RECESSED DRIVE OVER FIXTURES Load 8 kN | Class I IP67 IK10

EMFA’s Ani step mounted series is specially designed to deliver low-glare lighting to facades, columns, monuments, and trees with minimal installation depth and narrow trim. The fixture is made of a combination of 316L stainless steel and die cast aluminium. The tilted design reduces the glare of the LED’s The Linear LEDs with special lenseS gives excellent wallwashing effect. An anti-slip glass is available upon request.

Cover 316L Stainless steel Body Die cast aluminium Gaskets Silicone Diffusers 8 mm Tempered Glass Screws 316L Stainless Steel

“Customization” is EMFA’s standard EMFA offers many combinations for each fixture, as all fixtures are made in house. A combination of 6 standard paint colors, 8 LED colors, and 2 wattages, and available to make the fixture suitable for the required application. This is done without increasing lead-time and is available for large as well as small quantities.

Symmetrical

Galvanized Recessing Box 45º 90º

Asymmetrical

Asym. Glass

Trenched Glass Milky Glass

Clear Glass

55º 45º

ANI

RECESSED DRIVE OVER FIXTURES Load 8 kN | Class I IP67 IK10

Symmetrical Led

: Linear LEDs

Voltage

: 240 VAC with integrated driver (12-24 VDC on request)

Diffuser

45º 90º

: 8mm Tempered Glass

Beam Angle : 45°/ 60°/ 90°

ANI 3 Power Code No 18W 450201 36W 450211 18W 450202 36W 450212

Kelvin 3000 K 3000 K 4000 K 4000 K

ANI 4 Power Code No 24W 450301 48W 450311 24W 450302 48W 450312

Kelvin 3000 K 3000 K 4000 K 4000 K

Nominal Real Lumen Lumen Output Output 1200 lm 1700 lm 2300 lm 3300 lm 1380 lm 1955 lm 2645 lm 2932 lm

Nominal Real Lumen Lumen Output Output 1780 lm 2550 lm 3080 lm 4300 lm 2047 lm 2932 lm 3542 lm 5060 lm

Galvanized Recessing Box

180

154

Kelvin 3000 K 3000 K 4000 K 4000 K

108

148

Galvanized Recessing Box

180

154

Power Code No 12W 450101 24W 450111 12W 450102 24W 450112

Nominal Real Lumen Lumen Output Output 1020 lm 1460 lm 1780 lm 2550 lm 1173 lm 1679 lm 2047 lm 2932 lm

154

188

Galvanized Recessing Box

180

154

ANI 2

Kelvin 3000 K 3000 K 4000 K 4000 K

180

Power Code No 6W 450001 12W 450011 6W 450002 12W 450012

Nominal Real Lumen Lumen Output Output 600 lm 850 lm 1020 lm 1460 lm 690 lm 977 lm 1173 lm 1679 lm

ANI 1

: %70

130

: >80

L.O.R %

170

CRI

210

250

Mac Adam

228

Galvanized Recessing Box

ANI

RECESSED DRIVE OVER FIXTURES Load 8 kN | Class I IP67 IK10

Asymmetrical Led

: Linear LEDs

Voltage

: 240 VAC with integrated driver

Diffuser

: 8mm Tempered Glass

(12-24 VDC on request)

55º

45º

Beam Angle : 45°/ 60°/ 90°

ANI 3 Power Code No 18W 450701 36W 450711 18W 450702 36W 450712

Kelvin 3000 K 3000 K 4000 K 4000 K

ANI 4 Power Code No 24W 450801 48W 450811 24W 450802 48W 450812

Kelvin 3000 K 3000 K 4000 K 4000 K

Nominal Lumen Output 1700 lm 3300 lm 1955 lm 2932 lm

Real Lumen Output 1780 lm 3080 lm 2047 lm 3542 lm

Nominal Lumen Output 2550 lm 4300 lm 2932 lm 5060 lm

Real Lumen Output 1200 lm 2300 lm 1380 lm 2645 lm

180

Kelvin 3000 K 3000 K 4000 K 4000 K

Nominal Lumen Output 1460 lm 2550 lm 1679 lm 2932 lm

148

154

Galvanized Recessing Box

180

154

Power Code No 12W 450601 24W 450611 12W 450602 24W 450612

Real Lumen Output 1020 lm 1780 lm 1173 lm 2047 lm

108

154

188

Galvanized Recessing Box

180

154

ANI 2

180 80

Kelvin 3000 K 3000 K 4000 K 4000 K

Nominal Lumen Output 850 lm 1460 lm 977 lm 1679 lm

Power Code No 6W 450501 12W 450511 6W 450502 12W 450512

Real Lumen Output 600 lm 1020 lm 690 lm 1173 lm

ANI 1

: %70

130

: 80

L.O.R %

170

CRI

210

250

Mac Adam

228

Galvanized Recessing Box

KNIDOS

RECESSED DRIVE OVER FIXTURES Load 20 kN | Class I IP67 IK10

EMFA’s Knidos series consists of a range of LED, metal halide, and fluorescent sources to deliver the desired light effect to facades, columns, monuments and trees. The fixture is made of a combination of 316L stainless steel and glass reinforced polyester, which makes it completely resistant to corrosion. The sturdy fixture allows loads up to 20kN and IK 10. The LEDs used come in 3 different tones of white, as well as blue, red, green, and amber. An anti-slip glass is available upon request. Adjustable Asymmetrical LEDs In this series EMFA is introducing its first adjustable asymmetric LED unit. The LEDs can be internally adjusted up to 40 degree to give the desired light output to facades, columns, monuments, and trees without losing light to the sky. The Knidos is large enough, and has enough surface area so that at an ambient tempature of 50º C, 9 LEDs can be operated at 350 mA (9W).

Cover 316L Stainless steel Body Glass reinforced polyester Gaskets Silicone Diffusers 12 mm Tempered Glass Screws 316L Stainless Steel

“Customization” is EMFA’s standard EMFA offers many combinations for each fixture, as all fixtures are made in house. A combination of 2 finishes of stainless steel, 8 LED colors, 2 wattages, and 5 or more lenses and reflectors are available to make the fixture suitable for the required application. This is done without increasing lead-time and is available for large as well as small quantities.

LEDs Only highest quality LEDs such as Cree and Seoul Semiconductor are used in production allowing for maximum lumen output and maximum lifetime. Most LEDs run on 350mA or 700mA depending on how much light output is required. The white color temperature binning is 200K at most, and always on the same x,y coordinates on the CIE diagram in accordance with Energy Star. This ensures consistent supply of the same color temperatture over time. As LEDs are constantly developing and becoming more efficient, lumen output given in this catalogue are current as of March 2014. At 2700K, 3300K, and 4500K LED lumen output per led is 75lm; at 6000K the lumen output per led is 115lm. Total Lighting Output as printed in this catalogue is the actual light output of the entire fixture. The minimum CRI of the LEDs used is 85 with a majority of products over 90. Thermal Management All fixtures are designed to withstand ambient temperatures of at least 50˚C. The LEDs are mounted on metal core pcbs, which are mounted the aluminium body of the fixture so that the entire fixture acts as a heat sink. Extensive testing is performed in EMFA’s laboratory to ensure these values are maintained so that the lifetime of the LED is not compromised. Accessories:

Anti-slip Glass Please contact for this option.

KNIDOS

RECESSED DRIVE OVER FIXTURES Load 20 kN | Class I IP67 IK10

ADJUSTABLE LED FIXTURES

45º

Voltage

: 240V A.C with integrated driver (24V AC or DC on request)

Lens

: 10º, 25º, 40º

Diffuser

: 12 mm Clear Glass (Frosted Glass on request)

LED power 9 x 350 mA (9 W) Warm White Natural White Cool White Blue Red Amber Green

3000 K 4500 K 6000 K

Ø 350

Ø 330

Total Lighting Output 765 lm 765 lm 918 lm

Flush Mounted Code No 258001 258002 258003 258004 258005 258006 258007

Step Mounted Code No 258011 258012 258013 258014 258015 258016 258017

45º 275

45º 271

Ø 330

Flush Mounted

Step Mounted

ADJUSTABLE SPOTLIGHTER

45º

Lampholder Reflector Diffuser Temp Gear

: Gx8.5 : : Clear Glass : 102ºC : Electronic

METAL HALIDE CDMR-111 35W 10º or 40º Code No 254301 Flush Mounted 254311 Step Mounted

Lampholder Reflector Diffuser Temp Gear

: Gx8.5 : : Clear Glass : 102ºC : Electronic

METAL HALIDE CDMR-111 70W 10º or 40º Code No 254401 Flush Mounted 254411 Step Mounted

Ø 330

Ø 350

275

271

Ø 330

Flush Mounted

Ø 330

Step Mounted

KNIDOS

RECESSED DRIVE OVER FIXTURES Load 20 kN | Class I IP67 IK10

WALL WASHER

45º

Lampholder Reflector Diffuser Temp

: Rx 7s : Asymmetric 50º : Clear Glass : 105ºC

Lampholder Reflector Diffuser Temp

METAL HALIDE 70W

Flush Mounted Step Mounted

Code No 251111 251211

40º 0º

15º

Ø 350

Ø 330

METAL HALIDE 150W Code No 251101 251201

Flush Mounted Step Mounted

: Rx 7s-24 : Asymmetric 50º : Clear Glass : 176ºC

275

30º

500

50º 45º

271

0.93

60º

80º 250

1.68

0.46

Ø 330

50º

Flush Mounted

cd/klm

Step Mounted

ADJUSTABLE SPOTLIGHTER

45º

Lampholder Reflector Diffuser Temp

: G12 Adjustable ± 35º : 30º : Clear Glass : 102ºC

METAL HALIDE 70W Flush Mounted Step Mounted 35º 0º 1000

15º

Code No 254101 254201

: G12 Adjustable ± 35º : 30º : Clear Glass : 173ºC

METAL HALIDE 150W Flush Mounted Step Mounted

Code No 254111 254211

Ø 350

Ø 330

275

271

Ø 1.6 30º 30º 45º

Ø 330

60º

Flush Mounted

500

cd/klm

Lampholder Reflector Diffuser Temp

Ø 330

Step Mounted

KNIDOS

RECESSED DRIVE OVER FIXTURES Load 20 kN | Class I IP67 IK10

SYMMETRICAL UPLIGHTER WITH LOUVRE

Lampholder Reflector Diffuser Temp

: G x 24 q4 : Symmetric 50º : Clear Glass : 98ºC

Ø 1.38

Ø 2.93

Ø 350

Ø 330

COMPACT FLUO. 2 x 42W Flush Mounted Step Mounted

Code No 255101 255201

50º

30º

275

0º

15º

271

30º

500 Ø 330

Ø 330 250

Flush Mounted

Step Mounted

cd/klm

SYMMETRICAL WIDE BEAM UPLIGHTER

Lampholder Reflector Diffuser Temp

: G x 24 q4 : Symmetric 90º : Clear Glass : 98ºC

COMPACT FLUO. 2 x 42W Flush Mounted Step Mounted

Ø6 3m

Ø 350

Ø 330

50º 0º

Code No 256101 256201

30º 45º

60º

15º

15º 30º 45º

60º 275

500 250

271

cd/klm

Ø 330

Flush Mounted

Ø 330

Step Mounted

KNIDOS

RECESSED DRIVE OVER COOL GLASS FIXTURES Load 20 kN | Class I IP67 IK10

ADJUSTABLE SPOTLIGHTER

Lampholder Reflector Diffuser Temp

: G12 Adjustable ±15º : 30º or 42º : Clear Glass : 45ºC

Ø 2.1

Ø 350

METAL HALIDE 35W Step Mounted

Code No 257101

Ø 330 Ø 260

15º

METAL HALIDE 70W Step Mounted

Code No 257111

30º 45º

15º

40º 0º 15º

1000

45º 500

Cover 316L Stainless steel Body 316L Stainless steel Diffusers 12 mm Tempered Glass Gaskets Silicone Screws 316L Stainless Steel The Knidos Cool Glass Uplighter, completely made of 316L stainless steel has a maximum surface temperature or 55 degree when using a 70W metal halide lamp and is ideal for areas where corrosive agents such as salt water or fertilizers would harm aluminium fixtures. A fan is installed in the long body of 550mm to circulate the air for cooling. The sturdy fixture allows loads up to 20kN and IK10. An anti-slip glass is available upon request.

Glass Temperature Max 55ºC

550 30º

Special Vantilation System for Cooling

cd/klm

SANTOS 4

RECESSED DRIVE OVER FIXTURES Load 10 kN | Class I IP67 IK10

EMFA’s Santos flush mounted series is specially designed to deliver low-glare lighting to facades, columns, monuments and trees with minimal installation depth and narrow trim. The fixture is made of a combination of 316L stainless steel and die cast aluminium. A shield above the lamp reduces the glare of the metal halide lamps. A mirror finish reflector allows for a narrow to wide beam light output. An anti-slip glass is available upon request.

Cover 316L Stainless steel Body Die cast aluminium or aluminium profile with die cast aluminium bottom and connection box Gaskets Silicone Diffusers 8 mm Tempered Glass Screws 316L Stainless steel Glands 2 x PG 13.5 Recessing Tube Polyamide 6

Mounting Feature Provide at least 30 cm of drainage gravel to avoid the accumulation of water under the fixture. To make the fixture drive over, the recessing tube should be mounted flush to the ground.

Correct

When mounting the fixture on uneven surfaces, place so that the water does not accumulate on the surface of the fixture.

Incorrect This fixture is also available with 2 screws instead of 4. For this option, please contact us.

Anti-slip Glass Please contact for this option.

SANTOS 4

RECESSED DRIVE OVER FIXTURES Load 10 kN | Class I IP67 IK10

LED

Ø 208

Led

: COB LED - Adjustable

Reflector

: 10º, 23º, 38º Aluminium-Coated Polycarbonate Reflector

Diffuser

: Clear Glass

Gear

: 240V Non-Dimmable Driver (1-10V Dimmable Driver & DALI Driver available on request)

Temp

: 42ºC

303

Vertical Tilt : 30º 18 W - 500 mA Warm White Natural White

Total Lighting Output 3000 K 1224 lm

Code No 550201

4000 K

550202

1469 lm

10º

23º

38º

2m Ø 0,35m 0,01m²

13759 lx

2m Ø 0,81m 0,52m²

2705 lx

2m Ø 1,38m 1,49m²

989 lx

4m Ø 0,70m 0,38m²

3440 lx

4m Ø 1,63m 2,08m²

676 lx

4m Ø 2,76m 5,97m²

247 lx

6m Ø 1,05m 0,87m²

1529 lx

6m Ø 2,44m 4,68m²

301 lx

6m Ø 4,13m 13,40m²

110 lx

8m Ø 1,40m 1,54m²

861 lx

8m Ø 3,26m 8,33m²

169 lx

8m Ø 5,51m 23,84m²

62 lx

10m Ø 1,75m 2,40m²

550 lx

10m Ø 4,07m 13,02m²

108 lx

10m Ø 6,89m 37,29m²

40 lx

HALOGEN

Lampholder Reflector Diffuser Temp

: E27 Adjustable ±20º : : Clear Glass : 129ºC Code No 550101 HALOGEN PAR 30 75W

65lx

49lx

89lx

67lx

128lx

96lx

200lx

150lx

356lx

270lx

800lx

600lx

3200lx

2400lx

: G_53 Adjustable ±30º : : Clear Glass : 130ºC Code No 550141 HALOGEN RJ 111 50W

75W

30º

2.5m 2.0m 1.5m 1.0m 0.5m

Lampholder Reflector Diffuser Temp

10º

2.5m 2.0m 1.5m 1.0m 0.5m

75W

Ø 208

232,5

Ø 208

303

SANTOS 4

RECESSED DRIVE OVER FIXTURES Load 10 kN | Class I IP67 IK10

METAL HALIDE

Lampholder : G 8.5 fixed Reflector Diffuser

: 12º, 36º : Clear Glass

Temp

: 62ºC, 100ºC

METAL HALIDE 20W METAL HALIDE 35W

Code No 550111 550121

METAL HALIDE 70W

Code No 550131

125 250 375 500 625 750 875 1000 1125 1250 1375 1500 1625 1750 1825 2000 12º

90º

75º

125 75º 250 60º 375 500 45º 625 750 875 30º 1000 1125 1250 1375 1500 1625 1750 1825 15 2000 cd/klm

60º 45º

30º

cd/klm

Ø 208

162

Ø 208

232,5

36º

METAL HALIDE

Lampholder Reflector Diffuser Temp

: Gx8.5 Adjustable ±30º : : Clear Glass : 100ºC, 166ºC

METAL HALIDE CDMR 111 35W METAL HALIDE CDMR 111 70W

Ø 208

303

Code No 550151 550161

SANTOS 5

RECESSED DRIVE OVER FIXTURES Load 6 kN | Class I IP67 IK10

EMFA’s Santos step mounted series is specially designed to deliver low-glare lighting to facades, columns, monuments and trees with minimal installation depth and narrow trim. The fixture is made of a combination of 316L stainless steel and die cast aluminium. A shield above the lamp reduces the glare of the metal halide lamps. A mirror finish reflector allows for a narrow to wide beam light output. An anti-slip glass is available upon request.

Correct

When mounting the fixture on uneven surfaces, place so that the water does not accumulate on the surface of the fixture.

Incorrect This fixture is also available with 2 screws instead of 4. For this option, please contact us.

Anti-slip Glass Please contact for this option.

SANTOS 5

RECESSED DRIVE OVER FIXTURES Load 6 kN | Class I IP67 IK10

LED

Led

: COB LED - Adjustable

Reflector

: 10º, 23º, 38º Aluminium-Coated Polycarbonate Reflector

Ø 220

Diffuser

: Clear Glass

Gear

: 240V Non-Dimmable Driver (1-10V Dimmable Driver & DALI Driver available on request)

Temp

: 42ºC

299,5

Vertical Tilt : 30º

3000 K

Total Lighting Output Code No 1224 lm 551301

4000 K

1469 lm

18W LED - 500 mA Warm White Natural White

10º

551302

23º

38º

2m Ø 0,35m 0,01m²

13759 lx

2m Ø 0,81m 0,52m²

2705 lx

2m Ø 1,38m 1,49m²

989 lx

4m Ø 0,70m 0,38m²

3440 lx

4m Ø 1,63m 2,08m²

676 lx

4m Ø 2,76m 5,97m²

247 lx

6m Ø 1,05m 0,87m²

1529 lx

6m Ø 2,44m 4,68m²

301 lx

6m Ø 4,13m 13,40m²

110 lx

8m Ø 1,40m 1,54m²

861 lx

8m Ø 3,26m 8,33m²

169 lx

8m Ø 5,51m 23,84m²

62 lx

10m Ø 1,75m 2,40m²

550 lx

10m Ø 4,07m 13,02m²

108 lx

10m Ø 6,89m 37,29m²

40 lx

HALOGEN

Lampholder Reflector Diffuser Temp

: E27 Adjustable ±20º : : Clear Glass : 129ºC Code No 551101 HALOGEN PAR 30 75W

65lx

49lx

89lx

67lx

128lx

96lx

200lx

150lx

356lx

270lx

800lx

600lx

3200lx

2400lx

: G_53 Adjustable ±30º : : Clear Glass : 130ºC Code No 551141 HALOGEN RJ 111 50W

75W

30º

229

2.5m 2.0m 1.5m 1.0m 0.5m

Lampholder Reflector Diffuser Temp

10º

2.5m 2.0m 1.5m 1.0m 0.5m

75W

Ø 220

299,5

SANTOS 5

RECESSED DRIVE OVER FIXTURES Load 6 kN | Class I IP67 IK10

METAL HALIDE

Lampholder : G 8.5 fixed Reflector

: 12º, 36º

Diffuser

: Clear Glass

Temp

: 62ºC, 100ºC

HALOGEN PAR 20W HALOGEN PAR 35W

Code No 551111 551121

Lampholder : G 8.5 fixed Reflector : 12º, 36º Temp : 166ºC METAL HALIDE 70W

125 250 375 500 625 750 875 1000 1125 1250 1375 1500 1625 1750 1825 2000 12º

90º

75º

125 75º 250 60º 375 500 45º 625 750 875 30º 1000 1125 1250 1375 1500 1625 1750 1825 15 2000 cd/klm

60º 45º

30º

cd/klm

Ø 220

158,5

Ø 220

36º

229

Code No 551131

METAL HALIDE

Lampholder : Gx8.5 Adjustable ±30º Reflector : Diffuser Temp

Ø 220

: Clear Glass : 100ºC, 166ºC 299,5

METAL HALIDE CDMR 111 35W METAL HALIDE CDMR 111 70W

Code No 551151 551161

SANTOS 5

RECESSED DRIVE OVER FIXTURES Load 6 kN | Class I IP67 IK10

LED

Led

: COB LED - Adjustable

Reflector

: 10º, 23º, 38º Aluminium-Coated Polycarbonate Reflector

Ø 220

Diffuser

: Clear Glass

Gear

: 240V Non-Dimmable Driver (1-10V Dimmable Driver & DALI Driver available on request)

Temp

: 42ºC

299,5

Vertical Tilt : 30º 18W LED - 500 mA Warm White Natural White

3000 K 4000 K

Total Lighting Output Code No 768 lm 551311 864 lm

10º

551312

23º

38º

2m Ø 0,35m 0,01m²

13759 lx

2m Ø 0,81m 0,52m²

2705 lx

2m Ø 1,38m 1,49m²

989 lx

4m Ø 0,70m 0,38m²

3440 lx

4m Ø 1,63m 2,08m²

676 lx

4m Ø 2,76m 5,97m²

247 lx

6m Ø 1,05m 0,87m²

1529 lx

6m Ø 2,44m 4,68m²

301 lx

6m Ø 4,13m 13,40m²

110 lx

8m Ø 1,40m 1,54m²

861 lx

8m Ø 3,26m 8,33m²

169 lx

8m Ø 5,51m 23,84m²

62 lx

10m Ø 1,75m 2,40m²

550 lx

10m Ø 4,07m 13,02m²

108 lx

10m Ø 6,89m 37,29m²

40 lx

HALOGEN

Lampholder : E27 Adjustable ±20º

65lx

49lx

Reflector

: -

89lx

67lx

Diffuser

: Clear Glass

128lx

96lx

200lx

150lx

Temp

: 129ºC

356lx

270lx

800lx

600lx

3200lx

2400lx

HALOGEN PAR 30 75W

Code No 551201

Reflector

: -

Diffuser

: Clear Glass

Temp

: 130ºC

HALOGEN RJ 111 50W

Code No 551241

75W

30º

229

2.5m 2.0m 1.5m 1.0m 0.5m

Lampholder : G_53 Adjustable ±30º

10º

2.5m 2.0m 1.5m 1.0m 0.5m

75W

Ø 220

299,5

SANTOS 5

RECESSED DRIVE OVER FIXTURES Load 6 kN | Class I IP67 IK10

METAL HALIDE

Lampholder : G 8.5 fixed Reflector

: 12º, 36º

Diffuser

: Clear Glass

Temp

: 62ºC, 100ºC

METAL HALIDE 20W METAL HALIDE 35W

Code No 551211 551221

METAL HALIDE 70W

Code No 551231

125 250 375 500 625 750 875 1000 1125 1250 1375 1500 1625 1750 1825 2000 12º

90º

75º

125 75º 250 60º 375 500 45º 625 750 875 30º 1000 1125 1250 1375 1500 1625 1750 1825 15 2000 cd/klm

60º 45º

30º

cd/klm

Ø 220

229

Ø 220

36º

158,5

METAL HALIDE

Lampholder : Gx8.5 Adjustable ±30º Reflector

Ø 220

: -

Diffuser

: Clear Glass

Temp

: 100ºC, 166ºC

METAL HALIDE CDMR 111 35W METAL HALIDE CDMR 111 70W

299,5

Code No 551251 551261

TEOS

RECESSED DRIVE OVER FIXTURES Load 50 kN | Class I IP67 IK10

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

EMFA’s Teos 3 Recessed Drive Over LED Fixture is specially designed to deliver high output LED light to ground surfaces of roads, carparks and pathways. This heavy duty fixture is designed to withstand the weight of large vehicles. Its robust construction allows for a maximum static load of 5000kg. The body and head of the fixture are made of die cast aluminium, while the recessing tube is made of steel to withstand the repeated impact of driving vehicles’ tires. The high power LEDs are positioned and angled to provide maximum light output. The electronic LED driver is housed in the base of the fixture. The fixture comes with 2 x PG13.5 cable glands and 0.5m cable. Cover Die cast aluminium Body Die cast aluminium Gaskets Silicone Diffusers Polycarbonate Screws 316L Stainless steel Glands 2 x PG 13.5 Cable 0.5m 3x0,75 mm H05VV-F Recessing Tube Electrostatic powder paint Coated steel

Correct

Incorrect

When mounting the fixture on uneven surfaces, place so that the water does not accumulate on the surface of the fixture.

