16.505 FENCES, WALLS, AND SCrEENING
16.504.16 WATER-EFFICIENT LANDSCAPE REPORTING
A. The Planning Division shall prepare and annual report on implementation and enforcement no later than January 31st of each year. Reports shall be submitted to the Department of Water Resources. B. The report shall address the following:
1. State whether the City is adopting a single-agency ordinance or a regional agency alliance ordinance and the date of adoption or anticipated date adoption. 2. Define the reporting period. The reporting period shall commence on December 3, 2015 and end on December 28, 2015. In subsequent years, the reporting will be for the calendar year. 3. State if using a locally modified Water
Efficient Landscape Ordinance (WELO) or the Model WELO. If using a locally modified
WELO, how is it different than MWELO, and are there any exemptions specified? 4. State the entity responsible for implementing the regulations of this Chapter. 5. State number and types of projects subject to the regulations during the specified reporting period. 6. State the total area (in square feet or acres) subject to the regulations over the reporting period, if available. 7. Provide the number of new housing starts, new commercial projects, and landscape retrofits during the reporting period. 8. Describe the procedure for review of projects subject to the regulations of this Chapter. 9. Describe actions taken to verify compliance. Is a plan check performed; if so, by what entity? Is a site inspection performed; if so, by what entity? Is a post-installation audit required; if so, by whom? 10. Describe enforcement measures. 11. Explain challenges to implementing and enforcing the regulations of this Chapter. 12. Describe educational and other needs to properly apply the regulations of this Chapter.
16.505.01 PURPOSE AND APPLICABILITY
The purpose of these provisions is to prescribe standards for fences and walls within the City for the conservation and protection of property, buffering between uses of varying intensity, the assurance of safety and security, the enhancement of privacy, the control of dust, the abatement or attenuation of noise, and the improvement of the visual environment, and including the provision of a neat appearance to improve neighborhood character.
16.505.02 GENERAL REGULATIONS
A. Permits Required. Fences and walls that comply with the requirements of this Chapter are permitted. All other fences and walls require Zoning Compliance Review, pursuant to Chapter 16.603, Zoning Compliance
Review, approval by the Director. Any fence over 7 feet in height requires a building permit in addition to an Exception Permit in accordance with Chapter 16.608, Exceptions in areas where the fence height exceeds the limit for the zoning district or use. B. Maintenance. Fencing and walls shall be continuously maintained with no sign of rust or disrepair.
Graffiti shall be removed within 48 hours. C. Fencing and Wall Location.
1. Fence and Wall Location on a Lot. Fences may be erected, placed or maintained along or adjacent to a lot line or within a yard on the private property.
A fence located on a lot line shall be considered as being within the yard adjacent to that lot line.
The fence owner shall be responsible for properly locating all lot lines before construction of any fence 2. Fence and Wall Encroachment onto Public
Property. No portion of any fence or wall including gate doors, structure, foundation, or footings, shall encroach upon or project into any public right-of-way or other public property without the fence owner first obtaining an Encroachment
Permit from the Public Works Department. 3. Prohibited Fence and Wall Locations. No person shall place, construct, maintain, or cause to be placed any fence or wall that may endanger the public safety, including but not limited to the following:
a. Fire Hydrant Access. No fence shall obstruct free access to any fire hydrant. b. Sight Distance Triangle. Fencing shall meet the requirements of Section 16.501.11
Visibility At Intersections, Driveways,
And Alleys, to avoid interference with visibility at intersections and driveways.
4. Review by Traffic Engineer Required. To avoid traffic hazards and protect the safety of pedestrians, fences, walls, and other screening shall be subject to review by the Traffic
Engineer for the following locations:
a. Within 10 feet of the point of intersection of a vehicular accessway or driveway and a street or sidewalk; b. Within 20 feet of the point of intersection of 2 or more vehicular accessways including driveways, alleys, or streets. c. Measurements shall be made from the face of the curb or, if there is no curb, from the edge of the pavement.
