Babco Heavy-Duty Catalogue Fall 2023-V2

Page 1

Omer Mobile Column Lifts OMER’s state-of-the-art MCO MOBILE COLUMN lifts allow you to safely and efficiently lift any vehicle anywhere. The lift’s modular design includes wheelbases and assisted steering handles to provide greater maneuverability. The MCO MOBILE COLUMNS are battery operated and can be used as a single unit, in pairs or as sets of up to 10 units depending on model.

FEATURES: Built to higher standard of quality Compact design, highly manoeuvrable Premium options & accessories can expand the lift capabilities & productivity Can be used as a single unit, in pairs or sets of up to 10 units. Can acheive maximum height in 85 seconds Wired and wireless options available

OMER MOBILE COLUMN LIFTS MCO14.5-4-58B / MCO14.5-4-58-BW / MCO19B-4-76-B / MCO19B-4-76-BW

Easy to use touch screen console shows important lifting information & battery life | (800) 661-5313 |

Heavy-Duty BendPak HDS-27X With 309” runways, the HDS-27X is the first extendedlength model in BendPak’s super-duty four-post series. As a super-long lift that holds up to 27,000 lbs., this incredibly versatile lift accommodates massive Class 7 semi-trucks. There isn’t much this lift can’t handle. The superlong HDS-27X handles stretch limos, semi-trucks, city buses and other super-duty vehicles so keeping the commercial industry quickly-serviced and up to code it easy and attainable.

FEATURES: 27,000 lb. lifting capacity Extended runways Dual-hub cable sheaves Large base plates Secondary lock system Spring-loaded safety locks

Lifting Capacity:

27,000 lbs. (12,247 kg)


Runway Width:

*Max Capacity / Front Axle: 13,500 lbs. (6,123 kg)

K Length of Runways:

*Max Capacity / Rear Axle: 13,500 lbs. (6,123 kg)


22” (559 mm) 315.5” (8,014 mm)

Width Between Runways: 40” (1,016mm) or 45.25” (1,149mm)

A Min. Runway Height:

9.5” (241 mm)

M Runway Centerline:

B Max. Rise:

60” (1,524 mm)

N Outside Edge of Runways: 89.25” (2,267mm) or 94.5” (2,400mm)


67.25” (1,708mm) or 72.5” (1,842mm)

Max. Lifting Height:

69.5” (1,765 mm)

Wheelbase Rated Capacity: 230” (5,842 mm)

Time to Full Rise:

75 Seconds

75% Capacity:

195” (4,953 mm)

153.5” (3,899 mm)

50% Capacity:

165” (4,191 mm)

D Overall Width: E

Outside Length:

317” (9,468 mm)

25% Capacity:

130” (3,302 mm)


Overall Length:

372.75 (9,468 mm)

Locking Positions:


G Height of Columns: H Width Between Columns:

91.25” (2,318 mm)

Lock Spacing:

Every 4” (100 mm)

133.5” (3,391 mm)


220 VAC / 60Hz / 1Ph


Drive-Thru Clearance:

109” (2,769 mm)




6,944-lbs. (3,149 kg)


326” x 27” x 36” | (800) 661-5313 |

Omer KAR OMER’s unique pantograph heavy-duty OMER’s KAR Lifts are available in ten models and are suitable for lifting the widest range of commercial vehicles. OMER’s KAR Lifts are available in surface, recessed floor or flush-mounted installations. OMER’s KAR Lifts also include a huge variety of accessories making the lifts customizable for unique jobs. Available in Wash Bay, Alignment and Explosion-Proof Area version.

FEATURES: 31,000lb. - 99,000lb. lifting capacity Surface, recessed floor or flush-mounted Available in 10 models Huge amount of accessories available Length: 20ft. - 48ft. The only vertical-rise & sensor-less HD lift

Omer VEGA OMER’s VEGA lifts are parallelogram style lifts that provide quick and safe access while providing the lift capacity of a wide range of heavy-duty commercial vehicles. OMER’s VEGA lifts can be installed as surface-mounted or full flush mount. OMER’s VEGA lifts combine peak performance and safetly through its unique and proven design to optimize worker productivity.

FEATURES: 50,000lb. - 120,000lb. lifting capacity Lift a wide range of HD commercial vehicles Installed surface-mounted or flush-mounted Huge amount of accessories available Length: 26ft. - 50ft. Premium options and accessories available | (800) 661-5313 |

Chicago Pneumatic QRS-20HPD-TM This engineering marvel is quiet, powerful, reliable and made to be operating all day, every day, providing your shop with a consistent supply of compressed air when you need it. With its 20hp motor and 120-gallon receiver tank, the QRS20HPD-TM is set to provide unequaled pressure and consistency unlike any other compressor line on the market. Less maintenance than a piston-based air compressor and equipped with a tank-mounted air dryer to provide moisture-free air flow, the QRS20HP-TM should be a staple of any shop looking to increase production by getting customers in and out quickly and efficiently.

FEATURES: Low sound enclosure 100, 125 and 175 psi Continuous operating capability Space-saving design, <12 sq. ft Load / No Load with intelligent shutdown Spin-on filter and separator

Ravaglioli TD8060T Fastliner Aligner Whether you need a truck alignment machine for a complete multi-axle system or a machine for both selling and doing alignments, the Fastliner 8060 is the solution you are looking for. No more rolling, pushing or raising the vehicle, the 8060 makes it easy with 4 fully functioning Bluetooth measuring heads. Able to setup and measure in as little as two minutes, this accurate alignment machine will save you not only time but headaches as well with its easy process, portability and remote operation. The Fastliner 8060 is RAV’s most innovative, featurepacked truck alignment machine to date.

FEATURES: Welded metal console with molded top and monitor mount Sensor heads charge when docked on side of cabinet 4 Bluetooth measuring sensors 8” Android Tablet Industrial quality computer / 19” monitor / printer / keyboard Truck turntables (pair) / STDA29L | (800) 661-5313 |

Ravaglioli TD8060T Combo The RAV Combo Truck & Car Alignment System goes one step further by adding front sensor heads and premium software for automobiles and light trucks. If you are looking for a true onemachine-does-all system then look no further. Expertly aligns almost anything on wheels! The Fastliner 8060 is the solution you are looking for.

FEATURES: All the features and components of the TD8060T Fastliner, plus: Calibration and Trailer Alignment Packages Fast Clamps (set of 4) for Automotive 2 additional Bluetooth Front Sensor Heads for Automotive Automotive Software and Vehicle Database Charging for the extra car heads on back of cabinet

Heavy-Duty Frame Racks With an array of models to choose from, we are confident that we have just the right frame rack for your shop. From smaller racks, able to fit in tighter places, to large heavy-duty models able to tackle even the largest collision repairs on service vehicles or busses, Babco has the perfect frame rack and tower combination for you. Built with A50 steel for maximum strength, these truck racks come in 40, 50 and 60-foot models and are perfect for large trucks, emergency vehicles and farming equipment.

FEATURES: Available in 40, 50 and 60-foot models 6 - 14 towers depending on model 360 degress pulling radius Automatic entry of distance and diameter Standard with integrated pneumatic wheel lift Rim: 10”-26” / Rim width: 1.5”-22” / Max. Tire/Wheel Weight: 440lbs. | (800) 661-5313 |