LEDs Only highest quality LEDs such as Cree or Toplite are used in production allowing for maximum lumen output and maximum lifetime. Most LEDs run on 350mA or 700mA depending on how much light output is required. The white color temperature binning is 200K at most, and always on the same x,y coordinates on the CIE diagram in accordance with Energy Star. This ensures consistent supply of the same color temperatture over time. As LEDs are constantly developing and becoming more efficient, lumen output given in this catalogue are current as of March 2020. At 2700K, 3000K, and 4000K LED lumen output per led is 110lm; at 6000K the lumen output per led is 125lm. Total Lighting Output as printed in this catalogue is the actual light output of the entire fixture. The minimum CRI of the LEDs used is 85 with a majority of products over 90. Thermal Management All fixtures are designed to withstand ambient temperatures of at least 50˚C. The LEDs are mounted on metal core pcbs, which are mounted the aluminium body of the fixture so that the entire fixture acts as a heat sink. Extensive testing is performed in EMFA’s laboratory to ensure these values are maintained so that the lifetime of the LED is not compromised.

TEOS 3

RECESSED DRIVE OVER FIXTURES Load 50 kN | Class I IP67 IK10

Available in any of these RAL colors

7004

7016

9005

9016

Led

: Linear LEDs

Voltage

: 240 VAC with integrated driver

6002

1015

(12-24 VDC on request) Diffuser

Mono

Mono Mono Duo 1-way Duo 1-way Duo 2-way Duo 2-way Trio Trio Quad Quad

: Polycarbonate

1 x 350 mA (4W) LED 1 x 350 mA (4W) LED 2 x 350 mA (8W) LED 2 x 350 mA (8W) LED 2 x 350 mA (8W) LED 2 x 350 mA (8W) LED 3 x 350 mA (12W) LED 3 x 350 mA (12W) LED 4 x 350 mA (16W) LED 4 x 350 mA (16W) LED

Total Lighting Output Code No 165 lm 180101 192 lm 180102 330 lm 180111 384 lm 180112 330 lm 180121 384 lm 180122 495 lm 180131 576 lm 180132 660 lm 180141 768 lm 180142

3000 K 5000 K 3000 K 5000 K 3000 K 5000 K 3000 K 5000 K 3000 K 5000 K

Duo 1-way

Ø 240

177

Duo 2-way 159

63Lx

16Lx

Trio

0.5

1m m

1.5

7Lx 2m

4Lx m

2.5

2.5Lx

1.8Lx

1.3Lx

3.5

1Lx

Quad

Lux levels for one aperture at 3000K

MIRA

RECESSED DRIVE OVER FIXTURES Load 20 kN | Class I IP67 IK10

The Mira series consists of a range of LED and fluorescent sources to deliver the desired light effect to facades, columns, bridges, monuments, and signs. The series is made of a die cast aluminium body with electrostatic powder paint finished with a 316L stainless steel cover. The recessed versions are for drive over up to 20 kN including a stainless steel recessing box. The surface mounted versions come with a heavy-duty 316L stainless steel bracket. The fixtures come with integrated electronic ballasts and a specially developed potted power cable to effectively bond with the cast resin and stop any water ingress. The LEDs used come in 3 different tones of white, as well as blue, red, green, amber and RGB. Several lenses from 6 to 40 degrees are available to choose from to achieve the desired the light effect. Cover 316L Stainless steel Body Die cast aluminium Diffusers 12 mm Tempered Glass Gaskets Silicone Screws 316L Stainless steel Recessing Box Stainless steel “Customization” is EMFA’s standard EMFA offers many combinations for each fixture, as all fixtures are made in house. A combination of 2 finishes of stainless steel, 8 LED colors, 2 wattages, and 5 or more lenses and reflectors are available to make the fixture suitable for the required application. This is done without increasing lead-time and is available for large as well as small quantities.

MIRA 1

RECESSED DRIVE OVER FIXTURES Load 20 kN | Class I IP67 IK10

SYMMETRICAL LED

Voltage

Lens Diffuser Cable

: 240V AC with integrated driver (24V AC or DC on request) for RGB “240V AC with remote driver” : 10º, 25º, 40º : Clear Glass 12 mm (Frosted Glass on request) : Potted 5 m 3x0,75 H03 VV-F

12 x 350 mA (12 W) LED Warm White Natural White Cool White Blue Red Amber Green

3000 K 4500 K 6000 K

400

365

Total Lighting Output Code No 1020 lm 430111 1020 lm 430116 1224 lm 430117 430112 430113 430114 430115

27 x 350 mA (27 W) RGB LED RGB

100

65 370

Stainless Steel Recessing Box

Code No 430161

ASYMMETRICAL LED

12 x 350 mA (12 W) LED Warm White Natural White Cool White Blue Red Amber Green

3000 K 4500 K 6000 K

Total Lighting Output Code No 1020 lm 430351 1020 lm 430352 1224 lm 430353 430354 430355 430356 430357

27 x 350 mA (27 W) RGB LED RGB

400

365

6x25

100 20º

370

Stainless Steel Recessing Box

Code No 430361

MIRA 1

RECESSED DRIVE OVER FIXTURES Load 20 kN | Class I IP67 IK10

SYMMETRICAL FLUO.

Voltage

: 240V AC with integrated ballast

Diffuser

: Clear Glass 12 mm

(Frosted Glass on request) Reflector

400

: Symmetrical

Lampholder : W 4,3 x 8,5 d

365

55º

Ballast

: Electronic

Cable

: Potted 5 m 3x0,75 H03 VV-F

FLUO T-2 1x8W (included)

100 100 65

Code No 430141

370

Stainless Steel Recessing Box

ASYMMETRICAL FLUO.

Voltage

: 240V AC with integrated ballast

Diffuser

: Clear Glass 7 + 5 mm

Reflector

: Asymmetrical

(Frosted Glass on request) 400

365

35º

Lampholder : W 4,3 x 8,5 d Ballast

: Electronic

Cable

: Potted 5 m 3x0,75 H03 VV-F

72,5º

100

FLUO T-2 1x8W (included)

Code No 430151

370 65

Stainless Steel Recessing Box

MIRA 2

RECESSED DRIVE OVER FIXTURES Load 20 kN | Class I IP67 IK10

SYMMETRICAL LED

Voltage

: 240V AC with integrated ballast

(12V DC or 24V DC on request) Diffuser

160

: Clear Glass 12 mm (Frosted Glass on request)

Cable

125

400

: Potted 5 m 3x0,75 H03 VV-F

4 x 350 mA (12 W) LED Warm White Natural White

3000 K 5000 K

Total Lighting Output Code No 430721 1400 lm 430722 1680 lm

110

365

110

130

130 370

Stainless Steel Recessing Box

SYMMETRICAL LED

Voltage

: 240V AC with integrated ballast

(12V DC or 24V DC on request) Diffuser

160

: Milky Clear Glass 12 mm (Frosted Glass on request)

Cable

400

125

365

: Potted 5 m 3x0,75 H03 VV-F

4 x 350 mA (12 W) LED Warm White Natural White

3000 K 5000 K

Total Lighting Output Code No 700 lm 430731 840 lm 430732

110

130

130 370

Stainless Steel Recessing Box

MIRA 2

RECESSED DRIVE OVER FIXTURES Load 20 kN | Class I IP67 IK10

15°+15° ASYMMETRICAL LED

Voltage

: 240V AC with integrated driver for RGB “240V AC with remote driver” Lens : 10º, 25º, 40º Diffuser : Clear Glass 12 mm (Frosted Glass on request) Cable : Potted 5 m 3x0,75 H03 VV-F Total 24 x 350 mA (24 W) LED Lighting Output Code No 3000 K 2040 lm 430401 Warm White 4500 K 2040 lm 430406 Natural White 6000 K 2448 lm 430407 Cool White 430402 Blue 430403 Red 430404 Amber 430405 Green 54 x 350 mA (54 W) RGB LED RGB

90 160

125

365

400 25º

75º 110

110

130

15º 15º 370

Stainless Steel Recessing Box 130

Code No 430441

0°+15°+15° ASYMMETRICAL LED

36 x 350 mA (36 W) LED Warm White Natural White Cool White Blue Red Amber Green

3000 K 4500 K 6000 K

Total Lighting Output Code No 3060 lm 430501 3060 lm 430506 3672 lm 430507 430502 430503 430504 430505

90 160

125

40º 110 82º 130 110

15º 15º

0º

370

Stainless Steel Recessing Box 130

365

400

MIRA 2

RECESSED DRIVE OVER FIXTURES Load 20 kN | Class I IP67 IK10

30°+15°+0° ASYMMETRICAL LED

Voltage

: 240V AC with integrated driver

for RGB “240V AC with remote driver” Lens

: 10º, 25º, 40º

Diffuser

: Clear Glass 12 mm

160

125

(Frosted Glass on request) : Potted 5 m 3x0,75 H03 VV-F Total 36 x 350 mA (36 W) LED Lighting Output Code No 3000 K 3060 lm 430601 Warm White 4500 K 3060 lm 430606 Natural White 6000 K 3672 lm 430607 Cool White 430602 Blue 430603 Red 430604 Amber 430605 Green

365

400 55º

Cable

110

75º

130 110

370

30º 15º 0º

Stainless Steel Recessing Box

130

SYMMETRICAL LED

36 x 350 mA (36 W) LED Warm White Natural White Cool White Blue Red Amber Green

3000 K 4500 K 6000 K

Total Lighting Output Code No 3060 lm 430611 3060 lm 430612 3672 lm 430613 430614 430615 430616 430617

90 160

125

365

400

40º 110

82º 130

110

0º

370

Stainless Steel Recessing Box 130

MIRA 2

RECESSED DRIVE OVER FIXTURES Load 20 kN | Class I IP67 IK10

SYMMETRICAL FLUO.

Voltage

: 240V AC with integrated ballast

Diffuser

: Clear Glass 12 mm

90 160

(Frosted Glass on request) Reflector

: Symmetrical

125

Lampholder : W 4,3 x 8,5 d Ballast

: Electronic

FLUO T-2 3x8W (included)

365

400

121º 110

Code No 430701

130

110

370

Stainless Steel Recessing Box 130

ASYMMETRICAL METAL HALIDE

Voltage

: 240V AC with integrated ballast

Diffuser

: Clear Glass 12 mm

90 160

(Frosted Glass on request) Reflector

: Asymmetrical

125

Lampholder : G 8,5 Ballast

365

400

: Electronic 69º

Code No Metal Halide 70W (not included) 430711

110

130 110

370

Stainless Steel Recessing Box 130

ASSOS 2

RECESSED DRIVE OVER FIXTURES Load 15 kN | Class I IP67 IK10

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

EMFA’s Assos 2 series is specially designed to light facades, columns, monuments and trees with a die cast aluminium grill protecting the glass. The fixture can be equipped with metal halide, halogen or fluorescent lamps. The fixture is made completely of die cast aluminium body, which allows for IP67 and IK10 and a load of 15kN. The fixture comes with a polyamide recessing tube for easy mounting in the ground or concrete. A louvre can be ordered separately to reduce the glare of the lamps.

Cover Die cast aluminium Body Die cast aluminium or aluminium profile with die cast aluminium bottom and connection box. Gaskets Silicone Diffusers 8 mm Tempered Glass Screws 316L Stainless steel Glands 2 x PG 13.5 Recessing Tube Polyamide 6

Accessories: Louvre To avoid glare. Can be applied to all lamp types except Halogen PAR 30 and 38 Code No

955105

Dichroic Color Glass Filter Can be applied to all lamp types except Halogen PAR 38. Code No 955101 - Blue Code No 955102 - Red Code No 955103 - Yellow Code No 955104 - Green

Caution: The louvre and filter cannot be applied to the standard fixture. These options should be mentioned when ordering.

Correct

When mounting the fixture on uneven surfaces, place so that the water does not accumulate on the surface of the fixture.

Incorrect

This fixture is suitable for helicopter landing pads due to its heavy duty aluminium cover.

ASSOS 2

RECESSED DRIVE OVER FIXTURES Load 15 kN | Class I IP67 IK10

Lampholder : E27 fixed Reflector : Diffuser Temp

: Clear Glass : 129ºC

49lx

208lx

67lx

300lx

96lx

468lx

150lx

266lx

1875lx

600lx

7500lx

2400lx

10º

201141

Lampholder : G12 Fixed or Adjustable ± 20º Reflector

: 30º, 42º

Diffuser

: Clear Glass

Temp

500

: : Clear Glass

Temp

: 35W - 67ºC

(24º or 60º)

Ø 208

75º

625

60º 45º

70W

875

cd/km 30º

375

42º

30º

Ø 208

234,5

50W - 80ºC HALOGEN PAR 16 35W / 50 W

cd/km

70W

235

750 30º

875

Lampholder : Gu 5.3 Fixed or Adjustable ± 30º Diffuser

500

750

Code No METAL HALIDE 35W / 70W / 150W 201241

30º

375

45º

625

150W - 238ºC

1015

250 60º

375

70W - 144ºC

6002

Ø 205

90º

250

9016

125

75º

9005

4m 15º

90º 125

: 35W - 99ºC

Reflector

75W

7016

2.5m 2.0m 1.5m 1.0m 0.5m

75W

5º

2.5m 2.0m 1.5m 1.0m 0.5m

HALOGEN PAR 38 100W 30º

7004

152lx

833lx

Code No HALOGEN PAR 30 75W (10º or 30º) 201131

Available in any of these RAL colors

Code No 201181

ASSOS 3

RECESSED DRIVE OVER FIXTURES Load 15 kN | Class I IP67 IK10

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

EMFA’s Assos 3 series is specially designed to light pathways, roads, and gardens. The fixture can be equipped with LED, halogen or fluorescent lamps. The fixture has 3 different options of cover: Multi, Mono, Dual, and Wall to give different lighting effects. In combination with the die cast aluminium body, the fixture allows for IP67 and IK10 and a load of 15kN. The fixture comes with a polyamide recessing tube for easy mounting in the ground or concrete.

Cover Die cast aluminium Body Die cast aluminium or aluminium profile with die cast aluminium bottom and connection box. Gaskets Silicone Diffusers Tempered press glass or polycarbonate Screws 316L Stainless steel Glands 2 x PG 13.5 Recessing Tube Polyamide 6

Multi

Mono

Dual

Wall

Correct

Incorrect

When mounting the fixture on uneven surfaces, place so that the water does not accumulate on the surface of the fixture.

ASSOS 3

RECESSED DRIVE OVER FIXTURES Load 15 kN | Class I IP67 IK10

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

Ø 205

102

Mono

Led

: Linear LEDs

Voltage

: 240 VAC with integrated driver (12-24 VDC on request)

Diffuser

: Polycarbonate

Led

: Linear LEDs

Mono Dual Wall Multi

1 x 350 mA (3W) LED 2 x 350 mA (6W) LED 2 x 350 mA (6W) LED 1 x 320 mA (11W) LED

Total Lighting Code No Output 350 lm 203141 700 lm 204141 700 lm 205141 925 lm 202141

HALOGEN 25-40W Dual

Lampholder : G9 Fixed Diffuser

: Clear Glass Code No 202101 203101 204101 205101

Multi Mono Dual Wall

HALOGEN 25-40W Lampholder : Gx53 Fixed Multi

Diffuser Multi Mono Dual Wall

: Clear Glass / Polycarbonate Code No 202111 203111 204111 205111

HALOGEN 25-40W Lampholder : G 6.35 Fixed Diffuser Wall

Multi Mono Dual Wall

: Clear Glass Code No 202121 203121 204121 205121

ASSOS 4

RECESSED DRIVE OVER FIXTURES Load 15 kN | Class I IP67 IK10

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

EMFA’s Assos 4 series is specially designed to light facades, columns, monuments and trees. The fixture can be equipped with metal halide, halogen or fluorescent lamps. The fixture has 3 different options of cover: 316 stainless steel, die cast aluminium or bronze in combination with the die cast aluminium body which allows for IP67 and IK10 and a load of 15kN. The fixture comes with a polyamide recessing tube for easy mounting in the ground or concrete. A louvre can be ordered separately to reduce the glare of the lamps. An anti-slip glass is available upon request.

Cover Die cast aluminium / 316L Stainless Steel Body Die cast aluminium or aluminium profile with die cast aluminium bottom and connection box. Gaskets Silicone Diffusers 15 mm Tempered Glass Screws 316L Stainless steel Glands 2 x PG 13.5 Recessing Tube Polyamide 6

Mounting Feature

Accessories: Provide at least 30 cm of drainage gravel to avoid the accumulation of water under the fixture. To make the fixture drive over, the recessing tube should be mounted flush to the ground.

Louvre To avoid glare. Can be applied to all lamp types except Halogen PAR 30 and 38 Code No

Correct

When mounting the fixture on uneven surfaces, place so that the water does not accumulate on the surface of the fixture.

955105

Dichroic Color Glass Filter Can be applied to all lamp types except Halogen PAR 38. Code No 955101 - Blue Code No 955102 - Red Code No 955103 - Yellow Code No 955104 - Green

Incorrect

Caution: The louvre and filter cannot be applied to the standard fixture. These options should be mentioned when ordering. Anti-slip Glass Please contact for this option.

ASSOS 4

RECESSED DRIVE OVER FIXTURES Load 15 kN | Class I IP67 IK10

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

HALOGEN or FLUO.

HALOGEN LINEAR 60W Lampholder : R7s fixed Reflector

: 50ºC

Diffuser

: Frosted Glass

Temp

: 100ºC

Code No Alum. 206101 Inox (Stainless Steel) 207101

15lx

20lx

30lx

46lx

184lx

737lx

1m 4.5m 4.0m 3.5m 3.0m 2.5m 2.0m 1.5m 1.0m 0.5m

50º

ELECTRONIC FLUO. 23W Reflector

: 80ºC

Diffuser

: Frosted Glass

Temp

: 43ºC

101,5

4m 25º

82lx

100W

Lampholder : E27 Fixed

Ø 205

Ø 208

Code No 206111 Inox (Stainless Steel) 207111 Alum.

309

HALOGEN

HALOGEN PAR 30 75W Lampholder : E27 fixed Reflector

: -

Diffuser

: Clear Glass

Temp

: 129ºC

Code No 206131 Inox (Stainless Steel) 207131 Alum.

49lx

67lx

96lx

150lx 266lx

4m 15º

2400lx

: -

Diffuser

: Clear Glass

Temp

: 129ºC

239,5

2.5m 2.0m 1.5m 1.0m 0.5m

Reflector

Code No 221311 Inox (Stainless Steel) 221321 Alum.

600lx

75W 30º

HALOGEN PAR 30 75W Lampholder : E27 Adjustable ± 20º

Ø 205

Ø 208

309

ASSOS 4

RECESSED DRIVE OVER FIXTURES Load 15 kN | Class I IP67 IK10

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

HALOGEN

HALOGEN PAR 16 35W / 50W (24º or 60º) Lampholder : Gu 5.3 Fixed or Adjustable ± 30º Reflector

: -

Diffuser

: Clear Glass

Temp

: 35W - 67ºC

Ø 208

Alum. Inox (Stainless Steel)

Code No 206181 207181

238,5

50W - 80ºC

HALOGEN RJ 111 50W (4º, 8º or 24º) Lampholder : G 53 Fixed or Adjustable ± 20º Reflector

: -

Diffuser

: Clear Glass

Temp

: 130ºC

Ø 208

Alum. Inox (Stainless Steel)

Code No 221511 221521 309

METAL HALIDE

METAL HALIDE CDMR 111 35W / 70W Lampholder : G x 8.5 Fixed or Adjustable ± 15º Reflector

: -

Diffuser

: Clear Glass

Temp

: 166ºC

Ø 208

Alum. Inox (Stainless Steel)

Code No 206271 207271 379,5

METAL HALIDE 35W / 70W / 150W Lampholder : G12 Fixed or Adjustable ± 20º Reflector

: 30º, 42º

Diffuser

: Clear Glass

Temp

: 35W - 99ºC

Alum. Inox (Stainless Steel)

Code No 206241 207241

70W - 144ºC 150W - 238ºC 39

ASSOS 6

RECESSED DRIVE OVER FIXTURES Load 15 kN | Class I IP67 IK10

EMFA’s Assos 6 series is specially designed to light facades, columns, monuments and trees. The fixture can be equipped with metal halide, halogen or fluorescent lamps. The fixture is made of a combination of 316L stainless steel and die cast aluminium, which allows for IP67 and IK10 and a load of 15kN. The fixture comes with a polyamide recessing tube for easy mounting in the ground or concrete. A louvre can be ordered separately to reduce the glare of the lamps. An anti-slip glass is available upon request.

Cover 316L Stainless steel Body Die cast aluminium or aluminium profile with die cast aluminium bottom and connection box. Gaskets Silicone Diffusers 15 mm Tempered Glass (Aluminium Cover) Screws 316L Stainless steel Glands 2 x PG 13.5 Recessing Tube Polyamide 6

Mounting Features

Accessories: Provide at least 30 cm of drainage gravel to avoid the accumulation of water under the fixture. To make the fixture drive over, the recessing tube should be mounted flush to the ground.

Louvre To avoid glare. Can be applied to all lamp types except Halogen PAR 30 and 38 Code No

Correct

When mounting the fixture on uneven surfaces, place so that the water does not accumulate on the surface of the fixture.

955105

Dichroic Color Glass Filter Can be applied to all lamp types except Halogen PAR 38. Code No 955101 - Blue Code No 955102 - Red Code No 955103 - Yellow Code No 955104 - Green

Caution: The louvre and filter cannot be applied to the standard fixture. These options should be mentioned when ordering.

Incorrect

Anti-slip Glass Please contact for this option.

Square Version: All fixtures are available with a square cover with dimensions 220 x 220 mm. Please indicate square version when ordering. 41

ASSOS 6

RECESSED DRIVE OVER FIXTURES Load 15 kN | Class I IP67 IK10

HALOGEN or FLUO.

