PORTFOLIO OF WORKS ARTHUR LEHLOENYA (Professional Architect (PrArch37943290) BSc (Arch) (UP), B(Hons) Arch (UP), M(Prof) Arch (cum laude) (UP)

HOUSING AND URBAN ENVIRONMENTS

HERITAGE AND CULTURAL LANDSCAPES CITY PARK EXPERIMENTAL HOUSE HOUSE ON STRADELLA HOUSE ON SARBONNE

MASTERS’ THESIS

ENVIRONMENTAL POTENTIAL

I completed my Master in Architecture with distinction at the University of Pretoria in 2015 with a dissertation focusing on the contestation of the most prestigious and honoured building in Pretoria, the Union Buildings, and challenging social and past political notions and intercepting with a new programme that embraces collectivism. Realising the need for a broader knowledge of architecture and all its complexities related to heritage, I am pursuing a second Masters degree in Conservation in the Built Env for 2020 . I joined SAOTA in 2016 and was tasked as part of the production team, with international projects mostly based in the US and abroad. I have held a lecturing position at Vega School of Branding in Cape Town for the undergrad programme, and I am currently a tutor at the University of Cape Town’s Architecture School.

EDUCATION

EMPLOYMENT HISTORY

2021Master of Philosophy [MPhil(Conservation in the Built Env)] University of Cape Town, South Africa currently enrolled

2020-02-PRESENT Tutor at UCT Architecture Dpmnt (1st yrs) (Cape Town, SA)

2015Masters of Architecture [MProf(Arch)] University of Pretoria, South Africa cum laude

2018-08-2019-12 Lecturer at Vega (1st & 2nd yrs) (Cape Town, SA)

2014Honours Degree [BHons (Arch)] University of Pretoria, South Africa 1 distinction (theory component)

2018-01-2018-10 Candidate Architect at DHK architects (Cape Town, SA) 2016-03-2017-12 Candidate Architect at SAOTA (Cape Town, South Africa)

2012BachelorsDegree [BSc (Arch)] University of Pretoria, South Africa 1 distinction (environmental studies)

2014 Intern at DNT architects (Maseru, Lesotho)

COMPUTER LITERACY Autodesk Revit (Advanced Training Certified), Trimble Sketchup, Trimble LayOut, Autodesk AutoCAD (Intermediate), Adobe Suite (Photoshop, InDesign), V-ray for Sketchup, Lumion, MS Word

2013 Intern architect at Look Architecture and Design (Johannesburg, SA)

2009InternationalBaccalaureate[IB] Machabeng College Maseru, Lesotho

2018-11-PRESENT Professional Architect at SAOTA (Cape Town, SA)

Proof that I do good videos

Hospitality and Retail -PuntaSabana, Costa Rica -Initial Design Concept -TH_Resort, Thailand -Design Concept

Residential -Clifton Terraces, Cape Town, South Africa, Residential Development -Technical Documentation -BlueJay, Los Angeles, United States, Private Residence -Initial Design Concept to Final Design Development -810S, Los Angeles, United States, Private Residence -Initial Design Concept to Final Design Development -MalibuPCH, Los Angeles, United States, Private Residence -Initial Design Concept to Final Design Concept -Bellgave, Los Angeles, United States, Private Residence -Initial Design Concept to Initial Design Development -Stradella1055, Los Angeles, United States, Private Residence -Initial Design Concept to Construction -Vance, Los Angeles, United States, Private Residence -Final Design Development to Construction -Villa, Punta Cana, Dominican Republic, Private Residence -Initial Design Concept

us_lax_bjw us_lax_810-S us_lax_malibu us_lax_bellgave au_syd_coolong masterâ€™s thesis us_lax_1055-S

Proof that I exist Facebook Instagram LinkedIn Gmail YouTube Issuu Masters thesis Hand Sketches

PROJECT LIST (UNDER SAOTA)

v v

The disparities of South Africa force us as architects to not only consider areas highly developed and self sufficient but to also look into informal settlements to trying to create formalised spaces in the aim of bettering lives.

016

OPEN AIR THEATRE IN THE TOWNSHIP-PTA

v v

Government Printing Works, Pretoria, South Africa

032

GVMNT PRINTING WORKSHERITAGE

The house has a singular unifying butterfly roof that soars above the second floor level. The residence offers an indoor outdoor experience, and allows both to blur into each other. The setting is well suited for a vast pool area to enjoy views to the city

ARCHITECTURAL INTENT The intention of the project is based on shifting peopleâ€™s perceptions. The architecture plays with the notion of heights, dark and lights, scale and shifted perceptions, and openness and closure. The user will have to confront such spaces, to be able to test himself regarding the history.

Programme A film academy for the production of pasts. A virtual reconstruction of history and memory. The history of South Africa is re-enacted through dead presidents, leaders, politicians. This could even play out to form dialogues between old street names and new street names. Shifting perceptions is an experimental project, based on overlaying. By blurring boundaries, we metaphorically shift perceptions, to allow for users to understand and accept both black history and European history. This is a place that reconstructs history, reconstructs histories of architecture and histories of the culture of South Africa. The connection between this and church square is heightened by the use of holograms, activating street corners where spaces are un-programmed, and creating virtual routes and tours leading people to and fro church square. The un programmed spaces allow for vendors and hawkers to take charge of this, and use to their advantage to draw in tourists for his small scale enterprise.

GROUND FLOOR

FIRST FLOOR

Vision Relationships between memory and history in the public realm, insertion of an idea in the streetscape generates a conversation or influence a point of view. A visual narrative, as well as sensorial spaces. To blur the boundaries between realms, to define spaces without physical boundaries but rather shifting from space to space without noticing it has different accommodation. Creating soft thresholds for the inclusion of everyone.

The Old Government Printing works subjugated black history, and denied any kind of story denoting to the black manâ€™s history. With this suppression of knowledge, the new function or programme gives leeway for the same apartheid regime to give answers as to who they are and what they did to be able to do right what was once wrong. To be able to listen to what everyone has to say

SECOND FLOOR

ROOF PLAN

v v
