MANUFACTURING PROCESS OF ECHOPANEL® & MURA™ Established in 1987, Woven Image is an international interior finishes company with 1. Bottles made from PET identified by are collected from consumers.

sustainability and design leadership at its core.

From humble beginnings in Sydney, Woven Image now has offices throughout Australia as well as

2. Contaminents like lids and sticky labels are removed.

Bottles are chipped into tiny pellets.

Singapore, Hong Kong, China and the US, with a network of distributors covering all major markets including UK, Europe, North America and IndoPacific regions.

The product portfolio consists of acoustic finishes

3. Pellets are washed and sanitised.

such as EchoPanel®, suitable for wall, ceiling and space dividing applications in interior spaces including workplace, hospitality, education and

4. Pellets and colour are fed into a hopper. A heater at the base of the hopper melts the pellets to form a free-flowing resin.

healthcare sectors.

OUR ENVIRONMENTAL STORY The Woven Image portfolio has been designed with dematerialization, upcycling and lifecycle management front of mind. All base materials

5. Resin is pumped through a sophisticated shower-rose device, known as a Spinneret.

in this collection utilize recycled or waste materials and printed designs use non-toxic inks with low VOCs. Woven Image achieves first-class environmental

6. Cold air fans ‘set’ the fine fibres extruded from the Spinneret.

certifications for its key products, including Global GreenTag™ certification (GreenRate Level A), with the maximum Product Health Declaration™ Platinum Health and an Environmental Product Declaration (EPD). As a result, specifying these

7. Fibres are drawn and cut, then blended into a web.

products can secure credits under sustainable building tools including Leadership in Energy and Environmental Design (LEED v4.1), WELL™ Building Standard and Green Star. Woven Image

8. Web is compressed to make board ready for use.

2

EchoPanel® TRIO & EchoPanel® 12mm in color #365

is also a long-term supporter of GreenFleet and offsets its carbon emissions through their biodiverse program.

3

MAIN CONTENTS

ECHOPANEL® COLLECTION EC HOPANEL® PAL ET TE . . .................................. . . . . . . . . . . . . . . . . . . . . 0 6

Invented and launched by Woven Image in 2004, EchoPanel® is the original decorative interior

P REC I S I ON C U T D ESI G NS . . .............................. . . . . . . . . . . . . . . . . . . . . 0 8

paneling solution, with acoustic qualities and eco-innovation at its core. EchoPanel® production

EC HOPANEL® PALAC E............................... . . . . . . . . . . . . . . . . . . . . 1 0

uses post-consumer recycled PET bottles to

EC HOPANEL® OHM .................................... . . . . . . . . . . . . . . . . . . . . 1 2

create a superior upcycled product, with a 10-year life expectancy, after which the material is still

EC HOPANEL® EM P I RE............................... . . . . . . . . . . . . . . . . . . . . 1 4

100% recyclable. Since 2022, Woven Image have also committed to offset the embodied carbon of

EC HOPANEL® LONGI TU DE . . ........................ . . . . . . . . . . . . . . . . . . . . 1 6

EchoPanel® acoustic panels to zero.

EC HOPANEL® LATI TU DE............................ . . . . . . . . . . . . . . . . . . . . 1 8

EchoPanel® is available in a comprehensive range

EC HOPANEL® M ERI DI AN............................ . . . . . . . . . . . . . . . . . . . . 2 0

of neutral, mid tone and vibrant colors. Due to its unique manufacturing process, the color remains

C EI LI NG CO L L ECTI O N.. .................................... . . . . . . . . . . . . . . . . . . . . 2 2

consistent throughout the depth of the panel.

EchoPanel® is pinnable, durable, lightweight

FUJ I ........................................................ . . . . . . . . . . . . . . . . . . . . 2 4

and easy to cut and install, making it ideal for

EC HOPANEL® ARRAY................................. . . . . . . . . . . . . . . . . . . . . 2 6

a multitude of wall, ceiling and free-standing

EC HOPANEL® ELEM ENT............................. . . . . . . . . . . . . . . . . . . . . 2 8

commercial interior applications. Available in 0.47" (12mm) and 0.94" (24mm) thicknesses.