HALOGEN LINEAR 60W Lampholder : R7s fixed Reflector

: 50ºC

Diffuser

: Frosted Glass

Temp

: 100ºC

Inox (Stainless Steel)

Code No 212101

15lx

20lx

30lx

46lx

737lx

1m 50º

4.5m 4.0m 3.5m 3.0m 2.5m 2.0m 1.5m 1.0m 0.5m

Reflector

184lx

100W

Lampholder : E27 fixed

101,5

4m 25º

82lx

ELECTRONIC FLUO. 23W

Ø 205

Ø 185

Inox (Stainless Steel)

Code No 212111

: 80ºC

Diffuser

: Frosted Glass

Temp

: 43ºC

231

HALOGEN

HALOGEN PAR 16 35W / 50W (24º or 60º)

Ø 208

Lampholder : Gu 5.3 Fixed or Adjustable ± 30º Reflector

: -

Diffuser

: Clear Glass

Temp

: 35W - 67ºC

Inox (Stainless Steel)

Code No 212181 234,5

50W - 80ºC Ø 208

HALOGEN RJ111 50W (4º, 8º or 24º) Lampholder : G 53 Fixed or Adjustable ± 20º Reflector

Code No 212591

: -

Diffuser

: Clear Glass

Temp

: 130ºC

Inox (Stainless Steel)

305

ASSOS 6

RECESSED DRIVE OVER FIXTURES Load 15 kN | Class I IP67 IK10

HALOGEN

HALOGEN PAR 30 / 75W Lampholder : E27 fixed Reflector

: -

Diffuser

: Clear Glass

Temp

: 129ºC

Inox (Stainless Steel)

Code No 212131

49lx

67lx

96lx

150lx

266lx 600lx

2400lx

Reflector

Inox (Stainless Steel)

30º

235,5

2.5m 2.0m 1.5m 1.0m 0.5m

Lampholder : E27 Adjustable ± 20º

15º

75W

HALOGEN PAR 30 / 75W

Ø 205

Code No 221391

Ø 208

: -

Diffuser

: Clear Glass

Temp

: 129ºC

234,5

METAL HALIDE

METAL HALIDE CDMR 111 35W / 70W

Ø 208

Lampholder : G x 8.5 Fixed or Adjustable ± 15º Reflector

: -

Diffuser

: Clear Glass

Temp

: 166ºC

Inox (Stainless Steel)

375

METAL HALIDE 35W / 70W / 150W Lampholder : G12 Fixed or Adjustable ± 20º Reflector

: 30º, 42º

Diffuser

: Clear Glass

Temp

: 35W - 99ºC

Code No 212271

Inox (Stainless Steel)

Code No 212241 90º 125

90º 125

75º

250 375

70W - 144ºC

500

375 500

45º

625

150W - 238ºC

625

750

750 30º

875 cd/km

70W 30º

75º

250 60º

70W

875 42º

60º 45º

cd/km 30º

Walk Over

MIRA 5

RECESSED WALK OVER FIXTURES Load 20 kN | Class I IP67 IK10

The Mira series consists of a range of LED sources to deliver the desired light effect to facades, columns, bridges, monuments, and signs. The series is made of a die cast aluminium body with electrostatic powder paint finished with a 316L stainless steel cover. The recessed versions are for Walk over up to 20 kN including a stainless steel recessing box. The surface mounted versions come with a heavy-duty 316L stainless steel bracket. The fixtures come with integrated electronic ballasts and a specially developed potted power cable to effectively bond with the cast resin and stop any water ingress. The LEDs used come in 3 different tones of white, as well as blue, red, green, amber and RGB. Several lenses from 6 to 40 degrees are available to choose from to achieve the desired the light effect.

Cover 316L Stainless steel Body Die cast aluminium Diffusers 12 mm Tempered Glass Gaskets Silicone Screws 316L Stainless Steel Recessing Box Stainless steel

“Customization” is EMFA’s standard EMFA offers many combinations for each fixture, as all fixtures are made in house. A combination of 2 finished of stainless steel, 8 LED colors, 2 wattages, and 5 or more lenses and reflectors are available to make the fixture suitable for the required application. This is done without increasing lead-time and is available for large as well as small quantities.

MIRA 5

RECESSED WALK OVER FIXTURES Load 20 kN | Class I IP67 IK10

SYMMETRICAL LED

110

1000

Voltage

: 240V AC with integrated driver 80

(24V AC or DC on request) for RGB “240V AC with remote driver” Lens

: 10º, 25º, 40º

Diffuser

: Clear Glass 12 mm

Cable

: Potted 5 m 3x0,75 H03 VV-F

958

(Frosted Glass on request) 100

24 x 350 mA (24 W) LED Warm White Natural White Cool White Blue Red Amber Green

3300 K 4500 K 6000 K

24 x 700 mA (48 W) LED Warm White Natural White Cool White Blue Red Amber Green

3300 K 4500 K 6000 K

RGB LED 48W RGB

Total Lighting Output 2040 lm 2040 lm 2244 lm

Total Lighting Output 3848 lm 3848 lm 4232 lm

Code No 440201 440202 440203 440204 440205 440206 440207

988

Recessing Box

Code No 440211 440212 440213 440214 440215 440216 440217 Code No 440218

MILET ANI

RECESSED WALK OVER FIXTURES Load 2 kN | Class I IP67 IK10

Cover 316L Stainless steel Body Die cast aluminium Gaskets Silicone Diffusers 8 mm Tempered Glass Screws 316L Stainless Steel

Symmetrical

Galvanized Recessing Box 45º 90º

Asymmetrical

Asym. Glass

Trenched Glass Milky Glass

Clear Glass

55º 45º

ANI

RECESSED WALK OVER FIXTURES Load 2 kN | Class I IP67 IK10

Symmetrical Led

: Linear LEDs

Voltage

: 240 VAC with integrated driver (12-24 VDC on request)

Diffuser

45º 90º

: 8mm Tempered Glass

Beam Angle : 45°/ 60°/ 90°

ANI 3 Power Code No 18W 450201 36W 450211 18W 450202 36W 450212

Kelvin 3000 K 3000 K 4000 K 4000 K

ANI 4 Power Code No 24W 450301 48W 450311 24W 450302 48W 450312

Kelvin 3000 K 3000 K 4000 K 4000 K

Nominal Real Lumen Lumen Output Output 1200 lm 1700 lm 2300 lm 3300 lm 1380 lm 1955 lm 2645 lm 2932 lm

Nominal Real Lumen Lumen Output Output 1780 lm 2550 lm 3080 lm 4300 lm 2047 lm 2932 lm 3542 lm 5060 lm

Galvanized Recessing Box

180

154

Kelvin 3000 K 3000 K 4000 K 4000 K

108

148

Galvanized Recessing Box

180

154

Power Code No 12W 450101 24W 450111 12W 450102 24W 450112

Nominal Real Lumen Lumen Output Output 1020 lm 1460 lm 1780 lm 2550 lm 1173 lm 1679 lm 2047 lm 2932 lm

154

188

Galvanized Recessing Box

180

154

ANI 2

Kelvin 3000 K 3000 K 4000 K 4000 K

180

Power Code No 6W 450001 12W 450011 6W 450002 12W 450012

Nominal Real Lumen Lumen Output Output 600 lm 850 lm 1020 lm 1460 lm 690 lm 977 lm 1173 lm 1679 lm

ANI 1

: %70

130

: >80

L.O.R %

170

CRI

210

250

Mac Adam

228

Galvanized Recessing Box

ANI

RECESSED WALK OVER FIXTURES Load 2 kN | Class I IP67 IK10

Asymmetrical Led

: Linear LEDs

Voltage

: 240 VAC with integrated driver

Diffuser

: 8mm Tempered Glass

(12-24 VDC on request)

55º

45º

Beam Angle : 45°/ 60°/ 90°

ANI 3 Power Code No 18W 451701 36W 451711 18W 451702 36W 451712

Kelvin 3000 K 3000 K 4000 K 4000 K

ANI 4 Power Code No 24W 451801 48W 451811 24W 451802 48W 451812

Kelvin 3000 K 3000 K 4000 K 4000 K

Nominal Lumen Output 1700 lm 3300 lm 1955 lm 2932 lm

Real Lumen Output 1780 lm 3080 lm 2047 lm 3542 lm

Nominal Lumen Output 2550 lm 4300 lm 2932 lm 5060 lm

Real Lumen Output 1200 lm 2300 lm 1380 lm 2645 lm

180

Kelvin 3000 K 3000 K 4000 K 4000 K

Nominal Lumen Output 1460 lm 2550 lm 1679 lm 2932 lm

148

154

Galvanized Recessing Box

180

154

Power Code No 12W 451601 24W 451611 12W 451602 24W 451612

Real Lumen Output 1020 lm 1780 lm 1173 lm 2047 lm

108

154

188

Galvanized Recessing Box

180

154

ANI 2

180 80

Kelvin 3000 K 3000 K 4000 K 4000 K

Nominal Lumen Output 850 lm 1460 lm 977 lm 1679 lm

Power Code No 6W 451501 12W 451511 6W 451502 12W 451512

Real Lumen Output 600 lm 1020 lm 690 lm 1173 lm

ANI 1

: %70

130

: 80

L.O.R %

170

CRI

210

250

Mac Adam

228

Galvanized Recessing Box

ASSOS 6

RECESSED WALK OVER FIXTURES Class I IP67 IK10

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

EMFA’s Assos 6 Alum series is specially designed to light trees and bushes where drive over is not required. The fixture can be equipped with metal halide, halogen or fluorescent lamps. The fixture is made of die cast aluminium and allows for allows for IP67 and IK10. The fixture comes with a polyamide recessing tube for easy mounting in the ground or concrete. A louvre can be ordered separately to reduce the glare of the lamps. An anti-slip glass is available upon request.

Cover Die cast aluminium Body Die cast aluminium or aluminium profile with die cast aluminium bottom and connection box. Gaskets Silicone Diffusers 15 mm Tempered Glass (Aluminium Cover) Screws 316L Stainless steel Glands 2 x PG 13.5 Recessing Tube Polyamide 6

Mounting Features

Accessories: Provide at least 30 cm of drainage gravel to avoid the accumulation of water under the fixture. To make the fixture drive over, the recessing tube should be mounted flush to the ground.

Louvre To avoid glare. Can be applied to all lamp types except Halogen PAR 30 and 38 Code No

Correct

When mounting the fixture on uneven surfaces, place so that the water does not accumulate on the surface of the fixture.

955105

Dichroic Color Glass Filter Can be applied to all lamp types except Halogen PAR 38. Code No 955101 - Blue Code No 955102 - Red Code No 955103 - Yellow Code No 955104 - Green

Caution: The louvre and filter cannot be applied to the standard fixture. These options should be mentioned when ordering.

Incorrect

Anti-slip Glass Please contact for this option.

Square Version: All fixtures are available with a square cover with dimensions 200 x 200 mm. Please indicate square version when ordering.

ASSOS 6

RECESSED WALK OVER FIXTURES Class I IP67 IK10

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

HALOGEN or FLUO.

HALOGEN LINEAR 60W Lampholder : R7s fixed Reflector

: 50ºC

Diffuser

: Frosted Glass

Temp

: 100ºC

Alum.

Code No 211101

15lx

20lx

30lx

46lx

737lx

1m 50º

4.5m 4.0m 3.5m 3.0m 2.5m 2.0m 1.5m 1.0m 0.5m

Reflector

184lx

100W

Lampholder : E27 fixed

4m 25º

82lx

ELECTRONIC FLUO. 23W

Ø 185

Alum.

Code No 212281

: 80ºC

Diffuser

: Frosted Glass

Temp

: 43ºC

231

HALOGEN

HALOGEN PAR 16 35W / 50W (24º or 60º)

Ø 208

Lampholder : Gu 5.3 Fixed or Adjustable ± 30º Reflector

: -

Diffuser

: Clear Glass

Temp

: 35W - 67ºC

Alum.

Code No 211181 228,5

50W - 80ºC HALOGEN RJ 111 50W (4º, 8º or 24º) Lampholder : Gu 5.3 Fixed or Adjustable ± 20º Reflector

Alum.

Code No 221561

Ø 208

: -

Diffuser

: Clear Glass

Temp

: 130ºC

301,5

ASSOS 6

RECESSED WALK OVER FIXTURES Class I IP67 IK10

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

HALOGEN

INCANDESCENT 60 / 100W Lampholder : E27 fixed Reflector

Alum.

Code No 211111

: 80ºC

Diffuser

: Frosted Glass

Temp

: 60W - 117ºC

96lx

Code No 211131

Alum.

Code No 211361

: Clear Glass

Temp

: 129ºC

HALOGEN PAR 30 75W Lampholder : E27 Adjustable ± 20º : -

Diffuser

: Clear Glass

Temp

: 129ºC

2400lx

67lx

96lx

150lx 266lx

231

Lampholder : E27 Loose : -

Diffuser

: Clear Glass

Temp

: 197ºC

Alum.

Code No 211141

4m 15º

600lx

2400lx

1m 30º

49lx

67lx

96lx

150lx 266lx

234,5

Ø 185

4m 15º

600lx

2400lx

1m 30º

2.5m 2.0m 1.5m 1.0m 0.5m

75W

Ø 208

2.5m 2.0m 1.5m 1.0m 0.5m

HALOGEN PAR 38 100W 30º

30º

49lx

75W

Reflector

2.5m 2.0m 1.5m 1.0m 0.5m

Alum.

4m 15º

600lx

75W

Ø 185

: -

Diffuser

Reflector

266lx

HALOGEN PAR 30 75W Reflector

67lx

150lx

100W - 170ºC

Lampholder : E27 fixed

49lx

231

ASSOS 6

RECESSED WALK OVER FIXTURES Class I IP67 IK10

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

METAL HALIDE

METAL HALIDE 70W Lampholder : Rx7s-24 Fixed Reflector

: 80ºC

Diffuser

: Clear Glass

Temp

: 115ºC

Ø 208

Alum.

Code No 212261

372

METAL HALIDE

METAL HALIDE CDMR 111 35W / 70W

Ø 208

Lampholder : Gx8.5 Fixed or Adjustable ± 15º Reflector

: -

Diffuser

: Clear Glass

Temp

: 166ºC

Alum.

375

METAL HALIDE 35W / 70W / 150W Lampholder : G12 Fixed or Adjustable ± 20º Reflector

: 30º, 42º

Diffuser

: Clear Glass

Temp

: 35W - 99ºC

Code No 211271

Alum.

Code No 211241

90º 125

75º

250 375 500

70W - 144ºC

625

150W - 238ºC

875

375 500

45º

625

750

30º

60º 45º

750 30º cd/km

70W

75º

250 60º

70W

875 42º

cd/km 30º

MILET

RECESSED WALK OVER FIXTURES Load 7.5 kN | IP67 IK10

The Milet Recessed series consists of a range of LED and halogen sources to deliver the desired light effect to facades, columns, bridges, monuments, and trees. The fixtures are made of a combination of a 316L stainless steel cover and die cast aluminium body painted with electrostatic powder paint. Tempered glass, silicone gaskets and cast resin complete the fixture to make it IP67 IK10 and withstand rough environments. For the LED versions, a specially developed potted power cable is used to effectively bond with the cast resin and stop any water ingress. For the halogen versions, a PG9 cable gland allows for a secure connection of the on-site cable. A polycarbonate recessing box is included for installation into concrete or the ground. The LEDs used come in 3 different tones of white, as well as blue, red, green, amber and RGB. Several lenses from 6 to 40 degrees are available to choose from to achieve the desired the light effect. Asymmetric LEDs In this catalogue EMFA is introducing the tilted LED fixtures. These fixtures give an asymmetrical light output to facades, columns, bridges, monuments, and trees without losing light to the sky. The die cast aluminium body has a fixed built in tilt to allow for proper heat dissipation of the LEDs that can run up to 350mA. Cover 316L Stainless Steel Body Die cast aluminium Recessing Box Polycarbonate Glands 1 x PG 9 Gaskets Silicone Diffusers 12 mm Tempered Glass

LEDs Only highest quality LEDs such as Cree or Toplite are used in production allowing for maximum lumen output and maximum lifetime. Most LEDs run on 350mA or 700mA depending on how much light output is required. The white color temperature binning is 200K at most, and always on the same x,y coordinates on the CIE diagram in accordance with Energy Star. This ensures consistent supply of the same color temperatture over time. As LEDs are constantly developing and becoming more efficient, lumen output given in this catalogue are current as of March 2020. At 2700K, 3000K, and 4000K LED lumen output per led is 110lm; at 6000K the lumen output per led is 125lm. Total Lighting Output as printed in this catalogue is the actual light output of the entire fixture. The minimum CRI of the LEDs used is 85 with a majority of products over 90. Thermal Management All fixtures are designed to withstand ambient temperatures of at least 50ºC. The LEDs are mounted on metal core pcbs, which are mounted to the aluminium body of the fixture so that the entire fixture acts as a heat sink. Extensive testing is performed in EMFA’s laboratory to ensure these values are maintained so that the lifetime of the LED is not compromised. “Customization” is EMFA’s standard EMFA offers many combinations for each fixture, as all fixtures are made in house. A combination of 2 finishes of stainless steel, 8 LED colors, and 5 or more lenses and reflectors are available to make the fixture suitable for the required application. This is done without increasing lead-time and is available for large as well as small quantities. AntiStheft Screws

MILET

RECESSED WALK OVER FIXTURES Load 7.5 kN | IP67 IK10

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

MILET 2

HALOGEN 12V 20-35W (10º or 38º) Lampholder : Gu4

Code No 316101

HALOGEN 240V 40W Lampholder : G9

Reflector

: -

Reflector

: 40º

Diffuser

: Clear Glass

Diffuser

: Frosted Glass

Class III

Code No 316121

136

Class I

HALOGEN 12V 35W (10º or 38º or 60º) Lampholder : Gu 5.3

Code No 316111

HALOGEN 240V 50W (25º or 50º) Lampholder : Gu10

Reflector

: -

Reflector

: -

Diffuser

: Clear Glass

Diffuser

: Clear Glass

Code No 316131

110

Recessing Tube

Class I

Class III

Ø 127 14

MILET 4

HALOGEN 12V 20-35W (10º or 38º) Lampholder : Gu4

Code No 317101

HALOGEN 240V 40W Lampholder : G9

Reflector

: -

Reflector

: 40º

Diffuser

: Clear Glass

Diffuser

: Frosted Glass

Class III

Class I

HALOGEN 12V 35W (10º or 38º or 60º) Code No 317111 Lampholder : Gu 5.3

HALOGEN 240V 50W (25º or 50º) Lampholder : Gu10

Reflector

Code No 317121

136

Ø 127

Diffuser Class III

: : Clear Glass

Diffuser

: : Clear Glass

Code No 317131

14 110

Recessing Tube

Class I 57

MILET

RECESSED WALK OVER FIXTURES Load 7.5 kN | IP67 IK10

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

MILET 4 FLUSH MOUNTED

HALOGEN 12V 20-35W (10º or 38º) Lampholder : Gu4

Code No 318101

Code No 318121

HALOGEN 240V 40W Lampholder : G9

Reflector

: -

Reflector

: 40º

Diffuser

: Clear Glass

Diffuser

: Frosted Glass

Class III

Class I

HALOGEN 12V 35W (10º or 38º or 60º) Code No 318111 Lampholder : Gu 5.3

HALOGEN 240V 50W (25º or 50º) Lampholder : Gu10

Reflector

: -

Reflector

: -

Diffuser

: Clear Glass

Diffuser

: Clear Glass

Class III

127

Code No 318131

Ø 127 19 85 80

Recessing Tube

Class I

MILET 5 STEP MOUNTED

MILET 5 FLUSH MOUNTED 10º

60º

HALOGEN 12V 20W (10º) Step Mounted

Code No 319101

136

80 50

Lampholder : Gu4 Reflector

: -

Diffuser

: Clear Glass

Ø 127 14

80 34

Class III HALOGEN 12V 20W (10º) Flush Mounted

Code No 319201

127

Lampholder : Gu4 Reflector

: -

Diffuser

: Clear Glass

Class III 58

Ø 127 19 50 80

MILET

RECESSED WALK OVER LED FIXTURES Load 7.5 kN | IP67 IK10

MILET 2 LED

4 x 350 mA (4W) LED Voltage

: 240V A.C with integrated driver (12V AC or DC, 24V AC or DC on request)

Lens

: 25º (10º, 15º, 40º, 6 x 25 elliptic on request)

Diffuser

: 8 mm Tempered Glass (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

Warm White Natural White Cool White Blue Red Amber Green

3000 K 4500 K 6000 K

Total Lighting Output 340 lm 340 lm 408 lm

136

Code No 425211 425216 425217 425212 425213 425214 425215

136

Ø 127 19 85 80

Recessing Box

MILET 4 LED

3 x 350 mA (3W) LED Voltage

: 240V A.C with integrated driver (12V AC or DC, 24V AC or DC on request)

Lens

: 25º (10º, 15º, 40º, 6 x 25 elliptic on request)

Diffuser

: 8 mm Tempered Glass (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

Warm White Natural White Cool White Blue Red Amber Green

3000 K 4500 K 6000 K

Total Lighting Output 225 lm 225 lm 270 lm

Code No 425201 425206 425207 425202 425203 425204 425205

136

Ø 127 19 85 80

Recessing Box

BELKIS

RECESSED FIXTURES IP67 IK10

The Belkis Recessed series consists of a range of LED, fluorescent and halogen sources to deliver the desired light effect to facades, columns, bridges, monuments, and trees. The fixtures are made of a combination of a 316L stainless steel cover and die cast aluminium body painted with electrostatic powder paint. Tempered glass, silicone gaskets and cast resin complete the fixture to make it IP67 IK10 and withstand rough environments. A specially developed potted power cable is used to effectively bond with the cast resin and stop any water ingress. The fixtures come with an aluminium recessing tube for easy mounting in the ground or concrete. The LEDs used come in 3 different tones of white, as well as blue, red, green, amber and RGB. Several lenses from 6 to 40 degrees are available to choose from to achieve the desired light effect. Asymmetrical LEDs These fixtures give an asymmetrical light output to facades, columns, bridges, monuments, and trees without losing light to the sky. The die cast aluminium body has a fixed built in tilt to allow for proper heat dissipation of the LEDs that can run up to 700mA. Cover 316L Stainless steel Body Die cast aluminium Recessing Box Aluminium Gaskets Silicone Diffusers Tempered Glass Screws 316L Stainless steel “Customization” is EMFA’s standard EMFA offers many combinations for each fixture, as all fixtures are made in house. A combination of 2 finishes of stainless steel, 8 LED colors, 2 wattages, and 5 or more lenses and reflectors are available to make the fixture suitable for the required application. This is done without increasing lead-time and is available for large as well as small quantities. Honeycomb Louvre Belkis 1 Belkis 2 Belkis 3 Belkis 4 Belkis 5

Code No 953521 953522 953523 953524 953525

BELKIS MINI

RECESSED LED FIXTURES Class I IP67 IK10

Symmetrical

1 x 350 mA (1 W) LED Warm White Natural White Cool White Blue Red Amber Green

3000 K 4500 K 6000 K

Total Lighting Output 85 lm 85 lm 102 lm

Code No 391001 391002 391003 391004 391005 391006 391007

Voltage

: 240V A.C with integrated driver (24V AC or DC on request)

Lens

: 10º, 25º, 40º

Diffuser

: Clear Glass with painted circumference 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

