Kubota Krone Pre-Season Catalogue

RELENTLESS PERFORMANCE

HAY AND SILAGE P R E-SE AS ON NEW BIG PACK GEN 5 NEW ECTC CONNECT - 13M CUT

0.9

% FINANCE

PA U P T O 6 0 M O N T H S *

ACROSS THE KRONE RANGE

KRONEAUSTRALIA.COM.A U

2022 KRONE ON YOUR PHONE COMPETITION - $18K TOTAL PRIZE MONEY

02

0.9

STANDARD ON ALL BIG PACKS

THE BIG PACK IS SQUARED

Bale accumulater collects and deposits up to 4 bales with fully integrated scales.

Fully automatic clutches. If blocked, it will idle down and unblock itself.

UP FOR SUCCE SS, SE A SON

Up to five different strategies - the BaleCollect can deposit 4, 3, 2 or 1 bale.

Heaviest flywheels for smooth operation and productivity.

Transports like a trailer at 50km/h under 3m transport.

Standard weight scales.

AF TER SE A SON .

03

Tandem steering axle with radial tyres.

Hydraulic soft start available.

Other features include hydraulic jacks, electric bale length adjustment and LED lights.

SQUARE BALERS | KRONE

S Q UA R E BALERS

BALECOLLECT 1230

% FINANCE

PA U P T O 6 0 M O N T H S *

ACROSS THE KRONE RANGE

HEAVIEST FLYWHEEL

BP1290 HDP II

BP1290 HDP XTREME WITH BALECOLLECT

NEW POWERCLEAN

HDP II SQUARE BALER

HIGH SPEED BALER

New hydraulically driven PowerClean retrofit fan kit with positive pressure available for HDPII machines.

Krone has set a new benchmark in large square bale production with the HDP II, with a world first: the development of a unique 8-knotter system.

Standard models High Density Press (HDP) and HDP Xtreme models available, which will continue in the range.

Similar to new Gen 5 design, ensuring optimal cleanliness on top of the baler.

The Krone HDP II can produce up to 90% higher throughputs or up to 10% more density at the same ground speed than our original HDP.

POWERCLEAN

POWERCLEAN

Twine boxes fold down hydraulically for easy refilling of twine.

For all Krone parts ordered on a Machine Down order type and sourced ex Germany, we will now be using a DHL service called Time Definite with a 5-day delivery door-to-door (subject to airline/customs delays).

The HighSpeed range produces the best shaped and densest bales on the market.

Using the heaviest of components throughout the machine, the HighSpeed range impresses every experienced baler operator with its productivity and technical sophistication.

HDP Xtreme model is standard with auto lube system. It greases the complete VFS pre-chamber and replaceable wear liners for the bale chamber directly behind the plunger area. Other features are in line with our HDP HighSpeed.

Share your quality Krone photo for a chance to win!

Simply take a high-quality photo using your phone, tablet, camera or drone for your chance to win.

$18,500 worth of prizes*

Weekly winners each receive a $100 gift card 10 Major winners will recieve a share of $17,500 gift cards

*Offer is available for business borrowers only. This 0.90% p.a. finance rate offer is only available with a minimum 20% deposit, 60 monthly repayments and minimum financed amount of $4,000. Terms, conditions, fees, charges and credit criteria apply. Different term and different deposit may result in a different rate. Credit provided by Kubota Australia Pty Ltd ABN 72005300621. This finance offer is available until 30/04/22 with finance application submitted by 31/05/22 and applies to new Krone models. **Visit kroneonyourphone.kroneaustralia.com.au to view the full Terms & Conditions of this promotion.

KRONEAUSTRALIA.COM.AU

The Variable Fill System (VFS), unique to Krone, offers the highest throughput, 5-phase feed sequence for the bale chamber, offering rock-solid and well-formed bales, even in small windrows.

SHARE YOUR KRONE PHOTO

The updates on the Gen 5 over my previous Krone baler meets all my expectations. One of the major updates I like is the new PowerClean hydraulic driven fan, that literally keeps the whole machine clean.

“

- Craig Hage Regari Contracting Tanunda, South Australia

0.9

Introducing the all new Big Pack 5th generation range with 6 knotters. These square balers have been tested in Australian conditions and have the same strong performance levels and so much more than our HDP High Speed and Xtreme balers. The new machines are fully available for 2022 alongside the existing range of Big Pack 6 knotter High Speed and Xtreme, which stay in the range long term and then there are the legendary HDPII balers.

% FINANCE

The new Big Pack Gen 5 range has improved comfort of operation and reduced cost of ownership, while still maintaining the key attributes of the Big Pack.

These include amazing productivity, bale shape and density, reliability with the use of the strongest components, camless pick-up, VFS packer system with auto reset, 600kg flywheels for smooth operation and soft start. We now also offer the standard Gen 5 BP1290(VC) and BP1270(VC) for 2022.

NEW

1

PA U P T O 6 0 M O N T H S *

05

NEW BIG PACK GEN 5 | KRONE

S Q UA R E BALERS

“

04

N E W B I G PA C K 5 T H G E N E R AT I O N

ACROSS THE KRONE RANGE

2

FIND OUT MORE ABOUT SQUARE BALERS

4

3

NEW BP1290 HDP VC GEN 5

PowerClean knotter fan system with positive pressure, for the cleanest machine up the top and down the sides of the machine.

Close to 100% clean machine as the air stream is running to all key areas of the baler to simply keep it clean.

2 TWINE BOX The new twine box folds down in two modes hydraulically.

First mode: Complete door folds down, same as the HDP II design.

Second Mode: The twine box stays on the machine and folds upright hydraulically.

Twine box door is integrated into the twine box for no accumulation of debris up the top and inside the twine box. Use a 10kg or newly developed 15kg twine spool for longer working days.