D. Permitted Screening Types. Screening that complies with the requirements of this Chapter may consist of one or more of the following types:
1. Walls. Walls shall be constructed of concrete, stone, brick, tile or similar type of solid masonry material a minimum of 4 inches thick. 2. Berms. A berm shall be constructed of earthen materials and shall be landscaped in compliance with the requirements of this Chapter 16.504, Landscaping. 3. Planting. Plant materials, when used as a screen, shall consist of compact evergreen plants, and shall be planted in accordance with the requirements of this Chapter. planted in a minimum 3-footwide planting strip. They shall be of a kind, or used in such a manner, provide screening having a height which meets the requirements set forth in compliance with and a minimum height of 2 feet and width of 2 feet within 12 months after initial installation. The Director may require installation of walls, berms or solid fence, if, after 12 months after installation, the plant materials have not formed an opaque screen or if, at any time, the plant materials are not maintained so as to create the desired screen. E. Permitted Materials.
1. Fences. Fences shall be constructed of wood, metal, masonry or other permanent materials designed for permanent fencing. Non-residential uses. For non-residential uses in residential zoning districts, a wall or fence 8 feet in height is required along any rear or side property line that separates the non-residential use from adjacent residential uses.
No chain-link (nonmetallic finish) fence may be installed along the rear property line and any side property line not abutting a public rightof-way subject to review and approval by the
Director. Razor wire or barbed wire fences that cannot be seen from street review are allowed. 2. Hazardous and Prohibited Materials. Except in the RR Zoning District, fences shall not incorporate electrically charged wire, barbed wire and razor wire, chain link (except as permitted by this Chapter), unfinished plywood or similar unfinished materials, woven wire mesh (“chicken wire”), welded wire mesh, woven wire (“hog wire”) rope, cable, railroad ties, landscape timbers, utility poles or any other similar materials or materials not specifically manufactured for permanent fencing. The use of plywood or other composite panels or materials is not allowed unless the Director determines that the material is appropriate to maintain or enhance the architectural design of a building or development.
F. Posts and Supporting Members. All fence posts and related supporting members of the fence shall be erected so that the finished side or sides of the fence shall be facing the adjacent lot or public right-of-way. G. Painting and Staining. All wood fences shall be painted or stained to resist corrosion. H. Gates. Gates that are routinely locked shall be equipped with a doorbell device capable of notifying the occupants within the a building or a telephone number that can be used to notify the occupants. I. Entry features. Entry features over front yard gates (e.g., open latticed arbors and trellises), not exceeding eight feet in height, 3 feet in depth or 5 feet in width are allowed when located within the required front yard but outside the Sight Distance Triangle. J. Fences Facing Alleys. When a rear yard fence abuts an alley, the alley facing side of a solid fence shall be clearly labeled with the house address number.
16.505.03 FENCING AND SCREENING REQUIREMENTS IN MIXED-USE AND NON-RESIDENTIAL ZONING DISTRICTS
Screening that complies with the requirements of this Chapter shall be installed at the following locations in mixed-use and non-residential zoning districts:
A. Commercial, Industrial, Agricultural and Public and Semi-Public Use Types. Screening shall be provided along all boundaries other than streets, where the building site abuts residential uses. B. Automotive and Equipment Use Types.
Screening shall be provided on building sites with automotive and equipment use types, regardless of zoning, along all off-street parking and zoning district boundaries, other than streets. C. Storage and Loading Areas. Storage or loading areas shall be screened wherever such facilities are adjacent to a residential zoning district or when storage and loading areas are visible from a public street and along the perimeter of open off-street parking adjacent to residential zoning districts. D. Nonresidential and Multiple Unit Residential
Uses in or Adjacent to Residential Zoning
Districts. On building sites with nonresidential or multiple unit residential- uses located in or adjacent to Residential Zoning Districts along all property lines abutting single family residences.
For the purpose of this Section, nonresidential use shall not include home-based businesses.
16.505.04 HEIGHT STANDARDS FOR FENCES AND WALLS
A. Maximum height in Residential Zoning Districts. The height of fences in Residential Zoning Districts shall be limited by location as specified below in Table 16.505-A.
TABLE 16.505-A: ALLOWABLE FENCE HEIGHTS IN RESIDENTIAL ZONING
Location of Fence Maximum Basic Height
Required front yard 3 feet
Required side yard 6 feet
Required rear yard 6 feet
Maximum Height Exceptions
4 feet with the traffic Engineer’s approval through a Zoning Compliance review. the maximum height allowed with an Exception Permit.
a one-foot extension up to 7 feet with a decorative finish such as lattice is allowed. the maximum height allowed with an Exception Permit is permitted only if both abutting residential structures have at least 5-foot side yard setbacks, or if a residential lot abuts a mixed-use, commercial or industrial use.
a one-foot extension up to 7 feet with a decorative finish such as lattice is allowed. the maximum height exception may be allowed only when a rear yard abuts an interior side yard.