Ø 50

Ø 40

BELKIS 1

RECESSED LED FIXTURES Class I IP67 IK10

Symmetrical BELKIS 1 Fix to Recessing Tube with Silicone

1 x 350 mA (1 W) LED or 1 x 700 mA (3 W) LED

Warm White Natural White Cool White Blue Red Amber Green

Total Lighting Output 1W 3W 85 lm 225 lm 3000 K 85 lm 225 lm 4500 K 102 lm 270 lm 6000 K

1W Round 425191 425196 425197 425192 425193 425194 425195

1W Square 425291 425296 425297 425292 425293 425294 425295

3W Round 405501 405502 405503 405504 405505 405506 405507

3W Square 405511 405512 405513 405514 405515 405516 405517

Ø 70

101

Ø 66

Voltage

: 240V A.C with integrated driver

Lens

: 10º, 25º, 40º

Aluminum recessing tube

(24V AC or DC on request)

Diffuser

: Clear Glass with painted circumference 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

Symmetrical BELKIS 1 Fix to Recessing Tube with Screws

1 x 350 mA (1 W) LED or 1 x 700 mA (3 W) LED

Warm White Natural White Cool White Blue Red Amber Green

Total Lighting Output 1W 3W 85 lm 225 lm 3000 K 85 lm 225 lm 4500 K 102 lm 270 lm 6000 K

1W Round 425181 425186 425187 425182 425183 425184 425185

1W Square 425281 425286 425287 425282 425283 425284 425285

Voltage

: 240V A.C with integrated driver (24V AC or DC on request)

Lens

: 10º, 25º, 40º

3W Round 405521 405522 405523 405524 405525 405526 405527

3W Square 405531 405532 405533 405534 405535 405536 405537

Diffuser

: Clear Glass with painted circumference 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

Ø 95

101

Ø 66

Aluminum recessing tube

BELKIS 1

RECESSED LED FIXTURES Class I IP67 IK10

Asymmetrical 7° Tilted BELKIS 1 Fix to Recessing Tube with Silicone

7° Tilted 1 x 350 mA (1 W) LED or 1 x 700 mA (3 W) LED

Warm White Natural White Cool White Blue Red Amber Green

Total Lighting Output 1W 3W 85 lm 225 lm 3000 K 85 lm 225 lm 4500 K 102 lm 270 lm 6000 K

1W Round 405541 405542 405543 405544 405545 405546 405547

1W Square 405551 405552 405553 405554 405555 405556 405557

3W Round 405581 405582 405583 405584 405585 405586 405587

3W Square 405591 405592 405593 405594 405595 405596 405597

Ø 70

7° 75

101

Ø 66

Voltage

: 240V A.C with integrated driver (24V AC or DC on request)

Lens

: 10º, 25º, 40º

Aluminum recessing tube

Diffuser

: Clear Glass with painted circumference 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

Asymmetrical 7° Tilted BELKIS 1 Fix to Recessing Tube with Screws

7° Tilted 1 x 350 mA (1 W) LED or 1 x 700 mA (3 W) LED

Warm White Natural White Cool White Blue Red Amber Green

Total Lighting Output 1W 3W 85 lm 225 lm 3000 K 85 lm 225 lm 4500 K 102 lm 270 lm 6000 K

1W Round 405561 405562 405563 405564 405565 405566 405567

1W Square 405571 405572 405573 405574 405575 405576 405577

Voltage

: 240V A.C with integrated driver (24V AC or DC on request)

Lens

: 10º, 25º, 40º

3W Round 405601 405602 405603 405604 405605 405606 405607

3W Square 405611 405612 405613 405614 405615 405616 405617

Diffuser

: Clear Glass with painted circumference 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

Ø 95

7° 75

101

Ø 66

Aluminum recessing tube

BELKIS 1

RECESSED HALOGEN FIXTURES Load 5 kN | Class III IP67 IK10

Symmetrical BELKIS 1 Fix to Recessing Tube with Silicone

HALOGEN 12V 20W (10º or 38º) Lampholder : Gu4 Reflector

: -

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Code No Round Square 320101 320201

Ø 70

Transformer is not included. Remote transformer should be used.

100

Ø 60

Aluminum recessing tube

Symmetrical BELKIS 1 Fix to Recessing Tube with Screws

HALOGEN 12V 20W (10º or 38º) Lampholder : Gu4 Reflector

: -

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Code No Round Square 320111 320211

Ø 95

Transformer is not included. Remote transformer should be used. 101

Ø 66

Aluminum recessing tube

BELKIS 2

RECESSED RGB LED FIXTURES Class I IP67 IK10

Symmetrical BELKIS 2 Fix to Recessing Tube with Silicone

3 x 350 mA (3 W) LED or 3 x 700 mA (9 W) LED

Warm White Natural White Cool White Blue Red Amber Green

Total Lighting Output 3W 9W 255 lm 675 lm 3000 K 255 lm 675 lm 4500 K 306 lm 810 lm 6000 K

3W Round 422101 422106 422107 422102 422103 422104 422105

3W Square 422111 422116 422117 422112 422113 422114 422115

Voltage

: 240V A.C with integrated driver (24V AC or DC on request)

Lens

: 10º, 25º, 40º

9W Round 418331 418332 418333 418334 418335 418336 418337

9W Square 418341 418342 418343 418344 418345 418346 418347

Ø 90

60 101

Ø 84

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

Aluminum recessing tube

Symmetrical BELKIS 2 Fix to Recessing Tube with Screws

3 x 350 mA (3 W) LED or 3 x 700 mA (9 W) LED

Warm White Natural White Cool White Blue Red Amber Green

Total Lighting Output 3W 9W 255 lm 675 lm 3000 K 255 lm 675 lm 4500 K 306 lm 810 lm 6000 K

115

3W Round 425161 425166 425167 425162 425163 425164 425165

3W Square 425261 425266 425267 425262 425263 425264 425265

Voltage

: 240V A.C with integrated driver (24V AC or DC on request)

Lens

: 10º, 25º, 40º

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

9W Round 418351 418352 418353 418354 418355 418356 418357

9W Square 418361 418362 418363 418364 418365 418366 418367

Ø 115

115

60 101

Ø 84

Aluminum recessing tube

BELKIS 2

RECESSED LED WITH TIR LENS FIXTURES Class I IP67 IK10

Symmetrical BELKIS 2 Fix to Recessing Tube with Silicone

1 x 350 mA (3 W) LED or 1 x 350 mA (11 W) LED

Warm White Natural White Voltage

Total Lighting Output 3W 11W 3000 K 198 lm 655 lm 4000 K 237 lm 786 lm

3W Round 119001 119002

3W Square 119011 119012

11W Round 119021 119022

11W Square 119031 119032

Ø 90

: 240V A.C with integrated driver (24V AC or DC on request)

60 101

Lens

: 10º, 20º, 30º Mirror TIR Lens

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F Ø 84

Aluminum recessing tube

Symmetrical BELKIS 2 Fix to Recessing Tube with Screws

1 x 350 mA (3 W) LED or 1 x 350 mA (11 W) LED

Warm White Natural White Voltage

Total Lighting Output 3W 11W 3000 K 198 lm 655 lm 4000 K 237 lm 786 lm

3W Round 119101 119102

115

3W Square 119111 119112

11W Round 119121 119122

11W Square 119131 119132

Ø 115

115

: 240V A.C with integrated driver (24V AC or DC on request)

Lens

: 10º, 20º, 30º Mirror TIR Lens

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

60 101

Ø 84

Aluminum recessing tube

BELKIS 2

RECESSED RGB LED FIXTURES Class I IP67 IK10

Symmetrical BELKIS 2 Fix to Recessing Tube with Silicone

9 x 350 mA (9 W) RGB LED Voltage

: 240V A.C with remote driver

Lens

: 25º or 40º

Diffuser

: Clear Glass

Ø 90

8 mm (Frosted Glass on request) Cable

: Potted 10 m 4x0,75 H03 VV-F 60

Control by DMX, remote control, or push button

101

Code No Round Square 418371 418381

Ø 84

Aluminum recessing tube

Symmetrical BELKIS 2 Fix to Recessing Tube with Screws

115

9 x 350 mA (9 W) RGB LED Voltage

: 240V A.C with remote driver

Lens

: 25º or 40º

Diffuser

: Clear Glass

Cable

: Potted 10 m 4x0,75 H03 VV-F

Ø 115

115

8 mm (Frosted Glass on request) Control by DMX, remote control, or push button

60 101

Code No Round Square 425411 425421 Ø 84

Aluminum recessing tube

BELKIS 2

RECESSED LED FIXTURES Class I IP67 IK10

Asymmetrical Wallwasher BELKIS 2 Fix to Recessing Tube with Silicone

1 x 350 mA (1 W) LED or 1 x 700 mA (3 W) LED

Warm White Natural White Cool White Blue Red Amber Green

Total Lighting Output 1W 3W 210 lm 89 lm 3000 K 210 lm 89 lm 4500 K 230 lm 101 lm 6000 K

1W Round 326001 326002 326003 326004 326005 326006 326007

1W Square 326011 326012 326013 326014 326015 326016 326017

Voltage

: 240V A.C with integrated driver (24V AC or DC on request)

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

3W Round 326041 326042 326043 326044 326045 326046 326047

3W Square 326051 326052 326053 326054 326055 326056 326057

Ø 90

60 101

Ø 84

Aluminum recessing tube

Asymmetrical Wallwasher BELKIS 2 Fix to Recessing Tube with Screws

1 x 350 mA (3 W) LED or 1 x 700 mA (3 W) LED

Warm White Natural White Cool White Blue Red Amber Green

Total Lighting Output 1W 3W 210 lm 89 lm 3000 K 210 lm 89 lm 4500 K 230 lm 101 lm 6000 K

115

1W Round 326021 326022 326023 326024 326025 326026 326027

1W Square 326031 326032 326033 326034 326035 326036 326037

Voltage

: 240V A.C with integrated driver (24V AC or DC on request)

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

3W Round 326061 326062 326063 326064 326065 326066 326067

3W Square 326071 326072 326073 326074 326075 326076 326077

Ø 115

115

60 101

Ø 84

Aluminum recessing tube

BELKIS 2

RECESSED LED FIXTURES Class I IP67 IK10

Asymmetrical 7° Tilted BELKIS 2 Fix to Recessing Tube with Silicone

7° Tilted 3 x 350 mA (3 W) LED or 3 x 700 mA (9 W) LED

Warm White Natural White Cool White Blue Red Amber Green

Total Lighting Output 3W 9W 255 lm 675 lm 3000 K 255 lm 675 lm 4500 K 306 lm 810 lm 6000 K

3W Round 418391 418392 418393 418394 418395 418396 418397

3W Square 418401 418402 418403 418404 418405 418406 418407

Voltage

: 240V A.C with integrated driver (24V AC or DC on request)

Lens

: 10º, 25º, 40º

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

9W Round 418431 418432 418433 418434 418435 418436 418437

9W Square 418441 418442 418443 418444 418445 418446 418447

Ø 90

7° 60 101

Ø 84

Aluminum recessing tube

Asymmetrical 7° Tilted BELKIS 2 Fix to Recessing Tube with Screws

7° Tilted 3 x 350 mA (3 W) LED or 3 x 700 mA (9 W) LED

Warm White Natural White Cool White Blue Red Amber Green

Total Lighting Output 3W 9W 255 lm 675 lm 3000 K 255 lm 675 lm 4500 K 306 lm 810 lm 6000 K

115

3W Round 418411 418412 418413 418414 418415 418416 418417

3W Square 418421 418422 418423 418424 418425 418426 418427

Voltage

: 240V A.C with integrated driver (24V AC or DC on request)

Lens

: 10º, 25º, 40º

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

9W Round 418451 418452 418453 418454 418455 418456 418457

9W Square 418461 418462 418463 418464 418465 418466 418467

Ø 115

115

60 101

Ø 84

Aluminum recessing tube

BELKIS 2

RECESSED RGB LED FIXTURES Class I IP67 IK10

Asymmetrical 7° Tilted BELKIS 2 Fix to Recessing Tube with Silicone

7° Tilted 90

9 x 350 mA (9 W) RGB LED Voltage

: 240V A.C with remote driver

Lens

: 25º or 40º

Diffuser

: Clear Glass

Ø 90

8 mm (Frosted Glass on request) Cable

: Potted 10 m 4x0,75 H03 VV-F

7° 60

Control by DMX, remote control, or push button

101

Code No Round Square 417471 418481 Ø 84

Aluminum recessing tube Asymmetrical 7° Tilted BELKIS 2 Fix to Recessing Tube with Screws

7° Tilted 115

9 x 350 mA (9 W) RGB LED Voltage

: 240V A.C with remote driver

Lens

: 25º or 40º

Diffuser

: Clear Glass

Cable

: Potted 10 m 4x0,75 H03 VV-F

Ø 115

115

8 mm (Frosted Glass on request) Control by DMX, remote control, or push button

60 101

Code No Round Square 418491 418501 Ø 84

Aluminum recessing tube

BELKIS 2

RECESSED LED FIXTURES Class I IP67 IK10

Asymmetrical 15° Tilted BELKIS 2 Fix to Recessing Tube with Silicone

15° Tilted 3 x 350 mA (3 W) LED or 3 x 700 mA (9 W) LED

Warm White Natural White Cool White Blue Red Amber Green

Total Lighting Output 3W 9W 255 lm 675 lm 3000 K 255 lm 675 lm 4500 K 306 lm 810 lm 6000 K

115

3W Round 418511 418512 418513 418514 418515 418516 418517

3W Square 418521 418522 418523 418524 418525 418526 418527

Voltage

: 240V A.C with integrated driver (24V AC or DC on request)

Lens

: 10º, 25º, 40º

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

9W Round 418551 418552 418553 418554 418555 418556 418557

9W Square 418561 418562 418563 418564 418565 418566 418567

Ø 115

115

15° 73

101

Ø 108

Aluminum recessing tube

Asymmetrical 15° Tilted BELKIS 2 Fix to Recessing Tube with Screws

15° Tilted 3 x 350 mA (3 W) LED or 3 x 700 mA (9 W) LED

Warm White Natural White Cool White Blue Red Amber Green

Total Lighting Output 3W 9W 255 lm 675 lm 3000 K 255 lm 675 lm 4500 K 306 lm 810 lm 6000 K

140

3W Round 418531 418532 418533 418534 418535 418536 418537

3W Square 418541 418542 418543 418544 418545 418546 418547

Voltage

: 240V A.C with integrated driver (24V AC or DC on request)

Lens

: 10º, 25º, 40º

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

9W Round 418571 418572 418573 418574 418575 418576 418577

9W Square 418581 418582 418583 418584 418585 418586 418587

Ø 140

140

15° 73

101

Ø 108

Aluminum recessing tube

BELKIS 2

RECESSED LED WITH TIR LENS FIXTURES Class I IP67 IK10

Asymmetrical 15° Tilted BELKIS 2 Fix to Recessing Tube with Silicone

15°Tilted 115

1 x 350 mA (11 W) LED or 1 x 500 mA (18 W) LED

Warm White Natural White Voltage

Total Lighting Output 11W 18W 3000 K 655 lm 1153 lm 4000 K 786 lm 1383 lm

11W Round 119201 119202

11W Square 119211 119212

18W Round 119221 119222

18W Square 119231 119232

Ø 115

115

: 240V A.C with integrated driver

15°

(24V AC or DC on request)

101

Lens

: 10º, 20º, 30º Mirror TIR Lens

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

Ø 108

Aluminum recessing tube

Asymmetrical 15° Tilted BELKIS 2 Fix to Recessing Tube with Screws

15°Tilted 140

1 x 350 mA (11 W) LED or 1 x 500 mA (18 W) LED

Warm White Natural White Voltage

Total Lighting Output 11W 18W 3000 K 655 lm 1153 lm 4000 K 786 lm 1383 lm

11W Round 119301 119302

11W Square 119311 119312

18W Round 119321 119322

18W Square 119331 119332

Ø 140

140

: 240V A.C with integrated driver (24V AC or DC on request)

Lens

: 10º, 20º, 30º Mirror TIR Lens

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

15° 73

101

Ø 108

Aluminum recessing tube

BELKIS 2

RECESSED RGB LED FIXTURES Class I IP67 IK10

Asymmetrical 15° Tilted BELKIS 2 Fix to Recessing Tube with Silicone

15° Tilted 115

9 x 350 mA (9 W) RGB LED Voltage

: 240V A.C with remote driver

Lens

: 25º or 40º

Diffuser

: Clear Glass

Ø 115

115

8 mm (Frosted Glass on request) Cable

: Potted 10 m 4x0,75 H03 VV-F

15°

Control by DMX, remote control, or push button

101

Code No Round Square 418591 418601

Ø 108

Aluminum recessing tube

Asymmetrical 15° Tilted BELKIS 2 Fix to Recessing Tube with Screws

15° Tilted 140

9 x 350 mA (9 W) RGB LED Voltage

: 240V A.C with remote driver

Lens

: 25º or 40º

Diffuser

: Clear Glass

Cable

: Potted 10 m 4x0,75 H03 VV-F

Ø 140

140

8 mm (Frosted Glass on request) Control by DMX, remote control, or push button

15° 73

101

Code No Round Square 418611 418621

Ø 108

Aluminum recessing tube

BELKIS 2

RECESSED LED FIXTURES Class I IP67 IK10

Asymmetrical 25° Tilted BELKIS 2 Fix to Recessing Tube with Silicone

25° Tilted 3 x 350 mA (3 W) LED or 3 x 700 mA (9 W) LED

Warm White Natural White Cool White Blue Red Amber Green

Total Lighting Output 3W 9W 255 lm 675 lm 3000 K 255 lm 675 lm 4500 K 306 lm 810 lm 6000 K

115

3W Round 418631 418632 418633 418634 418635 418636 418637

3W Square 418641 418642 418643 418644 418645 418646 418647

Voltage

: 240V A.C with integrated driver (24V AC or DC on request)

Lens

: 10º, 25º, 40º

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

9W Round 418671 418672 418673 418674 418675 418676 418677

9W Square 418681 418682 418683 418684 418685 418686 418687

Ø 115

115

25° 73

101

Ø 108

Aluminum recessing tube

Asymmetrical 25° Tilted BELKIS 2 Fix to Recessing Tube with Screws

25° Tilted 3 x 350 mA (3 W) LED or 3 x 700 mA (9 W) LED

Warm White Natural White Cool White Blue Red Amber Green

Total Lighting Output 3W 9W 255 lm 675 lm 3000 K 255 lm 675 lm 4500 K 306 lm 810 lm 6000 K

140

3W Round 418651 418652 418653 418654 418655 418656 418657

3W Square 418661 418662 418663 418664 418665 418666 418667

Voltage

: 240V A.C with integrated driver (24V AC or DC on request)

Lens

: 10º, 25º, 40º

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

9W Round 418691 418692 418693 418694 418695 418696 418697

9W Square 418701 418702 418703 418704 418705 418706 418707

Ø 140

140

25° 73

101

Ø 108

Aluminum recessing tube

BELKIS 2

RECESSED LED WITH TIR LENS FIXTURES Class I IP67 IK10

Asymmetrical 25° Tilted BELKIS 2 Fix to Recessing Tube with Silicone

25°Tilted 115

1 x 350 mA (11 W) LED or 1 x 500 mA (18 W) LED

Warm White Natural White Voltage

Total Lighting Output 11W 18W 3000 K 655 lm 1153 lm 4000 K 786 lm 1383 lm

11W Round 119401 119402

11W Square 119411 119412

18W Round 119421 119422

18W Square 119431 119432

Ø 115

115

: 240V A.C with integrated driver

25°

(24V AC or DC on request)

101

Lens

: 10º, 20º, 30º Mirror TIR Lens

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

Ø 108

Aluminum recessing tube

Asymmetrical 25° Tilted BELKIS 2 Fix to Recessing Tube with Screws

25°Tilted 1 x 350 mA (11 W) LED or 1 x 500 mA (18 W) LED

Warm White Natural White Voltage

Total Lighting Output 11W 18W 3000 K 655 lm 1153 lm 4000 K 786 lm 1383 lm

11W Round 119501 119502

140

11W Square 119511 119512

18W Round 119521 119522

18W Square 119531 119532

Ø 140

140

: 240V A.C with integrated driver (24V AC or DC on request)

Lens

: 10º, 20º, 30º Mirror TIR Lens

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

25° 73

101

Ø 108

Aluminum recessing tube

BELKIS 2

RECESSED RGB LED FIXTURES Class I IP67 IK10

Asymmetrical 25° Tilted BELKIS 2 Fix to Recessing Tube with Silicone

25° Tilted 115

9 x 350 mA (9 W) RGB LED Voltage

: 240V A.C with remote driver

Lens

: 25º or 40º

Diffuser

: Clear Glass

Ø 115

115

8 mm (Frosted Glass on request) Cable

: Potted 10 m 4x0,75 H03 VV-F

25°

Control by DMX, remote control, or push button

101

Code No Round Square 418711 418721

Ø 108

Aluminum recessing tube

Asymmetrical 25° Tilted BELKIS 2 Fix to Recessing Tube with Screws

25° Tilted 140

9 x 350 mA (9 W) RGB LED Voltage

: 240V A.C with remote driver

Lens

: 25º or 40º

Diffuser

: Clear Glass

Cable

: Potted 10 m 4x0,75 H03 VV-F

Ø 140

140

8 mm (Frosted Glass on request) Control by DMX, remote control, or push button

25° 73

101

Code No Round Square 418731 418741

Ø 108

Aluminum recessing tube

BELKIS 2

RECESSED HALOGEN FIXTURES Load 1.5 kN | Class III IP67 IK10

Symmetrical BELKIS 2 Fix to Recessing Tube with Silicone

HALOGEN 12V 35W / 50W (10º or 38º) Lampholder : Gu 5.3 Reflector

: -

Diffuser

: 8 mm Tempered Glass

Code No Round Square 322101 322201

Ø 90

Transformer is not included. Remote transformer should be used. CLASS III

120

Aluminum recessing tube

Symmetrical BELKIS 2 Fix to Recessing Tube with Screws

HALOGEN 240V 35W / 50W (25º or 50º) Lampholder : Gu10 Reflector

: -

Diffuser

: 8 mm Tempered Glass

115

Code No Round Square 322121 322221

Ø 115

115

CLASS I

101

Ø 84

Aluminum recessing tube

BELKIS 3

RECESSED LED FIXTURES Load 5 kN | Class I IP67 IK10

Symmetrical BELKIS 3 Fix to Recessing Tube with Silicone

6 x 350 mA (6 W) LED Warm White Natural White Cool White Blue Red Amber Green

3000 K 4500 K 6000 K

Total Lighting Output 510 lm 510 lm 612 lm

115

Code No Round Square 422201 422211 422202 422216 422203 422217 422204 422212 422205 422213 422206 422214 422207 422215

Voltage

: 240V A.C with integrated driver (24V AC or DC on request)

Lens

: 10º, 25º, 40º

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

115

Ø 115

101

Ø 108

Aluminum recessing tube

Symmetrical BELKIS 3 Fix to Recessing Tube with Screws

6 x 350 mA (6 W) LED Warm White Natural White Cool White Blue Red Amber Green

3000 K 4500 K 6000 K

Total Lighting Output 510 lm 510 lm 612 lm

140

Code No Round Square 422221 422226 422227 422222 422223 422224 422225

422231 422236 422237 422232 422233 422234 422235

Voltage

: 240V A.C with integrated driver (24V AC or DC on request)