S PAC E DI VI DI NG CO L L ECTI O N . . ........................ . . . . . . . . . . . . . . . . . . . . 3 0 HANGI NG P ENDENTS ................................ . . . . . . . . . . . . . . . . . . . . 3 2 PALI NG.................................................... . . . . . . . . . . . . . . . . . . . . 3 6 P LATOON................................................. . . . . . . . . . . . . . . . . . . . . 3 8

®

4

EchoPanel® 12mm in color #660

5

ECHOPANEL® COLLECTION CONTENTS

E C H O P A N E L® C O L L E C T I O N

E C H O P A N E L® P A L E T T E 500

101

908

454

468

447

442

444

402

580

550

542

276

576

274

269

193

167

295

487

384

579

381

108

124

330

349

338

325

365

660

633

551

EchoPanel® 12mm in color #454

PANEL DIMENSIONS

110.24" (+/-0.39") x 47.24" (+/-0.2") I 2800mm (+/-10mm) x 1200mm (+/-5mm)

PANEL THICKNESS

0.47" I 12mm 0.94" I 24mm

SOUND ABSORPTION

AS ISO 354: 2006 (R2016) - direct fix results 0.47" αw 0.30 (MH) (12mm) NRC 0.45 SAA 0.43 Class D 0.94" αw 0.45 (MH) (24mm) NRC 0.65 SAA 0.63 Class D

QUICK REFERENCE GUIDE 0.47" x 110.24" x 47.24" I 12mm x 2800mm x 1200mm 0.94” x 110.24" x 47.24" I 24mm x 2800mm x 1200mm 101 108 124 167 193 269 274 276 295 325 330 338 349 365 381 384 402 442 444 447 454 468 487 500 542 550 551 576 579 580 633 660 908 0.47" (12mm)

For additional specifications and performance details please visit wovenimage.com HERE 6

0.94" (24mm)

7

ECHOPANEL® COLLECTION CONTENTS

E C H O P A N E L® C O L L E C T I O N

P R E C I S I O N D E S I G N S

8

EchoPanel® LONGITUDE in color #447

C U T

9

ECHOPANEL® COLLECTION CONTENTS

PRECISION CUT DESIGNS

E C H O P A N E L® P A L A C E

EchoPanel® PALACE in color #349

COLORS

Available in 31 EchoPanel® colors - see website for details

PANEL DIMENSIONS

108.27" (+/-0.08") x 43.31 (+/-0.08") I 2750mm (+/-2mm) x 1100mm (+/-2mm)

PANEL THICKNESS

0.47" I 12mm 0.94" I 24mm

SOUND ABSORPTION

AS ISO 354: 2006 (R2016) - direct fix results 0.47" αw 0.30 (MH) (12mm) NRC 0.45

SAA 0.43

Class D 0.94" (24mm)

αw NRC SAA Class

0.45 (MH) 0.65 0.63 D

For additional specifications and performance details please visit wovenimage.com HERE 10

11

ECHOPANEL® COLLECTION CONTENTS

PRECISION CUT DESIGNS

E C H O P A N E L® O H M

EchoPanel® OHM in color #454

COLORS

Full EchoPanel® 12mm & 24mm color range - see page 7

PANEL DIMENSIONS

108.27" (+/-0.08") x 43.31 (+/-0.08") I 2750mm (+/-2mm) x 1100mm (+/-2mm)

PANEL THICKNESS

0.47" I 12mm 0.94" I 24mm

SOUND ABSORPTION

AS ISO 354: 2006 (R2016) - direct fix results 0.47" αw 0.30 (MH) (12mm) NRC 0.45

SAA 0.43

Class D 0.94" (24mm)

αw NRC SAA Class

0.45 (MH) 0.65 0.63 D

For additional specifications and performance details please visit wovenimage.com HERE 12