3 VFS

- VARIABLE FILL SYSTEM

Larger HDP II VFS bearings and cam track.

Split inner cam track, easier to change.

Design goal was the reduction of running costs.

Redesigned VFS clutch triggering system, which allows the operator to adjust the biscuit from the cabin.

The most gentle pre-packer system which allows you to bale longer with the best top to bottom bale filling.

4 BALE CHAMBER Just like on our HDP Xtreme, the new HDP version of the machines have the standard chamber wear liners and auto greasing inside the VFS. New split bale ejector to be able to eject the last bale only or alternatively empty the full chamber.

NEW

NEW

1 KNOT TER FAN SYSTEM

GEN 5 standard non HDP square balers available, includes BP1290(VC) & BP1270(VC) MultiBale.

TWINE BOX

Central crank adjustment for crop roller height.

New rear mounting frame for extra twine boxes.

Open rear of the pick-up for improved clean out and to not remove pick-up covers.

New Krone original inoculant tank available for 2022.

New VC VariCut cutting unit, now belt driven like HDP II.

Blade cassette can be pulled out to the side.

New enclosed knotter trip gearbox.

BLADE CASSETTE

New moisture sensor with improved accuracy and many more updates to improve customer satisfaction.

INOCULANT TANK

VFS *Offer is available for business borrowers only. This 0.90% p.a. finance rate offer is only available with a minimum 20% deposit, 60 monthly repayments and minimum financed amount of $4,000. Terms, conditions, fees, charges and credit criteria apply. Different term and different deposit may result in a different rate. Credit provided by Kubota Australia Pty Ltd ABN 72005300621. This finance offer is available until 30/04/22 with finance application submitted by 31/05/22 and applies to new Krone models.

KRONEAUSTRALIA.COM.AU

BALE CHAMBER POWERCLEAN KNOTTER FAN

OTHER FEATURES

06

one tractor and labour unit. Compaction on our CTF (Controlled Traffic Farming) is reduced due to one less pass. The simultaneous or individual control of the mowers makes operation of this large combination straightforward.

A RELIABLE MOWING R ANG E TOUG H ENOUG H TO CUT THROUG H ANY TA SK .

“

- Luke & Tim Rethus

Rethus Broadacre Horsham, Victoria

0.9

MOWING RANGE | KRONE

M OW I N G RANGE

“ The ECTC Connect has allowed us to reduce our mowing job by

07

NEW

% FINANCE

PA U P T O 6 0 M O N T H S *

ACROSS THE KRONE RANGE

NEW ECTC CONNECT

NEW ECTC CONNECT

EC TRAILED MOWERS - ECTC 320 CRS

Trailed Mowers from 2.8m to 6.2m.

ECTC & ECTS (Trailed Centre & Side) mower range available in the new polyurethane roller conditioner, M-Roll steel conditioner and V-flail conditioner.

ECTS360CR/S and ECTS360CV available with a wide working width of 3.6m.

ECB & ECF MOWER RANGE

New ECB1000 non conditioner butterfly mower to replace existing ECB970.

M-ROLL STEEL SUPER CONDITIONER

SMARTCUT CUT TERBAR

SAFECUT SHEAR PIN

Krone’s SmartCut cutterbar features lifetime oil filling.

Disc impact protection system standard across all Krone mowers.

Krone’s fully welded one-piece construction gives exceptional resilience.

When the disc hits an obstacle, the roll pin breaks and the disc spins up on the threaded drive shaft, moving out of the way of the next disc, which continues to spin without damage.

Satellite gears are a Krone development, featuring massive spur gears to ensure positive mesh, slow speed and efficient power transmission across every disc.

NEW ECTC CONNECT

AM-R & ECR LINKAGE MOWERS

New ECTC Connect allows you to connect 2x ECTC400/500 trailed mowers to the rear, in combination with an ECF360 front mower, allowing up to 13m cut width.

Entry level AMR range with work widths from 2.4m up to 3.6m. Features include driven by shaft drive (no belts), quick change blades and heavy-duty headstock.

Mowers can be operated simultaneously, or individually, from the cab via an electrical box.

EASYCUT TRAILED CENTRE 4M & 5M

ECR DuoGrip centre of gravity suspension system which suspends the mower in its centre of gravity, maintaining uniform ground pressure across the entire working width.

Widest conditioner rollers in the industry.

Increased overlap between discs ensures a clean cut and smooth crop flow.

New ECTC500CRSM 5m mower with steel M-Roll design now available in limited stock in 2022.

Large range of ECB and ECF mowers with new M-Roll steel super conditioner / new polyurethane / V-tine / no conditioner and with or without cross conveyer for ECB mowers.

5 Conditioning systems available - M-Roll steel super conditioner (limited stock 2022 only in 5m model), steel square lug type conditioner, polyurethane roller and V-flail.

High output rates and heavy construction for massively efficient mowing.

Steel square lug type conditioner design from North America, conditions very well in Australian conditions.

Front mounted mowers from 3.2m to 3.6m, with swath boards for narrow windrow on roller conditioner mowers.

Premium level ECR range with work widths from 2.8m to 4.0m w/o conditioner, 2.8 and 3.2m conditioner models with new M-Roll, new polyurethane rollers or V-flail conditioner.

New updated polyurethane roller conditioner replaces the existing rubber roller.

Optional 3m transport kit available.

ECF320MT & ECR360

AMR320 *Offer is available for business borrowers only. This 0.90% p.a. finance rate offer is only available with a minimum 20% deposit, 60 monthly repayments and minimum financed amount of $4,000. Terms, conditions, fees, charges and credit criteria apply. Different term and different deposit may result in a different rate. Credit provided by Kubota Australia Pty Ltd ABN 72005300621. This finance offer is available until 30/04/22 with finance application submitted by 31/05/22 and applies to new Krone models.