Lens

: 10º, 25º, 40º

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

Ø 140

140

58 101

Ø 108

Aluminum recessing tube

BELKIS 3

RECESSED LED WITH TIR LENS FIXTURES Class I IP67 IK10

Symmetrical BELKIS 3 Fix to Recessing Tube with Silicone

1 x 350 mA (11 W) LED

Warm White Natural White Voltage

Total Lighting Output 11W 3000 K 784 lm 4000 K 941 lm

115

11W Round 119601 119602

11W Square 119611 119612

115

Ø 115

: 240V A.C with integrated driver (24V AC or DC on request)

Lens

: 10º, 20º, 30º Mirror TIR Lens

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

101

Ø 108

Aluminum recessing tube

Symmetrical BELKIS 3 Fix to Recessing Tube with Screws

140

1 x 350 mA (11 W) LED

Warm White Natural White Voltage

Total Lighting Output 11W 3000 K 784 lm 4000 K 941 lm

11W Round 119701 119702

11W Square 119711 119712

Ø 140

140

: 240V A.C with integrated driver (24V AC or DC on request)

Lens

: 10º, 20º, 30º Mirror TIR Lens

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

58 101

Ø 108

Aluminum recessing tube

BELKIS 3

RECESSED RGB LED FIXTURES Class I IP67 IK10

Symmetrical BELKIS 3 Fix to Recessing Tube with Silicone

115

18 x 350 mA (18 W) RGB LED Voltage

: 240V A.C with remote driver

Lens

: 25º or 40º

Diffuser

: Clear Glass

115

Ø 115

8 mm (Frosted Glass on request) Cable

: Potted 10 m 4x0,75 H03 VV-F

Control by DMX, remote control, or push button

101

Code No Round Square Ø 108

422261 422271

Aluminum recessing tube

Symmetrical BELKIS 3 Fix to Recessing Tube with Screws

140

18 x 350 mA (18 W) RGB LED Voltage

: 240V A.C with remote driver

Lens

: 25º or 40º

Diffuser

: Clear Glass

Cable

: Potted 10 m 4x0,75 H03 VV-F

Ø 140

140

8 mm (Frosted Glass on request) Control by DMX, remote control, or push button

58 101

Code No Round Square 422241 422251

Ø 108

Aluminum recessing tube

BELKIS 3

RECESSED UPLIGHT LOW GLARE LED FIXTURES Class I IP67 IK10

Symmetrical BELKIS 3 Fix to Recessing Tube with Silicone

22,5

(LEDs placed deep inside the fixture)

6 x 350 mA (6 W) LED Warm White Natural White Cool White Blue Red Amber Green

3000 K 4500 K 6000 K

Total Lighting Output 510 lm 510 lm 612 lm

115

Code No Round Square 326101 326111 326102 326112 326103 326113 326104 326114 326105 326115 326106 326116 326107 326117

Voltage

: 240V A.C with integrated driver (24V AC or DC on request)

Lens

: 10º, 25º, 40º

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

115

Ø 115

22,5 101

Ø 108

Aluminum recessing tube

Symmetrical BELKIS 3 Fix to Recessing Tube with Screws

22,5

(LEDs placed deep inside the fixture)

6 x 350 mA (6 W) LED Warm White Natural White Cool White Blue Red Amber Green

3000 K 4500 K 6000 K

Total Lighting Output 510 lm 510 lm 612 lm

140

Code No Round Square 326121 326122 326123 326124 326125 326126 326127

326131 326132 326133 326134 326135 326136 326137

Voltage

: 240V A.C with integrated driver (24V AC or DC on request)

Lens

: 10º, 25º, 40º

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

Ø 140

140

22,5 101

Ø 108

Aluminum recessing tube

BELKIS 3

RECESSED LED FIXTURES Class I IP67 IK10

Asymmetrical 15° Tilted BELKIS 3 Fix to Recessing Tube with Silicone

15°Tilted 6 x 350 mA (6 W) LED Warm White Natural White Cool White Blue Red Amber Green

3000 K 4500 K 6000 K

Total Lighting Output 510 lm 510 lm 612 lm

115

Code No Round Square 423101 423111 423102 423112 423103 423113 423104 423114 423105 423115 423106 423116 423107 423117

Voltage

: 240V A.C with integrated driver (24V AC or DC on request)

Lens

: 10º, 25º, 40º

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

Ø 115

115

15° 73

101

Ø 108

Aluminum recessing tube

Available with springs for false ceiling. Asymmetrical 15° Tilted BELKIS 3 Fix to Recessing Tube with Screws

15°Tilted 6 x 350 mA (6 W) LED Warm White Natural White Cool White Blue Red Amber Green

3000 K 4500 K 6000 K

Total Lighting Output 510 lm 510 lm 612 lm

140

Code No Round Square 423121 423122 423123 423124 423125 423126 423127

423131 423132 423133 423134 423135 423136 423137

Voltage

: 240V A.C with integrated driver (24V AC or DC on request)

Lens

: 10º, 25º, 40º

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

Available with springs for false ceiling. 84

Ø 140

140

15° 73

101

Ø 108

Aluminum recessing tube

BELKIS 3

RECESSED LED WITH TIR LENS FIXTURES Class I IP67 IK10

Asymmetrical 15° Tilted BELKIS 3 Fix to Recessing Tube with Silicone

15°Tilted 1 x 500 mA (18 W) LED or 1 x 700 mA (25 W) LED

Warm White Natural White Voltage

Total Lighting Output 18W 25W 3000 K 1170 lm 1620 lm 4000 K 1404 lm 1945 lm

18W Round 119801 119802

135

18W Square 119811 119812

25W Round 119821 119822

25W Square 119831 119832

Ø 135

135

: 240V A.C with integrated driver (24V AC or DC on request)

15°

Lens

: 10º, 20º, 30º Mirror TIR Lens

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

135

Ø 126

Aluminum recessing tube

Asymmetrical 15° Tilted BELKIS 3 Fix to Recessing Tube with Screws

15°Tilted 1 x 500 mA (18 W) LED or 1 x 700 mA (25 W) LED

Warm White Natural White

Total Lighting Output 18W 25W 3000 K 1170 lm 1620 lm 4000 K 1404 lm 1945 lm

Voltage

: 240V A.C with integrated driver

Lens

: 10º, 20º, 30º Mirror TIR Lens

18W Round 119901 119902

160

18W Square 119911 119912

25W Round 119921 119922

25W Square 119931 119932

160

Ø 160

(24V AC or DC on request) Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

15° 90

115

Ø 126

Aluminum recessing tube

BELKIS 3

RECESSED RGB LED FIXTURES Class I IP67 IK10

Asymmetrical 15° Tilted BELKIS 3 Fix to Recessing Tube with Silicone

15°Tilted 135

18 x 350 mA (18 W) RGB LED Voltage

: 240V A.C with remote driver

Lens

: 25º or 40º

Diffuser

: Clear Glass

Ø 135

135

8 mm (Frosted Glass on request) Cable

: Potted 10 m 4x0,75 H03 VV-F

Control by DMX, remote control, or push button

15° 90

135

Code No Round Square 423141 423151

Ø 126

Aluminum recessing tube

Asymmetrical 15° Tilted BELKIS 3 Fix to Recessing Tube with Screws

15°Tilted 160

18 x 350 mA (18 W) RGB LED Voltage

: 240V A.C with remote driver

Lens

: 25º or 40º

Diffuser

: Clear Glass

Cable

: Potted 10 m 4x0,75 H03 VV-F

160

Ø 160

8 mm (Frosted Glass on request) Control by DMX, remote control, or push button Code No Round Square

15° 90

115

423161 423171 Ø 126

Aluminum recessing tube

BELKIS 3

RECESSED LED FIXTURES Class I IP67 IK10

Asymmetrical 25° Tilted BELKIS 3 Fix to Recessing Tube with Silicone

25°Tilted 6 x 350 mA (6 W) LED Warm White Natural White Cool White Blue Red Amber Green

3000 K 4500 K 6000 K

Total Lighting Output 510 lm 510 lm 612 lm

Code No Round Square 423181 423191 423182 423192 423183 423193 423184 423194 423185 423195 423186 423196 423187 423197

Voltage

: 240V A.C with integrated driver (24V AC or DC on request)

Lens

: 10º, 25º, 40º

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

135

Ø 135

135

25° 90

135

Ø 126

Aluminum recessing tube

Available with springs for false ceiling. Asymmetrical 25° Tilted BELKIS 3 Fix to Recessing Tube with Screws

25°Tilted 6 x 350 mA (6 W) LED Warm White Natural White Cool White Blue Red Amber Green

3000 K 4500 K 6000 K

Total Lighting Output 510 lm 510 lm 612 lm

160

Code No Round Square 423201 423202 423203 423204 423205 423206 423207

423211 423212 423213 423214 423215 423216 423217

Voltage

: 240V A.C with integrated driver (24V AC or DC on request)

Lens

: 10º, 25º, 40º

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

160

Ø 160

25° 90

115

Ø 126

Aluminum recessing tube

Available with springs for false ceiling. 87

BELKIS 3

RECESSED LED WITH TIR LENS FIXTURES Class I IP67 IK10

Asymmetrical 25° Tilted BELKIS 3 Fix to Recessing Tube with Silicone

25°Tilted 1 x 500 mA (18 W) LED or 1 x 700 mA (25 W) LED

Warm White Natural White Voltage

Total Lighting Output 18W 25W 3000 K 1170 lm 1620 lm 4000 K 1404 lm 1945 lm

18W Round 120001 120002

135

18W Square 120011 120012

25W Round 120021 120022

25W Square 120031 120032

Ø 135

135

: 240V A.C with integrated driver (24V AC or DC on request)

25°

Lens

: 10º, 20º, 30º Mirror TIR Lens

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

135

Ø 126

Aluminum recessing tube

Asymmetrical 25° Tilted BELKIS 3 Fix to Recessing Tube with Screws

25°Tilted 1 x 500 mA (18 W) LED or 1 x 700 mA (25 W) LED

Warm White Natural White

Total Lighting Output 18W 25W 3000 K 1170 lm 1620 lm 4000 K 1404 lm 1945 lm

Voltage

: 240V A.C with integrated driver

Lens

: 10º, 20º, 30º Mirror TIR Lens

18W Round 120101 120102

160

18W Square 120111 120112

25W Round 120121 120122

25W Square 120131 120132

160

Ø 160

(24V AC or DC on request) Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

25° 90

115

Ø 126

Aluminum recessing tube

BELKIS 3

RECESSED RGB LED FIXTURES Class I IP67 IK10

Asymmetrical 25° Tilted BELKIS 3 Fix to Recessing Tube with Silicone

25°Tilted 135

18 x 350 mA (18 W) RGB LED Voltage

: 240V A.C with remote driver

Lens

: 25º or 40º

Diffuser

: Clear Glass

Ø 135

135

8 mm (Frosted Glass on request) Cable

: Potted 10 m 4x0,75 H03 VV-F

Control by DMX, remote control, or push button

25° 90

135

Code No Round Square 423221 423231

Ø 126

Aluminum recessing tube

Asymmetrical 25° Tilted BELKIS 3 Fix to Recessing Tube with Screws

25°Tilted 160

18 x 350 mA (18 W) RGB LED Voltage

: 240V A.C with remote driver

Lens

: 25º or 40º

Diffuser

: Clear Glass

Cable

: Potted 10 m 4x0,75 H03 VV-F

160

Ø 160

8 mm (Frosted Glass on request) Control by DMX, remote control, or push button Code No Round Square

25° 90

115

423241 423251 Ø 126

Aluminum recessing tube

BELKIS 4

RECESSED LED FIXTURES Class I IP67 IK10

Symmetrical BELKIS 4 Fix to Recessing Tube with Silicone

9 x 350 mA (9 W) LED Warm White Natural White Cool White Blue Red Amber Green

3000 K 4500 K 6000 K

Total Lighting Output 765 lm 765 lm 918 lm

Code No Round Square 422301 422311 422306 422316 422307 422317 422302 422312 422303 422313 422304 422314 422305 422315

Voltage

: 240V A.C with integrated driver (24V AC or DC on request)

Lens

: 10º, 25º, 40º

135

Ø 135

101

Ø 126

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

Aluminum recessing tube

Symmetrical BELKIS 4 Fix to Recessing Tube with Screws

9 x 350 mA (9 W) LED Warm White Natural White Cool White Blue Red Amber Green

3000 K 4500 K 6000 K

Total Lighting Output 765 lm 765 lm 918 lm

422321 422326 422327 422322 422323 422324 422325

422331 422336 422337 422332 422333 422334 422335

Voltage

: 240V A.C with integrated driver (24V AC or DC on request)

Lens

: 10º, 25º, 40º

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

160

Code No Round Square

160

Ø 160

65 101

Ø 126

Aluminum recessing tube

BELKIS 4

RECESSED LED WITH TIR LENS FIXTURES Class I IP67 IK10

Symmetrical BELKIS 4 Fix to Recessing Tube with Silicone

1 x 500 mA (18 W) LED or 1 x 700 mA (25 W) LED

Warm White Natural White Voltage

Total Lighting Output 18W 25W 3000 K 1170 lm 1620 lm 4000 K 1404 lm 1945 lm

13W Round 120201 120202

135

13W Square 120211 120212

25W Round 120221 120222

25W Square 120231 120232

Ø 135

135

: 240V A.C with integrated driver (24V AC or DC on request)

Lens

: 10º, 20º, 30º Mirror TIR Lens

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

101

Ø 126

Aluminum recessing tube

Symmetrical BELKIS 4 Fix to Recessing Tube with Screws

1 x 500 mA (18 W) LED or 1 x 700 mA (25 W) LED

Warm White Natural White

Total Lighting Output 18W 25W 3000 K 1170 lm 1620 lm 4000 K 1404 lm 1945 lm

Voltage

: 240V A.C with integrated driver

Lens

: 10º, 20º, 30º Mirror TIR Lens

13W Round 120301 120302

160

13W Square 120311 120312

25W Round 120321 120322

25W Square 120331 120332

160

Ø 160

(24V AC or DC on request) Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

101

Ø 126

Aluminum recessing tube

BELKIS 4

RECESSED UPLIGHT LOW GLARE LED FIXTURES Class I IP67 IK10

Symmetrical BELKIS 4 Fix to Recessing Tube with Silicone

32,5

(Leds places deep inside the fixtures)

6 x 350 mA (6 W) LED Warm White Natural White Cool White Blue Red Amber Green

3000 K 4500 K 6000 K

Total Lighting Output 510 lm 510 lm 612 lm

135

Code No Round Square 326201 326211 326202 326212 326203 326213 326204 326214 326205 326215 326206 326216 326207 326217

Voltage

: 240V A.C with integrated driver (24V AC or DC on request)

Lens

: 10º, 25º, 40º

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

Ø 135

135

32,5

115

Ø 126

Aluminum recessing tube

Symmetrical BELKIS 4 Fix to Recessing Tube with Screws

32,5

(Leds places deep inside the fixtures)

6 x 350 mA (6 W) LED Warm White Natural White Cool White Blue Red Amber Green

3000 K 4500 K 6000 K

Total Lighting Output 510 lm 510 lm 612 lm

160

Code No Round Square 326221 326231 326222 326232 326223 326233 326224 326234 326225 326235 326226 326236 326227 326237

Voltage

: 240V A.C with integrated driver (24V AC or DC on request)

Lens

: 10º, 25º, 40º

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

Ø 160

160

32,5 115

Ø 126

Aluminum recessing tube

BELKIS 4

RECESSED UPLIGHT LOW GLARE LED FIXTURES Class I IP67 IK10

Symmetrical BELKIS 4 Fix to Recessing Tube with Silicone

32,5

(Leds places deep inside the fixtures) 13W x 350 mA Led

135

: 350 mA 13W (Nichia)

Reflector

: 24º or 38º

Gear

: 240V Non-Dimmable Driver

Cable

: 0,5 m 2x0,75 mm H03 VV-F

Ø 135

Total Lighting Output Warm White Natural White

3000 K 4000 K

1750 lm 1900 lm

135

32,5

Code No Round Square 326301 326311 326302 326312

115

Ø 126

Aluminum recessing tube

Symmetrical BELKIS 4 Fix to Recessing Tube with Screws

32,5

(Leds places deep inside the fixtures) 13W x 350 mA

160

Led

: 350 mA 13W (Nichia)

Reflector

: 24º or 38º

Gear

: 240V Non-Dimmable Driver

Cable

: 0,5 m 2x0,75 mm H03 VV-F

Ø 160

Total Lighting Output Warm White Natural White

3000 K 4000 K

1750 lm 1900 lm

Code No Round Square 326321 326331 326322 326332

160

32,5

115

Ø 126

Aluminum recessing tube

BELKIS 5

RECESSED LED FIXTURES Class I IP67 IK10

Symmetrical BELKIS 5 Fix to Recessing Tube with Silicone

150

9 x 350 mA (9 W) LED or 9 x 700 mA (27 W) LED

Warm White Natural White Cool White Blue Red Amber Green

Total Lighting Output 9W 27W 765 lm 2100 lm 3000 K 765 lm 2100 lm 4500 K 918 lm 2520 lm 6000 K

9W Round 422421 422426 422427 422422 422423 422424 422425

9W Square 422431 422436 422437 422432 422433 422434 422435

Voltage

: 240V A.C with integrated driver (24V AC or DC on request)

Lens

: 10º, 25º, 40º

27W Round 423301 423302 423303 423304 423305 423306 423307

27W Square 423311 423312 423313 423314 423315 423316 423317

150

Ø 150

101

Ø 144

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

Aluminum recessing tube

Symmetrical BELKIS 5 Fix to Recessing Tube with Screws

180

9 x 350 mA (9 W) LED or 9 x 700 mA (27 W) LED

Warm White Natural White Cool White Blue Red Amber Green

Total Lighting Output 9W 27W 765 lm 2100 lm 3000 K 765 lm 2100 lm 4500 K 918 lm 2520 lm 6000 K

9W Round 422441 422446 422447 422442 422443 422444 422445

9W Square 422451 422456 422457 422452 422453 422454 422455

Voltage

: 240V A.C with integrated driver (24V AC or DC on request)

Lens

: 10º, 25º, 40º

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

27W Round 423321 423322 423323 423324 423325 423326 423327

27W Square 423331 423332 423333 423334 423335 423336 423337

Ø 180

180

101

Ø 144

Aluminum recessing tube 95

BELKIS 5

RECESSED RGB LED FIXTURES Class I IP67 IK10

Symmetrical BELKIS 5 Fix to Recessing Tube with Silicone

150

27 x 350 mA (27 W) RGB LED Voltage

: 240V A.C with remote driver

Lens

: 25º or 40º

Diffuser

: Clear Glass

150

Ø 150

8 mm (Frosted Glass on request) Cable

: Potted 10 m 4x0,75 H03 VV-F

Control by DMX, remote control, or push button

101

Code No Round Square 423341 423351 Ø 144

Aluminum recessing tube

Symmetrical BELKIS 5 Fix to Recessing Tube with Screws

180

27 x 350 mA (27 W) RGB LED Voltage

: 240V A.C with remote driver

Lens

: 25º or 40º

Diffuser

: Clear Glass

Cable

: Potted 10 m 4x0,75 H03 VV-F

Ø 180

180

8 mm (Frosted Glass on request) Control by DMX, remote control, or push button Code No Round Square

101

422481 422491 Ø 144

Aluminum recessing tube 96

BELKIS 5

RECESSED LED FIXTURES Class I IP67 IK10

Asymmetrical 15° Tilted BELKIS 5 Fix to Recessing Tube with Silicone

15°Tilted 9 x 350 mA (9 W) LED or 9 x 700 mA (27 W) LED

Warm White Natural White Cool White Blue Red Amber Green

Total Lighting Output 9W 27W 765 lm 2100 lm 3000 K 765 lm 2100 lm 4500 K 918 lm 2520 lm 6000 K

9W Round 423361 423362 423363 423364 423365 423366 423367

150

9W Square 423371 423372 423373 423374 423375 423376 423377

Voltage

: 240V A.C with integrated driver (24V AC or DC on request)

Lens

: 10º, 25º, 40º

27W Round 423601 423602 423603 423604 423605 423606 423607

27W Square 423611 423612 423613 423614 423615 423616 423617

150

Ø 150

15 100

125

Ø 144

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

Aluminum recessing tube

Asymmetrical 15° Tilted BELKIS 5 Fix to Recessing Tube with Screws

15°Tilted 9 x 350 mA (9 W) LED or 9 x 700 mA (27 W) LED

Warm White Natural White Cool White Blue Red Amber Green

Total Lighting Output 9W 27W 765 lm 2100 lm 3000 K 765 lm 2100 lm 4500 K 918 lm 2520 lm 6000 K

9W Round 423381 423382 423383 423384 423385 423386 423387

180

9W Square 423391 423392 423393 423394 423395 423396 423397

Voltage

: 240V A.C with integrated driver (24V AC or DC on request)

Lens

: 10º, 25º, 40º

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

27W Round 423621 423622 423623 423624 423625 423626 423627

27W Square 423631 423632 423633 423634 423635 423636 423637

Ø 180

180

15 100

125

Ø 144

Aluminum recessing tube

BELKIS 5

RECESSED LED WITH TIR LENS FIXTURES Class I IP67 IK10

Asymmetrical 15° Tilted BELKIS 5 Fix to Recessing Tube with Silicone

15°Tilted 1 x 700 mA (25 W) LED or 1 x 900 mA (32 W) LED

Warm White Natural White Voltage

Total Lighting Output 25W 32W 3000 K 1645 lm 2134 lm 4000 K 1974 lm 2561 lm

25W Round 120401 120402

150

25W Square 120411 120412

32W Round 120421 120422

32W Square 120431 120432

150

Ø 150

: 240V A.C with integrated driver (24V AC or DC on request)

Lens

: 10º, 20º, 30º Mirror TIR Lens

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

100

125

Ø 144

Aluminum recessing tube

Asymmetrical 15° Tilted BELKIS 5 Fix to Recessing Tube with Screws

15°Tilted 1 x 700 mA (25 W) LED or 1 x 900 mA (32 W) LED

Warm White Natural White

Total Lighting Output 25W 32W 3000 K 1645 lm 2134 lm 4000 K 1974 lm 2561 lm

Voltage

: 240V A.C with integrated driver

Lens

: 10º, 20º, 30º Mirror TIR Lens

25W Round 120501 120502

180

25W Square 120511 120512

32W Round 120521 120522

32W Square 120531 120532

Ø 180

180

(24V AC or DC on request) Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

15 100

125

Ø 144

Aluminum recessing tube 99

BELKIS 5

RECESSED LED FIXTURES Class I IP67 IK10

Asymmetrical 15° Tilted BELKIS 5 Fix to Recessing Tube with Silicone

15°Tilted 150

27 x 350 mA (27 W) RGB LED Voltage

: 240V A.C with remote driver

Lens

: 25º or 40º

Diffuser

: Clear Glass

150

Ø 150

8 mm (Frosted Glass on request) Cable

: Potted 10 m 4x0,75 H03 VV-F 15

Control by DMX, remote control, or push button

100

125

Code No Round Square 423401 423411

Ø 144

Aluminum recessing tube

Asymmetrical 15° Tilted BELKIS 5 Fix to Recessing Tube with Screws

15°Tilted 180

27 x 350 mA (27 W) RGB LED Voltage

: 240V A.C with remote driver

Lens

: 25º or 40º

Diffuser

: Clear Glass

Cable

: Potted 10 m 4x0,75 H03 VV-F

Ø 180

180

8 mm (Frosted Glass on request) Control by DMX, remote control, or push button 15