13

ECHOPANEL® COLLECTION CONTENTS

PRECISION CUT DESIGNS

E C H O P A N E L® E M P I R E

EchoPanel® EMPIRE in color #365

COLORS

Full EchoPanel® 12mm & 24mm color range - see page 7

PANEL DIMENSIONS

108.27" (+/-0.08") x 43.31 (+/-0.08") I 2750mm (+/-2mm) x 1100mm (+/-2mm)

PANEL THICKNESS

0.47" I 12mm 0.94" I 24mm

SOUND ABSORPTION

AS ISO 354: 2006 (R2016) - direct fix results 0.47" αw 0.30 (MH) (12mm) NRC 0.45

SAA 0.43

Class D 0.94" (24mm)

αw NRC SAA Class

0.45 (MH) 0.65 0.63 D

For additional specifications and performance details please visit wovenimage.com HERE 14

15

ECHOPANEL® COLLECTION CONTENTS

PRECISION CUT DESIGNS

E C H O P A N E L® L O N G I T U D E

EchoPanel® LONGITUDE in color #269

COLORS

Full EchoPanel® 12mm & 24mm color range - see page 7

PANEL DIMENSIONS

108.27" (+/-0.08") x 43.31 (+/-0.08") I 2750mm (+/-2mm) x 1100mm (+/-2mm)

PANEL THICKNESS

0.47" I 12mm 0.94" I 24mm

SOUND ABSORPTION

AS ISO 354: 2006 (R2016) - direct fix results 0.47" αw 0.30 (MH) (12mm) NRC 0.45

SAA 0.43

Class D 0.94" αw 0.45 (MH) (24mm) NRC 0.65

SAA 0.63

Class D

For additional specifications and performance details please visit wovenimage.com HERE 16

17

ECHOPANEL® COLLECTION CONTENTS

PRECISION CUT DESIGNS

E C H O P A N E L® L A T I T U D E

EchoPanel® LATITUDE in color #454

COLORS

Full EchoPanel® 12mm & 24mm color range - see page 7

PANEL DIMENSIONS

108.27" (+/-0.08") x 43.31 (+/-0.08") I 2750mm (+/-2mm) x 1100mm (+/-2mm)

PANEL THICKNESS

0.47" I 12mm 0.94" I 24mm

SOUND ABSORPTION

AS ISO 354: 2006 (R2016) - direct fix results 0.47" αw 0.30 (MH) (12mm) NRC 0.45

SAA 0.43

Class D 0.94" (24mm)

αw NRC SAA Class

0.45 (MH) 0.65 0.63 D

For additional specifications and performance details please visit wovenimage.com HERE 18

19

ECHOPANEL® COLLECTION CONTENTS

PRECISION CUT DESIGNS

E C H O P A N E L® M E R I D I A N

EchoPanel® MERIDIAN in colors #580 & #454

COLORS

Full EchoPanel® 12mm & 24mm color range - see page 7

PANEL DIMENSIONS

108.27" (+/-0.08") x 43.31 (+/-0.08") I 2750mm (+/-2mm) x 1100mm (+/-2mm)

PANEL THICKNESS

0.47" I 12mm 0.94" I 24mm

SOUND ABSORPTION

AS ISO 354: 2006 (R2016) - direct fix results 0.47" αw 0.30 (MH) (12mm) NRC 0.45

SAA 0.43

Class D 0.94" (24mm)

αw NRC SAA Class

0.45 (MH) 0.65 0.63 D

For additional specifications and performance details please visit wovenimage.com HERE 20

21

ECHOPANEL® COLLECTION CONTENTS

E C H O P A N E L® C O L L E C T I O N

CEILING COLLECTION Woven Image have created design-driven and easy-to-install acoustic ceilings solutions for use in commercial interior spaces.

EchoPanel® Array is a fully scalable acoustic ceiling system that accommodates 0.47" (12mm) and 0.94" (24mm) EchoPanel® baffles.