KRONEAUSTRALIA.COM.AU

NEW

Triple Combination Mowers from 8.7m to 10.1m.

SMARTCUT CUTTERBAR SYSTEM

NEW

EC TRAILED MOWERS

08 09

0.9

KRONE’ S WAG ONS & TEDDERS ARE THE KE Y TO QUALIT Y FOR AG E .

RAKES RANGE

LE ADING DUR ABILIT Y & S TABILIT Y WITH E XCEP TIONAL LIF T TINE .

NEW

% FINANCE

PA U P T O 6 0 M O N T H S *

TEDDERS, WAGONS, RAKES | KRONE

TEDDERS & WAG O N S ACROSS THE KRONE RANGE

NEW SWADRO TC1370

NEW VENDRO 820

SWADRO RAKES

New features include Krone OptiTurn rotors with new OptiTurn curved tine for optimum throw of crop, ensuring clean high-quality forage.

Runout stock still available for existing KW linkage range.

Linkage tedders with working widths from 4.6m to 11m.

Features the heaviest square tube frame on the market, with the gearbox installed under the frame to maintain strength in the frame and remove any stress.

NEW

New ‘Vendro’ linkage tedder range available from 4.6m to 11.2m, replacing the existing KW linkage tedder range.

KWT trailed tedders with working widths from 8.8m to 19.6m; not all models will include the new Vendro updates.

OCTOLINK

Krone’s OctoLink clutches are always in mesh for full power and do not require greasing.

The camless EasyFlow pick-up has 68% fewer moving parts for quieter performance and reduced wear.

Single rotor working widths 3.5m - 4.6m.

Fully enclosed gearbox with dry cam track design - no oil leaks.

Your choice of height adjustment – mechanical or fully electric from the cab.

The TC / TS Multi Rotor Range with working widths up to 19m in centre or side delivery.

Lifts the crop off the ground towards the centre of the tine for improved fodder quality and less drag.

Higher forward speeds.

Features the best and strongest axle, using components from Krone’s semi-trailer manufacturing division and removes any stress.

SWADRO TC760

DURAMAX DRY CAM TRACK

ZX wagon is the highest capacity silage wagon on the planet, featuring a rotor driven by a power belt, planetary gearbox and standard SpeedSharp.

LESS DRAG

Steep angle is the key for a precise windrow shape.

Maintenance-free steep dry cam track design made from bainite hardened cast steel with spherical graphite.

ZX430GD

3-year warranty on dry cam track.

DURAMAX CAM TRACK

*Offer is available for business borrowers only. This 0.90% p.a. finance rate offer is only available with a minimum 20% deposit, 60 monthly repayments and minimum financed amount of $4,000. Terms, conditions, fees, charges and credit criteria apply. Different term and different deposit may result in a different rate. Credit provided by Kubota Australia Pty Ltd ABN 72005300621. This finance offer is available until 30/04/22 with finance application submitted by 31/05/22 and applies to new Krone models.

KRONEAUSTRALIA.COM.AU

Boost your productivity with the speed and effectiveness of the camless pick-up design and large rotors with hardox tines.

New for 2022 is the TC1250 all mechanical four rotor rake with 12.5m working width. Limited supply.

Exceptionally strong frame for high stability and durability, setting the benchmark for four rotor raking.

KRONE’S LIFT TINE

WAGON RANGE (28M 3 - 56M 3 ) Krone’s extensive range of AX, MX, RX, TX and ZX silage wagons ranging from 28m3 - 56m3.

New TC1370 four rotor rake with hydropneumatic suspension and integral Soft-Down drop rate control.

New TC1370 tyre size 710/35 R22.5 and new very wide rotor tyres of size 16x9.50-8.

NEW

NEW

VENDRO & KWT TEDDERS

10 11

0.9

PROPELLED, THE BIG MOWER R ANG E FORG E S AHE AD

H A R V E ST E R RANGE

G O BIG THIS SE A SON WITH THE L ARG E SC ALE HARVES TER R ANG E .

% FINANCE

BIG MOWERS & HARVESTERS | KRONE

BIG M OW E R S

SUPER SIZED AND SELF-

PA U P T O 6 0 M O N T H S *

ACROSS THE KRONE RANGE

BIG M 450

BIG X 1180

BIG X HARVESTERS

BIG M SELF-PROPELLED MOWER

Big X 480-1180 Self-Propelled Forage Harvester range available.

450 HP 6-cylinder Liebherr engine.

Available with the M-Roll steel super conditioner, rubber roller or CV flail for perfect conditioning to suit your application.

Large lift cab design to see over large corn crop.

Smaller range with 490-626 HP ensures Krone can supply the right machine for your business.

Comes standard with cross conveyor auger system with hydraulic hoods that are controlled from the cab.

Big M’s standard with swath hoods and swath boards.

Stone and metal detector stops intake instantly.

BIG M 450

6 x feed roller in LOC housing.

Larger drive liners and components.

BIG X 1180 WITH LIFT CAB

Smoothest running in-grass with VariStream spring-loaded belly and blower plates.

Self-propelled mower with up to 11.7m working width for CR model and 9.95m for CV-Flail model.

Moisture sensor and yield meter available.

Transport at 3.6m for CR model and 3.0m for CV at 40km/h.

EasyCollect header, XDisc direct cut head and EasyFlow grass pick-ups available.

M-ROLL CONDITIONING RESULT

OPTIMAX CORN PROCESSOR WITH IMPROVED SPRING PRESSURE AND UP TO 305MM ROLLER DIAMETER

M-ROLL SUPER CONDITIONER

*Offer is available for business borrowers only. This 0.90% p.a. finance rate offer is only available with a minimum 20% deposit, 60 monthly repayments and minimum financed amount of $4,000. Terms, conditions, fees, charges and credit criteria apply. Different term and different deposit may result in a different rate. Credit provided by Kubota Australia Pty Ltd ABN 72005300621. This finance offer is available until 30/04/22 with finance application submitted by 31/05/22 and applies to new Krone models.

