Folder on Wqll Ponel Jig fimber Engineering Company is offering free a four page folder describing the "Teco IJniJig" for wall fanel assembly. The "Uni-Jig" can be used with practically any modular system utilizing 16" and 24" spacing.

Consisting of a series of stud locators, pressure bars and.base locator plates which are mounted on any sturdily built wood work table, Tecots "Uni-Jig" makes it possible to assemble a wide variety of wall panels without the need for special measuring or marking of studs, plates and other parts that go to make up a wall section.

The "Uni-Jig" is simple to use because the stud locators and pressure bars literally snap into position. The locators and bars are formed of square tubular steel sections and are equipped with a spring actuated pin at each end. The pin is inserted in modularly spaced holes drilled into base locator plates at the top and bottom of the jig.

Only seeonds are required to set up the "IJni-Jig" for fabrication when modular spacing is used. When non-modular panels are to be built, the exact location of studs and other parts can be determined through the use of scales which run the full lntcsting In lmoginolion ond Reseorch To Bene'/;l Indu'lry

For further information on hoY our iPecial automated highli."J tirting, gluing and -fin-- isning equiPment can serve Vour -Particular needs - Please lontait our rePresentative' todaY.

Four-Page Folder ls Free length of the top and bottom of the jig. The scale is graduated in inches but also has superimposed upon it every eight inches a series of letters which relate to Teco's system of programmed fabrication.
