Contents Downlights
Battens
Includes iCan, Spartan Range, Marlin & More
Includes Barracuda, Barracuda Extreme & Q-Nex
Page 6
Page 68
Dimmer Modules
Highbays
Includes All-Dim, All-Dim Dummy & All-Dim Grid
Includes LumoMax & Accessories
Page 38
Page 78
LED Lamps
Emergency
Includes Caterham, Jaguar, Triumph & More
Includes Em-Spot, EMPack & Emergency Signage Range
Page 42
Page 82
Bulkheads
Floodlights
Includes Bruno 3, Lennox 2, Victory 2 & More
Includes Osprey, Q-Nex Accessories & More
Page 50
Page 94
LED Panels
Outdoor
Includes Altitude & Altitude CCT Ranges
Includes Excalibur2, Sabre2, Floyd2 & More
Page 62 4
Page 104 e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
Marker Lights
Aluminium Profiles
Includes Noble, Marine, Beam, Valiant & More
Includes Profile1, Orca, StealthEdge & More
Page 114
Page 220
Under Cabinet & Bedroom
iQ Smart Controls
Includes SwiftCCT & Cygnet Ranges
Includes Smart-E, Smart-R, Smart-T & More
Page 144
Page 234
LED Strips
Information
Includes Seamless Pro COB, Monza, Pro Range & More
Includes Index, Dimming Comparisons, LUX Tables & More
Page 150
Page 248
Strip Accessories Includes Colour1+, StripMOD, UniCube & More
Page 190
LED Drivers Includes Drive350, Drive12 & Drive24 Ranges
Page 204 e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
5
Downlights Spartan - 6W Downlight........................................................................... 8
NEW
Spartan Pro - 4W/6W Downlight.............................................................. 12
NEW
Marlin - 5W/7W Downlight....................................................................... 15 iCan65 - GU10 Downlight......................................................................... 16 iCan75 - GU10 Downlight........................................................................ 18 iCan75 Platinum - GU10 Downlight......................................................... 20 Atom Fixed - 5W Downlight..................................................................... 22 Atom Adjustable - 5W Downlight............................................................ 22 Polaris - 8W Downlight............................................................................. 25 Defender Mini - 9W Downlight................................................................. 27 Defender Fixed - 10W Downlight............................................................. 28 Defender Adjustable - 10W Downlight.................................................... 30 GU10 Lamp Holders................................................................................. 32 StealthDL - Plaster-in GU10 Baffle.......................................................... 33 Orbit CCT 6 - 6W Downlight.................................................................... 34 Orbit CCT 12 - 12W Downlight................................................................ 35 Orbit CCT 18 - 18W Downlight................................................................ 36 Orbit CCT 24 - 24W Downlight................................................................ 37
6W Fixed IP65 CCT Selectable Dimmable LED Fire Rated Downlight
• 2 Part Connector With Push Terminals
• IP65 Rated
• 30, 60, 90 Minutes Fire Rated (Timber Joist)
• Loop-In Loop-Out Quick Connect Push Terminal
• 30, 90 Minutes Fire Rated I-Joist • 30 Minutes Fire Rated Metal Web Joist
• Ultra Slim Polar White Bezel As Standard
• Compliant To; Part B - Fire, Part C - Moisture, Part E - Acoustic & Part L Air Leakage
• Insulation Coverable
• CCT Selectable (3000K, 4000K & 6500K)
• Up to 110lm/w Output
• Low Profile Clip-On Bezels Available*
97mm
CCT Selectable
Code AFD600D/CCT
8
40mm
Ø86mm
47mm
25mm
80mm
Cut Out 55-75mm
2 Part Connector With Push Terminals
Cutout
Overall
Ø55-75mm
Ø86mm
Colour Temp CCT
e: sales@allledgroup.com
Useful Lumens ≤510lm
t: 0208 841 9000
Total Lumens ≤660lm
w: allledgroup.com
Accessories* Bezels* AFD600DBZ/AB Antique Brass
AFD600DBZ/AN Anthracite
AFD600DBZ/PB Polished Brass
AFD600DBZ/BB Brushed Brass
AFD600DBZ/PC Polished Chrome
AFD600DBZ/BLK Carbon Black
AFD600DBZ/SN Satin Nickel
THIN JUST GOT THINNER Razor-thin Bezel at 0.8mm That’s the thickness of just 8 A4 sheets of paper
*Item(s) Sold Separately
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
9
10
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
Twist The Lens To Change The CCT
No more pulling out the downlight from the ceiling to change the CCT. With an industry first, All LED introduces this remarkable innovation.
with
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
11
4W/6W IP44 CCT & Wattage Selectable Dimmable LED Fire-Rated Downlight
• Revolutionary RotaLens™ Technology – Twist The Lens To Change The CCT Without Removing The Downlight From The Ceiling • Wattage Selectable – Easily Switch Between 4W And 6W To Customise The Output To Your Lighting Needs • Quick & Simple Wiring – 2-Part Push-Fit Connector With Loop-In / Loop-Out Terminals For Faster Installs • Fire Rated – Tested For 30, 60, And 90 Minutes On Timber Joists, 30 & 90 Minutes On I-Joists, And 30 Minutes On Metal Web Joists • Regulation Ready – Compliant With Part B (Fire), Part C (Moisture), Part E (Acoustic), And Part L (Air Leakage)
• CCT Selectable – Choose From 3000K (Warm White), 4000K (Cool White), Or 6500K (Daylight) • IP44 Rated – Protection Against Dust And Splashes, Perfect For Bathrooms And Kitchens • 0.8mm Ultra-Slim Polar White Bezel – Sleek, Modern Look Included As Standard • Insulation Coverable – Built To Work Safely With Insulation • High Efficiency – Delivers Up To 126 Lumens Per Watt For Maximum Brightness With Low Energy Use • Fits Within A Minimum Ceiling Void Of 40mm (Excluding Insulation)
97mm
Wattage Selectable
2 Part Connector With Push Terminals
Code
Colour Temp
AFD600D/PRO
CCT
12
40mm
Ø86mm
47mm
25mm
80mm
Cut Out 55-75mm
4W
Useful Lumens ≤400lm
Total Lumens ≤510lm
6W
≤590lm
≤755lm
Wattage
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
Twist The Lens To Change The CCT
Accessories* Bezels* AFD600DBZ/AB Antique Brass
AFD600DBZ/AN Anthracite
AFD600DBZ/PB Polished Brass
3000K
AFD600DBZ/BB Brushed Brass
AFD600DBZ/PC Polished Chrome
4000K
AFD600DBZ/BLK Carbon Black
AFD600DBZ/SN Satin Nickel
6500K *Item(s) Sold Separately
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
13
All New Connector For Faster Installations
Record Speed 2-Part Push-Fit Connector With Loop-In / Loop-Out Terminals
5W/7W IP65 4x CCT & Wattage Selectable Fire-Rated Dimmable LED Downlight
Quick & Simple Wiring With
• Quick & Simple Wiring – Record Speed 2-Part Push-Fit Connector With Loop-In / Loop-Out Terminals For Faster Installs • Wattage Selectable – Easily Switch Between 5W And 7W • Fire Rated – Tested For 30, 60, And 90 Minutes On Timber Joists, 30 Minutes On I-Joists, And 30 Minutes On Metal Web Joists • Regulation Ready – Compliant With Part B (Fire), Part C (Moisture), Part E (Acoustic), And Part L (Air Leakage) • CCT Selectable – Choose From 2700K, 3000K, 4000K Or 6000K
• IP65 Rated • Insulation Coverable • Slim Snap-On Bezels Available In Polished Chrome, Satin Nickel And Carbon Black* • High Efficiency – Delivers Up To 115 Lumens Per Watt For Maximum Brightness With Low Energy Use • Fits Within A Minimum Ceiling Void Of 40mm (Excluding Insulation) • Polar White Bezel Included
Accessories* 37mm
AFD570DBZ/SN Satin Nickel Bezel
Code
Colour Temp
AFD570D/CCT
CCT
47mm
AFD570DBZ/PC Polished Chrome Bezel
Ø88mm
AFD570DBZ/BLK Carbon Black Bezel
103mm 37mm
150mm
Cut Out 70-80mm
5W
Useful Lumens ≤485lm
Total Lumens ≤600lm
7W
≤660lm
≤810lm
Wattage
*Item(s) Sold Separately
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
15
65mm GU10 Fire Rated Downlight
• 30, 60, 90 Minutes Fire Rated (Timber Joist) • 30 Minutes Fire Rated Staircraft i-Joist • 30 Minutes Fire Rated Wolf System Metal Web Joist
• Loop-in Loop-Out Quick Connect Push Terminals • Open Vent Design - Improves Lamp Life • Low Profile With Ultra Slim Twist & Lock Bezel
• Compliant to; Part B - Fire, Part C - Moisture, Part E - Acoustic & Part L Air Leakage
Quick Connect Push Terminals Open-Vent Technology
55mm
25mm
36mm
80mm
Ø82mm
Heavy Duty Springs
Super Slim Twist & Lock Bezels
Compatible GU10 Lamps* For More Info See Page 43
Code
Cutout
Overall
AFD65
Ø65mm
Ø85mm
16
Ø65mm
AGU470D Caterham
e: sales@allledgroup.com
AGU501D Morgan
t: 0208 841 9000
AGU700D Jaguar
w: allledgroup.com
Accessories* Bezels* Fixed
AFD65BZ/F/BLK Carbon Black
AFD65BZ/F/PC Polished Chrome
AFD65BZ/F/SN Satin Nickel
AFD65BZ/F/WH Polar White
AFD65BZ/IP/SN Satin Nickel
AFD65BZ/IP/WH Polar White
IP65
AFD65BZ/IP/BLK Carbon Black
AFD65BZ/IP/PC Polished Chrome
Plaster In Trimless Kit*
Insulation Cover*
AFD65/TK Fire Rated White Plaster-In Kit
AFD65/75/IC Click On Insulation Cover
Cutout: Ø110mm • Overall: Ø150mm • Depth: 35mm *Item(s) Sold Separately
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
17
75mm GU10 Fire Rated Downlight
• 30, 60, 90 Minutes Fire Rated (Timber Joist) • 30 Minutes Fire Rated Staircraft i-Joist • 30 Minutes Fire Rated Wolf System Metal Web Joist
• Loop-in Loop-Out Quick Connect Push Terminals • Open Vent Design - Improves Lamp Life • Low Profile With Ultra Slim Twist & Lock Bezel
• Compliant to; Part B - Fire, Part C - Moisture, Part E - Acoustic & Part L Air Leakage
Quick Connect Push Terminals Open-Vent Technology
55mm
25mm
36mm
80mm
Ø89mm
Heavy Duty Springs
Super Slim Twist & Lock Bezels
Compatible GU10 Lamps* For More Info See Page 43
Code
Cutout
Overall
AFD75
Ø75mm
Ø91.5mm
18
Ø75mm
AGU470D Caterham
e: sales@allledgroup.com
AGU501D Morgan
t: 0208 841 9000
AGU700D Jaguar
w: allledgroup.com
Accessories* Bezels* Adjustable AFD75BZ/A/**
Fixed AFD75BZ/F/**
IP65 AFD75BZ/IP/**
ALL FINISHES AVAILABLE IN FIXED, ADJUSTABLE & IP65 AFD75BZ/**/AB Antique Brass
AFD75BZ/**/AN Anthracite
AFD75BZ/**/PB Polished Brass
AFD75BZ/**/BB Brushed Brass
AFD75BZ/**/PC Polished Chrome
Converter Plates*
AFD75BZ/**/BC Brushed Copper
AFD75BZ/**/SN Satin Nickel
AFD75BZ/**/BLK Carbon Black
AFD75BZ/**/WH Polar White
Suitable for Ø78-125mm Cutouts • Overall: Ø150mm • Depth: 4mm
AFD75/CP/BLK - Carbon Black AFD75/CP/PC - Polished Chrome AFD75/CP/SN - Satin Nickel AFD75/CP/WH - Polar White
Multiples*
AFD75/M/01 Solo Plate
AFD75/M/02 Duet Plate
AFD75/M/03 Trio Plate
AFD75/M/04 Quad Plate
130mmx130mm
130mmx237mm
130mmx340mm
237mmx237mm
Plaster In Trimless Kits*
Insulation Cover*
AFD65/75/IC Click On Insulation Cover AFD75/TK/WH Fire Rated White Plaster-In Kit
AFD75/TK/BLK Fire Rated Black Plaster-In Kit
Cutout: Ø110mm • Overall: Ø150mm • Depth: 35mm *Item(s) Sold Separately
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
19
75mm Premium Anti-Glare GU10 Fire Rated Downlight
• 30, 60, 90 Minutes Fire Rated (Timber Joist)
• Open Vent Design - Improves Lamp Life
• 30 Minutes Fire Rated Staircraft i-Joist • 30 Minutes Fire Rated Wolf System Metal Web Joist
• Fixed & Adjustable Low Profile With Ultra Slim Twist & Lock Bezels* Available (Carbon Black/ Polar White Paint Finish)
• Compliant to; Part B - Fire, Part C - Moisture, Part E - Acoustic & Part L Air Leakage
• Fully Customisable Carbon Black & Polar White Baffle (Included With Bezel*)
• Loop-in Loop-Out Quick Connect Push Terminals
• Removable Honeycomb & IP Rated Glass (Included With Bezel*)
Bezel Breakdown Twist & Lock Design
57mm
86mm
Polar White & Carbon Black Interchangeable Baffles
Honeycomb Accessory
Ø91mm
Compatible GU10 Lamps*
Fixed & Adjustable Bezels
For More Info See Page 43
Code
Cutout
Overall
AFDP75
Ø75mm
Ø91mm
20
152mm
IP Glass Fixed IP20 / IP65 Adjustable IP20 / IP54
AGU470D Caterham
e: sales@allledgroup.com
AGU501D Morgan
t: 0208 841 9000
AGU700D Jaguar
w: allledgroup.com
Accessories* Bezels* Fixed IP20/IP65
Adjustable IP20/IP54
AFDP75BZ/F/WH Polar White With Black or White Baffles
AFDP75BZ/A/WH Polar White With Black or White Baffles
AFDP75BZ/F/BLK Carbon Black With Black or White Baffles
AFDP75BZ/A/BLK Carbon Black With Black or White Baffles
Converter Plates*
Suitable for Ø78-125mm Cutouts • Overall: Ø150mm • Depth: 4mm
AFD75/CP/BLK - Carbon Black AFD75/CP/PC - Polished Chrome AFD75/CP/SN - Satin Nickel AFD75/CP/WH - Polar White
Multiples*
AFD75/M/01 Solo Plate
AFD75/M/02 Duet Plate
AFD75/M/03 Trio Plate
AFD75/M/04 Quad Plate
130mmx130mm
130mmx237mm
130mmx340mm
237mmx237mm
Plaster In Trimless Kits*
Insulation Cover*
AFDP75/IC Click On Insulation Cover AFD75/TK/WH Fire Rated White Plaster-In Kit
AFD75/TK/BLK Fire Rated Black Plaster-In Kit
Cutout: Ø110mm • Overall: Ø150mm • Depth: 35mm *Item(s) Sold Separately
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
21
5W IP65 CCT Selectable Dimmable LED Fire Rated Downlight
• 30, 60, 90 Minutes Fire Rated (Timber Joist)
• Loop-in Loop-Out Quick Connect Push Terminals
• 30 Minutes Fire Rated Staircraft i-Joist • 30 Minutes Fire Rated Wolf System Metal Web Joist
• Ultra Slim Low Profile Bezel • OptiDim - Advanced Dim To Zero Technology
• CCT Selectable (3000K, 4000K & 6000K)
• Dimmable
• IP65 Rated
• Integrated LED
Fixed
Adjustable
72mm
Version
72mm
37mm
Cutout: Ø58 - 75 mm
Finish
91mm
20mm
37mm
Cutout: Ø55 - 75 mm
Code
• DiamondTec Lens
72mm
60mm
91mm
• 20° Maximum Tilt (Adjustable Only)
20mm
• Compliant to; Part B - Fire, Part C - Moisture, Part E - Acoustic & Part L Air Leakage
Colour Temp CCT
Useful Lumens ≤370lm
Total Lumens ≤490lm
AFD05/F/BK/CCT
Fixed
Carbon Black
AFD05/F/PC/CCT
Fixed
Polished Chrome
CCT
≤370lm
≤490lm
AFD05/F/SN/CCT
Fixed
Satin Nickel
CCT
≤370lm
≤490lm
AFD05/F/WH/CCT
Fixed
Polar White
CCT
≤370lm
≤490lm
AFD05/A/BK/CCT
Adjustable
Carbon Black
CCT
≤360lm
≤490lm
AFD05/A/PC/CCT
Adjustable
Polished Chrome
CCT
≤360lm
≤490lm
AFD05/A/SN/CCT
Adjustable
Satin Nickel
CCT
≤360lm
≤490lm
AFD05/F/WH/CCT
Adjustable
Polar White
CCT
≤360lm
≤490lm
Please refer to LUX charts at the rear of the catalogue for reference purposes.
22
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
Finishes* Fixed
AFD05/F/BK/CCT Carbon Black
AFD05/F/PC/CCT Polished Chrome
AFD05/F/SN/CCT Satin Nickel
AFD05/F/WH/CCT Polar White
AFD05/A/PC/CCT Polished Chrome
AFD05/A/SN/CCT Satin Nickel
AFD05/A/WH/CCT Polar White
Adjustable
AFD05/A/BK/CCT Carbon Black
IP65 Rated Adjustable
Easy Access CCT Switch
Accessories* For More Info See Page 19
AFD75/TK/** Fire Rated Plaster-In Kit
AFD75/CP/** Converter Plates
AFD75/M/** Multiples Plates *Item(s) Sold Separately
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
23
At All LED, innovation sits at the heart of everything we do. That is why we are incredibly proud and truly honoured to announce that our Polaris DimTo-Warm LED Fire Rated Downlight received the prestigious Red Dot Award 2025 for Lighting Design. Winning a Red Dot is no small feat. It represents one of the highest accolades of design excellence on the global stage, a symbol recognised by lighting professionals around the world. To have Polaris acknowledged in this way is both an honour and a validation of the passion, precision and expertise that drive all of us at All LED. Our team understands the importance of creating products that are not only technically robust but also beautifully designed, and Polaris delivers on both fronts. The Polaris Dim-To-Warm LED Fire Rated Downlight transforms what is possible with ambient lighting. Engineered with advanced Dim-To-Warm technology, it effortlessly transitions from a crisp 3000K down to a golden, intimate 2100K as it dims, emulating the warmth of traditional incandescent lighting. This customisable feature allows users to craft beautifully tailored atmospheres with ease, bringing warmth, depth and comfort to any space.
SCAN FOR VIDEO
PERFECT FOR ATMOSPHERIC LIGHTING
CCT 2100K
CCT 3000K
8W IP65 Dim-To-Warm LED Fire Rated Downlight
• Dim To Warm Technology From 2100K To 3000K
• IP65 Rated From Front When Installed • 2 Part Quick Connector
• 30, 60, 90 Minutes Fire Rated (Timber Joist)
• Loop-In Loop-Out Push Terminals
• 30 Minutes Fire Rated Knauf i-Joist
• Insulation Coverable
• Compliant To; Part B - Fire, Part C - Moisture, Part E - Acoustic & Part L - Air Leakage
• Mains Dimmable As Standard
2 Part Quick Connector
Push Terminals
Low Profile Light Unit
25mm
50mm
Ø105mm
128mm 41mm
Ø122mm
This Product Is Used Mainly For Mood And Effect Purposes. Please Refer To The Lux Table On Datasheet For More Information. We Recommend That This Product Is Supplemented With Other Light Sources. Colour Temp 2100K to 3000K
Code AFDD10W/DTW
Useful Lumens ≤400lm
Total Lumens ≤400lm
Please refer to LUX charts at the rear of the catalogue for reference purposes. e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
25
FIRE RATED DOWNLIGHT RANGE
FIXED
A D J U S TA B L E
Excellent Dimming Compatibility Supplied With Driver DALI & 0-10V Dimming Options Available 26
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
9W Mini IP65 Fire Rated Baffled LED Downlight
• 30, 60, 90 Minutes Fire Rated (Timber Joist)
• Black And White Baffle Included
• Compliant to; Part B - Fire, Part C - Moisture, Part E - Acoustic & Part L Air Leakage
• Magnetic Bezel
• IP65 Rated
• High Colour Rendering Index CRI 90+
• Insulation Coverable
• Dimmable
Included Accessories
100mm
Black Baffle
White Baffle
Magnetic Bezel
Insulation Cover
Ø70mm
Ø50mm
74mm
Colour Temp 3000K
Useful Lumens ≤580lm
Total Lumens ≤580lm
Code
Version
AFDMR11/30
Standard
AFDMR11/40
Standard
4000K
≤620lm
≤620lm
AFDMR11/30/DALI
DALI Dimmable
3000K
≤580lm
≤580lm
AFDMR11/40/DALI
DALI Dimmable
4000K
≤620lm
≤620lm
AFDMR11/30/0-10V
0-10V Dimmable
3000K
≤580lm
≤580lm
AFDMR11/40/0-10V
0-10V Dimmable
4000K
≤620lm
≤620lm
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
27
Fixed 10W IP65 Dimmable LED Fire Rated Downlight
• 30, 60, 90 Minutes Fire Rated (Timber Joist)
• Integrated 10W Cree COB LED
• Compliant to; Part B - Fire, Part C - Moisture, Part E - Acoustic & Part L Air Leakage
• Low Glare Design
• IP65 Rated
• Interchangeable Twist & Lock Bezels
• Dimmable
• Excellent Dimming Compatibility
• Halogen Style Lens
50mm
Ø65mm
Twist & Lock Bezels
Ø82mm
Driver With Push Terminals Supplied
Useful Lumens ≤860lm
Total Lumens ≤980lm
4000K
≤880lm
≤1000lm
3000K
≤860lm
≤980lm
4000K
≤880lm
≤1000lm
0-10V Dimmable
3000K
≤860lm
≤980lm
0-10V Dimmable
4000K
≤880lm
≤1000lm
Code
Version
AFD010D/30
Standard
AFD010D/40
Standard
AFD010D/30/DALI
DALI Dimmable
AFD010D/40/DALI
DALI Dimmable
AFD010D/30/0-10V AFD010D/40/0-10V
Colour Temp 3000K
Please refer to LUX charts at the rear of the catalogue for reference purposes.
28
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
Accessories* Bezels* AFD010BZ/WH Polar White
AFD010BZ/BK Carbon Black
AFD010BZ/PC Polished Chrome
AFD010BZ/SN Satin Nickel
AFD010BZ/MWBB Matte White With Black Baffle
AFD010BZ/MWMW Matte White With White Baffle
Trimless Plaster-in Kit*
AFD010TK Matte White Baffled Fire Rated Trimless Kit 95mm Cutout (Bezel & Luminaire Required)
Emergency Accessories*
AEMPACK/240V 7W Universal Emergency Pack For 220-240V LED Loads
AEM/PACK Maintained Or Non Maintained Emergency Pack
For More Info See Page 85
For More Info See Page 84 *Item(s) Sold Separately
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
29
Adjustable 10W IP44 Dimmable LED Fire Rated Downlight
• 30, 60, 90 Minutes Fire Rated (Timber Joist)
• Integrated 10W Cree COB LED
• Compliant to; Part B - Fire, Part C - Moisture, Part E - Acoustic & Part L Air Leakage
• 30° Maximum Tilt
• IP44 Rated
• Interchangeable Twist & Lock Bezels
• Halogen Style Lens
• Dimmable
45mm
Ø85mm
Twist & Lock Bezels
Ø98mm
Driver With Push Terminals Supplied
Useful Lumens ≤860lm
Total Lumens ≤980lm
4000K
≤880lm
≤1000lm
3000K
≤860lm
≤980lm
4000K
≤880lm
≤1000lm
0-10V Dimmable
3000K
≤860lm
≤980lm
0-10V Dimmable
4000K
≤880lm
≤1000lm
Code
Version
AFD110ADJD/30
Standard
AFD110ADJD/40
Standard
AFD110ADJD/30/DALI
DALI Dimmable
AFD110ADJD/40/DALI
DALI Dimmable
AFD110ADJD/30/0-10V AFD110ADJD/40/0-10V
Colour Temp 3000K
Please refer to LUX charts at the rear of the catalogue for reference purposes.
30
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
Accessories* Bezels* AFD110ADJBZ/WH Polar White
AFD110ADJBZ/PC Polished Chrome
AFD110ADJBZ/SN Satin Nickel
AFD110ADJBZ/MW Matte White
Trimless Plaster-in Kit*
AFD110ADJTK Matte White Baffled Fire Rated Trimless Kit 120mm Cutout (Bezel & Luminaire Required)
Emergency Accessories*
AEMPACK/240V 7W Universal Emergency Pack For 220-240V LED Loads
AEM/PACK Maintained Or Non Maintained Emergency Pack
For More Info See Page 85
For More Info See Page 84 *Item(s) Sold Separately
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
31
GU10 Double Insulated Lamp Holders
GU10 Lamp Holder With Connection Box
GU10 Lamp Holder With 30cm Cable
• Ceramic GU10 Lamp Holder
• Ceramic GU10 Lamp Holder
• Open Platform Connection Box
• Long 30cm Cable Length
• Cable Length 18cm
• GU10 Cable Retention
• Loop-In & Loop-Out
Compatible GU10 Lamps* For More Info See Page 43
AGU470D Caterham
AGU501D Morgan
Code
Description
ALHGU101/B
GU10 Lamp Holder With Connection Box
ALHGU101/L30
GU10 Lamp Holder With 30cm Cable
AGU700D Jaguar
*Item(s) Sold Separately
32
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
StealthDL
Adjustable Plaster-In Baffle GU10 Downlight
• Modern Low Glare Design
• 35° Horizontal Tilt
• Matte White RAL9016 & Black Baffle
• Spring Retention Lamp Holder
• 360° Rotatable
• Cast Aluminium Construction
Accessories*
ABAF002/MW White Baffle
360° Adjustable Plaster-in Design With Standard Black Baffle
Compatible GU10 Lamps* 55mm
For More Info See Page 43
AGU470D Caterham
AGU501D Morgan
Code ADLT002BB/MW
Ø120mm
AGU700D Jaguar
Finish
Lamp Holder
Matte White
GU10 (25W Max) *Item(s) Sold Separately
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
33
6W CCT Slimline Panel Commercial Downlight
• 5 Year Guarantee
• Ideal For Use In Shallow Ceiling Voids
• CCT Selectable (3000K/4000K/6000K)
• High Luminous Efficiency
• UV Stable
• Plug & Play DC Connector Driver
• Flicker Free Driver
• Uniform Light Output
• Low Glare Edge-Lit Design
• 0-10V & DALI Dimmable Options Available
• Slimline Design
25mm
Ø105mm
Ø120mm
Pre-Wired LED Driver Code
Slimline Design Version
Colour Temp
Useful Lumens
Total Lumens ≤460lm
AFPD006/CCT
Standard
CCT
≤460lm
AFPD006/CCT/EM
Emergency
CCT
≤460lm
≤460lm
AFPD006/CCT/EM/ST
Emergency Self Test
CCT
≤460lm
≤460lm
AFPD006TD/CCT
Mains Dimmable
CCT
≤460lm
≤460lm
AFPD006TD/CCT/EM
Mains Dimmable Emergency
CCT
≤460lm
≤460lm ≤460lm
AFPD006TD/CCT/EM/ST
Mains Dimmable Emergency
CCT
≤460lm
AFPD006/CCT/DALI
DALI Dimmable
CCT
≤460lm
≤460lm
AFPD006/CCT/DALI/EM
DALI Dimmable Emergency
CCT
≤460lm
≤460lm
AFPD006/CCT/DALI/EM/ST
DALI Dimmable Emergency Self Test
CCT
≤460lm
≤460lm
AFPD006/CCT/0-10
0-10V Dimmable
CCT
≤460lm
≤460lm
AFPD006/CCT/0-10/EM
0-10V Dimmable Emergency
CCT
≤460lm
≤460lm
AFPD006/CCT/0-10/EM/ST
0-10V Dimmable Emergency Self Test
CCT
≤460lm
≤460lm
Please refer to LUX charts at the rear of the catalogue for reference purposes.
34
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
12W CCT Slimline Panel Commercial Downlight
• 5 Year Guarantee
• Ideal For Use In Shallow Ceiling Voids
• CCT Selectable (3000K/4000K/6000K)
• High Luminous Efficiency
• UV Stable
• Plug & Play DC Connector Driver
• Flicker Free Driver
• Uniform Light Output
• Low Glare Edge-Lit Design
• 0-10V & DALI Dimmable Options Available
• Slimline Design
25mm
Ø155mm
Ø170mm
CCT Selectable
Slimline Design
Code
Version
Colour Temp
Useful Lumens
Total Lumens
AFPD012/CCT
Standard
CCT
≤1150lm
≤1150lm
AFPD012/CCT/EM
Emergency
CCT
≤1150lm
≤1150lm
AFPD012/CCT/EM/ST
Emergency Self Test
CCT
≤1150lm
≤1150lm
AFPD012TD/CCT
Mains Dimmable
CCT
≤1150lm
≤1150lm
AFPD012TD/CCT/EM
Mains Dimmable Emergency
CCT
≤1150lm
≤1150lm
AFPD012TD/CCT/EM/ST
Mains Dimmable Emergency
CCT
≤1150lm
≤1150lm
AFPD012/CCT/DALI
DALI Dimmable
CCT
≤1150lm
≤1150lm
AFPD012/CCT/DALI/EM
DALI Dimmable Emergency
CCT
≤1150lm
≤1150lm
AFPD012/CCT/DALI/EM/ST
DALI Dimmable Emergency Self Test
CCT
≤1150lm
≤1150lm
AFPD012/CCT/0-10
0-10V Dimmable
CCT
≤1150lm
≤1150lm
AFPD012/CCT/0-10/EM
0-10V Dimmable Emergency
CCT
≤1150lm
≤1150lm
AFPD012/CCT/0-10/EM/ST
0-10V Dimmable Emergency Self Test
CCT
≤1150lm
≤1150lm
Please refer to LUX charts at the rear of the catalogue for reference purposes. e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
35
18W CCT Slimline Panel Commercial Downlight
• 5 Year Guarantee
• Ideal For Use In Shallow Ceiling Voids
• CCT Selectable (3000K/4000K/6000K)
• High Luminous Efficiency
• UV Stable
• Plug & Play DC Connector Driver
• Flicker Free Driver
• Uniform Light Output
• Low Glare Edge-Lit Design
• 0-10V & DALI Dimmable Options Available
• Slimline Design
25mm
Ø205mm
Ø225mm
Pre-Wired LED Driver
CCT Selectable
Code
Version
Colour Temp
Useful Lumens
Total Lumens
AFPD018/CCT
Standard
CCT
≤1750lm
≤1750lm
AFPD018/CCT/EM
Emergency
CCT
≤1750lm
≤1750lm
AFPD018/CCT/EM/ST
Emergency Self Test
CCT
≤1750lm
≤1750lm
AFPD018TD/CCT
Mains Dimmable
CCT
≤1750lm
≤1750lm
AFPD018TD/CCT/EM
Mains Dimmable Emergency
CCT
≤1750lm
≤1750lm
AFPD018TD/CCT/EM/ST
Mains Dimmable Emergency
CCT
≤1750lm
≤1750lm
AFPD018/CCT/DALI
DALI Dimmable
CCT
≤1750lm
≤1750lm
AFPD018/CCT/DALI/EM
DALI Dimmable Emergency
CCT
≤1750lm
≤1750lm
AFPD018/CCT/DALI/EM/ST
DALI Dimmable Emergency Self Test
CCT
≤1750lm
≤1750lm
AFPD018/CCT/0-10
0-10V Dimmable
CCT
≤1750lm
≤1750lm
AFPD018/CCT/0-10/EM
0-10V Dimmable Emergency
CCT
≤1750lm
≤1750lm
AFPD018/CCT/0-10/EM/ST
0-10V Dimmable Emergency Self Test
CCT
≤1750lm
≤1750lm
Please refer to LUX charts at the rear of the catalogue for reference purposes.
36
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
24W CCT Slimline Panel Commercial Downlight
• 5 Year Guarantee
• Ideal For Use In Shallow Ceiling Voids
• CCT Selectable (3000K/4000K/6000K)
• High Luminous Efficiency
• UV Stable
• Plug & Play DC Connector Driver
• Flicker Free Driver
• Uniform Light Output
• Low Glare Edge-Lit Design
• 0-10V & DALI Dimmable Options Available
• Slimline Design
25mm
Ø225mm
Ø240mm
Plug & Play
Slimline Design
Code
Version
Colour Temp
Useful Lumens
Total Lumens
AFPD024/CCT
Standard
CCT
≤2400lm
≤2400lm
AFPD024/CCT/EM
Emergency
CCT
≤2400lm
≤2400lm
AFPD024/CCT/EM/ST
Emergency Self Test
CCT
≤2400lm
≤2400lm
AFPD024TD/CCT
Mains Dimmable
CCT
≤2400lm
≤2400lm
AFPD024TD/CCT/EM
Mains Dimmable Emergency
CCT
≤2400lm
≤2400lm
AFPD024TD/CCT/EM/ST
Mains Dimmable Emergency
CCT
≤2400lm
≤2400lm
AFPD024/CCT/DALI
DALI Dimmable
CCT
≤2400lm
≤2400lm
AFPD024/CCT/DALI/EM
DALI Dimmable Emergency
CCT
≤2400lm
≤2400lm
AFPD024/CCT/DALI/EM/ST
DALI Dimmable Emergency Self Test
CCT
≤2400lm
≤2400lm
AFPD024/CCT/0-10
0-10V Dimmable
CCT
≤2400lm
≤2400lm
AFPD024/CCT/0-10/EM
0-10V Dimmable Emergency
CCT
≤2400lm
≤2400lm
AFPD024/CCT/0-10/EM/ST
0-10V Dimmable Emergency Self Test
CCT
≤2400lm
≤2400lm
Please refer to LUX charts at the rear of the catalogue for reference purposes. e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
37
Dimmer Modules All-Dim - 150W Dimmer............................................................................ 41 All-Dim - Dummy Dimmer........................................................................ 41 All-Dim - Grid Dimmer.............................................................................. 41
Dimmer Switch Range
Large Terminals For Easy Wiring
Smooth Dimming Performance
Compact Size
Featuring our advanced OptiDim technology, it ensures smooth and flicker-free dimming performance
All-Dim Dimmer Switch Range
150W Programmable 2 Way LED Dimmer Module
6A (1000W) 2 Way Dummy Dimmer Switch Module
150W Programmable 2 Way LED Grid Dimmer & Adaptor Plates
• Designed For Use With LEDs • Programmable Leading Edge And Trailing Edge Modes • Adjustable Minimum Brightness Setting • Advanced OptiDim Technology • Compact Size With Earth Lug Voids • Compatible With Huge Range Of Products • Slim, Slightly Off-Centre Spindle • Suitable For Retrofit And New Installations
• Dummy Dimmer Module • 6 Amps (1000W Max Load) • Slim, Off-Centre Spindle - Fits Almost All Dimmer Plates • Two Way On/Off Switching Function • Compact Size With Earth Lug Void • Suitable For Retrofit And New Installations • Identical In Appearance To Dimmer Switch (ADIM/150W)
• 5W - 150W LED Max Load. Designed For Use With LED Loads • Includes 9 Adaptors: BG, Crabtree, Deta, Hamilton, Hager, MK Logic, Schneider Lisse, Schneider Ultimate And Wandsworth • Adaptors Available In Black Or White Finish • Includes ALL LED Dimmer Nut Tool • No Maximum Luminaire Quantity • Adjustable Minimum Brightness Setting • Advanced OptiDim Technology • Wide Dimming Compatibility • Centre Spindle • Ideal For Retrofit And New Installations • Enlarged Terminals For Easy Wiring
Code
Version
Watts
ADIM/150W
Dimmer Module
5W-150W
ADIM/DUM6A
Dummy Dimmer
0W-1000W
ADIM150/GRID/WH
Grid Dimmer, Tool & White Adaptor Plates Kit
5W - 150W
Accessories* Code
Description
ADIM/TOOL
Dimmer Nut Tool
ADIM150/GRID/BLK/ADAPT
Black Adaptors† *Item(s) Sold Separately. † For Use With Grid Dimmer
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
41
LED Lamps Caterham - 4.7W GU10............................................................................ 44 Morgan - 5.5W GU10................................................................................ 45 Jaguar - 7W GU10.................................................................................... 46 Glass Filters For Lamps & Fixtures.......................................................... 47 Aston - 2W G9.......................................................................................... 48 Triumph - 9W GLS.................................................................................... 49
4.7W High Output OptiDim LED GU10
• Advanced OptiDim Technology
• Labour & Waste Saving
• High Lumen Output
• Packed In Sleeves Of 10
• Energy Saving Up To 92%
• 100% Recycled Packaging
†
Colour Options
55mm
Ø50mm
AGU470D/27 2700K
AGU470D/30 3000K
100% AGU470D/40 4000K
Dim To Zero Technology
1%
AGU470D/60 6500K Colour Temp
Useful Lumens
AGU470D/27
2700K
≤380lm
≤443lm
AGU470D/30
3000K
≤365lm
≤430lm
AGU470D/40
4000K
≤414lm
≤486lm
AGU470D/60
6500K
≤424lm
≤498lm
Code
Please refer to LUX charts at the rear of the catalogue for reference purposes.