KRONEAUSTRALIA.COM.AU

Other standard features include: hydraulic cut height, hydraulic floatation setup, GPS ready, front and rear suspension and active steering.

12 13

SE T THE S TANDARD WITH THE HIG HES T BALE

“

- Warrick Trease, Ben Wallis, Mathew Goldsmith & Suzie McGarvey

DENSITIES IN THE M ARKE T

T F McGarvey Agricultural Contractor Inverloch, Victoria

0.0

NEW VARIPACK | KRONE

NEW VA R I PAC K

“

Running three of the new VariPack V190XC Plus in South Gippsland out of a fleet of six Krone round balers, we are well impressed with

the balers capability in wet silage. We are also very

happy with the productivity and bale shape in hay.

% FINANCE

PA U P T O 3 6 M O N T H S *

ACROSS THE ROUND BALER RANGE

4 FREE 3600M NET ROLLS With any Round Baler OFFER ENDS 30 APRIL 2022

NEW VARIPACK STANDARD

NEW VARIPACK PLUS

NEW VARIPACK FEATURES ACROSS THE RANGE

V165(XC) produces bale diameters from 0.8m to 1.65m, and V190(XC) 0.8m to 1.9m.

EasyFlow camless pick-up.

Integral rotor that integrates two feed rollers into either side of the rotor.

New 3-zone bale density adjustment from cab.

Easy insert net wrap system.

Bale chamber consists of four 275mm wide endless heavy-duty belts for the highest bale densities in the market.

Single axle with tyre size of 500/55-20 12 PR for standard models and 600/50 R22.5 for Plus models.

Door cycle time of 4-5 seconds.

Easiest drive system with 3-chain system.

Highest productivity in the market.

NEW VARIPACK PLUS - FEATURES

Specialist in hay and straw and can also bale silage well. Standard with factory mounted scraper roller for smooth roller.

Specialist in silage, hay and straw.

High performing belt baler in wet silage.

XC Models standard with 26 knives and 42mm spacing with hydraulic activation of knives.

2nd belt drive with up to 10% more density over the standard models.

In-cab selection of 0 / 13 / 13 / 26 knives, including self- cleaning automation.

Auto lubrication and electric oiler.

Baler automation to open & close chamber automatically.

Single belt drive.

Two central grease banks and new electric oiler.

EasyFlow camless pick-up with straight tine formation, 4 rows.

EasyFlow camless pick-up with W-pattern tine arrangement, 5 rows.

EASY INSERT NET SYSTEM (STD. & PLUS MODELS)

INTEGRAL ROTOR (STD. & PLUS MODELS)

XC models comes standard with 17 knives with 64mm spacing with hydraulic activation of knives.

0 / 8 / 9 / 17 knives from outside of the cab. *Offer is available for business borrowers only. This 0.00% p.a. finance rate offer is only available with a minimum 20% deposit, 36 monthly repayments and minimum financed amount of $4,000. Terms, conditions, fees, charges and credit criteria apply. Different term and different deposit may result in a different rate. Credit provided by Kubota Australia Pty Ltd ABN 72005300621. This finance offer is available until 30/04/22 with finance application submitted by 31/05/22 and applies to new Krone models.

KRONEAUSTRALIA.COM.AU

VariPack belt baler line up consists of the standard V165(XC), V190(XC) and Plus versions V165XCPlus and V190XCPlus, and now also includes the new V165Plus and V190Plus without cutter.

NEW VARIPACK STANDARD - FEATURES

14 15

0.0

THE MOS T COMPRE HE NSIVE FE ATURES ALL WR APPED UP

COMPRIMA PLUS ROUND BALERS Comprima V150XC Plus and CV150XC Plus combi pack, replacing the existing Comprima Xtreme range.

Bale density adjustable standard from cabin.

Auto-greasing system standard for models.

New W-pattern tine arrangement with camless pick-up for constant flow of crop.

New design covers.

Wider NovoGrip Belt compared to other Comprima models.

ROUND BALERS | KRONE

ROUND BALERS

ROUND BALERS WITH

% FINANCE

PA U P T O 3 6 M O N T H S *

ACROSS THE ROUND BALER RANGE

4 FREE 3600M NET ROLLS With any Round Baler OFFER ENDS 30 APRIL 2022

COMPRIMA V150XC PLUS

NEW CV150XC PLUS

EASY WRAP 150

COMPRIMA COMBI PACK

Krone’s first newly developed bale wrapper.

Single arm, 3PL machine with fastest wrapping speed of up to 36 rpm.

NEW

Facelift CV150XC-2 and new CV150XC Plus models available.

Fully automatic.

W-pattern tine arrangement camless pick-up for constant flow of crop.

Film roll holder with additional LED lights and keypad for external control.

Ultrasound sensor that replaces the sensor arms on the wrapping table.

Standard with bale turner, 2nd guide roller, ground roller, and counterweight.

Extra wheel and rubber mat on the bale turner that effectively protects the paddock and drop down action of the bale turner.

FACELIFT COMPRIMA ROUND BALER

CCI1200 12” terminal standard.

FORTIMA V1500

FORTIMA ROUND BALER

Now offers a drop floor for non-cutter balers.

Fixed chamber entry level F1250 producing 1.25m bales with low HP requirements.

Feed rotor for non-cutter Fortima for improved feed and productivity.

Choose from the variable V1500 (0.9 to 1.5m) and V1800 (0.9 to 1.8m).

Other features include updated KMC software and a new crop feed roller.

Chain & slat provides high density bales and avoids fragmentation in dry hay or wet silage conditions.

