4.6) Wheel Dumpers
C815s Rear Tip 26,455 (12,000) 20,017 (9,080) 6.5 (5.0) 10.5 (8.0) Three-way Tip 26,455 (12,000) 22,090 (10,020) 5.5 (4.2) 10.5 (8.0) Swivel Tip 26,455 (12,000) 24,559 (11,140) 8.5 (6.5) 10.5 (8.0) Water Truck 3,000 Gallons N/A N/A N/A Track Dumpers
C912s Rear Tip 22,046 (10,000) 31,415 (14,250) 6.1 (4.7) 8.5 (6.5) Swivel Tip 22,046 (10,000) 32,738 (14,850) 6.1 (4.7) 8.5 (6.5)
MODEL TILTING TRAVEL SPEED PAYLOAD HEAPED CAPACITY ENGINE ENGINE EMISSION AIR DIRECTION MPH (KM/H) LBS. (KG) CU YDS. (CU M) HP (kW) MFG LEVEL CONDITIONING PRINOTH
PANTHER T6 rear tip 9.3 (15) 12,000 (5,443) 4.1 (3.13) 143 (107) CAT C4.4 U.S. EPA Tier IV Final EU Stage V YES PANTHER T7R swivel 8.1 (13) 15,432 (7,000) 4.8 (3.67) 200 (150) CAT C4.4 U.S. EPA Tier IV Final EU Stage V YES PANTHER T8 rear tip 6.2 (10) 16,000 (7,257) 5.75 (4.40) 225 (168) CAT C7.1 EPA Tier IV Final EU Stage IV YES PANTHER T12 rear tip 6.2 (10) 25,000 (11,340) 7.65 (5.85) 250 (186.5) CAT C7.1 EPA Tier IV Final EU Stage IV YES PANTHER T14R swivel 8.1 (13) 29,100 (13,200) 9.4 (7.19) 275 (205) CAT C7.1 EPA Tier IV Final EU Stage IV YES PANTHER T16 rear tip 8.1 (13) 33,500 (15,195) 11.5 (8.80) 300 (225) CAT C7.1 EPA Tier IV Final EU Stage IV YES
Compact Track Carriers, Dumpers & Trucks
MODEL SIZE TRANSMISSION TILTING PAYLOAD EMPTY WEIGHT STRUCK CAPACITY HEAPED CAPACITY ENGINE ENGINE DIRECTION LBS. (KG) LBS. (KG) CU YDS. (CU M) CU YDS. (CU M) MFG HP (kW) AUSA
D100AHA Ultra Compact Hydrostatic Front & High 2,200 (998) 2,966 (1,300) 0.52 (.40) 0.74 (0.57) 20.9 (15.6) Kubota D1105E48 D100AHA Compact Ultra Compact Hydrostatic Front & High 2,200 (998) 2,966 (1,300) 0.52 (.40) 0.74 (0.57) 20.9 (15.6) Kubota D1105E48 D100 AHG Ultra Compact Hydrostatic Swivel 2,200 (998) 2,966 (1,300) 0.51 (0.39) 0.71 (0.54) 20.9 (15.6) Kubota D1105E48 D120 AHA Ultra Compact Hydrostatic Front & High 2,600 (1,179) 3,031 (1,375) 0.67 (0.51) 0.91 (0.70) 20.9 (15.6) Kubota D1105E48 D120 AHG Ultra Compact Hydrostatic Swivel 2,600 (1,179) 3,031 (1,375) 0.65 (0.50) 0.9 (0.69) 20.9 (15.6) Kubota D1105E48 D150 AHA Ultra Compact Hydrostatic Front & High 3,300 (1,497) 3,329 (1,510) 0.89 (0.68) 1.1 (0.84) 20.9 (15.6) Kubota D1105E48 D150 AHG Ultra Compact Hydrostatic Swivel 3,300 (1,497) 3,329 (1,510) 0.82 (0.63) 1.18 (0.90) 20.9 (15.6) Kubota D1105E48 D350 AHG Compact Hydrostatic Swivel 7,700 (3,493) 6,130 (2,781) 2.34 (1.79) 2.78 (2.13) 44 (32.8) Kubota D1803CR-T-E5B D450 AHG Compact Hydrostatic Swivel 9,900 (4,491) 6,400 (2,903) 2.69 (2.06) 3.49 (2.67) 45 (32.8) Kubota D1803CR-T-E5B D601 AHG Compact