Consolidation Exercise Answers

Consolidation exerCise answers

ECG Exercise 1

Acceptable diagnostic quality.

Regular narrow complex tachycardia (likely PSVT) rate of 215. Global ST elevation (likely due to rate).

Return to Exercise 1

ECG Exercise 2

Acceptable diagnostic quality

regular sinus rhythm, rate of 78

ST elevation > 1 mm in I and aVL (Lateral) with reciprocal changes in II, III and aVF (Inferior). Also ST elevation > 2mm in V2-V4 (Septal and Anterior).

This combination of Septal, Anterior and lateral is also known as ‘Extensive Anterior’ Involvement’.

Return to Exercise 2

ECG Exercise 3

Acceptable diagnostic quality. This ECG does not have a 10 second strip of Lead II. As a result, it may be difficult to accurately assess the rhythm. It is sufficient however to determine ST segment and T Wave abnormalities.

Mostly regular sinus tachycardia, rate of 100. LBBB morphology. (QRS duration >0.12, broad R waves in lateral leads, and dominant S wave in V1).

Return to Exercise 3

ECG Exercise 4

Acceptable diagnostic quality.

Regular sinus bradycardia rate of 52. P wave morphology suggestive of LAE.

ST elevation > 2mm in V2-V5 (Septal, Anterior and Lateral). Also 1mm elevation in Lead I, and borderline elevation aVL (Lateral)

This combination of Septal, Anterior and Lateral is also known as ‘Extensive Anterior’ Involvement’.

Return to Exercise 4

ECG Exercise 5

Acceptable diagnostic quality.

Regular sinus rhythm, rate of 68.

T wave abnormalities - flipped T waves in I, aVL, V4-V6 (Lateral) and T wave flattening in II & aVF (Inferior)

Return to Exercise 5

ECG Exercise 6

Acceptable diagnostic quality.

Atrial flutter with 2:1 block* (atrial rate of 300, ventricular rate of 150).

*The block ratio in Atrial Flutter can change. Have a look at the Lead II 10 second strip. In the first R-R interval, the block ratio is 2:1. The following two are 3:1 (atrial rate 300 ventricular rate 100), then reverts back to 2:1 for the remainder of the ECG.

Return to Exercise 6

ECG Exercise 7

Acceptable diagnostic quality.

Third degree AV block (AKA complete heart block) with a ventricular rate of 37.

ST elevation > 1 mm in II, III & aVF (Inferior) with reciprocal ST depression in I, aVL (Lateral). Also pathological* Q waves in II & III (Inferior).

Return to Exercise 7

ECG Exercise 8

Acceptable diagnostic quality.

NSR rate of 78.

Return to Exercise 8
