DIMENSIONS ARE NOMINAL. DO NOT DRILL BEFORE RECEIVING PRODUCT. IS NON-STRUCTURAL. ** RAIL RAIL IS ADJUSTABLE AND REMOVABLE.
65 51
500 40
1200mm RAIL AND 2400mm RAIL ALSO AVAILABLE SEPARATELY. 1200 - SMSR1200BK 2400 - SMSR2400BK
NAME: SIZE: WK/WH: CONFIGURATION:
ALLEGRA SMAL50100BK 500 x 1000 x 40 WALL HUNG MIRROR
WWW.ADPAUSTRALIA.COM .AU
492 MIRROR
ADJUSTABLE 345-500** 550 RAIL LENGTH
238 FROM TOP EDGE TO TOP BRACKET HOLES *
1000
940 MIRROR
475 BRACKET NOMINAL HOLE SPACING *
315
60 BRACKET NOMINAL HOLE SPACING *
100
