Highlights from Aura Light
A selection from our product range
Sustainable & Efficient Lighting
Aura Light is a Swedish lighting company with over 80 years of experience in delivering high-quality and energyefficient lighting solutions. Our products are designed to provide you with the best possible lighting solution, no matter the environment. We combine sleek design with high energy efficiency, and our advanced lighting control systems make it easy to create the perfect illumination for any occasion. With a strong focus on sustainability and innovation, Aura Light offers solutions that not only brighten your spaces but also contribute to a greener future. Discover how our products can enhance both your work environment and energy consumption.
The assortment represents a selection of our product portfolio. More variants can be found at auralight.com.
PROPERTIES
3 different sizes. Separate upward light. On/off, DALI, ActiveAhead, Casambi (special request). IP20.
APPLICATIONS
Offices, corridors, public spaces.
Kvill PE
Suspended luminaire with the latest technology and premium optics. Separate light module for indirect lighting. Available in white and black and in three different sizes. Supplied with an adjustable wire suspension (250–5000 mm).
PROPERTIES
On/Off, DALI, ActiveAhead, Casambi (special request). 3 different sizes. IP20.
APPLICATIONS
Offices, corridors, public areas.
Kvill CE
Ceiling or wall luminaire with the latest technology and premium optics. Kvill CE creates an aura effect on the wall or ceiling. Available in white and black as standard and in three different sizes.
PROPERTIES
Can be semi recessed mounted. On/off, DALI, TW, ActiveAhead, Casambi (special request). IP20.
APPLICATIONS
Offices, corridors, public areas.
Kvill RE
Recessed luminaire with the latest technology and premium optics. Available in white or black as standard, in a 470 mm size. The model can also be installed semi-recessed.
PROPERTIES
On/off, DALI, ActiveAhead-2, Casambi, Pull Dim. Different lengths and optics. Customized system luminaire as special request.
APPLICATIONS
Offices, corridors, schools.
Sevede PE
Linear office lighting in white or black. Two standard lengths. A unique feature is the ability to create a seamless light line in the desired length. Available with four types of optics: opal, microprismatic, lens, and asymmetric lens.
PROPERTIES
Different lengths and optics. On/off, DALI, ActiveAhead-2, Casambi. Customized system luminaire as special request.
APPLICATIONS
Offices, corridors, schools.
Sevede CE
Linear office lighting in white or black. Two standard lengths. Flexible c/c makes installation easy. A unique feature is the ability to create a seamless light line in the desired length. Three types of optics: opal, lens, or asymmetric lens.
PROPERTIES
On/off, DALI, ActiveAhead-2, Casambi. Different lengths and optics. Customized system luminaire as special request.
APPLICATIONS
Offices, corridors, schools.
Sevede RE
Linear office lighting in white or black. Two standard lengths. Flexible c/c makes installation easy. A unique feature is the ability to create a seamless light line in the desired length. Three types of optics: opal, lens, or asymmetric lens.
PROPERTIES
Line prismatic optics. On/off, DALI, ActiveAhead-2. Customized lengths as special request.
APPLICATIONS
Offices, schools.
Sevede WA
Linear whiteboard lighting. Two standard lengths for single installations. Can be adapted for larger boards by connecting multiple units. Flexible c/c spacing for brackets. Features linear prismatic optics that direct the light toward the board.
Stairwell at Nacka Strand. Opuz creates a beautiful aura effect on the wall. It is also suitable for offices or corridors.
PROPERTIES
DALI. Ø400 & Ø500. Adjustable power 12-39W. IP20, IK08.
APPLICATIONS
Offices, schools, public areas.
Gloster
Globe luminaire with an elegant and timeless design. Its white finish and minimalist silhouette make it a versatile choice that suits various interior styles. This suspended luminaire is ideal for hanging either alone or in a group.
PROPERTIES
On/off, DALI, Casambi. UGR ≤16. IP20.
APPLICATIONS
Offices, schools, corridors, retail.
Cellini Panel
Recessed luminaire with center grid and lens optics that provide glare-free lighting. Excellent color rendering. Center grid available in black, gray, or white. The central light module and microprismatic panel can be controlled individually.
