Bosch Greenstar Boiler Repair & Cleaning Kits
Bosch Greenstar is the best-selling boiler in the world (with over 4 million sold)
There are millions of Bosch Greenstar wall and floor boilers installed world wide. If you install and service these great boilers, you’ll want to have our handy repair parts and cleaning kit on hand in your truck. The contents of these kits are necessary for the most common Bosch Greenstar service calls. Get your kit today!
Greenstar 5 Yr Maintenance Kit
Cleaning the Heat Exchanger for the Bosch Greenstar shouldn't be necessary for a few years after installation. When it comes time to clean it, this kit will come in handy.
Greenstar Parts Kit
Every component of this Bosch Greenstar Parts Kit was carefully selected based on feedback from technical service calls with contractors like you. This kit contains all of the necessary components for the most common repairs.
Greenstar Ultimate Parts Kit
The
Part Number Quantity Description 8-737-704-671-0 1 Control unit HT3 GZT5II 8-718-664-920-0 1 Set of electrodes/ignitor assembly 8-718-226-391-0 1 Gas valve USA 8-716-106-847-0 1 Diverter valve assembly motor 8-710-506-271-0 1 Siphon 8-714-500-117-0 1 Temperature sensor 8-722-963-858-0 1 Temperature limiter 8-710-103-153-0 1 Gasket 8-711-004-168-0 1 Burner gasket
Part Number USD List Price CAD List Price 7-738-005-190 $1,071 $1,495
Part Number Quantity Description 7-719-002-502 1 Brush set WB5 (Includes 5 Brushes and 5 Gaskets (87101031530)) 7-719-002-503 1 Cleaning tool WB5 8-718-664-920-0 1 Electrode 8-711-004-168-0 1 Burner gasket
Part Number USD List Price CAD List Price 7-738-005-718 $258 $382
Contact your distributor to order a kit! Call Bosch at 1-800-798-8161 with any questions. (Information subject to change without notice.) Part Number Quantity Description 8-718-664-920-0 1 Electrode 8-711-004-168-0 1 Burner gasket 8-737-704-671-0 1 Control unit HT3 GZT5-II 8-710-103-153-0 1 Gasket 8-722-963-858-0 1 Temperature limiter 8-718-226-391-0 1 Gas valve 8-716-117-299 1 Foot M8 8-716-106-356-0 1 Supply manifold complete 8-718-226-184-0 1 Fan RG128 8-748-300-739-0 1 Printed circuit 8-718-226-173-0 1 Pump 8-718-226-185-0 1 Fan RG130 8-716-108-212-0 1 Heat exchanger plates 8-737-700-289-0 1 Sensor 8-716-106-435-0 1 Seal 15mm 8-714-500-117-0 1 Temperature sensor 8-744-503-045-0 1 Fuse 8-718-226-172-0 1 Pump ZBR 8-716-106-433-0 1 Flow turbine adapter 8-737-703-427-0 1 Safety valve 8-710-506-267-0 1 Temperature limiter assembly 8-716-106-847-0 1 Diverter valve assemby motor 8-737-701-343-0 1 Cylinder temperature sensor 8-714-500-087-0 1 Temperature sensor 8-710-506-271-0 1 Siphon 8-716-106-445-0 1 Air vent valve 8-718-682-332-0 1 Nut M8 with flange 8-718-226-386-0 1 Adapter Minimum pressure switch 8-716-106-799-0 1 Ignition harness 8-718-006-658-0 1 Burner 8-714-500-081-0 1 DHW temperature sensor 8-716-119-295-0 1 Diaphragm valve 8-710-725-353-0 1 Silencer 8-729-000-183-0 1 Washer 8-718-003-836-0 1 Shield
Greenstar Ultimate Parts Kit is comprehensive in its contents and designed to address most downtime issues you may have. Part Number USD List Price CAD List Price 7-738-007-193 $4,250 $5,738 75HPT1800C 8/23