Code No Round Square

100

125

423421 423431 Ø 144

Aluminum recessing tube 100

BELKIS 5

RECESSED LED FIXTURES Class I IP67 IK10

Asymmetrical 25° Tilted BELKIS 5 Fix to Recessing Tube with Silicone

25°Tilted 9 x 350 mA (9 W) LED or 9 x 700 mA (27 W) LED

Warm White Natural White Cool White Blue Red Amber Green

Total Lighting Output 9W 27W 765 lm 2100 lm 3000 K 765 lm 2100 lm 4500 K 918 lm 2520 lm 6000 K

9W Round 423441 423442 423443 423444 423445 423446 423447

150

9W Square 423451 423452 423453 423454 423455 423456 423457

Voltage

: 240V A.C with integrated driver (24V AC or DC on request)

Lens

: 10º, 25º, 40º

27W Round 423641 423642 423643 423644 423645 423646 423647

27W Square 423651 423652 423653 423654 423655 423656 423657

150

Ø 150

25 100

125

Ø 144

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

Aluminum recessing tube

Asymmetrical 25° Tilted BELKIS 5 Fix to Recessing Tube with Screws

25°Tilted 9 x 350 mA (9 W) LED or 9 x 700 mA (27 W) LED

Warm White Natural White Cool White Blue Red Amber Green

Total Lighting Output 9W 27W 765 lm 2100 lm 3000 K 765 lm 2100 lm 4500 K 918 lm 2520 lm 6000 K

9W Round 423461 423462 423463 423464 423465 423466 423467

180

9W Square 423471 423472 423473 423474 423475 423476 423477

Voltage

: 240V A.C with integrated driver (24V AC or DC on request)

Lens

: 10º, 25º, 40º

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

27W Round 423661 423662 423663 423664 423665 423666 423667

27W Square 423671 423672 423673 423674 423675 423676 423677

Ø 180

180

25 100

125

Ø 144

Aluminum recessing tube 101

BELKIS 5

RECESSED LED WITH TIR LENS FIXTURES Class I IP67 IK10

Asymmetrical 25° Tilted BELKIS 5 Fix to Recessing Tube with Silicone

25°Tilted 1 x 700 mA (25 W) LED or 1 x 900 mA (32 W) LED

Warm White Natural White Voltage

Total Lighting Output 25W 32W 3000 K 1645 lm 2134 lm 4000 K 1974 lm 2561 lm

25W Round 120601 120602

150

25W Square 120611 120612

32W Round 120621 120622

32W Square 120631 120632

150

Ø 150

: 240V A.C with integrated driver (24V AC or DC on request)

Lens

: 10º, 20º, 30º Mirror TIR Lens

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

100

125

Ø 144

Aluminum recessing tube

Asymmetrical 25° Tilted BELKIS 5 Fix to Recessing Tube with Screws

25°Tilted 1 x 700 mA (25 W) LED or 1 x 900 mA (32 W) LED

Warm White Natural White

Total Lighting Output 25W 32W 3000 K 1645 lm 2134 lm 4000 K 1974 lm 2561 lm

Voltage

: 240V A.C with integrated driver

Lens

: 10º, 20º, 30º Mirror TIR Lens

25W Round 120701 120702

180

25W Square 120711 120712

32W Round 120721 120722

32W Square 120731 120732

Ø 180

180

(24V AC or DC on request) Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

25 100

125

Ø 144

Aluminum recessing tube 102

BELKIS 5

RECESSED RGB LED FIXTURES Class I IP67 IK10

Asymmetrical 25° Tilted BELKIS 5 Fix to Recessing Tube with Silicone

25°Tilted 150

27 x 350 mA (27 W) RGB LED Voltage

: 240V A.C with remote driver

Lens

: 25º or 40º

Diffuser

: Clear Glass

150

Ø 150

8 mm (Frosted Glass on request) Cable

: Potted 10 m 4x0,75 H03 VV-F 25

Control by DMX, remote control, or push button

100

125

Code No Round Square 423481 423491

Ø 144

Aluminum recessing tube

Asymmetrical 25° Tilted BELKIS 5 Fix to Recessing Tube with Screws

25°Tilted 180

27 x 350 mA (27 W) RGB LED Voltage

: 240V A.C with remote driver

Lens

: 25º or 40º

Diffuser

: Clear Glass

Cable

: Potted 10 m 4x0,75 H03 VV-F

Ø 180

180

8 mm (Frosted Glass on request) Control by DMX, remote control, or push button 25

Code No Round Square

100

125

423501 423511 Ø 144

Aluminum recessing tube 103

BELKIS 5

RECESSED LED FIXTURES Class I IP67 IK10

Asymmetrical Wallwasher BELKIS 5 Fix to Recessing Tube with Silicone

Wallwasher 1 x 350 mA (12 W) LED or 1 x 700 mA (25 W) LED 150

Warm White Warm White Natural White

Voltage

Total Lighting Output 12W 25W 2700 K 1005 lm 1848 lm 3000 K 1005 lm 1848 lm 4000 K 1078 lm 1919 lm

12W Round 423701 423702 423703

12W Square 423711 423712 423713

25W Round 423801 423802 423803

25W Square 423811 423812 423813

150

Ø 150

: 240V A.C with integrated driver

100

125

(24V AC or DC on request) Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

Ø 144

Aluminum recessing tube Asymmetrical Wallwasher BELKIS 2 Fix to Recessing Tube with Screws

Wallwasher 180

1 x 350 mA (12 W) LED or 1 x 700 mA (25 W) LED

Warm White Warm White Natural White

Voltage

Total Lighting Output 12W 25W 2700 K 1005 lm 1848 lm 3000 K 1005 lm 1848 lm 4000 K 1078 lm 1919 lm

12W Round 423721 423722 423723

12W Square 423731 423732 423733

25W Round 423821 423822 423823

25W Square 423831 423832 423833

Ø 180

180

: 240V A.C with integrated driver (24V AC or DC on request)

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

100

125

Ø 144

Aluminum recessing tube 104

BELKIS 5

RECESSED LED FIXTURES Class I IP67 IK10

Asymmetrical Wallwasher BELKIS 5 Fix to Recessing Tube with Silicone

2 x 700 mA (6 W) LED Total Lighting Output Warm White Natural White Cool White Blue Red Amber Green

3000 K 4500 K 6000 K

450 lm 450 lm 540 lm

30º Round 423521 423522 423523 423524 423525 423526 423527

30º Square 423531 423532 423533 423534 423535 423536 423537

Voltage

: 240V A.C with integrated driver (24V AC or DC on request)

Lens

: 10º, 25º, 40º

60º Round 423561 423562 423563 423564 423565 423566 423567

60º Square 423571 423572 423573 423574 423575 423576 423577

150

Ø 150

150

101

Ø 144

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

Aluminum recessing tube

Asymmetrical Wallwasher BELKIS 5 Fix to Recessing Tube with Screws

2 x 700 mA (6 W) LED

180

Total Lighting Output Warm White Natural White Cool White Blue Red Amber Green

3000 K 4500 K 6000 K

450 lm 450 lm 540 lm

30º Round 423541 423542 423543 423544 423545 423546 423547

30º Square 423551 423552 423553 423554 423555 423556 423557

Voltage

: 240V A.C with integrated driver (24V AC or DC on request)

Lens

: 10º, 25º, 40º

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

60º Round 423581 423582 423583 423584 423585 423586 423587

60º Square 423591 423592 423593 423594 423595 423596 423597

180

Ø 180

101

Ø 144

Aluminum recessing tube 105

BELKIS 5

RECESSED HALOGEN FIXTURES Class I IP67 IK10

Symmetrical BELKIS 5 Fix to Recessing Tube with Silicone

HALOGEN 240W PAR 30 / 75W (10º or 30º) Lampholder : E27 Fixed Reflector

: -

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

COMPACT FLUO. AR 111 11W (45º) Lampholder : Gx53 Reflector

: -

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Lamp

: Megaman

Gear

: Electronic (in lamp)

Code No Round Square

150

324111 324211 150

Ø 150

Code No Round Square 324131 324231

170

Ø 140

Aluminum recessing tube Symmetrical BELKIS 5 Fix to Recessing Tube with Screws

HALOGEN 240W PAR 30 / 75W (10º or 30º) Lampholder : E27 Fixed Reflector

: -

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

COMPACT FLUO. AR 111 11W (45º) Lampholder : Gx53 Reflector

: -

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Lamp

: Megaman

Gear

: Electronic (in lamp)

180

Code No Round Square 324121 324221 Ø 180

180

Code No Round Square 324141 324241 170

Ø 140

Aluminum recessing tube 106

PATNOS

RECESSED FIXTURES IP67 IK10

The Patnos series is an adaption of the Belkis Recessed series using less or no visible screws. No screws are visible on the cover if silicone is used to glue the fixture to the recessing tube. The series is designed to light walls, facades, columns, monuments, and trees. The fixtures are made of a combination of a 316L stainless steel cover and die cast aluminium body painted with electrostatic powder paint. Tempered glass, silicone gaskets and cast resin complete the fixture to make it IP67 IK10 and withstand rough environments. A specially developed potted power cable is used to effectively bond with the cast resin and stop any water ingress. The fixtures come with an aluminium recessing tube for easy mounting in the ground or concrete. The LEDs used come in 3 different tones of white, as well as blue, red, green, amber and RGB. Several lenses from 6 to 40 degrees are available to choose from to achieve the desired light effect. Asymmetrical LEDs In this catalogue EMFA is introducing the tilted LED fixtures. These fixtures give an asymmetrical light output to facades, columns, bridges, monuments, and trees without losing light to the sky. The die cast aluminium body has a fixed built in tilt to allow for proper heat dissipation of the LEDs that can run up to 700mA. Cover 316L Stainless steel Body Die cast aluminium Recessing Box Aluminium Gaskets Silicone Diffusers Tempered Glass Screws 316L Stainless steel “Customization” is EMFA’s standard EMFA offers many combinations for each fixture, as all fixtures are made in house. A combination of 2 finishes of stainless steel, 8 LED colors, 2 wattages, and 5 or more lenses and reflectors are available to make the fixture suitable for the required application. This is done without increasing lead-time and is available for large as well as small quantities. Honeycomb Louvre Belkis 1 Belkis 2 Belkis 3 Belkis 4 Belkis 5

Code No 953521 953522 953523 953524 953525

107

PATNOS 1

RECESSED LED FIXTURES Class I IP67 IK10

Symmetrical PATNOS 1 Fix to Recessing Tube with Silicone

1 x 350 mA (1 W) LED or 1 x 700 mA (3 W) LED

Warm White Natural White Cool White Blue Red Amber Green

Total Lighting Output 1W 3W 85 lm 225 lm 3000 K 85 lm 225 lm 4500 K 102 lm 270 lm 6000 K

1W Round 160001 160002 160003 160004 160005 160006 160007

1W Square 160011 160012 160013 160014 160015 160016 160017

3W Round 160041 160042 160043 160044 160045 160046 160047

3W Square 160051 160052 160053 160054 160055 160056 160057

Ø 70

101

Ø 66

Voltage

: 240V A.C with integrated driver (24V AC or DC on request)

Lens

: 10º, 25º, 40º

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

Aluminum recessing tube

Symmetrical PATNOS 1 Fix to Recessing Tube with Screws

1 x 350 mA (1 W) LED or 1 x 700 mA (3 W) LED

Warm White Natural White Cool White Blue Red Amber Green

Total Lighting Output 1W 3W 85 lm 225 lm 3000 K 85 lm 225 lm 4500 K 102 lm 270 lm 6000 K

1W Round 160021 160022 160023 160024 160025 160026 160027

1W Square 160031 160032 160033 160034 160035 160036 160037

Voltage

: 240V A.C with integrated driver (24V AC or DC on request)

Lens

: 10º, 25º, 40º

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

108

3W Round 160061 160062 160063 160064 160065 160066 160067

3W Square 160071 160072 160073 160074 160075 160076 160077

Ø 95

101

Ø 66

Aluminum recessing tube

PATNOS 1

RECESSED LED FIXTURES Class I IP67 IK10

Asymmetrical 7° Tilted PATNOS 1 Fix to Recessing Tube with Silicone

7° Tilted 1 x 350 mA (1 W) LED or 1 x 700 mA (3 W) LED

Warm White Natural White Cool White Blue Red Amber Green

Total Lighting Output 1W 3W 85 lm 225 lm 3000 K 85 lm 225 lm 4500 K 102 lm 270 lm 6000 K

1W Round 160201 160202 160203 160204 160205 160206 160207

1W Square 160211 160212 160213 160214 160215 160216 160217

3W Round 160241 160242 160243 160244 160245 160246 160247

3W Square 160251 160252 160253 160254 160255 160256 160257

Ø 70

7° 75

101

Ø 66

Voltage

: 240V A.C with integrated driver (24V AC or DC on request)

Lens

: 10º, 25º, 40º

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

Aluminum recessing tube

Asymmetrical 7° Tilted PATNOS 1 Fix to Recessing Tube with Screws

7° Tilted 1 x 350 mA (1 W) LED or 1 x 700 mA (3 W) LED

Warm White Natural White Cool White Blue Red Amber Green

Total Lighting Output 1W 3W 85 lm 225 lm 3000 K 85 lm 225 lm 4500 K 102 lm 270 lm 6000 K

1W Round 160221 160222 160223 160224 160225 160226 160227

1W Square 160231 160232 160233 160234 160235 160236 160237

Voltage

: 240V A.C with integrated driver (24V AC or DC on request)

Lens

: 10º, 25º, 40º

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

3W Round 160261 160262 160263 160264 160265 160266 160267

3W Square 160271 160272 160273 160274 160275 160276 160277

Ø 95

7° 75

101

Ø 66

Aluminum recessing tube

109

PATNOS 2

RECESSED LED FIXTURES Class I IP67 IK10

Symmetrical PATNOS 2 Fix to Recessing Tube with Silicone

3 x 350 mA (3 W) LED or 3 x 700 mA (9 W) LED

Warm White Natural White Cool White Blue Red Amber Green

Total Lighting Output 3W 9W 255 lm 675 lm 3000 K 255 lm 675 lm 4500 K 306 lm 810 lm 6000 K

3W Round 161001 161002 161003 161004 161005 161006 161007

3W Square 161011 161012 161013 161014 161015 161016 161017

Voltage

: 240V A.C with integrated driver (24V AC or DC on request)

Lens

: 10º, 25º, 40º

9W Round 161041 161042 161043 161044 161045 161046 161047

9W Square 161051 161052 161053 161054 161055 161056 161057

Ø 90

60 101

Ø 84

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

Aluminum recessing tube

Symmetrical PATNOS 2 Fix to Recessing Tube with Screws

3 x 350 mA (3 W) LED or 3 x 700 mA (9 W) LED

Warm White Natural White Cool White Blue Red Amber Green

Total Lighting Output 3W 9W 255 lm 675 lm 3000 K 255 lm 675 lm 4500 K 306 lm 810 lm 6000 K

115

3W Round 161021 161022 161023 161024 161025 161026 161027

3W Square 161031 161032 161033 161034 161035 161036 161037

Voltage

: 240V A.C with integrated driver (24V AC or DC on request)

Lens

: 10º, 25º, 40º

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

110

9W Round 161061 161062 161063 161064 161065 161066 161067

9W Square 161071 161072 161073 161074 161075 161076 161077

Ø 115

115

60 101

Ø 84

Aluminum recessing tube

PATNOS 2

RECESSED RGB LED FIXTURES Class I IP67 IK10

Symmetrical PATNOS 2 Fix to Recessing Tube with Silicone

9 x 350 mA (9 W) RGB LED Voltage

: 240V A.C with remote driver

Lens

: 25º or 40º

Diffuser

: Clear Glass

Ø 90

8 mm (Frosted Glass on request) Cable

: Potted 10 m 4x0,75 H03 VV-F 60

Control by DMX, remote control, or push button

101

Code No Round Square 161081 161091

Ø 84

Aluminum recessing tube

Symmetrical PATNOS 2 Fix to Recessing Tube with Screws

115

9 x 350 mA (9 W) RGB LED Voltage

: 240V A.C with remote driver

Lens

: 25º or 40º

Diffuser

: Clear Glass

Cable

: Potted 10 m 4x0,75 H03 VV-F

Ø 115

115

8 mm (Frosted Glass on request) Control by DMX, remote control, or push button

60 101

Code No Round Square 161101 161111 Ø 84

Aluminum recessing tube

111

112

PATNOS 2

RECESSED LED FIXTURES Class I IP67 IK10

Asymmetrical Wallwasher PATNOS 2 Fix to Recessing Tube with Silicone

Wallwasher 1 x 350 mA (1 W) LED or 1 x 700 mA (3 W) LED

Warm White Natural White Cool White Blue Red Amber Green

Total Lighting Output 1W 3W 210 lm 89 lm 3000 K 210 lm 89 lm 4500 K 230 lm 101 lm 6000 K

1W Round 161601 161602 161603 161604 161605 161606 161607

1W Square 161611 161612 161613 161614 161615 161616 161617

Voltage

: 240V A.C with integrated driver (24V AC or DC on request)

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

3W Round 161641 161642 161643 161644 161645 161646 161647

3W Square 161651 161652 161653 161654 161655 161656 161657

Ø 90

60 101

Ø 84

Aluminum recessing tube

Asymmetrical Wallwasher PATNOS 2 Fix to Recessing Tube with Screws

Wallwasher 1 x 350 mA (3 W) LED or 1 x 700 mA (3 W) LED

Warm White Natural White Cool White Blue Red Amber Green

Total Lighting Output 1W 3W 210 lm 89 lm 3000 K 210 lm 89 lm 4500 K 230 lm 101 lm 6000 K

115

1W Round 161621 161622 161623 161624 161625 161626 161627

1W Square 161631 161632 161633 161634 161635 161636 161637

Voltage

: 240V A.C with integrated driver (24V AC or DC on request)

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

3W Round 161661 161662 161663 161664 161665 161666 161667

3W Square 161671 161672 161673 161674 161675 161676 161677

Ø 115

115

60 101

Ø 84

Aluminum recessing tube

113

PATNOS 2

RECESSED LED FIXTURES Class I IP67 IK10

Asymmetrical 7° Tilted PATNOS 2 Fix to Recessing Tube with Silicone

7° Tilted 3 x 350 mA (3 W) LED or 3 x 700 mA (9 W) LED

Warm White Natural White Cool White Blue Red Amber Green

Total Lighting Output 3W 9W 255 lm 675 lm 3000 K 266 lm 675 lm 4500 K 306 lm 810 lm 6000 K

3W Round 161201 161202 161203 161204 161205 161206 161207

3W Square 161211 161212 161213 161214 161215 161216 161217

Voltage

: 240V A.C with integrated driver (24V AC or DC on request)

Lens

: 10º, 25º, 40º

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

9W Round 161241 161242 161243 161244 161245 161246 161247

9W Square 161251 161252 161253 161254 161255 161256 161257

Ø 90

7° 60 101

Ø 84

Aluminum recessing tube

Asymmetrical 7° Tilted PATNOS 2 Fix to Recessing Tube with Screws

7° Tilted 3 x 350 mA (3 W) LED or 3 x 700 mA (9 W) LED

Warm White Natural White Cool White Blue Red Amber Green

Total Lighting Output 3W 9W 255 lm 675 lm 3000 K 266 lm 675 lm 4500 K 306 lm 810 lm 6000 K

115

3W Round 161221 161222 161223 161224 161225 161226 161227

3W Square 161231 161232 161233 161234 161235 161236 161237

Voltage

: 240V A.C with integrated driver (24V AC or DC on request)

Lens

: 10º, 25º, 40º

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

114

9W Round 161261 161262 161263 161264 161265 161266 161267

9W Square 161271 161272 161273 161274 161275 161276 161277

Ø 115

115

60 101

Ø 84

Aluminum recessing tube

PATNOS 2

RECESSED RGB LED FIXTURES Class I IP67 IK10

Asymmetrical 7° Tilted PATNOS 2 Fix to Recessing Tube with Silicone

7° Tilted 90

9 x 350 mA (9 W) RGB LED Voltage

: 240V A.C with remote driver

Lens

: 25º or 40º

Diffuser

: Clear Glass

Ø 90

8 mm (Frosted Glass on request) Cable

: Potted 10 m 4x0,75 H03 VV-F

7° 60

Control by DMX, remote control, or push button

101

Code No Round Square 161281 161291 Ø 84

Aluminum recessing tube Asymmetrical 7° Tilted PATNOS 2 Fix to Recessing Tube with Screws

7° Tilted 115

9 x 350 mA (9 W) RGB LED Voltage

: 240V A.C with remote driver

Lens

: 25º or 40º

Diffuser

: Clear Glass

Cable

: Potted 10 m 4x0,75 H03 VV-F

Ø 115

115

8 mm (Frosted Glass on request) Control by DMX, remote control, or push button

60 101

Code No Round Square 161301 161311 Ø 84

Aluminum recessing tube

115

116

PATNOS 2

RECESSED LED FIXTURES Class I IP67 IK10

Asymmetrical 15° Tilted PATNOS 2 Fix to Recessing Tube with Silicone

15° Tilted 3 x 350 mA (3 W) LED or 3 x 700 mA (9 W) LED

Warm White Natural White Cool White Blue Red Amber Green

Total Lighting Output 3W 9W 255 lm 675 lm 3000 K 266 lm 675 lm 4500 K 306 lm 810 lm 6000 K

115

3W Round 161321 161322 161323 161324 161325 161326 161327

3W Square 161331 161332 161333 161334 161335 161336 161337

Voltage

: 240V A.C with integrated driver (24V AC or DC on request)

Lens

: 10º, 25º, 40º

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

9W Round 161361 161362 161363 161364 161365 161366 161367

9W Square 161371 161372 161373 161374 161375 161376 161377

Ø 115

115

15° 73

101

Ø 108

Aluminum recessing tube

Asymmetrical 15° Tilted PATNOS 2 Fix to Recessing Tube with Screws

15° Tilted 3 x 350 mA (3 W) LED or 3 x 700 mA (9 W) LED

Warm White Natural White Cool White Blue Red Amber Green

Total Lighting Output 3W 9W 255 lm 675 lm 3000 K 266 lm 675 lm 4500 K 306 lm 810 lm 6000 K

140

3W Round 161341 161342 161343 161344 161345 161346 161347

3W Square 161351 161352 161353 161354 161355 161356 161357

Voltage

: 240V A.C with integrated driver (24V AC or DC on request)

