CONSTRUCTION EQUIPMENT GUIDE’S OFFROAD TRUCK CHARTS

see CHART page 69

MFG. ARTICULATED (A)/ DRIVE OPERATING WEIGHT RATED PAYLOAD ENGINE DRIVE SYSTEM MODEL RIGID (R) CONFIGURATION POUNDS (KGS) TONS (METRIC TONS) TYPE MECH/ELECTR.

BELL TRUCKS

B20E LGP A 6WD 76,044 (34,493) 19.9 (18.0) Mercedes Benz (MTU) OM934LA M B25E A 6WD 96,253 (43,660) 26.5 (24.0) Mercedes Benz (MTU) OM936LA M B30E A 6WD 106,505 (48,310) 30.8 (28.0) Mercedes Benz (MTU) OM936LA M B35E A 6WD 140,829 (63,879) 37.0 (33.5) Mercedes Benz (MTU) OM470LA M B40E A 6WD 157,042 (71,233) 43.0 (39.0) Mercedes Benz (MTU) OM471LA M B45E A 6WD 161,656 (73,326) 45.4 (41.0) Mercedes Benz (MTU) OM471LA M B50E A 6WD 178,740 (81,075) 50.0 (45.4) Mercedes Benz (MTU) OM473LA M B60E A 4WD 214,898 (97,476) 60.6 (55.0) Mercedes Benz (MTU) OM473LA M

CATERPILLAR

770G R 2WD 157,000 (71,214) 42.1 (38.2) 772G R 2WD 181,000 (82,100) 51.6 (46.8)

Cat C15 Cat C18 773G R 2WD 226,500 (102,739) 61.0 (55.3) Cat C27 ACERT 775G R 2WD 246,500 (111,811) 70.5 (64.0) Cat C27 ACERT 777G R 2WD 363,000 (164,654) 105.9 (95.0) Cat C32 ACERT 785 R 2WD 550,000 (249,476) 153 (139) Cat 3512E 785D R 2WD 550,000 (249,476) 136 (123.4) Cat 3512C HD 789 (Tier 4 Final/Stage V) R 2WD 715,000 (324,319) 211 (191) Cat 3516E 789D R 2WD 700,000 (317,515) 181 (164.2) Cat 3516C HD 793F R 2WD 851,000 (386,007) 227 (205.9) Cat C175-16 793D R 2WD 846,240 (383,848) 256 (232) Cat 3516B HD 793F R 2WD 851,000 (386,007) 256 (232( 794 AC R 2WD 1,150,000 (521,631) 327 (297) Cat C175-16 Cat C175-16

796 AC R 2WD 1,270,000 (576,062) 360 (327) Cat C175-16 Auto Auto Auto Auto Auto Auto Auto Auto Auto Auto Auto Auto Auto Auto

797F R 2WD 1,375,000 (623,690) 363 (329.3) Cat C175-20

Auto 798 AC R 2WD 1,375,000 (623,690) 410 (372) Cat C175-16 Auto 725 A 6WD 50,795 (23,040) 26.5 (24) Cat C9.3 ACERT Powershift w/ lockup torque converter 730 A 6WD 52,690 (23,900) 31 (28) Cat C13 ACERT Powershift w/ lockup torque converter 730 EJ A 6WD 58,643 (26,600) 31 (28) Cat C13 ACERT Powershift w/ lockup torque converter 735 A 6WD 55,645 (25,240) 35 (32) Cat C13 ACERT Powershift w/ lockup torque converter 740 EJ A 6WD 79,622 (36,116) 42 (38) Cat C18 ACERT Powershift w/ lockup torque converter 740 GC A 6WD 71,377 (32,376) 40 (36.3) Cat C15 ACERT Powershift w/ lockup torque converter 745 A 6WD 73,553 (33,363) 45 (41) Cat C18 ACERT Powershift w/ lockup torque converter

DOOSAN

DA30-5 A 6x6 113,318 (51,400) 30 (28) DA45-5 A 6x6 156,749 (71,100) 45 (41) Scania DC9 M Scania DC13 M

HITACHI

EH3500AC-3 R RWD 709,888 (322,000) 200 (181) Cummins QSKTA50-CE E EH4000AC-3 R RWD 846,575 (384,000) 243.6 (221) Cummins QSKTA60-CE E EH5000AC-3 R RWD 1,102,310 (500,000) 326 (296) Cummins QSKTTA60-CE E

HYDREMA TRUCKS

912HM Water Tanker A 4x4 18,210 (8,260) 11 (10) Cummins B4.5 Stage 5 Turbo Diesel M 912HM Flatbed A 4x4 18,210 (8,260) 11 (10) Cummins B4.5 Stage 5 Turbo Diesel M 912FS Rail A 4x4 22,050 (9,979) 11 (10) Cummins B4.5 Stage 5 Turbo Diesel M 912GHM A 4x4 19,224 (8,720 11 (10) Cummins B4.5 Stage 5 Turbo Diesel M 912GS A 4x4 17,637 (8,000) 11 (10) Cummins B4.5 Stage 5 Turbo Diesel M 922GHM A 6x6 30,754 (13,950) 22 (20) Cummins QSB, 6.7 EPA Tier V Turbo Diesel M 920GHM A 6x6 30,754 (13,950) 22 (20) Cummins QSB, 6.7 EPA Tier V Turbo Diesel M 707G 75hp A 4x4 12,015 (5,450) 7.1 (6.5) Cummins F3.8 Stage 5 Turbo Diesel M 707G 122hp A 4x4 12,015 (5,450) 7.1 (6.5) Cummins F3.8 Stage 5 Turbo Diesel, SCR-catalyst AdBlue M

VOLVO

A25G A 6x4 and 6x6 104,499 (47,400) 27.6 (25) A30G A 6x4 and 6x6 115,302 (52,300) 33 (29) A35G A 6x4 and 6x6 139,883 (63,450) 38 (34.5) A40G A 6x4 and 6x6 151,898 (68,900) 43 (39) A45G A 6x4 and 6x6 156,749(71,000) 45.2 (41) A45G FS A 6x4 and 6x6 157,630 (71,500) 45.2 (41)

Volvo D11M M Volvo D11M M Volvo D13J M Volvo D13J M Volvo D16J M Volvo D16J M A60H A 6x4 and 6x6 217,700 (98,750) 60.6 (55) Volvo D16J M R100 R 4x2 rear wheel drive 363,216 (164,752) 105 (95) Cummins QST30 M