DS500 touch screen terminal standard from 2020 machines.

W-pattern tine arrangement for a constant flow of crop.

The largest in-market 530mm feed rotor for efficient throughput.

CCI800 8" terminal standard from 2020 machines.

Hard or soft core adjustment.

NEW EASYWRAP 150

3

YEAR OR 30,000 BALE WA R R A N T Y

On Comprima Novogrip Belt Elevators

*Offer is available for business borrowers only. This 0.00% p.a. finance rate offer is only available with a minimum 20% deposit, 36 monthly repayments and minimum financed amount of $4,000. Terms, conditions, fees, charges and credit criteria apply. Different term and different deposit may result in a different rate. Credit provided by Kubota Australia Pty Ltd ABN 72005300621. This finance offer is available until 30/04/22 with finance application submitted by 31/05/22 and applies to new Krone models.

KRONEAUSTRALIA.COM.AU

NovoGrip belt and slat system produces tight core bales with V150(XC) 0.9m to 1.5m and V180(XC) 0.9m to 1.8m.

16 17

TILL AG E , FO CUSED ON INCRE A SING YIELD

MAX CHISEL VERTICAL TILL AGE Available in work widths of 3.5m to 7.3m.

Features a double row of 610mm discs with the patented Samurai Edge.

Heavy-duty Toggle-trip reset shanks with 38cm-spaced shanks.

2

Shank working depth up to 12” (305mm) and 1,111kg breakout.

Rear chopper reel finishing tool chops residue and smoothens finish.

Heavy rear roller with active hydraulic down pressure provides an excellent finish in all conditions.

TILLAGE RANGE | GREAT PLAINS

T I L L AG E RANGE

TRUE VERTIC AL

YEAR

1.9

% FINANCE

PA U P T O 6 0 M O N T H S*

ACROSS THE GREAT PL AINS RANGE

STANDARD WARRANTY^

ACROSS THE GREAT PL AINS RANGE

AGGRESSIVE DEEP PRIMARY TILL AGE WITH THREE WORK ZONES AND A SMOOTH UNIFORM FINISH

MC5319 MAX CHISEL - 19 SHANK, 7.3M TILLAGE WIDTH

TURBOMAX - ULTIMATE RESIDUE MANAGEMENT

NO TILL IN-LINE SUB SOILER

Turbo-Max blades are set 19cm apart on two rows of coulter gangs.

Shatters yield-robbing compaction layers.

Unique low surface disturbance shanks and tips.

Rear gangs offset the front gangs, splitting the blade spacing to 3.75” (9.5cm) for superior residue sizing in one pass.

Up to 6.1m working width.

Optional tow hitch recommended for tracked or articulated tractors.

Gang angle is hydraulically adjustable on-the-go from 0˚ to 6˚, providing greater flexibility.

Spring Auto-Reset or Shear bolt protection.

Up to 500mm working depth.

Cover crop establishment using the air Turbo-Seeder attachment.

8M TURBOMAX WITH 3M TRANSPORT

PROUDLY DISTRIBUTED BY KUBOTA AUSTRALIA

NEW SS0300-6 PL5200 WITH SUB SOILER TOW HITCH *Offer is available for business borrowers only. This 1.90% p.a. finance rate offer is only available with a minimum 20% deposit, 60 monthly repayments and minimum financed amount of $4,000. Terms, conditions, fees, charges and credit criteria apply. Different term and different deposit may result in a different rate. Credit provided by Kubota Australia Pty Ltd ABN 72005300621. This finance offer is available until 30/06/22 and applies to new Kubota Implements, Great Plains and Land Pride Ag models. ^ Two year standard warranty on Great Plains includes parts and labour in year 1. Year 2 covers parts only.

KUBOTA.COM.AU

Optional rear berm conditioner smoothens and consolidates the soil surface.

Working widths from 3.0m to 14.6m with narrow 3m transport options.

18 19

COMPACT NO-TILL DRILLS

PL ACEMENT WITH SIMPLE

7.5” (191mm) standard row spacing with the ability to block off individual rows.

AND RELIABLE OPER ATION .

Working widths from 6ft (1.8m) to 10ft (3m).

Simple and reliable mechanical drive.

TRIPLE DISC DESIGN 06 SERIES OPENER USED ON NO-TILL COMPACT DRILLS. SEPARATE SHOOT FOR MAIN SEED, FERTILIZER AND SMALL SEED.

YEAR

2

SEEDING RANGE | GREAT PLAINS

SEEDING RANGE

E XCEP TIONAL SEED

STANDARD WARRANTY^

ACROSS THE GREAT PL AINS RANGE

1.9

3P806NT 2.4m DRILL

% FINANCE

PA U P T O 6 0 M O N T H S*

ACROSS THE GREAT PL AINS RANGE

V300F NO-TILL 3M DRILL 3.0m transport and working width.

2000 MIN-TILL DRILL 6.1m

19 row - 6.22" (158mm) row spacing.

Large 3,100 litre hopper capacity.

1200, 1500 & 2000 DRILLS

Main seed, fertiliser and small seed.

3 models 1200 - 12ft (3.6m), 1500 - 15ft (4.6m), 2000 - 20ft (6.1m).

Row spacing from 6” (152mm) with the ability to block off individual rows.

Main seed, fertiliser and small seed.

Optional Centre Pivot Hitch maintains coulter and double disc alignment in turns.

00 Series Double Disc Opener.

Triple Disc - 18" Turbo Coulter with 00 Series Double Disc Opener.

Active hydraulic row unit down pressure system.

Full length calibration tray allows more convenient calibration.

LINKAGE MOUNTED OR TRAILED

NTS26 BROADCAST SEEDER

The 1200, 1500 & 2000 drills are linkage mounted as standard but can convert to trailed, with several hitch options available.