Notes
Within sight distance triangle
Not permitted Not permitted Not permitted
B. Exceptions to Residential Fence Height Regulations. The Director may grant an Exception to the fence height requirements imposed by this Chapter, in accordance with Chapter 16.608, Exceptions if the Director makes all of the following findings:
1. The proposed fence will not create or exacerbate a public safety hazard;
2. The design, materials, scale and color of the proposed fence are compatible and harmonious with the subject site, site improvements and other properties within the immediate vicinity. 3. The fencing type, including any gate is open and permits direct vision through at least 80 percent of any one square foot segment of vertical fence surface area. Measured surface area does not include major posts, pilasters, or other structures which provide lateral strength.
C. Maximum Height in Mixed-Use and Non-Residential zoning districts.
1. Mixed-Use, Commercial, Office and
Medical Zoning Districts. Required screening, except for plant material, shall not be more than 6 feet in height. 2. Industrial Zoning Districts. Required screening, except for plant materials, shall not be more than 8 feet in height. 3. Automotive and Equipment Type Uses. Fences, walls and other screening on any building site with an automotive and equipment use type, except sales/rental - light equipment, required screening shall not be more than 8 feet in height. Fences, walls and other screening on any building site with an automotive and equipment sales/rental - light use shall not be more than 6 feet in height. 4. Parking Facilities. Notwithstanding the provisions of an applicable zoning district, screening around an unenclosed off-street parking facility shall not be more than 6 feet in height. 5. Courtyard. Fences, walls and other screening installed to create a courtyard without a roof shall be a maximum of 5 feet in height and be set back a minimum of 10 feet from the front property line or back of sidewalk, whichever is the least. Courtyards shall include the following design elements::
a. Building characteristics including the dimensions, color and architectural design; b. Compatibility of the architectural and design features of the proposed courtyard with the features of the adjoining, as well as neighboring buildings; and c. Landscaping, including the effort to minimize removal of existing vegetation and to match replacements with vegetation of the site. 6. All Other Building Sites. Fences, walls, and other screening on building sites not subject to the regulations of subsections A through C shall be subject to the following height limits:
a. Within Required Front Yard. Except as provided in Section 16.104.15, Measuring
Height of Fences and Walls, the maximum height of fences and walls located within any required front yard shall be 3 feet unless the
Traffic Engineer, as part of Zoning Compliance
Review, pursuant to Chapter 16.603 Zoning
Compliance Review, determines that a 4-foot fence would not create a visibility hazard.
The maximum height of a fence or wall beyond the required front yard is 6 feet. b. Within Required Side Yard for Corner Lot.
Except as provided in Section 16.104.15,
Measuring Height of Fences and Walls, the maximum height of a fence, wall, or screening located within 10 feet of a side property line, adjoining a public street shall be 3 feet unless the Traffic Engineer determines that a 4-foot fence would not create a visibility hazard as provided through a Zoning Compliance
Review. A fence may be 6 feet in height when located further than 11 feet from the side property line adjoining a public street.
i. The Director in consultation with the Traffic
Engineer may reduce the fence setback to 3 feet from the back of the sidewalk where the side yard is 3 feet below street grade. ii. An Encroachment Permit shall be obtained prior to erecting a fence or wall between the curb or sidewalk and the property line.
c. Within Required Side and Rear Yard for
Interior Lots. The maximum height shall not be more than 6 feet. A one-foot extension up to 7 feet is allowed with a decorative finish such as lattice on the top one-foot.
D. Other Requirements.
1. Open fences that do not obstruct a view may be 6 feet in height. 2. For designated City landmarks and properties that are located within a Designated
Heritage or Historic District:
a. The maximum height for fences within the front setback area and/or the street side yard setback area shall be 3 feet 6 inches. b. Requests for an Exception. In accordance with
Chapter 16.608, Exceptions, the permission to exceed the height limits of this Chapter shall be subject to review and approval by the
Secretary of the Architectural Heritage and
Landmarks Commission or his/her designee.