Cellini
Cellini Panel
Cellini Panel
Cellini Panel
Cellini Panel
Cellini Panel
Cellini Panel RE 595x595 35W 3500 930 White
Cellini Panel RE 595x595 35W 3500 940 White
Cellini Panel RE 595x595 35W 3500 930 Black 35
Cellini Panel RE 595x595 35W 3500 940 Black 35 3500
Cellini Panel RE 595x595 35W 3500 930 Grey
Cellini Panel RE 595x595 35W 3500 940 Grey 35 3500
30359303520-1 30359303559-1
30359403520-1 30359403559-1
30349303520-1 30349303559-1
30349403559-1
PROPERTIES
On/off, DALI, ActiveAhead, Casambi. Integrated sensor. Design Patterns. A-, E- and Ds-ceiling. UGR 19. IP20/44, CLO, 3000/4000K, TW, CRI 80, CRI 90.
APPLICATIONS
Offices, schools, hospitals, corridors, public areas.
Aura Lunaria
High-quality LED panel with various models and dimensions. A wide selection of accessories for customized design and functionality. Flexible with different lumen packages, color rendering index, and control options.
PROPERTIES
Different sizes On/off, DALI. Efficacy up to 128 lm/W. SDCM 3. UGR 19.
APPLICATIONS
Offices, schools, hospital.
Lanternin
Low-profile LED panel, available in various sizes. A great lighting solution that meets the requirements of offices, schools, and hospital environments. Delivered with an external driver for on/off or DALI control. Good glare control, UGR <19.
PROPERTIES
On/off, DALI, ActiveAhead, Casambi (on request).
Dark-Light optics.
APPLICATIONS
Offices, corridors, public areas.
Brahe Panel
LED panel equipped with two 300x60 mm downlights. Latest LED technology for maximum efficiency and optimal light distribution. High-quality lens and reflector technology minimizes glare and provides precise and pleasant lighting.
PROPERTIES
On/off, DALI, ActiveAhead, Casambi (on request). Dark-Light optics. Flexible installation. ENEC.
APPLICATIONS
Offices, corridors, public areas.
Brahe
Minimalist and energy-efficient downlight. Modern LED technology and advanced lens and reflector technology provide well-controlled, glare-free light. Suitable for recessed installation in ceiling tiles, cluster mounting, or in fixed ceilings.
PROPERTIES
On/off, DALI. 3 CCT technology. Up to 120 lm/W.
APPLICATIONS
Offices, public areas, corridors, hospitals, schools.
Safie MP
Recessed downlight available in three different sizes. It has a wide beam angle for general lighting in environments such as hotels, offices, and hospitals. Designed for renovation projects where compact fluorescent lamps are being replaced.
PROPERTIES
3 different sizes. Up to 150 lm/W.
On/off, DALI. UGR 19.
APPLICATIONS
Offices, public areas, corridors, hospitals, schools, retail.
Safie Mirror
Downlight in three sizes with innovative reflector and lens optics that reduce the luminaire height and minimize glare. The larger sizes can be surface-mounted with an accessory, the smallest size is only intended for recessed installation.
Sankt Anna School in Söderköping chose Kvill from Aura Light for their newly renovated dining hall.
PROPERTIES
On/off, DALI. Interchangeable reflector. Rotatable. 115 lm/W
APPLICATIONS
Offices, corridors, hospitals, schools, retail, public areas.
Safie Adjustable
Recessed downlight with a wide beam angle. Provides excellent general lighting for all types of applications. It has a 355° horizontal and 30° vertical rotation angle. Designed for renovation and replacement of metal halide downlights.
PROPERTIES
On/off, DALI, Phase-Cut.
3 different sizes. IP44.
APPLICATIONS
Retail, hotels, receptions.
Samo
Downlight with modern design and high performance. Its design and white reflector provide excellent glare-free light. Different sizes, light levels, and beam angles, allowing for everything from good general lighting to accent lighting.