44
e: sales@allledgroup.com
Total Lumens
†Compared to a 50W Halogen
t: 0208 841 9000
w: allledgroup.com
MORGAN
5.5W High Output Dimmable LED GU10
• High Efficiency
• Dimmable
• Full Polycarbonate & Aluminium Jacket
• Diamond Cut Lens Technology For Optimum Beam Angle
• Retrofit Size For Replacing Halogen Lamps
Colour Options
56mm
Ø50mm
AGU501D/27 2700K
AGU501D/30 3000K
Diamond Cut Lens
AGU501D/40 4000K
AGU501D/60 6000K Colour Temp
Useful Lumens
AGU501D/27
2700K
≤361lm
≤463lm
AGU501D/30
3000K
≤381lm
≤489lm
AGU501D/40
4000K
≤408lm
≤521lm
AGU501D/60
6000K
≤408lm
≤521lm
Code
Total Lumens
Please refer to LUX charts at the rear of the catalogue for reference purposes. e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
45
7W High Output Dimmable LED GU10
• High Efficiency
• Dimmable
• Retrofit Size For Replacing Halogen Lamps
• Slimline Multi-Faceted Lens
• Latest Technology For Optimum Beam Angle
Colour Options
56mm
Ø50mm
AGU700D/30 3000K
AGU700D/40 4000K
Multi-Faceted Lens
AGU700D/60 6000K
Code
Colour Temp
Useful Lumens
Total Lumens
AGU700D/30
3000K
≤484lm
≤615lm
AGU700D/40
4000K
≤511lm
≤643lm
AGU700D/60
6000K
≤487lm
≤645lm
Please refer to LUX charts at the rear of the catalogue for reference purposes.
46
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
Glass Filters For GU10, MR16 LED Lamps & Fixtures
Compatible With: Caterham GU10 Morgan GU10 Jaguar GU10 • Colour Treated Glass • Designed To Fit Most GU10/MR16 Size Lamps & Fittings
• Can Be Installed In Many Fixtures Or Affixed To Lamps To Create A Brilliant Lighting Effect • 1mm Thickness
• Maintains Colour Matching AGF/SPK/BLU Blue Filter
AGF/SPK/DAY Daylight Filter
AGF/SPK/GR Green Filter
To Install Simply Place Filter Between Lamp and Bezel Code
Ø49.5mm
AGF/SPK/YEL Yellow Filter
1mm
Colour
AGF/SPK/BLU
Blue
AGF/SPK/DAY
Daylight
AGF/SPK/GR
Green
AGF/SPK/RED
Red
AGF/SPK/YEL
Yellow
e: sales@allledgroup.com
AGF/SPK/RED Red Filter
t: 0208 841 9000
w: allledgroup.com
47
G9 Retro-Fit Glass Body 2W COB Wafer LED Lamp
• Retrofit Size & Look
• 2W COB Wafer Technology
• Non Dimmable
• Full Glass Construction
COB Wafer LED Technology
Solid State Driver-in-Diode
High Density Glass Cover
Retrofit Size
Code
Colour Temp
Cap
AG920/30
3000K
AG920/40
4000K
48
32mm
50mm
14mm
Useful Lumens
Total Lumens
G9
≤250lm
≤250lm
G9
≤265lm
≤265lm
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
9W E27/B22 Dimmable LED GLS Lamps
Triumph
• Perfect Replacement For Incandescent GLS Lamps
• 360° Omni-Directional Light Distribution
• Dimmable
• Designed To Emulate Traditional Light Source
• Provides Uniform Lighting
Colour Temp
Cap
AGLS901ESD/30
3000K
AGLS901ESD/60
6000K
AGLS901BCD/30 AGLS901BCD/60
Code
e: sales@allledgroup.com
108mm
60mm
108mm
60mm
Useful Lumens
Total Lumens
ES | E27
≤825lm
≤825lm
ES | E27
≤850lm
≤850lm
3000K
BC | B22
≤825lm
≤825lm
6000K
BC | B22
≤850lm
≤850lm
t: 0208 841 9000
w: allledgroup.com
49
Bulkheads Q-Nex Plug & Play For Bulkheads .......................................................... 52 Bruno 3 - 16W Bulkhead.......................................................................... 54 Lennox 2 - 14W Bulkhead........................................................................ 56 Victory 2 - 12W Bulkhead........................................................................ 57 Romano - 13W Bulkhead......................................................................... 58 Costello - 13W Bulkhead......................................................................... 59 Microwave Sensor.................................................................................... 61
INTRODUCING
F O R
B U L K H E A D S
Q-NEX PLUG & PLAY 3-HOUR EMERGENCY PACK • • • • • • •
AB/EMPACK AB/EMPACK/ST
Quick Connection Design Lithium Battery Technology Install In Seconds 3 Hours Emergency Run Time 24 Hours Charge Time With 3 Hour Discharge Time Self Test Version Available (AB/EMPACK/ST) Integrated Emergency Indicator
Q-NEX PLUG & PLAY 2-IN-1 MICROWAVE AND CORRIDOR SENSOR AB/MSC • 2-In-1 Fully Programmable Microwave On/Off / Corridor Function Sensor • Easy Commissioning & Programmable Using DIP Switches • Install In Seconds • Maximum Mounting Height Of Up To 6m • Maximum Detection Range Of Up To 12m
Only To Be Used With Compatible Products
LENNOX 2 14W LED IP65 IK08 CCT SLIM-DESIGN BULKHEAD AB/LEN/CCT
BRUNO 3 16W IP65 IK10 CCT SELECTABLE LED BULKHEAD AB/BRU/CCT
• • • • • • • • • •
• • • •
IP65 Rating IK08 Shatter Resistant Construction CCT Selectable (3000K/4000K/6000K) Suitable For Wall & Ceiling Mounting For Indoor, Outdoor & Coastal Applications Quick Release Flip-Down Gear Tray Push Terminals Integrated Besa Mounts Premium Grade Polycarbonate Modern Slim-Design
• • • • • • •
Ultra High Efficiency & High Lumen Output ≤148lm/W Four Side Conduit Entries For Easy Install IP65 Rating IK10 Premium Grade Polycarbonate Shatter Resistant Construction CCT Selectable (3000K / 4000K / 6000K) White Ring Bezel Included As Standard Suitable For Wall & Ceiling Mounting For Indoor, Outdoor & Coastal Applications Quick Release Flip-Down Gear Tray Push Terminals Integrated Besa Mounts
16W LED IP65 IK10 CCT Selectable Bulkhead
• Plug & Play Replaceable Battery Emergency Modules (AB/EMPACK & AB/EMPACK/ST)*
• IK10 Premium Grade Polycarbonate Shatter Resistant Construction
• Plug & Play 2-in-1 Fully Programmable Microwave On/Off / Corridor Function Sensor Module (AB/MSC)*
• CCT Selectable (3000K / 4000K / 6000K)
• Ultra High Efficiency & High Lumen Output ≤148lm/W • Four Side Conduit Entries For Easy Install • IP65 Rating
• White Ring Bezel Included As Standard • Suitable For Wall & Ceiling Mounting • For Indoor, Outdoor & Coastal Applications • Quick Release Flip-Down Gear Tray • Push Terminals • Integrated Besa Mounts Ø300mm
Besa Box Mounting
75mm
Easily Upgraded With Q-Nex
Code
Colour Temp
Useful Lumens
Total Lumens
AB/BRU/CCT
CCT
≤2370lm
≤2370lm
54
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
Accessories* Q-Nex Plug & Play*
AB/EMPACK Q-Nex Plug & Play 3-Hour Emergency Pack
AB/EMPACK/ST Q-Nex Plug & Play Self Testing 3-Hour Emergency Pack
Bezels*
AB/MSC Q-Nex Plug & Play 2-In-1 Microwave / Corridor Sensor
AB/BRU/ALB Anti-Ligature Base • Ultra-Strong Sheet Steel Formed Single Piece Base • Designed To Create A Safe Environment In High Risk Areas • Ideal For Hospitals, Courts, Prisons & Cells, Public Transport & All Public Facilities • Aesthetic, Modern Design - Powder Coated Polar White Finish
• Anti-Tamper Non-Grindable, Recessed Security Screws With Tool Included • IK10+ Rating, Designed For The Toughest Environments • Loop-In Loop-Out Design With Multiple Entries • Totally Flush Installation - Surface Designed To Receive Anti-Pick Sealant
Alternative Decorative Bezels Available In Several Styles And Colours Check Online For Stock
*Item(s) Sold Separately
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
55
14W LED IP65 IK08 CCT Selectable Slim-Design Bulkhead
SCAN FOR VIDEO
• Plug & Play Replaceable Battery Emergency Modules (AB/EMPACK & AB/EMPACK/ST)*
• Suitable For Wall & Ceiling Mounting
• Plug & Play 2-in-1 Fully Programmable Microwave On/Off / Corridor Function Sensor Module (AB/MSC)*
• Quick Release Flip-Down Gear Tray
• IP65 Rating
• For Indoor, Outdoor & Coastal Applications • Push Terminals • Integrated Besa Mounts • Premium Grade Polycarbonate
• IK08 Shatter Resistant Construction
• Modern Slim-Design
• CCT Selectable (3000K/4000K/6000K)
Accessories*
79mm
Ø330mm
AB/EMPACK & AB/EMPACK/ST Q-Nex Plug & Play 3-Hour Emergency Packs
AB/MSC Q-Nex Plug & Play 2-In-1 Microwave / Corridor Sensor
AB/LEN/BZ-BLK Matte Black Bezel
AB/LEN/BZ-PC Polished Chrome Bezel
Code
Colour Temp
Useful Lumens
Total Lumens
AB/LEN/CCT
CCT
≤1420lm
≤1420lm *Item(s) Sold Separately
56
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
12W LED IP65 IK08 Coastal CCT Selectable Bulkhead
• IP65 Rating
• Black And White Standard Trims Included
• IK08 High Impact Durable Polycarbonate Housing
• Additional Decorative Trims Available*
• CCT Selectable (3000K/4000K/6000K)
• Polycarbonate Body Ideal For Coastal Applications
• Wall And Ceiling Mounting
• 3 Years Guarantee
• Loop In Loop Out Pre-Moulded Cable Entries
75mm
Accessories* ABHW12BZ/BK Black Decorative Trim Pack
105mm
Includes: Bidirectional Trim Tridirectional Trim 230mm
ABHW12BZ/WH White Decorative Trim Pack Includes: Bidirectional Trim Tridirectional Trim
Code
Colour Temp
Useful Lumens
Total Lumens
ABHW12/CCT
CCT
≤1050lm
≤1050lm *Item(s) Sold Separately
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
57
13W IP65 CCT Selectable Oval Utility Bulkhead
• Quick Install Hinged Terminal Box
• For Indoor, Outdoor & Coastal Applications
• Loop-In Loop-Out Design With Push Terminals
• IK06 Impact Resistant
• CCT Selectable (3000K / 4000K / 6500K)
• IP65 Rating
48mm
210mm
105mm
Quick Install Hinged Terminal Box
Loop-In Loop-Out Push Terminals
Code
Colour Temp
Useful Lumens
Total Lumens
ABE13OVW/CCT
CCT
≤1520lm
≤1520lm *Item(s) Sold Separately
58
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
13W IP65 CCT Selectable Round Utility Bulkhead
• Quick Install Hinged Terminal Box
• For Indoor, Outdoor & Coastal Applications
• Loop-In Loop-Out Design With Push Terminals
• IK06 Impact Resistant
• CCT Selectable (3000K / 4000K / 6500K)
• IP65 Rating
Ø190mm
48mm
Quick Install Hinged Terminal Box
Loop-In Loop-Out Push Terminals
Code
Colour Temp
Useful Lumens
Total Lumens
ABE13RDW/CCT
CCT
≤1775lm
≤1775lm *Item(s) Sold Separately
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
59
60
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
Fully Programmable Microwave Sensor • Suitable For Use With LEDs • Low Load Switching Capacity • In-Built Lux Sensor • 5.8Ghz Frequency
360°
• Push Fit Terminals • Adjustable Detection Range • Adjustable Lux Range • Adjustable Timer Function
S1 S2 S3 S4 S5 S6 S7 S8 ON
5
6
7
8
7
8
LUX: S6, S7, S8
Max: 10m
8
1
S5 0 1 0 1 0 1 0 1
S6
S7
S8
LUX
0 0 0 0 1 1 1 1
0 0 1 1 0 0 1 1
0 1 0 1 0 1 0 1
24H 10 LUX 20 LUX 50 LUX 100 LUX 200 LUX 300 LUX 500 LUX
360
3
4
5
TIME: S3, S4, S5
Time
6
7
8
LUX: S6, S7, S8
t: 0208 841 9000
Max: 10m
S1 S2 S3 S4 S5 S6 S7 S8
10s ON 1min 5min 10min 1 2 15min SENS: S1, S2 360 20min 25min 30min
SAB Max: 10m
3
4
5
TIME: S3, S4, S5
6
7
360
8
LUX: S6, S7, S8
Height of Installation 2.5~3.5m Max: 10m
86.1mm 78mm 70mm
41mm
e: sales@allledgroup.com
2
SENS: S1, S2
0 0 1 1 0 0 1 1
360
SAB
LUX: S6, S7, S8
(Height of Installation 2.5m) Detection Range 360
Detection Angle
42mm
Max: 10m
2m 5m 8m 10m
S4
2.5 - 3.5 m
SAB
SAB
2.5 - 3.5 m
3
TIME: S3, S4, S5
0 1 0 6 7 1
2.5 - 3.5 m
2
S3 S4 S5 S6 S7 S8
TIME: S3, S4, S5
4
ON
0 0 1 4 5 1 S3
6
3
ON
S1 S2 S3 S4 S5 S6 S7 0 S8 0 ON SAB 0 0 1 10m 8 1 2 3 4 5 6Max: 7 1 SENS: S1, S2 TIME: S3, S4, S5 LUX: S6, S7, 1 S8 1
5
2
S5 S8 LUX: S6, S7, S8 S1 SENS: S2 S1, S3 S2S4TIME: S5 S3, S6S4,S7
1
4
1
S1 S2 S3 S4S1 S5 S6 S2 S7 S8 Detection Range
SENS: S1, S2
3
SAB
w: allledgroup.com
Code
Power
Operating Temperature
AMS001
0.5W
-15°C ~ +60°C
Setting
Min
Max
Detection Distance Time Lux
2m 10sec 10lux
10m 30min ∞
61
LED Panels Altitude - 32W 600x600 Panel.................................................................. 64 Altitude CCT - 32W 600x600 Panel......................................................... 64 Altitude CCT - 32W 1200x300 Panel....................................................... 66 Altitude CCT - 40W 1200x600 Panel....................................................... 67
32W 600x600 LED Panels TP(a) Rated
• 5 Year Guarantee
• Pre-Wired LED Driver & DC Connector
• Single Colour Or CCT Selectable
• White Painted Frame (RAL9016)
• TP(a) Flame Retardant Diffuser
• Back-Lit
• UV Stable
• Emergency Plug & Play Pack*
• Flicker Free Driver
• Plug and Play LED Driver DALI and 0-10V
• UGR <19 Glare Rating
Slimline Design
Pre-Wired LED Driver
TP(a) Flame Retardant Diffuser
Accessories*
Plug & Play Emergency Pack Compatible
30mm
595mm
595mm
APNL632/SBOX Surface Box
APNL600/SUSPKIT Suspension Kit
54mm *Item(s) Sold Separately
64
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
Single Colour Panels Code
Version
Colour Temp
Useful Lumens
Total Lumens
APNL632A/40
Standard
4000K
≤3900lm
≤3900lm
APNL632A/40/EM
Emergency
4000K
≤3900lm
≤3900lm
APNL632A/40/EM/ST
Emergency Self Test
4000K
≤3900lm
≤3900lm
APNL632A/40/DALI
DALI
4000K
≤3900lm
≤3900lm
APNL632A/40/DALI/EM
DALI + Emergency
4000K
≤3900lm
≤3900lm
APNL632A/40/DALI/EM/ST
DALI + Emergency Self Test
4000K
≤3900lm
≤3900lm
APNL632A/40/0-10
0-10V
4000K
≤3900lm
≤3900lm
APNL632A/40/0-10/EM
0-10V + Emergency
4000K
≤3900lm
≤3900lm
APNL632A/40/0-10/EM/ST
0-10V + Emergency Self Test
4000K
≤3900lm
≤3900lm
APNL632A/60
Standard
6000K
≤4000lm
≤4000lm
APNL632A/60/EM
Emergency
6000K
≤4000lm
≤4000lm
APNL632A/60/EM/ST
Emergency Self Test
6000K
≤4000lm
≤4000lm
APNL632A/60/DALI
DALI
6000K
≤4000lm
≤4000lm
APNL632A/60/DALI/EM
DALI + Emergency
6000K
≤4000lm
≤4000lm
APNL632A/60/DALI/EM/ST
DALI + Emergency Self Test
6000K
≤4000lm
≤4000lm
APNL632A/60/0-10
0-10V + Emergency
6000K
≤4000lm
≤4000lm
APNL632A/60/0-10/EM
0-10V
6000K
≤4000lm
≤4000lm
APNL632A/60/0-10/EM/ST
0-10V + Emergency Self Test
6000K
≤4000lm
≤4000lm
Code
Version
Colour Temp
Useful Lumens
Total Lumens
APNL632A/CCT
Standard
CCT
≤4140lm
≤4140lm
APNL632A/CCT/EM
Emergency
CCT
≤4140lm
≤4140lm
APNL632A/CCT/EM/ST
Emergency Self Test
CCT
≤4140lm
≤4140lm
APNL632A/CCT/DALI
DALI
CCT
≤4140lm
≤4140lm
APNL632A/CCT/DALI/EM
DALI + Emergency
CCT
≤4140lm
≤4140lm
APNL632A/CCT/DALI/EM/ST
DALI + Emergency Self Test
CCT
≤4140lm
≤4140lm
APNL632A/CCT/0-10
0-10V
CCT
≤4140lm
≤4140lm
APNL632A/CCT/0-10/EM
0-10V + Emergency
CCT
≤4140lm
≤4140lm
APNL632A/CCT/0-10/EM/ST
0-10V + Emergency Self Test
CCT
≤4140lm
≤4140lm
CCT Selectable Panels
Please refer to LUX charts at the rear of the catalogue for reference purposes. e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
65
32W 1200x300 CCT LED Panel TP(a) Rated
• CCT Selectable (3000K, 4000K, 6500K)
• UGR <19 Glare Rating
• Up to 121lm/W, High Efficiency
• 5 Year Guarantee
• White Painted Single Piece Frame (RAL9003)
• Plug & Play Emergency Pack Available
• TP(a) Flame Retardant Opal Diffuser
• 0-10V Dimming Or DALI Options Available
• UV Stable
• Pre-Wired LED Driver & DC Connector
• Flicker Free
Accessories* 295mm
1195mm
31mm
APNL1232/SBOX Surface Box
APNL600/SUSPKIT Suspension Kit
Code
Version
Colour Temp
Useful Lumens
Total Lumens
APNL1232A/CCT
Standard
CCT
≤3900lm
≤3900lm
APNL1232A/CCT/EM
Emergency
CCT
≤3900lm
≤3900lm
APNL1232A/CCT/EM/ST
Emergency Self Test
CCT
≤3900lm
≤3900lm
APNL1232A/CCT/DALI
DALI
CCT
≤3900lm
≤3900lm
APNL1232A/CCT/DALI/EM
DALI + Emergency
CCT
≤3900lm
≤3900lm
APNL1232A/CCT/DALI/EM/ST
DALI + Emergency Self Test
CCT
≤3900lm
≤3900lm
APNL1232A/CCT/0-10
0-10V
CCT
≤3900lm
≤3900lm
APNL1232A/CCT/0-10/EM
0-10V + Emergency
CCT
≤3900lm
≤3900lm
APNL1232A/CCT/0-10/EM/ST
0-10V + Emergency Self Test
CCT
≤3900lm
≤3900lm
Please refer to LUX charts at the rear of the catalogue for reference purposes.
66
e: sales@allledgroup.com
*Item(s) Sold Separately
t: 0208 841 9000
w: allledgroup.com
40W 1200x600 CCT LED Panel TP(a) Rated
• 5 Year Guarantee
• Pre-Wired LED Driver & DC Connector
• CCT Selectable (3000K, 4000K, 6500K)
• White Painted Single Piece Frame (RAL9003)
• TP(a) Flame Retardant Opal Diffuser
• Back Lit LED Panel
• UV Stable
• Plug & Play Emergency Pack
• Flicker Free
• Plug and Play LED Driver DALI and 0-10V
• UGR <19 Glare Rating
Accessories* 595mm
1195mm
APNL1240/SBOX Surface Box
APNL600/SUSPKIT Suspension Kit
35mm
64mm
Code
Version
Colour Temp
Useful Lumens
Total Lumens
APNL1240A/CCT
Standard
CCT
≤5000lm
≤5000lm
APNL1240A/CCT/EM
Emergency
CCT
≤5000lm
≤5000lm
APNL1240A/CCT/EM/ST
Emergency Self Test
CCT
≤5000lm
≤5000lm
APNL1240A/CCT/DALI
DALI
CCT
≤5000lm
≤5000lm
APNL1240A/CCT/DALI/EM
DALI + Emergency
CCT
≤5000lm
≤5000lm
APNL1240A/CCT/DALI/EM/ST
DALI + Emergency Self Test
CCT
≤5000lm
≤5000lm
APNL1240A/CCT/0-10
0-10V
CCT
≤5000lm
≤5000lm
APNL1240A/CCT/0-10/EM
0-10V + Emergency
CCT
≤5000lm
≤5000lm
APNL1240A/CCT/0-10/EM/ST
0-10V + Emergency Self Test
CCT
≤5000lm
≤5000lm
Please refer to LUX charts at the rear of the catalogue for reference purposes. e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
*Item(s) Sold Separately
67
Battens Q-Nex Plug & Play For Battens ............................................................... 70 Barracuda - IP20 Batten.......................................................................... 72 Barracuda Extreme - IP66 Batten............................................................ 74 Q-Nex Installation Guide.......................................................................... 76
CCT Selectable Wattage Selectable IP20 Rating Multiple Cable Entry Holes 4ft, 5ft and 6ft Versions
F
O
R
B
A T
T
E
N
S
ABAR/EM/ST
Q-NEX PLUG & PLAY 3-HOUR SELF-TEST EMERGENCY PACK • Quick Connection Design • Lithium Battery Technology • Conversion In Seconds • 3 Hours Emergency Run Time • 24 Hours Charge Time With 3 Hour Discharge Time • 5 Year Guarantee • Suitable For Use With Barracuda And Barracuda Extreme Battens
CCT Selectable Wattage Selectable IP66 & IK10 Rating Anti-Corrosive 2ft, 4ft, 5ft and 6ft Versions
FAST, WIRELESS PLUG & PLAY UPGRADES ABAR/MS2IN1
Q-NEX PLUG & PLAY 2-IN-1 MICROWAVE / CORRIDOR SENSOR • Easy Commissioning & Programmable Using DIP Switches • Install In Seconds • Maximum Mounting Height Of Up To 5m • Maximum Detection Range Of Up To 10m • 5 Year Guarantee • Suitable For Use With Barracuda And Barracuda Extreme Battens
Only To Be Used With Compatible Products
Twin/Single High Lumen IP20 CCT & Wattage Selectable LED Batten
• Plug & Play Self Testing Emergency Module Available (ABAR/EMPACK/ST)* • Plug & Play 2-In-1 Fully Programmable Microwave On/Off / Corridor Function Sensor Module Available (ABAR/MS2IN1)* • CCT Selectable (3000K / 4000K / 6500K) • Wattage Selectable • Available in 4ft, 5ft and 6ft Versions
• Drop Down Gear Tray For Easy Installation • Ultra High Efficiency & High Lumen • Dynamically Located Push Terminals • Integrated Besa Mounts • Multiple Cable Entry Holes • 5 Year Guarantee • Suspension Kit Available (APNL600/SUSPKIT)*
4ft IP20
1248mm
1248mm
1180mm
70mm
1518mm
70mm
5ft IP20
1180mm
1180mm 64mm
Multiple Conduit Entry Points & Besa Mounts
64mm
6ft IP20
1818mm
70mm
Seamless Diffuser With High Output
70mm
1480mm 64mm
64mm
Multiple Surface Mount Options
72
Quick Connection Push Terminals
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
Accessories*
ABAR/EM/ST Q-Nex Plug & Play Self Testing Emergency Module
Code
ABAR/MS2IN1 Q-Nex Plug & Play 2-In-1 Microwave / Corridor Function Sensor Module
Version
ABAR/4FT/CCT
IP20 4ft
ABAR/5FT/CCT
IP20 5ft
ABAR/6FT/CCT
IP20 6ft
Wattage
t: 0208 841 9000
w: allledgroup.com
Total Lumens
33W
≤4800lm
≤4800lm
28W
≤4000lm
≤4000lm
23W
≤3400lm
≤3400lm
18W
≤2600lm
≤2600lm
55W
≤8100lm
≤8100lm
47W
≤7000lm
≤7000lm
38W
≤5700lm
≤5700lm
29W
≤3900lm
≤3900lm
64W
≤9800lm
≤9800lm
55W
≤8100lm
≤8100lm
44W
≤6700lm
≤6700lm
33W
≤5000lm
≤5000lm
Please refer to LUX charts at the rear of the catalogue for reference purposes. e: sales@allledgroup.com
Useful Lumens
*Item(s) Sold Separately
73
Twin/Single High Lumen IP66 IK10 CCT & Wattage Selectable Anti-Corrosive LED Batten
• Plug & Play Self Testing Emergency Module Available (ABAR/EMPACK/ST)* • Plug & Play 2-In-1 Fully Programmable Microwave On/Off / Corridor Function Sensor Module Available (ABAR/MS2IN1)* • CCT Selectable (3000K / 4000K / 6500K) • Wattage Selectable • Available in 2ft, 4ft, 5ft and 6ft Versions
• Ultra High Efficiency & High Lumen • IP66, IK10 Rating • Dynamically Located Push Terminals • Integrated Besa Mounts • Drop Down Gear Tray For Easy Installation • 5 Year Guarantee • Suspension Kit Available (APNL600/SUSPKIT)*
2ft IP66
670mm 370mm
1270mm
4ft IP66
1270mm 930mm
78mm
930mm
Stainless Steel (IP66) Stay Open Clips
1570mm 1168mm
78mm
5ft IP66
96mm
96mm
6ft IP66
1870mm 1498mm
78mm
Pre-Drilled Cable Entries & Besa Mounts
78mm
96mm
78mm
96mm
96mm
Integrated Cable Management
74
Fully Polycarbonate Construction
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
Accessories*
ABAR/EM/ST Q-Nex Plug & Play Self Testing Emergency Module
Code
ABAR/MS2IN1 Q-Nex Plug & Play 2-In-1 Microwave / Corridor Function Sensor Module
Version
ABAR/XT2FT/CCT
IP66 2ft
ABAR/XT4FT/CCT
IP66 4ft
ABAR/XT5FT/CCT
IP66 5ft
ABAR/XT6FT/CCT
IP66 6ft
Wattage
Useful Lumens
Total Lumens
18W
≤2430lm
≤2430lm
15W
≤2091lm
≤2091lm
12W
≤1822lm
≤1822lm
10W
≤1426lm
≤1426lm
33W
≤5000lm
≤5000lm
28W
≤4200lm
≤4200lm
23W
≤3500lm
≤3500lm
18W
≤2600lm
≤2600lm
55W
≤8750lm
≤8750lm
47W
≤7600lm
≤7600lm
38W
≤6200lm
≤6200lm
29W
≤4750lm
≤4750lm
64W
≤10100lm
≤10100lm
55W
≤8600lm
≤8600lm
44W
≤7000lm
≤7000lm
33W
≤5300lm
≤5300lm
Please refer to LUX charts at the rear of the catalogue for reference purposes. e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
ABAR/XTCLIP/SS 316L Stainless Steel Clips
*Item(s) Sold Separately
75
Barracuda IP20 ABAR/*FT/CCT Available in 4ft, 5ft & 6ft
BARRACUDA
RANGE
EASY INSTALLATION
Barracuda IP66 ABAR/XT*FT/CCT Available in 2ft, 4ft, 5ft & 6ft
STEP 1
Lock EM Pack into batten and plug into driver using connector
STEP 2
Plug the EM Pack test indicator into the provided slot in the batten
SCAN ME FOR FULL INSTALLATION VIDEO
Q-Nex EM Pack ABAR/EM/ST Plug & Play
BARRACUDA
RANGE
EASY INSTALLATION
Q-Nex Microwave Sensor ABAR/MS2IN1 Plug & Play
STEP 3
Install Microwave Sensor and lock into place in the batten
STEP 4
Connect the Microwave Sensor cables into the batten driver
SCAN ME FOR FULL INSTALLATION VIDEO
Highbay Lights LumoMax - HighBay................................................................................. 80 LumoMax Accessories............................................................................. 81
IP65, CCT & Power Selectable, Ultra-Efficient High Power LED HighBay
• High Efficiency & High Lumen Output • IP65 & IK08 Perfect For Harsh Environments
• Compatible With 110V Site Transformer For Building Sites
• CCT Selectable (3000K / 4000K / 5000K)
• 1-10V Dimmable
• Wattage Selectable
• Emergency Pack Available (AHB/EM/ST)*
• 2m Pre-Wired Tough Rubber Cable
• Plug & Play Microwave Sensor Available (AHB/MS)*
• High Quality Diecast Carbon Black Aluminium Body
• One Programmable Remote Required For Unlimited Amount Of Microwave Sensors (AHB/RMT)* • 5 Year Guarantee
High Quality Diecast Aluminium Body
260mm
38mm
164mm 119mm
100W & 150W
Perfect For Harsh Environments
220mm
2m Pre-Wired Tough Rubber Cable
80
295mm
46mm
167mm 122mm
200W
220mm
CCT & Power Selectable
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
Accessories* Emergency Pack* AHB/EM/ST Self Testing Emergency Pack • Self-Testing • IP65 • Over Temperature Protection, Over Charge Protection, Over Discharge Protection, Short Circuit Protection • Compatible With LumoMax Highbays (AHB/100/CCT, AHB/150/CCT, AHB/200/CCT) • 3 Years Guarantee (Includes Battery) • Battery: Li-ion Battery
Microwave Sensor* AHB/MS Plugin Microwave/Corridor Sensor • IP65 • 2-in-1 Microwave and Corridor Sensor • Daylight Sensor Function, 10 - 500Lux • Up to 12m Max Range, 10 sec - 60 min • Timer Function • Hold time 10 sec - 60 min • Compatible with LumoMax Highbays (AHB/100/CCT, AHB/150/CCT, AHB/200/CCT) • Sensor Remote Programmer Required (AHB/RMT)
Remote Control* AHB/RMT Sensor Remote Programmer • Compatible With LumoMax Highbays (AHB/100/CCT, AHB/150/CCT, AHB/200/CCT)* • Sensor Required (AHB/MS)*
Code
Version
AHB/100/CCT
100W
AHB/150/CCT
150W
AHB/200/CCT
200W
Wattage
Useful Lumens
Total Lumens
100W
≤12,610lm
≤16,210lm
80W
≤10,290lm
≤13,230lm
60W
≤8,235lm
≤10,585lm
150W
≤18,339lm
≤23,479lm
120W
≤15,570lm
≤19,936lm
100W
≤13,702lm
≤17,543lm
200W
≤25,152lm
≤32,208lm
150W
≤19,700lm
≤25,226lm
120W
≤16,645lm
≤21,461lm
Please refer to LUX charts at the rear of the catalogue for reference purposes. e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
*Item(s) Sold Separately
81
Emergency Lighting EMPack - 2W Emergency Pack............................................................... 84 EMPack240 - 7W Emergency Pack......................................................... 85 EvacuLite - 4.8W Bulkhead...................................................................... 86 EvacuLite Mini - 4.2W Bulkhead.............................................................. 87 5-In-1 Blade - Hanging Exit Sign............................................................. 88 SecureBright - Twin Flood Light.............................................................. 89 BrightGuard MT - Steel Exit Sign ........................................................... 90 BrightGuard PC - Polycarbonate Exit Box.............................................. 91 Em-Spot - 1.2W Downlight...................................................................... 92
EMPack
2W Universal Emergency Pack For LED Loads
• >3 Hour Duration
• Up To 150W Load Supported (LED Strip Only)
• Lithium LiFePO4 Battery • Remote Indicator & Mounting Collar
• Can Be Wired As Maintained Or Non-Maintained
• Wide Compatibility, Including 24V LED Strips
• Self Test Option Available (AEM/PACK/ST)
Compatibility Code
Max Watts
Page
ADRCV
150W
218
ADRCV...TD
80W
219
ADRCC
35W
206
ADRCC...TD
35W
206
APNL632
32W
64
APNL1240
40W
67
AFPD
25W
34
AFD010
10W
28
AFD110
10W
30
AFDMR11
9W
27
20mm Cutout Recessed Low Profile LED Indicator
52mm
205mm
42.5mm 25mm
Code
Version
Output
Duration
AEM/PACK
Standard
12-60V DC
3 Hrs
AEM/PACK/ST
Self Testing
12-60V DC
3 Hrs
84
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
EMPack240
7W Universal Emergency Pack For 220-240V LED Loads
• Compatible With 220–240V AC Downlights, Lamps, And Other Lighting Fixtures
• Operation For Continuous Illumination During Power Outages
• Designed For Seamless Integration With A Wide Range Of Lighting Products
• Fully Functional With Dimmable Lighting Products
• Provides Reliable Performance For Approved Fixtures Up To 40 Watts
• Rigorously Tested With All Our Lighting Solutions For Guaranteed Performance And Peace Of Mind*
• Advanced Lithium Battery Technology. Ensures A Minimum Of 3 Hours Emergency
• Battery Can Be Easily Disconnected From The Inverter For Maintenance Or Replacement
158mm
45mm 45mm
20mm Cutout Recessed Low Profile LED Indicator
28mm 41mm
215mm
Code
Version
Output
Duration
AEMPACK/240V
Standard
320V DC
3 Hrs
*Compatibility Table Available Upon Request. Must Be Used With All LED Compatible Items For Warranty Purposes.