Delivering high acoustic performance, Array controls reverberated noise in shared spaces.

Choose from our beautifully crafted baffles in the extensive EchoPanel® color palette, or work with us to create your own unique designs. Featuring streamlined aluminum hardware, Array has been engineered for easy installation, and can be used in both ceiling or wall applications.

EchoPanel® Element comprises a series of cut EchoPanel® blades which slot together to provide a direct fix, grid or suspended acoustic ceiling solution.

Woven Image can also support your interiors project with custom ceiling solutions, including baffle systems. Contact your Woven Image representative for more information.

22

EchoPanel® ARRAY WEDGE 24mm in colors #468, #908, #454 & #500

23

ECHOPANEL® COLLECTION CONTENTS

CEILING COLLECTION

FUJI

FUJI ROKU in color #420

COLORS

Available in 4 colors - see website for details

DIMENSIONS

FUJI ROKU 22.05" (+/- 0.12") x 22.05" (+/- 0.12") x 3.54" (+/- 0.12") 560mm (+/- 3mm) x 560mm (+/- 3mm) x 90mm (+/- 3mm)

THICKNESS

FUJI JUNI

22.05" (+/- 0.12") x 45.67" (+/- 0.12") x 3.54" (+/- 0.12") 560mm (+/- 3mm) x 1160mm (+/- 3mm) x 90mm (+/- 3mm)

FUJI KU

33.07" (+/- 0.12") x 33.07" (+/- 0.12") x 5.2" (+/- 0.12") 840mm (+/- 3mm) x 840mm (+/- 3mm) x 132mm (+/- 3mm)

0.18" I 4.6mm

For additional specifications and performance details please visit wovenimage.com HERE 24

SOUND ABSORPTION

with perimeter AS ISO 11654: 2002 (2016) I AS ISO 354: 2006 (R2016) I ASTM C423 - 17 FUJI ROKU

αw NRC SAA

0.75 0.70 0.72

FUJI JUNI

αw NRC SAA

0.80 0.80 0.76

FUJI KU

αw NRC SAA

0.80 0.75 0.74 25

ECHOPANEL® COLLECTION CONTENTS

CEILING COLLECTION

E C H O P A N E L® A R R A Y 12mm & 24mm

EchoPanel® ARRAY VIADUCT 24mm in color #447

COLORS

Full EchoPanel® 12mm & 24mm color ranges - see page 7

DIMENSIONS

94.49" (+/- 0.2") x 11.69" (+/- 0.2") I 2400mm (+/- 5mm) x 297mm (+/- 5mm)

SOUND ABSORPTION

0.47" I 12mm - direct fix results AS ISO 354: 2006 (R2016) AS ISO 11654: 2002 (2016) ASTM C423 - 17 αw 0.65 (H) NRC 0.70 SAA 0.68 Class C

26

SOUND ABSORPTION

0.94" I 24mm - direct fix results AS ISO 354: 2006 (R2016) AS ISO 11654: 2002 (2016) ASTM C423 - 17 αw 0.75 (MH) NRC 0.85 SAA 0.83 Class C

For additional specifications and performance details please visit wovenimage.com HERE 27

ECHOPANEL® COLLECTION CONTENTS

CEILING COLLECTION

E C H O PA N E L® E L E M E N T

454

442

542

Also available in the full EchoPanel® 0.94" (24mm) color range, subject to minimum order quantities.