Lens

: 10º, 25º, 40º

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

9W Round 161381 161382 161383 161384 161385 161386 161387

9W Square 161391 161392 161393 161394 161395 161396 161397

Ø 140

140

15° 73

101

Ø 108

Aluminum recessing tube

117

118

PATNOS 2

RECESSED RGB LED FIXTURES Class I IP67 IK10

Asymmetrical 15° Tilted PATNOS 2 Fix to Recessing Tube with Silicone

15° Tilted 115

9 x 350 mA (9 W) RGB LED Voltage

: 240V A.C with remote driver

Lens

: 25º or 40º

Diffuser

: Clear Glass

Ø 115

115

8 mm (Frosted Glass on request) Cable

: Potted 10 m 4x0,75 H03 VV-F

15°

Control by DMX, remote control, or push button

101

Code No Round Square 161401 161411

Ø 108

Aluminum recessing tube

Asymmetrical 15° Tilted PATNOS 2 Fix to Recessing Tube with Screws

15° Tilted 140

9 x 350 mA (9 W) RGB LED Voltage

: 240V A.C with remote driver

Lens

: 25º or 40º

Diffuser

: Clear Glass

Cable

: Potted 10 m 4x0,75 H03 VV-F

Ø 140

140

8 mm (Frosted Glass on request) Control by DMX, remote control, or push button

15° 73

101

Code No Round Square 161421 161431

Ø 108

Aluminum recessing tube

119

PATNOS 2

RECESSED LED FIXTURES Class I IP67 IK10

Asymmetrical 25° Tilted PATNOS 2 Fix to Recessing Tube with Silicone

25° Tilted 3 x 350 mA (3 W) LED or 3 x 700 mA (9 W) LED

Warm White Natural White Cool White Blue Red Amber Green

Total Lighting Output 3W 9W 255 lm 675 lm 3000 K 255 lm 675 lm 4500 K 310 lm 810 lm 6000 K

115

3W Round 161441 161442 161443 161444 161445 161446 161447

3W Square 161451 161452 161453 161454 161455 161456 161457

Voltage

: 240V A.C with integrated driver (24V AC or DC on request)

Lens

: 10º, 25º, 40º

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

9W Round 161481 161482 161483 161484 161485 161486 161487

9W Square 161491 161492 161493 161494 161495 161496 161497

Ø 115

115

25° 73

101

Ø 108

Aluminum recessing tube

Asymmetrical 25° Tilted PATNOS 2 Fix to Recessing Tube with Screws

25° Tilted 3 x 350 mA (3 W) LED or 3 x 700 mA (9 W) LED

Warm White Natural White Cool White Blue Red Amber Green

Total Lighting Output 3W 9W 255 lm 675 lm 3000 K 255 lm 675 lm 4500 K 310 lm 810 lm 6000 K

140

3W Round 161461 161462 161463 161464 161465 161466 161467

3W Square 161471 161472 161473 161474 161475 161476 161477

Voltage

: 240V A.C with integrated driver (24V AC or DC on request)

Lens

: 10º, 25º, 40º

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

120

9W Round 161501 161502 161503 161504 161505 161506 161507

9W Square 161511 161512 161513 161514 161515 161516 161517

Ø 140

140

25° 73

101

Ø 108

Aluminum recessing tube

121

PATNOS 2

RECESSED RGB LED FIXTURES Class I IP67 IK10

Asymmetrical 25° Tilted PATNOS 2 Fix to Recessing Tube with Silicone

25° Tilted 115

9 x 350 mA (9 W) RGB LED Voltage

: 240V A.C with remote driver

Lens

: 25º or 40º

Diffuser

: Clear Glass

Ø 115

115

8 mm (Frosted Glass on request) Cable

: Potted 10 m 4x0,75 H03 VV-F

25°

Control by DMX, remote control, or push button

101

Code No Round Square 161521 161531

Ø 108

Aluminum recessing tube

Asymmetrical 25° Tilted PATNOS 2 Fix to Recessing Tube with Screws

25° Tilted 140

9 x 350 mA (9 W) RGB LED Voltage

: 240V A.C with remote driver

Lens

: 25º or 40º

Diffuser

: Clear Glass

Cable

: Potted 10 m 4x0,75 H03 VV-F

Ø 140

140

8 mm (Frosted Glass on request) Control by DMX, remote control, or push button

25° 73

101

Code No Round Square 161541 161551

Ø 108

Aluminum recessing tube

122

PATNOS 3

RECESSED LED FIXTURES Class I IP67 IK10

Symmetrical PATNOS 3 Fix to Recessing Tube with Silicone

6 x 350 mA (6 W) LED Warm White Natural White Cool White Blue Red Amber Green

3000 K 4500 K 6000 K

Total Lighting Output 510 lm 510 lm 612 lm

115

Code No Round Square 162001 162011 162002 162012 162003 162013 162004 162014 162005 162015 162006 162016 162007 162017

Voltage

: 240V A.C with integrated driver (24V AC or DC on request)

Lens

: 10º, 25º, 40º

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

115

Ø 115

101

Ø 108

Aluminum recessing tube

Symmetrical PATNOS 3 Fix to Recessing Tube with Screws

6 x 350 mA (6 W) LED Warm White Natural White Cool White Blue Red Amber Green

3000 K 4500 K 6000 K

Total Lighting Output 510 lm 510 lm 612 lm

140

Code No Round Square 162021 162022 162023 162024 162025 162026 162027

162031 162032 162033 162034 162035 162036 162037

Voltage

: 240V A.C with integrated driver (24V AC or DC on request)

Lens

: 10º, 25º, 40º

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

Ø 140

140

58 101

Ø 108

Aluminum recessing tube

123

PATNOS 3

RECESSED RGB LED FIXTURES Class I IP67 IK10

Symmetrical PATNOS 3 Fix to Recessing Tube with Silicone

115

18 x 350 mA (18 W) RGB LED Voltage

: 240V A.C with remote driver

Lens

: 25º or 40º

Diffuser

: Clear Glass

115

Ø 115

8 mm (Frosted Glass on request) Cable

: Potted 10 m 4x0,75 H03 VV-F

Control by DMX, remote control, or push button

101

Code No Round Square Ø 108

162041 162051

Aluminum recessing tube

Symmetrical PATNOS 3 Fix to Recessing Tube with Screws

140

18 x 350 mA (18 W) RGB LED Voltage

: 240V A.C with remote driver

Lens

: 25º or 40º

Diffuser

: Clear Glass

Cable

: Potted 10 m 4x0,75 H03 VV-F

Ø 140

140

8 mm (Frosted Glass on request) Control by DMX, remote control, or push button

58 101

Code No Round Square 162061 162071

Ø 108

Aluminum recessing tube

124

PATNOS 3

RECESSED UPLIGHT LOW GLARE LED FIXTURES Class I IP67 IK10

Symmetrical PATNOS 3 Fix to Recessing Tube with Silicone

22,5

(Leds places deep inside the fixtures)

6 x 350 mA (6 W) LED Warm White Natural White Cool White Blue Red Amber Green

3000 K 4500 K 6000 K

Total Lighting Output 510 lm 510 lm 612 lm

115

Code No Round Square 162401 162411 162402 162412 162403 162413 162404 162414 162405 162415 162406 162416 162407 162417

Voltage

: 240V A.C with integrated driver (24V AC or DC on request)

Lens

: 10º, 25º, 40º

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

115

Ø 115

22,5 101

Ø 108

Aluminum recessing tube

Symmetrical PATNOS 3 Fix to Recessing Tube with Screws

22,5

(Leds places deep inside the fixtures)

6 x 350 mA (6 W) LED Warm White Natural White Cool White Blue Red Amber Green

3000 K 4500 K 6000 K

Total Lighting Output 510 lm 510 lm 612 lm

140

Code No Round Square 162421 162431 162422 162432 162423 162433 162424 162434 162425 162435 162426 162436 162427 162437

Voltage

: 240V A.C with integrated driver (24V AC or DC on request)

Lens

: 10º, 25º, 40º

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

Ø 140

140

22,5 101

Ø 108

Aluminum recessing tube

125

PATNOS 3

RECESSED LED FIXTURES Class I IP67 IK10

Asymmetrical 15° Tilted PATNOS 3 Fix to Recessing Tube with Silicone

15°Tilted 6 x 350 mA (6 W) LED Warm White Natural White Cool White Blue Red Amber Green

3000 K 4500 K 6000 K

Total Lighting Output 510 lm 510 lm 612 lm

Code No Round Square 162201 162211 162202 162212 162203 162213 162204 162214 162205 162215 162206 162216 162207 162217

Voltage

: 240V A.C with integrated driver (24V AC or DC on request)

Lens

: 10º, 25º, 40º

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

135

Ø 135

135

15° 90

135

Ø 126

Aluminum recessing tube

Available with springs for false ceiling. Asymmetrical 15° Tilted PATNOS 3 Fix to Recessing Tube with Screws

15°Tilted 6 x 350 mA (6 W) LED Warm White Natural White Cool White Blue Red Amber Green

3000 K 4500 K 6000 K

Total Lighting Output 510 lm 510 lm 612 lm

162221 162222 162223 162224 162225 162226 162227

162231 162232 162233 162234 162235 162236 162237

Voltage

: 240V A.C with integrated driver (24V AC or DC on request)

Lens

: 10º, 25º, 40º

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

Available with springs for false ceiling. 126

160

Code No Round Square

160

Ø 160

15° 90

115

Ø 126

Aluminum recessing tube

PATNOS 3

RECESSED RGB LED FIXTURES Class I IP67 IK10

Asymmetrical 15° Tilted PATNOS 3 Fix to Recessing Tube with Silicone

15°Tilted 135

18 x 350 mA (18 W) RGB LED Voltage

: 240V A.C with remote driver

Lens

: 25º or 40º

Diffuser

: Clear Glass

Ø 135

135

8 mm (Frosted Glass on request) Cable

: Potted 10 m 4x0,75 H03 VV-F

Control by DMX, remote control, or push button

15° 90

135

Code No Round Square 162241 162251

Ø 126

Aluminum recessing tube

Asymmetrical 15° Tilted PATNOS 3 Fix to Recessing Tube with Screws

15°Tilted 160

18 x 350 mA (18 W) RGB LED Voltage

: 240V A.C with remote driver

Lens

: 25º or 40º

Diffuser

: Clear Glass

Cable

: Potted 10 m 4x0,75 H03 VV-F

160

Ø 160

8 mm (Frosted Glass on request) Control by DMX, remote control, or push button Code No Round Square

15° 90

115

162261 162271 Ø 126

Aluminum recessing tube

127

PATNOS 3

RECESSED LED FIXTURES Class I IP67 IK10

Asymmetrical 25° Tilted PATNOS 3 Fix to Recessing Tube with Silicone

25°Tilted 6 x 350 mA (6 W) LED Warm White Natural White Cool White Blue Red Amber Green

3000 K 4500 K 6000 K

Total Lighting Output 510 lm 510 lm 612 lm

Code No Round Square 162281 162291 162282 162292 162283 162293 162284 162294 162285 162295 162286 162296 162287 162297

Voltage

: 240V A.C with integrated driver (24V AC or DC on request)

Lens

: 10º, 25º, 40º

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

135

Ø 135

135

25° 90

135

Ø 126

Aluminum recessing tube

Available with springs for false ceiling. Asymmetrical 25° Tilted PATNOS 3 Fix to Recessing Tube with Screws

25°Tilted 6 x 350 mA (6 W) LED Warm White Natural White Cool White Blue Red Amber Green

3000 K 4500 K 6000 K

Total Lighting Output 510 lm 510 lm 612 lm

162301 162302 162303 162304 162305 162306 162307

162311 162312 162313 162314 162315 162316 162317

Voltage

: 240V A.C with integrated driver (24V AC or DC on request)

Lens

: 10º, 25º, 40º

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

Available with springs for false ceiling. 128

160

Code No Round Square

160

Ø 160

25° 90

115

Ø 126

Aluminum recessing tube

PATNOS 3

RECESSED RGB LED FIXTURES Class I IP67 IK10

Asymmetrical 25° Tilted PATNOS 3 Fix to Recessing Tube with Silicone

25°Tilted 135

18 x 350 mA (18 W) RGB LED Voltage

: 240V A.C with remote driver

Lens

: 25º or 40º

Diffuser

: Clear Glass

Ø 135

135

8 mm (Frosted Glass on request) Cable

: Potted 10 m 4x0,75 H03 VV-F

Control by DMX, remote control, or push button

25° 90

135

Code No Round Square 162321 162331

Ø 126

Aluminum recessing tube

Asymmetrical 25° Tilted PATNOS 3 Fix to Recessing Tube with Screws

25°Tilted 160

18 x 350 mA (18 W) RGB LED Voltage

: 240V A.C with remote driver

Lens

: 25º or 40º

Diffuser

: Clear Glass

Cable

: Potted 10 m 4x0,75 H03 VV-F

160

Ø 160

8 mm (Frosted Glass on request) Control by DMX, remote control, or push button Code No Round Square

25° 90

115

162341 162351 Ø 126

Aluminum recessing tube

129

PATNOS 4

RECESSED LED FIXTURES Class I IP67 IK10

Symmetrical PATNOS 4 Fix to Recessing Tube with Silicone

9 x 350 mA (9 W) LED Warm White Natural White Cool White Blue Red Amber Green

3000 K 4500 K 6000 K

Total Lighting Output 765 lm 765 lm 918 lm

Code No Round Square 163001 163011 163002 163012 163003 163013 163004 163014 163005 163015 163006 163016 163007 163017

Voltage

: 240V A.C with integrated driver (24V AC or DC on request)

Lens

: 10º, 25º, 40º

135

Ø 135

101

Ø 126

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

Aluminum recessing tube

Symmetrical PATNOS 4 Fix to Recessing Tube with Screws

9 x 350 mA (9 W) LED Warm White Natural White Cool White Blue Red Amber Green

3000 K 4500 K 6000 K

Total Lighting Output 765 lm 765 lm 918 lm

163021 163022 163023 163024 163025 163026 163027

163031 163032 163033 163034 163035 163036 163037

Voltage

: 240V A.C with integrated driver (24V AC or DC on request)

Lens

: 10º, 25º, 40º

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

130

160

Code No Round Square

160

Ø 160

65 101

Ø 126

Aluminum recessing tube

131

PATNOS 4

RECESSED UPLIGHT LOW GLARE LED FIXTURES Class I IP67 IK10

Symmetrical PATNOS 4 Fix to Recessing Tube with Silicone

32,5

(LEDs placed deep inside the fixture)

6 x 350 mA (6 W) LED Warm White Natural White Cool White Blue Red Amber Green

3000 K 4500 K 6000 K

Total Lighting Output 510 lm 510 lm 612 lm

135

Code No Round Square 163101 163111 163102 163112 163103 163113 163104 163114 163105 163115 163106 163116 163107 163117

Voltage

: 240V A.C with integrated driver (24V AC or DC on request)

Lens

: 10º, 25º, 40º

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

135

Ø 135

32,5

115

Ø 126

Aluminum recessing tube

Symmetrical PATNOS 4 Fix to Recessing Tube with Screws

32,5

(LEDs placed deep inside the fixture)

6 x 350 mA (6 W) LED Warm White Natural White Cool White Blue Red Amber Green

3000 K 4500 K 6000 K

Total Lighting Output 510 lm 510 lm 612 lm

160

Code No Round Square 163121 163131 163122 163132 163123 163133 163124 163134 163125 163135 163126 163136 163127 163137

Voltage

: 240V A.C with integrated driver (24V AC or DC on request)

Lens

: 10º, 25º, 40º

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

132

160

Ø 160

32,5 115

Ø 126

Aluminum recessing tube

PATNOS 4

RECESSED UPLIGHT LOW GLARE LED FIXTURES Class I IP67 IK10

Symmetrical PATNOS 4 Fix to Recessing Tube with Silicone

32,5

(LEDs placed deep inside the fixture) 13W x 350 mA Led

135

: 350 mA 13W (Nichia)

Reflector

: 24º or 38º

Gear

: 240V Non-Dimmable Driver

Cable

: 0,5 m 2x0,75 mm H03 VV-F

Ø 135

Total Lighting Output Warm White Natural White

3000 K 4000 K

1750 lm 1900 lm

135

32,5

Code No Round Square 163141 163151 163142 163152

115

Ø 126

Aluminum recessing tube

Symmetrical PATNOS 4 Fix to Recessing Tube with Screws

32,5

(LEDs placed deep inside the fixture) 13W x 350 mA

160

Led

: 350 mA 13W (Nichia)

Reflector

: 24º or 38º

Gear

: 240V Non-Dimmable Driver

Cable

: 0,5 m 2x0,75 mm H03 VV-F

Ø 160

Total Lighting Output Warm White Natural White

3000 K 4000 K

1750 lm 1900 lm

Code No Round Square 163161 163171 163162 163172

160

32,5

115

Ø 126

Aluminum recessing tube

133

PATNOS 5

RECESSED LED FIXTURES Class I IP67 IK10

Symmetrical PATNOS 5 Fix to Recessing Tube with Silicone

150

9 x 350 mA (9 W) LED or 9 x 700 mA (27 W) LED

Warm White Natural White Cool White Blue Red Amber Green

Total Lighting Output 9W 27W 765 lm 2100 lm 3000 K 765 lm 2100 lm 4500 K 918 lm 2520 lm 6000 K

9W Round 164001 164002 164003 164004 164005 164006 164007

9W Square 164011 164012 164013 164014 164015 164016 164017

Voltage

: 240V A.C with integrated driver (24V AC or DC on request)

Lens

: 10º, 25º, 40º

27W Round 164041 164042 164043 164044 164045 164046 164047

27W Square 164051 164052 164053 164054 164055 164056 164057

150

Ø 150

101

Ø 144

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

Aluminum recessing tube

Symmetrical PATNOS 5 Fix to Recessing Tube with Screws

180

9 x 350 mA (9 W) LED or 9 x 700 mA (27 W) LED

Warm White Natural White Cool White Blue Red Amber Green

Total Lighting Output 9W 27W 765 lm 1350 lm 3000 K 765 lm 1350 lm 4500 K 918 lm 1620 lm 6000 K

9W Round 164021 164022 164023 164024 164025 164026 164027

9W Square 164031 164032 164033 164034 164035 164036 164037

Voltage

: 240V A.C with integrated driver (24V AC or DC on request)

Lens

: 10º, 25º, 40º

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

134

27W Round 164061 164062 164063 164064 164065 164066 164067

27W Square 164071 164072 164073 164074 164075 164076 164077

Ø 180

180

101

Ø 144

Aluminum recessing tube

PATNOS 5

RECESSED RGB LED FIXTURES Class I IP67 IK10

Symmetrical PATNOS 5 Fix to Recessing Tube with Silicone

150

27 x 350 mA (27 W) RGB LED Voltage

: 240V A.C with remote driver

Lens

: 25º or 40º

Diffuser

: Clear Glass

150

Ø 150

8 mm (Frosted Glass on request) Cable

: Potted 10 m 4x0,75 H03 VV-F

Control by DMX, remote control, or push button

101

Code No Round Square 164081 164091

Ø 144

Aluminum recessing tube

Symmetrical PATNOS 5 Fix to Recessing Tube with Screws

180

27 x 350 mA (27 W) RGB LED Voltage

: 240V A.C with remote driver

Lens

: 25º or 40º

Diffuser

: Clear Glass

Cable

: Potted 10 m 4x0,75 H03 VV-F

Ø 180

180

8 mm (Frosted Glass on request) Control by DMX, remote control, or push button Code No Round Square

101

164101 164111 Ø 144

Aluminum recessing tube 135

PATNOS 5

RECESSED LED FIXTURES Class I IP67 IK10

Asymmetrical 15° Tilted PATNOS 5 Fix to Recessing Tube with Silicone

15°Tilted 9 x 350 mA (9 W) LED or 9 x 700 mA (27 W) LED

Warm White Natural White Cool White Blue Red Amber Green

Total Lighting Output 9W 27W 765 lm 2100 lm 3000 K 765 lm 2100 lm 4500 K 918 lm 2520 lm 6000 K

9W Round 164201 164202 164203 164204 164205 164206 164207

150

9W Square 164211 164212 164213 164214 164215 164216 164217

Voltage

: 240V A.C with integrated driver (24V AC or DC on request)

Lens

: 10º, 25º, 40º

27W Round 164701 164702 164703 164704 164705 164706 164707

27W Square 164711 164712 164713 164714 164715 164716 164717

150

Ø 150

15 100

125

Ø 144

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

Aluminum recessing tube

Asymmetrical 15° Tilted PATNOS 5 Fix to Recessing Tube with Screws

15°Tilted 9 x 350 mA (9 W) LED or 9 x 700 mA (27 W) LED

Warm White Natural White Cool White Blue Red Amber Green

Total Lighting Output 9W 27W 765 lm 2100 lm 3000 K 765 lm 2100 lm 4500 K 918 lm 2520 lm 6000 K

9W Round 164221 164222 164223 164224 164225 164226 164227

180

9W Square 164231 164232 164233 164234 164235 164236 164237

Voltage

: 240V A.C with integrated driver (24V AC or DC on request)

Lens

: 10º, 25º, 40º

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

136

27W Round 164721 164722 164723 164724 164725 164726 164727

27W Square 164731 164732 164733 164734 164735 164736 164737

Ø 180

180

15 100

125

Ø 144

Aluminum recessing tube

PATNOS 5

RECESSED RGB LED FIXTURES Class I IP67 IK10

Asymmetrical 15° Tilted PATNOS 5 Fix to Recessing Tube with Silicone

15°Tilted 150

27 x 350 mA (27 W) RGB LED Voltage

: 240V A.C with remote driver

Lens

: 25º or 40º

Diffuser

: Clear Glass

150

Ø 150

8 mm (Frosted Glass on request) Cable

: Potted 10 m 4x0,75 H03 VV-F 15

Control by DMX, remote control, or push button

100

125

Code No Round Square 164241 164251

Ø 144

Aluminum recessing tube

Asymmetrical 15° Tilted PATNOS 5 Fix to Recessing Tube with Screws

15°Tilted 180

27 x 350 mA (27 W) RGB LED Voltage

: 240V A.C with remote driver

Lens

: 25º or 40º

Diffuser

: Clear Glass

Cable

: Potted 10 m 4x0,75 H03 VV-F

Ø 180

180

8 mm (Frosted Glass on request) Control by DMX, remote control, or push button 15

Code No Round Square

100

125

164261 164271 Ø 144

Aluminum recessing tube 137

PATNOS 5

RECESSED LED FIXTURES Class I IP67 IK10

Asymmetrical 25° Tilted PATNOS 5 Fix to Recessing Tube with Silicone

25°Tilted 9 x 350 mA (9 W) LED or 9 x 700 mA (27 W) LED

Warm White Natural White Cool White Blue Red Amber Green

Total Lighting Output 9W 27W 765 lm 2100 lm 3000 K 765 lm 2100 lm 4500 K 918 lm 2520 lm 6000 K

9W Round 164281 164282 164283 164284 164285 164286 164287

150

9W Square 164291 164292 164293 164294 164295 164296 164297

Voltage

: 240V A.C with integrated driver (24V AC or DC on request)

Lens

: 10º, 25º, 40º

27W Round 164741 164742 164743 164744 164745 164746 164747

27W Square 164751 164752 164753 164754 164755 164756 164757

150

Ø 150

25 100

125

Ø 144

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

Aluminum recessing tube

Asymmetrical 25° Tilted PATNOS 5 Fix to Recessing Tube with Screws

25°Tilted 9 x 350 mA (9 W) LED or 9 x 700 mA (27 W) LED

Warm White Natural White Cool White Blue Red Amber Green

Total Lighting Output 9W 27W 765 lm 2100 lm 3000 K 765 lm 2100 lm 4500 K 918 lm 2520 lm 6000 K

9W Round 164301 164302 164303 164304 164305 164306 164307

180

9W Square 164311 164312 164313 164314 164315 164316 164317

Voltage

: 240V A.C with integrated driver (24V AC or DC on request)

