Ball Valve Lockout
This lockout device is placed over the top of the ball valve to prevent the valve handle from being turned. Once in the correct isolated position, the handle of the valve is trapped within the body of the lockout, preventing the handle from being operated.
USING A BALL VALVE LOCKOUT
DIRECTIONS FOR USE:
PLEASE NOTE:
Holes on the slider section have a staggered repeat which ensures that at least one hole will be tight when placed against the valve. If more than one padlock is required then a hasp should be used.
STEP 1
Turn the valve handle to the correct position,
Either on or off.
STEP 3
Move slider section down the shaft of the lockout until tight against the valve body.
STEP 2
Lockout the device by placing the main body over the top of the valve handle. Ensure the valve handle sits inside channel.
STEP 4
Insert a padlock or hasp through the most appropriate hole which keeps the slider secure.
FIND THE FULL RANGE OF PIPELINE IDENTIFICATION ON PAGE 118
Ball Valve Lockout
3 sizes available.
Size
Code 9.5 - 31mm LOK023 32 - 63mm LOK024 50 - 203mm LOK025
Butterfly Valve Lockout
When slid into position the wedge on the slider section prevents the compression handle being squeezed, preventing operation of the valve.
Working in a similar way to the standard ball valve lockouts, the wedge on the slider section sits between the compression handle and lever, preventing operation.
8 - 45mm
Code LOK018
Flange Ball Valve Lockout
Once the flange ball valve is in the desired position and the handle removed, this lockout device fits over the top of the stem ring.
The two sections of the device slide together over the top of the stem, ensuring it is suitable for various sizes of valves.
Hole size: 46 x 38mm
Size
Code 150 x 220 x 70mm LOK186
DIRECTIONS FOR USE:
STEP 1 STEP 2 STEP 3
