I n te l l i g e n t L i g h t i n g Cont rol
P O W E R F U L
S I M P L I C I T Y
POWERFUL CONNECTIVITY, SIMPLE TO USE
Integrates with almost any compatible devices including Decorative Controls Doorbells
CCTV
Alarms
Remote Controls
Smart Backbox Module
DALI/0-10V Controller
Keep Existing Light Switches
2
5-in-1 LED Strip Controller
Voice Control
Retrofit In-Line Smart Junction Box
Designed & Engineered For Seamless Integration In Both Domestic & Commercial Environments
Intelligent Lighting Control
Retrofit System
Advanced Dimming Technology
Voice Control
Alexa App Control
Integrates With Alexa Compatible Devices
Global Control & Geofencing
Option To Keep Your Existing Light Switch
Smart Functions Work When Switch Is On Or Off
2.4GHz Hop & Mesh Technology
Effortless Commissioning & Programming
Program Without Accessing Modules
Global Technical Support
2.4GHz
Make Your Existing Light Switches Smart For Control At Your Fingertips The ONLY System Of Its Kind
Hub Choice May Affect Functionality
SMART-R Terminal Module •
LiLo Technology For Live-in & Live-Out Wiring
•
Works With Existing Wiring
•
Retrofit Solution
•
Works With A Normal Light Switch (AC Mains)
•
User Friendly Reset & Programming From The Light Switch
•
Load Stabiliser Recommended*
•
Can Be Used Independently With A Remote Or In Conjunction With A Smart Hub*
SMART-R Code
Options
Min Load
Max Load
AiQ/DIM400M/LL
Dimmable
8W LED
400W (250W LED)
AiQ/RLY1000M/LL
Relay
20W LED
1000W (300W LED)
SMART-SL LOAD STABILISER Code
Description
AiQ/STLOAD
Load Stabliliser
* See Page 15
4
Call us on 0208 841 9000 | Email us at sales@allledgroup.com
Scan Here For More Information
SMART-E Smart Junction Box Relay Or Dimmer
Alexa Control Allows Cross Platform Integration
SMART-R Module behind existing light switch
SMART-E Smart Junction Box Relay or Dimmer
Alexa Control Allows Cross Platform Integration
SMART-E Junction Box Relay & Dimmer Options •
Designed To Replace A Traditional Junction Box
•
Fits Through A 55mm Cutout
•
Zigbee Hop & Mesh Technology
•
Works With Existing Wiring
•
Retrofit Solution
•
Works With A Normal Light Switch (AC Mains)
•
User Friendly Reset & Programming From Light Switch
•
Can Be Used Independently With A Remote Or In Conjunction With A Smart Hub*
SMART-E Code
Options
Min Load
Max Load
AiQ/DIM400B/LN
Dimmable
0W
400W
AiQ/RLY400B/LN
Relay
0W
400W (250 LED)
* See Page 15
www.allledgroup.com
7
Monotone Smart Remote 4 Zone Remote Control •
Supports 4 Groups For Connecting A Max. of 30 Lighting Devices
•
Can Be Used With Or Without A Smart Hub
•
Single Colour
•
Can Control ALL iQ Controllers Only x1 Lithium Cell 3V
On & Off/Dimming •
Can Be Used Independently Or In
CR2032
Conjunction With A Smart Hub*
MONO SMART REMOTE Code
Options
AiQ/4Z/RMT
Single Colour/4 Zones
SMART-SL Load Stabiliser •
Load Stabiliser
•
Replaces The Traditional Synthetic Load Acting As A Load Regulator For Extremely Low Current Or Inductive Circuits
•
Super Efficient Design Consumes Less Than 1W SMART-SL Code
Description
AiQ/STLOAD
Load Stabliliser
* See Page 15
8
Call us on 0208 841 9000 | Email us at sales@allledgroup.com
SMART-E Smart Junction Box Relay or Dimmer
SMART-S 12-24V 5-in-1 Intelligent LED Strip Controller
SMART Remotes RGBW, CCT, Single Colour Controls
Scan Here For More Information
SMART-S 12-24V 5-in-1 intelligent LED Strip Controller •
DIP Switch 5-In-1 LED Strip Controller
•
AIQ/STRIP/REC Compatible with Single Colour, CCT, RGB, RGBW & RGBWW+CW Strip
•
Flexibility To Be Used On Both A Smart System Or Just A Remote Control
•
Programable Through A Light Switch Or Program Button On Device
•
24V Single Colour & RGBW 384W Max. 24V RGB 288W Max. 24V CCT 192W Max.
