Capital45 Brochure

Capital45

Premium architectural steel doorsets.

About Capital45

With over 40 years of experience in the industry, our Capital45 is an established premium architectural steel doorsets, enhanced by a full project management service Designed for inspiring buildings and innovative infrastructure of high profile clients, the Capital45 steel doorsets provide solutions for fire, acoustic and security requirements.

Bespoke-engineered and precision-manufactured to suit varying architectural design requirements and project and performance briefs. With solutions for personnel, fire protection, security, acoustic, and emergency egress briefs, the Capital45 is designed to be a versatile doorset suited to varying building requirements.

Having widely installed throughout the UK, some of our most notable projects include the Leadenhall Building, 20 Fenchurch Street, affectionately known as the ‘Walkie Talkie’ due to its unique shape, and The Gherkin.

SUITABLE APPLICATIONS

Capital45 is also installed doorsets in major retail, residential and operational infrastructures including One Hyde Park, Trinity Leeds, Victoria Gate Leeds, the De Vere Building, Heathrow Terminal 5, and the Emirates Air Line. We continue to work within major developments across the UK, and are proud to play our part in enhancing the country’s skyline.

All Capital45 doors are manufactured in the UK at our main production and parent company, Bradbury Group, in Scunthorpe.

We stand for quality, precision and beauty.

Capital45 Brochure 01-01GB 07-23 Capital45

Commercial Buildings Luxury Accommodations & Hotels Transport Hubs & Railway Stations Retail Complexes & Shopping Centres Schools & Universities Hospitals & Pharmaceutical Enviroments Recording Studios & Theatres Other Infrastructure Schemes Variant Min Height (mm) Max Height (mm) Min Width (mm) Max Width (mm) Single outward opening doorsets 1500 2950 600 1470 Double outward opening doorsets 1500 2950 1050 2830 Single inward opening doorsets 1500 2950 600 1470 Double inward opening doorsets 1500 2950 1050 2830

Accreditations

Capital45 doors are also available with optional vision panels and louvres for ventilation.

Tested by BRE to BS EN ISO 10140-2:2010, Capital45 doors are certified to provide up to 36dB of noise reduction.

Capital45 doors are available with a fire integrity rating of up to 180 minutes with a mineral wool infill, certified by Exova under the CERTIFIRE scheme. Capital45 doorsets have also passed rigorous smoke testing.

Door Configuration

Certain Capital45 doors are available with a thermal rating from 1.9W/m2K to 3.8W/m2K, depending on specification.

Capital45 doorsets are tailored to each individual’s needs and architectural specifications. The doorset can be supplied with a range of varying configurations, accreditations and aesthetically pleasing polyester powder coated finishes. We can also futureproof our doorset with in-built wiring and reinforcement support to allow for access control solutions to be added at some point in the future.

FINISH

Doorsets are available primed or polyester powder coated in a wide range of colours and finishes. Bespoke options include high quality wood-grain and textured effects, as well as Extra Life paint, offering up to 10 years’ anti-rust warranty underwritten by Cromadex Akzo Nobel.

INSTALLATION

With over 25 years’ experience in the survey and installation of security products, Bradbury’s team of accredited installation engineers provide a nationwide fitting service.