EchoPanel® ELEMENT #454 suspended

EchoPanel® ELEMENT #442 clipped to ceiling grid

ASSEMBLED DIMENSIONS

92.52" (+/-0.08") x 92.52" (+/-0.08") x 8.46" (+/-0.08") 2350mm (+/-2mm) x 2350mm (+/-2mm) x 215mm (+/-2mm)

BLADE THICKNESS

0.94" I 24mm

SOUND ABSORPTION

AS ISO 354: 2006 (R2016) - direct fix results αw 0.40 NRC 0.35 SAA 0.36 Class D

BOX COMPONENTS

8 x EchoPanel® blades 16 x ceiling clips Suspension kit sold separately

For additional specifications and performance details please visit wovenimage.com HERE 28

EchoPanel® ELEMENT in color #542

29

ECHOPANEL® COLLECTION CONTENTS

E C H O P A N E L® C O L L E C T I O N

S PAC E D I V I D I N G C O L L E CT I O N Our range of EchoPanel® space dividing systems includes hanging pendents, free-standing room dividers and workstation screens.

These products allow open plan spaces, typical of modern workplace and hospitality environments, to be partitioned with ease and flexibility whilst reducing reverberated noise to improve both comfort and productivity.

30

EchoPanel® 12mm SUMMIT pendent in colors #442 & #365

31

ECHOPANEL® COLLECTION CONTENTS

SPACE DI V IDING COLLEC T ION

HANGING PENDENTS

32

EchoPanel® 12mm TANDEM pendent in color #579

500

101

908

454

468

447

442

444

402

580

550

542

276

576

274

269

193

167

295

487

384

579

381

108

124

330

349

338

325

365

660

633

551 33

ECHOPANEL® COLLECTION CONTENTS

SPACE DI V IDING COLLEC T ION

HANGING PENDENTS

PENDENT DESIGNS 0.47" I 12mm

TANDEM 0.47" I 12mm

SUMMIT 0.47" I 12mm

DOT 0.47" I 12mm

SPLAY 0.47" I 12mm

EchoPanel® 12mm SPLAY pendent in colors #101, #660 & #365

COLORS

Full EchoPanel® 0.47" (12mm) color range - see page 27

PENDENT DESIGNS

5 styles

PANEL DIMENSIONS

0.47" I 12mm 94.49" (+/-0.2") x 47.24" (+/-0.39") 2400mm (+/-5mm) x 1200mm (+/-10mm)

SOUND ABSORPTION

See EchoPanel® 0.47" (12mm) on page 6 for details

BOX COMPONENTS

1 x cut EchoPanel® 0.47" (12mm) 1 x 12mm hanging pendent component kit

For additional specifications and performance details please visit wovenimage.com HERE 34

35

ECHOPANEL® COLLECTION CONTENTS

SPACE DI V IDING COLLEC T ION

PA L I N G

454

442

542

Also available in the full EchoPanel® 0.94" (24mm) color range, subject to minimum order quantities.

EchoPanel® PALING in color #442 with charcoal joiners

EchoPanel® PALING in color #442 with copper joiners

PRODUCT TYPE

Free-standing system

PANEL DIMENSIONS

PALING A (end panel) & B (middle panel) 11.22" (+/-0.08") x 68.9" (+/-0.08") 285mm (+/-2mm) x 1750mm (+/-2mm)

PANEL THICKNESS

0.94" I 24mm

JOINER COLORS

Cream, charcoal and copper - to be specified in order

SOUND ABSORPTION

See EchoPanel® 0.94" (24mm) on page 6 for details

For additional specifications and performance details please visit wovenimage.com HERE 36

PALING in color #542 with cream joiners

37

ECHOPANEL® COLLECTION CONTENTS

SPACE DI V IDING COLLEC T ION

P L AT O O N

PLATOON in colors #442 & #542 with charcoal joiners

PRODUCT TYPE

Free-standing system

PANEL DIMENSIONS

68.9" (+/-0.08") x 137.8" (+/-0.08") 1750mm (+/-2mm) x 3500mm (+/-2mm)

PANEL THICKNESS

0.94" I 24mm

JOINER COLORS

Cream and charcoal - to be specified in order

SOUND ABSORPTION

See EchoPanel® 0.94" (24mm) on page 6 for details

BOX COMPONENTS

6 x PLATOON panels 10 x pivot joiners

38

454

442

542

For additional specifications and performance details please visit wovenimage.com HERE 39

MAIN CONTENTS

MURA™ COLLECTION M U RA™ PAL ET TE........................................... . . . . . . . . . . . . . . . . . 4 2

Mura™ is an innovative and versatile, 0.075" (1.9mm) thick, surface finish that is highly cost effective and easy to install. The face side has been designed to create a smooth clean look, whilst the back has been engineered with a forgiving texture that can be adhered to a variety of surfaces including walls, workstation screens and operable walls.

