CLAY STREET
Three Embarcadero Center
GENERAL
Rentable Area
6064 SF (R-3113)
Storefront Frontage 236’-7” (R-3113)
Ceiling Height 9’-0”
ARCHITECTURAL
Present Condition
Clothing and apparel store
General Layout
Open retail space with storefront windows and dressing rooms in the back on each floor
Storefront Construction
Anodized aluminum frames, clear glass
Ceiling Construction
Gypsum board throughout, open in storage spaces
Special Features
Dressing Rooms, two single-use bathrooms on street level
STRUCTURAL
Construction Type
Reinforced concrete
MECHANICAL
HVAC Equipment
Approximately 28 tons of HVAC located on Street Level- Equipped with (3) Carrier Air Handler Units:
• AHU-4: Serial Number: 2901F97820 Model #39LA08QBBA2-AHJ-2G
• AHU-5: Serial Number: 2901F97816 Model #39LA12QBAAR-AGN-BG
• AHU-6: Serial Number: 2901F977821 Model #39LA08QBBA2-AHJ-2G
Approximately 20 tons of HVAC located on Lobby Level-Equipped w/ (2) Carrier & (1) Magic Aire Air Handler Units:
• AHU-1: Serial Number: 2901F97819 Model #39LA08MBCAQ-CGJ-29
• AHU-2: Serial Number: 2901F97806 Model #39LA08KAA3-AKN-A9
• AHU-3: Serial Number: 970300019 Model #180-BHW-4
Hot/Chilled Water - HVAC
Street Level
• Hot/Chilled Water Services: 2” Chilled Supply/Return serving space from risers
• 1 ¼” Heating Supply/Return serving space from risers
Lobby Level
• Hot/Chilled Water Services: 2” Chilled Supply/Return serving space from risers
• 1 ¼” Heating Supply/Return serving space from risers
• Chilled water risers located at column line 13,C
• Heating water risers located at column line 11,C
HVAC Controls Johnson Controls Special Ventilation None
ELECTRICAL
Service
Street Level Service:
400 amp,120/208V, 3ph, 4-wire. (1)
Service feed to Distribution Panel 1 on Street level. Fed from A-level Electrical Panel APLD.
Lobby Level Service:
300 amp,120/208V, 3ph, 4-wire. (1) Service feed to Distribution Panel 2 on Lobby Level. Fed from A-level Electrical Panel APLD.
Sub-Panels
Street Level Electrical Room:
Distribution Panel 1- 120/208V, 3ph, 4-wire, 400 amp rated.
Lobby Level Storage Room:
Distribution Panel 2- 120/208V, 3ph, 4-wire, 400 amp rated
Lighting
• Track lighting and recessed cans throughout showroom. Track lighting in show windows.
• Fluorescent lighting in storage rooms.
DATA/COMMUNICATIONS
Telephone/Data MPOE
4” Conduit stubbed to backboard in Lobby level Storage Room from “A” level MPOE room.
Data Available
Telco conduit in Lobby level Storage Room space connects to the building main telephone, (MPOE) room. Tenant needs to contract with the building’s riser management company to connect their premises.
FIRE/LIFE SAFETY
Fire Sprinklers
Existing, ready for Tenant’s final distribution to meet specific application and use of premises.
Fire Alarm
Fire Alarm stubbed to premises. Tenant to modify as needed to meet specific application and use of premises.
PLUMBING
Toilet Rooms
Current space has (2) restrooms located within the Street Level portion of space. Each restroom containing (1) water closet, (1) sink with instant tankless water heater and (1) floor drain
Water Heater
Tankless water heater in each restroom
Drinking Fountain Street Level: (1) Elkay Hi-low drinking fountain present at column line 11,D
Domestic Water
• Street Level: 1 ½ Domestic cold water serving space from riser
• Lobby Level: 1 ½ Domestic cold water serving space from riser
• 2” Domestic cold water riser located at column line 11, C
Waste
4” Waste Riser located at intersection of column line 11, C within space, tie-in for waste located below slab of premises.
Vent
Vent Riser located at column line 11, C