The Centre Pivot Hitch converts a standard drill into a trailed no-till machine.

NTS No-Till Seeder available in 7’ (2.13m), 9’ (2.74m) and 11’ (3.35m) working widths.

Ideal for multi-species planting and cover crops. 3 seed boxes with individual rate control on each box.

Native grass seed and small seeds box as standard.

Adjustable front spiked roller for seedbed preparation.

1500 DRILL WITH CENTRE PIVOT HITCH

Drawbar kit included allowing 3-point linkage or drawbar attachment.

NTS26

*Offer is available for business borrowers only. This 1.90% p.a. finance rate offer is only available with a minimum 20% deposit, 60 monthly repayments and minimum financed amount of $4,000. Terms, conditions, fees, charges and credit criteria apply. Different term and different deposit may result in a different rate. Credit provided by Kubota Australia Pty Ltd ABN 72005300621. This finance offer is available until 30/06/22 and applies to new Kubota Implements, Great Plains and Land Pride Ag models. ^ Two year standard warranty on Great Plains includes parts and labour in year 1. Year 2 covers parts only.

KUBOTA.COM.AU

The Centre Pivot Hitch allows exceptional direct drilling performance. Hydraulic weight transfer and integrated weight brackets allow extra down-pressure to be applied in tough no-till applications.

PROUDLY DISTRIBUTED BY KUBOTA AUSTRALIA

V300F

20 21

G ROUND BRE AKING DIREC T DRILL PERFORM ANCE IN A VERSATILE & COMPAC T PACK AG E

The second generation Spartan has been evolved to further increase durability and ease of use. Hydraulic metering allows push-button calibration and onthe-go rate adjustment. The Spartan is in a class of it’s own when it comes to working in undulating ground thanks to the unique implement mounting and hydraulic weight transfer system.

We recently took delivery of our third “Spartan drill. Versatility and consistent results make the Spartan a perfect fit for our business

2

- Barry Millard

“

Millard AG Heywood VIC

SPARTAN RANGE | GREAT PLAINS

S PA R TA N RANGE

N TA 6 0 7 - 2 & N TA 9 0 7 - 2 S PA R TA N

YEAR

1.9

% FINANCE

PA U P T O 6 0 M O N T H S*

ACROSS THE GREAT PL AINS RANGE

STANDARD WARRANTY^

ACROSS THE GREAT PL AINS RANGE

NTA607-2

THE SMALL, BIG TIME PERFORMER Sometimes big things do come in small packages, and the Great Plains 6-9m Narrow Transport Air Drills are no exception.

This new, stronger, second generation incarnation of this drill features one pass no-till operation, dual hoppers and a compact design with 3m transport width.

Up to 250kg down pressure on each row making this machine ideal for tough Australian conditions.

NTA907-2

SPARTAN NTA907-2 (9M) The Great Plains Spartan range has the versatility you need in a compact package.

Integrated blockage sensors as standard on both 6m & 9m Spartan.

Triple disc system with independent coulter and double disc opener used across the Spartan range.

6” or 7.5” row spacing with individual row shut-off capability.

2 x 3,500 litre hoppers with double shoot to opener.

Hydraulic loading/unloading auger with wireless remote control.

CAT 4 hitch with integrated hydraulic jack stand.

Integrated blockage sensors as standard.

07 SERIES TRIPLE DISC OPENER USED ON 6M AND 9M SPARTAN

SPARTAN NTA607-2 (6M) 2 x 2,885 litre hoppers.

Metering system with 5 sowing shafts (2 x 4 star, 2 x 2 star and 1 x small seed shaft).

Variable rate hydraulic metering drive with simple push-button calibration.

PROUDLY DISTRIBUTED BY KUBOTA AUSTRALIA

3M TRANSPORT WIDTH NTA907-2 *Offer is available for business borrowers only. This 1.90% p.a. finance rate offer is only available with a minimum 20% deposit, 60 monthly repayments and minimum financed amount of $4,000. Terms, conditions, fees, charges and credit criteria apply. Different term and different deposit may result in a different rate. Credit provided by Kubota Australia Pty Ltd ABN 72005300621. This finance offer is available until 30/06/22 and applies to new Kubota Implements, Great Plains and Land Pride Ag models. ^ Two year standard warranty on Great Plains includes parts and labour in year 1. Year 2 covers parts only.

KUBOTA.COM.AU

6” or 7.5” spacing with individual row shut-off capability.

22 23

M U LC H E R RANGE

YOUR OPER ATION IS , THERE’ S A KUBOTA IMPLEMENT TO DELIVER G RE AT RE SULT S .

RIG ID OR FOLDING ROTARY

R OTA RY CUTTERS

CUT TERS WITH SING LE OR DUAL SPINDLE , MOUNTED OR TR AILED & VARIOUS CUT TING WIDTHS .

5

YEAR

1.9

% FINANCE PA U P T O 6 0 M O N T H S*

ACROSS THE IMPLEMENTS RANGE

VEGETATION MANAGEMENT RANGE | IMPLEMENTS

NO M AT TER WHAT SIZE

GEARBOX WARRANTY ON RC3715

SE8320

RC3715

KUBOTA SE SERIES

HEAV Y DUT Y FOLDING ROTARY CUT TERS

Solid construction with a robust gearbox and very strong power transmission to the ‘V’ belts driving the rotor.

Up to 6.0m working width.

Up to 100mm cut capacity.

The chassis is double plated in areas subjected to high stress.

3 spindles for optimum cutting capacity and cut quality.

Kubota’s precisely manufactured rotor shafts and hard wearing blades make them extremely reliable.

SINGLE & DUAL-SPINDLE RIGID ROTARY CUT TERS Up to 3.0m working width.

Heavy duty swivelling single or dual tailwheel.

