A Division of BendPak Inc.
TEMPEST SERIES
WINDSTORM SERIES
Thin metal rods to charge particles
Positive Charged Metal Plate
Clean Air
Incoming uncharged particles/air Metal Plates
The negative charged particles are attracted to the positively charged metal plate.
Counterclockwise – Summer Generates Cooling Effect
Clockwise – Winter Effectively Mixes Warm and Cold Air
Fan Diameter 11.5 ft. / 3.5 m
Mount to Motor 49.2 in. / 1,250 mm
Motor Diameter 13.4 in. / 340 mm
Mount to Blade* 42.5 in. / 1,080 mm
RPM (Variable) 90 RPM Max.
Number of Blades 6
Air Volume 148,321 cfm / 4,200 cmm
Fan Hanging Weight 152 lbs. / 69 kg
Voltage/Current** 208-240VAC, 50/60Hz, 1Ph., 5A
Frequency/Phase 50/60 Hz., 1 Ph.
UL Certification Yes
Intertek ETL Listed Yes
OPT. Ceiling Height 17 ft. / 5,258 mm
Control Cable Length ≈80 ft. / 25 m
Operating Temperature -13° to +140° F / -10.5° to +60° C
Operating Humidity <95% Non-Condensing
Fan Diameter 16.5 ft. / 5 m
Mount to Motor 51.5 in. / 1,310 mm
Motor Diameter 13.4 in. / 340 mm
Mount to Blade* 41.3 in. / 1,049 mm
RPM (Variable) 78 RPM Max.
Number of Blades 6
Air Volume 360,210 cfm / 10,200 cmm
Fan Hanging Weight 209.5 lbs. / 95 kg
Voltage/Current** 208-240VAC, 50/60Hz, 1Ph., 5A
Frequency/Phase 50/60 Hz., 1 Ph.
UL Certification Yes
Intertek ETL Listed Yes
OPT. Ceiling Height 25 ft. / 7,544 mm
Control Cable Length ≈80 ft. / 25 m
Operating Temperature -13° to +140° F / -10.5° to +60° C
Operating Humidity <95% Non-Condensing
Low Speed
mm
13.4 in. / 340 mm 16.5 ft.
Fan Diameter 20 ft. / 6.1 m
Mount to Motor 54.3 in. / 1,379 mm
Motor Diameter 17.3 in. / 439 mm
Mount to Blade* 43.3 in. / 1,100 mm
RPM (Variable) 60 RPM Max.
Number of Blades 5
Air Volume 448,496 cfm / 12,700 cmm
Fan Hanging Weight 282 lbs. / 128 kg
Voltage/Current** 208-240VAC, 50/60Hz, 1Ph., 7A
Frequency/Phase 50/60 Hz., 1 Ph.
UL Certification Yes
Intertek ETL Listed Yes
OPT. Ceiling Height 30 ft. / 9,144 mm
Control Cable Length ≈80 ft. / 25 m
Operating Temperature -13° to +140° F / -10.5° to +60° C
Operating Humidity <95% Non-Condensing
43.3 in.* 1,100 mm
17.3 in. / 439 mm 20 ft. 6.1 m
54.3 in. 1,379 mm
Fan Diameter 24 ft. / 7.3 m
Mount to Motor 54.3 in. / 1,379 mm
Motor Diameter 17.25 in. / 439 mm
Mount to Blade* 43.3 in. / 1,100 mm
RPM (Variable) 55 RPM Max.
Number of Blades 5
Air Volume 524,422 cfm / 14,850 cmm
Fan Hanging Weight 295.5 lb. / 134 kg
Voltage/Current** 208-240VAC, 50/60Hz, 1Ph., 7A
Frequency/Phase 50/60 Hz., 1 Ph.
UL Certification Yes
Intertek ETL Listed Yes
OPT. Ceiling Height 36 ft. / 10,973 mm
Control Cable Length ≈80 ft. / 25 m
Operating Temperature -13° to +140° F / -10.5° to +60° C
Operating Humidity <95% Non-Condensing
