UG Architecture Portfolio

Portfolio ANTONY SIMON

Contents o1 o2 o3 o4 o5 o6

The Thermal Garden The Substrate Studio The Weave Retentive Thresholds Soft Armature Physical Prototyping

o1 The Thermal Garden CIBALI AYACAPI HAMAM, ISTANBUL, TURKEY Professor Igor Peraza Designed in collaboration with Negar Shafiee Fatema Al Osta The Thermal Garden rehabilitates the dilapidated Cibali Ayakapı Hammam as an agricultural research and community center, reviving its historical significance while at the same time introducing a contemporary architectural narrative. Located in the heart of Istanbul’s Fatih district along the southern bank of the Golden Horn, the project juxtaposes preservation and innovation. The new intervention mirrors the pure geometry and formal clarity of the original hammam while intentionally contrasting it in materiality and spatial experience. While the historic structure is introverted, heavy, and stereotomic; defined by stone, brick, and marble, the new addition is open, light, and tensile, built with sustainable materials like KALWALL and recycled steel. Inspired by the traditional art of Ebru (Turkish paper marbling), the design portrays the layering of culture and vibrant colors, bringing together craft and architecture in a space that welcomes light, color, and community engagement.

SITE PLAN

GENERATIVE DIAGRAM

Footprint for the new proposal

Subtraction to create a plaza

Extrusion and rotation of massing

Canopy to provide shading while also forming a datum with the top of the existing hammam

Voids in the extruded volumes to bring in light mimicking the dome

Final Proposal

PLANS

The project transitions from public to private as we move up. The ground the first floor hosts working studios and a small café, while the u

d floor accommodates for exhibition areas and public gathering spaces, uppermost level is dedicated exclusively to agricultural research

SECTION AA

SECTION BB

Looking out into the plaza

Working studio

The project explores the contrast between the original hammam and the contemporary intervention. While the former is characterized by stereotomic, heavy massing, the latter introduces a tensile, lightweight structure

adjacent to CAAD, the project reimagines the main o2 plaza through a subterranean design-build hub. inspiration from the existing Starbucks The Substrate Studio Drawing skylight and courtyard, the project revolves around the Embedded within the gardens of the AUS Plaza

THE PLAZA, AMERICAN UNIVERSITY OF SHARJAH, UAE Professor Roberto Castillo

relationship between enclosed and open-to-air underground spaces and their discreet subterranean connections. The double-height fabrication spaces are positioned beneath angular skylights, framed by overlooking studios and supported by peripheral services, storage, and technician offices. Directly connected to CAAD through the existing wood labs, the extension ensures seamless continuity of workflow from design to assembly. A sunken courtyard and communal lounge link the new structure to the broader campus fabric. The project aims to creates a contemplative and productive environment to further develop CAAD’s design build program

SITE PLAN

SECTION BB

PLAN G-2

Strategically integrated air vents distributed throughout the structure to promote passive ventilation, enhancing natural airflow and minimizing dependence on mechanical cooling systems

A multi-layered skylight system comprising of tensile fabric, a space frame, and a double-glazed curtain wall enveloped in a Mashrabiya-inspired screen, to mitigate solar heat gain while allowing for natural daylight to come through

The roofing system incorporates extensive green cover reducing heat gain and lowering the temperature within the structure

SUSTAINABILITY

SECTION DD The Design-Build Hub is directly accessible from CAAD Labs, facilitating seamless workflow between design, fabrication, and assembly

EXTERIOR RENDERS View from the Main Entrance of CAAD

Looking towards the design build extension from the adjacent sunken courtyard. The courtyard serves as a shaded transitional space, offering direct access to the student center quadrangle thus enhancing campus walkability

Looking down into the fabrication space

SECTIONAL PERSPECTIVE

Looking up into the studios

The hub features an expansive fabrication space with new laboratories, while the Design and Build studios are positioned to overlook and engage with the making process below

Located along the Dubai Creek, adjacent to the Jameel Arts Centre, ‘The Weave’ is envisioned as a museum and cultural art center to honor the life and work of Emirati artist Hassan Sharif. The design adopts a radial, pinwheel-like geometry to capitalize on the panoramic views of the Al Jaddaf waterfront, while organizing programmatic zones around a dynamic central core.

Inspired by Sharif’s intricate weaving techniques, the project features a modular precast concrete roof system that performs as a filtration device controlling the amount of sunlight within the gallery spaces.