Hydrostatic Swivel 13,000 (5,897) 9,898 (4,490) 4.12 (3.15) 4.12 (3.15) 74.3 (55.4) Deutz TD 3.6 L4 D601 APG Compact Mechanic Swivel 13,000 (5,897) 10,352 (4,696) 3.42 (2.61) 4.12 (3.15) 74.3 (55.4) Deutz TD 3.6 L4 D1000 APG Large Mechanic Swivel 22,000 (9,979) 10,500 (4,763) 4.1 (3.13) 6.26 (4.79) 74.3 (55.4) Deutz TD 3.6 L4 DR601 AHG Large Reverse Hydrostatic Swivel 13,000 (5,897) 10,648 (4,830) 3.21 (2.45) 4.12 (3.15) 74.3 (55.4) Deutz TD 3.6 L4 DR1001 AHG Large Reverse Hydrostatic Swivel 22,000 (9,979) 11,133 (5,050) 4.32 (3.30) 5.1 (3.90) 74.3 (55.4) Deutz TD 3.6 L4
MODEL TILTING PAYLOAD EMPTY WEIGHT WHEEL CAPACITY STRUCK CAPACITY HEAPED ENGINE ENGINE DIRECTION LBS. (KG) LBS. (KG) CU YDS. (CU M) CU YDS. (CU M) HP (kW) MFG FIORI
D40 Swivel 8,820 (4,001) 7,495 (3,400) 305/75-18 2.6 (2.0) 3.5 (2.7) 56 (42) Kohler KDI 1903 D90SW Swivel 19,842 (9,000) 12,566 (5,700) 405/70-20 4.5 (3.4) 6.3 (4.8) 75 (56) Kohler KDI 2504 D100 Swivel 22,046 (10,000) 12,125 (5,500) N/A 4.8 (3.6) 6.8 (5.2) 122 (91) Kohler KDI 3404
MODEL TILTING PAYLOAD EMPTY WEIGHT TRACK WIDTH GROUND PRESSURE HEAPED ENGINE ENGINE DIRECTION LBS. (KG) LBS. (KG) IN. (CM) (LOADED) CAPACITY HP (kW) MFG TERRAMAC
RT6 Rear tilt 12,000 (5,443) 17,880 (8,110) 23.6 (59.9) 5.3 PSI varies based on material 155 (116) @ 2200 RPM Cummins B4.5 Perf. Series, (average is 4.5 yards ) US T4F/EU Stage V RT9 Rear tilt 18,000 (8,165) 26,180 (11,875) 27.5 (69.9) 6.4 PSI varies based on material 225 (168) @ 2200 RPM Cummins QSB 6.7 T4F (average is 6.5 yards) RT14 Rear tilt 28,000 (12,700) 34,260 (15,540) 31.5 (80) 7.4 PSI varies based on material 310 (231) @ 2200 RPM Cummins QSB 6.7 T4F (average is 10.2 yards) RT7R 360 degree 14,000 (6,350) 23,730 (10,764) 27.5 (69.9) 5.5 PSI varies based on material 165 (123) @ 2200 RPM Cummins B4.5 Perf. Series, (average is 5.1 yards) US T4F/EU Stage V RT14R 360 degree 28,000 (12,700) 42,220 (19,151) 31.5 (80) 8.3 PSI varies based on material 320 (239) @ 1800 RPM Cummins QSL9 T4F (average is 10.2 yards) RT6U* N/A 15,380 (6,976) 15,020 (6,813) 23.6 (59.9) 5.3 PSI N/A 155 (116) @ 2200 RPM Cummins B4.5 Perf. Series, US T4F/EU Stage V RT9U* N/A 23,512 (10,665) 20,668 (9,375) 27.5 (69.9) 6.4 PSI N/A 225 (168) @ 2200 RPM Cummins QSB 6.7 T4F RT14U* N/A 35,260 (15,994) 27,000 (12,247) 31.5 (80) 7.4 PSI N/A 310 (231) @ 2200 RPM Cummins QSB 6.7 T4F
Page 68 • September 28, 2022 • www.constructionequipmentguide.com • Off-Road Section • Construction Equipment Guide For Rebrand, Firm Considered Decades of Hauling Heritage
The RA40 on the Rokbak stand at Hillhead.