•
Internal DIP Switches Allow Multiple
Key
Choices For Programming •
5-in-1 Unit Can Be Preset To Control Any One Of The 5 Options
1
2
Single Colour Dimming CCT RGB RGB(W) RGBWW+CW SMART-S
Multiple Control Options
Code
Voltage
AiQ/STRIP/REC
12-24V DC
Can Be Used Independently With Remote Or In Conjunction With A Smart Hub* * See Page 15
10
Call us on 0208 841 9000 | Email us at sales@allledgroup.com
SMART-E Smart Junction Box Relay Or Dimmer
SMART-S 12-24V 5-in-1 Intelligent LED Strip Controller
SMART-WS Smart Wall Station Controller
www.allledgroup.com
11
SMART-DALI DALI 0/1-10V Signal Generator & 5A Relay
SMART Remotes RGBW, CCT, Single Colour Controls
RGBW Smart Remote All in One Remote for Colour •
Supports 4 Groups For Connecting A Maximum Of 30 Lighting Devices
•
4 Zone Zigbee 5 Channel
•
Single Colour, Trilogy/CCT, RGB & RGB/White
•
Can Be Used Independently Or In Conjunction With A Smart Hub* x2 Lithium Cell 3V
CR2032
RGBW SMART REMOTE Code
Zones
Batteries
AiQ/RGBW/RMT
4
x2 CR2032
SMART-WS Smart Wall Station •
Mains Input (LN)
•
Touch Sensitive
•
Glass Construction
•
ZigBee Hop & Mesh Technology
•
Single Colour, Trilogy/CCT, RGB & RGB/White
•
Requires Pairing Prior To Backbox install
•
Can Be Used Independently Or In Conjunction With A Smart Hub*
SMART-WS Code
Operating Voltage
AiQ/WSW/4Z
220-240V (LN)
Scan Here For More Information
*Compatible Hub Required Not Included See page 15
www.allledgroup.com
13
SMART-CONTACT Smart Door and Window Contact
•
Self-Adhesive Door & Window Contact
•
Easy Programming - Simply Press and Hold
•
Routines Enable Automation on Smart System
•
2 x CR2045 Batteries Included
x2 Lithium Cell 3V
CR2045
SMART-CONTACT Code
Batteries
AIQ/DWC/WH
CR2045 x 2
SMART-CONTACT Door & Window Contact Sensor
SMART-R Module Behind Existing Light Switch
SMART Remotes RGBW, CCT, Single Colour Controls
Scan Here For More Information
SMART-DALI DALI 0/1-10V Signal Generator & 5A Relay
•
Dali 0/1-10V Converter
•
Creates & Converts Smart Signals Into Dali Or 0/1-10V Signals
•
Compatible With All iQ Devices
•
DALI Addressable And Able To Be Grouped
•
DALI Broadcast Mode
•
RGBW & CCT DALI Control Output
•
Can Be Used With Or Without Inbuilt Relay
•
For 0/1-10V Simply Set DIP Switch 10 to Down
•
Can Be Used Independently Or In Conjunction With A Smart Hub*
SMART-DALI Code
Capacity Operating Voltage
AiQ/DALI/0/1-10V
5A
220-240V
* See Below
COMPATIBLE ALEXA HUBS
Echo 4th Gen. With Smart Home Hub
Echo Show 10 3rd Gen
www.allledgroup.com
Echo Studio 1st Gen
15
Yes. Anyone Can Use It.