Mura™ boasts an on-trend color palette and print designs. Made from 60% recycled PET with low VOCs, Mura™ has the same first-rate environmental certifications as EchoPanel®.

®

40

Wall: MURA™ in color #454 Desk screen: MURA™ in color #551

41

MURA™ COLLECTION CONTENTS

M U R A™ C O L L E C T I O N

M U R A ™ PA L E T T E

501

101

908

454

468

447

442

444

402

580

550

542

274

487

269

330

349

384

124

167

365

660

551

ROLL DIMENSIONS

236", 984" or 4134" roll I 6m, 25m or 105m roll

WIDTH

47.64" (+/-0.2") I 1210mm (+/-5mm)

THICKNESS

0.07" (+/-0.01") I 1.9mm (+/-0.25mm)

SOUND ABSORPTION

AS ISO 354: 2006 (R2016) - direct fix results αw 0.10 (H) NRC Value 0.10 SAA 0.08

For print area, layout information & full specifications please visit wovenimage.com HERE 42

MURA™ in color #384

43

MAIN CONTENTS

E M B O S S E D P A NE L C O LLE C T IO N ZEN . . ............................................................. . . . . . . . . . . . . . . . . . . . . 4 6

The embossed acoustic panel collection represents the latest innovation from Woven Image. Made

I ON . . ............................................................. . . . . . . . . . . . . . . . . . . . . 4 8

using recycled plastic, this design-led collection embraces the trend towards tactile surfaces and

GEM .............................................................. . . . . . . . . . . . . . . . . . . . . 5 0

three-dimensional textures, interweaving cuttingedge design with sustainability and commercial

P I C O............................................................. . . . . . . . . . . . . . . . . . . . . 5 2

performance.

Available in four unique designs; Zen, Ion, Gem and Pico, which have been specially designed to provide a floor-to-ceiling acoustic solution for commercial office interiors and pattern matches for continuous wall and double-height installations.

The collection received four international awards in 2020 and 2021 for their innovative designs; the Dezeen Award for Workplace Design, and the FX Design Award for Best Surface in 2020 and in 2021, the Architizer Award for A+ Products and an INDE Award. The uniqueness of the design was observed instantly by the Dezeen Awards judges who said that “in this instance, there was an attempt to define the space in sculptural terms and also give the product tactility”. The Dezeen Awards received more than 4,300 entries, from 85 countries across 5 continents.

®

44

ZEN in color #365

45

EMBOSSED PANEL COLLECTION CONTENTS

EMBOS SED PA NEL COLLEC T ION

ZEN

501

101

908

454

550

447

402

580

274

269

487

167

330

349

384

365

660

551

468

124

PANEL DIMENSIONS

110.24" (+/-0.08") x 44.49" (+/-0.08") I 2800mm (+/-2mm) x 1130mm (+/-2mm)

PANEL THICKNESS

0.35" (+/-7%) I 9mm (+/-7%)

SOUND ABSORPTION

AS ISO 354: 2006 (R2016) - direct fix results αw 0.20 (H) NRC 0.30 SAA 0.28 Class E

For additional specifications and performance details please visit wovenimage.com HERE 46

ZEN in color #908

47

EMBOSSED PANEL COLLECTION CONTENTS

EMBOS SED PA NEL COLLEC T ION

ION

101

908

468

550

447

402

580

274

487

167

124

349

384

660

551

PANEL DIMENSIONS

110.24" (+/-0.08") x 44.49" (+/-0.08") I 2800mm (+/-2mm) x 1130mm (+/-2mm)