16.505.05 MEASUREMENT OF HEIGHT OF FENCES, WALLS AND SCREENING
A. The height of fences, walls and other screening shall be measured above the actual adjoining level of finished grade as defined in Section 16.104.15, Measuring
Height of Fences and Walls, except that where there is a difference in elevation on opposite sides of such fence, wall or other screening, the height shall be measured from the highest elevation within a 3-foot radius on either side of the fence or other screening. B. Notwithstanding these requirements, where the finished elevation of the property is lower at the boundary line, or within 5 feet inside the boundary line, than an abutting property elevation, such change in elevation may be used in lieu of, or in combination with, additional screening to satisfy a screening requirement. C. Where screening is required along a public or private street and the roadway elevation is higher than the property in question, the Director may permit screens higher than permitted by the applicable height limit based on review of a Chapter submitted by an applicant demonstrating difference in elevation when:
1. Proposed fence height is in compliance with higher grade elevation; 2. Proposed fence is located on private property; and 3. No other fence is proposed along the adjacent property.
16.505.06 FENCING ON RETAINING WALLS
The height of fences constructed on or attached to retaining walls shall not exceed 6 feet measured vertically from the highest finished grade within a 3-foot radius of the base of the wall to the highest point of the fence or wall directly above as shown in Section 16.104.15, Measuring Height of Fences or Walls.
A. Mixed-use and Non-Residential Zoning
Districts. Fencing and walls shall be installed on the property line except when adjacent to a public street; in which case the fencing and wall shall be installed behind required landscaping. B. Residential Zoning Districts. When the back of the sidewalk is not the property line, the Director may allow the setback to be measured from the inside of the sidewalk. If there is no sidewalk, the
Director, subject to the concurrence of the Director of Public Works, may allow the setback to be measured from the future location of the sidewalk.
Further, if a fence or wall is to be located in the public right-of-way, an Encroachment Permit from the Public Works Department will be required.
16.505.08 TEMPORARY FENCING
Temporary fencing may be used to provide security for approved “special events,” for construction sites, for vacant structures, and for vacant land, which cannot otherwise be secured, subject to approval of a Temporary Use Permit pursuant to Chapter 16.338, Temporary Uses. The fencing shall consist of chain link fencing or other materials approved by Director and shall be limited to a height of 8 feet. The use of temporary fencing around occupied and permanent structures is prohibited.
A. Special Events. The fencing around approved “special events” shall be removed at the conclusion of the event. B. Construction Sites. The fencing for construction sites shall not be installed until a building permit or grading permit has been issued and shall be removed prior to final inspection. In the event that the building permits expire before the construction is completed, the Director may issue an Temporary Use Permit pursuant to Chapter 16.338, Temporary Uses, to allow the fencing to remain for a longer period of time. C. Vacant Land and Vacant Structures. The use of temporary fencing around vacant land or vacant structures shall be subject to the terms and conditions specified in a Temporary Use Permit authorizing this fencing. Any temporary fence that remains on a site for more than 6 months shall comply with fence regulations of this Chapter.
16.505.09 TYPES OF LANDSCAPE SCREENING
A. The three basic types of vegetative screens that are required as follows: 1. Opaque Screen. A screen that is opaque from the ground to a maximum height of at least 6 feet, with intermittent visual obstruction (trees or large plants) from the opaque portion to. An opaque screen may be composed of a densely planted vegetation. Compliance of planted vegetative screens will be based on the average mature height and density of foliage of the subject species, or field observation of existing vegetation. The opaque portion of the screen must be opaque in all seasons of the year. At maturity, the portion of intermittent visual obstructions should not contain any completely unobstructed openings more than 5 feet wide. 2. Semi-Opaque Screen. A screen that is opaque from the ground to a height of 3 feet, with intermittent visual obstruction (trees or large plants) from above the opaque portion to a height of at least 6 feet. The semi-opaque screen is intended to partially block visual contact between uses and to create a strong impression of the separation of spaces. The semi-opaque screen may be composed of a landscaped earth berm or planted vegetation. Compliance of planted vegetative screens will be based on the average mature height and density of foliage of the subject species, or field observation of existing vegetation. At maturity, the portion of intermittent visual obstructions should not contain any completely unobstructed openings more than 10 feet wide. 3. Broken Screen. A screen composed of intermittent visual obstructions from the ground to a height of at least 6 feet. The broken screen is intended to create the impression of a separation of spaces without necessarily eliminating visual contact between the spaces. It may be composed of a landscaped earth berm, planted vegetation or existing vegetation. Compliance of planted vegetative screens or natural vegetation will be judged on the basis of the average mature height and density of foliage of the subject species, or field observation of existing vegetation. The screen may contain deciduous plants. B. Separation of zoning districts. Where the side or rear yard of a use in a Mixed-Use, Commercial or Industrial zoning district abuts a Residential Zoning District, those side or rear yards shall be screened from uses in that
Residential Zoning District with an opaque screen. C. Separation of Non-Conforming Uses. Whenever a residential lot is occupied by a non-conforming commercial or industrial use, the side and rear yards shall be screened with an opaque screen.