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
85
4.8W IP65 IK10 Emergency Bulkhead
• Functions As A Maintained Or Non-Maintained Luminaire
• Marine Grade Tough Polycarbonate Construction - Suitable for Coastal Areas
• 20mm Conduit/Side Entries And Besa Box Mounts
• Universal Self-Adhesive Legends Included
• IK10 Vandal Resistant Design
• >3 Hours Of Continuous Light In Emergency Mode
• Loop-In And Out Push Terminals For Easy Wiring
• Suitable for Wall & Ceiling Mounting
• IP65 Rated - Suitable For Internal & External Applications
• 160lm/w High Lumen Output
69mm
341mm
109mm
Universal Self-Adhesive Legends Included
Code
Lumens
Duration
AEMBH/M
≤160lm
3 Hrs
86
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
4.2W IP65 IK10 Mini Emergency Bulkhead
• Functions As A Maintained Or Non-Maintained Luminaire
• Marine Grade Tough Polycarbonate Construction - Suitable for Coastal Areas
• 20mm Conduit/Side Entries And Besa Box Mounts
• Universal Self-Adhesive Legends Included
• IK10 Vandal Resistant Design
• >3 Hours Of Continuous Light In Emergency Mode
• Loop-In And Out Push Terminals For Easy Wiring
• Suitable for Wall & Ceiling Mounting
• IP65 Rated - Suitable For Internal & External Applications
• 140lm/w High Lumen Output
59mm
230mm
91mm
Universal Self-Adhesive Legends Included
Code
Lumens
Duration
AEMBH/MINI/M
≤140lm
3 Hrs
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
87
0.8W 5-In-1 Maintained Emergency Hanging Exit Sign
• 20mm Cable Entries
• >3 Hours Of Continuous Light In Emergency Mode
• Loop-In And Out Push Terminals For Easy Wiring
• Wall & Ceiling Mounting Kits Available*
• Down Arrow Included. Different Exit Sign Plates Available*
• Supplied With Down Legend
• Functions As A Maintained Luminaire
Accessories*
AEMBLADE/SKIT Suspension Mounting Kit AEMBLADE/RKIT Recessed Mounting Kit
AEMBLADE/WKIT Wall Mounting Kit
44mm
334mm
AEMBLADE/UP Up Arrow Exit Sign Plate
212mm
AEMBLADE/L/R Left/Right Arrow Exit Sign Plate
299mm
Code
Lumens
Duration
AEMBLADE/M
≤36lm
3 Hrs *Item(s) Sold Separately
88
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
2.5W IP65 IK10 Emergency Twin Flood Light
• Marine Grade Tough Polycarbonate Construction - Suitable for Coastal Areas
• Functions As A Non-Maintained Luminaire • 20mm Conduit/Side Entries • IK10 Vandal Resistant Design • Loop-In And Out Push Terminals For Easy Wiring
• Suitable For Wall & Ceiling Mounting
300mm
• IP65 Rated - Suitable For Internal & External Applications
• >3 Hours Of Continuous Light In Emergency Mode
300mm
57mm
Code
Lumens
Duration
AEMTWIN/NM
≤360lm
3 Hrs
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
89
3.5W Steel Maintained & Non-Maintained Exit Sign
• Functions As A Maintained Or Non-Maintained Luminaire
• Loop-In And Out Push Terminals For Easy Wiring
• LEDs Directionally Illuminate The Door Way
• Down Arrow Included. Different Exit Sign Plates Available*
• 20mm Conduit/Side Entries And Besa Box Mounts
• >3 Hours Of Continuous Light In Emergency Mode
392.5mm
197mm
52mm
Accessories*
AEMBOX/R Right Arrow Exit Sign Plate
AEMBOX/UP Up Arrow Exit Sign Plate
AEMBOX/L Left Arrow Exit Sign Plate
Code
Lumens
Duration
AEMBOX/M/M
≤90lm
3 Hrs *Item(s) Sold Separately
90
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
4W Polycarbonate Maintained & Non-Maintained Exit Box
• Functions As A Maintained Or Non-Maintained Luminaire
• Loop-In And Out Push Terminals For Easy Wiring
• LEDs Directionally Illuminate The Door Way
• Legends Included
• 12mm Conduit Entries And Besa Box Mounts
• >3 Hours Of Continuous Light In Emergency Mode
330mm
186mm
30mm
Exit Sign Can Be Rotated For Maximum Flexibility
Code
Lumens
Duration
AEMBOXSL/M
≤95lm
3 Hrs
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
91
1.2W LED Non-Maintained Emergency Downlight
• 1.2W High Lumen Output LED
• Non-Maintained
• Polar White, Anthracite Grey & Carbon Black Bezels Included
• Integrated Charging Indicator • Advanced LiFePO4 Battery Technology
• >3 Hours Emergency Duration
• 5 Year Guarantee
Twist & Lock Bezels Included
265mm 93mm
165mm 23mm 30mm
200mm Cable Length 32-55mm Cut Out
Carbon Black
22mm 60mm
Anthracite Grey
Polar White
Code
Lumens
Duration
AEM/SPOT
≤120lm
3 Hrs
92
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
93
Floodlights NEW
SpeedLock308 ......................................................................................... 99 Q-Nex Plug & Play For Floodlights ......................................................... 100 Osprey - Floodlights................................................................................. 101 Skylancer - Floodlights............................................................................ 103
Build On Ground
Less Time On Ladder
Fewer Holes In Wall
Quicker Install Time
Floodlight Fitting Made Simpler! For Use With WISKA® COMBI® 308
In Partnership With
Floodlight Fitting Made Simpler! 1
2
3
Take out locks on WISKA® COMBI® 308
Put Speedlock308 quicklock nuts into WISKA® COMBI® 308 lid
Attach floodlight onto SpeedLock308
4
5
6
Put floodlight cable into WISKA® COMBI® 308
Attach WISKA® COMBI® 308 onto mounted wall bracket
Join floodlight cable with mains electricity
7
8
9
Connect WISKA® COMBI® 308 lid
Place Speedlock308 and floodlight combination onto WISKA® COMBI® 308
Turn quick-lock nuts
Universal Floodlight Quick Install Bracket
In Partnership With
• WISKA® COMBI® 308 Compatible
• Less Drilled Holes Needed In Mounting Wall
• Designed For All LED Floodlights*
• Tool-Less Quick-Lock Nuts
• More Work Done At Ground Level, Spend Less Time On Ladder
• Jobs Completed Safer And Quicker
53mm
116mm
148mm
Cable Management
Quick-Lock Nuts
SCAN QR CODE FOR PRODUCT GUIDE VIDEO
Code ASPEED308/BK
Material Polycarbonate *Item(s) Sold Separately
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
99
F O R
F L O O D L I G H T S
Featuring Manual Override Sensor
Q-Nex PIR Sensor AFL/PIR/BK
IP65 Rated Up to 10m Detection Range Easily & Fully Programmable Manual Override Function With Indicator
Q-Nex Photocell AFL/PCELL/BK
IP65 Rated Automatic Dusk-To-Dawn Sensor To Be Used With Compatible Products
Carbon Black IP65 CCT Selectable Floodlight
• Q-Nex Plug & Play Technology PIR Or Photocell Sensor Accessories*
• 1m Pre-Wired Tough Rubber Cable
• IP65 Rated
• Prismatic Toughened Glass
• CCT Selectable (3000K/4000K/6000K)
• Slimline Diecast Carbon Black Aluminium Body
• Easy-Install Angled Bracket
Available In Four Sizes
AFLD10BK/CCT 10W
AFLD20BK/CCT 20W
AFLD30BK/CCT 30W
AFLD50BK/CCT 50W
Accessories*
AFL/PCELL/BK Q-Nex Plug & Play Carbon Black IP65 Photocell
AFL/PIR/BK Q-Nex Plug & Play Carbon Black IP65 PIR Sensor Version
Colour Temp
AFLD10BK/CCT
10W
CCT
≤914lm
≤971lm
AFLD20BK/CCT
20W
CCT
≤1966lm
≤2146lm
AFLD30BK/CCT
30W
CCT
≤3178lm
≤3542lm
AFLD50BK/CCT
50W
CCT
≤5112lm
≤5832lm
Code
Useful Lumens
Total Lumens
*Item(s) Sold Separately
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
101
Available In 3 Sizes
IP65, IK06, CCT & Wattage Selectable, High Power Flood Light
• High Efficiency & High Lumen Output
• Prismatic Toughened Glass
• IP65 & IK06 Perfect for Harsh Environments
• High Quality Diecast Carbon Black
• Low Profile Design To Reduce Wind Drag
• Aluminium Body
• CCT Selectable (3000K / 4000K / 6500K) • Wattage Selectable
• Compatible With 110V Site Transformer For Building Sites
• 1.3m Pre-Wired Tough Rubber Cable
• 5 Year Guarantee
• Easy-Install Angled Bracket
Pre-Wired 1.3m Cable
CCT & Wattage Selection
Code
Version
AFL100BK/CCT
100W
AFL150BK/CCT
150W
AFL200BK/CCT
e: sales@allledgroup.com
200W
t: 0208 841 9000
w: allledgroup.com
Easy-Install Angled Bracket
Prismatic Tough Glass
Wattage
Useful Lumens
Total Lumens
100W
≤12,000lm
≤14,200lm
80W
≤9,620lm
≤11,360lm
60W
≤7,210m
≤8,520lm
150W
≤16,660lm
≤19,750lm
135W
≤15,000lm
≤17,780lm
120W
≤13,330lm
≤15,800lm
200W
≤22,940lm
≤27,360lm
180W
≤20,650lm
≤24,630lm
160W
≤18,355lm
≤21,890lm
103
Outdoor Lighting Floyd2 - Wall/Step Light........................................................................... 106 Excalibur2 - 6W Spike Light..................................................................... 107 Sabre2 - GU10 Spike Light...................................................................... 108 Gladius - 3W Spike Light......................................................................... 109 Morph - Wall Light ................................................................................... 111 Tubular - Wall Light .................................................................................. 112 Outdoor Light Accessories...................................................................... 113
3.4W IP65 CCT Carbon Black Surface Mount Exterior Wall/Step Light
• Surface Installation
• ≤120lm/W
• CCT Selectable (3000K / 4000K / 6500K)
• Loop-In and Loop-Out 20mm Cable Entries
• IP65 Rated
• 120lm High Efficiency LEDs
• Two 20mm Cable Entries
• Marine Grade Polycarbonate Construction
• Suitable For Coastal Areas
CCT Comparison
28mm
80mm
229mm
3000K
4000K
6500K Code
Colour Temp
Useful Lumens
Total Lumens
ABLS240/CCT
CCT
≤413lm
≤413lm
106
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
6W IP65 Carbon Black LED Garden Wall/Spike Light
• IP65 Rating
• Metal Gland Pre-Wired To 2.5m Of Toughened Rubber Cable
• Diamond Halogen Style Lens • Detachable Spike For Surface Mounting • Carbon Black Powder Coat
• Interchangeable Coloured Glass Filters Available (Sold Separately)
• Aluminium Body Featuring Anti-Glare Cowl
270mm
95mm
Ø60mm
122mm 109mm
Anti-Glare Cowl
Detachable Spike
Colour Filter Accessories* For More Info See Page 47
AGF/SPK/***
Code
Colour Temp
Useful Lumens
Total Lumens
ASPK600/30
3000K
≤550lm
≤550lm
ASPK600/40
4000K
≤600lm
≤600lm *Item(s) Sold Separately
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
107
GU10 Carbon Black IP65 Garden Wall/Spike Light
• IP65 Rating
• Diecast Aluminium Body
• GU10 Lamp Holder (GU10 Sold Separately)
• Metal Gland Pre-Wired To 2.5m Of Toughened Rubber Cable
• Wall & Surface Mountable
• Interchangeable Coloured Glass Filters Available (Sold Separately)
• Carbon Black Powder Coat Finish
60mm
78mm
320mm
5mm Tempered Glass
Detachable Spike
Colour Filter Accessories*
Compatible GU10 Lamps*
For More Info See Page 47
For More Info See Page 43
AGU470D Caterham
AGF/SPK/***
Code ASPKGU10A/BK
AGU501D Morgan
AGU700D Jaguar
Wattage
Finish
1x 35W GU10
Carbon Black *Item(s) Sold Separately
108
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
3W 350mA IP65 RA90 Anti-Glare Carbon Black Spike Luminaire
• Glare Reducing Honeycomb & Lens
• Colour Rendering Index 90+
• 3W Cree COB LED
• Cast Aluminium Construction & Polymer Spike
• Pre-Flexed To 2m Of Cable
• Dims With Triac Dimmable LED Driver*
• Detachable Spike For Surface Mounting
• 350mA Constant Current (Series Wiring)
• Carbon Black Powder Coat Finish
250mm 92mm 40mm
158mm
Glare Reducing Honeycomb & Lens
Pre-Flexed To 2m Of Cable
See Page 205 For Series Wiring 350mA Drivers Code
Colour Temp
Useful Lumens
Total Lumens
ASPK3CC/30
3000K
≤175lm
≤175lm *Item(s) Sold Separately
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
109
110
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
14W IP65 CCT Selectable Decorative Bi-Directional Wall Luminaire
Adjustable Beam Angle
• IP65 Rating
• Diecast Aluminium Body
• CCT Selectable (3000K / 4000K / 6000K)
• Wago Connectors Included
• Adjustable Beam Angle Via Adjustment Doors (0-120°)
• White Finish • Aluminium Accessory Cover Available*
Accessories*
Bi-Directional Light
Adjustable Beam Angle 0 - 120°
150mm
AWL10/AL/ACC Aluminium Cover
68mm 96.5mm
Code
Colour Temp
Useful Lumens
Total Lumens
AWL10WH/CCT
CCT
≤770lm
≤770lm *Item(s) Sold Separately
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
111
GU10 Bidirectional Wall Light
• IP65 Rating
• Cast Aluminium Wall Bracket
• GU10 (Lamps Sold Separately)
• Loop-In Loop-Out Jumbo Sized Integrated Connection Box With 2x 20mm Large Grommets
• Carbon Black, Polar White Or Brushed Aluminium Finishes Available
• Easy Installation
Available Finishes*
AWLGU/AL/022 Brushed Aluminium
AWLGU/BK/022 Carbon Black
AWLGU/WH/022 Polar White Ø65mm
Compatible GU10 Lamps*
153mm
For More Info See Page 43
AGU470D Caterham Code
AGU501D Morgan
AGU700D Jaguar
100mm
Lamp Holder
Finish
GU10
Brushed Aluminium
AWLGU/BK/022
GU10
Carbon Black
AWLGU/WH/022
GU10
Polar White
AWLGU/AL/022
*Item(s) Sold Separately
112
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
Outdoor Light Accessories
Black Aluminium Spike Accessory
IDC Technology 2 Hole Jelly Filled Cable Crimp†
• Black Powdercoat Finish
• IDC Technology
• Cast Aluminium
• 2 Hole Jelly Filled Cable Crimp Connectors
• For Use With Floodlight Range & Spike Lights
• Compact Design
Code
Description
ALASPK01
Black Aluminium Spike Accessory
AJKC100PACK
IDC Technology 2 Hole Jelly Filled Cable Crimp † When using double insulated cable extra waterproofing protection is required
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
113
Marker, Ground & Low Level Lights Beam - 1W 12V Marker Light................................................................... 116 Valiant - 1.2W Marker Light...................................................................... 117 Micro - 1W 350mA Marker Light.............................................................. 118 Mini - 1W 350mA Marker Light................................................................ 120 Midi - 1W 350mA Marker Light................................................................ 122 Vector - Adjustable 350mA Mini Spotlight.............................................. 124 Halo - 1W 350mA Marker Light................................................................ 125 Britannia - 1W 350mA Ground Light........................................................ 126 Pathfinder - 1W 350mA Low Level Light................................................. 127 Noble 1 - 1W 350mA Ground Light.......................................................... 128 Noble 3 - 3W 350mA Ground Light.......................................................... 130 Noble 7 - 7W 350mA Ground Light.......................................................... 132 Marine 1 - 1W 350mA Ground Light........................................................ 134 Marine 3 - 3W 350mA Ground Light........................................................ 135 Marine 7 - 7W 350mA Ground Light........................................................ 136 Polycarbonate Mounting Sleeves............................................................ 137 Oxford - 1W 350mA Low Level Light....................................................... 138 Sloane Classic - 1W 350mA Low Level Light.......................................... 139 Sloane Square - 1W 350mA Low Level Light.......................................... 140 Sloane Linear - 1W 350mA Low Level Light........................................... 141 Dawn - 1W 350mA Eyelid Marker Light................................................... 142 Trafalgar - 3W CCT Selectable Low Level Light..................................... 143
1W 12V Marker Light
• 5 Year Guarantee
• Prismatic Lens
• Dimmable When Used With Our 12V CV Dimmable LED Drivers†
• Max. DC Loom Length 20m (0.75mm2 Cable)
• Quality Aluminium Construction • 1.5m Pre-Wired Cable
• Load: 1…20 PCS X 1W LED (ADRCV1225TD) Dimmable Option | 1…20 PCS X 1W LED (ADRCV1230) NON-Dimmable Option
Available Finishes*
25mm
Ø37.5mm
AML12V/AL Aluminium
AML12V/BLK Carbon Black
Ø28mm
AML12V/WH Polar White Code
Finish
Colour Temp 3000K
Useful Lumens ≤90lm
Total Lumens ≤90lm ≤110lm
AML12V/AL/30
Aluminium
AML12V/AL/40
Aluminium
4000K
≤110lm
AML12V/BLK/30
Carbon Black
3000K
≤90lm
≤90lm
AML12V/BLK/40
Carbon Black
4000K
≤110lm
≤110lm
AML12V/WH/30
Polar White
3000K
≤90lm
≤90lm
AML12V/WH/40
Polar White
4000K
≤110lm
≤110lm
*Item(s) Sold Separately. † When Used With a Suitable ALL LED Dimmable Driver
116
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
1.2W 240V IP67 Stainless Steel Marker Light
• 304 Stainless Steel Construction Rated To IP67
Featuring
• Featuring AquaStop Technology • 1.2W LED Array • 220-240V AC Mains Operating Voltage
This product is equipped with All LED’s technology which prevents water gaining entry into the luminaire via the cable
• Driver Over Rated At 2 Metric Tonnes When Used In Mounting Sleeve • Ultra Tough Polycarbonate Optics • Mounting Sleeve Included • 2.5m Pre-Wired Though Rubber Cable
68mm
Ø40mm
Ø30mm
Ø40mm
37mm
Cut Out 32-35mm
Code
Finish
AGLM01/SS/30
Stainless Steel
e: sales@allledgroup.com
t: 0208 841 9000
Colour Temp
Useful Lumens
Total Lumens
3000K
≤20lm
≤23lm
w: allledgroup.com
117
1W 350mA IP44 Marker Light
• IP44 Rating
• Matte White Paintable Finish+
• 1W LED
• Dimmable With A Dimmable LED Driver†
• Anti-Glare Trimless Ultra Slim Profile
• 350mA Constant Current (Series Wiring)
• Frosted Glass For A Soft Edge Beam
• 2m Pre-Wired Cable
• Interchangeable Bezels Available*
Available Finishes*
AMKR012AL Brushed Aluminium
Ø16mm
Ø12mm
21mm
AMKR012WH Polar White
AMKR012AL/30
Brushed Aluminium
Colour Temp 3000K
AMKR012AL/40
Brushed Aluminium
4000K
≤70lm
≤70lm
AMKR012WH/30
Polar White
3000K
≤60lm
≤60lm
AMKR012WH/40
Polar White
4000K
≤70lm
≤70lm
Code
Finish
Useful Lumens ≤60lm
Total Lumens ≤60lm
*Item(s) Sold Separately. † When Used With a Suitable ALL LED Dimmable Driver. + Applies to White Finish Models Only
118
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
Accessories* Bezels* AMKR012BZ/AB Antique Brass^
AMKR012BZ/BLK Carbon Black
AMKR012BZ/BB Brushed Brass^
AMKR012BZ/COP Polished Copper^
See Page 205 For Series Wiring 350mA Drivers *Item(s) Sold Separately. ^ Bezel Not Recommended For Outdoor Use
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
119
1W 350mA IP44 Marker Light
• IP44 Rating
• Ultra Slim Profile
• 1W LED
• Dimmable With A Dimmable LED Driver†
• Anti-Glare Design
• 350mA Constant Current (Series Wiring)
• Clear Glass Provides A Sharp Edged Beam For Strong Architectural Effect
• 2m Pre-Wired Cable
• Interchangeable Bezels Available*
Available Finishes*
Ø20mm
Ø30mm
25mm
AMKR020AL Brushed Aluminium
AMKR020WH Polar White
AMKR020AL/30
Brushed Aluminium
Colour Temp 3000K
AMKR020AL/40
Brushed Aluminium
4000K
≤70lm
AMKR020AL/BL
Brushed Aluminium
Blue
≤25lm
≤25lm
AMKR020WH/30
Polar White
3000K
≤60lm
≤60lm
AMKR020WH/40
Polar White
4000K
≤70lm
≤70lm
AMKR020WH/BL
Polar White
Blue
≤25lm
≤25lm
Code
Finish
Useful Lumens ≤60lm
Total Lumens ≤60lm ≤70lm
*Item(s) Sold Separately. † When Used With a Suitable ALL LED Dimmable Driver.
120
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
Accessories* Bezels* AMKR020BZ/AB Antique Brass^
AMKR020BZ/BLK Carbon Black
AMKR020BZ/BB Brushed Brass^
AMKR020BZ/COP Polished Copper^
Trimless Plaster-in Kit*
AMKR020/BAFWH Matte White Baffled Trimless Kit 38mm Cutout (Bezel & Luminaire Required)
See Page 205 For Series Wiring 350mA Drivers *Item(s) Sold Separately. ^ Bezel Not Recommended For Outdoor Use
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
121
1W 350mA IP65 Marker Light
• IP65 Rating
• Interchangeable Bezels Available*
• 1W LED
• Dimmable with Dimmable LED Driver†
• Diamond Cut Lens
• 350mA Constant Current (Series Wiring)
• Matte White Paintable Finish
• Driveover Rated At 2 Metric Tonnes When Used In 32mm Mounting Sleeve (AGL/MS032)*
• Flush Toughened Glass
• 1m Pre-Wired Cable
• Cree Diode Inside +
Available Finishes*
AMKR032AL Matte Brushed Aluminium
AMKR032WH Polar White
AMKR032AL/30
Matte Brushed Aluminium
Colour Temp 3000K
AMKR032AL/40
Matte Brushed Aluminium
4000K
≤95lm
AMKR032AL/BL
Matte Brushed Aluminium
Blue
≤40lm
≤40lm
AMKR032WH/30
Polar White
3000K
≤85lm
≤85lm
AMKR032WH/40
Polar White
4000K
≤95lm
≤95lm
AMKR032WH/BL
Polar White
Blue
≤40lm
≤40lm
Code
Finish
Useful Lumens ≤85lm
Total Lumens ≤85lm ≤95lm
*Item(s) Sold Separately. † When Used With a Suitable ALL LED Dimmable Driver. + Applies to White Finish Models Only
122
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
Accessories* Bezels* AMKR032BZ/AB Antique Brass^
AMKR032BZ/BLK Carbon Black
AMKR032BZ/COP Polished Copper^
AMKR032BZ/BB Brushed Brass^
See Page 205 For Series Wiring 350mA Drivers *Item(s) Sold Separately. ^ Bezel Not Recommended For Outdoor Use
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
123
3W 350mA IP44 Adjustable Spotlight
• IP44 Rating
• CRI 90+
• 3W COB LED
• 350mA Constant Current (Series Wiring)
• Baffled Anti-Glare Design
• Dimmable With Dimmable LED Driver†
• 25° Max Tilt Angle
• 1m Pre-Wired Cable
• Diamond Cut Lens
Available Finishes*
31mm
25°
AMKR044AL Matte Brushed Aluminium
AMKR044WH Polar White
Ø52mm
See Page 205 For Series Wiring 350mA Drivers
AMKR044AL/30
Matte Brushed Aluminium
Colour Temp 3000K
AMKR044AL/40
Matte Brushed Aluminium
4000K
≤230lm
AMKR044WH/30
Polar White
3000K
≤210lm
≤210lm
AMKR044WH/40
Polar White
4000K
≤230lm
≤230lm
Code
Finish
Useful Lumens ≤210lm
Total Lumens ≤210lm ≤230lm
*Item(s) Sold Separately. † When Used With a Suitable ALL LED Dimmable Driver.
124
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
1W 350mA IP65 Marker Light
• IP65 Rating
• Toughened Flush Optics
• 1W LED
• 350mA Constant Current (Series Wiring)
• Unique Anti-Glare Optics
• Dimmable With Dimmable LED Driver†
• 316L Stainless Steel
• 1m Pre-Wired Cable
• Suitable For In Ground Use
Ø44mm
Ø35mm
Available Finishes*
27mm
AGLH035SS Stainless Steel 316L
AGLH035WH Polar White
See Page 205 For Series Wiring 350mA Drivers
AGLH035SS/27
Marine Grade Stainless Steel 316L
Colour Temp 2700K
AGLH035SS/30
Marine Grade Stainless Steel 316L
3000K
≤24lm
AGLH035SS/40
Marine Grade Stainless Steel 316L
4000K
≤24lm
≤24lm
AGLH035WH/27
Polar White
2700K
≤21lm
≤21lm
Code
Finish
Useful Lumens ≤21lm
Total Lumens ≤21lm ≤24lm
AGLH035WH/30
Polar White
3000K
≤24lm
≤24lm
AGLH035WH/40
Polar White
4000K
≤24lm
≤24lm
*Item(s) Sold Separately. † When Used With a Suitable ALL LED Dimmable Driver.
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
125
ou
nt i
ng Sleeve
In
M
1W 350mA IP67 Baffle Honeycomb Ground Light
c lu ded
• IP67 Rating
• Toughened Flush Glass
• 1W LED
• 350mA Constant Current (Series Wiring)
• Glare-Reducing Honeycomb
• Dimmable With Dimmable LED Driver†
• 316L Stainless Steel
• 15° Narrow Beam Angle
• Drive Over Rated (2 Metric Tonnes) When Installed With Included Mounting Sleeve
• Robust Metal Cable Gland • 2m Pre-Wired Tough Rubber Cable
Available Finishes*
AGLX020SS Stainless Steel 316L
Ø27mm
Ø20mm
32mm
AGLX020WH Polar White
See Page 205 For Series Wiring 350mA Drivers
Stainless Steel 316L
Colour Temp 2700K
AGLX020SS/30
Stainless Steel 316L
3000K
≤77lm
≤77lm
AGLX020SS/40
Stainless Steel 316L
4000K
≤81lm
≤81lm
Code
Finish
AGLX020SS/27
Useful Lumens ≤76lm
Total Lumens ≤76lm
AGLX020WH/27
Polar White
2700K
≤76lm
≤76lm
AGLX020WH/30
Polar White
3000K
≤77lm
≤77lm
AGLX020WH/40
Polar White
4000K
≤81lm
≤81lm
*Item(s) Sold Separately. † When Used With a Suitable ALL LED Dimmable Driver.
126
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
1W 350mA IP65 Low Level Light
• IP65 Rating
• 350mA Constant Current (Series Wiring)
• 1W LED
• Dimmable With Dimmable LED Driver†
• Anti-Glare Lighting Solution • Unidirectional & Bi-Directional Options
• Driveover Rated At 2 Metric Tonnes When Used In 32mm Mounting Sleeve (AGL/MS032)*
• Ideal for Stair & Path Lighting
• 1m Pre-Wired Cable
Available Options*
Ø32mm
APF032AL/01 Unidirectional
33mm
Ø37mm
33mm
Ø37mm
Ø32mm
APF032AL/02 Bi-Directional
See Page 205 For Series Wiring 350mA Drivers
Matte Brushed Aluminium
Colour Temp 3000K
Useful Lumens ≤80lm
Total Lumens ≤80lm
Matte Brushed Aluminium
4000K
≤90lm
≤90lm
Matte Brushed Aluminium
3000K
≤80lm
≤80lm
4000K
≤90lm
≤90lm
Code
Version
Finish
APF032AL/01/30
Unidirectional
APF032AL/01/40
Unidirectional
APF032AL/02/30
Bi-Directional
APF032AL/02/40
Bi-Directional
Matte Brushed Aluminium
*Item(s) Sold Separately. † When Used With a Suitable ALL LED Dimmable Driver.
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
127
1W 350mA IP65 Matte Brushed Aluminium Ground Light
• IP65 Rating
• 350mA Constant Current (Series Wiring)
• 1W LED
• Dimmable With Dimmable Driver†
• Glare-Reducing Baffle Design
• Narrow Beam Angle
• Driveover Rated At 2 Metric Tonnes When Used In 32mm Mounting Sleeve (AGL/MS032)*
• Toughened Flush Glass
• Interchangeable Bezels Available*
• 1m Pre-Wired Cable
• Slim Bezel
37mm
37mm
32mm
Matte Brushed Aluminium
Colour Temp 3000K
Useful Lumens ≤80lm
Total Lumens ≤80lm
Matte Brushed Aluminium
4000K
≤90lm
≤90lm
Code
Finish
AGL032AL/30 AGL032AL/40
*Item(s) Sold Separately. † When Used With a Suitable ALL LED Dimmable Driver.
128
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
Accessories* Bezels* AGL032BZ/BLK Carbon Black
AGL032BZ/AB Antique Brass^
AGL032BZ/BB Brushed Brass^
AGL032BZ/WH Polar White
AGL032BZ/COP Polished Copper^
See Page 205 For Series Wiring 350mA Drivers *Item(s) Sold Separately. ^ Bezel Not Recommended For Outdoor Use
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
129
3W 350mA IP65 Matte Brushed Aluminium Ground Light
• IP65 Rating
• Narrow Beam Angle
• 3W COB LED
• Toughened Flush Glass
• Featuring AquaStop Technology
• Slim Bezel
• Glare-Reducing Baffle Design
• 350mA Constant Current (Series Wiring)
• Driveover Rated At 2 Metric Tonnes When Used in 48mm Mounting Sleeve (AGL/MS048)*
• Dimmable With Dimmable Driver† • 1m Pre-Wired Cable
• Interchangeable Bezels Available*
57mm
56mm
48mm
Featuring This product is equipped with All LED’s technology which prevents water gaining entry into the luminaire via the cable
AGL045AL/30
Matte Brushed Aluminium
Colour Temp 3000K
AGL045AL/40
Matte Brushed Aluminium
4000K
Code
Finish
Useful Lumens ≤165lm
Total Lumens ≤165lm
≤190lm
≤190lm
*Item(s) Sold Separately. † When Used With a Suitable ALL LED Dimmable Driver.
130
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
Accessories* Bezels* AGL045BZ/BLK Carbon Black
AGL045BZ/AB Antique Brass^
AGL045BZ/BB Brushed Brass^
AGL045BZ/WH Polar White
AGL045BZ/COP Polished Copper^
See Page 205 For Series Wiring 350mA Drivers *Item(s) Sold Separately. ^ Bezel Not Recommended For Outdoor Use
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
131
7W 350mA IP65 Matte Brushed Aluminium Ground Light
• IP65 Rating
• Narrow Beam Angle
• 7W COB LED
• Toughened Flush Glass
• Featuring AquaStop Technology
• Slim Bezel
• Glare-Reducing Baffle Design
• 350mA Constant Current (Series Wiring)
• Driveover Rated At 2 Metric Tonnes When Used in 60mm Mounting Sleeve (AGL/MS060)*
• Dimmable With Dimmable Driver† • 1m Pre-Wired Cable
• Interchangeable Bezels Available*
75mm
70mm
60mm
Featuring This product is equipped with All LED’s technology which prevents water gaining entry into the luminaire via the cable
AGL060AL/30
Matte Brushed Aluminium
Colour Temp 3000K
AGL060AL/40
Matte Brushed Aluminium
4000K
Code
Finish
Useful Lumens ≤410lm
Total Lumens ≤410lm
≤440lm
≤440lm
*Item(s) Sold Separately. † When Used With a Suitable ALL LED Dimmable Driver.
132
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
Accessories* Bezels* AGL060BZ/BLK Carbon Black
AGL060BZ/AB Antique Brass^
AGL060BZ/BB Brushed Brass^
AGL060BZ/WH Polar White
AGL060BZ/COP Polished Copper^
See Page 205 For Series Wiring 350mA Drivers *Item(s) Sold Separately. ^ Bezel Not Recommended For Outdoor Use
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
133
1W 350mA IP67 316L Stainless Steel Baffle Honeycomb Ground Light
• IP67 Rating
• Toughened Flush Glass
• 1W LED
• Slim Bezel
• Featuring AquaStop Technology • Glare-Reducing Honeycomb & Baffle Design
• Tough Rubber Robust Cable For Extreme Outdoor Use
• 316L Marine Grade Stainless Steel
• 350mA Constant Current (Series Wiring)
• Drive Over Rated (2 Metric Tonnes) When Used In 32mm Mounting Sleeve (AGL/MS032)*
• Dimmable With Dimmable LED Driver†
Ø37mm
Ø32mm
• 2m Pre-Wired Cable
37.5mm
See Page 205 For Series Wiring 350mA Drivers
AGL032SS/27
316L Stainless Steel
Colour Temp 2700K
AGL032SS/30
316L Stainless Steel
3000K
≤80lm
≤80lm
AGL032SS/40
316L Stainless Steel
4000K
≤85lm
≤85lm
Code
Finish
Useful Lumens ≤70lm
Total Lumens ≤70lm
*Item(s) Sold Separately. † When Used With a Suitable ALL LED Dimmable Driver
134
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
3W 350mA IP67 316L Stainless Steel Baffle Honeycomb Ground Light
• IP67 Rating
• Toughened Flush Glass
• 3W COB LED
• Slim Bezel
• Featuring AquaStop Technology • Glare-Reducing Honeycomb & Baffle Design
• Tough Rubber Robust Cable For Extreme Outdoor Use
• 316L Marine Grade Stainless Steel
• 350mA Constant Current (Series Wiring)
• Drive Over Rated (2 Metric Tonnes) When Used In 48mm Mounting Sleeve (AGL/MS048)*
• Dimmable With Dimmable LED Driver†
Ø56mm
Ø48mm
• 1m Pre-Wired Cable
55mm
See Page 205 For Series Wiring 350mA Drivers
AGL045SS/27
316L Stainless Steel
Colour Temp 2700K
AGL045SS/30
316L Stainless Steel
3000K
≤175lm
≤175lm
AGL045SS/40
316L Stainless Steel
4000K
≤190lm
≤190lm
Code
Finish
Useful Lumens ≤150lm
Total Lumens ≤150lm
*Item(s) Sold Separately. † When Used With a Suitable ALL LED Dimmable Driver
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
135
7W 350mA IP67 316L Stainless Steel Baffle Honeycomb Ground Light
• IP67 Rating
• Toughened Flush Glass
• 7W COB LED
• Slim Bezel
• Featuring AquaStop Technology • Glare-Reducing Honeycomb & Baffle Design
• Tough Rubber Robust Cable For Extreme Outdoor Use
• 316L Marine Grade Stainless Steel
• 350mA Constant Current (Series Wiring)
• Drive Over Rated (2 Metric Tonnes) When Used In 60mm Mounting Sleeve (AGL/MS060)*
• Dimmable With Dimmable LED Driver†
Ø70mm
Ø60mm
• 1m Pre-Wired Cable
73mm
See Page 205 For Series Wiring 350mA Drivers
AGL060SS/27
316L Stainless Steel
Colour Temp 2700K
AGL060SS/30
316L Stainless Steel
3000K
≤265lm
≤265lm
AGL060SS/40
316L Stainless Steel
4000K
≤280lm
≤280lm
Code
Finish
Useful Lumens ≤240lm
Total Lumens ≤240lm
*Item(s) Sold Separately. † When Used With a Suitable ALL LED Dimmable Driver
136
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
Mounting Sleeves For Driveover Rated Lights
AGL/MS032
AGL/MS048
AGL/MS060
32mm Mounting Sleeve
48mm Mounting Sleeve
60mm Mounting Sleeve
Internal Diameter: 30.5mm
Internal Diameter: 49mm
Internal Diameter: 58mm
External Diameter: Ø35mm / Ø38mm
External Diameter: Ø53mm / Ø57mm
External Diameter: Ø64mm
Height: 90mm
Height: 90mm
Height: 90mm
For Use With
For Use With
For Use With
Midi Range (AMKR032)
Noble 3 Range (AGL045AL)
Noble 7 Range (AGL060AL)
Pathfinders (APF032AL)
Marine 3 Range (AGL045SS)
Marine 7 Range (AGL060SS)
Noble 1 (AGL032AL) Marine 1 (AGL032SS)
Code
Size
Material
Driveover Rating
AGL/MS032
32mm
Polycarbonate
2 Metric Tonnes
AGL/MS048
48mm
Polycarbonate
2 Metric Tonnes
AGL/MS060
60mm
Polycarbonate
2 Metric Tonnes
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
137
1W LED 350mA IP65 Round Low Level Light
Angled Light Direction
• IP65 Rating
• Ultra Slim Profile
• Low Glare Low Level Lighting
• 350mA Constant Current (Series Wiring)
• Frosted Glass For A Soft Edge Beam
• Dimmable With Dimmable LED Driver†
• Ideal For Wall, Stair & Plinth Lighting
• 1m Pre-Wired Cable
ALRD032AL Brushed Aluminium
ALRD032PC Polished Chrome
Ø39mm
Ø32mm
Available Finishes*
21mm
See Page 205 For Series Wiring 350mA Drivers
ALRD032WH Polar White
Brushed Aluminium
Colour Temp 3000K
ALRD032AL/40
Brushed Aluminium
4000K
≤90lm
ALRD032PC/30
Polished Chrome
3000K
≤80lm
≤80lm
ALRD032PC/40
Polished Chrome
4000K
≤90lm
≤90lm
Code
Finish
ALRD032AL/30
Useful Lumens ≤80lm
Total Lumens ≤80lm ≤90lm
ALRD032WH/30
Polar White
3000K
≤80lm
≤80lm
ALRD032WH/40
Polar White
4000K
≤90lm
≤90lm
*Item(s) Sold Separately. † When Used With a Suitable ALL LED Dimmable Driver
138
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
1W LED 350mA IP65 Low Level Light
Angled Light Direction
• IP65 Rating
• Ultra Slim Profile
• Low Glare Low Level Lighting
• 350mA Constant Current (Series Wiring)
• Frosted Glass For Optimum Light Distribution
• Dimmable With Dimmable LED Driver†
• Ideal For Wall & Stair Lighting
• 1m Pre-Wired Cable
ALSQ032AL Brushed Aluminium
ALSQ032PC Polished Chrome
39mm
Ø32mm
Available Finishes*
21mm
See Page 205 For Series Wiring 350mA Drivers
ALSQ032WH Polar White
Brushed Aluminium
Colour Temp 3000K
ALSQ032AL/40
Brushed Aluminium
4000K
≤90lm
ALSQ032PC/30
Polished Chrome
3000K
≤80lm
≤80lm
ALSQ032PC/40
Polished Chrome
4000K
≤90lm
≤90lm
Code
Finish
ALSQ032AL/30
Useful Lumens ≤80lm
Total Lumens ≤80lm ≤90lm
ALSQ032WH/30
Polar White
3000K
≤80lm
≤80lm
ALSQ032WH/40
Polar White
4000K
≤90lm
≤90lm
*Item(s) Sold Separately. † When Used With a Suitable ALL LED Dimmable Driver
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
139
1W LED 350mA IP65 Low Level Light
Angled Light Direction
• IP65 Rating
• Ultra Slim Profile
• Low Glare Low Level Lighting
• 350mA Constant Current (Series Wiring)
• Clear Glass For Optimum Light Distribution
• Dimmable With Dimmable LED Driver†
• Ideal For Wall & Stair Lighting
• 1m Pre-Wired Cable
ALSQ032OP/AL Brushed Aluminium
ALSQ032OP/PC Polished Chrome
37.5mm
Ø32mm
Available Finishes*
22mm
See Page 205 For Series Wiring 350mA Drivers
ALSQ032OP/WH Polar White
Brushed Aluminium
Colour Temp 3000K
ALSQ032OP/AL/40
Brushed Aluminium
4000K
≤90lm
ALSQ032OP/PC/30
Polished Chrome
3000K
≤80lm
≤80lm
ALSQ032OP/PC/40
Polished Chrome
4000K
≤90lm
≤90lm
Code
Finish
ALSQ032OP/AL/30
Useful Lumens ≤80lm
Total Lumens ≤80lm ≤90lm
ALSQ032OP/WH/30
Polar White
3000K
≤80lm
≤80lm
ALSQ032OP/WH/40
Polar White
4000K
≤90lm
≤90lm
*Item(s) Sold Separately. † When Used With a Suitable ALL LED Dimmable Driver
140
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
1W LED 350mA IP65 Low Level Light
Angled Light Direction
• IP65 Rating
• Ultra Slim Profile
• Low Glare Low Level Lighting
• 350mA Constant Current (Series Wiring)
• Clear Glass For Optimum Light Distribution
• Dimmable With Dimmable LED Driver†
• Ideal For Wall & Stair Lighting
• 1m Pre-Wired Cable
ALSQ032SC/AL Brushed Aluminium
ALSQ032SC/PC Polished Chrome
37.5mm
Ø32mm
Available Finishes*
22mm
See Page 205 For Series Wiring 350mA Drivers
ALSQ032SC/WH Polar White
Brushed Aluminium
Colour Temp 3000K
ALSQ032SC/AL/40
Brushed Aluminium
4000K
≤90lm
ALSQ032SC/PC/30
Polished Chrome
3000K
≤80lm
≤80lm
ALSQ032SC/PC/40
Polished Chrome
4000K
≤90lm
≤90lm
Code
Finish
ALSQ032SC/AL/30
Useful Lumens ≤80lm
Total Lumens ≤80lm ≤90lm
ALSQ032SC/WH/30
Polar White
3000K
≤80lm
≤80lm
ALSQ032SC/WH/40
Polar White
4000K
≤90lm
≤90lm
*Item(s) Sold Separately. † When Used With a Suitable ALL LED Dimmable Driver
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
141
1W 350mA IP65 Low Profile Brushed Aluminium Eyelid Marker Light
• IP65 Rating
• Flush Toughened Glass
• 1W LED
• Interchangeable Bezels Available*
• Low Glare, High Power Output
• Dimmable With Dimmable Driver†
• Cree Diode Inside
• Suitable For Wall & In Ground Use
• Super Slim Bezel
• 1m Pre-Wired Cable
• Matte Brushed Aluminium
Ø42mm
Ø32mm
Accessories*
37mm
ALRE032BZ/BLK Carbon Black Bezel
ALRE032BZ/WH Polar White Bezel
See Page 205 For Series Wiring 350mA Drivers
ALRE032AL/27
Brushed Aluminium
Colour Temp 2700K
ALRE032AL/30
Brushed Aluminium
3000K
≤44lm
≤44lm
ALRE032AL/40
Brushed Aluminium
4000K
≤50lm
≤50lm
Code
Finish
Useful Lumens ≤34lm
Total Lumens ≤34lm
*Item(s) Sold Separately. † When Used With a Suitable ALL LED Dimmable Driver
142
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
3W IP54 CCT 240V Dimmable LED Square Low Level Light
• IP54 rating
• Mains Dimmable
• 3W LED
• Paintable Polar White Finish Bezel
• CCT Selectable (3000K / 4000K / 6000K)
• Fixings Included
• Opal Polycarbonate Lens
• Clip-On Carbon Black & Stainless Steel Screwless Bezels Available*
• Ideal For Stair & Plinth Lighting
• Fits in a 35mm Galvanised Metal & Dry Lining Box
• Ultra Slim Profile • Strong Polycarbonate Body
Accessories*
ATRAF/BZ/BLK Carbon Black Bezel
85mm
85mm
49mm
25mm
ATRAF/BZ/SS Stainless Steel Bezel
Code
Finish
ATRAF/CCT
Polar White
Colour Temp CCT
Useful Lumens ≤165lm
Total Lumens ≤165lm
*Item(s) Sold Separately.
