Suspended Plate

Bunting suspended plate magnets are designed to be suspended above open conveyors to remove ferrous objects and fines found in conveyed materials such as ceramic raw materials and spray dried ceramics.

• Suspends over conveyor belt or drop off point to remove ferrous contaminants without interrupting product flow. • Powerful ceramic magnet field reaches deep into conveyed material to pull ferrous tramp from flat-belt and trough style conveyers. Rare earth magnet models are available for applications that require greater magnetic power. • Sturdy, free-standing, bolt-together support frame offers a convenient mounting option. • Optional stripper plate slides out for fast, easy, out-of-the-way cleaning.

Our Suspended Plates come in sizes matched to common belt widths and are outfitted with eye-bolts to aid in handling and overhead suspension. • 950 Suspended Plates are designed for deep 10″ reachout troughing applications and for high conveyor speeds of 100 to 300 fpm. • 650 Suspended Plates are designed for medium-duty and lighter burden depth where 6 1/2″ reachout is adequate. The 650 Series is a cost effective choice when dealing with lighter product density, lower conveyor speeds, or thinner burden depths. • 450 Suspended Plates are designed for light-duty flat belt applications with a 6 1/2″ reachout. They can be upgraded from ceramic to rare earth magnets, resulting in higher intensity magnetic fields to separate metal fines from thin, light layers of products conveyed at speeds under 100 fpm on flat belts.