PROPERTIES
On/off, DALI. 3-Phase in-track spot. Compatible to Ivela, Stucci and Global-track system. Can be tilted 90° and rotated 355°.
APPLICATIONS
Offices, retail, public areas.
Ribes
Spotlight with a cylindrical design for mounting on a 3-phase track. The adapter features an integrated LED driver equipped with a safety lock that ensures stability and allows the spotlight to tilt 355° and rotate 90°.
Common to the products is that they are available in a number of different variants and can be customized to meet specific needs and preferences. In addition, they can also be equipped with Smart Lighting Control for enhanced convenience and efficiency. Most of the luminaires are developed by our team in Vimmerby, these luminaires are crafted with carefully selected components and materials that prioritize environmental sustainability. This ensures that they are not only energy-efficient but also resource-friendly, boasting a long service life.
∙ High-end luminaires with outstanding technical characteristics
∙ Extra superior optics that provide very good glare control and an even light
∙ Sustainable luminaires with a low CO 2 climate footprint
∙ Flexible luminaires with the possibility of customization
∙ High lumen per watt with the possibility of smart control for energy optimization
PROPERTIES
On/off, DALI, ActiveAhead. Emergency light. Two different lengths, 1200 & 1500. Very good light quality, CRI 90. Options for smart control and sensor solutions.
APPLICATIONS Offices.
Ceos EVO
Premium solution for office lighting. The frame is made of recycled aluminum. White or black as standard, with two different lengths. Adjustable ratio between indirect and direct light, with some versions being individually adjustable.
PROPERTIES
DALI, pull-dim. Flexible C/C. CRI 80 for high quality of light.
APPLICATIONS
Offices.
Ceos ECO
Sleek office luminaire with a frame made of recycled aluminum. 1200 mm length as standard and white finish. With CRI 80 for high light quality and microprism optics for good glare control, it is an excellent choice for office environments.
PROPERTIES
On/off, DALI, emergency light (on request). Adjustable sensor. Adjustable CCT and lumen output. IP54. IK08. ENEC.
APPLICATIONS
Stairwells, circulation areas, public areas.
Collina
Ceiling luminaire using high-lumen SMD LEDs. Fire-rated material for heat and corrosion resistance. Removable base and diffuser for easy maintenance and installation. Cable entry from the side or the back.
PROPERTIES
On/off, motion and daylight sensor. Emergency light 3h. Adjustable lumen output (dip-switch). IK10. IP65.
APPLICATIONS
Stairwells, circulation areas.
Annero
Wall- or ceiling-mounted luminaire available in three versions – on/off, motion and daylight sensor, or motion and daylight sensor with emergency function and 3-hour battery backup. All versions come with three-step adjustable light output.
PROPERTIES
On/off, DALI, DALI BT (bluetooth mesh). Smart features. Emergency sensor. Built in sensor. Different sizes. IP40 ceiling, IP54 wall.
APPLICATIONS
Stairwell, circulation areas.
Opuz
Ceiling- or wallmounted luminaire for stairwells or common areas. Available with a built-in sensor that enhances safety for residents and saves energy. Emergency lighting versions are available upon request.
PROPERTIES
Adjustable lumen output (dip-switch).
Electrophoretic Coating. IK10. IP65.
APPLICATIONS
Outdoor.
Eris
Outdoor luminaire with adjustable light output. A high-quality finish that protects against corrosion makes it suitable for installations exposed to harsh weather conditions. Ideal for areas with a risk of physical impact or vandalism.
PROPERTIES
Qi wireless charger. Dimmable 5-100%.
Adjustable colour temperature USB for wire charging.
APPLICATIONS
Offices
Combus
Desk lamp with touch display and integrated USB port. Wireless charging for smartphones, compatible with all Qi-enabled devices. Dimmable from 5 to 100 percent. The color temperature can be continuously adjusted from 2700 K to 6400 K.
PROPERTIES
On/off with sensor (on time is preset to one minute). IP44, sensor version IP20.
APPLICATIONS
Bathrooms, laundry rooms, utility rooms.