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
143
Under Cabinet & Bedroom Lights Swift CCT - Under Cabinet Light............................................................. 147 Cygnet - Reading Light............................................................................ 149
146
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
2.3W 240V CCT Selectable Under Cabinet Light
• 240V Direct To Mains
• Surface Mounting Pattress Included
• CCT Selectable (3000K / 4000K / 6000K)
• Product May Be Surface or Recess Mounted
• Pre-Wired With 1m Flexible Cable
• Low Power, High Output
• Side & Rear Entry Cable Design
Available Finishes*
ACL240BK/CCT Carbon Black
ACL240SN/CCT Satin Nickel
ACL240WH/CCT Polar White
22mm
Ø69mm
Recessed Or Surface Mounting Options
Side & Rear Cable Entry Design
Code
Finish
Colour Temp CCT
Useful Lumens ≤260lm
Total Lumens ≤260lm
ACL240BK/CCT
Carbon Black
ACL240SN/CCT
Satin Nickel
CCT
≤260lm
≤260lm
ACL240WH/CCT
Polar White
CCT
≤260lm
≤260lm
*Item(s) Sold Separately.
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
147
148
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
2W Wall Mounted Adjustable Neck LED Reading Light
• Flexible Silicone Arm
• Striking Contrasting Low Profile Switch
• Recessed Low Glare LED
• Precision CNC Milled Base And Head
• Matte Black Baffle
• Available in Carbon Black* or Polar White*
• Powder Coated Body
90mm
Ø80mm
320mm
34mm
Matte Black Baffle
Flexible Silicone Arm
Code
Finish
Ø26mm
Colour Temp 3000K
Useful Lumens ≤140lm
Total Lumens ≤140lm ≤170lm
AWLG030/WH/30
Polar White
AWLG030/WH/40
Polar White
4000K
≤170lm
AWLG030/BK/30
Carbon Black
3000K
≤140lm
≤140lm
AWLG030/BK/40
Carbon Black
4000K
≤170lm
≤170lm
*Item(s) Sold Separately.
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
149
LED Strips LED Bespoke Service............................................................................... 153
NEW
Monza - Neon LED Strip.......................................................................... 154
NEW
Monza Mini - Mini Neon LED Strip.......................................................... 156
NEW
Monza RGB - RGB Neon LED Strip......................................................... 158
NEW
Pro-Digital - 12W COB Pixel SPI Strip..................................................... 160
NEW
Seamless - 5W COB LED Strip................................................................ 162 Seamless - 10W COB LED Strip.............................................................. 164 Seamless Pro - 9W COB LED Strip......................................................... 166
NEW
Nfiniti9 - Long Length LED Strip.............................................................. 168 Pro-Flex - Flexible LED Strip................................................................... 170 Trilogy - CCT LED Strip............................................................................ 172 Colour-Pro - Single Colour LED Strip...................................................... 174 Pro - 5W LED Strip................................................................................... 176 Pro - 10W LED Strip................................................................................. 178 Pro - 15W LED Strip................................................................................. 180 Pro - 20W LED Strip................................................................................. 182 Seamless-RGB - COB RGB LED Strip.................................................... 184 Pro RGB - RGB+W LED Strip.................................................................. 186
LED Strip Bespoke Service
Customised & Ready To Go
*Additional Guarantee Based On LED Strips Not Being Modified Or Re-soldered. Terms & Conditions Apply. Subject To Availability.
152
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
LED Strip Bespoke Service
“
Using All LED’s Bespoke LED Strip Service made my life so much easier and saved me a huge amount of time on this incredible job!
”
Iulian Dascalu, Electrician, London
• Express Service • Cost Effective & Reliable
• Tailored Labelling To Suit Your Project Requirements
• Supplied On Reels & In Bags
• Every Item Is Tested Before Packaging
• Work Carried Out To The Highest Standard
• Circuit Design Service Available
Work Carried Out To The Highest Standard
Individually Packaged & Labelled
Code
Lead Free Soldering
Tested & Quality Control Checked
Description
AB00
Measured & Cut to Length, Individually Packaged
AB20
IP20 Strip Measured & Cut to Length, Soldered with 50cm Cable, IP20 Rated Individually Packaged
AB65
IP65 Strip Measured & Cut to Length, Soldered with 50cm Cable, Resealed to IP65, Individually Packaged
AB67
IP67 Strip Measured & Cut to Length, Soldered with 50cm Cable, Resealed to IP67, Individually Packaged
ABADD
Additional “Tails” Cable (per Metre)
AB67-RGB
IP67 RGB Strip Measured & Cut to Length, Soldered with 50cm Cable, Including Reel & Individually Bagged
AB67-0306-SINGLE
IP67 0306 Neon Strip Measured & Cut to Length, Soldered with 50cm Cable, Including Reel & Individually Bagged
AB67-1010-SINGLE
IP67 1010 Neon Strip Measured & Cut to Length, Soldered with 50cm Cable, Including Reel & Individually Bagged
AB67-1414-RGB
IP67 1414 RGB Neon Strip Measured & Cut to Length, Soldered with 50cm Cable, Including Reel & Individually Bagged
ABADD-IP67-RGB
1m Additional Cable For RGB IP67
ABADD-IP67-SINGLE
1m Additional Cable IP67 - Single Colour
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
153
9W/m 10x10mm 24V IP67 Neon LED Strip Light
Supplied In 50m Reels Or With Bespoke Cutting Service#
• Continuous And Even Dotless Light Effect. • High CRI 90 - Delivers More Vibrant And TrueTo-Life Colours. • Ingress Protection: IP67 - Suitable For Both Indoor And Outdoor Applications.
• Maximum Lengths: 15m (Powered Single End) Or 30m (Powered Both Ends) • Cutting Intervals: Every 40mm For Precise Length Adjustment.
• Dimmable - Compatible With A Dimmable Driver*
Available Options*
18mm
12mm 12mm
10mm
12mm
10mm
40mm Min. Bend Radius - 10cm
ANS1010TB Top Bend
ANS1010SB Side Bend
Code
Version
Colour Temp
Useful Lumens
ANS1010SB/22
Side Bend
2200K
320lm/m
320lm/m
ANS1010SB/30
Side Bend
3000K
405lm/m
405lm/m
ANS1010SB/40
Side Bend
4000K
407lm/m
407lm/m
ANS1010TB/22
Top Bend
2200K
460lm/m
460lm/m
ANS1010TB/30
Top Bend
3000K
500lm/m
500lm/m
ANS1010TB/40
Top Bend
4000K
580lm/m
580lm/m
154
e: sales@allledgroup.com
t: 0208 841 9000
Total Lumens
w: allledgroup.com
Accessories* End Caps*
ANS1010/EC/IP67 End Caps
ANS1010/LE/IP67 Live Ends
ANS1010/LE/REAR/IP67 Rear Entry Live Ends
Mounting*
ANS1010/MC/10PK Mounting Clips
APA1010AL/STD Profile (2 Metres)
*Sold Separately. # Bespoke Services Additional Cost. Marine use will make guarantee 2 years. Do not use alcohol, chlorine, sulphur based chemicals on product.
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
155
5W/m 3x6mm 24V IP67 Mini Neon LED Strip Light
Supplied In 50m Reels Or With Bespoke Cutting Service#
• Continuous And Even Dotless Light Effect • High CRI 90 - Delivers More Vibrant And TrueTo-Life Colours. • Ingress Protection: IP67 - Suitable For Both Indoor And Outdoor Applications. • Dimmable - Compatible With A Dimmable Driver*
Available Options*
• Maximum Lengths: 5m (Powered Single End) Or 10m (Powered Both Ends) • Cutting Intervals: Every 25mm For Precise Length Adjustment. • At Just 3mm, It’s A Breakthrough In Optical Design.
12mm
7mm 5mm
3mm
8mm
6mm
25mm Min. Bend Radius - 5cm
ANS0306SB Side Bend
Code
Version
Colour Temp
Useful Lumens
ANS0306SB/22
Side Bend
2200K
95lm/m
95lm/m
ANS0306SB/30
Side Bend
3000K
120lm/m
120lm/m
ANS0306SB/40
Side Bend
4000K
120lm/m
120lm/m
156
e: sales@allledgroup.com
t: 0208 841 9000
Total Lumens
w: allledgroup.com
Accessories* End Caps*
ANS0306/EC/IP67 End Caps
ANS0306/LE/IP67 Live Ends
Mounting*
ANS0306/ALP Mounting Profile (x2 1 Metre)
APA0306AL/STD Profile (2 Metres)
*Sold Separately. # Bespoke Services Additional Cost. Marine use will make guarantee 2 years. Do not use alcohol, chlorine, sulphur based chemicals on product.
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
157
15W/m 14x14mm RGBWW 24V IP67 Neon LED Strip Light
Supplied In 50m Reels Or With Bespoke Cutting Service#
• Continuous And Even Dotless Light Effect. • High CRI 90 - Delivers More Vibrant And TrueTo-Life Colours. • Ingress Protection: IP67 - Suitable For Both Indoor And Outdoor Applications.
• Maximum Lengths: 5m (Powered Single End) Or 10m (Powered Both Ends) • Cutting Intervals: Every 50mm For Precise Length Adjustment.
• Dimmable - Compatible With A Dimmable Driver*
Available Options*
23mm
16mm 16mm
14mm
16mm
14mm
50mm Min. Bend Radius - 15cm
ANS1414/RGBWW/TB Top Bend
ANS1414/RGBWW/SB Side Bend
Code
Version
Colour Temp
Useful Lumens
Total Lumens
ANS1414/RGBWW/SB
Side Bend
RGBWW
≥400lm/m
≥400lm/m
ANS1414/RGBWW/TB
Top Bend
RGBWW
≥419lm/m
≥419lm/m
158
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
Accessories* End Caps*
ANS1414/EC/IP67 End Caps
ANS1414/LE/IP67 Live Ends
ANS1414/LE/REAR/IP67 Rear Entry Live Ends
Mounting*
ANS1414/MC/10PK Mounting Clips
APA1414AL/STD Profile (2 Metres)
*Sold Separately. # Bespoke Services Additional Cost. Marine use will make guarantee 2 years. Do not use alcohol, chlorine, sulphur based chemicals on product.
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
159
12W/m 24V COB Pixel SPI LED Strip IP20 / IP67
UP TO
10
Adhesive
METRES MAX RUN
IP20 Supplied In 40m Reels IP67 Supplied In 30m Reels Or With Bespoke Cutting Service#
• Delivers A Smooth, Continuous Line Of Light With No Visible LED Spotting
• Flexible Integration - Fully Compatible With ASCDIM/SLC32 Stair Lighting Systems
• Run Length - Up To 10m Powered From A Single End For Cleaner Installations
• Cutting Intervals: Every 100mm For Precise Length Adjustment
• Customised Bespoke Service Available#
IP20
100mm 12mm
Bespoke Service Customised & Ready To Go • Express Service • Cost Effective & Reliable
IP67
• Supplied On Reels & In Bags
10.5mm
100mm
• Work Carried Out To The Highest Standard
14mm 16.5mm
• Tailored Labelling To Suit Your Project Requirements • Every Item Is Tested Before Packaging • Circuit Design Service Available 18mm
Code
AST12PX/RGB
AST12PX/IP/RGB
160
Version
IP20
IP67
7mm
5mm
Colour Temp
Useful Lumens
Red
≤87lm
Total Lumens ≤87lm
Green
≤232lm
≤232lm
Blue
≤42lm
≤42lm
RGB
≤346lm
≤346lm
Red
≤87lm
≤87lm
Green
≤232lm
≤232lm
Blue
≤42lm
≤42lm
RGB
≤346lm
≤346lm
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
LED Strip Profiles+ For More Info See Page 221
APA001
APA002
APA003
APA004
APAC06
APA007
APA008
APA112
APA222AL
APA333AL
APAORC/WH
12W/m COB Compatible Drivers 24V LED Drivers+ For More Info See Page 218 Code
Specification
Length
ADRCV2415
24V 15W
1.25m Max
ADRCV2430
24V 30W
2.5m Max
ADRCV2460
24V 60W
5m Max
ADRCV2480
24V 80W
6.66m Max
ADRCV24100
24V 100W
8.33m Max^
ADRCV24150
24V 150W
12.5m Max^
ADRCV24200
24V 200W
16.66m Max^
ADRCV24320
24V 320W
26.66m Max^
Controllers+
ASC/PX/REC Pixel Strip Receiver
ASC/PX/RMT Pixel Strip Remote
ASC/PX/WSW/1Z Pixel Strip Wall Controller
Other Accessories Additional Items
Bespoke Service# For More Info See Page 153
Code
Description
Code
Description
AHSTC
Clear Heat Shrink Tubing 30cm Length
AB00
Bespoke Cut To Length
ASGL02
Non-Acidic LED Strip Silicon Sealant
AB20
ASBWC
Solder Butt Water Resistant Insulated Heat Shrink Connector (100 Pack)
Bespoke IP20 Soldered Ends 50cm Cable
AB67
Bespoke IP67 Soldered Ends 50cm Cable
ABADD
1m Additional Cable
+ Item(s) Sold Separately. ^ Recommended 10m Max Length (>10m Wire In Parallel). † Max Load 12V = 40W, 24V = 80W. * When Used With A Dimmable Driver. # Bespoke Services Additional Cost.
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
161
5W/m 24V COB LED Strip IP20 / IP67
UP TO
20
Adhesive
METRES MAX RUN
IP20 Supplied In 40m Reels IP67 Supplied In 30m Reels Or With Bespoke Cutting Service#
• Continuous And Even Dotless Light Effect • Available In 2200K, 2700K, 3000K, 4000K • Dimmable* (When Used With A Dimmable Driver)
• Maximum 50mm Cut Points • Customised Bespoke Service Available#
IP20
50mm 8mm
Bespoke Service Customised & Ready To Go
• Max Length Powered Single End 10m and 20m Double Ended
• Express Service • Cost Effective & Reliable
IP67
• Supplied On Reels & In Bags
50mm
• Work Carried Out To The Highest Standard
10mm
10mm 12.5mm
• Tailored Labelling To Suit Your Project Requirements • Every Item Is Tested Before Packaging • Circuit Design Service Available
24.5mm
7mm
5mm
Code
Version
Colour Temp
Useful Lumens
Total Lumens
AST05/COB/22
IP20
2200K
≤360lm
≤360lm
AST05/COB/27
IP20
2700K
≤460lm
≤460lm
AST05/COB/30
IP20
3000K
≤480lm
≤480lm
AST05/COB/40
IP20
4000K
≤500lm
≤500lm
AST05IP/COB/22
IP67
2200K
≤350lm
≤350lm
AST05IP/COB/27
IP67
2700K
≤450lm
≤450lm
AST05IP/COB/30
IP67
3000K
≤470lm
≤470lm
AST05IP/COB/40
IP67
4000K
≤490lm
≤490lm
162
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
LED Strip Profiles+ For More Info See Page 221
APA001
APA002
APA003
APA004
APAC06
APA007
APA008
APA112
APA222AL
APA333AL
APAORC/WH
5W/m COB Compatible Drivers 24V LED Drivers+
24V Dimmable LED Drivers+ For More Info See Page 219
For More Info See Page 218 Code
Specification
Length
Code
Spec.
ADRCV2415
24V 15W
3m Max
ADRCV2425TD
ADRCV2430
24V 30W
6m Max
ADRCV2450TD
ADRCV2460
24V 60W
12m Max
ADRCV2480
24V 80W
16m Max
ADRCV24100
24V 100W
20m Max^
ADRCV24150
24V 150W
30m Max^
ADRCV24200
24V 200W
40m Max^
ADRCV24320
24V 320W
64m Max^
5W/m COB Compatible Connectors P1 Connectors†
Load
Length
24V 25W
1.25-25W
0.25 - 5m
24V 50W
2.5-50W
0.50 - 10m
ADRCV24100TD
24V 100W
5-100W
1.0 - 20m
ADRCV24150TD
24V 150W
7.5-150W
1.5 - 30m
Other Accessories Bespoke Service# For More Info See Page 153
For More Info See Page 194 Code
Description
IP
Code
Description
ASCC8MM/LE
Live End
IP20
AB00
Bespoke Cut To Length
ASCC8MM/CUP
Coupler
IP20
ASCC8MM/2CAB
Double Ended
IP20
AB20
Bespoke IP20 Soldered Ends 50cm Cable
ASCC8MM/LE/10PK
Live End 10 Pack
IP20
AB67
ASCC8MM/CUP/10PK
Coupler 10 Pack
IP20
Bespoke IP67 Soldered Ends 50cm Cable
ABADD
1m Additional Cable
ASCC8MM/2CAB/10PK Double Ended 10 Pack
IP20
ASCC/COB8/COR
IP20
Corner Connector for COB
ASCC/COB8/COR/10PK Corner Connector for COB 10 Pack
IP20
Navigate Corners Easily With Our COB Corner Connector
Choice Of IP20 Connectors + Item(s) Sold Separately. ^ Recommended 10m Max Length (>10m Wire In Parallel). † Max Load 12V = 40W, 24V = 80W. * When Used With A Dimmable Driver. # Bespoke Services Additional Cost.
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
163
10W/m 24V COB LED Strip IP20 / IP67
UP TO
10
Adhesive
METRES MAX RUN
IP20 Supplied In 40m Reels IP67 Supplied In 30m Reels Or With Bespoke Cutting Service#
• Continuous And Even Dotless Light Effect
• 50mm Cut Points
• Max Length Powered Single End 5m And 10m Double Ended
• 480LED/m
• High CRI 90+
• Customised Bespoke Service Only#
IP20
50mm 8mm
Bespoke Service Customised & Ready To Go
• Mains Dimmable With Dimmable LED Driver
• Express Service • Cost Effective & Reliable
IP67
• Supplied On Reels & In Bags
50mm
• Work Carried Out To The Highest Standard
10mm
10mm 12.5mm
• Tailored Labelling To Suit Your Project Requirements • Every Item Is Tested Before Packaging • Circuit Design Service Available
24.5mm
7mm
5mm
Code
Version
Colour Temp
Useful Lumens
AST010/COB/27
IP20
2700K
≤760lm
Total Lumens ≤760lm
AST010/COB/30
IP20
3000K
≤760lm
≤760lm
AST010/COB/40
IP20
4000K
≤860lm
≤860lm
AST010/COB/60
IP20
6000K
≤1020lm
≤1020lm
AST010IP/COB/27
IP67
2700K
≤670lm
≤670lm
AST010IP/COB/30
IP67
3000K
≤760lm
≤760lm
AST010IP/COB/40
IP67
4000K
≤823lm
≤823lm
AST010IP/COB/60
IP67
6000K
≤828lm
≤828lm
164
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
LED Strip Profiles+ For More Info See Page 221
APA001
APA002
APA003
APA004
APAC06
APA007
APA008
APA112
APA222AL
APA333AL
APAORC/WH
10W/m COB Compatible Drivers 24V LED Drivers+
24V Dimmable LED Drivers+ For More Info See Page 219
For More Info See Page 218 Code
Specification
Length
Code
Spec.
ADRCV2415
24V 15W
1.5m Max
ADRCV2425TD
ADRCV2430
24V 30W
3m Max
ADRCV2450TD
ADRCV2460
24V 60W
6m Max
ADRCV2480
24V 80W
8m Max
ADRCV24100
24V 100W
10m Max^
ADRCV24150
24V 150W
15m Max^
ADRCV24200
24V 200W
20m Max^
ADRCV24320
24V 320W
32m Max^
10W/m COB Compatible Connectors P1 Connectors†
Load
Length
24V 25W
1.25-25W
0.15 - 2.5m
24V 50W
2.5-50W
0.25 - 5m
ADRCV24100TD
24V 100W
5-100W
0.5 - 10m
ADRCV24150TD
24V 150W
7.5-150W
0.75 - 15m
Other Accessories Bespoke Service# For More Info See Page 153
For More Info See Page 194 Code
Description
IP
Code
Description
ASCC8MM/LE
Live End
IP20
AB00
Bespoke Cut To Length
ASCC8MM/CUP
Coupler
IP20
ASCC8MM/2CAB
Double Ended
IP20
AB20
Bespoke IP20 Soldered Ends 50cm Cable
ASCC8MM/LE/10PK
Live End 10 Pack
IP20
AB67
ASCC8MM/CUP/10PK
Coupler 10 Pack
IP20
Bespoke IP67 Soldered Ends 50cm Cable
ABADD
1m Additional Cable
ASCC8MM/2CAB/10PK Double Ended 10 Pack
IP20
ASCC/COB8/COR
IP20
Corner Connector for COB
ASCC/COB8/COR/10PK Corner Connector for COB 10 Pack
IP20
Navigate Corners Easily With Our COB Corner Connector
Choice Of IP20 Connectors + Item(s) Sold Separately. ^ Recommended 10m Max Length (>10m Wire In Parallel). † Max Load 12V = 40W, 24V = 80W. * When Used With A Dimmable Driver. # Bespoke Services Additional Cost.
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
165
9W/m 24V COB LED Strip IP20 / IP67
UP TO
20
Adhesive
METRES MAX RUN
IP20 Supplied In 40m Reels IP67 Supplied In 30m Reels Or With Bespoke Cutting Service#
• Continuous And Even Dotless Light Effect • High CRI 90+
• Max Length Powered Single End 10m And 20m Double Ended
• 50mm Cut Points
• 420LED/m
• Mains Dimmable With Dimmable LED Driver*
• Customised Bespoke Service Only#
IP20
50mm 8mm
Bespoke Service Customised & Ready To Go • Express Service • Cost Effective & Reliable
IP67
• Supplied On Reels & In Bags
50mm
• Work Carried Out To The Highest Standard
10mm
10mm 12.5mm
• Tailored Labelling To Suit Your Project Requirements • Every Item Is Tested Before Packaging • Circuit Design Service Available
24.5mm
7mm
5mm
Code
Version
Colour Temp
Useful Lumens
Total Lumens
AST09L/COB/27
IP20
2700K
≤650lm
≤650lm
AST09L/COB/30
IP20
3000K
≤700lm
≤700lm
AST09L/COB/40
IP20
4000K
≤740lm
≤740lm
AST09L/COB/60
IP20
6000K
≤780lm
≤780lm
AST09LIP/COB/27
IP67
2700K
≤650lm
≤650lm
AST09LIP/COB/30
IP67
3000K
≤700lm
≤700lm
AST09LIP/COB/40
IP67
4000K
≤740lm
≤740lm
AST09LIP/COB/60
IP67
6000K
≤780lm
≤780lm
166
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
LED Strip Profiles+ For More Info See Page 221
APA001
APA002
APA003
APA004
APAC06
APA007
APA008
APA112
APA222AL
APA333AL
APAORC/WH
9W/m COB Compatible Drivers 24V LED Drivers+
24V Dimmable LED Drivers+ For More Info See Page 219
For More Info See Page 218 Code
Specification
Length
Code
Spec.
ADRCV2415
24V 15W
1.67m Max
ADRCV2425TD
ADRCV2430
24V 30W
3.33m Max
ADRCV2450TD
ADRCV2460
24V 60W
6.67m Max
ADRCV2480
24V 80W
8.89m Max
ADRCV24100
24V 100W
11.11m Max
ADRCV24150
24V 150W
16.67m Max
ADRCV24200
24V 200W
22.22m Max
ADRCV24320
24V 320W
35.56m Max
9W/m COB Compatible Connectors P1 Connectors†
Load
Length
24V 25W
1.25-25W
0.14 - 2.78m
24V 50W
2.5-50W
0.28 - 5.56m
ADRCV24100TD
24V 100W
5-100W
0.56 - 11.11m
ADRCV24150TD
24V 150W
7.5-150W
0.83 - 16.67m
Other Accessories Bespoke Service# For More Info See Page 153
For More Info See Page 194 Code
Description
IP
Code
Description
ASCC8MM/LE
Live End
IP20
AB00
Bespoke Cut To Length
ASCC8MM/CUP
Coupler
IP20
ASCC8MM/2CAB
Double Ended
IP20
AB20
Bespoke IP20 Soldered Ends 50cm Cable
ASCC8MM/LE/10PK
Live End 10 Pack
IP20
AB67
ASCC8MM/CUP/10PK
Coupler 10 Pack
IP20
Bespoke IP67 Soldered Ends 50cm Cable
ABADD
1m Additional Cable
ASCC8MM/2CAB/10PK Double Ended 10 Pack
IP20
ASCC/COB8/COR
IP20
Corner Connector for COB
ASCC/COB8/COR/10PK Corner Connector for COB 10 Pack
IP20
Navigate Corners Easily With Our COB Corner Connector
Choice Of IP20 Connectors + Item(s) Sold Separately. † Max Load 12V = 40W, 24V = 80W. * When Used With A Dimmable Driver. # Bespoke Services Additional Cost.
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
167
9W/m 24V Long Length LED Strip IP20 / IP67
UP TO
40
Adhesive
METRES MAX RUN
IP20 Supplied In 60m Reels IP67 Supplied In 40m Reels Or With Bespoke Cutting Service#
• Maximum Lengths: Single End Powered 20m Max Or Double Ended Up To 40m
• Customisation: Bespoke Lengths, Configurations, And Colour Temperatures Available Upon Request.
• Dimming Capability: Dimmable When Paired With A Compatible Dimmable Driver.
• High Density 120 LED/m
• Cutting Increments: Cut Points Every 50mm.
• 3 Year Guarantee IP20 50mm 10mm
Bespoke Service Customised & Ready To Go • Express Service • Cost Effective & Reliable
IP67
• Work Carried Out To The Highest Standard • Every Item Is Tested Before Packaging
33mm
12mm
50mm 12mm
6mm
• Tailored Labelling To Suit Your Project Requirements • Circuit Design Service Available
Code
7mm
5mm
14mm
• Supplied On Reels & In Bags
Version
Colour Temp
Useful Lumens
Total Lumens
AST900/27
IP20
2700K
≤840lm
≤840lm
AST900/30
IP20
3000K
≤850lm
≤850lm
AST900/40
IP20
4000K
≤925lm
≤925lm
AST900/60
IP20
6000K
≤880lm
≤880lm
AST900IP/27
IP67
2700K
≤750lm
≤750lm
AST900IP/30
IP67
3000K
≤760lm
≤760lm
AST900IP/40
IP67
4000K
≤850lm
≤850lm
AST900IP/60
IP67
6000K
≤820lm
≤820lm
168
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
LED Strip Profiles+ For More Info See Page 221
APA001
APA002
APA003
APA004
APAC06
APA007
APA008
APA112
APA222AL
APA333AL
APAORC/WH
9W/m Compatible Drivers 24V LED Drivers+
24V Dimmable LED Drivers+ For More Info See Page 219
For More Info See Page 218 Code
Specification
Length
Code
Spec.
ADRCV2415
24V 15W
1.67m Max
ADRCV2425TD
ADRCV2430
24V 30W
3.33m Max
ADRCV2450TD
ADRCV2460
24V 60W
6.67m Max
ADRCV2480
24V 80W
8.89m Max
ADRCV24100
24V 100W
11.11m Max
ADRCV24150
24V 150W
16.67m Max
ADRCV24200
24V 200W
22.22m Max
ADRCV24320
24V 320W
35.56m Max
Load
Length
24V 25W
1.25-25W
0.14 - 2.78m
24V 50W
2.5-50W
0.28 - 5.56m
ADRCV24100TD
24V 100W
5-100W
0.56 - 11.11m
ADRCV24150TD
24V 150W
7.5-150W
0.83 - 16.67m
Other Accessories Additional Items+
Bespoke Service# For More Info See Page 153
Code
Description
Code
Description
AHSTC
Clear Heat Shrink Tubing 30cm Length
AB00
Bespoke Cut To Length
ASGL01
Non-Acidic LED Strip Silicon Sealant
AB20
ASBWC
Solder Butt Water Resistant Insulated Heat Shrink Connector (100 Pack)
Bespoke IP20 Soldered Ends 50cm Cable
AB67
ACRAB/100M
Red & Black 0.2mm Cable Price Per Metre
Bespoke IP67 Soldered Ends 50cm Cable
ABADD
1m Additional Cable
+ Item(s) Sold Separately. † Max Load 12V = 40W, 24V = 80W. * When Used With A Dimmable Driver. # Bespoke Services Additional Cost.
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
169
7.2W/m 24V Bendable LED Strip IP20 / IP65
Adhesive
IP20 Supplied In 40m Reels IP65 Supplied In 30m Reels Or With Bespoke Cutting Service#
• Designed For Corners & Complex Shapes • Designed To Bend On Horizontal Surfaces
• Mains Dimmable When Used With A Dimmable Driver*
• 100mm Cut Point Intervals
• 60 LED/m
• Soldered Connection Only
• Customised Bespoke Service Available#
Bespoke Service Customised & Ready To Go 100mm
• Express Service
6mm
• Cost Effective & Reliable • Supplied On Reels & In Bags • Work Carried Out To The Highest Standard • Tailored Labelling To Suit Your Project Requirements • Every Item Is Tested Before Packaging • Circuit Design Service Available
Code
Version
Colour Temp
Useful Lumens
Total Lumens
AST720F/27
IP20
2700K
≤699lm
≤699lm
AST720F/30
IP20
3000K
≤870lm
≤870lm
AST720F/40
IP20
4000K
≤925lm
≤925lm
AST720F/60
IP20
6000K
≤814lm
≤814lm
AST720FIP/27
IP65
2700K
≤675lm
≤675lm
AST720FIP/30
IP65
3000K
≤705lm
≤705lm
AST720FIP/40
IP65
4000K
≤909lm
≤909lm
AST720FIP/60
IP65
6000K
≤770lm
≤770lm
170
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
LED Strip Profiles+ For More Info See Page 221
APA001
APA002
APA003
APA004
APAC06
APA007
APA008
APA112
APA222AL
APA333AL
APAORC/WH
7.2W/m Compatible Drivers 24V LED Drivers+
24V Dimmable LED Drivers+ For More Info See Page 219
For More Info See Page 218 Code
Specification
Length
Code
Spec.
ADRCV2415
24V 15W
2.1m Max
ADRCV2425TD
ADRCV2430
24V 30W
4.1m Max
ADRCV2450TD
ADRCV2460
24V 60W
8.3m Max
ADRCV2480
24V 80W
11.1m Max
ADRCV24100
24V 100W
13.8m Max^
ADRCV24150
24V 150W
20.8m Max^
ADRCV24200
24V 200W
27.7m Max^
ADRCV24320
24V 320W
44.4m Max^
Load
Length
24V 25W
1.25-25W
0.2 - 3.4m
24V 50W
2.5-50W
0.4 - 6.9m
ADRCV24100TD
24V 100W
5-100W
0.7 - 13.8m
ADRCV24150TD
24V 150W
7.5-150W
1.1 - 20.8m
Other Accessories Additional Items+
Bespoke Service# For More Info See Page 153
Code
Description
Code
Description
AHSTC
Clear Heat Shrink Tubing 30cm Length
AB00
Bespoke Cut To Length
ASGL01
Non-Acidic LED Strip Silicon Sealant
AB20
ASBWC
Solder Butt Water Resistant Insulated Heat Shrink Connector (100 Pack)
Bespoke IP20 Soldered Ends 50cm Cable
AB65
ACRAB/100M
Red & Black 0.2mm Cable Price Per Metre
Bespoke IP65 Soldered Ends 50cm Cable
ABADD
1m Additional Cable
Master The Corner
+ Item(s) Sold Separately. ^ Recommended 10m Max Length (>10m Wire In Parallel). † Max Load 12V = 40W, 24V = 80W. * When Used With A Dimmable Driver. # Bespoke Services Additional Cost.
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
171
10W/m 24V CCT LED Strip IP20 / IP65
Adhesive
IP20 Supplied In 40m Reels IP65 Supplied In 30m Reels Or With Bespoke Cutting Service#
• Constant Colour & Wattage • 100mm Cut Point Intervals
• Mains Dimmable When Used With A Dimmable Driver*
• 120 LED/m
• High Output, Compact Light Source
• Product Code Featured On All LED Strips
• Customised Bespoke Service Available#
Select Colour At Time Of Installation. Choice Of 3000K / 4000K / 6000K Bespoke Service Customised & Ready To Go
100mm
• Express Service 10mm
• Cost Effective & Reliable • Supplied On Reels & In Bags • Work Carried Out To The Highest Standard • Tailored Labelling To Suit Your Project Requirements • Every Item Is Tested Before Packaging • Circuit Design Service Available
Code
Version
Colour Temp
Useful Lumens
Total Lumens
AST010/CCT
IP20
CCT
≤1100lm
≤1100lm
AST010IP/CCT
IP65
CCT
≤880lm
≤880lm
172
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
LED Strip Profiles+ For More Info See Page 221
APA001
APA002
APA003
APA004
APAC06
APA007
APA008
APA112
APA222AL
APA333AL
APAORC/WH
10W/m Compatible Drivers 24V LED Drivers+ For More Info See Page 218 Code
Specification
Length
ADRCV2415
24V 15W
1.5m Max
ADRCV2430
24V 30W
3m Max
ADRCV2460
24V 60W
6m Max
ADRCV2480
24V 80W
8m Max
ADRCV24100
24V 100W
10m Max^
ADRCV24150
24V 150W
15m Max^
ADRCV24200
24V 200W
20m Max^
ADRCV24320
24V 320W
32m Max^
Other Accessories Additional Items+
Bespoke Service# For More Info See Page 153
Code
Description
Code
Description
AHSTC
Clear Heat Shrink Tubing 30cm Length
AB00
Bespoke Cut To Length
ASGL01
Non-Acidic LED Strip Silicon Sealant
AB20
ASBWC
Solder Butt Water Resistant Insulated Heat Shrink Connector (100 Pack)
Bespoke IP20 Soldered Ends 50cm Cable
AB65
Bespoke IP65 Soldered Ends 50cm Cable
ABADD
1m Additional Cable
+ Item(s) Sold Separately. ^ Recommended 10m Max Length (>10m Wire In Parallel). † Max Load 12V = 40W, 24V = 80W. * When Used With A Dimmable Driver. # Bespoke Services Additional Cost.
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
173
10W/m 24V LED Strip IP20 / IP65
Adhesive IP20 Supplied In 40m Reels IP65 Supplied In 30m Reels Or With Bespoke Cutting Service#
• Available in A Range of Colours: Filament Yellow, Apple Green, Corsa Red, Azure Blue, Ambient Amber
• Mains Dimmable When Used With A Dimmable Driver*
• 50mm Cut Point Intervals
• Customised Bespoke Service Available#
• 120 LED/m
Bespoke Service Customised & Ready To Go
50mm
• Express Service
10mm
• Cost Effective & Reliable • Supplied On Reels & In Bags • Work Carried Out To The Highest Standard • Tailored Labelling To Suit Your Project Requirements • Every Item Is Tested Before Packaging • Circuit Design Service Available
Code
Version
Colour
Useful Lumens
Total Lumens ≤464lm
AST010/YL
IP20
Filament Yellow
≤464lm
AST010/GR
IP20
Apple Green
≤915lm
≤915lm
AST010/RD
IP20
Corsa Red
≤250lm
≤250lm
AST010/BL
IP20
Azure Blue
≤132lm
≤132lm
AST010/AB
IP20
Ambient Amber
≤796lm
≤796lm
AST010IP/YL
IP65
Filament Yellow
≤453lm
≤453lm
AST010IP/GR
IP65
Apple Green
≤887lm
≤887lm
AST010IP/RD
IP65
Corsa Red
≤239lm
≤239lm
AST010IP/BL
IP65
Azure Blue
≤128lm
≤128lm
AST010IP/AB
IP65
Ambient Amber
≤792lm
≤792lm
174
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
LED Strip Profiles+ For More Info See Page 221
APA001
APA002
APA003
APA004
APAC06
APA007
APA008
APA112
APA222AL
APA333AL
APAORC/WH
10W/m Compatible Drivers 24V LED Drivers+
24V Dimmable LED Drivers+ For More Info See Page 219
For More Info See Page 218 Code
Specification
Length
Code
Spec.
