Ascent Wetroom Trays

Pre-Formed Wetroom Shower Base

Designed for walk-in shower and wetroom applications, the Ascent Wetroom Trays are pre-formed to create an effective water slope to the drain. They are floor level panels that can easily be trimmed to fit the shower area. Trays are ready to receive a tiled finish of the customers choice.

Ascent pre-formed Wetroom Trays are made using a waterproof extruded polystyrene (XPS) and are covered on both sides in a combination of polymer resin and quartz, compatible with most tile adhesives. All Wetroom Trays are exclusively made to accept our QX range of Linear and Square Drains. They are sufficiently robust to be covered with mosaic tiles without the risk of compression through point loading.

Ascent Wetroom Trays and Boards are suitable for use with Underfloor Heating. All Drains can also be used without a shower base. NOTE: Ascent Wetroom Trays ARE NOT SUITABLE for Vinyl Flooring.

Ascent Wetroom Trays can be laid directly onto existing wooden or concrete floors but must be supported over it’s entire area, including trap (see diagram).

Wooden floors can be lowered by ‘under-boarding’. Removing the existing floor boards, fixing battens and plywood, finishing level with the top of the joists.

If the tray is to be laid onto the existing floorboards, they must be in good condition and must be screwed down at very close centres.

When the tray is laid onto a concrete floor, the surface below the tray must be perfectly flat, with a channel for the trap & waste pipe.

Care must be taken when preparing the slopes to the drain in all applications.

Trays can be trimmed on-site to exact requirement, up to a maximum of 50mm*