Melba
Wall-mounted luminaire designed for placement above sinks in bathrooms or similar spaces such as laundry rooms or utility areas. The luminaire can be equipped with a presence sensor. The sensor’s activation time is preset to one minute.
PROPERTIES
DALI. 3 CCT. 120lm/W.
APPLICATIONS
Bathrooms, laundry rooms, utility rooms.
Melia
Mirror luminaire for placement above sinks in bathrooms or similar spaces such as laundry rooms or utility rooms.
Housing made of white-painted aluminium with a transparent cover. Clips and quick connectors ensure easy installation.
PROPERTIES
On/off.
APPLICATIONS
Kitchens, laundry rooms or similar spaces.
Avena
IP21-rated luminaire for installation under wall cabinets in kitchens or similar spaces. Housing made of white-painted sheet steel with a frosted diffuser. Cable entry from the top and two knock-outs on the back for through-wiring.
Two channels make it possible to control Cellini’s centrally placed light module and the microprismatic panel individually.
Energy-saving
Easy to use & install
High comfort
Responsive
Flexible
Bluetooth Mesh
Light when and where it’s needed
Smart Lighting Control – optimal, convenient, and energy-efficient lighting
We have created a range of intelligent luminaires and offer control via ActiveAhead from Helvar or Casambi. Smart control is based on wireless communication through Bluetooth mesh, where each luminaire is equipped with its own sensor or node that communicates with surrounding luminaires.
Black suspended Kvill PE with lighting control at Fastoffice in Gävle. A state-of-the-art office hotel with spacious shared areas.
various smart lighting control solutions.
Kvill, Sevede, Sarek, Helags, Ceos EVO, and Aura Lunaria are all available with
Wireless sensors – Casambi & ActiveAhead
1. Casambi PIR Large Range Sensor
PIR Large Range Sensor with a large detection range of up to Ø40m at a mounting height of up to 15m.
Ideal for warehouses, logistics and production halls.
Power-free zero-crossing circuit for switching and Dali dimming output for max. 10 ballasts. Separate light sensor for optimised light measurement from a great mounting height.
2. Casambi PIR Large Room Sensor
PIR Large Room Sensor with a large detection area of up to Ø15m at a mounting height of up to 3m. Particularly suitable for large, open office areas, entrance areas, meeting and conference rooms. Power-free zero-crossing circuit for switching and Dali dimming output for max. 10 ballasts.
3. Casambi PIR Universal Sensor
PIR universal sensor with a detection range of up to Ø7m at a mounting height of up to 3m. Unobtrusive recessed ceiling mounting due to flat lens technology. Optimal for small office and storage rooms, corridors and entrance areas. Power-free zero-crossing switching for switching and Dali dimming output for max. 10 ballasts.
4. ActiveAhead Node advanced 5609
Connects DALI luminaires and system sensors to the Helvar ActiveAhead wireless lighting control solution.
5. ActiveAhead Node Sense Circular Holder 5693
Mounting accessory to mount the 5634 ActiveAhead Node Sense multisensor to a recessed ceiling.
6. ActiveAhead Sense Circular Holder 5692
Mounting accessory to mount the 5630 ActiveAhead Sense multisensor to a recessed ceiling.
7. ActiveAhead Node Multisensor
High Bay White 5641
High bay area sensor with radio for the wireless Helvar ActiveAhead solution. Can be used to connect DALI luminaires and system sensors to the solution.
8. ActiveAhead Node Multisensor
High Bay Black 5641B
High bay area sensor with radio for the wireless Helvar ActiveAhead solution. Can be used to connect DALI luminaires and system sensors to the solution.
9. ActiveAhead Node Multisensor 5640 White
Area sensor with radio for the wireless Helvar ActiveAhead solution. Can be used to connect DALI luminaires and system sensors to the solution.
10. ActiveTune Personal Lighting
Tune the light settings above desks with an easy-to-use mobile app. Selected lights and preferences can be saved for quick access.
11. Wireless Control Panel
ActiveAhead 185W
Wireless, battery-less, Bluetooth®
Low Energy control panels with four configurable button functions, for use directly with Helvar ActiveAhead and RoomSet solutions.