ADRCV2415
24V 15W
1.5m Max
ADRCV2425TD
ADRCV2430
24V 30W
3m Max
ADRCV2450TD
ADRCV2460
24V 60W
6m Max
ADRCV2480
24V 80W
8m Max
ADRCV24100
24V 100W
10m Max^
ADRCV24150
24V 150W
15m Max^
ADRCV24200
24V 200W
20m Max^
ADRCV24320
24V 320W
32m Max^
Load
Length
24V 25W
1.25-25W
0.15 - 2.5m
24V 50W
2.5-50W
0.25 - 5m
ADRCV24100TD
24V 100W
5-100W
0.5 - 10m
ADRCV24150TD
24V 150W
7.5-150W
0.75 - 15m
10W/m Compatible Connectors UniCube Connectors+
P1 Connectors† For More Info See Page 195
For More Info See Page 192 Code
Quantity
Type
Code
Description
IP
ASTC/UNI
1
Straight
ASCC10MM/LE
10mm LED Single End Connector
IP20
ASTC/UNI/10PK
10
Straight
ASCC10MM/2CAB
10mm LED Double Ended Connector
IP20
ASTC/UNI/L90
1
90°
ASCC10MM/IP/LE
10mm LED Single End Connector
IP65
ASTC/UNI/L90/10PK
10
90°
ASCC10MM/IP/CUP
10mm LED Coupling Connector
IP65
ASCC10MM/IP/2CAB
10mm LED Double Ended Connector
IP65
Other Accessories Additional Items+
Bespoke Service# For More Info See Page 153
Code
Description
Code
Description
AHSTC
Clear Heat Shrink Tubing 30cm Length
AB00
Bespoke Cut To Length
ASGL01
Non-Acidic LED Strip Silicon Sealant
AB20
ASBWC
Solder Butt Water Resistant Insulated Heat Shrink Connector (100 Pack)
Bespoke IP20 Soldered Ends 50cm Cable
AB65
ACRAB/100M
Red & Black 0.2mm Cable Price Per Metre
Bespoke IP65 Soldered Ends 50cm Cable
ABADD
1m Additional Cable
+ Item(s) Sold Separately. ^ Recommended 10m Max Length (>10m Wire In Parallel). † Max Load 12V = 40W, 24V = 80W. * When Used With A Dimmable Driver. # Bespoke Services Additional Cost.
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
175
5W/m 12V LED Strip IP20 / IP65
Adhesive
IP20 Supplied In 40m Reels IP65 Supplied In 30m Reels Or With Bespoke Cutting Service#
• Mains Dimmable When Used With A Dimmable Driver*
• 50mm Cut Point Intervals
• Product Code Featured On All LED Strips
• Customised Bespoke Service Available#
• 60 LED/m
Bespoke Service Customised & Ready To Go
50mm
• Express Service
8mm
• Cost Effective & Reliable • Supplied On Reels & In Bags • Work Carried Out To The Highest Standard • Tailored Labelling To Suit Your Project Requirements • Every Item Is Tested Before Packaging • Circuit Design Service Available
Code
Version
Colour Temp
Useful Lumens
AST005/27
IP20
2700K
≤476lm
Total Lumens ≤476lm
AST005/30
IP20
3000K
≤494lm
≤494lm
AST005/40
IP20
4000K
≤490lm
≤490lm
AST005/60
IP20
6000K
≤500lm
≤500lm
AST005IP/27
IP65
2700K
≤417lm
≤417lm
AST005IP/30
IP65
3000K
≤415lm
≤415lm
AST005IP/40
IP65
4000K
≤463lm
≤463lm
AST005IP/60
IP65
6000K
≤494lm
≤494lm
176
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
LED Strip Profiles+ For More Info See Page 221
APA001
APA002
APA003
APA004
APAC06
APA007
APA008
APA112
APA222AL
APA333AL
APAORC/WH
5W/m Compatible Drivers 12V LED Drivers+
12V Dimmable LED Drivers+ For More Info See Page 217
For More Info See Page 216 Code
Specification
Length
Code
Spec.
Load
Length
ADRCV1215
12V 15W
3m Max
ADRCV1225TD
12V 25W
1.25-25W
1 - 5m
ADRCV1230
12V 30W
6m Max
ADRCV1250TD
12V 50W
2.5-50W
1 - 10m
ADRCV1260
12V 60W
12m Max^
ADRCV12100TD
12V 100W
5-100W
1 - 20m
ADRCV1280
12V 80W
16m Max^
ADRCV24150TD
24V 150W
7.5-150W
0.75 - 15m
ADRCV12100
12V 100W
20m Max^
5W/m Compatible Connectors UniCube Connectors+
P1 Connectors† For More Info See Page 194
For More Info See Page 192 Code
Quantity
Type
Code
Description
IP
ASTC/UNI
1
Straight
ASCC8MM/LE
Live End
IP20
ASTC/UNI/10PK
10
Straight
ASCC8MM/CUP
Coupler
IP20
ASTC/UNI/L90
1
90°
ASCC8MM/2CAB
Double Ended
IP20
ASTC/UNI/L90/10PK
10
90°
ASCC8MM/LE/10PK
Live End 10 Pack
IP20
ASCC8MM/CUP/10PK
Coupler 10 Pack
IP20
ASCC8MM/2CAB/10PK Double Ended 10 Pack
IP20
Other Accessories Additional Items+
Bespoke Service# For More Info See Page 153
Code
Description
Code
Description
AHSTC
Clear Heat Shrink Tubing 30cm Length
AB00
Bespoke Cut To Length
ASGL01
Non-Acidic LED Strip Silicon Sealant
AB20
ASBWC
Solder Butt Water Resistant Insulated Heat Shrink Connector (100 Pack)
Bespoke IP20 Soldered Ends 50cm Cable
AB65
ACRAB/100M
Red & Black 0.2mm Cable Price Per Metre
Bespoke IP65 Soldered Ends 50cm Cable
ABADD
1m Additional Cable
+ Item(s) Sold Separately. ^ Recommended 10m Max Length (>10m Wire In Parallel). † Max Load 12V = 40W, 24V = 80W. * When Used With A Dimmable Driver. # Bespoke Services Additional Cost.
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
177
10W/m 24V LED Strip IP20 / IP65
Adhesive
IP20 Supplied In 40m Reels IP65 Supplied In 30m Reels Or With Bespoke Cutting Service#
• Mains Dimmable When Used With A Dimmable Driver*
• 50mm Cut Point Intervals
• Product Code Featured On All LED Strips
• Customised Bespoke Service Available#
• 140 LED/m
Bespoke Service Customised & Ready To Go
50mm
• Express Service
10mm
• Cost Effective & Reliable • Supplied On Reels & In Bags • Work Carried Out To The Highest Standard • Tailored Labelling To Suit Your Project Requirements • Every Item Is Tested Before Packaging • Circuit Design Service Available
Code
Version
Colour Temp
Useful Lumens
Total Lumens
AST010/27
IP20
2700K
≤1200lm
≤1200lm
AST010/30
IP20
3000K
≤1230lm
≤1230lm
AST010/40
IP20
4000K
≤1260lm
≤1260lm
AST010/60
IP20
6000K
≤1220lm
≤1220lm
AST010IP/27
IP65
2700K
≤1000lm
≤1000lm
AST010IP/30
IP65
3000K
≤1020lm
≤1020lm
AST010IP/40
IP65
4000K
≤1110lm
≤1110lm
AST010IP/60
IP65
6000K
≤1140lm
≤1140lm
178
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
LED Strip Profiles+ For More Info See Page 221
APA001
APA002
APA003
APA004
APAC06
APA007
APA008
APA112
APA222AL
APA333AL
APAORC/WH
10W/m Compatible Drivers 24V LED Drivers+
24V Dimmable LED Drivers+ For More Info See Page 219
For More Info See Page 218 Code
Specification
Length
Code
Spec.
ADRCV2415
24V 15W
1.5m Max
ADRCV2425TD
ADRCV2430
24V 30W
3m Max
ADRCV2450TD
ADRCV2460
24V 60W
6m Max
ADRCV2480
24V 80W
8m Max
ADRCV24100
24V 100W
10m Max^
ADRCV24150
24V 150W
15m Max^
ADRCV24200
24V 200W
20m Max^
ADRCV24320
24V 320W
32m Max^
Load
Length
24V 25W
1.25-25W
0.15 - 2.5m
24V 50W
2.5-50W
0.25 - 5m
ADRCV24100TD
24V 100W
5-100W
0.5 - 10m
ADRCV24150TD
24V 150W
7.5-150W
0.75 - 15m
10W/m Compatible Connectors UniCube Connectors+
P1 Connectors† For More Info See Page 195
For More Info See Page 192 Code
Quantity
Type
Code
Description
IP
ASTC/UNI
1
Straight
ASCC10MM/LE
10mm LED Single End Connector
IP20
ASTC/UNI/10PK
10
Straight
ASCC10MM/2CAB
10mm LED Double Ended Connector
IP20
ASTC/UNI/L90
1
90°
ASCC10MM/IP/LE
10mm LED Single End Connector
IP65
ASTC/UNI/L90/10PK
10
90°
ASCC10MM/IP/CUP
10mm LED Coupling Connector
IP65
ASCC10MM/IP/2CAB
10mm LED Double Ended Connector
IP65
Other Accessories Additional Items+
Bespoke Service# For More Info See Page 153
Code
Description
Code
Description
AHSTC
Clear Heat Shrink Tubing 30cm Length
AB00
Bespoke Cut To Length
ASGL01
Non-Acidic LED Strip Silicon Sealant
AB20
ASBWC
Solder Butt Water Resistant Insulated Heat Shrink Connector (100 Pack)
Bespoke IP20 Soldered Ends 50cm Cable
AB65
ACRAB/100M
Red & Black 0.2mm Cable Price Per Metre
Bespoke IP65 Soldered Ends 50cm Cable
ABADD
1m Additional Cable
+ Item(s) Sold Separately. ^ Recommended 10m Max Length (>10m Wire In Parallel). † Max Load 12V = 40W, 24V = 80W. * When Used With A Dimmable Driver. # Bespoke Services Additional Cost.
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
179
15W/m 24V LED Strip IP20 / IP65
Adhesive
IP20 Supplied In 40m Reels IP65 Supplied In 30m Reels Or With Bespoke Cutting Service#
• Mains Dimmable When Used With A Dimmable Driver*
• 50mm Cut Point Intervals
• Product Code Featured On All LED Strips
• Customised Bespoke Service Available#
• 140 LED/m
Bespoke Service Customised & Ready To Go
50mm
• Express Service
10mm
• Cost Effective & Reliable • Supplied On Reels & In Bags • Work Carried Out To The Highest Standard • Tailored Labelling To Suit Your Project Requirements • Every Item Is Tested Before Packaging • Circuit Design Service Available
Code
Version
Colour Temp
Useful Lumens
AST015/24
IP20
2400K
≤1534lm
≤1534lm
AST015/30
IP20
3000K
≤1665lm
≤1665lm
AST015/40
IP20
4000K
≤1820lm
≤1820lm
AST015IP/24
IP65
2400K
≤1427lm
≤1427lm
AST015IP/30
IP65
3000K
≤1493lm
≤1493lm
AST015IP/40
IP65
4000K
≤1665lm
≤1665lm
180
e: sales@allledgroup.com
t: 0208 841 9000
Total Lumens
w: allledgroup.com
LED Strip Profiles+ For More Info See Page 221
APA001
APA002
APA003
APA004
APAC06
APA007
APA008
APA112
APA222AL
APA333AL
APAORC/WH
15W/m Compatible Drivers 24V LED Drivers+
24V Dimmable LED Drivers+ For More Info See Page 219
For More Info See Page 218 Code
Specification
Length
Code
Spec.
ADRCV2415
24V 15W
1m Max
ADRCV2425TD
ADRCV2430
24V 30W
2m Max
ADRCV2450TD
ADRCV2460
24V 60W
4m Max
ADRCV2480
24V 80W
5.3m Max
ADRCV24100
24V 100W
6.6m Max^
ADRCV24150
24V 150W
10m Max^
ADRCV24200
24V 200W
13.3m Max^
ADRCV24320
24V 320W
21.3m Max^
Load
Length
24V 25W
1.25-25W
0.1 - 1.6m
24V 50W
2.5-50W
0.2 - 3.3m
ADRCV24100TD
24V 100W
5-100W
0.35 - 6.6m
ADRCV24150TD
24V 150W
7.5-150W
0.5 - 10m
15W/m Compatible Connectors UniCube Connectors+
P1 Connectors† For More Info See Page 195
For More Info See Page 192 Code
Quantity
Type
Code
Description
IP
ASTC/UNI
1
Straight
ASCC10MM/LE
10mm LED Single End Connector
IP20
ASTC/UNI/10PK
10
Straight
ASCC10MM/2CAB
10mm LED Double Ended Connector IP20
ASTC/UNI/L90
1
90°
ASCC10MM/IP/LE
10mm LED Single End Connector
IP65
ASTC/UNI/L90/10PK
10
90°
ASCC10MM/IP/CUP
10mm LED Coupling Connector
IP65
ASCC10MM/IP/2CAB
10mm LED Double Ended Connector IP65
Other Accessories Additional Items+
Bespoke Service# For More Info See Page 153
Code
Description
Code
Description
AHSTC
Clear Heat Shrink Tubing 30cm Length
AB00
Bespoke Cut To Length
ASGL01
Non-Acidic LED Strip Silicon Sealant
AB20
ASBWC
Solder Butt Water Resistant Insulated Heat Shrink Connector (100 Pack)
Bespoke IP20 Soldered Ends 50cm Cable
AB65
ACRAB/100M
Red & Black 0.2mm Cable Price Per Metre
Bespoke IP65 Soldered Ends 50cm Cable
ABADD
1m Additional Cable
+ Item(s) Sold Separately. ^ Recommended 10m Max Length (>10m Wire In Parallel). † Max Load 12V = 40W, 24V = 80W. * When Used With A Dimmable Driver. # Bespoke Services Additional Cost.
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
181
20W/m 24V LED Strip IP20 / IP65
Adhesive
IP20 Supplied In 40m Reels IP65 Supplied In 30m Reels Or With Bespoke Cutting Service#
• CRI 90+ • 50mm Cut Point Intervals
• Mains Dimmable When Used With A Dimmable Driver*
• Product Code Featured On All LED Strips
• Soldered Connection Only
• 160 LED/m
• Customised Bespoke Service Available#
Bespoke Service Customised & Ready To Go
50mm
• Express Service
12mm
• Cost Effective & Reliable • Supplied On Reels & In Bags • Work Carried Out To The Highest Standard • Tailored Labelling To Suit Your Project Requirements • Every Item Is Tested Before Packaging • Circuit Design Service Available
Code
Version
Colour Temp
Useful Lumens
Total Lumens
AST020/30
IP20
3000K
≤2200lm
≤2200lm
AST020/40
IP20
4000K
≤2100lm
≤2100lm
AST020IP/30
IP65
3000K
≤1660lm
≤1660lm
AST020IP/40
IP65
4000K
≤1860lm
≤1860lm
182
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
LED Strip Profiles+ For More Info See Page 221
APA001
APA002
APA003
APA004
APAC06
APA007
APA008
APA112
APA222AL
APA333AL
APAORC/WH
10W/m Compatible Drivers 24V LED Drivers+
24V Dimmable LED Drivers+ For More Info See Page 219
For More Info See Page 218 Code
Specification
Length
Code
Spec.
ADRCV2415
24V 15W
0.75m Max
ADRCV2425TD
ADRCV2430
24V 30W
1.5m Max
ADRCV2450TD
ADRCV2460
24V 60W
3m Max
ADRCV2480
24V 80W
4m Max
ADRCV24100
24V 100W
5m Max^
ADRCV24150
24V 150W
7.5m Max^
ADRCV24200
24V 200W
10m Max^
ADRCV24320
24V 320W
16m Max^
Load
Length
24V 25W
1.25-25W
0.05 - 1.25m
24V 50W
2.5-50W
0.3 - 2.5m
ADRCV24100TD
24V 100W
5-100W
0.3 - 5m
ADRCV24150TD
24V 150W
7.5-150W
0.3 - 7.5m
Competitors Product
CRI>90 Render Colours More Vividly CRI>70 Low CRI
CRI>90 High CRI
Other Accessories Additional Items+
Bespoke Service# For More Info See Page 153
Code
Description
Code
Description
AHSTC
Clear Heat Shrink Tubing 30cm Length
AB00
Bespoke Cut To Length
ASGL01
Non-Acidic LED Strip Silicon Sealant
AB20
ASBWC
Solder Butt Water Resistant Insulated Heat Shrink Connector (100 Pack)
Bespoke IP20 Soldered Ends 50cm Cable
AB65
Bespoke IP65 Soldered Ends 50cm Cable
ABADD
1m Additional Cable
+ Item(s) Sold Separately. ^ Recommended 10m Max Length (>10m Wire In Parallel). * When Used With A Dimmable Driver. # Bespoke Services Additional Cost.
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
183
5W/m 24V RGB COB LED Strip IP20 / IP67
Adhesive
IP20 Supplied In 40m Reels IP65 Supplied In 30m Reels Or With Bespoke Cutting Service#
• Continuous And Even Light Effect
• 50mm Cut Points - 840 LEDs/m
• Max Length Powered Single End 10m and 20m Double Ended
• Customised Bespoke Service Available#
Bespoke Service Customised & Ready To Go
IP20 150mm
50mm
• Express Service • Cost Effective & Reliable
10mm
• Supplied On Reels & In Bags • Work Carried Out To The Highest Standard
IP67
• Tailored Labelling To Suit Your Project Requirements
150mm
12mm
50mm
• Every Item Is Tested Before Packaging • Circuit Design Service Available 24mm
6mm
Code AST005/COB/RGB
AST005IP/COB/RGB
184
Version IP20
IP67
10mm
14mm
5mm
7mm
Colour Temp
Useful Lumens
Red
≤37lm
Total Lumens ≤37lm
Green
≤24lm
≤24lm
Blue
≤141lm
≤141lm ≤37lm
Red
≤37lm
Green
≤21lm
≤21lm
Blue
≤129lm
≤129lm
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
LED Strip Profiles+ For More Info See Page 221
APA001
APA002
APA003
APA004
APAC06
APA007
APA008
APA112
APA222AL
APA333AL
APAORC/WH
5W/m Compatible Drivers 24V LED Drivers+ For More Info See Page 218 Code
Specification
Length
ADRCV2415
24V 15W
3m Max
ADRCV2430
24V 30W
6m Max
ADRCV2460
24V 60W
12m Max
ADRCV2480
24V 80W
16m Max
ADRCV24100
24V 100W
20m Max^
ADRCV24150
24V 150W
30m Max^
ADRCV24200
24V 200W
40m Max^
ADRCV24320
24V 320W
64m Max^
Controllers Colour 1++ For More Info See Page 197 Code
Description
ASCRF/RGBW/REC
One Zone 12-24VDC RGBW LED Receiver
ASCRF/RGBW/RMT
RGBW LED Remote Controller
Other Accessories Additional Items+
Bespoke Service# For More Info See Page 153
Code
Description
Code
Description
AHSTC
Clear Heat Shrink Tubing 30cm Length
AB00
Bespoke Cut To Length
ASGL02
Non-Acidic LED Strip Silicon Sealant
AB20
ASBWC
Solder Butt Water Resistant Insulated Heat Shrink Connector (100 Pack)
Bespoke IP20 Soldered Ends 50cm Cable
AB67
Bespoke IP67 Soldered Ends 50cm Cable
ABADD
1m Additional Cable
+ Item(s) Sold Separately. ^ Recommended 10m Max Length (>10m Wire In Parallel). * When Used With A Dimmable Driver. # Bespoke Services Additional Cost.
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
185
20W/m 24V RGB+W LED Strip IP20 / IP65
Adhesive
IP20 Supplied In 40m Reels IP65 Supplied In 30m Reels Or With Bespoke Cutting Service#
• 100mm Cut Point Intervals • Soldered Connection Only
• Warm White (WW) 3000K & Cool White (CW) 4000K
• 120 LED/m
• Customised Bespoke Service Available#
Bespoke Service Customised & Ready To Go
100mm
• Express Service
12mm
• Cost Effective & Reliable • Supplied On Reels & In Bags • Work Carried Out To The Highest Standard • Tailored Labelling To Suit Your Project Requirements • Every Item Is Tested Before Packaging • Circuit Design Service Available
Code
Version
Colour Temp
Useful Lumens
Total Lumens
AST020/RGBWW
IP20
Warm White
≤980lm
≤980lm
AST020/RGBCW
IP20
Cool White
≤1060lm
≤1060lm
AST020/RGBWW & AST020/RGBCW
Red
≤100lm
≤100lm
IP20
Green
≤330lm
≤330lm
Blue
≤80lm
≤80lm
AST020IP/RGBWW
IP65
Warm White
≤800lm
≤800lm
AST020IP/RGBCW
IP65
Cool White
≤900lm
≤900lm
AST020IP/RGBWW & AST020IP/RGBCW
Red
≤100lm
≤100lm
IP65
Green
≤330lm
≤330lm
Blue
≤90lm
≤90lm
186
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
LED Strip Profiles+ For More Info See Page 221
APA001
APA002
APA003
APA004
APAC06
APA007
APA008
APA112
APA222AL
APA333AL
APAORC/WH
20W/m Compatible Drivers 24V LED Drivers+ For More Info See Page 218 Code
Specification
Length
ADRCV2415
24V 15W
0.75m Max
ADRCV2430
24V 30W
1.5m Max
ADRCV2460
24V 60W
3m Max
ADRCV2480
24V 80W
4m Max
ADRCV24100
24V 100W
5m Max^
ADRCV24150
24V 150W
7.5m Max^
ADRCV24200
24V 200W
10m Max^
ADRCV24320
24V 320W
16m Max^
Controllers Colour 1++ For More Info See Page 197 Code
Description
ASCRF/RGBW/REC
One Zone 12-24VDC RGBW LED Receiver
ASCRF/RGBW/RMT
RGBW LED Remote Controller
Other Accessories Additional Items+
Bespoke Service# For More Info See Page 153
Code
Description
Code
Description
AHSTC
Clear Heat Shrink Tubing 30cm Length
AB00
Bespoke Cut To Length
ASGL01
Non-Acidic LED Strip Silicon Sealant
AB20
ASBWC
Solder Butt Water Resistant Insulated Heat Shrink Connector (100 Pack)
Bespoke IP20 Soldered Ends 50cm Cable
AB65
Bespoke IP65 Soldered Ends 50cm Cable
ABADD
1m Additional Cable
+ Item(s) Sold Separately. ^ Recommended 10m Max Length (>10m Wire In Parallel). * When Used With A Dimmable Driver. # Bespoke Services Additional Cost.
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
187
188
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
Strip Connector & Profile Compatibility Charts
12V Strip Accessories Part Code
Strip
Volts
APA001
APA002
APA003
APA004
APAC06
APA007
APA008
ASTC/UNI
IP20 5W
12+24
•
•
•
•
ASTC/UNI/L90
IP20 5W
12+24
•
•
•
•
•
•
•
•
•
ASCC8MM/LE
IP20 5W
12
IP20 5W
12
•
•
•
ASCC8MM/IP/LE
IP65 5W
12
•
•
•
•
•
•
•
ASCC8MM/IP/2CAB
IP65 5W
12
•
•
•
•
•
•
•
ASCC8MM/IP/CUP
IP65 5W
12
•
•
•
•
•
•
•
ASCC8MM/CUP
•
12
•
IP20 5W
•
ASCC8MM/2CAB
Volts
APA001
APA002
APA003
APA004
APAC06
APA007
APA008
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
• •
• •
APA112T APA222AL
• • • •
24V Strip Accessories Part Code
Strip
IP20 ASTC/UNI 12+24 5-15W IP20 ASTC/UNI/L90 12+24 5-15W IP20 COB ASCC8MM/LE 24 9-10W IP20 COB ASCC8MM/2CAB 24 9-10W IP20 COB ASCC8MM/CUP 24 9-10W IP20 ASCC10MM/LE 24 10-15W IP20 ASCC10MM/2CAB 24 10-15W IP65 ASCC10MM/IP/LE 24 10-15W IP65 ASCC10MM/IP/2CAB 10-15W 24 IP65 ASCC10MM/IP/CUP 24 10-15W
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
•
• • • •
• • • •
APA112T APA222AL
•
• •
189
LED Strip Accessories UniCube - Solderless LED Strip Connector............................................ 192 LED Strip Connector Range .................................................................... 194 Colour1+ RF Remote & Controls............................................................. 197 LED Strip Stair Controller......................................................................... 198 1-10V | StripMOD - LED Strip Controller................................................. 199 DALI | StripMOD - LED Strip Controller................................................... 200 DALI | StripMod - 4-In-1 Strip Controller................................................. 201 DMX | StripMOD - LED Strip Controller................................................... 202 DMX | StripMOD - Wall Station................................................................ 203
UniCube LED Strip Connector The Only One in the World That You Can Terminate Twin and Earth Into!
AS SEEN BY OVER 5.5 MILLION VIEWERS ON
SCAN TO WATCH THE VIDEO
Perfect Connection Without The Need to Solder The UniCube LED Strip Connector was developed with speed & simplicity in mind. An elegant and easy to use revolutionary product, merging the terminal block, connector and coupler into one
Straight Connector
90º Connector
1 Connector 3 Connections
Live End Strip to Cable
LED Strip Coupler Strip to Strip
Cable Coupler Cable to Cable
Maximum Load Per Connector: 150W Max @ 24V / 75W Max @ 12V
192
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
• Fits 8mm And 10mm Width All LED Strips
• Allows Fast Connection Of Strip To Strip, Cable To Strip, And Cable To Cable • Fits In APA004 & APA007 Profiles
• Manufactured from Clear Optical Polycarbonate to Allow Maximum Light Transmission
• Faster Than Soldering
• Best Used With Solid Core Cables
• Requires Only A Screwdriver
• 10 Packs Available
Code
22mm
12.5mm
Quantity
Type
1
Straight
ASTC/UNI/10PK
1x10 Pack
Straight
ASTC/UNI/L90
1
90°
1x10 Pack
90°
ASTC/UNI
ASTC/UNI/L90/10PK
“
9.5mm
22mm
9.5mm
12.5mm
Max 13mm
• 3-In-1 Universal Design
12mm 10mm
Universal LED Strip Connector
Max 13mm
UNICUBE
22mm
I can’t believe nobody thought of this simple but effective solution before. I absolutely love these little beauties!
”
- Robert Aslan, Aslan Electrical Services
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
193
Connectors For LED Strip
P1 8mm IP20 Connectors*
Double Ended Connector
Live End
P1 8mm IP65 Connectors*
Coupler
Double Ended Connector
Live End
Coupler
Code
Description
Code
Description
Cable
ASCC8MM/LE
Live End
ASCC8MM/IP/LE
Live End
0.51m
ASCC8MM/LE/2M
Live End 2 Metre Tail
ASCC8MM/IP/CUP
Coupler
ASCC8MM/CUP
Coupler
ASCC8MM/IP/2CAB
Double Ended
0.17m
ASCC8MM/2CAB
Double Ended ASCC8MM/IP/LE/10PK
Live End 10 Pack
0.51m
ASCC8MM/LE/10PK
Live End 10 Pack
ASCC8MM/IP/CUP/10PK
Coupler 10 Pack
ASCC8MM/LE/2M/10PK
Live End 2 Metre Tail 10 Pack
ASCC8MM/IP/2CAB/10PK
Double Ended 10 Pack
ASCC8MM/CUP/10PK
Coupler 10 Pack
ASCC8MM/2CAB/10PK
Double Ended 10 Pack
ASCC8MM IP20 Compatibility
0.17m
ASCC8MM/IP IP65 Compatibility
Code
Power
PCB Width
Type
Code
Power
PCB Width
Type
AST005
5.0W/m
8mm
IP20
AST005IP
5.0W/m
8mm
IP65
AST010/COB
10W/m
8mm
IP20
AST09L/COB
9W/m
8mm
IP20
194
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
COB IP20 Connectors*
Navigate Corners Easily With Our COB Corner Connector
Code
Description
ASCC/COB8/COR
Corner Connector for COB
ASCC/COB8/COR/10PK Corner Connector for COB 10 Pack
ASCC/COB8/COR Compatibility Code
Power
PCB Width
Type
AST010/COB
10W/m
8mm
IP20
AST09L/COB
9W/m
8mm
IP20
P1 10mm IP20 Connectors*
P1 10mm IP65 Connectors*
Double Ended Connector
Double Ended Connector
Live End
Live End
Coupler
Code
Description
Cable
Code
Description
Cable
ASCC10MM/LE
Live End
0.51m
ASCC10MM/IP/LE
Live End
0.51m
ASCC10MM/2CAB
Double Ended
0.16m
ASCC10MM/IP/CUP
Coupler
ASCC10MM/IP/2CAB
Double Ended
0.17m
ASCC10MM/LE/10PK
Live End 10 Pack
0.51m
ASCC10MM/2CAB/10PK
Double Ended 10 Pack
0.16m
ASCC10MM/IP/LE/10PK
Live End 10 Pack
0.51m
ASCC10MM/IP/CUP/10PK
Coupler 10 Pack
ASCC10MM/IP/2CAB/10PK Double Ended 10 Pack
ASCC10MM IP20 Compatibility
0.17m
ASCC10MM/IP IP65 Compatibility
Code
Power
PCB Width
Type
Code
Power
PCB Width
Type
AST010
10W/m
10mm
IP20
AST010IP
10W/m
10mm
IP65
AST015
15W/m
10mm
IP20
AST015IP
15W/m
10mm
IP65
* Max. 40W @12V, 80W @24V
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
195
196
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
Colour1+
12-24V RGB/RGB+W Single Zone LED Strip Control Receiver & Remote
• Pair Multiple Receivers To One Remote Control • Single Zone Control
• Maximum 8 Receivers Can Be Paired To One Remote Control
• Synchronise Receiver Output
• 30m Maximum Range (Uninterrupted)
• Blend Warm, Cool Or Daylight From RGB Or RGBW
• 3x AAA Batteries Required† • Compatible With RGB/RGB+W LED Strip
Compatibility* Colour
IP20
RGB
AST005IP/COB/RGB
5W/m
IP67
RGB
AST0144/RGB
14.4W/m
IP20
RGB
AST0144IP/RGB
14.4W/m
IP65
RGB
AST020/RGBWW
20W/m
IP20
RGBWW
AST020IP/RGBWW
20W/m
IP65
RGBWW
AST020/RGBCW
20W/m
IP20
RGBCW
AST020IP/RGBCW
20W/m
IP65
RGBCW
46.5mm
IP
5W/m
16mm
Power/m
AST005/COB/RGB
120mm
17.6mm
48mm
Code
145mm
Code
Description
Power
Output
Signal Type
ASCRF/RGBW/REC
Receiver
240W Max. (12V) 480W Max. (24V)
5A x 4 Channels
RF
ASCRF/RGBW/RMT
Remote
x3 AAA Batteries†
RF
Driver & Strip Required. †Batteries Not Included. *Item(s) Sold Separately
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
197
Stair Controller StripMOD
32 Step PIR Stair Light Controller With Digital SPI Output
• 32 Step Capacity, 1A Per Step Max • 2 x Digital RGB SPI Signal Output, Compatible With 28 Digital LED Strip ICs
• Adjustable Colour, Speed And Brightness Modes
• Easy Programming With OLED Display
• 2 x PIR Sensors & Daylight Sensor, Option To Use A Retractive Switch
• Integrated Rapid Self-Test Function
• PIR Cut-out 20mm
• 4 Selectable LED Strip Modes
• Can Be Used With Constant Voltage Single Colour LED Strip Or Digital/SPI RGB Strip
Easy Programming
68mm
25.5mm
86mm
186mm
PIR Sensors Included
SCAN QR CODE FOR PRODUCT GUIDE VIDEO
Code
Sensor
Voltage
ASCDIM/SLC32
Lux
5-24V DC
198
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
1-10V StripMOD
Constant Voltage Dimming Unit (20A)
• Compatible With Any 1-10V System • 1-100% Dimming Range
• 4 Channel 5A Output (4x60w At 12v / 4x120w At 24v)
• Smooth Dimming
• LED Driver & LED Strip Required
• High Performance
18mm
45.6mm
178.9mm
Code ASCDIM/1-10
e: sales@allledgroup.com
t: 0208 841 9000
Capacity
Signal Type
4 x 5A
1-10V
w: allledgroup.com
199
DALI StripMOD
Constant Voltage Dimming Unit (8A)
• Works With DALI-1 Single Colour Strip • 1-100% Dimming Range
• 1 Channel 8A Output (1x 96w At 12v / 1x 192w At 24v)
• Smooth Dimming
• LED Driver & LED Strip Required
37mm
• High Performance
20mm
Ultra-compact size and high 8A capacity allows precise control of larger LED Strip loads
85mm 95mm
Code
Output
Signal Type
ASCDIM/DALI/8A
1x 8A
DALI
200
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
DALI StripMOD
DALI 4-In-1 LED Strip Controller
• Compatible With DALI, DALI 2
• Smooth Dimming
• Compatible With Single Colour / CCT / RGB / RGBW LED Strips
• High Performance
• Retractive Switch Push To Dim Function - On/ Off, Dimming And CCT, RGB(W) Colour Control
• 4 Channels 5A Output (4x 60W At 12V / 4x 120W At 24V)
• 1 - 100% Dimming Range
54mm
28mm
170mm
Code
Output
Signal Type
ASCDIM/DALI/4IN1
4x 5A
DALI
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
201
DMX StripMOD
• 1-100% Dimming Range
• 4 Channel 5A Output (4x 60w At 12v / 4x 120w At 24v)
• Smooth Dimming
• LED Driver & LED Strip Required
• High Performance
• Compatible With RGB/RGB+W LED Strips
22mm
46mm
• Compatible With DMX512
Constant Voltage Dimming Unit (20A)
178mm
Capacity
Signal Type
ASCDIM/DMX
Code
4x 5A
DMX
202
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
DMX StripMOD
1 Zone RGBW Wall Mounted Controller
• Universal RGBW And RGB DMX512 Wired Signal Output
• 1 Gang 35mm Backbox Required
• Touch Sensitive Glass Control Panel
• 5 Core Power Cable Recommended For DMX Wiring
• For Use With ASCDIM/DMX
• 1 Zone Control With 4 Programmable Scenes • 10 Built-In Colour Changing Effects, On/Off And 1-100% Dimming Control
• 12/24V DC Driver Required* • Available In Gloss White And Black Finish
• Create Over 16 Million Colours Using RGBW Buttons
Colour Options*
29mm
86mm
86mm
ASC/DMX/WS1/B Gloss Black
ASC/DMX/WS1/W Gloss White
Code
Finish
Operating Voltage
ASC/DMX/WS1/W
Gloss White
12-24V DC
ASC/DMX/WS1/B
Gloss Black
12-24V DC *Item(s) Sold Separately
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
203
LED Drivers Nano-Drive - 2-4W 350mA LED Driver.................................................... 206 Drive350 - 1-11W 350mA LED Driver...................................................... 207 Drive350 - 1-4W 350mA LED Driver........................................................ 208 Drive350 - 4-9W 350mA LED Driver........................................................ 209 Drive350 - 9-18W 350mA LED Driver...................................................... 210 Drive350 - 12-25W 350mA LED Driver.................................................... 211 UNIDRIVE-CC - 12W DALI Driver............................................................ 212 UNIDRIVE-CC - 30W DALI Driver............................................................ 213 UNIDRIVE-CC - 40W DALI Driver............................................................ 214 UNIDRIVE-CC - 60W DALI Driver............................................................ 215 Drive12 - 12V LED Drivers........................................................................ 216 Drive12TD - 12V Dimmable LED Drivers................................................. 217 Drive24 - 24V LED Drivers........................................................................ 218 Drive24TD - 24V Dimmable LED Drivers................................................. 219
Nano
2-4W 350mA Dimmable IP55 Constant Current LED Driver
FITS THROUGH
28mm HOLE
• IP55 Rating
• Max. DC Loom Length 200m (1.5mm² Cable)
• Compact Size Fits through A 28mm Hole
• Load: 1…4 PCS x 1W LED (350mA) 1 PC x 3W LED (350mA)
• 1…4W Capacity (On/Off) • 2…4W Capacity (Dimmable) • Pre-Wired Unit With Tough High Temperature Cables
Compatibility*
18mm
Code
Name
Operating Load
AMKR012
Micro
1...4 PCS
118
AMKR020
Mini
1...4 PCS
120
AGLX020
Britannia
1...4 PCS
126
APF032AL
Pathfinder
1...4 PCS
127
ALRE032AL
Dawn
1...4 PCS
142
ALSQ032
Sloane
1...4 PCS
139
ALRD032
Oxford
1...4 PCS
138
AMKR032
Midi
1...4 PCS
122
AGLH035
Halo
1...4 PCS
125
AMKR044
Vector
1 PC
124
AGL032
Noble 1/Marine 1
1...4 PCS
128 / 134
AGL045
Noble 3/Marine 3
1 PC
130 / 135
Page
19.5mm
79mm
Ø28mm
Code
Watts
Output Current
Output Voltage
ADRCC350NANOTD/2-4
2-4W
350mA
6-12V DC *Item(s) Sold Separately
206
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
Drive350
1-11W 350mA Constant Current LED Driver
• Loop-In Loop-Out Terminals • Max. DC Loom Length 200m (1.5mm2 cable) • Easy-Wire Large Terminals • Short Circuit, Overload, Over-Voltage, and Thermal Protection
• Load: 1…11 PCS x 1W LED (350mA) 1...3 PCS x 3W LED (350mA) 1 PC x 7W LED (350mA)
Operating Load
Name
Page
AMKR012
Micro
1...11 PCS
118
AMKR020
Mini
1...11 PCS
120
AGLX020
Britannia
1...11 PCS
126
APF032AL
Pathfinder
1...11 PCS
127
ALRE032AL
Dawn
1...11 PCS
142
ALSQ032
Sloane
1...11 PCS
139
ALRD032
Oxford
1...11 PCS
138
AMKR032
Midi
1...11 PCS
122
AGLH035
Halo
1...11 PCS
125
AMKR044
Vector
1...3 PCS
124
AGL032
Noble 1/Marine 1
1...11 PCS
128 / 134
AGL045
Noble 3/Marine 3
1...3 PCS
130 / 135
AGL060
Noble 7/Marine 7
1 PC
132 / 136
98.5mm
Ø46mm
39mm
Code
22mm
Compatibility*
Code
Watts
Output Current
Output Voltage
ADRCC350/1-11
1-11W
350mA
2-34V DC *Item(s) Sold Separately
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
207
Drive350
1-4W 350mA Dimmable Constant Current LED Driver
• Compact Size
• Max. DC Loom Length 200m (1.5mm2 Cable)
• Dimmable
• Load: 1...4 PCS x 1W LED (350mA) 1 PC x 3W LED (350mA)
• Flicker Free Dimming Pre-Wired Cables
Name
Operating Load
Page
AMKR012
Micro
1...4 PCS
118
AMKR020
Mini
1...4 PCS
120
AGLX020
Britannia
1...4 PCS
126
APF032AL
Pathfinder
1...4 PCS
127
ALRE032AL
Dawn
1...4 PCS
142
ALSQ032
Sloane
1...4 PCS
139
ALRD032
Oxford
1...4 PCS
138
AMKR032
Midi
1...4 PCS
122
AGLH035
Halo
1...4 PCS
125
AMKR044
Vector
1 PC
124
AGL032
Noble 1/Marine 1
1...4 PCS
128 / 134
AGL045
Noble 3/Marine 3
1 PC
130 / 135
Ø35mm
38mm
21mm
Code
27mm
Compatibility*
Code
Watts
Output Current
Output Voltage
ADRCC350TD/1-4
1-4W
350mA
6-12V DC *Item(s) Sold Separately
208
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
Drive350
4-9W 350mA Dimmable Constant Current LED Driver
• Easy Wire Large Terminals • Dimmable • Flicker Free Dimming • Max. DC Loom Length 200m (1.5mm2 Cable)
• Load: 4…9 PCS x 1W LED (350mA) 1...3 PCS x 3W LED (350mA) 1 PC x 7W LED (350mA)
Name
Operating Load
Page
AMKR012
Micro
4...9 PCS
118
AMKR020
Mini
4...9 PCS
120
AGLX020
