Baby Lock Array Spec Sheet

BABY LOCK

Embroidery Machine Harness your fearless creativity with the Baby Lock Array multi-needle embroidery machine. Use a brilliant high definition touchscreen as the control center for all of your embroidery masterpieces. Make quick changes to designs and start embroidering right away. Create your own designs or use any of the 126 built-in designs. This powerful six-needle machine includes a variety of features, including a crosshair positioning laser, that will make your wildest creative dreams become a reality.

6 Needle Machine

7-7/8" x 11-3/4" Embroidery Field

IQ Intuition Monitoring®

Embroidery Crosshair Positioning Laser

1,000 Stitches per Minute

BabyLock.com

Array

Embroidery Machine

Six Efficient Needles

7 7/8″ x 11 3/4″ Embroidery F ield

With six needles, you’ll love how quickly you can embroider large, multi-colored designs; and you can finish projects without excessive thread changes between jobs.

Embroider on a massive 7 7/8″ x 11 3/4″ space, giving you more room than ever before!

Embroidery Crosshair Positioning Laser

IQ Intuition Monitoring®

Use the crosshair positioning laser to preview the position of your embroidery design. Then adjust the position and angle for precise alignment. Your embroidery will be perfectly placed every time.

Wireless Capability

Using optional Palette 11 software, easily send designs to your computer for editing or to machine for stitching. Wirelessly download and install software updates for the machine.

Keep track of your project’s progress with this convenient feature that alerts your phone when the bobbin needs to be changed, if a thread breaks, if a thread needs to be changed and when stitching is done.

Intuitive Color Management

Use Color Visualizer to effortlessly find a variety of color schemes for your projects. Select from random, gradient, vivid, or soft effects.

Service

T he Ba by Lo ck Edu cation We provide you with a Ex pe rie nc e comprehensive library of education and training so you’ll always have something to learn.

Convenience Features • 50 font styles • 24 Built-in tutorial videos • Built-in memory (10MB) • Bobbin system: front loading, vertical rotary hook • Uses pre-wound bobbins (Class “L”) • Push button, automatic needle threader • 2 LED lights to illuminate work area • Upper thread breakage sensors • Manual tension control • Automatic thread trimmer (upper and lower) • Start/stop button with lock feature • Onscreen speed control while stitching • Change screen and thumbnail background color • Embroidery shortcut key • Change embroidery position using speed keys • Needle bar/frame move key repositions the hoop for easy access • Advanced editing features Included Accessories • Accessory case • Instruction guides • Embroidery frames ° 200mm x 300mm (7-7/8″ X 11-3/4″) ° 130mm x 180mm (7″ X 5″) ° 100mm x 100mm (3-7/8″ X 3-7/8″) ° 60mm x 40mm (2-1/4″ X 1-1/2″) • Embroidery sheets ° 200mm x 300mm (7-7/8″ X 11-3/4″) ° 130mm x 180mm (7″ X 5″) ° 100mm x 100mm (3-7/8″ X 3-7/8″) ° 60mm x 40mm (2-1/4″ X 1-1/2″) • USB cable • Needle set x 2 • Prewound bobbin x 6 • Spool net x 6 • Spool mat x 6 • Touch pen • Needle changing and threading tool • Needle plate cover • Oiler • 60-Day Trial of Online Sewing Classes • Plus more Optional Accessories • Palette 11 (ECS11) • 4″ x 4″ Versatile magnetic frame M kit (ENMF-100S) • 5″ x 7″ Versatile magnetic frame L kit (ENMF-180S) • Magnetic frame set (ENMFA50) • Magnetic sash frame (ENMF360) • Tubular frame table (ESTABLE) • Wide table (ENTABLE) • Embroidery stand (ALSTAND) • Flat brim cap frame set (EPCF4) • Cap frame set (EPCF3) • Quilt frame (ENF200) • Border frame (ENBF) • Flat frame (BMP-FF) • Round frame set (ENRFS) • Embroidery frame holder C (ENRF-ARMC) • Clamp frame S straight set (ENCLFS1) • Clamp frame M Set (ENCLF100) • Compact frame set (ENCOMFS) • Sleeve frame (ENSF) • Bobbin winder set (EPBW1) • Metal bobbin set (BMP-BOB) Warranty: 25-year limited, 2-year parts, 5-year computer circuit, 5-year electrical, 1-year labor

We provide the highest quality products and services, and can meet your needs better than anyone else.

For a complete list of specifications and accessories visit BabyLock.com

Su pport

You can rely on Baby Lock for the support you need to get the most out of your machine.

LBSP-BMY6 7/2023
