n PFERD cuts and their application

PFERD cuts and their application

PFERD cuts for universal applications PFERD cuts for high-performance applications

Single cut

n Machining of steel, cast iron, stainless steel (INOX), nickel-based alloys and titanium alloys. n High stock removal. n Good surface finish.

Double cut

n Similar to single cut, but with cross cut. n Machining of steel, cast iron, stainless steel (INOX), nickel-based alloys and titanium alloys. n High stock removal.

Diamond cut n Machining of stainless steel (INOX), steel and high-temperature-resistant materials such as nickel-based and cobalt-based alloys. n High stock removal with short chips. n Good surface finish.

PFERD cuts for performance applications

OMNI cut

n High stock removal rate on key materials such as steel, cast steel, stainless steel (INOX), non-ferrous metals and cast iron. n Similar to the double cut but with a significantly higher stock removal rate.

STEEL cut

n Extremely high stock removal rate on steel and cast steel. n Smooth milling. n Reduced vibration and less noise.

INOX cut

n Extremely high stock removal rate on all austenitic, rust and acid-resistant steels, stainless steel (INOX) and soft titanium alloys. n Significantly reduced vibration and less noise.

ALU cut

n High stock removal rate on aluminum and aluminum alloys, non-ferrous metals and plastics. n Smooth milling.

CAST cut

n Extremely high stock removal rate on cast iron. n Smooth milling. n Reduced vibration and less noise.

EDGE cut

n Creates exact edge shapes – with either 30° or 45° chamfering or a defined radius of 1/8”. n Safe and comfortable to guide.

TOUGH cut

n High stock removal rate on cast iron, steel up to 580 HV (54 HRC). n Extremely resistant to impacts. n Suitable for use with high surface contact angles > 1/3 and under impact loads.

MICRO cut

n Good stock removal on almost all materials up to 940 HV (68 HRC). n High surface quality. n Reduced vibration and less noise.

HICOAT® coatings n PFERD carbide burs are also available with HICOAT® coatings. n Improved anti-adhesion characteristics. n Effective chip discharge. n Lower thermal loads. n Increased service life. n Also suitable for use at higher peripheral speeds when compared with uncoated burs.