ROKBAK from page 60 WhatÊs in a Name?
With a small focus group put together from marketing, branding, commercial, sales and dealer development backgrounds, the task of selecting a new name could begin.
“Some of our original shortlist names turned out to be similar to those used elsewhere, but the team came up with one that we all loved and was truly unique and impactful,” said Douglas. “We were told by Legal that they had never seen anything as clean as it, and that we should grab it with both hands.”
The team then consulted a handful of select dealers across Asia, Europe, the Americas and Oceania in an attempt to understand how different cultures would perceive the most critical aspects of the new brand.
“One piece of dealer feedback was that it was important to ensure our eight decades of hauling heritage was embedded in the new brand, which was essential for us too,” said Douglas. “One way we incorporated this is through a ‘Made in Britain’ element within our machine branding for certain markets.
“Of all the dealers we initially tested the Rokbak name and new color on, the majority were immediately enthusiastic, leaving just a couple of individuals who needed to see a little bit more to be convinced. I wasn’t remotely surprised at how quickly they changed their minds at the launch.
True Success
That enthusiasm must have been contagious because when the Rokbak brand was finally revealed on Sept. 1 2021 — gratifyingly taking the media, customers and the competition by surprise — the public reaction was music to Douglas’ ears.
“I was delighted by how well it was received externally,” he said. “The momentum built quickly, with customers and dealers alike eager to get their hands on Rokbakbranded products, whether that was haulers, work wear or coffee mugs. Seeing the news bouncing around social media was great too, perhaps the best feedback you can get.
“When people see the new Sand paintjob in real life they are blown away — it looks incredible on the iron. We’ve been out at a few trade shows and open days this year — including Hillhead, Balmoral Show and ScotPlant — and the feedback has been that our haulers were the best-looking pieces of equipment on site.”
The success of the entire rebranding project also was recognized by a wider audience when the company walked away from the Star Awards 2022 with five accolades from the Marketing Society, as well as a CeeD Industry Award at the start of the year.
For more information, visit www.rokbak.com.