Britannia
4...9 PCS
126
APF032AL
Pathfinder
4...9 PCS
127
ALRE032AL
Dawn
4...9 PCS
142
ALSQ032
Sloane
4...9 PCS
139
ALRD032
Oxford
4...9 PCS
138
AMKR032
Midi
4...9 PCS
122
AGLH035
Halo
4...9 PCS
125
AMKR044
Vector
1...3 PCS
124
AGL032
Noble 1/Marine 1
4...9 PCS
128 / 134
AGL045
Noble 3/Marine 3
1...3 PCS
130 / 135
AGL060
Noble 7/Marine 7
1 PC
132 / 136
Ø43mm
39mm
Code
22mm
Compatibility*
115mm
Code
Watts
Output Current
Output Voltage
ADRCC350TD/4-9
4-9W
350mA
11-26V DC *Item(s) Sold Separately
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
209
Drive350
9-18W 350mA Dimmable Constant Current LED Driver
• Easy Wire Large Terminals • Dimmable • Flicker Free Dimming • Max. DC Loom Length 200m (1.5mm2 Cable)
• Load: 9…18 PCS x 1W LED (350mA) 3...6 PCS x 3W LED (350mA) 2 PCS x 7W LED (350mA)
Name
Operating Load
Page
AMKR012
Micro
9...18 PCS
118
AMKR020
Mini
9...18 PCS
120
AGLX020
Britannia
9...18 PCS
126
APF032AL
Pathfinder
9...18 PCS
127
ALRE032AL
Dawn
9...18 PCS
142
ALSQ032
Sloane
9...18 PCS
139
ALRD032
Oxford
9...18 PCS
138
AMKR032
Midi
9...18 PCS
122
AGLH035
Halo
9...18 PCS
125
AMKR044
Vector
3...6 PCS
124
AGL032
Noble 1/Marine 1
9...18 PCS
128 / 134
AGL045
Noble 3/Marine 3
3...6 PCS
130 / 135
AGL060
Noble 7/Marine 7
2 PCS
132 / 136
Ø55mm
44mm
Code
28mm
Compatibility*
127mm
Code
Watts
Output Current
Output Voltage
ADRCC350TD/9-18
9-18W
350mA
28-57V DC *Item(s) Sold Separately
210
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
Drive350
12-25W 350mA Dimmable Constant Current LED Driver
• Easy Wire Large Terminals • Dimmable • Flicker Free Dimming • Max. DC Loom Length 200m (1.5mm2 Cable)
• Load: 12…25 PCS X 1W LED (350mA) 4...8 PCS x 3W LED (350mA) 1...3 PCS x 7W LED (350mA)
Name
Operating Load
Page
AMKR012
Micro
12...25 PCS
118
AMKR020
Mini
12...25 PCS
120
AGLX020
Britannia
12...25 PCS
126
APF032AL
Pathfinder
12...25 PCS
127
ALRE032AL
Dawn
12...25 PCS
142
ALSQ032
Sloane
12...25 PCS
139
ALRD032
Oxford
12...25 PCS
138
AMKR032
Midi
12...25 PCS
122
AGLH035
Halo
12...25 PCS
125
AMKR044
Vector
4...8 PCS
124
AGL032
Noble 1/Marine 1
12...25 PCS
128 / 134
AGL045
Noble 3/Marine 3
4...8 PCS
130 / 135
AGL060
Noble 7/Marine 7
1...3 PCS
132 / 136
127mm Ø55mm 44mm
Code
28mm
Compatibility*
Code
Watts
Output Current
Output Voltage
ADRCC350TD/12-25
12-25W
350mA
36-78V DC *Item(s) Sold Separately
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
211
12W DALI & 1-10V Constant Current Driver
UNIDRIVE-CC
• DALI, DALI2, (0)1-10V, Retractive Push Dimming All-In-One Unit • Selectable Constant Current Output By DIP Switch
• Wide Output Voltage • Short Circuit / Over Temperature / Over Voltage Protection
Compatibility* Page 28
Defender Fixed
1 PC
Defender Adjustable
1 PC
30
Defender Mini
1 PC
27
Orbit 6 CCT
1 PC
34
Orbit 12 CCT
1 PC
35
1W Marker Light
3...12 PCS
128
3W Marker Light
1...4 PCS
130
7W Marker Light
1...2 PCS
132
Code
Operating Voltage
Operating Current
ADRCC12D/100-440MA
220-240V AC
0.07A
Ø54mm
46mm
Operating Load
23.8mm
Name
120mm
Max Power Output
12.6W
Max Output Voltage
Current / Output / Voltages (DC)
55V DC
100mA / 0.9-4W / 9-40V 180mA / 1.60-7.2W / 9-40V 270mA / 2.40-10.8W / 9-40V 350mA / 3.2-12.6W / 9-40V 440mA / 4-11.88W / 9-40V *Item(s) Sold Separately
212
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
30W DALI & 1-10V Constant Current Driver
UNIDRIVE-CC
• DALI, DALI2, (0)1-10V, Retractive Push Dimming All-In-One Unit • Selectable Constant Current Output By DIP Switch
• Wide Output Voltage • Short Circuit / Over Temperature / Over Voltage Protection
Compatibility* Operating Load
Page 35
1 PC 1 PC
36
Orbit 24 CCT
1 PC
37
1W Marker Light
3...23 PCS
128
3W Marker Light
1...7 PCS
130
7W Marker Light
1...3 PCS
132
22mm
Orbit 12 CCT Orbit 18 CCT
Ø73mm 67mm
Name
103mm
Code
Operating Voltage
Operating Current
Max Power Output
ADRCC30D/300-900MA
220-240V AC
0.16A
30W
Max Output Voltage
Current / Output / Voltages (DC)
68V DC
300mA / 2.7-17W / 9-58V 350mA / 3-20W / 9-58V 400mA / 3.6-23W / 9-58V 450mA / 4-26W / 9-58V 500mA / 4.5-29W / 9-58V 550mA / 5-30W / 9-55V 600mA / 5.4-30W / 9-50V 650mA / 5.8-30W / 9-46V 700mA / 6.3-30W / 9-42V 750mA / 6.7-30W / 9-40V 800mA / 7.2-30W / 9-38V 850mA / 7.6-30W / 9-35V 900mA / 8.1-30W / 9-34V *Item(s) Sold Separately
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
213
40W DALI & 1-10V Constant Current Driver
UNIDRIVE-CC
• DALI, DALI2, (0)1-10V, Retractive Push Dimming All-In-One Unit • Selectable Constant Current Output By DIP Switch
• Wide Output Voltage • Short Circuit / Over Temperature / Over Voltage Protection
Compatibility* Page
Altitude 32W
1 PC
64
Altitude 40W
1 PC
67
Ø85mm 79mm
Operating Load
23.8mm
Name
123mm
Code
ADRCC40D/700-1200MA
Operating Voltage
220-240V AC
Operating Current
0.22A
Max Power Output
40W
Max Output Voltage
Current / Output / Voltages (DC)
68V DC
700mA / 6.3-40W / 9-57V 750mA / 6.7-40W / 9-54V 800mA / 7.2-40W / 9-50V 850mA / 7.6-40W / 9-47V 900mA / 8.1-40W / 9-45V 950mA / 8.5-40W / 9-42V 1000mA / 9.0-40W / 9-40V 1050mA / 9.5-40W / 9-38V 1100mA / 9.9-40W / 9-36V 1150mA / 10.3-40W / 9-35V 1200mA / 10.8-40W / 9-33V *Item(s) Sold Separately
214
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
60W DALI & 1-10V Constant Current Driver
UNIDRIVE-CC
• DALI, DALI2, (0)1-10V, Retractive Push Dimming All-In-One Unit • Selectable Constant Current Output By DIP Switch
• Wide Output Voltage • Short Circuit / Over Temperature / Over Voltage Protection
Compatibility* Operating Load
Page
Altitude 32W
1 PC
64
Altitude 40W
1 PC
67
30mm
58mm
Name
202mm
Ø67mm
Code
ADRCC60D/900-1750MA
Operating Voltage
220-240V AC
Operating Current
Max Power Output
0.32A
60W
Max Output Voltage
Current / Output / Voltages (DC)
68V DC
900mA / 8.1-52.2W / 9-58V 1050mA / 9.4-60W / 9-58V 1200mA / 10.8-60W / 9-50V 1400mA / 12.6-60W / 9-43V 1750mA / 15.7-60W / 9-34V *Item(s) Sold Separately
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
215
Drive12
12V Constant Voltage LED Drivers
• 12V Constant Voltage
• Screw Terminals
• Zero Load Function
• SELV, Over Voltage Protection, Over Current Protection, Overload Protection, Thermal Cut-Out, Short Circuit Protection
• Non-Dimmable
Product
Operating Load
Output Current
ADRCV1215
15W 12V DC Constant Voltage Driver
0-15W
1.25A
ADRCV1230
30W 12V DC Constant Voltage Driver
0-30W
2.5A
ADRCV1260
60W 12V DC Constant Voltage Driver
0-60W
5A
ADRCV1280
80W 12V DC Constant Voltage Driver
0-80W
6.66A
ADRCV12100
100W 12V DC Constant Voltage Driver
0-100W
8.3A
Code
Dimensions Cutout: Ø47mm Width: 40mm Length: 101mm Height: 20mm Cutout: Ø51mm Width: 45mm Length: 123mm Height: 19mm Cutout: Ø55mm Width: 45mm Length: 170mm Height: 28mm Cutout: Ø55mm Width: 45mm Length: 170mm Height: 28mm Cutout: Ø55mm Width: 45mm Length: 170mm Height: 28mm
For Product Compatibility Please Refer to Rear of Catalogue
216
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
Drive12TD
12V Constant Voltage Triac Dimmable LED Drivers
• 12V Constant Voltage
• Screw Terminals
• Available In 25W, 50W, 100W And 150W
• SELV, Overload, No Load, Short Circuit, Thermal & Overcurrent Protection
• Dimmable - Compatible with Trailing & Leading Edge Dimmers
Product
Operating Load
Output Current
Dimensions
ADRCV1225TD
25W 12V DC Constant Voltage Dimmable Driver
1.25 - 30W
2.5A
Cutout: Ø51mm Width: 46mm Length: 158mm Height: 18mm
ADRCV1250TD
50W 12V DC Constant Voltage Dimmable Driver
2.5 - 50W
4.16A
Cutout: Ø64mm Width: 58mm Length: 177mm Height: 22mm
ADRCV12100TD
100W 12V DC Constant Voltage Dimmable Driver
5 - 100W
8.33A
Cutout: Ø76mm Width: 67mm Length: 195mm Height: 31mm
Code
For Product Compatibility Please Refer to Rear of Catalogue e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
217
Drive24
24V Constant Voltage LED Drivers
• 24V Constant Voltage
• Screw Terminals
• Zero Load Function
• SELV, Over Voltage Protection, Over Current Protection, Overload Protection, Thermal Cut-Out, Short Circuit Protection
• Non-Dimmable
Product
Operating Load
Output Current
ADRCV2415
15W 24V DC Constant Voltage Driver
0-15W
0.625A
ADRCV2430
30W 24V DC Constant Voltage Driver
0-30W
1.25A
ADRCV2460
60W 24V DC Constant Voltage Driver
0-60W
2.5A
ADRCV2480
80W 24V DC Constant Voltage Driver
0-80W
3.33A
ADRCV24100
100W 24V DC Constant Voltage Driver
0-100W
4.16A
ADRCV24120
120W 24V DC Constant Voltage Driver
0-120W
5A
ADRCV24150
150W 24V DC Constant Voltage Driver
0-150W
6.25A
ADRCV24200
200W 24V DC Constant Voltage Driver
0-200W
8.33A
ADRCV24320
320W 24V DC Constant Voltage Driver
0-320W
13.3A
Code
Dimensions Cutout:Ø47mm Width: 40mm Length: 101mm Height: 20mm Cutout: Ø51mm Width: 45mm Length: 123mm Height: 19mm Cutout: Ø55mm Width: 45mm Length: 170mm Height: 28mm Cutout: Ø55mm Width: 45mm Length: 170mm Height: 28mm Cutout: Ø55mm Width: 45mm Length: 170mm Height: 28mm Cutout: Ø59mm Width: 45mm Length: 316mm Height: 34mm Cutout: Ø72mm Width: 63mm Length: 180mm Height: 31mm Cutout: Ø76mm Width: 67mm Length: 195mm Height: 31mm Cutout: Ø88mm Width: 78mm Length: 215mm Height: 35mm
For Product Compatibility Please Refer to Rear of Catalogue
218
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
Drive24TD
24V Constant Voltage Triac Dimmable LED Drivers
• 24V Constant Voltage
• Screw Terminals
• Available In 25W, 50W, 100W And 150W
• SELV, Overload, No Load, Short Circuit, Thermal & Overcurrent Protection
• Dimmable - Compatible with Trailing & Leading Edge Dimmers
Product
Operating Load
Output Current
Dimensions
ADRCV2425TD
25W 24V DC Constant Voltage Dimmable Driver
1.25 - 30W
1.25A
Cutout: Ø51mm Width: 46mm Length: 158mm Height: 18mm
ADRCV2450TD
50W 24V DC Constant Voltage Dimmable Driver
2.5 - 50W
2.08A
Cutout: Ø64mm Width: 58mm Length: 177mm Height: 22mm
ADRCV24100TD
100W 24V DC Constant Voltage Dimmable Driver
5 - 100W
4.2A
Cutout: Ø76mm Width: 67mm Length: 195mm Height: 31mm
ADRCV24150TD
150W 24V DC Constant Voltage Dimmable Driver
7.5 - 150W
6.25A
Cutout: Ø76mm Width: 67mm Length: 195mm Height: 31mm
Code
For Product Compatibility Please Refer to Rear of Catalogue e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
219
Aluminium Profiles Profile1 - Shallow Surface........................................................................ 222 Profile2 - 45° Angled................................................................................ 223 Profile3 - Recessed.................................................................................. 224 Profile4 - Deep Surface............................................................................ 225 Profile6 - Flexible Surface........................................................................ 227 Profile7 - Deep Recessed........................................................................ 228 Profile8 - Double Width Surface.............................................................. 229 Stealth - Trimless...................................................................................... 230 StealthLine - Trimless............................................................................... 231
NEW
StealthEdge - Trimless............................................................................. 232
NEW
Orca - Coving............................................................................................ 233
2m Shallow Surface Profile With Diffuser
• Extruded 6063 Aircraft Aluminium
• 4 End Caps And 4 Brackets Included
• High Strength Material
• RAL9016 Painted (White Model Only)
• Click In Opal Polycarbonate Diffuser
Profile Includes • 2m Aluminium Extrusion 7mm
• 2m Opal Diffuser • 4 Clear Brackets
12mm
• 4 End Caps 18mm
Accessories*
APA/CDIF Clear Diffuser for APA001
APA/BKDIF Black Diffuser for APA001
APA/ODIF Opal Diffuser for APA001
APA001/BK/COR Black Corner Accessory
APA001/AL/ACC Accessory Pack (Aluminium)
APA001/BK/ACC Accessory Pack (Black)
APA001/WH/ACC Accessory Pack (White)
APA001/WH/COR White Corner Accessory
Accessory Pack Includes: 2 x Open End Caps / 2 x Closed End Caps / 4 x Clear Surface Mounting Fixing Code
Colour
Material
Diffuser
Aluminium
Aircraft Aluminium 6063
Opal Polycarbonate
APA001/BK
Black
Aircraft Aluminium 6063
Opal Polycarbonate
APA001/WH
White
Aircraft Aluminium 6063
Opal Polycarbonate
APA001/AL
*Item(s) Sold Separately
222
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
2m 45˚ Angled Profile With Diffuser
• Extruded 6063 Aircraft Aluminium
• 4 End Caps And 4 Brackets Included
• High Strength Material
• RAL9016 Painted (White Model Only)
• Click In Opal Polycarbonate Diffuser
Profile Includes • 2m Aluminium Extrusion 19
m
m
.2
• 4 End Caps
m
12
m
.7
25
• 4 Clear Brackets
m
m
.3
18.5mm
• 2m Opal Diffuser
Accessories*
APA/CDIF Clear Diffuser for APA002
APA/BKDIF Black Diffuser for APA002
APA/ODIF Opal Diffuser for APA002
APA002/AL/ACC Accessory Pack (Aluminium)
APA002/BK/ACC Accessory Pack (Black)
APA002/WH/ACC Accessory Pack (White)
Accessory Pack Includes: 2 x Open End Caps / 2 x Closed End Caps / 4 x Clear Surface Mounting Fixing Code
Colour
Material
Diffuser
Aluminium
Aircraft Aluminium 6063
Opal Polycarbonate
APA002/BK
Black
Aircraft Aluminium 6063
Opal Polycarbonate
APA002/WH
White
Aircraft Aluminium 6063
Opal Polycarbonate
APA002/AL
*Item(s) Sold Separately
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
223
2m Shallow Surface Profile With Diffuser
• Extruded 6063 Aircraft Aluminium
• 4 End Caps And 4 Brackets Included
• High Strength Material
• RAL9016 Painted (White Model Only)
• Click In Opal Polycarbonate Diffuser
Profile Includes
22mm
• 2m Aluminium Extrusion 6.5mm
• 2m Opal Diffuser • 4 End Caps
10.5mm
Accessories*
15.5mm
APA003/CDIF Clear Diffuser for APA003
APA003/BKDIF Black Diffuser for APA003
APA003/ODIF Opal Diffuser for APA003
APA003/AL/ACC Accessory Pack (Aluminium)
APA003/BK/ACC Accessory Pack (Black)
APA003/WH/ACC Accessory Pack (White)
Accessory Pack Includes: 2 x Open End Caps / 2 x Closed End Caps / Polymer End Caps Code
Colour
Material
Diffuser
Aluminium
Aircraft Aluminium 6063
Opal Polycarbonate
APA003/BK
Black
Aircraft Aluminium 6063
Opal Polycarbonate
APA003/WH
White
Aircraft Aluminium 6063
Opal Polycarbonate
APA003/AL
*Item(s) Sold Separately
224
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
2m Deep Surface Profile With Diffuser
• Extruded 6063 Aircraft Aluminium
• 4 End Caps And 4 Brackets Included
• High Strength Material
• RAL9016 Painted (White Model Only)
• Click In Opal Polycarbonate Diffuser
Profile Includes 16mm
• 2m Aluminium Extrusion • 2m Opal Diffuser • 4 Clear Brackets
13mm
• 4 End Caps
Accessories*
18mm
APA/CDIF Clear Diffuser for APA004
APA/BKDIF Black Diffuser for APA004
APA/ODIF Opal Diffuser for APA004
APA004/BK/COR Black Corner Accessory
APA004/AL/ACC Accessory Pack (Aluminium)
APA004/BK/ACC Accessory Pack (Black)
APA004/WH/ACC Accessory Pack (White)
APA004/WH/COR White Corner Accessory
Accessory Pack Includes: 2 x Open End Caps / 2 x Closed End Caps / 4 x Clear Surface Mounting Fixing Code
Colour
Material
Diffuser
Aluminium
Aircraft Aluminium 6063
Opal Polycarbonate
APA004/BK
Black
Aircraft Aluminium 6063
Opal Polycarbonate
APA004/WH
White
Aircraft Aluminium 6063
Opal Polycarbonate
APA004/AL
*Item(s) Sold Separately
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
225
226
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
2m Flexible Surface Profile With Diffuser
• Anodised Aluminium Finish
• Opal Polycarbonate Diffuser
• Engineered For Flexible Surface Mount Solution
• End Caps & Brackets Included
• High Strength Material
• Bend Radius: 6 Inch Maximum
Profile Includes
17mm
• 2m Aluminium Extrusion • 2m Opal Diffuser 6mm
• 4 Steel Brackets 12mm
• 4 End Caps
Accessories*
APAC06/ACC Accessory Pack (Aluminium) Accessory Pack Includes: 4 x End Caps / 4 x Steel Clips
Code
Colour
Material
Diffuser
APAC06
Aluminium
Aluminium Alloy
Opal Polycarbonate *Item(s) Sold Separately
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
227
2m Deep Recessed Profile With Diffuser
• Extruded 6063 Aircraft Aluminium
• 4 End Caps And 4 Brackets Included
• High Strength Material
• RAL9016 Painted (White Model Only)
• Click In Opal Polycarbonate Diffuser
Profile Includes 15.92mm
• 2m Aluminium Extrusion • 2m Opal Diffuser • 4 Clear Brackets
12.5mm
• 4 End Caps 17.5mm
Accessories*
APA/CDIF Clear Diffuser for APA007
APA/BKDIF Black Diffuser for APA007
APA/ODIF Opal Diffuser for APA007
APA007/AL/ACC Accessory Pack (Aluminium)
APA007/BK/ACC Accessory Pack (Black)
APA007/WH/ACC Accessory Pack (White)
Accessory Pack Includes: 2 x Open End Caps / 2 x Closed End Caps / Polymer End Caps Code
Colour
Material
Diffuser
Aluminium
Aircraft Aluminium 6063
Opal Polycarbonate
APA007/BK
Black
Aircraft Aluminium 6063
Opal Polycarbonate
APA007/WH
White
Aircraft Aluminium 6063
Opal Polycarbonate
APA007/AL
*Item(s) Sold Separately
228
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
2m Double Width Surface Profile With Diffuser
• Extruded 6063 Aircraft Aluminium
• 4 End Caps And 4 Brackets Included
• High Strength Material
• RAL9016 Painted (White Model Only)
• Click In Opal Polycarbonate Diffuser
Profile Includes 11.64mm
• 2m Aluminium Extrusion • 2m Opal Diffuser • 4 Clear Brackets
21mm
• 4 End Caps
23.4mm
Accessories*
APA008/BKDIF Black Diffuser for APA008
APA008/ODIF Opal Diffuser for APA008
APA008/AL/ACC Accessory Pack (Aluminium)
APA008/BK/ACC Accessory Pack (Black)
APA008/WH/ACC Accessory Pack (White)
Accessory Pack Includes: 2 x Open End Caps / 2 x Closed End Caps / 4 x Clear Surface Mounting Fixing Code
Colour
Material
Diffuser
Aluminium
Aircraft Aluminium 6063
Opal Polycarbonate
APA008/BK
Black
Aircraft Aluminium 6063
Opal Polycarbonate
APA008/WH
White
Aircraft Aluminium 6063
Opal Polycarbonate
APA008/AL
*Item(s) Sold Separately
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
229
2m Painted Plaster-in Trimless Profile
• Extruded 6063 Aircraft Aluminium
• Designed For Easy Installation
• High Strength Material
• Engineered For A Continuous Light Effect
• Click In Opal Polycarbonate Diffuser & End Caps Included
• 30mm Visible Aperture When Installed • Foam Protection Included To Facilitate Plastering Cutout 56 mm
Profile Includes 23 mm
• 2m Opal Diffuser • 4 End Caps
26 mm
• 2m Aluminium Extrusion
30 mm
92 mm
Accessories*
APA/CDIF Clear Diffuser for APA112T
APA/BKDIF Black Diffuser for APA112T
APA112T/BK/ACC Accessory Pack (Black)
APA112T/ACC Accessory Pack (White)
APA/ODIF Opal Diffuser for APA112T
Accessory Pack Includes: 2 x Open End Caps / 2 x Closed End Caps Code
Colour
Material
Diffuser
APA112T/BK
Black
Aircraft Aluminium 6063
Opal Polycarbonate
APA112T/WH
White
Aircraft Aluminium 6063
Opal Polycarbonate *Item(s) Sold Separately
230
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
2m Aluminium Plaster-in Trimless Profile
• Extruded 6063 Aircraft Aluminium
• Smoked Black Diffuser Available*
• Anodised Aluminium Finish
• Designed For Easy Installation
• High Strength Material
• Engineered For A Continuous Light Effect
• Click In Opal Polycarbonate Diffuser & End Caps Included
• 13mm Width Visible When Installed
Recommended Cutout 18mm
Profile Includes
12.5mm
• 4 End Caps
11mm
• 2m Opal Diffuser
13.9mm
16mm
• 2m Aluminium Extrusion
55.4mm
Accessories*
APA222/BKDIF Black Diffuser for APA008
APA222AL/ACC Accessory Pack (Aluminium)
Accessory Pack Includes: 2 x Open End Caps / 2 x Closed End Caps
Code APA222AL
Colour
Material
Diffuser
Aluminium
Aircraft Aluminium 6063
Opal Polycarbonate *Item(s) Sold Separately
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
231
2m Aluminium Edge/Tiling Profile
• Engineered For A Continuous, Seamless Light Effect
• Designed For Quick And Easy Installation
• Click-In Opal Polycarbonate Diffuser With End Caps Included
• Improves LED Strip Lifetime By Reducing Heat Build-Up
• Achieves A Smooth, Dotless Lighting Finish
Profile Includes
13mm
• 2m Aluminium Extrusion 14mm
• 2m Opal Diffuser • 4 End Caps
36mm
Accessories*
APA333AL/ACC Accessory Pack Accessory Pack Includes: 2 x Open End Caps / 2 x Closed End Caps
Code APA333AL
Colour
Material
Diffuser
Aluminium
Aircraft Aluminium
Opal Polycarbonate *Item(s) Sold Separately
232
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
2m Aluminium Coving Profile
• Designed To Create A Smooth, Continuous Concave Curve Between Wall And Ceiling
• Paintable Polar White Finish For A Clean, Modern Look
• Two-Piece Construction For Quick And Easy Installation
• End Caps Included For A Complete Solution • Compatible With LED Strips Up To 15mm Wide 20mm
Profile Includes • 2 End Caps
Accessories*
51mm
29mm
• 2m Aluminium Extrusion
36mm
APAORC/WH/ACC Accessory Pack Accessory Pack Includes: 2 x End Caps
Code APAORC/WH
Colour
Material
Polar White
Aircraft Aluminium *Item(s) Sold Separately
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
233
iQ Intelligent Lighting Control Smart-T - Dimmer..................................................................................... 238 Smart-R - Module..................................................................................... 239 Smart-E - Junction Box............................................................................ 240 Smart-S - Strip Controller........................................................................ 241 Smart-DALI - DALI Signal Generator....................................................... 243 RGBW Smart Remote.............................................................................. 244 Mono 4 Zone Remote............................................................................... 244 Smart-WS - Wall Station.......................................................................... 245 Smart-CONTACT - Window & Door Contact........................................... 246 Smart-SL - Load Stabiliser....................................................................... 247
Powerful Connectivity, Simple To Use
Independent control of LED strip
Ability to program the lights to turn on at set times
Program which lights turn on as you enter the property
Simple install for making your lights smart
Keep Smart Simple Retrofit System
Advanced Dimming Technology
Voice Control
Alexa App Control
Integrates With Alexa Compatible Devices
Global Control
Option To Keep Your Existing Light Switch
Smart Functions Work When Switch Is On Or Off
2.4GHz Hop & Mesh Technology
Effortless Commissioning & Programming
Program Without Accessing Modules
Global Technical Support
Choose Your Control
4 Zone Remote Control
4 Zone Colour Control Remote Control
4 Zone Colour Control Remote Wall Station
Smart Rotary Zigbee Dimmer Module
Phone App
For more information scan the QR code
Voice Control
Smart Rotary Zigbee Dimmer Module
SMART-T
• LiLo Technology For Common & L1 Live-In & Live-Out Wiring
• Can Be Used Independently Or In Conjunction With A Smart Hub*
• Retrofit Solution
• Can Be Used With Remote Control
• 2 - Way Wiring Compatible Using A Retractive Switch
• Can Be Used With Retractive Switch For 2 Way Control
• User Friendly Reset & Programming
64mm
6mm
12mm
27mm
27mm 9mm 24mm
26mm
Code
Description
Min Load
Max Load
AiQ/DIM250/LL
Smart Dimmer
5W
250W *Item(s) Sold Separately
238
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
Relay & Dimmer Smart Terminal Module
SMART-R
• LiLo Technology For Common & L1 Live-in & Live-Out Wiring
• Load Stabiliser Recommended*
• Retrofit Solution
• Can Be Used Independently With A Remote Or In Conjunction With A Smart Hub*
• Works With A Normal Light Switch (AC Mains)
• Fits In 35mm Backbox
• User Friendly Reset & Programming From The Light Switch
46mm
21mm
45mm
Code
Description
Min Load
Max Load
AiQ/DIM400M/LL
Dimmer
7W (LED)
400W (250W LED)
AiQ/RLY1000M/LL
Relay
20W (LED)
1000W (300W LED) *Item(s) Sold Separately
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
239
Relay & Dimmer Smart Junction Box
SMART-E
• Designed To Replace A Traditional Junction Box • Fits Through A 55mm Cutout • Zigbee Hop & Mesh Technology • Works With Existing Wiring
• Works With A Normal Light Switch (AC Mains) • User Friendly Reset & Programming From Light Switch • Can Be Used Independently With A Remote Or In Conjunction With A Smart Hub*
52mm
27mm
130mm
Ø55mm
Code
Description
AiQ/DIM400B/LN
Dimmer
Min Load -
Max Load 400W
AiQ/RLY400B/LN
Relay
-
400W (300W LED) *Item(s) Sold Separately
240
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
12-24V 5-in-1 Intelligent LED Strip Controller
SMART-S
• DIP Switch 5-In-1 LED Strip Controller • AiQ/STRIP/REC Compatible With Single Colour, CCT, RGB, RGBW & RGBWW+CW Strip
• 24V Single Colour & RGBW 384W Max. 24V RGB 288W Max. 24V CCT 192W Max. • Internal DIP Switches Allow Multiple Choices For Programming
• Flexible Can Be Used On Both A Smart System Or Just A Remote Control
• 5-in-1 Unit Can Be Preset To Control Any One Of The 5 Options
• Programmable Through A Light Switch Or Program Button On Device
• Can Be Used Independently With A Remote Or In Conjunction With A Smart Hub*
16mm
47mm
Internal DIP Switches Allow Multiple Choices For Programming 145mm
Code
Description
Min Load
AiQ/STRIP/REC
5-In-1 Strip Controller
12-24V DC *Item(s) Sold Separately
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
241
242
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
SMART-DALI
DALI 0/1-10V Signal Generator & 5A Relay
• DALI 0/1-10V Converter
• RGBW & CCT DALI Control Output
• Creates & Converts Smart Signals Into DALI Or 0/1-10V Signals
• Can Be Used With Or Without Inbuilt Relay
• Compatible With All iQ Devices • DALI Addressable And Able To Be Grouped
• For 0/1-10V Simply Set DIP Switch 10 to Down • Can Be Used Independently With A Remote Or In Conjunction With A Smart Hub*
• DALI Broadcast Mode
21mm
DIP Switch Controls
36mm
80mm
Code AiQ/DALI/0/1-10V
Capacity
Min Load
Max Load
5A
20W
1000W *Item(s) Sold Separately
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
243
Smart Remote Controls
x2 Lithium Cell 3V
x1 Lithium Cell 3V
CR2032
CR2032
Monotone Smart Remote
RGBW Smart Remote
4-Zone Remote
All in One Remote
• Supports 4 Groups For Connecting A Max. of 30 Lighting Devices
• Supports 4 Groups For Connecting A Maximum Of 30 Lighting Devices
• Can Be Used With Or Without A Zigbee Smart Hub
• 4 Zone Zigbee 5 Channel • Single Colour, Trilogy/CCT, RGB & RGB/White
• Single Colour • Can Control ALL iQ Controllers Only On & Off / Dimming
10mm
46mm
39mm
13mm
150mm
137mm
Code
Description
Code
Description
AiQ/4Z/RMT
Single Colour/4 Zones
AiQ/RGBW/RMT
All in One Remote For Colour *Item(s) Sold Separately
244
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
SMART-WS
4 Zone Smart Wall Station
• Mains Input (LN)
• Zigbee Hop & Mesh Technology
• Touch Sensitive
• Single Colour, Trilogy/CCT, RGB & RGB/White
• Glass Construction
• Requires Pairing Prior To Backbox Install
86mm
86mm
30mm
Code
Operating Voltage
AiQ/WSW/4Z
220-240V (LN) *Item(s) Sold Separately
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
245
Smart Control Wireless Door/Window Sensor
SMART-CONTACT
• Self-Adhesive Door & Window Contact
• 2 x CR2045 Batteries Included
• Easy Programming - Simply Press And Hold
• Smart Hub Required*
• Routines Enable Automation On Smart System
9mm
98mm
38mm
98mm
9mm
Code
Batteries
AiQ/DWC/WH
CR2045 x2 *Item(s) Sold Separately
246
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
SMART-SL
Smart Load Stabiliser
• Load Stabiliser
• Low Current Or Inductive Circuits
• Replaces The Traditional Synthetic Load Acting As A Load Regulator For Extremely
• Compact Design
25mm
Live
10mm
20mm
Load
• Consumes Less Than 1W
140mm
Stabiliser
Neutral
Code
Description
AiQ/STLOAD
Load Stabiliser *Item(s) Sold Separately
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
247
Information Fire Rating Explained............................................................................... 250 What is IP Zoning?................................................................................... 251 Useful Lumens vs Total Lumens.............................................................. 253 Dimming Compatibility Charts................................................................. 254 Lux Tables................................................................................................. 260 LED Strip & Driver Compatibility Charts.................................................. 272 Our Company .......................................................................................... 274 Index......................................................................................................... 282
Fire Rating Explained As technology in both lighting and construction improves, the attention to the very serious, but containable threat that a fire can pose to a building has become central to a variety of associated industries. Domestic and commercial properties contain ceilings that although normal in appearance, are actually fire barriers and are constructed to British or European standards that will help reduce the spread of a fire and help contain it. If this barrier is breached (for example by using a downlight or by making a hole) the fixture inserted into the breach must be ‘fire rated’ and must not affect the general integrity of the ceiling and/or its fire rating. In general most UK domestic properties require fire rated fixtures and commercial properties will usually have concrete ceilings that are constructed to double up as a fire barrier (in this case fire rated fixtures are not a requirement). Please consult with your local electrician for further advice on this. It is important that the fire rated downlight is suitable for the ceiling construction in which it is to be installed in and must not compromise the integrity of the fire barrier.
RESIDENTIAL
COMMERCIAL 90 mins
Minimum Periods of Fire Resistance
18M
90 mins
60 mins
60 mins
30 mins
30 mins
60 mins
5M
10M
250
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
What is IP Zoning? As a result of European standardisation, Amendment 1 of the 17th addition of the IET Wiring Regulations (BS7671), the following regulations apply to bathroom lighting. For anything outside zones 0, 1 & 2 this is treated as ‘outside of zones’, therefore no IP requirement (More: Regulation 701.32.4 of BS7671)
ZONE 0
ZONE 1
ZONE 2
Any fittings used here must be SELV (Separated Extra Low Voltage - Max. 12 Volts) and have a minimum rating of IPX7 (IP67) (protected against immersion in water - total immersion proof).
Above the bath or shower to a height of 2.25m. A minimum rating of IPX4 is required.
The area stretching to 0.6m outside the bath or shower and above the bath or shower if over 2.25m. An IP (rating of at least IPX4 is required).
IP (Ingress Protection) Rating Explained
IPXX The first digit - Protection against ingress of foreign bodies, like: tools, dust, fingers, etc.
The second digit - Protection against ingress of liquids. Ex. IP44 offers protection against solid objects greater than 1 mm and water sprayed from all directions.