PROPERTIES
On/off, DALI, sensor versions, ActiveAhead, Koolmesh, Casambi. New reflector technology & LED module. High lumen output, 165 lm/W.
APPLICATIONS
Industries, warehouses, corridors, stairwells.
Kleva
Environmentally friendly and energy-efficient IP44-rated luminaire with high performance and good light quality. Suitable for common areas such as corridors. Made of 75% recycled aluminum. Climate-neutral PC plastic diffuser.
PROPERTIES
On/off, DALI, sensor versions. High lumen output, 161 lm/W. IP44 ceiling, IP40 wall. Swedish-made LED module.
APPLICATIONS
Interiors, industries, production.
Z44
Energy-efficient IP44 luminaire for general lighting in industrial environments. High luminous efficacy of up to 161 lm/W.
Available with various sensor options. A cost-effective universal luminaire that provides even and shadow-free illumination.
PROPERTIES
On/off, DALI. Ball-proof DIN 18032-3.
5 000-18 000 lm. Up to 174 lm/W. IP23, IP54. D-marking. ENEC.
APPLICATIONS
Industries, warehouses, retail, public areas.
Helags
White-painted industrial luminaire available with three different light distributions: wide, medium, and narrow.
Removable light unit for easy installation. Through-wiring and terminal blocks at both ends. Length 1200 or 1500 mm.
PROPERTIES
On/off, DALI, ActiveAhead, Casambi.
5530-18310 lm. Up to 182 lm/W. Emergency light. Ceiling, wire.
IP23. ENEC.
APPLICATIONS
Industries, warehouses.
Sarek EVO
Efficient IP23-rated luminaire in two different lengths. Ceiling-mounted or suspended by wire. Removable optical rail allows easy access for maintenance. The option to integrate wireless control systems facilitates the reuse of existing wiring.
PROPERTIES
On/off, DALI. Up to 19 230 lm.
Ball-proof DIN 18032-3. Sturdy
ball-proof square lamella.
Anti-corrosive housing.
Long-lasting durability.
APPLICATIONS
Sports halls.
Sarek EVO Sport
Sports luminaire with high luminous efficacy and light output. The ball-proof cross-louvre glare shield combined with a semi-diffuse MIRO 5 reflector and microprismatic acrylic diffuser provides superior visual comfort.
absorb a lot of light.
Dark surfaces
With Sarek, Bosgård School achieves 400 lux, which is twice as much as before.
PROPERTIES
On/off, DALI, ActiveAhead.
Cost-effective. Easy to install.
High efficiency up to 175 lm/W.
Emergency light.
APPLICATIONS
Industries, warehouses, retail, public areas.
Sarek ECO
Efficient IP23-rated luminaire available in three different lengths. Comes with two standard light distribution options: wide or medium. Openable installation boxes at each end and 5- or 7-pole through-wiring make installation easy.
PROPERTIES
On/off, DALI. Luminous flux up to 69 000 lm. Low UGR. IP66. ENEC. APPLICATIONS
Industries, warehouses, sports arenas.
Aspa
Versatile and modular IP66 luminaire with high luminous flux. With fixed brackets or suspension chain, it is ball-proof for sports activities. Aspa controls glare with a low UGR value and provides uniform lighting for a well-lit environment.
Certos is excellent for outdoor environments where high-quality lighting is required. Kongamek has it installed under a roof.
PROPERTIES
On/off, DALI. High efficacy 170 lm/W. D-marking. CRI 80. SDCM 3. IK08. ENEC.
APPLICATIONS
Industries, warehouses.
Spartan
Efficient and lightweight IP65 luminaire with a luminous flux of up to 34,000 lumens. Adjustable optics and various lumen output options via DIP switch for easy customization. Chain suspension only, no wire suspension.
PROPERTIES
On/off, DALI. Emergency function 3h. Different optics. SDCM 3. IK 10+ (IK08 for glass panel). ENEC.
APPLICATIONS
Industries, warehouses, sports arenas.
