STR01 – 12V model
LOW VOLTAGE 12 VOLT MODEL
MIRROR POLISHED AND BRUSHED SATIN MANUFACTURED FROM 304 GRADE STAINLESS STEEL
COLOURED FINISHES MANUFACTURED FROM 201 GRADE STAINLESS STEEL ALL TOWEL RAILS AVAILABLE WITH EITHER BOTTOM LEFT OR RIGHT OUTPUT
3M CABLE, NO PLUG, INCLUDES THE TRANSFORMER
CAN BE MOUNTED UPSIDE DOWN 10 YEAR WARRANTY FOR CONSTRUCTION / HEATING ELEMENT
COATING ON COLOURED RAILS ARE COVERED BY A 2 YEAR WARRANTY
FEATURES
• Square bar / Height 800mm / 7 evenly spaced bars / 80W
• Low voltage 12V ladder
• Vertical bars 30mm x 30mm
• Horizontal bars 19mm x 19mm
• 110mm from wall
12v ladders are manufactured using individual elements so one of the vertical bars is not heated, however this does not affect the rails ability to warm/dry a towel as all horizontal bars are fully heated.
CODE SIZE (MM) FINISH
12V-STR01LEFT 600x800 Polished
12V-STR01RIGHT 600x800 Polished
PLEASE NOTE: NOT ALL PRODUCTS ARE AVAILABLE IN ALL FINISHES. IF NOT LISTED IN THE SPECIFICATIONS IT IS NOT CURRENTLY AVAILABLE.
Cable exits the back 35mm from bottom of rail. When ordering please specify left or right side as viewed from the FRONT 570 110 80 35 90 90 40 120 620 800 600
SQUARE HEATED
