Instruments

Today's boat owners want more information than ever before - and Yamaha Digital Network Gauges deliver it.

Yamaha is proud to offer a comprehensive line-up of Digital Network Gauges, to bring you more convenience, flexibility, and clear information than you ever thought possible. This really is the leading edge of rigging technology, matched up with the supreme level of innovation and reliability you’ve come to expect from Yamaha. Experience it.

An all-new, thin Yamaha CL5 touchscreen is small in size but big on information and ability. Its sophisticated, modern design features intuitive operation and matches the latest boat console trends. *1

Description Replacement Cover Replacement Bezel Part Number 6YM-87278-00-00 6YM-83512-00-00 (x2)

Regular indications*2: • Shift position • Engine speed • Trim position • Engine temperature • Cooling water pressure • Oil pressure • Main battery voltage • Sub-battery voltage • Boat speed • Fuel economy • Fuel consumption • Fuel flow • Engine operating hours • Trip meter • Available fuel volume • Connections for up to 4 tanks • Seawater temperature • Depth • Maintenance interval notice • Trolling speed adjustment (depending on model) Alert indication*2: • Overheat • Low oil pressure • Low voltage • Water in fuel Setting *2 • Trim Assist (On/Off) and Preset • PTT Switch Preset (��uadengine) • Tank Preset • Calibration

• Check engine • Check system • Steering malfunction • Low fuel pressure

Condition indication*2: • Steer Friction (Regular/Heavy) • Lock to Lock (Constant/��ariable) • Speed Control (RPM/GPS) • Autopilot Setting • Joystick and SetPoint Setting • Reset

• Yamaha security system on duty

• Trip ��nformation • Engine under warming up icon • Diagnosis (Trouble codes) • Engine synchronization icon • Autopilot icon and status/ bar • Technician setting • Maintenance Reminder

• Speed Control icon • Single Lever icon • Trim Assist icon • Status message • Maintenance Reminder

*1 These displays are also compatible with mechanical controlled outboards, both come in convenient kits for mechanical and Drive By Wire, please see the display option section *2 Contents of indication may vary by outboard models and/or external accessories applied.

6Y8 Digital Network Gauges are simple, streamlined and sophisticated. The large LCD displays provide easy-to-read information at a glance, allowing you to monitor everything from engine function and fuel management to trim levels, battery voltage, and more. Available as a convenient Rigging Kit. (please see the display option section)

General features: - Each LCD display can show multiple types of information. - Information is shown in 2 different formats for main (large - on top) and sub-information (small - below). - Pre-selectable sub-information selection. - Each LCD display performs a self-function check on start-up. - Backlighting can be dimmed individually or together (when multiple gauges are installed).

6Y8-8350T-20-00 • Engine speed • Trim position • Oil pressure • Cooling water pressure (*2) • Total operating hours • Trip hours • Battery voltage • Engine temperature • Maintenance interval notice • Overheat alert • Low oil pressure alert • Low battery voltage alert • Water in fuel alert • Check Engine alert • Trolling speed adjustment (depends on outboard model) • Diagnosis code

(*1) GPS connection required (NMEA 0813) (*2) Optional sensor required (see page 81)

6Y8-83500-20-00 • Boat speed (*1) • Trip meter • Clock • Battery voltage • Fuel tank level (up to 2 tanks) • Fuel flow • Fuel consumption • Fuel economy • Seawater temperature (*2) • Seawater depth (*2)

Description Part Number DASHBOARD ROUND (2 HOLES) YMM09D010000 GAUGE PLATE RINGS (2 PCS) YMM09PR10000
