Oil firms rein in spending

Kuwait seeks overseas oil assets

OIL AND GAS firms are cutting back on investments to try and improve profits and save cash for dividends, perhaps signaling an end to a decade-long boom in capital spending. Companies seeking to bring oil fields into production have splashed out on new drilling, equipment or pipelines, supported by rising oil prices. But suppliers and analysts expect investment growth to slow sharply this year and in 2014, in www.seadrill.com line with a projected fall in oil prices. The spending boom has squeezed budgets and forced companies to sell assets and issue debt to pay dividends.

Onshore spending will be hurt the most, including the saturated US shale segment. New ultradeep markets, such as Brazil, West Africa and Mexico, will still flourish, however, as they offer the rare opportunities for big finds.

“Oil firms have a dilemma: They still need to grow their production, which is virtually flat and even declining, so they have to spend but will have to become much more selective,” Magnus Lundetrae, the chief financial officer of Seadrill, the world’s biggest offshore rig operator said.

“In total they’ll spend around US$700 billion (this) year...I expect spending to be flat (from next year) ... with onshore declining and offset by deepwater.”

KUWAIT IS SEEKING to make oil acquisitions in regions including Southeast Asia as part of plans to meet output targets, according to a senior industry executive in the Gulf state. Sheikh Nawaf Saudi AlSabah, CEO of Kuwait Foreign Petroleum Exploration (KUFPEC), told Bloomberg that he was “looking very seriously” at overseas assets.

The state-owned firm currently has blocks in China and Vietnam, where it is seeking to do more. “The way to do this is through acquisitions, and acquisitions that are not piecemeal but that are strategic in nature,” Sheikh Nawaf said.

He added that current output is “not a level that we like”, with gas production accounting for 80 per cent of output. “The challenge is to try and get more oil as well.”

KUFPEC, which also operates in Asia, Africa, Australia and other parts of the Middle East, also wants to increase reserves to 650mn barrels by 2020 from its present 400mn barrels. It has exploration licenses in Pakistan and Australia, and recently secured another in Yemen.

Meanwhile, Kuwait Petroleum International (KPI) issued the company's first sustainability report for the year 2012-2013.

Chief Executive Officer of Kuwait Petroleum International, Mr. Bakheet Al-Rashidi announced, "that this report is the first, and will not be the last in the way of global sustainability of the company. Our efforts to issue this report is to document our sustainability development not only to our employees, but to our shareholders, partners, investors, banks, governments, and many more stakeholders who deals with KPI and its affiliates. The report will also reflect our ambition to always be on the way of progress and prosperity in all concerned areas.”

6 Oil Review Middle East Issue Six 2013

www.oilreview.me

S02 ORME 6 2013 News_Layout 1 18/09/2013 16:31 Page 7

S02 ORME 6 2013 News_Layout 1 18/09/2013 16:31 Page 8

News

Executives Calendar 2013/2014 OCTOBER 2013 7-9

M.E. Drilling Conference & Expo

DUBAI

www.spe.org/events/medt/2013

7-10

Doha International Oil & Gas Exhibition

DOHA

www.dioge-qatar-expo.com

8-10

Kuwait Oil and Gas Show

KUWAIT

www.kogs2013.com

28-30

SPE Intelligent Energy Conference & Expo

DUBAI

www.intelligentenergy-me.com

NOVEMBER 2013 10-13

Adipec 2013

ABU DHABI

www.adipec.com

25-27

SAOGE

DHAHRAN

www.saoge.org

BASRA

www.basraoilgas.com

DECEMBER 2013 5-8

Basra International Oil & Gas Exhibition

JANUARY 2014 19-22

ITPC 2014

DOHA

www.itpcnet.org

20-22

World Future Energy Summit

ABU DHABI

www.worldfutureenergysummit.com

AL KHOBAR

www.petroenvironment.com

FEBRUARY 2014 24-26

Petro Environment

Readers should verify dates and location with sponsoring organisations as this information is sometimes subject to change.

South Sudan sees US$1bn oil sales

Oil exports have resumed

SOUTH SUDAN MADE almost US$1bn from oil sales since resuming production in April, of which it had to pass on a quarter to Sudan for exporting crude through its territory, the oil ministry said.

The landlocked African nation needs to export the crude, its economic lifeline, through two pipelines crossing Sudan, from which it seceded in 2011 after decades of civil war.