Sustainability is central to the project’s material palette, with precast concrete, reclaimed wood, and recycled steel used to reduce environmental impact and enhance building performance.

o3 The Weave

AL JADDAF WATERFRONT, DUBAI, UAE Professor George Newlands Designed in collaboration with Fatema Al Osta

SITE PLAN

STRUCTURAL AXON C D C

1.75m 3.5m 1.75m

A B 2.5m

A 3m 2.5m

ROOF MODULES

PLANS

WALL SECTION

SECTION EE

Lobby social seating

EXPLODED AXONOMETRIC

ELEVATION 1 - ENTRY

The project comprises of six galleries (three naturally lit and three designed for light-sensitive work), alongside an archive library, a projection room, and dedicated spaces for exhibition preparation and the storage of Mr. Sharif’s paintings and sculptures. The project aspires to honor and celebrate the enduring legacy of Mr. Sharif’s artistic contributions

RENDERS

Natural light exhibition area Archival library

o4 Retentive Thresholds AL QASBA CANAL, SHARJAH, UAE Professor Charles Jones

Situated along the banks of the Al Qasba Canal, in the Al Qasba district in Sharjah, this architectural landscape intervention addresses critical urban and public realm challenges. The project is designed to mitigate and control flooding caused due to storm water from the surrounding catchment zone. Beyond flood management, the proposal aims to revitalize the edge of the canal by enhancing pedestrian connectivity and reactivating public space through the ‘naked street’ concept. The design promotes a shared environment for both vehicles and pedestrians.

Existing waterfront restaurants have been integrated into the scheme with indoor dining, outdoor dining as well as dining areas extending along the canal bank. The project attempts to reinforce the canal as a social and ecological spine of the suburb

SITE PLAN 650m3

Max

444m3

Other Subsurface Storage

Cellular Storage

84m3 184.5m3

175.5m3

Surafce Forebay Storage

SURFACE AND SUBSURFACE STORAGE

PLAN

SECTION AA

Cellular Storage

Permeable Pavement

Forebay Storage

Rain Gardens

Permeable Pavement

Canal

The project is designed to manage and retain stormwater from the surrounding catchment zone during a 100-year flood event. A comprehensive water management strategy has been implemented, incorporating cellular storage beneath existing structures, rain gardens, permeable pavement systems, and surface-level retention through a forebay

Repurposed canal edge

Vegetation Indoor

Outdoor Canal Waterfront

Dining Cellular Water Storage

Permeable Pavement Storage Rain Garden

Sub-Surface Stormwater Storage

Surface Stormwater Storage

Retaining Walls

EXPLODED AXONOMETRIC

Forebay at capacity

The ‘naked street’ concept was applied that creates shared suburban spaces between pedestrian and vehicular traffic. This approach reduces visual and physical clutter, enhancing walkability and promoting a more pedestrian-friendly environment

Implemented naked street

STREETSCAPE SECTION

Canal

4.5m Canal Waterfront Walkway

12.5m

3m

5m

6m

Canal Waterfront Dining

Running Track

Cycling Track

Rain Garden

P Si

BEFORE V

Physical simulation test of the water filtration efficiency of the canal ed filtration pe

3.5m

Paved idewalk

4m Paved Vehicular Access

28m Paved Sidewalk

Stepped Green Park

VS AFTER

dge dining with sand and red-dyed water to visualize flow and sediment erformance

CONSTRUCTION TIMELINE AXONOMETRIC

SITE PLAN

o5 Soft Armature

Professor George Katodrytis

Soft Armature is a speculative, process and research driven architectural project that envisions a temporary adoptable shading system that can be deployed across a number of different spatial environments. Utilizing Gothic ribbed vaults and brutalist massing as structural and conceptual inspiration, the project explores the intersection between permanence and transience through fabric casted forms anchored to a ribbed framework.

The system aims to support a range of programs from sheltering pilgrims and open air markets to hosting cultural gatherings. Infrastructural yet sculptural, the project proposes a living architecture that evolves, changes and erodes, conforming with the landscape within which it is placed

SITE SECTION

PLAN

SITE ELEVATION

The project comprises of a series of parametric modules, waiting in height providing different atmospheric conditions for different program. These modules have spatial continuity unified along a single datum with the ground plane being carved out to accommodate these shifts and volumes.

Underground corridors link these spaces enabling spatial continuity and respite from the hot arid surface environment

This timeline illustrates the cycle of a performative architectural system and how it responds to the env and anchored across the ribs in its second phase. As natural elements such as sandstorms and rainfall in enclosures shaped by environmental conditions. In it’s final stage the fabric is removed leaving b

vironment. Initially composed of exposed structural ribs and foundation walls, elastic fabric is overlaid nteract with the system, the fabric swells and deforms through gravity and pressure creating temporary behind some casted remnants that can be used as service elements for the next seasons structure

o6 Physical Prototyping

A collection of physical models made as a part of a number of design courses, using various fabrication techniques including laser cutting, casting, CNC milling, 3d printing, and plastic thermo-forming

Site model

Structural section model

Supersuraface tester models

Forebay tester model

Structural section model

Detailed seater model

Fabric casting model experiments

Timeline casted models