Foreign Body Ingress
Liquid Ingress
0. No protection from foreign bodies; 1. Protected against solid objects greater than 50mm (e.g. accidental touch by hands); 2. Protected against solid objects up to 12mm (e.g. fingers); 3. Protected against solid objects greater than 2.5mm (e.g. tools and wires); 4. Protected against solid objects greater than 1mm (e.g. small tools and wires); 5. Protected against dust, limited ingress (e.g. no harmful deposit); 6. Totally protected against dust.
0. No protection from liquids; 1. Protection against vertically falling drops of water (e.g. condensation); 2. Protection against direct sprays of water up to 15º degrees from vertical; 3. Protection against direct sprays of water up to 60º from vertical; 4. Protection against water sprayed from all directions limited ingress permitted; 5. Protected against low pressure jets of water from all directions - limited ingress permitted; 6. Protected against high pressure jets of water (use on ship deck) - limited ingress permitted; 7. Protected against the effects of immersion between 15cm and 1m; 8. Protected against long periods of immersion under pressure.
60cm Radius
e: sales@allledgroup.com
225cm
t: 0208 841 9000
60cm
w: allledgroup.com
cm
60
251
252
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
Useful Lumens vs Total Lumens
Non-Directional Light Measured in a 360° sphere and displayed as total lumens which reflect the uniform light in all directions Directional Light Measured in either a 90° or 120° cone and displayed as useful lumens disregarding light beyond cone area • 120° - applies to light sources with a cone of light (Beam Angle) <120° • 90° - applies to light sources with a cone of light (Beam Angle) <90° Lumens (Luminous Flux) is the unit of measurement for visible light emitted from a light source. Delving into the concept of useful lumens helps to establish a clear understanding of the distinctions among various light sources and their emitted beams.
In simple terms, when a light source is designated as directional, only the visible light within a 90° or 120° cone is considered for measurement. Any light beyond this cone remains unmeasured and does not contribute to the useful lumens.
A regular lamp distributes visible light in numerous directions, creating a broad beam angle, thereby earning the classification of a non-directional light source. On the other hand, spotlight lamps like the GU10 possess a directional beam angle where approximately 80% of their light falls within a 120° cone, categorising them as directional sources.
For instance, consider a directional lamp that emits a total of 600 lumens; however, the useful lumens might be 500. The remaining lumens are by no means wasted as they continue to be emitted from the light source into the surrounding environment. The concept of useful lumens helps us gauge the portion that falls within the specific 90° or 120° cone.
The measurement of useful lumens holds significant relevance in contemporary product design consideration. The methodology for quantifying useful lumens depends on the beam angle of the light source and the categorisation as directional or non-directional. Examples Of Non-Directional Light Sources
Altitude
e: sales@allledgroup.com
Orbit CCT
t: 0208 841 9000
Triumph
w: allledgroup.com
Conversely, if a light source is categorised as non-directional, it undergoes assessment within a 360° sphere. The total lumens are then presented as lumens or total lumens, given that the product radiates light uniformly in all directions. Examples Of Directional Light Sources
Defender Range
GU10 Lamps
Atom Range
253
Dimming Compatibility Charts AGU470D - Caterham Range ADIM/150W
AiQ/DIM250/LL
ADIM150/GRID/WH
No. of Lamps
Min
Max
No. of Lamps
Min
Max
No. of Lamps
Min
Max
1
15%
100%
1
15%
100%
1*
19%
100%
5
6%
100%
5
6%
100%
5
8%
100%
10
6%
100%
10
6%
100%
10
6%
100%
15
5%
100%
15
5%
100%
15
6%
100%
20
6%
100%
20
6%
100%
20
6%
100%
25
5%
100%
25
5%
100%
25
5%
100%
30
6%
100%
30
6%
100%
30
5%
100%
35
5%
100%
AiQ/DIM/400M/LL No. of Lamps
Min
1
14%
5
7%
AiQ/DIM/400B/LN Max
No. of Lamps
Min
Max
100%
1
12%
100%
100%
5
7%
100%
10
6%
100%
10
6%
100%
15
5%
100%
15
5%
100%
20
5%
100%
20
5%
100%
25
5%
100%
25
5%
100%
30
5%
100%
30
5%
100%
35
5%
100%
35
5%
100%
AGU501D - Morgan Range ADIM/150W
ADIM150/GRID/WH
AiQ/DIM/250/LL
No. of Lamps
Min
Max
No. of Lamps
Min
Max
No. of Lamps
Min
Max
1
16%
100%
1
16%
100%
1
25%
100%
5
19%
100%
5
19%
100%
5
15%
100%
10
18%
100%
10
18%
100%
10
15%
100%
15
6%
100%
AiQ/DIM/400M/LL
AiQ/DIM/400B/LN
No. of Lamps
Min
Max
No. of Lamps
Min
Max
1
16%
100%
1
24%
100%
5
18%
100%
5
20%
100%
10
20%
100%
10
20%
100%
15
20%
100%
15
19%
100%
20
19%
100%
20
20%
100%
*AiQ/STLOAD Required
254
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
Dimming Compatibility Charts AGU700D - Jaguar Range ADIM/150W
ADIM150/GRID/WH
AiQ/DIM250/LL
No. of Lamps
Min
Max
No. of Lamps
Min
Max
No. of Lamps
Min
Max
1
10%
100%
1
10%
100%
1
10%
100%
5
4%
100%
5
9%
100%
5
9%
100%
10
7%
100%
10
7%
100%
AiQ/DIM/400M/LL No. of Lamps
Min
10
4%
100%
15
3%
100%
20
3%
100%
25
3%
100%
30
3%
100%
35
3%
100%
AiQ/DIM/400B/LN Max
No. of Lamps
Min
Max
1
0%
100%
1
0%
100%
5
8%
100%
5
4%
100%
10
8%
100%
10
3%
100%
15
8%
100%
15
3%
100%
20
7%
100%
20
3%
100%
25
7%
100%
25
3%
100%
30
5%
100%
30
3%
100%
35
5%
100%
35
3%
100%
ATRAF/CCT - Trafalgar Range ADIM/150W
ADIM150/GRID/WH
No. of Lamps
Min
Max
No. of Lamps
Min
Max
1
13%
100%
1
13%
100%
5
10%
100%
5
10%
100%
10
8%
100%
10
8%
100%
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
255
Dimming Compatibility Charts AFD600D/CCT – Spartan ADIM/150W
ADIM150/GRID/WH
AiQ/DIM250/LL
No. of Lamps
Min
Max
No. of Lamps
Min
Max
No. of Lamps
Min
Max
1
13%
100%
1
13%
100%
1
17%
100%
5
9%
100%
5
9%
100%
5
13%
100%
8
9%
100%
8
9%
100%
8
12%
100%
10
9%
100%
10
9%
100%
10
11%
100%
AiQ/DIM/400M/LL No. of Lamps
Min
AiQ/DIM/400B/LN Max
No. of Lamps
Min
Max
1
18%
100%
1
19%
100%
5
14%
100%
5
15%
100%
8
14%
100%
8
15%
100%
10
14%
100%
10
15%
100%
AFDD10W/DTW – Polaris ADIM/150W
ADIM150/GRID/WH
AiQ/DIM250/LL
No. of Lamps
Min
Max
No. of Lamps
Min
Max
No. of Lamps
Min
Max
1
8%
100%
1
8%
100%
1
14%
100%
5
3%
100%
5
3%
100%
5
10%
100%
8
2%
100%
8
2%
100%
8
9%
100%
15
7%
100%
15
7%
100%
AiQ/DIM/400M/LL
8%
100%
11%
100%
AiQ/DIM/400B/LN
No. of Lamps
Min
Max
No. of Lamps
Min
Max
1
7%
100%
1
10%
100%
256
15 20
5
12%
100%
5
15%
100%
8
19%
100%
8
18%
100%
15
8%
100%
15
12%
100%
20
8%
100%
20
13%
100%
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
Dimming Compatibility Charts AFD05 - Atom Range ADIM/150W
ADIM150/GRID/WH
AiQ/DIM250/LL
No. of Lamps
Min
Max
No. of Lamps
Min
Max
No. of Lamps
Min
Max
1
15%
100%
1
15%
100%
1
19%
100%
5
6%
100%
5
6%
100%
5
8%
100%
10
6%
100%
10
6%
100%
10
6%
100%
15
5%
100%
15
5%
100%
15
6%
100%
20
6%
100%
20
6%
100%
20
6%
100%
25
5%
100%
25
5%
100%
25
5%
100%
30
6%
100%
30
6%
100%
30
5%
100%
35
5%
100%
AiQ/DIM/400M/LL
AiQ/DIM/400B/LN
No. of Lamps
Min
Max
No. of Lamps
Min
Max
1
14%
100%
1
12%
100%
5
7%
100%
5
7%
100%
10
6%
100%
10
6%
100%
15
5%
100%
15
5%
100%
20
5%
100%
20
5%
100%
25
5%
100%
25
5%
100%
30
5%
100%
30
5%
100%
35
5%
100%
35
5%
100%
40
5%
100%
40
4%
100%
45
5%
100%
45
4%
100%
50
5%
100%
50
4%
100%
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
40
5%
100%
45
5%
100%
50
5%
100%
257
Dimming Compatibility Charts AFD - Defender Range ADIM/150W
ADIM150/GRID/WH
AiQ/DIM250/LL
No. of Lamps
Min
Max
No. of Lamps
Min
Max
No. of Lamps
Min
Max
1
5%
100%
1
5%
100%
1
4%
100%
5
4%
100%
5
4%
100%
5
38%
100%
10
5%
100%
10
5%
100%
10
43%
100%
20
52%
100%
AiQ/DIM/400B/LN No. of Lamps
Min
AiQ/DIM/400M/LL Max
No. of Lamps
Min
Max
1
5%
100%
1
4%
100%
5
5%
100%
5
38%
100%
10
4%
100%
10
43%
100%
20
5%
100%
20
52%
100%
ADRCC350NANOTD/2-4 - Nano Driver ADIM/150W
ADIM150/GRID/WH
Qty tested
Min
Max
Qty tested
Min
Max
1
18%
100%
1
18%
100%
258
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
259
Lux Tables ABAR/4FT/CCT Barracuda 4 Foot
Room Width
200 LUX (2.4m Height) 5M 10M 15M 20M 25M 30M 35M 40M 45M 50M
Room Width
300 LUX (2.4m Height) 5M 10M 15M 20M 25M 30M 35M 40M 45M 50M
Room Length 5M 2 4 6 6 9 12 12 15 16 16
10M 3 6 9 12 16 20 20 25 25 30
15M 6 9 12 20 25 25 30 36 36 42
20M 8 12 20 25 30 36 42 42 49 56
25M 8 16 25 30 36 42 49 56 64 72
5M 3 6 8 10 12 16 16 20 25 25
10M 5 9 18 20 25 30 30 36 42 42
15M 8 16 20 25 36 42 49 49 56 64
20M 10 20 25 36 42 49 56 64 72 81
25M 12 25 30 42 49 64 72 81 90 100
30M 12 20 25 36 42 49 56 64 81 81
35M 12 20 30 36 49 56 64 72 81 90
40M 15 25 36 42 56 64 72 81 90 100
45M 16 25 36 49 64 72 81 90 110 121
50M 18 30 42 56 72 81 90 100 120 132
35M 18 30 42 56 72 81 100 110 121 144
40M 20 36 49 64 81 90 110 121 144 156
45M 25 42 56 72 90 110 121 144 156 308
50M 25 42 64 81 100 132 132 156 169 196
35M 9 16 20 25 36 42 49 49 56 72
40M 8 16 25 30 36 42 49 56 72 81
45M 12 20 25 36 42 49 56 64 81 81
50M 12 20 30 36 49 56 64 81 81 90
35M 12 20 30 42 49 56 64 72 81 90
40M 15 25 36 42 56 64 72 81 100 110
45M 16 25 36 49 64 72 81 100 110 121
50M 16 30 42 56 72 81 90 110 121 132
Room Length 30M 16 25 36 49 64 72 81 90 110 121
ABAR/5FT/CCT Barracuda 5 Foot
Room Width
200 LUX (2.4m Height) 5M 10M 15M 20M 25M 30M 35M 40M 45M 50M
Room Width
300 LUX (2.4m Height) 5M 10M 15M 20M 25M 30M 35M 40M 45M 50M
Room Length 5M 1 2 3 4 6 6 9 9 12 12
10M 2 4 6 9 12 12 16 16 20 20
15M 3 6 9 12 16 20 20 25 25 30
20M 4 8 12 16 20 25 30 30 36 36
25M 6 10 16 20 25 30 36 36 42 49
5M 1 3 6 8 9 10 12 15 16 16
10M 3 6 9 12 16 20 20 25 25 30
15M 5 9 12 20 25 25 30 36 42 42
20M 8 12 16 25 30 36 42 49 49 56
25M 8 16 25 30 36 42 49 56 72 72
30M 6 12 16 25 30 36 42 42 49 56
Room Length 30M 10 20 25 36 42 49 64 64 81 81
The information presented in the tables above is provided as a recommendation only. We strongly advise that customers verify and calculate the advice given. The quantities shown are based on the assumption that items are installed in a uniform pattern and have been rounded to match the figures in the tables. All LED Ltd. cannot be held responsible for any discrepancies between actual installations and the provided information. Ultimately, the decision on the number of units to install in any given area rests with the customer.
260
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
Lux Tables ABAR/6FT/CCT Barracuda 6 Foot
Room Width
200 LUX (2.4m Height) 5M 10M 15M 20M 25M 30M 35M 40M 45M 50M
Room Width
300 LUX (2.4m Height) 5M 10M 15M 20M 25M 30M 35M 40M 45M 50M
Room Length 5M 1 2 4 4 6 6 9 9 12 12
10M 2 4 6 9 12 12 16 16 20 20
15M 3 6 9 12 16 20 20 25 25 30
20M 4 9 12 16 20 25 30 30 36 42
25M 6 12 16 20 25 30 36 36 42 49
5M 2 3 6 8 9 10 12 16 16 16
10M 3 6 9 12 16 20 25 25 30 30
15M 6 9 16 20 24 30 30 36 42 42
20M 8 12 20 25 30 36 42 49 56 56
25M 10 16 25 30 36 42 56 56 72 72
30M 8 12 20 25 30 36 42 49 56 56
35M 8 15 20 30 36 42 49 56 64 72
40M 10 16 25 30 36 49 49 64 72 81
45M 10 20 30 36 42 56 64 72 81 81
50M 12 20 30 36 49 64 72 80 81 90
35M 12 24 30 42 49 64 72 81 90 100
40M 14 25 36 49 56 72 81 90 100 110
45M 16 30 42 49 64 72 90 100 110 121
50M 18 30 49 56 72 81 100 100 121 132
35M 10 20 30 36 42 56 64 72 81 90
40M 12 25 30 42 49 64 72 81 90 100
45M 14 25 36 49 56 72 81 90 100 110
50M 16 30 42 49 64 80 90 100 110 121
35M 15 30 42 56 64 81 90 100 121 132
40M 18 36 49 64 72 90 100 121 132 144
45M 24 36 56 72 81 99 121 132 144 156
50M 24 42 56 81 90 110 132 144 156 182
Room Length 30M 10 20 30 36 42 56 64 72 81 81
ABAR/XT4FT/CCT Barracuda Extreme 4 Foot
Room Width
200 LUX (2.4m Height) 5M 10M 15M 20M 25M 30M 35M 40M 45M 50M
Room Width
300 LUX (2.4m Height) 5M 10M 15M 20M 25M 30M 35M 40M 45M 50M
Room Length 5M 2 3 4 6 8 9 10 12 15 16
10M 3 6 8 10 16 16 20 25 25 30
15M 4 9 12 16 20 25 30 30 36 42
20M 6 12 16 20 25 30 36 42 49 49
25M 9 16 20 25 30 42 42 49 56 64
5M 3 4 8 9 12 15 16 20 20 25
10M 4 9 12 16 20 25 30 30 36 42
15M 6 12 20 25 30 36 42 49 56 56
20M 10 16 25 30 42 49 56 64 72 72
25M 12 20 30 42 49 56 64 72 81 90
30M 10 16 25 30 42 49 56 56 72 81
Room Length 30M 16 25 36 49 56 72 81 90 100 110
The information presented in the tables above is provided as a recommendation only. We strongly advise that customers verify and calculate the advice given. The quantities shown are based on the assumption that items are installed in a uniform pattern and have been rounded to match the figures in the tables. All LED Ltd. cannot be held responsible for any discrepancies between actual installations and the provided information. Ultimately, the decision on the number of units to install in any given area rests with the customer.
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
261
262
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
Lux Tables ABAR/XT5FT/CCT Barracuda Extreme 5 Foot
Room Width
200 LUX (2.4m Height) 5M 10M 15M 20M 25M 30M 35M 40M 45M 50M
Room Width
300 LUX (2.4m Height) 5M 10M 15M 20M 25M 30M 35M 40M 45M 50M
Room Length 5M 1 2 3 4 6 6 8 9 8 10
10M 2 4 6 8 9 12 12 16 16 20
15M 3 6 9 12 12 16 20 20 25 25
20M 4 9 12 16 16 20 25 25 30 36
25M 5 9 12 16 20 25 30 36 36 42
5M 1 3 4 6 8 8 12 12 12 16
10M 3 6 8 12 12 16 20 20 25 25
15M 4 9 12 16 20 25 25 30 36 36
20M 6 12 16 20 25 30 36 42 42 49
25M 8 15 20 25 30 36 42 49 56 64
30M 6 12 16 20 25 30 36 42 42 49
35M 8 12 20 25 30 36 42 49 49 56
40M 9 16 20 25 36 42 49 49 56 64
45M 10 16 25 30 36 42 49 64 72 81
50M 10 20 25 36 42 49 64 72 72 81
35M 12 18 25 36 42 49 64 64 72 81
40M 12 20 30 42 49 56 64 81 90 100
45M 14 25 36 42 56 64 72 90 100 110
50M 14 25 36 49 64 72 81 100 110 121
35M 8 12 20 25 30 36 42 49 56 64
40M 9 16 20 30 36 42 49 56 64 72
45M 10 18 25 30 42 49 56 64 72 81
50M 10 20 25 36 42 56 64 72 81 81
35M 10 20 30 36 49 56 64 72 81 90
40M 12 25 36 42 49 64 72 81 90 100
45M 14 25 36 49 64 72 81 90 100 110
50M 16 30 42 56 64 81 90 100 110 132
Room Length 30M 9 16 24 30 36 42 49 56 64 72
ABAR/XT6FT/CCT Barracuda Extreme 6 Foot
Room Width
200 LUX (2.4m Height) 5M 10M 15M 20M 25M 30M 35M 40M 45M 50M
Room Width
300 LUX (2.4m Height) 5M 10M 15M 20M 25M 30M 35M 40M 45M 50M
Room Length 5M 1 2 3 4 6 6 8 9 9 10
10M 2 4 6 8 9 12 16 16 16 20
15M 3 6 9 12 15 16 20 24 25 30
20M 4 8 12 16 20 20 25 30 36 36
25M 6 9 16 16 20 30 30 36 42 42
5M 1 3 4 6 8 9 12 12 15 15
10M 3 6 9 12 12 16 20 24 24 30
15M 4 9 12 16 20 25 30 36 36 42
20M 6 12 16 20 30 30 36 42 49 56
25M 9 15 20 30 36 42 49 56 64 64
30M 6 12 16 20 25 36 36 42 49 56
Room Length 30M 9 18 25 30 42 49 56 64 72 81
The information presented in the tables above is provided as a recommendation only. We strongly advise that customers verify and calculate the advice given. The quantities shown are based on the assumption that items are installed in a uniform pattern and have been rounded to match the figures in the tables. All LED Ltd. cannot be held responsible for any discrepancies between actual installations and the provided information. Ultimately, the decision on the number of units to install in any given area rests with the customer.
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
263
Lux Tables AFDD10W/DTW Polaris
Room Width
200 LUX (2.4m Height) 1M 2M 3M 4M 5M 6M 7M 8M 9M 10M
Room Width
300 LUX (2.4m Height) 1M 2M 3M 4M 5M 6M 7M 8M 9M 10M
Room Length 1M 4 6 6 9 9 9 12 12 16 16
2M 5 6 9 12 12 16 16 16 20 20
3M 6 9 12 16 16 20 20 25 25 30
4M 9 12 16 16 20 25 25 30 36 36
1M 6 9 9 12 12 16 16 20 20 25
2M 7 9 12 16 20 20 25 25 30 30
3M 9 12 16 20 25 30 30 36 42 42
4M 12 16 20 25 30 36 42 42 49 56
5M 9 12 16 20 25 30 30 36 36 42
6M 9 16 20 25 30 30 36 42 42 49
7M 12 16 20 25 30 36 42 49 49 56
8M 12 16 25 30 36 42 49 49 56 64
9M 16 20 25 36 36 42 49 56 64 64
10M 16 20 30 36 42 49 56 64 64 72
7M 16 25 30 42 49 56 56 64 72 81
8M 20 25 36 42 49 56 64 72 81 90
9M 20 30 42 49 56 64 72 81 90 100
10M 25 30 42 56 64 72 81 90 100 110
7M 1 1 1 2 2 2 3 3 4 4
8M 1 1 2 2 2 3 4 4 4 4
9M 1 1 2 2 3 3 4 4 6 6
10M 1 2 2 2 2 4 4 4 6 6
7M 2 2 2 3 3 4 4 6 6 6
8M 2 2 3 3 4 4 6 6 6 8
9M 2 2 3 4 4 6 6 6 9 9
10M 3 3 3 4 6 6 6 8 9 9
Room Length 5M 12 20 25 30 36 42 49 49 56 64
6M 16 20 30 36 42 49 56 56 64 72
APNL632A - Altitude 32W 600x600
Room Width
200 LUX (2.4m Height) 1M 2M 3M 4M 5M 6M 7M 8M 9M 10M
Room Width
300 LUX (2.4m Height) 1M 2M 3M 4M 5M 6M 7M 8M 9M 10M
Room Length 1M 1 1 1 1 1 1 1 1 1 1
2M 1 1 1 1 1 1 1 1 2 2
3M 1 1 1 1 1 1 1 2 2 2
4M 1 1 1 1 1 1 2 2 2 2
1M 1 1 1 1 1 1 2 2 2 2
2M 1 1 1 1 1 2 2 2 2 3
3M 1 1 1 1 2 2 2 3 3 3
4M 1 1 1 2 2 2 3 3 4 4
5M 1 1 1 1 1 2 2 2 3 3
6M 1 1 1 1 1 2 2 3 3 4
Room Length 5M 1 1 2 2 2 3 3 4 4 6
6M 1 2 2 2 3 3 4 4 6 6
The information presented in the tables above is provided as a recommendation only. We strongly advise that customers verify and calculate the advice given. The quantities shown are based on the assumption that items are installed in a uniform pattern and have been rounded to match the figures in the tables. All LED Ltd. cannot be held responsible for any discrepancies between actual installations and the provided information. Ultimately, the decision on the number of units to install in any given area rests with the customer.
264
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
Lux Tables APNL1232A - Altitude 32W 1200x300
Room Width
200 LUX (2.4m Height) 1M 2M 3M 4M 5M 6M 7M 8M 9M 10M
Room Width
300 LUX (2.4m Height) 1M 2M 3M 4M 5M 6M 7M 8M 9M 10M
Room Length 1M 1 1 1 1 1 1 1 1 1 2
2M 1 1 1 1 1 1 1 1 2 2
3M 1 1 1 1 1 1 1 2 2 2
4M 1 1 1 1 1 2 2 2 2 2
1M 1 1 1 1 1 1 1 1 2 2
2M 1 1 1 1 1 2 2 2 2 3
3M 1 1 1 1 2 2 2 3 3 3
4M 1 1 1 2 2 2 3 3 3 4
5M 1 1 1 1 2 2 2 2 3 4
6M 1 1 1 2 2 2 2 3 4 4
7M 1 1 2 2 2 2 3 4 4 4
8M 1 2 2 2 2 3 4 4 4 4
9M 2 2 2 2 4 4 4 4 4 6
10M 2 2 2 3 4 4 4 4 6 6
7M 2 2 2 3 4 4 6 6 6 6
8M 2 2 3 3 4 4 6 6 6 8
9M 2 3 3 4 4 6 6 6 9 9
10M 2 3 3 4 6 6 6 9 9 9
7M 1 1 1 1 1 2 2 2 3 3
8M 1 1 1 1 2 2 2 3 3 4
9M 1 1 1 2 2 2 2 4 4 4
10M 1 1 2 2 2 3 4 4 4 4
7M 1 1 2 2 2 3 4 4 4 6
8M 1 2 2 2 3 3 4 4 6 6
9M 1 2 2 3 3 4 4 6 6 6
10M 2 2 2 3 4 4 6 6 6 6
Room Length 5M 1 1 2 2 3 3 4 4 4 6
6M 1 1 2 2 3 4 4 4 6 6
APNL1240A - Altitude 40W 1200x600
Room Width
200 LUX (2.4m Height) 1M 2M 3M 4M 5M 6M 7M 8M 9M 10M
Room Width
300 LUX (2.4m Height) 1M 2M 3M 4M 5M 6M 7M 8M 9M 10M
Room Length 1M 1 1 1 1 1 1 1 1 1 1
2M 1 1 1 1 1 1 1 1 1 1
3M 1 1 1 1 1 1 1 1 1 2
4M 1 1 1 1 1 1 1 1 2 2
1M 1 1 1 1 1 1 1 1 2 2
2M 1 1 1 1 1 1 1 2 2 2
3M 1 1 1 1 1 1 2 2 2 2
4M 1 1 1 1 1 2 2 2 3 3
5M 1 1 1 1 1 1 1 2 2 2
6M 1 1 1 1 1 1 2 2 2 3
Room Length 5M 1 1 1 1 2 2 2 3 3 4
6M 1 1 1 2 2 2 3 4 4 4
The information presented in the tables above is provided as a recommendation only. We strongly advise that customers verify and calculate the advice given. The quantities shown are based on the assumption that items are installed in a uniform pattern and have been rounded to match the figures in the tables. All LED Ltd. cannot be held responsible for any discrepancies between actual installations and the provided information. Ultimately, the decision on the number of units to install in any given area rests with the customer.
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
265
Lux Tables AFPD006/CCT - Orbit CCT 6W
Room Width
200 LUX (2.4m Height) 1M 2M 3M 4M 5M 6M 7M 8M 9M 10M
Room Width
300 LUX (2.4m Height) 1M 2M 3M 4M 5M 6M 7M 8M 9M 10M
Room Length 1M 3 4 6 8 9 6 12 12 16 16
2M 4 6 8 9 12 12 16 16 20 20
3M 6 8 9 12 15 16 20 20 25 25
4M 8 9 12 12 16 20 25 25 30 30
1M 6 6 9 12 12 15 16 20 20 25
2M 6 9 9 12 16 20 20 25 30 30
3M 9 12 15 16 20 25 30 30 36 36
4M 12 15 16 20 25 30 36 36 42 42
5M 8 12 12 16 20 20 25 30 30 36
6M 10 12 16 20 20 30 30 36 36 42
7M 12 16 16 20 25 30 36 42 42 49
8M 12 16 20 25 30 36 42 42 49 56
9M 15 20 25 30 30 36 42 49 56 56
10M 16 20 25 30 36 42 49 56 56 63
7M 16 20 30 36 42 42 49 56 64 72
8M 20 25 30 36 42 56 56 64 72 81
9M 20 25 36 42 49 56 64 72 80 90
10M 24 30 36 49 56 64 72 81 90 99
7M 4 6 6 9 12 12 16 16 16 20
8M 4 6 8 9 12 15 16 20 20 25
9M 6 6 8 12 12 16 16 20 25 25
10M 6 9 9 12 12 16 20 20 25 30
7M 6 9 10 16 15 20 25 25 25 30
8M 8 10 12 16 16 20 25 30 30 36
9M 9 12 12 16 20 25 25 30 36 36
10M 9 12 16 16 25 25 30 35 36 42
Room Length 5M 12 16 20 25 30 36 42 42 49 56
6M 15 20 25 30 36 42 42 49 56 64
AFPD012/CCT Orbit CCT 12W
Room Width
200 LUX (2.4m Height) 1M 2M 3M 4M 5M 6M 7M 8M 9M 10M
Room Width
300 LUX (2.4m Height) 1M 2M 3M 4M 5M 6M 7M 8M 9M 10M
Room Length 1M 1 2 2 3 3 4 5 6 6 6
2M 2 2 3 3 4 6 6 6 8 8
3M 2 3 3 4 6 6 6 9 9 12
4M 3 3 4 6 6 6 9 9 12 12
1M 2 3 4 4 6 6 6 8 9 9
2M 3 3 4 6 6 6 9 9 12 12
3M 4 4 4 6 9 9 12 12 16 16
4M 4 4 6 9 9 12 15 16 16 20
5M 3 4 6 6 8 12 12 12 12 16
6M 4 4 6 6 9 10 12 15 16 20
Room Length 5M 5 6 9 9 12 15 16 16 20 25
6M 6 6 9 12 12 15 20 20 25 30
The information presented in the tables above is provided as a recommendation only. We strongly advise that customers verify and calculate the advice given. The quantities shown are based on the assumption that items are installed in a uniform pattern and have been rounded to match the figures in the tables. All LED Ltd. cannot be held responsible for any discrepancies between actual installations and the provided information. Ultimately, the decision on the number of units to install in any given area rests with the customer.
266
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
Lux Tables AFPD018/CCT - Orbit CCT 18W
Room Width
200 LUX (2.4m Height) 1M 2M 3M 4M 5M 6M 7M 8M 9M 10M
Room Width
300 LUX (2.4m Height) 1M 2M 3M 4M 5M 6M 7M 8M 9M 10M
Room Length 1M 1 1 2 2 2 3 3 4 4 2
2M 1 1 2 2 3 3 4 4 4 6
3M 1 2 2 2 4 4 6 6 6 6
4M 2 2 3 3 4 6 6 6 8 9
1M 1 2 2 3 3 4 4 6 6 6
2M 2 2 3 4 4 4 6 6 8 9
3M 2 3 3 4 6 6 6 8 9 10
4M 3 3 4 6 6 8 9 9 12 12
5M 2 3 4 4 6 6 8 8 9 9
6M 3 3 4 6 6 6 9 9 9 12
7M 3 4 4 6 6 9 9 12 12 12
8M 3 4 6 6 8 9 12 12 12 12
9M 4 6 6 8 9 12 12 12 15 16
10M 4 6 6 8 9 12 12 16 16 20
7M 4 6 6 9 10 12 12 16 16 20
8M 5 6 9 9 12 12 16 20 20 20
9M 6 8 9 10 12 16 16 20 20 25
10M 6 9 9 12 16 16 20 20 25 30
7M 2 3 3 4 4 6 6 6 9 9
8M 2 3 3 4 6 6 6 9 9 12
9M 3 3 4 4 6 6 9 9 12 12
10M 3 4 4 6 6 9 9 9 12 12
7M 3 4 4 6 6 9 10 12 12 16
8M 4 4 6 6 8 9 12 12 12 16
9M 4 5 6 8 8 10 12 12 16 20
10M 4 6 6 9 9 12 12 16 16 20
Room Length 5M 3 4 6 6 9 9 12 12 12 12
6M 4 4 6 8 9 9 12 16 16 16
AFPD024/CCT Orbit CCT 24W
Room Width
200 LUX (2.4m Height) 1M 2M 3M 4M 5M 6M 7M 8M 9M 10M
Room Width
300 LUX (2.4m Height) 1M 2M 3M 4M 5M 6M 7M 8M 9M 10M
Room Length 1M 1 1 1 1 1 1 2 2 3 3
2M 1 1 1 1 2 2 3 3 3 4
3M 1 1 1 2 2 2 3 3 4 4
4M 1 1 2 2 2 3 4 4 6 6
1M 1 1 1 2 2 3 3 4 4 4
2M 1 1 2 2 3 3 4 4 6 6
3M 1 2 2 3 3 4 4 6 6 6
4M 2 2 3 4 4 6 6 6 8 9
5M 2 2 2 2 3 4 4 6 6 6
6M 2 2 2 3 4 4 6 6 9 9
Room Length 5M 2 3 3 4 6 6 6 9 9 9
6M 3 3 4 6 6 6 8 9 12 12
The information presented in the tables above is provided as a recommendation only. We strongly advise that customers verify and calculate the advice given. The quantities shown are based on the assumption that items are installed in a uniform pattern and have been rounded to match the figures in the tables. All LED Ltd. cannot be held responsible for any discrepancies between actual installations and the provided information. Ultimately, the decision on the number of units to install in any given area rests with the customer.
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
267
268
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
Lux Tables AFD010 / AFD110 - Defender Fixed & Adjustable
Room Width
200 LUX (2.4m Height) 1M 2M 3M 4M 5M 6M 7M 8M 9M 10M
Room Width
300 LUX (2.4m Height) 1M 2M 3M 4M 5M 6M 7M 8M 9M 10M
Room Length 1M 1 1 1 1 2 2 2 3 3 4
2M 1 1 2 2 2 4 4 4 6 6
3M 2 1 2 3 4 4 6 6 6 9
4M 2 2 3 4 4 6 6 9 9 9
1M 1 1 1 2 3 3 4 6 6 6
2M 1 1 2 3 4 6 6 6 8 9
3M 2 2 3 4 6 6 9 9 12 12
4M 2 3 4 6 6 9 12 12 12 16
5M 2 2 4 4 6 6 9 9 9 12
6M 2 3 4 6 6 8 9 12 12 16
7M 3 4 6 6 9 9 12 12 16 16
8M 3 4 6 8 9 12 12 16 16 16
9M 4 6 6 9 12 12 12 16 18 20
10M 4 6 9 9 12 16 16 16 20 24
7M 4 6 9 9 12 16 20 20 25 25
8M 4 6 9 12 16 16 20 25 25 30
9M 6 6 9 12 16 20 20 25 30 30
10M 6 9 12 15 20 20 25 30 30 36
7M 8 9 12 16 20 24 30 30 36 36
8M 9 12 12 20 25 25 30 36 36 42
9M 9 12 16 20 25 30 30 36 42 49
10M 10 16 16 25 25 30 36 42 49 49
7M 12 16 20 25 30 36 36 42 49 56
8M 12 16 20 25 30 36 42 48 56 64
9M 15 20 25 30 36 42 49 56 64 72
10M 16 20 25 36 36 49 56 64 72 72
Room Length 5M 3 4 6 6 8 9 12 16 16 20
6M 3 4 6 9 9 12 16 16 20 20
AFD05 Atom Downlight
Room Width
200 LUX (2.4m Height) 1M 2M 3M 4M 5M 6M 7M 8M 9M 10M
Room Width
300 LUX (2.4m Height) 1M 2M 3M 4M 5M 6M 7M 8M 9M 10M
Room Length 1M 2 3 4 4 4 6 8 9 9 12
2M 3 4 4 6 8 9 9 12 12 16
3M 4 4 6 9 9 12 12 16 16 16
4M 4 6 8 9 12 16 16 20 20 24
1M 3 4 6 6 9 9 12 12 15 16
2M 4 6 6 9 12 12 16 16 20 20
3M 6 6 9 12 15 16 20 20 25 25
4M 6 9 12 16 16 20 25 25 30 36
5M 6 8 9 12 15 16 20 20 25 30
6M 6 9 12 12 16 20 25 25 30 30
Room Length 5M 9 12 15 18 20 25 30 30 36 42
6M 9 12 16 20 25 30 36 36 42 49
The information presented in the tables above is provided as a recommendation only. We strongly advise that customers verify and calculate the advice given. The quantities shown are based on the assumption that items are installed in a uniform pattern and have been rounded to match the figures in the tables. All LED Ltd. cannot be held responsible for any discrepancies between actual installations and the provided information. Ultimately, the decision on the number of units to install in any given area rests with the customer.
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
269
Lux Tables AGU700D Jaguar 7W GU10
Room Width
200 LUX (2.4m Height) 1M 2M 3M 4M 5M 6M 7M 8M 9M 10M
Room Width
300 LUX (2.4m Height) 1M 2M 3M 4M 5M 6M 7M 8M 9M 10M
Room Length 1M 1 2 2 3 3 4 6 6 6 6
2M 1 2 3 4 6 6 6 8 9 9
3M 2 3 4 6 6 9 9 10 12 12
4M 3 4 6 6 9 9 12 12 16 16
1M 1 2 3 4 6 6 8 9 9 10
2M 2 3 4 6 8 9 9 12 12 16
3M 3 4 6 8 10 12 15 16 16 20
4M 4 6 9 12 12 16 16 20 24 25
5M 3 4 6 9 12 12 12 16 20 20
6M 4 6 9 9 12 16 16 20 20 20
7M 6 6 9 12 15 16 20 20 25 25
8M 6 8 12 12 16 20 20 25 25 36
9M 6 9 12 16 20 20 25 25 30 36
10M 8 9 12 16 20 25 25 30 36 42
7M 8 10 12 16 20 25 30 36 36 42
8M 9 12 16 20 25 30 30 36 42 49
9M 9 12 16 20 25 30 36 42 49 56
10M 12 16 20 25 30 36 42 49 49 56
7M 6 9 12 16 20 25 24 30 30 36
8M 9 9 12 16 20 25 30 30 36 42
9M 8 12 16 20 25 30 30 36 42 49
10M 9 12 16 20 25 36 36 42 42 56
7M 9 12 20 25 30 36 42 42 49 56
8M 16 16 20 25 30 36 42 49 56 64
9M 12 16 25 30 36 42 49 56 64 72
10M 15 20 25 30 42 49 56 64 72 81
Room Length 5M 6 8 9 12 16 20 20 25 25 30
6M 6 9 12 16 20 20 25 30 30 36
AGU470D Caterham 4.7W GU10
Room Width
200 LUX (2.4m Height) 1M 2M 3M 4M 5M 6M 7M 8M 9M 10M
Room Width
300 LUX (2.4m Height) 1M 2M 3M 4M 5M 6M 7M 8M 9M 10M
Room Length 1M 1 2 3 4 4 6 6 6 8 9
2M 2 3 4 6 6 8 9 9 12 12
3M 3 4 6 6 9 12 12 12 16 16
4M 4 6 6 9 12 12 16 16 20 20
1M 2 3 4 6 6 9 9 10 12 15
2M 3 4 6 8 9 12 15 16 16 20
3M 4 6 9 12 12 16 20 20 25 25
4M 6 9 10 15 16 20 25 25 30 30
5M 4 6 9 12 16 16 20 20 25 25
6M 6 8 12 12 16 20 20 25 30 30
Room Length 5M 8 9 12 16 20 25 30 30 36 42
6M 9 12 16 20 25 30 36 42 42 49
The information presented in the tables above is provided as a recommendation only. We strongly advise that customers verify and calculate the advice given. The quantities shown are based on the assumption that items are installed in a uniform pattern and have been rounded to match the figures in the tables. All LED Ltd. cannot be held responsible for any discrepancies between actual installations and the provided information. Ultimately, the decision on the number of units to install in any given area rests with the customer.