PANEL THICKNESS

0.35" (+/-7%) I 9mm (+/-7%)

SOUND ABSORPTION

AS ISO 354: 2006 (R2016) - direct fix results αw 0.20 (H) NRC 0.30 SAA 0.28 Class E

For additional specifications and performance details please visit wovenimage.com HERE 48

ION in colors #550 & #908

49

EMBOSSED PANEL COLLECTION CONTENTS

EMBOS SED PA NEL COLLEC T ION

GEM

101

908

468

550

447

402

580

274

487

167

124

349

384

660

551

PANEL DIMENSIONS

110.24" (+/-0.08") x 44.49" (+/-0.08") I 2800mm (+/-2mm) x 1130mm (+/-2mm)

PANEL THICKNESS

0.35" (+/-7%) I 9mm (+/-7%)

SOUND ABSORPTION

AS ISO 354: 2006 (R2016) - direct fix results αw 0.20 (H) NRC 0.30 SAA 0.28 Class E

For additional specifications and performance details please visit wovenimage.com HERE 50

GEM in color #167

51

EMBOSSED PANEL COLLECTION CONTENTS

EMBOS SED PA NEL COLLEC T ION

PICO

501

101

908

454

550

447

402

580

274

269

487

167

330

349

384

365

660

551

468

124

PANEL DIMENSIONS

110.24" (+/-0.08") x 44.49" (+/-0.08") I 2800mm (+/-2mm) x 1130mm (+/-2mm)

PANEL THICKNESS

0.35" (+/-7%) I 9mm (+/-7%)

SOUND ABSORPTION

AS ISO 354: 2006 (R2016) - direct fix results αw 0.20 (H) NRC 0.30 SAA 0.28 Class E

For additional specifications and performance details please visit wovenimage.com HERE 52

PICO in colors #384, #468 & #274

53

MAIN CONTENTS

ACOUSTIC TILE COLLECTION Whether your interiors project requires large scale

B A L A N C E . . ................................................... . . . . . . . . . . . . . . . . . 5 6

coverage or to create smaller design features,

A S C E N T ....................................................... . . . . . . . . . . . . . . . . . 5 8

this range provides an endless stream of design configurations that provide great aesthetics whilst

D U N E ........................................................... . . . . . . . . . . . . . . . . . 6 0

controlling reverberated noise in; Collaborative workspaces and meeting rooms

W A V E ........................................................... . . . . . . . . . . . . . . . . . 6 2

Classrooms and music rooms Cafés and restaurants Lobbies and public spaces They are lightweight, easy to install, and pattern match without the need for trimming.

Tiles in this collection are made from EchoPanel® or Mura™, which achieves first-rate environmental certifications.

54

WAVE tiles in color #101

55

ACOUSTIC TILE COLLECTION CONTENTS

AC OUS T IC

T IL E

COL L EC T ION

BALANCE

101

908

454

468

402

442

542

550

269

487

384

330

325

633

365

TILE THICKNESS

0.47" (+/-7%) I 12mm (+/-7%)

SOUND ABSORPTION

AS ISO 354: 2006 (R2016) - direct fix results αw 0.45 (MH) NRC 0.65 SAA 0.63 Class D

BOX COMPONENTS

BALANCE 670 - 12 x tiles BALANCE 1340 - 6 x tiles

BALANCE 670 13.19" (335mm)

BALANCE 670 BALANCE 1340

26.38" (670mm)

BALANCE 1340 13.19" (335mm)

PRODUCT NAME

52.76" (1340mm)

For additional specifications and performance details please visit wovenimage.com HERE 56

BALANCE 1340 tiles in color #454 & BALANCE 670 tiles in color #384

57

ACOUSTIC TILE COLLECTION CONTENTS

AC OUS T IC

T IL E

COL L EC T ION

ASCENT

501

101

454

908

402

447

542

269

274

487

167

124

349

330

660

551

365

1.97" (50mm) 19.68" (500mm)