Up to 100mm cut capacity.

5-year gearbox warranty on most models.

Single or dual spindle.

Comprehensive range offering.

3-Point Linkage Mounted.

540 and 1,000rpm options.

Land Pride performance swivel hitch.

Built to match tractors with 25 PTO HP through to 260 PTO HP.

LED Transport lights.

RCG3715 Galvanised model with 15ft (4.6m) working width.

SE4235

*Offer is available for business borrowers only. This 1.90% p.a. finance rate offer is only available with a minimum 20% deposit, 60 monthly repayments and minimum financed amount of $4,000. Terms, conditions, fees, charges and credit criteria apply. Different term and different deposit may result in a different rate. Credit provided by Kubota Australia Pty Ltd ABN 72005300621. This finance offer is available until 30/06/22 and applies to new Kubota Implements, Great Plains and Land Pride Ag models.

RCF3696

KUBOTA.COM.AU

5 or 7-year gearbox warranty depending on model.

Working widths range from 1.5 m through to 4.0m.

24

MORE THAN 1 40 YE ARS HE AT TRE ATMENT OF S TEEL THAT WITHS TANDS AUS TR ALIA’ S HARSHES T PLOUG HING CONDITIONS .

DISC SPREADERS

LE ADING TECHNOLOGY AND PRECISION FARMING WITH ADVANCED SEC TION CONTROL

1.9

% FINANCE

PLOUGHS & DISC SPREADERS | IMPLEMENTS

REVERSIBLE P LO U G H

OF E XPERIENCE WITH

25

PA U P T O 6 0 M O N T H S*

ACROSS THE IMPLEMENTS RANGE

DSXL-W GEOSPREAD

KUBOTA DS SERIES Full section control available on the GEOSPREAD models using 1m section widths.

ISOBUS COMPATIBLE Precision farming makes mechanical work smart, efficient and easy.

With the ISOBUS technology your implements are better connected, operated, controlled and monitored.

4 load cells (5 tonne per cell) and centralised reference sensor deliver unrivalled dosing accuracy.

Easy setting of application rate for up to 54m spreading width.

Your needs and demands drive Kubota’s precision farming solutions.

For small to large scale farm operations.

Accurate and consistent spreading pattern.

RM3005V - 6 FURROW

Capacity ranges from 700L to 4,575L.

KUBOTA RM SERIES Smart auto-line system, plough pulls straight at any set working width. Guarantees easy pulling and reducing fuel consumption.

VARIOMAT enables quick hydraulic adjustments of the working width on the fly.

DSX (EX TRA L ARGE)

Hydraulically controlled hopper shutter with spreading widths up to 21m.

Includes Kubota Rotorflow system with 8 vanes per disc, and can spread up to 28m.

Capable of a maximum 54m spreading width with up to 4,575L capacity.

Includes all Disc Spreader range features, despite being the most compact model.

Compatible with larger spreader accessories, such as the aluminium hopper extensions and TrimFlow border spreading system.

Driving speed stays constant with dual PTO input shafts. Combined with ‘slow rotating’ agitator system, the DSX is capable of operating with high disc speeds to ensure a very even spreading pattern.

4 spreading vanes are easily detachable for static calibration tests.

95% of a Kubota plough is heat treated and hardened for ultimate strength in Australia’s harsh conditions.

Easily access and adjust the application rate.

CARBUERISED STEEL

PROUDLY DISTRIBUTED BY KUBOTA AUSTRALIA

DSM (MEDIUM)

HEAT TREATMENT

DSX-W GEOSPREAD models come standard with central hydraulic drive.

*Offer is available for business borrowers only. This 1.90% p.a. finance rate offer is only available with a minimum 20% deposit, 60 monthly repayments and minimum financed amount of $4,000. Terms, conditions, fees, charges and credit criteria apply. Different term and different deposit may result in a different rate. Credit provided by Kubota Australia Pty Ltd ABN 72005300621. This finance offer is available until 30/06/22 and applies to new Kubota Implements, Great Plains and Land Pride Ag models.

KUBOTA.COM.AU

Efficient non-stop system for quality ploughing in stony conditions.

DSC (COMPACT)

26 27

T H E B E S T S TA R T F O R YO U R S O I L

YOUR OPER ATION IS , THERE’ S A KUBOTA IMPLEMENT TO DELIVER G RE AT RE SULT S .

When it comes to seed germination, balance is key. Kubota’s versatile CD Series enable both shallow and deep cultivation with the right mixture and quantity of straw and

2

residue, ensuring good penetration, cutting quality and output, while keeping adjustments simple and maintenance costs low.

COMPACT DISCS | IMPLEMENTS

C O M PAC T DISCS

NO M AT TER WHAT SIZE

YEAR

1.9

% FINANCE PA U P T O 6 0 M O N T H S*

ACROSS THE IMPLEMENTS RANGE

FACTORY WARRANTY CD SERIES

CD2350 COMPACT DISC & SH200E SEED BOX

CD2600T 6.0m COMPACT DISC

KUBOTA CD SERIES Cage roller may be selected for a more economical option.

Maintenance-free bearings.

SH Box is the ideal factory fit seeding option.

Choice of 2 rollers.

Conical shaped hardened disc ensures constant cutting angle independently of the disc diameter with extra long wear life.

Actipack roller for clod crushing and very firm re-compaction of the soil.

Easily adapted for heavy and sticky soil conditions.

Available from 2.0m to 7.0m working width.

CD BEARING HUB

PROUDLY DISTRIBUTED BY KUBOTA AUSTRALIA

CD DISC DESIGN

SH SEED BOX ATTACHMENT

CD2500F

*Offer is available for business borrowers only. This 1.90% p.a. finance rate offer is only available with a minimum 20% deposit, 60 monthly repayments and minimum financed amount of $4,000. Terms, conditions, fees, charges and credit criteria apply. Different term and different deposit may result in a different rate. Credit provided by Kubota Australia Pty Ltd ABN 72005300621. This finance offer is available until 30/06/22 and applies to new Kubota Implements, Great Plains and Land Pride Ag models.