Certos
Efficient IP65 luminaire with a luminous flux of up to 34,560 lumens (+/- 10%). Available with different optics and emergency versions for a variety of applications. SDCM3, IK10+ for PC diffuser and lens optics, and IK08 for glass cover.
PROPERTIES
On/off, DALI (on request).
6 different optics. 3 SDCM. CRI 80. IP66. Safety glass IK10.
APPLICATIONS
Outdoor, parking areas, sports arenas.
Morisia Flood
Universal floodlight for all types of area lighting. Wide range of wattages and light distributions. Pole-mounted solutions available up to 18 meters.
Morisia Flood illuminates both the façade and the large lumber yard at the Byggmax hardware store in Hultsfred.
PROPERTIES
On/off. Aluminum die-cast housing. RAL 7022. Sea water protected, DIN EN ISO 9227. Including 10/15m connection cord.
APPLICATIONS
Walkways, driveways, forecourts
Berzelia
Street luminaire for lighting traffic areas according to EN13201. Suitable for post-top and side-mounted installation. UV- and heat-resistant lens optic 2, COL1030, as standard. Other types of optics available on request.
Berzelia
PROPERTIES
Aluminum die-cast housing. RAL 7022. Sea water protected, DIN EN ISO 9227. Including 10/15m connection cord.
APPLICATIONS
Driveways, parking areas, walkways.
Berzelia Street
Street lighting luminaire designed for illuminating traffic areas in accordance with EN13201. For post-top and side-mounted installation. Comes standard with UV- and heat-resistant lens optic 2, COL1030. Other optic types available upon request.
PROPERTIES
On/off. Energy-efficient up to 145 lm/W. IP69K. IK10. ENEC. D-marking.
APPLICATIONS
Industries, retail.
PipeLED
Tube-shaped luminaire designed to meet the demands of the process industry. It withstands tough conditions and can be cleaned with a high-pressure washer. The end caps feature a vent valve that automatically prevents condensation.
PROPERTIES
On/off, DALI. Series mounting.
Energy-efficient, up to 142 lm/W. IP66, IK08. ENEC.
APPLICATIONS
Industries, retail.
PipeLED-C
Tube-shaped luminaire for tough industrial environments. Withstands high-pressure cleaning and features vented end caps that that automatically prevent condensation.
RM Snickerier has installed the IP66-rated Alekza luminaire in its facility in Vimmerby
PROPERTIES
On/off, DALI. Available in 2 lengths.
Frosted diffuser. IP66. IK08 (PC). IK03 (PMMA). D-marking.
APPLICATIONS
Industries, warehouses, parking areas.
Alekza
Dust- and moisture-proof IP66 luminaire for demanding environments. Versions with PMMA diffuser and glass fiberreinforced polyester housing are available for areas requiring strong chemical resistance, such as animal housing.
PROPERTIES
On/off. Available in 2 lengths. Energy-efficient, 150 lm/W. Through-wiring. IP65. IK08.
APPLICATIONS Industries.
Glomma IP65
Functional IP65 luminaire made of impact-resistant polycarbonate, IK08. The opal diffuser provides soft, wide-beam, and pleasant light. Easy installation with stainless steel ceiling brackets.
PROPERTIES
On/off, DALI. Available in 2 lengths.
Energy-efficient 140 lm/W. IP66. IK10.
APPLICATIONS
Industries, warehouses, parking garages.
Tilia
Robust IP66-rated luminaire for industrial settings, warehouses, and parking garages. Aluminum housing with end caps and cover made of PC. Continuous wiring and cable entry at each end with two included cable glands.
Aura Light develops and sells smart lighting as is energyefficient, economical and environmentally friendly, with long lifetime and high quality. We call it Brighter Lighting. Our sustainable lighting solutions make it possible for our professional customers to reduce both cost, consumption and environmental impact.
Aura Light International AB Röntgenvägen 3C
SE-171 54 Solna
Phone: +46 (0)8 564 881 40
Order phone: +46 (0)20 32 30 30
Order fax: +46 (0)8 564 883 45
E-mail: order@auralight.se www.auralight.com