The neighbours, which fought one of Africa’s longest civil wars which ended in 2005, agreed in March to resume cross-border flows. Juba had shut down its oil production in January 2012 when a row over pipeline fees escalated.

Sudan had threatened since April to halt oil exports in a conflict over alleged rebel support but agreed to continue crude flows at a summit of the two presidents recently.

South Sudan sold around 9.8mn barrels of oil for US$969mn until the start of September, its oil ministry said in a statement. It had to pay US$91mn in fees for using pipelines crossing Sudan and Port Sudan. An extra US$147mn was paid by Juba as part of a package to compensate Sudan for the loss of most oil reserves with southern secession, as agreed in a deal in September. Juba needs to make this monthly payment to Sudan for more than two years.

8 Oil Review Middle East Issue Six 2013

Fluid drilling threat identified A CORROSIVE DRILLING fluid that triggered the North Sea's worst gas leak in 20 years could threaten similar deep-sea wells across the world, and operator Total has already warned Shell that its nearby Shearwater field may be at risk.

The corrosive fluids implicated in the leak at Total's Elgin field, such as calcium bromide, are commonly used in such deep-sea wells, and experts fear a recurrence as operators, under pressure to offset declining output from conventional reservoirs, turn to deeper, hotter and higher pressure fields.

"Bromide brines have been used in thousands of wells since their introduction in the 1980s," John Downs, a chemical engineer who runs his own consultancy group, said. "An extensive well repair programme may be needed if the stress corrosion cracking caused by bromide brine in Elgin is also happening elsewhere."

So worried is Total about recurrence in the Elgin field itself, it has plans to kill at least 10 other wells in the complex as well as the one that leaked, which could cost more than US$2.34bn to replace.

The North Sea is host to the highest number of high-pressure, high-temperature (HPHT) reservoirs of any mature oil and gas producing basin.

Total UK chairman Patrice de Vivies said he had co-operated particularly closely with Royal Dutch/Shell when sharing information on the causes of the leak. "With Shell we have shared even more as they have a neighbouring field, Shearwater, meaning they potentially have, perhaps not identical, but similar problems," de Vivies said.

Any signs of another Elgin may warrant wider investigations into the effects of fluids used in HPHT wells, potentially leading to the killing of more wells and upsetting plans to squeeze more from the North Sea. The recent revival in the North Sea's fortunes hinges on investment in HPHT fields. They are also common off the coast of Brazil and in the Gulf of Mexico. The industry has had to adapt the materials and fluids it uses to cope with the treacherous conditions. www.oilreview.me

S02 ORME 6 2013 News_Layout 1 18/09/2013 16:31 Page 9

S03 ORME 6 2013 Analysis_Layout 1 18/09/2013 16:40 Page 10

Analysis

Compared with the frenzy of recent years, gas development in the Middle East looks like it has entered a more calm and quiet period, writes independent oil analyst Samuel Ciszuk

Gas boom gives way to a

steadier market T

HE BREAK-NECK DEVELOPMENT of Qatar’s North Field has tailed off, with only more domestic-demand focussed projects remaining, while other LNG exporters like Oman look at a future of managed decline. Parts of the Levant might prove the exception with exploration accelerating, but project-wise, 2013 and 2014 look more like middle-years even there.

Gas has in many ways gone from a very hot topic to business-as-usual in the Middle East, compared to the years of the Gulf development boom of the previous decade. Then, enormous agglomerations of skilled personnel, machinery and material used up in the development primarily of the North Field (mainly on the Qatari side), caused ripples – and elevated project costs – in other growth areas like Egypt’s deepwater Nile Delta play and offshore Libya.

That the gas industry is less of a hot topic currently is not necessarily a sign that the industry has a problem, however, in the aftermath of the 2011 uprisings in the region, political uncertainty and outright breakdown of order has put a cap on spending by international oil companies (IOCs) in countries like Egypt, Libya and Syria. In the Gulf, however, the cause for global media’s change of focus is much more likely the increased focus on projects feeding domestic demand. There, political stability looks only slightly different from a decade ago, except for Yemen, where a condition of near state implosion has to be regarded as the norm.

Iranian gas development activity is at a near standstill due to international sanctions of course.

However, the process of gradual sanctions scaring upstream gas investment and making domesticfunded and operated projects struggle to procure technology, machinery and materials – and certain technical skills – has crept up on the industry in near slow-motion over the last eight years.
