SQUARE HEATED
STR06 – Standard 240V model
MANUFACTURED FROM 304 GRADE
STAINLESS STEEL
IP55 RATED
ALL TOWEL RAILS AVAILABLE WITH EITHER BOTTOM LEFT OR RIGHT OUTPUT
ALL STANDARD RAILS ARE DUAL PURPOSE, OFFERING A PLUG AS STANDARD, BUT PACK CONTAINS A HARD WIRING KIT
CAN BE MOUNTED UPSIDE DOWN 10 YEAR WARRANTY FOR CONSTRUCTION / HEATING ELEMENT
COATING ON COLOURED RAILS ARE COVERED BY A 2 YEAR WARRANTY
FEATURES
• Square bar / Height 750mm / 7 evenly spaced bars / 125W
• Standard model is 240V / IP55 rated
• Vertical bars 30mm x 30mm
• Horizontal bars 19mm x 19mm
• 110mm from wall
• Cable length: 1.4m, plug included
• To see our range of low voltage (12V) models please refer to our website for the complete range: radiantheating.com.au
STR06LEFT 950x750 Polished
STR06RIGHT 950x750 Polished
PLEASE NOTE: NOT ALL PRODUCTS ARE AVAILABLE IN ALL FINISHES. IF NOT LISTED IN THE SPECIFICATIONS IT IS NOT CURRENTLY AVAILABLE.
Cable exits the back 35mm from bottom of rail. When ordering please specify left or right side as viewed from the FRONT 110 920 950 80 35 90 90 108 51 570 750
CODE SIZE (MM)
FINISH