A Montano Co., Inc. www.amontanoco.com 571 Route 212 • Saugerties, NY 12477 845.247.0206
All Island Equipment www.allislandequipment.com 39 Jersey St. • West Babylon, NY 11704 631.643.2605
Butler Equipment www.butlerequip.com 631 New Park Avenue • West Hartford, CT 06110 860.233.5439
Chappell Tractor www.chappelltractor.com 454 Route 13 South • Milford, NH 03055 603.673.2640 251 Route 125 • Brentwood, NH 03833 800.616.5666 391 Loudon Road • Concord, NH 03301 800.358.6007
George & Swede Sales & Service www.georgeandswede.com 7155 Big Tree Rd. Pavilion (Buffalo/Rochester), NY 14525 585.584.3425
Highway Equipment Company www.highway-equipment.com 22035 Perry Highway • Zelienople (Pittsburgh), PA 724.452.7800 Dubois, PA 15801 814.371.3600
Lorusso Heavy Equipment, LLC www.lhequip.com 160 Elm St. • Walpole, MA 02801 508.660.7600 Modern Group Ltd. www.moderngroup.com 2501 Durham Rd. • Bristol, PA 19007 800.866.3376 Allentown, PA 18106 610.398.1101 York, PA 17406 800.866.3376 Edison, NJ 08837 800.866.3376 Hasbrouck Heights, NJ 07604 201.288.1441
Quality Fleet Service, Inc. www.qualityfleetservice.com 548 New Ludlow Road • South Hadley, MA 01075 413.213.0632
Seaview Equipment LLC www.seaviewequipment.com 640 Crescent Ave. • Bridgeport, CT 06608 203.330.0130
TB Equipment & Rental www.tbequipment.net 892 Odlin Rd. • Bangor, ME 04401 207.262.0014
Tracey Road Equipment, Inc. www.traceyroad.com 6803 Manlius Center Rd. • East Syracuse, NY 13057 315.437.1471 • 800.872.2390 Adams Center, NY 315.788.0200 • 888.335.0200 Albany, NY 518.438.1100 • 866.740.8853 Kirkwood, NY 607.775.5010 • 800.370.9488 Queensbury, NY 518.793.9688 • 800.872.2390 Utica, NY 315.765.8746 • 800.872.2390
Shafer Equipment, LLC www.shaferequipmentwv.com 141 Campbell’s Creek Drive • Charleston, WV 25306 304.548.4300
W W E K EE E P A A M E R I C A O O N T R A A C K
MOROOKACARRIERS.COM 804-409-6360
CHART from page 58
MFG. ARTICULATED (A)/ DRIVE OPERATING WEIGHT RATED PAYLOAD ENGINE DRIVE SYSTEM MODEL RIGID (R) CONFIGURATION POUNDS (KGS) TONS (METRIC TONS) TYPE MECH/ELECTR.
DOOSAN
DA30-5 A 6x6 113,318 (51,400) 30 (28) Scania DC9 M DA45-5 A 6x6 156,749 (71,100) 45 (41) Scania DC13 M
HITACHI
EH4000AC-3 R RWD 844,800 (384,000) 238 (216) MTU 16V4000C65 E
KOMATSU
HM300-5 A 6WD 117,892 (53,475) 30.9 (28) Komatsu SAA6D125E-7 M HM400-5 A 6WD 165,644 (75,135) 44.1 (40) Komatsu SAA6D140E-7 M HD325-8 R RWD 155,999 (70,760) 40.3 (36.5) Komatsu SAA6D140E-7 M HD405-8 R RWD 170,671 (77,415) 44.1 (40) Komatsu SAA6D140E-7 M HD465-8 R RWD 228,178 (103,500) 61 (55) Komatsu SAA6D170E-7 M HD605-8 R RWD 252,870 (114,700) 69.4 (63) Komatsu SAA6D170E-7 M HD785-8 R RWD 365,967 (166,000) 101.6 (92.2) Komatsu SAA12V140E-7 M HD1500-8E0 R RWD 550,229 (249,580) 153.2 (139) Komatsu SDA16V159E-3 M 730E-10 R RWD 745,328 (338,075) 205 (186) Komatsu SSDA16V159 AC Elec 830E-1AC R RWD 850,650 (385,848) 244 (222) Komatsu SDA16V160 AC Elec 830E-5 R RWD 901,400 (408,875) 250 U.S ton (227) Komatsu SDA16V160 AC Elec 930E-4SE R RWD 1,115,000 (505,755) 320 (290) Komatsu SSDA18V170 AC Elec 930E-5 R RWD 1,150,000 (521,640) 320 (290) Komatsu SSDA16V160 AC Elec 930E-5 SE R RWD 1,150,000 (521,640) 320 (290) Komatsu SSDA18V170 AC Elec 980E-5 R RWD 1,384,500 (627,999) 400 (363) Komatsu SSDA18V170 AC Elec