270
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
Lux Tables AGU501D Morgan 5.5W GU10
Room Width
200 LUX (2.4m Height) 1M 2M 3M 4M 5M 6M 7M 8M 9M 10M
Room Width
300 LUX (2.4m Height) 1M 2M 3M 4M 5M 6M 7M 8M 9M 10M
Room Length 1M 1 2 3 4 4 6 6 8 8 9
2M 2 3 4 6 6 8 9 9 12 12
3M 3 3 6 6 9 9 12 12 16 16
4M 3 6 6 9 10 12 16 16 20 20
1M 2 3 4 6 6 9 9 10 12 12
2M 3 4 6 8 9 12 15 16 16 20
3M 4 4 9 10 12 16 20 20 20 25
4M 6 8 10 12 16 20 25 25 30 30
5M 4 6 9 12 12 16 20 20 25 25
6M 6 9 12 12 16 20 25 25 30 30
7M 6 9 12 16 20 20 25 30 36 36
8M 6 9 12 16 20 25 30 36 36 42
9M 8 12 16 20 25 25 36 36 42 42
10M 9 12 16 20 25 30 36 42 42 49
7M 9 12 20 20 30 30 35 42 49 56
8M 10 16 20 25 30 36 42 49 56 64
9M 12 16 20 30 36 42 49 56 64 64
10M 12 20 25 30 36 49 49 56 72 72
7M 6 8 12 12 16 20 25 25 30 30
8M 8 9 12 16 20 25 25 30 30 36
9M 9 12 16 16 20 25 30 30 36 42
10M 9 12 16 20 25 30 30 36 42 49
7M 9 12 16 20 25 30 36 36 42 49
8M 10 15 20 25 30 36 36 42 49 56
9M 12 16 20 25 36 36 42 49 56 64
10M 12 16 25 30 36 42 49 49 64 64
Room Length 5M 6 9 12 16 20 25 30 30 36 42
6M 8 12 15 20 25 30 36 36 42 49
AFD600D Spartan Downlight
Room Width
200 LUX (2.4m Height) 1M 2M 3M 4M 5M 6M 7M 8M 9M 10M
Room Width
300 LUX (2.4m Height) 1M 2M 3M 4M 5M 6M 7M 8M 9M 10M
Room Length 1M 2 2 3 4 4 6 6 6 8 9
2M 2 3 4 6 6 8 9 9 12 12
3M 3 4 6 6 9 9 12 12 12 16
4M 4 4 6 9 10 12 12 16 16 20
1M 2 3 4 6 6 8 9 10 12 12
2M 3 4 6 9 9 12 12 14 16 16
3M 4 6 9 9 12 16 16 20 20 25
4M 6 6 9 12 16 20 20 24 24 30
5M 4 6 9 9 12 16 16 20 20 25
6M 6 8 9 12 15 16 20 25 25 25
Room Length 5M 6 9 12 16 20 20 25 30 30 36
6M 9 10 15 16 20 25 30 36 36 42
The information presented in the tables above is provided as a recommendation only. We strongly advise that customers verify and calculate the advice given. The quantities shown are based on the assumption that items are installed in a uniform pattern and have been rounded to match the figures in the tables. All LED Ltd. cannot be held responsible for any discrepancies between actual installations and the provided information. Ultimately, the decision on the number of units to install in any given area rests with the customer.
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
271
LED Strip & Driver Compatibility Charts 12V Strip LED Drivers Product
Maximum Length Shown
Part Code
Load
AST005
ADRCV1215
15W Max
3m
ADRCV1230
30W Max
6m
ADRCV1260
60W Max
12m*
ADRCV1280
80W Max
16m*
ADRCV12100
100W Max
20m
ADRCV1225TD
5-25W
5m
ADRCV1250TD
5-50W
10m
ADRCV12100TD
5-100W
20m
Non Dimmable
Dimmable
24V Strip LED Drivers Product
Maximum Length Shown
Part Code
Load
AST010/COB
AST010
AST015
AST020
ADRCV2415
15W Max
1.5m
1.5m
1m
0.75m
ADRCV2430
30W Max
3m
3m
2m
1.5m
ADRCV2460
60W Max
6m
6m
4m
3m
ADRCV2480
80W Max
8m
8m
5.33m
4m
ADRCV24100
100W Max
10m*
10m*
6.6m*
5m*
ADRCV24150
150W Max
15m*
15m*
10m*
7.5m*
ADRCV24200
200W Max
20m*
20m*
13.3m*
10m*
ADRCV24320
320W Max
32m*
32m*
21.3m*
16m*
ADRCV2425TD
5-25W
2.5m
2.5m
1.6m
1.2m
ADRCV2450TD
5-50W
5m
5m
3.3m
2.5m
ADRCV24100TD
5-100W
10m
10m
6.6m
5m
ADRCV24150TD
5-150W
15m
15m
10m
7.5m
Non Dimmable
Dimmable
*Recommended 10m Max Length (>10m Wire In Parallel)
272
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
LED Strip & Driver Compatibility Charts 24V RGB & RGB+W Strip LED Drivers Product
Maximum Length Shown
Part Code
Load
AST0144/RGB
AST020/RGBCW & AST020/RGBWW
ADRCV2415
15W Max
1m
0.75m
ADRCV2430
30W Max
2m
1.5m
ADRCV2460
60W Max
4m
3m
ADRCV2480
80W Max
5.5m
4m
ADRCV24100
100W Max
6.9m*
5m*
ADRCV24150
150W Max
10m*
7.5m*
ADRCV24200
200W Max
13.8m*
10m*
ADRCV24320
320W Max
22.2m*
16m
Non Dimmable
24V Speciality Strip LED Drivers Product
Maximum Length Shown
Part Code
Load
AST05L
AST08L
AST09L
AST720F
AST010
ADRCV2415
15W Max
3m
1.8m
1.67m
2.1m
1.5m
ADRCV2430
30W Max
6m
3.7m
3.33m
4.1m
3m
ADRCV2460
60W Max
12m
7.5m
6.67m
8.3m
6m
ADRCV2480
80W Max
16m
10m
8.89m
11.1m
8m
ADRCV24100
100W Max
20m*
12.5m*
11.11m*
13.8m*
10m*
ADRCV24150
150W Max
30m*
18.6m*
16.67m*
20.8m*
15m*
ADRCV24200
200W Max
40m*
25m*
22.22m*
27.7m*
20m*
ADRCV24320
320W Max
64m*
40m*
35.5m*
44.4m*
32m*
ADRCV2425TD
5-25W
5m
3.1m
2.78m
3.4m
2.5m
ADRCV2450TD
5-50W
10m
6.25m
5.56m
6.9m
5m
ADRCV24100TD
5-100W
20m
12.5m
11.11m
13.8m
10m
ADRCV24150TD
5-150W
30m
18.7m
16.67m
20.8m
15m
Non Dimmable
Dimmable
*Recommended 10m Max Length (>10m Wire In Parallel)
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
273
Contact Us All LED Limited 42 Sedgwick Road Luton LU4 9DT Tel: +44 (0)208 841 9000 Email: sales@allledgroup.com Web: www.allledgroup.com
All LED We are a leading manufacturer of high-quality LED lighting products. Since our founding in 2014, we have been committed to providing innovative, energy-efficient lighting solutions that meet the needs of wholesalers and electricians alike. Our products are designed with sustainability and energy efficiency in mind. LED lighting is much more efficient than traditional lighting technologies, and our products use the latest LED technology to provide superior light quality while using less energy. This means that our products are not only better for the environment, but they can also help to reduce energy bills and maintenance costs.
Accreditations, Awards & Memberships The LIAQA assured company mark shows that as an LIA member we have successfully fulfilled the criteria set by the LIA for product acceptance, manufacturing process requirements, and have provided evidence that supports product conformity. LIAQA Assured Members can showcase to their customers that as suppliers of lighting and lighting related products they have a system in place that effectively addresses product compliance and quality control. All LED are proud to be an assured company member of the LIA. ICEL is the Industry Committee for Emergency Lighting. It’s mission is to strengthen the industry and promote the benefits of good quality lighting. It represents all aspects of UK, EU and international legislation and standards at the highest level, whilst protecting the interests of the public and LIA ICEL Members. ISO 9001 is the international standard that specifies requirements for a quality management system (QMS). Organisations use the standard to demonstrate the ability to consistently provide products and services that meet customer and regulatory requirements. All LED is an ISO9001:2015 certified company. The Electrical Distributors’ Association (EDA) serves as the primary trade association in the UK, dedicated to advocating for the interests of wholesale distributors of electrotechnical products. It supports members by providing resources, training, and a unified industry voice. Luckins is the UK’s leading specialist in product and pricing data services for the electrical, HVAC and plumbing sectors. Luckins provide comprehensive product databases with seamless integration on existing order processing platforms for electrical wholesalers and distributors. All LED is partnered with Recolight to help reduce and safely dispose of and recycle all waste electrical goods, ensuring and upkeeping social and ethical standards that form the basis of All LED’s corporate responsibilities.
All LED makes every effort to maintain the accuracy and quality of the information provided in this catalogue. However, All LED cannot guarantee and assumes no legal liability or responsibility for the accuracy or completeness of the information provided. The information contained in this catalogue is for general guidance only. You should neither act, nor refrain from action, on the basis of any such information. You should take appropriate professional advice on your specific installation because the application of our equipment may vary depending on specific circumstances. From time to time we may update products and their technical aspects, so its always best to contact us to verify any details as catalogues tend to sometimes have quite a long life in a constantly changing environment of the technologies that come with LEDs. The copyright of all content on this catalogue is owned by All LED and/or the various manufacturers of our equipment. No part of the All LED catalogue may be changed, reproduced, stored in or transmitted on any website or medium without the prior written permission of All LED. Requests to republish any material must be sent to sales@allledgroup.com. Dimming compatibility with third party company products is subject to change without prior notice and does not imply full compatibility.
276
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
Participating Brands
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
277
Awards & Innovation All LED has been crowned with the prestigious award of top product of the year on four occasions. Through our innovative approach to product design, we have pioneered the creation of award-winning products that are not only stylish and functional, but also environmentally friendly. Our commitment to innovation has been recognised by industry experts and consumers alike, and our products have been featured in leading publications in the UK. One of the key factors that sets us apart from our competitors is our focus on user experience. We have designers and engineers work closely with our customers to understand their needs and wants, and then use that feedback to develop products that meet or exceed expectations. This user-centric approach has resulted in a number of successful products, including the iCan75. We are experts in fire rated downlights as shown by our iCan75, the can that simply does it all. One can, three bezels and nine finishes. We have also recently taken a new approach to smart lighting systems with our award winning iQ Intelligent Lighting Control system which allows you to keep your existing light switches, and have full control or your lights through voice control, mobile app or just using your light switches. With sustainability in mind, we use only the highest quality materials in our products and are committed to reducing environmental impact throughout our supply chain.
278
This commitment to sustainability is well represented in the packaging design for our Caterham lamp, with its patented low waste, labour saving, recycled and plastic free packaging which itself doubles up as its own display unit. We have masterfully dealt with major pollutants and waste focusing on redesigning our innovative and planet friendly multi-unit boxes. More recently we were recognised for our all new marker light Beam which has been hailed as a testament to the fusion of cutting-edge technology, thoughtful design, and a commitment to lasting quality. Beam’s dimming capabilities, paired with our 12V Constant Voltage dimmable LED drivers, create a symphony of lighting possibilities. From intimate gatherings to focused work sessions, allowing you to control the ambiance with a simple adjustment. In addition to our innovative approach to product design and its commitment to sustainability, we are also known for our exceptional customer and technical service. We offer a wide range of support services, including product training, installation assistance, and troubleshooting. Our customer service team is available to answer questions and resolve any issues that customers may have. As a result of our innovative approach to product design, our commitment to sustainability, and our exceptional customer service, we have become a leader in the lighting industry. Our products are used in homes, businesses, and public spaces around the country, and we are consistently recognised for our quality, performance, and design.
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
AWARDED TOP PRODUCT 2024 Beam isn’t just another lighting solution; it’s a testament to the fusion of cutting-edge technology, thoughtful design, and a commitment to lasting quality. Beam’s dimming capabilities, paired with its 12V Constant Voltage dimmable LED drivers, create a symphony of lighting possibilities.
AML12V/**
In a world saturated with lighting choices, Beam shines brightly. Its combination of enduring quality, adaptable design, and user-friendly features sets it apart. Beam is more than just a lighting solution; it’s an investment in enhanced living.
AWARDED TOP PRODUCT 2023 The Caterham GU10 Lamp - All LED’s newest eco-friendly, low consumption, high output, retrofittable GU10 lamp with OptiDim Technology. An advanced and highly engineered clever dimming technology allowing the lamp to smoothly dim to zero with no flicker or strobing. The only product of its kind boasting 99.1% compatibility with dimmer switches.
AGU470D/**
Even better, is the fact that these lamps are pre-packed in boxes of 10, saving the countless hours wasted unpacking lamps on job sites, whilst making clean up practically non-existent.
AWARDED TOP PRODUCT 2022
AiQ/RLY400B/LN
Designed in the UK to replace the standard junction box, the Smart-E contains push terminals and a hand operated cable clamp with ample room for wiring. The innovative, clean and crisp design which contains technology patented by All LED also fits through a 55mm spotlight hole. It is a fully retrofit solution which works with all existing wiring and provides hop and mesh technology.
AWARDED TOP PRODUCT 2020 The revolutionary and award winning iCan75 fire rated GU10 downlight by All LED has remained at the forefront of the lighting industry since its launch. The innovative twist and lock body allows all 24 bezels (fixed, adjustable and IP65) to be installed on the same fire rated body.
AFD75
e: sales@allledgroup.com
The iCan75 is also shallow-void compliant and an insulation-coverable cap accessory is available where required. One can, fire rated, and ultra slim bezels. Fixed Adjustable and IP65 in multiple colour variations, fit on the same fixture. The entire iCan range is 30, 60, 90 minute timber joist fire rated, as well as 30 minute StairCraft i-Joist fire rated and Wolf Systems Metal Web Joist Rated.
t: 0208 841 9000
w: allledgroup.com
279
Case Studies
280
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
Icons & Symbols IP Rating Icons IP20 to IP68
Lumens
RF Signal
Product Guarantee 1-5 Years
IK Rating Icons IK01 to IK10
Wattage
Microwave Sensor
Lifetime Guarantee
Vandal Proof
Beam Angle
DALI Dimmable
Coastal
Timber Joist Rated
Product Lifetime
1-10V Dimmable
RGB, RGBWW or RGBCW
iJoist Rated
Dimmable
SMD LED
Colour Rendering index
Metal Web Joist Rated
Dimmable With Driver
COB LED
CCT Selectable Switch
Acoustic Rated
Driverless Technology
Live-In Live-Out Technology
Colour Temperature 2400K to 6500K
Air Leakage Rated
Prewired With Length of Cable
240V AC
Emergency
Moisture Rated
Open Vent Technology
Bathroom Suitable
Series Wiring
Class 1
Edison Screw Lamp Base
2 Tonnes Driveover Rated
Fire Rated
Class 2
Bayonette Lamp Base
Manual Override
12V DC
Class 3
GU10 Retrofit Lamp Base
350mA
24V DC
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
281
Index Product Code
Page
Product Code
Page
Product Code
Page
AB00 153
ADRCC350TD/1-4 208
AFD05/A/SN/CCT 22
AB20 153
ADRCC350TD/4-9 209
AFD05/F/BK/CCT 22
AB65 153
ADRCC350TD/9-18 210
AFD05/F/PC/CCT 22
AB67 153
ADRCC350TD/12-25 211
AFD05/F/SN/CCT 22
ABADD 153
ADRCV1215 216
AFD05/F/WH/CCT 22
ABAF002/MW 33
ADRCV1225TD 217
AFD010BZ/BK 29
ABAR/4FT/CCT 73
ADRCV1230 216
AFD010BZ/MWBB 29
ABAR/5FT/CCT 73
ADRCV1250TD 217
AFD010BZ/MWMW 29
ABAR/6FT/CCT 73
ADRCV1260 216
AFD010BZ/PC 29
ABAR/EM/ST 73
ADRCV1280 216
AFD010BZ/SN 29
ABAR/MS2IN1 73
ADRCV2415 218
AFD010BZ/WH 29
ABAR/XT2FT/CCT 75
ADRCV2425TD 219
AFD010D/30 28
ABAR/XT4FT/CCT 75
ADRCV2430 218
AFD010D/30/0-10V 28
ABAR/XT5FT/CCT 75
ADRCV2450TD 219
AFD010D/30/DALI 28
ABAR/XT6FT/CCT 75
ADRCV2460 218
AFD010D/40 28
ABAR/XTCLIP/SS 75
ADRCV2480 218
AFD010D/40/0-10V 28
AB/BRU/ALB 55
ADRCV12100 216
AFD010D/40/DALI 28
AB/BRU/CCT 54
ADRCV12100TD 217
AFD010TK 29
ABE13OVW/CCT 58
ADRCV24100 218
AFD65 16
ABE13RDW/CCT 59
ADRCV24100TD 219
AFD65/75/IC 17
AB/EMPACK 55
ADRCV24120 218
AFD65BZ/F/BLK 17
AB/EMPACK/ST 55
ADRCV24150 218
AFD65BZ/F/PC 17
ABHW12BZ/BK 57
ADRCV24150TD 219
AFD65BZ/F/SN 17
ABHW12BZ/WH 57
ADRCV24200 218
AFD65BZ/F/WH 17
ABHW12/CCT 57
ADRCV24320 218
AFD65BZ/IP/BLK 17
AB/LEN/BZ-BLK 56
AEMBH/M 86
AFD65BZ/IP/PC 17
AB/LEN/BZ-PC 56
AEMBH/MINI/M 87
AFD65BZ/IP/SN 17
AB/LEN/CCT 56
AEMBLADE/L/R 88
AFD65BZ/IP/WH 17
ABLS240/CCT 106
AEMBLADE/M 88
AFD65/TK 17
AB/MSC 55
AEMBLADE/RKIT 88
AFD75 18
ACL240BK/CCT 147
AEMBLADE/SKIT 88
AFD75BZ/**/AB 19
ACL240SN/CCT 147
AEMBLADE/UP 88
AFD75BZ/**/AN 19
ACL240WH/CCT 147
AEMBLADE/WKIT 88
AFD75BZ/**/BB 19
ADIM150/GRID/BLK/ADAPT 41
AEMBOX/L 90
AFD75BZ/**/BC 19
ADIM150/GRID/WH 41
AEMBOX/M/M 90
AFD75BZ/**/BLK 19
ADIM/150W 41
AEMBOX/R 90
AFD75BZ/**/PB 19
ADIM/DUM6A 41
AEMBOXSL/M 91
AFD75BZ/**/PC 19
ADIM/TOOL 41
AEMBOX/UP 90
AFD75BZ/**/SN 19
ADLT002BB/MW 33
AEM/PACK 84
AFD75BZ/**/WH 19
ADRCC12D/100-440MA 212
AEMPACK/240V 85
AFD75/CP/PC
19, 21
ADRCC30D/300-900MA 213
AEM/PACK/ST 84
AFD75/CP/SN
19, 21
ADRCC40D/700-1200MA 214
AEM/SPOT 92
AFD75/CP/WH
19, 21
ADRCC60D/900-1750MA 215
AEMTWIN/NM 89
AFD75/M/01
19, 21
ADRCC350/1-11 207
AFD05/A/BK/CCT 22
AFD75/M/02
19, 21
ADRCC350NANOTD/2-4 206
AFD05/A/PC/CCT 22
AFD75/M/03
19, 21
282
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
Index Product Code
Page
Product Code
AFD75/M/04
19, 21
AFPD006/CCT/DALI/EM/ST 34
AGF/SPK/RED 47
AFD75/TK/BLK
19, 21
AFPD006/CCT/EM 34
AGF/SPK/YEL 47
AFD75/TK/WH
19, 21
AFPD006/CCT/EM/ST 34
AGL032AL/30 128
AFD110ADJBZ/MW 31
AFPD006TD/CCT 34
AGL032AL/40 128
AFD110ADJBZ/PC 31
AFPD006TD/CCT/EM 34
AGL032BZ/AB 129
AFD110ADJBZ/SN 31
AFPD006TD/CCT/EM/ST 34
AGL032BZ/BB 129
AFD110ADJBZ/WH 31
AFPD012/CCT 35
AGL032BZ/BLK 129
AFD110ADJD/30 30
AFPD012/CCT/0-10 35
AGL032BZ/COP 129
AFD110ADJD/30/0-10V 30
AFPD012/CCT/0-10/EM 35
AGL032BZ/WH 129
AFD110ADJD/30/DALI 30
AFPD012/CCT/0-10/EM/ST 35
AGL032SS/27 134
AFD110ADJD/40 30
AFPD012/CCT/DALI 35
AGL032SS/30 134
AFD110ADJD/40/0-10V 30
AFPD012/CCT/DALI/EM 35
AGL032SS/40 134
AFD110ADJD/40/DALI 30
AFPD012/CCT/DALI/EM/ST 35
AGL045AL/30 130
AFD110ADJTK 31
AFPD012/CCT/EM 35
AGL045AL/40 130
AFD570D/CCT 15
AFPD012/CCT/EM/ST 35
AGL045BZ/AB 131
AFD600D/CCT 8
AFPD012TD/CCT 35
AGL045BZ/BB 131
AFD600D/PRO 12
AFPD012TD/CCT/EM 35
AGL045BZ/BLK 131
AFDD10W/DTW 25
AFPD012TD/CCT/EM/ST 35
AGL045BZ/COP 131
AFDMR11/30 27
AFPD018/CCT 36
AGL045BZ/WH 131
AFDMR11/30/0-10V 27
AFPD018/CCT/0-10 36
AGL045SS/27 135
AFDMR11/30/DALI 27
AFPD018/CCT/0-10/EM 36
AGL045SS/30 135
AFDMR11/40 27
AFPD018/CCT/0-10/EM/ST 36
AGL045SS/40 135
AFDMR11/40/0-10V 27
AFPD018/CCT/DALI 36
AGL060AL/30 132
AFDMR11/40/DALI 27
AFPD018/CCT/DALI/EM 36
AGL060AL/40 132
AFDP75 20
AFPD018/CCT/DALI/EM/ST 36
AGL060BZ/AB 133
AFDP75BZ/A/BLK 21
AFPD018/CCT/EM 36
AGL060BZ/BB 133
AFDP75BZ/A/WH 21
AFPD018/CCT/EM/ST 36
AGL060BZ/BLK 133
AFDP75BZ/F/BLK 21
AFPD018TD/CCT 36
AGL060BZ/COP 133
AFDP75BZ/F/WH 21
AFPD018TD/CCT/EM 36
AGL060BZ/WH 133
AFDP75/IC 21
AFPD018TD/CCT/EM/ST 36
AGL060SS/27 136
AFL100BK/CCT 103
AFPD024/CCT 37
AGL060SS/30 136
AFL150BK/CCT 103
AFPD024/CCT/0-10 37
AGL060SS/40 136
AFL200BK/CCT 103
AFPD024/CCT/0-10/EM 37
AGLH035SS/27 125
AFLD10BK/CCT 101
AFPD024/CCT/0-10/EM/ST 37
AGLH035SS/30 125
AFLD20BK/CCT 101
AFPD024/CCT/DALI 37
AGLH035SS/40 125
AFLD30BK/CCT 101
AFPD024/CCT/DALI/EM 37
AGLH035WH/27 125
AFLD50BK/CCT 101
AFPD024/CCT/DALI/EM/ST 37
AGLH035WH/30 125
AFL/PCELL/BK 101
AFPD024/CCT/EM 37
AGLH035WH/40 125
AFL/PIR/BK 101
AFPD024/CCT/EM/ST 37
AGLM01/SS/30 117
AFPD006/CCT 34
AFPD024TD/CCT 37
AGL/MS032 137
AFPD006/CCT/0-10 34
AFPD024TD/CCT/EM 37
AGL/MS048 137
AFPD006/CCT/0-10/EM 34
AFPD024TD/CCT/EM/ST 37
AGL/MS060 137
AFPD006/CCT/0-10/EM/ST 34
AGF/SPK/BLU 47
AGLX020SS/27 126
AFPD006/CCT/DALI 34
AGF/SPK/DAY 47
AGLX020SS/30 126
AFPD006/CCT/DALI/EM 34
AGF/SPK/GR 47
AGLX020SS/40 126
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
Page
Product Code
Page
283
Index Product Code
Page
Product Code
Page
Product Code
Page
AGLX020WH/27 126
ALRE032BZ/WH 142
AMKR032WH/30 122
AGLX020WH/30 126
ALSQ032AL/30 139
AMKR032WH/40 122
AGLX020WH/40 126
ALSQ032AL/40 139
AMKR032WH/BL 122
AGU470D/27 44
ALSQ032OP/AL/30 140
AMKR044AL/30 124
AGU470D/30 44
ALSQ032OP/AL/40 140
AMKR044AL/40 124
AGU470D/40 44
ALSQ032OP/PC/30 140
AMKR044WH/30 124
AGU470D/60 44
ALSQ032OP/PC/40 140
AMKR044WH/40 124
AGU501D/27 45
ALSQ032OP/WH/30 140
AML12V/AL/30 116
AGU501D/30 45
ALSQ032OP/WH/40 140
AML12V/AL/40 116
AGU501D/40 45
ALSQ032PC/30 139
AML12V/BLK/30 116
AGU501D/60 45
ALSQ032PC/40 139
AML12V/BLK/40 116
AGU700D/30 46
ALSQ032SC/AL/30 141
AML12V/WH/30 116
AGU700D/40 46
ALSQ032SC/AL/40 141
AML12V/WH/40 116
AGU700D/60 46
ALSQ032SC/PC/30 141
AMS001 61
AHB/100/CCT 81
ALSQ032SC/PC/40 141
ANS0306SB/22 156
AHB/150/CCT 81
ALSQ032SC/WH/30 141
ANS0306SB/30 156
AHB/200/CCT 81
ALSQ032SC/WH/40 141
ANS0306SB/40 156
AHB/EM/ST 81
ALSQ032WH/30 139
ANS1010/LE/REAR/IP67 155
AHB/MS 81
ALSQ032WH/40 139
ANS1010SB/22 154
AHB/RMT 81
AMKR012AL/30 118
ANS1010SB/30 154
AiQ/4Z/RMT 244
AMKR012AL/40 118
ANS1010SB/40 154
AiQ/DALI/0/1-10V 243
AMKR012BZ/AB 119
ANS1010TB/22 154
AiQ/DIM250/LL 238
AMKR012BZ/BB 119
ANS1010TB/30 154
AiQ/DIM400B/LN 240
AMKR012BZ/BLK 119
ANS1010TB/40 154
AiQ/DIM400M/LL 239
AMKR012BZ/COP 119
ANS1414/LE/REAR/IP67 159
AiQ/DWC/WH 246
AMKR012WH/30 118
ANS1414/RGBWW/SB 158
AiQ/RGBW/RMT 244
AMKR012WH/40 118
ANS1414/RGBWW/TB 158
AiQ/RLY400B/LN 240
AMKR020AL/30 120
APA001/AL 222
AiQ/RLY1000M/LL 239
AMKR020AL/40 120
APA001/AL/ACC 222
AiQ/STLOAD 247
AMKR020AL/BL 120
APA001/BK 222
AiQ/STRIP/REC 241
AMKR020/BAFWH 121
APA001/BK/ACC 222
AiQ/WSW/4Z 245
AMKR020BZ/AB 121
APA001/BK/COR 222
AJKC100PACK 113
AMKR020BZ/BB 121
APA001/WH 222
ALHGU101/B 32
AMKR020BZ/BLK 121
APA001/WH/ACC 222
ALHGU101/L30 32
AMKR020BZ/COP 121
APA001/WH/COR 222
ALRD032AL/30 138
AMKR020WH/30 120
APA002/AL 223
ALRD032AL/40 138
AMKR020WH/40 120
APA002/AL/ACC 223
ALRD032PC/30 138
AMKR020WH/BL 120
APA002/BK 223
ALRD032PC/40 138
AMKR032AL/30 122
APA002/BK/ACC 223
ALRD032WH/30 138
AMKR032AL/40 122
APA002/WH 223
ALRD032WH/40 138
AMKR032AL/BL 122
APA002/WH/ACC 223
ALRE032AL/27 142
AMKR032BZ/AB 123
APA003/AL 224
ALRE032AL/30 142
AMKR032BZ/BB 123
APA003/AL/ACC 224
ALRE032AL/40 142
AMKR032BZ/BLK 123
APA003/BK 224
ALRE032BZ/BLK 142
AMKR032BZ/COP 123
APA003/BK/ACC 224
284
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
Index Product Code
Page
Product Code
Page
Product Code
Page
APA003/BKDIF 224
APF032AL/02/30 127
APNL1240A/CCT/DALI 67
APA003/CDIF 224
APF032AL/02/40 127
APNL1240A/CCT/DALI/EM 67
APA003/ODIF 224
APNL600/SUSPKIT 64
APNL1240A/CCT/DALI/EM/ST 67
APA003/WH 224
APNL632A/40 65
APNL1240A/CCT/EM 67
APA003/WH/ACC 224
APNL632A/40/0-10 65
APNL1240A/CCT/EM/ST 67
APA004/AL 225
APNL632A/40/0-10/EM 65
APNL1240/SBOX 67
APA004/AL/ACC 225
APNL632A/40/0-10/EM/ST 65
ASCC8MM/2CAB 194
APA004/BK 225
APNL632A/40/DALI 65
ASCC8MM/2CAB/10PK 194
APA004/BK/ACC 225
APNL632A/40/DALI/EM 65
ASCC8MM/CUP 194
APA004/BK/COR 225
APNL632A/40/DALI/EM/ST 65
ASCC8MM/CUP/10PK 194
APA004/WH 225
APNL632A/40/EM 65
ASCC8MM/IP/2CAB 194
APA004/WH/ACC 225
APNL632A/40/EM/ST 65
ASCC8MM/IP/2CAB/10PK 194
APA004/WH/COR 225
APNL632A/60 65
ASCC8MM/IP/CUP 194
APA007/AL 228
APNL632A/60/0-10 65
ASCC8MM/IP/CUP/10PK 194
APA007/AL/ACC 228
APNL632A/60/0-10/EM 65
ASCC8MM/IP/LE 194
APA007/BK 228
APNL632A/60/0-10/EM/ST 65
ASCC8MM/IP/LE/10PK 194
APA007/BK/ACC 228
APNL632A/60/DALI 65
ASCC8MM/LE 194
APA007/WH 228
APNL632A/60/DALI/EM 65
ASCC8MM/LE/2M 194
APA007/WH/ACC 228
APNL632A/60/DALI/EM/ST 65
ASCC8MM/LE/2M/10PK 194
APA008/AL 229
APNL632A/60/EM 65
ASCC8MM/LE/10PK 194
APA008/AL/ACC 229
APNL632A/60/EM/ST 65
ASCC10MM/2CAB 195
APA008/BK 229
APNL632A/CCT 65
ASCC10MM/2CAB/10PK 195
APA008/BK/ACC 229
APNL632A/CCT/0-10 65
ASCC10MM/IP/2CAB 195
APA008/BKDIF 229
APNL632A/CCT/0-10/EM 65
ASCC10MM/IP/2CAB/10PK 195
APA008/ODIF 229
APNL632A/CCT/0-10/EM/ST 65
ASCC10MM/IP/CUP 195
APA008/WH 229
APNL632A/CCT/DALI 65
ASCC10MM/IP/CUP/10PK 195
APA008/WH/ACC 229
APNL632A/CCT/DALI/EM 65
ASCC10MM/IP/LE 195
APA112T/ACC 230
APNL632A/CCT/DALI/EM/ST 65
ASCC10MM/IP/LE/10PK 195
APA112T/BK 230
APNL632A/CCT/EM 65
ASCC10MM/LE 195
APA112T/BK/ACC 230
APNL632A/CCT/EM/ST 65
ASCC10MM/LE/10PK 195
APA112T/WH 230
APNL632/SBOX 64
ASCC/COB8/COR 195
APA222AL 231
APNL1232A/CCT 66
ASCC/COB8/COR/10PK 195
APA222AL/ACC 231
APNL1232A/CCT/0-10 66
ASCDIM/1-10 199
APA222/BKDIF 231
APNL1232A/CCT/0-10/EM 66
ASCDIM/DALI/4IN1 201
APA333AL 232
APNL1232A/CCT/0-10/EM/ST 66
ASCDIM/DALI/8A 200
APA333AL/ACC 232
APNL1232A/CCT/DALI 66
ASCDIM/DMX 202
APA/BKDIF 222
APNL1232A/CCT/DALI/EM 66
ASCDIM/SLC32 198
APAC06 227
APNL1232A/CCT/DALI/EM/ST 66
ASC/DMX/WS1/B 203
APAC06/ACC 227
APNL1232A/CCT/EM 66
ASC/DMX/WS1/W 203
APA/CDIF 222
APNL1232A/CCT/EM/ST 66
ASC/PX/REC 161
APA/ODIF 222
APNL1232/SBOX 66
ASC/PX/RMT 161
APAORC/WH 233
APNL1240A/CCT 67
ASC/PX/WSW/1Z 161
APAORC/WH/ACC 233
APNL1240A/CCT/0-10 67
ASCRF/RGBW/REC 197
APF032AL/01/30 127
APNL1240A/CCT/0-10/EM 67
ASCRF/RGBW/RMT 197
APF032AL/01/40 127
APNL1240A/CCT/0-10/EM/ST 67
ASPEED308/BK 99
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
285
Index Product Code
Page
Product Code
Page
Product Code
Page
ASPK3CC/30 109
AST010IP/60 178
ASTC/UNI 193
ASPK600/30 107
AST010IP/AB 174
ASTC/UNI/10PK 193
ASPK600/40 107
AST010IP/BL 174
ASTC/UNI/L90 193
ASPKGU10A/BK 108
AST010IP/CCT 172
ASTC/UNI/L90/10PK 193
AST005/27 176
AST010IP/COB/27 164
ATRAF/BZ/BLK 143
AST005/30 176
AST010IP/COB/30 164
ATRAF/BZ/SS 143
AST005/40 176
AST010IP/COB/40 164
ATRAF/CCT 143
AST005/60 176
AST010IP/COB/60 164
AWL10/AL/ACC 111
AST05/COB/22 162
AST010IP/GR 174
AWL10WH/CCT 111
AST05/COB/27 162
AST010IP/RD 174
AWLG030/BK/30 149
AST05/COB/30 162
AST010IP/YL 174
AWLG030/BK/40 149
AST05/COB/40 162
AST010/RD 174
AWLG030/WH/30 149
AST005/COB/RGB 184
AST010/YL 174
AWLG030/WH/40 149
AST005IP/27 176
AST12PX/IP/RGB 160
AWLGU/AL/022 112
AST005IP/30 176
AST12PX/RGB 160
AWLGU/BK/022 112
AST005IP/40 176
AST015/24 180
AWLGU/WH/022 112
AST005IP/60 176
AST015/30 180
AST05IP/COB/22 162
AST015/40 180
AST05IP/COB/27 162
AST015IP/24 180
AST05IP/COB/30 162
AST015IP/30 180
AST05IP/COB/40 162
AST015IP/40 180
AST005IP/COB/RGB 184
AST020/30 182
AST09L/COB/27 166
AST020/40 182
AST09L/COB/30 166
AST020IP/30 182
AST09L/COB/40 166
AST020IP/40 182
AST09L/COB/60 166
AST020IP/RGBCW 186
AST09LIP/COB/27 166
AST020IP/RGBWW 186
AST09LIP/COB/30 166
AST020/RGBCW 186
AST09LIP/COB/40 166
AST020/RGBWW 186
AST09LIP/COB/60 166
AST720F/27 170
AST010/27 178
AST720F/30 170
AST010/30 178
AST720F/40 170
AST010/40 178
AST720F/60 170
AST010/60 178
AST720FIP/27 170
AST010/AB 174
AST720FIP/30 170
AST010/BL 174
AST720FIP/40 170
AST010/CCT 172
AST720FIP/60 170
AST010/COB/27 164
AST900/27 168
AST010/COB/30 164
AST900/30 168
AST010/COB/40 164
AST900/40 168
AST010/COB/60 164
AST900/60 168
AST010/GR 174
AST900IP/27 168
AST010IP/27 178
AST900IP/30 168
AST010IP/30 178
AST900IP/40 168
AST010IP/40 178
AST900IP/60 168
286
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
287
Notes
288
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
Notes
e: sales@allledgroup.com
t: 0208 841 9000
w: allledgroup.com
289
“
The lighting is not just aesthetically pleasing but allows us to separate training zones and give different atmosphere or intensity depending on what type of session we are running. At ADC we pride ourselves on having a first class facility and All LED lights really give the wow factor. - Chris, Owner, ADC
”
Illuminating Innovation
All LED Limited 42 Sedgwick Road, Luton LU4 9DT Tel + : +44 (0)208 841 9000 Email: sales@allledgroup.com Web: www.allledgroup.com
