NOTES: DUE TO THE MANUFACTURING NATURE OF CERAMICS, +/-5MM VARIATION IN SIZE AND DETAIL CAN BE EXPECTED.
DO NOT DRILL OR ROUGH IN UNTIL YOU HAVE RECEIVED AND MEASURED YOUR PRODUCT. BASIN SUITS 32MM WASTE. ADP UNIVERSAL PLUG AND
PRODUCT MATERIAL DIMENSIONS STYLE FINISH CAPACITY VERSION 3 COLOUR CODE DATE 27/02/2023
ARCH FLUTED CERAMIC 415W X 360D X 100H ABOVE COUNTER WHITE GLOSS - TOPCAFL4136GW 8L TO RIM TOPCAFL4136* MATTE - TOPCAFL4136MW 75DIA CUTOUT 8L CAPACITY TO RIM 415 360 100 80 80 45DIA WASTE 415 415 360 360 100 100
WASTE RECOMMENDED (SOLD SEPARATELY). BASIN CUTOUT IS A 75 DIAMETER HOLE. ALL DIMENSIONS ARE IN MILLIMETRES. DO NOT MEASURE FROM DRAWING.