16.505.10 SCREENING OF EQUIPMENT
These requirements apply to new development, new land uses, additions and expansions of 50 percent or more in floor area, replacement equipment that is added to serve existing buildings, condominium conversions, and new equipment. They do not apply to existing equipment that serves existing buildings. The Director may waive or modify screening requirements for upgrades to existing mechanical equipment.
A. General Requirements. All exterior mechanical equipment, whether on a roof, on the side of a structure, or located on the ground, shall be screened from public view.
Exterior mechanical equipment to be screened includes, without limitation, heating, ventilation, air conditioning, refrigeration equipment, plumbing lines, ductwork, transformers, smoke exhaust fans, water meters, backflow preventers, service entry section, back-up and emergency generators, and similar utility devices. 1. Screening shall be architecturally integrated into the main structure with regard to materials, color, shape, and size to appear as an integral part of the building or structure. 2. Equipment shall be screened on all sides, and screening materials shall be opaque. 3. When screening with plants, evergreen types of vegetation shall be planted and maintained. Plant material sizes and types shall be selected and installed so that, at the time of building occupancy, such plants effectively screen their respective equipment. 4. The use of wood expanded metal lath, and chain link for the purpose of screening is prohibited.
B. Requirements for Specific Types of Mechanical Equipment. The following additional screening standards apply to the specified types of mechanical equipment:
1. Roof-Mounted Equipment.
a. Whenever feasible, roof-mounted equipment screening shall be constructed as an encompassing monolithic unit or a series of architecturally similar screening units on large roofs, rather than as several individual screens (i.e., multiple equipment screens, or “hats,” surrounding individual elements will not be permitted).
The height of the screening element shall equal or exceed the height of the structure’s tallest installed equipment.
FIGURE 16.505-A: SCREENING OF ROOF-MOUNTED EQUIPMENT
Roof mounted equipment
Roof mounted equipment screening must be an encompassing monolithic unit and shall be the same height as the equipment
2. Ground-Mounted Equipment. Ground-mounted equipment that faces a street shall be screened to a height of 12 inches above the equipment, unless such screening conflicts with utility access, in which case reasonable accommodation shall be allowed.
a. Acceptable screening devices consist of decorative walls and/or berms (3:1 maximum slope) with supplemental landscaping materials, including trees, shrubs, and groundcovers. b. For screen walls that are 3 feet high or lower, vegetative materials may be substituted for 50 percent of the screening device. c. This requirement does not apply to incidental equipment such as generators and air conditioners. However, electrical substations, water tanks, sewer pump stations, and similar utilities are required to be screened and secured with a wall one foot above the equipment (not to exceed fencing and wall height limits without an exception). If the wall is greater than 25 feet in length, then the wall shall include breaks and design features including varying materials, wall caps, and landscaping. 3. Exterior Wall Equipment. Wall-mounted equipment, including, without limitation, electrical meters, electrical distribution cabinets, service entry sections, and valves and cabinets that face a street or public parking and are not recessed and/or separated from the street by intervening building(s) or walls or gates, shall be screened.
Screening devices shall incorporate elements of the building design (e.g., shape, color, texture and material). For screen walls that are 3 feet in height or lower, vegetative materials may be substituted for 50 percent of the screening device. This requirement does not apply to fire-related elements.
C. Exceptions in Industrial Zoning Districts. Due to its size, some outdoor equipment that is ancillary to operations in the IL and IG Zoning Districts may not be fully screened from view. In these cases, operators of such equipment shall only be required to provide screening that is consistent with provisions of this Chapter to the extent feasible.
FIGURE 16.505-B: SCREENING OF GROUND-MOUNTED EQUIPMENT
Top of screening element must be one foot higher than the top of the installed equipment