19.68" (+/-0.08") x 35.43" (+/-0.2") x 1.97" (+/-0.2") 500mm (+/-2mm) x 900mm (+/-5mm) x 50mm (+/-5mm)

TILE THICKNESS

0.16" (+/-0.02") I 4mm (+/-0.5mm) measured 0.39" (10mm) above trimmed edge

SOUND ABSORPTION

AS ISO 354: 2006 (R2016) - direct fix results αw 0.60 (MH) NRC 0.70 SAA 0.66 Class C

BOX COMPONENTS

6 x tiles, 16 x installation clips

35.43" (900mm)

TILE DIMENSIONS

®

For additional specifications and performance details please visit wovenimage.com HERE 58

ASCENT tiles in color #269

59

ACOUSTIC TILE COLLECTION CONTENTS

AC OUS T IC

T IL E

COL L EC T ION

DUNE

908

101

447

542

487

269

349

660

TILE DIMENSIONS

19.69" (+/-0.08") x 19.69" (+/-0.08") x 1.97" (+/-0.2") 500mm (+/-2mm) x 500mm (+/-2mm) x 50mm (+/-5mm)

TILE THICKNESS

0.16" (+/-0.02") I 4mm (+/-0.5mm) - measured 0.39" (10mm) above trimmed edge

SOUND ABSORPTION

AS ISO 354: 2006 (R2016) - direct fix results αw 0.50 (MH) NRC 0.60 SAA 0.58 Class D

BOX COMPONENTS

9 x tiles, 16 x installation clips

A

19.69" (500mm)

A

Section A-A

1.97" (50mm)

A

19.69" (500mm)

For additional specifications and performance details please visit wovenimage.com HERE 60

DUNE tiles in colors #908 & #349

61

ACOUSTIC TILE COLLECTION CONTENTS

AC OUS T IC

T IL E

COL L EC T ION

WAV E

101

447

542

487

269

349

660

TILE DIMENSIONS

19.69" (+/-0.08") x 19.69" (+/-0.08") x 2.46" (+/-0.2") 500mm (+/-2mm) x 500mm (+/-2mm) x 62.5mm (+/-5mm)

TILE THICKNESS

0.16" (+/-0.02") I 4mm (+/-0.5mm) - measured 0.39" (10mm) above trimmed edge

SOUND ABSORPTION

AS ISO 354: 2006 (R2016) - direct fix results αw 0.50 (MH) NRC 0.60 SAA 0.58 Class D

BOX COMPONENTS

9 x tiles, 16 x installation clips

19.69" (500mm)

908

2.46" (62.5mm) A

A

Section A-A

19.69" (500mm)

For additional specifications and performance details please visit wovenimage.com HERE 62

WAVE tiles in color #487

63

MAIN CONTENTS

AC O US T I C FA BRI C

F O C U S WAV E

909

451

442

440

172

338

332

273

WIDTH

53.94" I 137cm

PATTERN REPEAT

Horizontal 0.98", Vertical 4.33" Horizontal 2.5cm, Vertical 11cm

SOUND ABSORPTION

AS ISO 354: 2006 (R2016) - direct fix results αw 0.20 (H) NRC Value 0.30 SAA 0.29

For additional specifications and performance details please visit wovenimage.com HERE 64

FOCUS WAVE in color #172

65

MAIN CONTENTS

E C H O P A N E L® C O L L E C T I O N

PRINT DESIGNS Shown here are a small selection of our printed EchoPanel® designs. These can be printed single or double-sided, making them suitable for walls, ceilings and partitions.

Woven Image has a long history of working with global design and manufacturing clients to deliver unique customized prints. Contact us to discuss your project requirements.

Tilt

Frequency

Trapeze

Trio

Astro

For additional specifications and performance details please visit wovenimage.com HERE 66

67

For additional specifications and performance details please visit wovenimage.com HERE Woven Image Pty Ltd

-

+1 949 220 3727

-

enquiries@wovenimage.com

-

wovenimage.com