KUBOTA.COM.AU

Robust disc arms and high capacity bearings deliver excellent durability.

28 29

14,000 tonnes of onions per year

“

- Vince Galati Galati Farms Western Australia

P OW E R H A R R OW S & SEEDING

DAIRY FARMER TO HORTICULTUR AL APPLIC ATIONS , SUPREME SEEDBED PREPAR ATION IS OUR SPECIALT Y.

1.9

% FINANCE

POWER HARROWS & SEEDING | IMPLEMENTS

V E G E TA B L E PLANTERS

“ With Kubota we plant over

PA U P T O 6 0 M O N T H S*

ACROSS THE IMPLEMENTS RANGE

PP1601TF-SX VP1600F TRIPLE BED VEGETABLE PLANTER

PH3600F 6.0m POWER HARROW AND SH500 SEED BOX BOX

KUBOTA VP SERIES Versatile, precise and economic vacuum planter.

Guaranteed customised precision sowing for all sorts of vegetable seeds.

KUBOTA PH & SD SERIES The ultimate machine for vegetable producers.

Available rigid or as a parallel hydraulic folding model.

Almost 1700 different build configurations possible.

PH Series Power Harrows are suited to small tractors right through to large tractors, up to 400 PTO HP. Self-supporting trough construction, as well as standard ‘Quick-fit’ tine holders.

2m to 6.5m working widths.

Conical bearings offer optimum performance.

Working widths from 2.5m to 6m folding.

VP SINGLE SOWING ROW

PROUDLY DISTRIBUTED BY KUBOTA AUSTRALIA

VP TWIN SOWING ROW

VP DOUBLE SOWING ROW

SD HOPPER DESIGN

PH2301 POWER HARROW & SD2301MP SEED DRILL

*Offer is available for business borrowers only. This 1.90% p.a. finance rate offer is only available with a minimum 20% deposit, 60 monthly repayments and minimum financed amount of $4,000. Terms, conditions, fees, charges and credit criteria apply. Different term and different deposit may result in a different rate. Credit provided by Kubota Australia Pty Ltd ABN 72005300621. This finance offer is available until 30/06/22 and applies to new Kubota Implements, Great Plains and Land Pride Ag models.

KUBOTA.COM.AU

A range of seeding options also available to suit Kubota Power Harrows.

30 31

ACCUR ATE , HIG H SPEED SEEDING , SIMPLIFIED.

“ We are very happy with the precise placement of the seed from our Kubota Planter. It is very evident on plant emergence.

“

- Alex Mountjoy Bears Lagoon Silage Services Bears Lagoon, VIC

PRECISION PLANTERS | IMPLEMENTS

PRECISION PLANTERS

THE PP SERIES DELIVERS

B e a r s L a g o o n S i l a g e S e r v i ce s s ow i n g co rn i n S o u t h e rn N S W ri g ht n e a r t h e M u rr ay R i ve r.

Fr e s h ly g r a d e d i rri g at i o n b ay s a n d p u n c h i n g 9 4 ,0 0 0 s e e d s/ h a of co rn i n t h e g r o u n d at 1 5 . 1 k m /h m a ke s f o r h a p py c u s to m e r s .

1.9

% FINANCE PA U P T O 6 0 M O N T H S*

ACROSS THE IMPLEMENTS RANGE

PP1450V 6 ROW 4.5m SX HIGH SPEED

PP1601TF 8 ROW 6.0m SX HIGH SPEED

KUBOTA PP SERIES

ISOMATCH TELLUS GO+

For all large seed crops that require precise seed singulation and placement like corn, beans, peas, pumpkins and even melons.

7 inch full colour touchscreen display.

User friendly touchscreen push buttons and rotary button.

Today precision farming has become more and more important. With GEOcontrol and GEOseed®, Kubota offers both applications for the PP Series, to maximise the machine output and prevent double seeding.

Section control possible.

Low price point option.

ISOMATCH TELLUS PRO

The PP Series is available with working widths from 3m to 6m with flexible row widths and a wide range of additional equipment.

12 inch full colour touch screen display.

PROUDLY DISTRIBUTED BY KUBOTA AUSTRALIA

HD-II VACUUM SOWING ROW FOR PRECISE SEED SINGULATION

SX HIGH SPEED SOWING ROW WITH SOWING SPEEDS UP TO 18KM/H

Section control and variable rate mapping possible.

ISOMATCH TELLUS PRO

*Offer is available for business borrowers only. This 1.90% p.a. finance rate offer is only available with a minimum 20% deposit, 60 monthly repayments and minimum financed amount of $4,000. Terms, conditions, fees, charges and credit criteria apply. Different term and different deposit may result in a different rate. Credit provided by Kubota Australia Pty Ltd ABN 72005300621. This finance offer is available until 30/06/22 and applies to new Kubota Implements, Great Plains and Land Pride Ag models.

KUBOTA.COM.AU

Display 2 ISOBUS implements at once. For example, an ISOBUS front hopper and a rear mounted precision planter.

Up to 18km/h working speeds with the NEW SX High Speed Planter.

The HD-II vacuum row unit is also available for a more economical option.

ISOMATCH TELLUS GO

TILLAGE AND SEEDING P R E-S EA S O N

2 0 2 2

1.9

% FINANCE PA U P T O 6 0 M O N T H S*

ACROSS THE KUBOTA IMPLEMENTS, GREAT PL AINS & L AND PRIDE AG RANGE

KUBOTA.COM.AU | GREATPLAINSAUSTRALIA.COM.AU
