LET THERE BE LIGHT (AND A BIT OF CONTROL) Continuing from the front cover, flex7 explains the benefits of its new range of plug-in switches.
ortunately, John Henry Holmes soon provided the perfect addition to Edison’s light bulb by inventing the ‘quick-break’ switch in 1884. His design ensured the contacts opened or closed very quickly, regardless of the force exerted by the operator on the actuator, which significantly reduced the amount of arcing inherent in previous incarnations, and prolonged the working life of the switch. Thus, the humble light switch was born, and ever since we’ve been able to turn the bedroom light off. Aesthetically, the light switch has evolved since the advent of the quickbreak switch, but the principles behind its operation have remained fundamentally the same. If the mechanics of the light switch haven’t changed much per se, the methods and materials employed when wiring to it certainly have. If you want to comply with current wiring regs, then there’s a good chance that today’s switch drop will require not only earthed mechanical protection, but RCD protection as well, depending on the particular characteristics of the installation. Section 522.6 of BS 7671 details these requirements in full and compliance will almost certainly result in the need for additional materials, labour, and the costs associated with purchasing and installing them. If you’d rather avoid installing earthed metallic and/or RCD protection to literally every switch drop, yet still comply with BS 7671, the aforementioned Section 522.6 provides a means of doing so in the form of regulation 522.6.204, indent (v): “For the purposes of Regulation 522.6.201 (ii), Regulation 522.6.202 (ii) and Regulation 522.6.203 (ii), a cable shall... (v) form part of a SELV or PELV circuit meeting the requirement of Regulation 414.4.”
Popular misconceptions You may think that installing a PELV control system is a costly and complicated exercise, and that sticking with the more familiar 230V option is easier, but nothing could be further from the truth. The flex7 system incorporates PELV control as standard, meaning that
any wiring to a connected control device, whether switch or sensor, requires neither mechanical nor RCD protection, regardless of cable location. Furthermore, because the link from controller to device is made via factory prepared leads complete with RJ connectivity, there’s no onsite cutting, stripping and terminating required; everything simply plugs together. In short, opting to go down the PELV route can make for a quick, easy, error-free install with the added bonus of reducing materials and labour.
“That familiar old light switch that we instinctively fumble for as we enter or leave the room will remain a familiar fixture in our lives for a good while yet.”
Plug-in technology Since their inception in 2003, all flex7 sensor heads have incorporated RJ connectivity and operated at PELV, a feature which has been well received by our customers. However, when it comes to a switch lead, although one end plugs into the controller, the third-party switch at the other end is invariably a standard catalogue product from one of the mainstream accessory manufacturers, and as such has to be connected using the time honoured method of screwed terminals. Clearly, it still operates at PELV (5V in this instance) courtesy of the controller, but is no quicker to physically connect up than any common or garden switch. Last year we launched our own flex7 scene set plate, and because we think plug-in control is a better option than hard-wired, we built RJ connectivity into it as standard. Feedback from installers has been extremely positive, and one comment has rung out loud and clear: “You should do switches like this!” We’ve listened and have developed a range of momentary switches that operate at PELV, plug-in at the control pack and, uniquely, plug-in at the switch as well. In doing so, they have probably brought about one of the biggest changes the light switch has seen in more than a hundred years.
Why make the switch? flex7 momentary switches come in a black or white finish, and are designed to clip directly into any manufacturer’s 50x50 Euromod decorative fascia, ensuring seamless integration with the specified accessories – which should keep the architects happy. Whether using a one, two, three or four-gang variant, a standard single back box with 60.3mm
centre is all that’s required, so no need to choose between single or double at first fix stage; one size fits all. Because the lead is factory prepared with the RJ plug, connecting the switch literally takes a second, as opposed to the minute it probably takes on average to terminate a conventional 230V, one-gang, one-way; stripping the sheath, baring the conductors, sleeving the earth, connecting via screwed terminals. Add this to the considerable saving with respect to labour as a result of opting for a PELV system, and the opportunity to reduce installation time to a minimum has never been so attainable. The ability to mix and match module colour with decorative fascias from most accessory manufacturers means that the intended ’look’ need not be compromised, and, in the spirit of Part M2, Section 4 of The Building Regulations, also makes it possible to achieve a colour contrast between switch, fascia and wall finish to aid partially sighted users if required.
Simply plug-in a switch drop lead to provide PELV switching in seconds
Not the end yet Despite a flurry of recent articles in the trade press predicting its imminent demise due to the rise of smart lighting and IoT, that familiar old light switch that we instinctively fumble for as we enter or leave the room will remain a familiar fixture in our lives for a good while yet. We’d be as bold as to say that we can guarantee tens of thousands will be installed in building projects up and down the UK in the next 12 months alone. If each of those switches were a flex7 plug-in switch, then overall time-savings could be phenomenal. Flex7, flex7.co.uk