Lens

: 10º, 25º, 40º

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

138

27W Round 164761 164762 164763 164764 164765 164766 164767

27W Square 164771 164772 164773 164774 164775 164776 164777

Ø 180

180

25 100

125

Ø 144

Aluminum recessing tube

PATNOS 5

RECESSED RGB LED FIXTURES Class I IP67 IK10

Asymmetrical 25° Tilted PATNOS 5 Fix to Recessing Tube with Silicone

25°Tilted 150

27 x 350 mA (27 W) RGB LED Voltage

: 240V A.C with remote driver

Lens

: 25º or 40º

Diffuser

: Clear Glass

150

Ø 150

8 mm (Frosted Glass on request) Cable

: Potted 10 m 4x0,75 H03 VV-F 25

Control by DMX, remote control, or push button

100

125

Code No Round Square 164321 164331

Ø 144

Aluminum recessing tube

Asymmetrical 25° Tilted PATNOS 5 Fix to Recessing Tube with Screws

25°Tilted 180

27 x 350 mA (27 W) RGB LED Voltage

: 240V A.C with remote driver

Lens

: 25º or 40º

Diffuser

: Clear Glass

Cable

: Potted 10 m 4x0,75 H03 VV-F

Ø 180

180

8 mm (Frosted Glass on request) Control by DMX, remote control, or push button 25

Code No Round Square

100

125

164341 164351 Ø 144

Aluminum recessing tube 139

PATNOS 5

RECESSED LED FIXTURES Class I IP67 IK10

Asymmetrical Wallwasher PATNOS 5 Fix to Recessing Tube with Silicone

1 x 350 mA (12 W) LED or 1 x 700 mA (25 W) LED 150

Warm White Warm White Natural White

Voltage

Total Lighting Output 12W 25W 2700 K 1005 lm 1848 lm 3000 K 1005 lm 1848 lm 4000 K 1078 lm 1919 lm

12W Round 164801 164802 164803

12W Square 164811 164812 164813

25W Round 164901 164902 164903

25W Square 164911 164912 164913

150

Ø 150

: 240V A.C with integrated driver

100

125

(24V AC or DC on request) Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

Ø 144

Aluminum recessing tube Asymmetrical Wallwasher PATNOS 5 Fix to Recessing Tube with Screws

180

1 x 350 mA (12 W) LED or 1 x 700 mA (25 W) LED

Warm White Warm White Natural White

Voltage

Total Lighting Output 12W 25W 2700 K 1005 lm 1848 lm 3000 K 1005 lm 1848 lm 4000 K 1078 lm 1919 lm

12W Round 164821 164822 164823

12W Square 164831 164832 164833

25W Round 164921 164922 164923

25W Square 164931 164932 164933

Ø 180

180

: 240V A.C with integrated driver (24V AC or DC on request)

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

100

125

Ø 144

Aluminum recessing tube 140

GORDION

RECESSED LED FIXTURES Load 5 kN | Class I IP67 IK08

The Gordion series is an adaption of the Belkis Recessed series without the stainless steel cover. Merely a painted glass finishes the look of the fixture. Once placed inside the stainless steel tube, the fixture can only be removed with a special tool. The Gordion series is designed to light walls, facades, columns, monuments, and trees. The fixtures are made of die cast aluminium body painted with electrostatic powder paint. Tempered glass, silicone gaskets and cast resin complete the fixture to make it IP67 IK10 and withstand rough environments. A specially developed potted power cable is used to effectively bond with the cast resin and stop any water ingress. The LEDs used come in 3 different tones of white, as well as blue, red, green, amber and RGB. Several lenses from 6 to 40 degrees are available to choose from to achieve the desired light effect. Body Die cast aluminium Recessing Tube 316L Stainless steel Gaskets Silicone Diffusers Tempered Glass with painted circumference “Customization” is EMFA’s standard EMFA offers many combinations for each fixture, as all fixtures are made in house. A combination of 2 finishes of stainless steel, 8 LED colors, 2 wattages, and 5 or more lenses and reflectors are available to make the fixture suitable for the required application. This is done without increasing lead-time and is available for large as well as small quantities. Honeycomb Louvre Belkis 1 Belkis 2 Belkis 3 Belkis 4 Belkis 5

Code No 953521 953522 953523 953524 953525

141

GORDION 1

RECESSED LED FIXTURES Class I IP67 IK08

Symmetrical GORDION 1

1 x 350 mA (1 W) LED Warm White Natural White Cool White Blue Red Amber Green

3000 K 4500 K 6000 K

Total Lighting Output Code No 85 lm 170001 85 lm 170002 102 lm 170003 170004 170005 170006 170007

Ø 66

100

Ø 66

Voltage

: 240V A.C with integrated driver (24V AC or DC on request)

Lens

: 10º, 25º, 40º

Diffuser

: Clear Glass with painted circumference 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

Asymmetrical 7º Tilted GORDION 1

7° Tilted 1 x 350 mA (1 W) LED Warm White Natural White Cool White Blue Red Amber Green

3000 K 4500 K 6000 K

Total Lighting Output Code No 85 lm 85 lm 102 lm

170011 170012 170013 170014 170015 170016 170017

Ø 66

7º Ø 100

Ø 66

Voltage

: 240V A.C with integrated driver (24V AC or DC on request)

Lens

: 10º, 25º, 40º

Diffuser

: Clear Glass with painted circumference 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

142

GORDION 2

RECESSED LED FIXTURES Class I IP67 IK08

Symmetrical GORDION 2

3 x 350 mA (3 W) LED Warm White Natural White Cool White Blue Red Amber Green

3000 K 4500 K 6000 K

Total Lighting Output Code No 255 lm 170101 255 lm 170102 306 lm 170103 170104 170105 170106 170107

Ø 82

Ø 85

Ø 82

Voltage

: 240V A.C with integrated driver (24V AC or DC on request)

Lens

: 10º, 25º, 40º

Diffuser

: Clear Glass with painted circumference 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

Asymmetrical 7º Tilted GORDION 2

7° Tilted 3 x 350 mA (3 W) LED Warm White Natural White Cool White Blue Red Amber Green

3000 K 4500 K 6000 K

Total Lighting Output Code No 255 lm 255 lm 306 lm

170111 170112 170113 170114 170115 170116 170117

Ø 82

7º Ø 85

Ø 82

Voltage

: 240V A.C with integrated driver (24V AC or DC on request)

Lens

: 10º, 25º, 40º

Diffuser

: Clear Glass with painted circumference

143

GORDION 2

RECESSED LED FIXTURES Class I IP67 IK08

Asymmetrical 15º Tilted GORDION 2

15°Tilted 3 x 350 mA (3 W) LED Warm White Natural White Cool White Blue Red Amber Green

3000 K 4500 K 6000 K

Total Lighting Output Code No 255 lm 170141 255 lm 170142 306 lm 170143 170144 170145 170146 170147

Ø 104

15º 100

Ø 104

Voltage

: 240V A.C with integrated driver (24V AC or DC on request)

Lens

: 10º, 25º, 40º

Diffuser

: Clear Glass with painted circumference 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

Asymmetrical 25º Tilted GORDION 2

25°Tilted 3 x 350 mA (3 W) LED Warm White Natural White Cool White Blue Red Amber Green

3000 K 4500 K 6000 K

Total Lighting Output Code No 255 lm 255 lm 306 lm

170151 170152 170153 170154 170155 170156 170157

Ø 104

25º 100

Ø 104

Voltage

: 240V A.C with integrated driver (24V AC or DC on request)

Lens

: 10º, 25º, 40º

Diffuser

: Clear Glass with painted circumference

144

GORDION 2

RECESSED RGB LED FIXTURES Class I IP67 IK08

Symmetrical GORDION 2

Voltage

: 240V A.C with remote driver

Lens

: 25º or 40º

Diffuser

: Clear Glass with painted circumference 8 mm

Ø 82

(Frosted Glass on request) Cable

: Potted 10 m 4x0,75 mm H03 VV-F

Control by DMX, remote control, or push button Ø 85

9 x 350 mA (9 W) RGB LED

Code No 170121

Ø 82

Asymmetrical 7º / 15º / 25º Tilted GORDION 2

Voltage

: 240V A.C with remote driver

Lens

: 25º or 40º

Diffuser

: Clear Glass with painted circumference 8 mm

(24V AC or DC on request) Ø 104

Ø 82

Ø 104

(Frosted Glass on request) Cable

: Potted 10 m 4x0,75 mm H03 VV-F

7º

Control by DMX, remote control, or push button 9 x 350 mA (9 W) RGB LED

7º Tilted 170131

15º Tilted 170161

Ø 85

25º Tilted 170171

15º 100

Ø 82

25º 100

Ø 104

145

GORDION 3

RECESSED LED FIXTURES Class I IP67 IK08

Symmetrical GORDION 3

6 x 350 mA (6 W) LED Warm White Natural White Cool White Blue Red Amber Green

3000 K 4500 K 6000 K

Total Lighting Output Code No 510 lm 170201 510 lm 170202 612 lm 170203 170204 170205 170206 170207

Ø 104

100

Ø 104

Voltage

: 240V A.C with integrated driver (24V AC or DC on request)

Lens

: 10º, 25º, 40º

Diffuser

: Clear Glass with painted circumference 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

Asymmetrical 15º Tilted GORDION 3

15° Tilted 6 x 350 mA (6 W) LED Warm White Natural White Cool White Blue Red Amber Green

3000 K 4500 K 6000 K

Total Lighting Output Code No 510 lm 510 lm 612 lm

170211 170212 170213 170214 170215 170216 170217

Voltage

: 240V A.C with integrated driver (24V AC or DC on request)

Lens

: 10º, 25º, 40º

Diffuser

: Clear Glass with painted circumference

146

Ø 125

15º 115

Ø 125

GORDION 3

RECESSED LED FIXTURES Class I IP67 IK08

Asymmetrical 25º Tilted GORDION 3

25° Tilted 6 x 350 mA (6 W) LED Warm White Natural White Cool White Blue Red Amber Green Voltage

3000 K 4500 K 6000 K

Total Lighting Output Code No 420 lm 420 lm 505 lm

170221 170222 170223 170224 170225 170226 170227

Ø 125

25º 115

: 240V A.C with integrated driver (24V AC or DC on request)

Lens

: 10º, 25º, 40º

Diffuser

: Clear Glass with painted circumference 8 mm

Cable

: Potted 5 m 3x0,75 mm H03 VV-F

Ø 125

(Frosted Glass on request)

Four Season's Hotel Bosphorus

147

GORDION 3

RECESSED RGB LED FIXTURES Class I IP67 IK08

Symmetrical GORDION 3

Voltage

: 240V A.C with remote driver

Lens

: 25º, 40º

Diffuser

: Clear Glass with painted circumference 8 mm

Cable

: Potted 10 m 4x0,75 mm H03 VV-F

Ø 104

(Frosted Glass on request) Control by DMX, remote control, or push button 9 x 350 mA (9 W) RGB LED

100

Code No 170231

Ø 104

Asymmetrical 15º / 25º Tilted GORDION 3

Voltage

: 240V A.C with remote driver

Lens

: 25º or 40º

Diffuser

: Clear Glass with painted circumference 8 mm

Ø 125

(Frosted Glass on request) Cable

: Potted 10 m 4x0,75 mm H03 VV-F

Control by DMX, remote control, or push button 9 x 350 mA (9 W) RGB LED

15º 115

15º Tilted 170241

115

25º Tilted 170251 Ø 125

148

25º

Ø 125

GORDION 4

RECESSED LED FIXTURES Class I IP67 IK08

Symmetrical GORDION 4

9 x 350 mA (9 W) LED Warm White Natural White Cool White Blue Red Amber Green

3000 K 4500 K 6000 K

Total Lighting Output Code No 765 lm 170301 765 lm 170302 918 lm 170303 170304 170305 170306 170307

Voltage

: 240V A.C with integrated driver

Lens

: 10º, 25º, 40º

Diffuser

: Clear Glass with painted circumference 8 mm

Ø 125

(24V AC or DC on request)

(Frosted Glass on request) Cable

: Potted 5 m 3x0,75 mm H03 VV-F

149

GORDION 5

RECESSED LED FIXTURES Class I IP67 IK08

Symmetrical GORDION 5

9 x 350 mA (9 W) LED Warm White Natural White Cool White Blue Red Amber Green

3000 K 4500 K 6000 K

Total Lighting Output Code No 765 lm 170401 765 lm 170402 918 lm 170403 170404 170405 170406 170407

Ø 143

100

Ø 143

Voltage

: 240V A.C with integrated driver (24V AC or DC on request)

Lens

: 10º, 25º, 40º

Diffuser

: Clear Glass with painted circumference 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

Asymmetrical 15º Tilted GORDION 5

15° Tilted 9 x 350 mA (9 W) LED Warm White Natural White Cool White Blue Red Amber Green

3000 K 4500 K 6000 K

Total Lighting Output Code No 765 lm 765 lm 918 lm

170411 170412 170413 170414 170415 170416 170417

Voltage

: 240V A.C with integrated driver (24V AC or DC on request)

Lens

: 10º, 25º, 40º

Diffuser

: Clear Glass with painted circumference

150

Ø 143

15º 135

Ø 143

GORDION 5

RECESSED LED FIXTURES Class I IP67 IK08

Asymmetrical 25º Tilted GORDION 5

25° Tilted 9 x 350 mA (9 W) LED Warm White Natural White Cool White Blue Red Amber Green

3000 K 4500 K 6000 K

Total Lighting Output Code No 765 lm 170421 765 lm 170422 918 lm 170423 170424 170425 170426 170427

Voltage

: 240V A.C with integrated driver (24V AC or DC on request)

Lens

: 10º, 25º, 40º

Ø 143

25º 135

Ø 143

Diffuser

: Clear Glass with painted circumference 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

Symmetrical GORDION 5

Voltage

: 240V A.C with remote driver

Lens

: 25º, 40º

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Cable

: Potted 10 m 4x0,75 mm H03 VV-F

Ø 143

Control by DMX, remote control, or push button

27 x 350 mA (27 W) RGB LED

Code No 170431

100

Ø 143

151

152

Wall Recessed

153

154

MILET ANI

WALL RECESSED Class I IP55 IK08

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

EMFA’s Ani wall recessed series is specially designed to deliver low-glare lighting to facades, walkways, pathways and driveways with minimal installation depth and narrow trim. The fixture is made of a combination of 316L stainless steel and die cast aluminium. The tilted design reduces the glare of the LED’s The Linear LEDs with special lenseS gives excellent wallwashing effect. An anti-slip glass is available upon request. Cover 316L Stainless steel or Aluminium Body Die cast aluminium Gaskets Silicone Diffusers 4 mm Tempered Glass Screws 316L Stainless Steel Glands PG 11 “Customization” is EMFA’s standard EMFA offers many combinations for each fixture, as all fixtures are made in house. A combination of 6 standard paint colors, 8 LED colors, and 2 wattages, and available to make the fixture suitable for the required application. This is done without increasing lead-time and is available for large as well as small quantities.

Symmetrical

45º 90º

Asymmetrical

Asym. Glass

Trenched Glass Milky Glass

Clear Glass

55º 45º

155

ANI

INOX WALL RECESSED Class I IP55 IK08

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

Symmetrical Led

: Linear LEDs

Voltage

: 240 VAC with integrated driver

Diffuser

: 4mm Tempered Glass

45º 90º

(12-24 VDC on request) Beam Angle : 45°/ 60°/ 90°

ANI 2 Kelvin 3000 K 3000 K 4000 K 4000 K

ANI 3 Kelvin 3000 K 3000 K 4000 K 4000 K

ANI 4

156

Kelvin 3000 K 3000 K 4000 K 4000 K

154

148

Galvanized Recessing Box

210

154

188

Galvanized Recessing Box

250

180

Power Code No 24W 456301 48W 456311 24W 456302 48W 456312

Nominal Real Lumen Lumen Output Output 1780 lm 2550 lm 3080 lm 4300 lm 2047 lm 2932 lm 3542 lm 5060 lm

170

180

Power Code No 18W 456201 36W 456211 18W 456202 36W 456212

Nominal Real Lumen Lumen Output Output 1200 lm 1700 lm 2300 lm 3300 lm 1380 lm 1955 lm 2645 lm 2932 lm

108

Galvanized Recessing Box

180

Power Code No 12W 456101 24W 456111 12W 456102 24W 456112

Nominal Real Lumen Lumen Output Output 1020 lm 1460 lm 1780 lm 2550 lm 1173 lm 1679 lm 2047 lm 2932 lm

154

Kelvin 3000 K 3000 K 4000 K 4000 K

130

180

Power Code No 6W 456001 12W 456011 6W 456002 12W 456012

Nominal Real Lumen Lumen Output Output 600 lm 850 lm 1020 lm 1460 lm 690 lm 977 lm 1173 lm 1679 lm

ANI 1

154

: %70

: >80

L.O.R %

CRI

Mac Adam

228

Galvanized Recessing Box

ANI

INOX WALL RECESSED Class I IP67 IK08

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

Asymmetrical Led

: Linear LEDs

Voltage

: 240 VAC with integrated driver

Diffuser

: 4mm Tempered Glass

(12-24 VDC on request)

55º 45º

Beam Angle : 45°/ 60°/ 90°

ANI 2 Kelvin 3000 K 3000 K 4000 K 4000 K

ANI 3 Kelvin 3000 K 3000 K 4000 K 4000 K

ANI 4 Kelvin 3000 K 3000 K 4000 K 4000 K

Real Lumen Output 1780 lm 3080 lm 2047 lm 3542 lm

Nominal Lumen Output 2550 lm 4300 lm 2932 lm 5060 lm

Nominal Lumen Output 1700 lm 3300 lm 1955 lm 2932 lm

148

154

Galvanized Recessing Box

210

154

188

Galvanized Recessing Box

250

180

Power Code No 24W 456801 48W 456811 24W 456802 48W 456812

Real Lumen Output 1200 lm 2300 lm 1380 lm 2645 lm

108

170

180

Power Code No 18W 456701 36W 456711 18W 456702 36W 456712

Nominal Lumen Output 1460 lm 2550 lm 1679 lm 2932 lm

154

180

Power Code No 12W 456601 24W 456611 12W 456602 24W 456612

Real Lumen Output 1020 lm 1780 lm 1173 lm 2047 lm

130

Kelvin 3000 K 3000 K 4000 K 4000 K

Nominal Lumen Output 850 lm 1460 lm 977 lm 1679 lm

180

Power Code No 6W 456501 12W 456511 6W 456502 12W 456512

Real Lumen Output 600 lm 1020 lm 690 lm 1173 lm

ANI 1

154

: %64

: 80

L.O.R %

CRI

Mac Adam

228

Galvanized Recessing Box

157

ANI

ALUM WALL RECESSED Class I IP55 IK08

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

Symmetrical Led

: Linear LEDs

Voltage

: 240 VAC with integrated driver

Diffuser

: 4mm Tempered Glass

45º 90º

(12-24 VDC on request) Beam Angle : 45°/ 60°/ 90°

Kelvin 3000 K 3000 K 4000 K 4000 K

ANI 3 Kelvin 3000 K 3000 K 4000 K 4000 K

ANI 4

158

Kelvin 3000 K 3000 K 4000 K 4000 K

129

123

Galvanized Recessing Box

180

129

163

Galvanized Recessing Box

220

180

Power Code No 24W 455301 48W 455311 24W 455302 48W 455312

Nominal Real Lumen Lumen Output Output 1780 lm 2550 lm 3080 lm 4300 lm 2047 lm 2932 lm 3542 lm 5060 lm

140

150

Power Code No 18W 455201 36W 455211 18W 455202 36W 455212

Nominal Real Lumen Lumen Output Output 1200 lm 1700 lm 2300 lm 3300 lm 1380 lm 1955 lm 2645 lm 2932 lm

Galvanized Recessing Box

150

Power Code No 12W 455101 24W 455111 12W 455102 24W 455112

Nominal Real Lumen Lumen Output Output 1020 lm 1460 lm 1780 lm 2550 lm 1173 lm 1679 lm 2047 lm 2932 lm

ANI 2

129

Kelvin 3000 K 3000 K 4000 K 4000 K

100

150

Power Code No 6W 455001 12W 455011 6W 455002 12W 455012

Nominal Real Lumen Lumen Output Output 600 lm 850 lm 1020 lm 1460 lm 690 lm 977 lm 1173 lm 1679 lm

ANI 1

: %70

: >80

L.O.R %

CRI

Mac Adam

129

203

Galvanized Recessing Box

ANI

ALUM WALL RECESSED Class I IP55 IK08

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

Asymmetrical Led

: Linear LEDs

Voltage

: 240 VAC with integrated driver

Diffuser

: 4mm Tempered Glass

(12-24 VDC on request)

55º 45º

Beam Angle : 45°/ 60°/ 90°

Kelvin 3000 K 3000 K 4000 K 4000 K

ANI 3 Kelvin 3000 K 3000 K 4000 K 4000 K

ANI 4 Kelvin 3000 K 3000 K 4000 K 4000 K

Nominal Lumen Output 1700 lm 3300 lm 1955 lm 2932 lm

Real Lumen Output 1780 lm 3080 lm 2047 lm 3542 lm

Nominal Lumen Output 2550 lm 4300 lm 2932 lm 5060 lm

123

129

Galvanized Recessing Box

180

163

129

Galvanized Recessing Box

220

180

Power Code No 24W 455801 48W 455811 24W 455802 48W 455812

Real Lumen Output 1200 lm 2300 lm 1380 lm 2645 lm

140

150

Power Code No 18W 455701 36W 455711 18W 455702 36W 455712

Nominal Lumen Output 1460 lm 2550 lm 1679 lm 2932 lm

150

Power Code No 12W 455601 24W 455611 12W 455602 24W 455612

Real Lumen Output 1020 lm 1780 lm 1173 lm 2047 lm

129

ANI 2

100

129

Kelvin 3000 K 3000 K 4000 K 4000 K

Nominal Lumen Output 850 lm 1460 lm 977 lm 1679 lm

150

Power Code No 6W 455501 12W 455511 6W 455502 12W 455512

Real Lumen Output 600 lm 1020 lm 690 lm 1173 lm

ANI 1

: %64

: 80

L.O.R %

CRI

Mac Adam

203

Galvanized Recessing Box

159

SANTOS 6

WALL RECESSED FIXTURES Class I IP67 IK10

EMFA’s Santos 6 Wall Recessed Fixture is specially designed to deliver glare-free lighting in open areas and pathways. The combination of the ribbed glass, which creates a horizontal elliptical light output and the lamp cover, which hides the source of light, allows for an unobtrusive comfortable lighting effect. The fixture is made of a combination of 316L stainless steel and aluminium. The narrow depth of 159 mm allows the fixture to be installed in most walls. The electronic ballast is housed in the thermally separated base of the fixture.

Cover 316L Stainless steel Body Die cast aluminium or aluminium profile with die cast aluminium bottom and connection box. Gaskets Silicone Diffusers 5 mm ribbed tempered Glass Screws 316L Stainless steel Glands 2 x PG 13.5 Recessing Tube Polyamide 6

Correct

Incorrect

160

When mounting the fixture on uneven surfaces, place so that the water does not accumulate on the surface of the fixture.

SANTOS 6

WALL RECESSED FIXTURES Class I IP67 IK10

12W LED - 350 mA Voltage

: 240V AC with integrated driver (12V DC or 24V DC on request)

Reflector

: -

Temp

: 45ºC

Warm White

3000 K

Code No Round Square

Ø 220

552121 552221

Natural White

4000 K

Code No Round Square 552122 552222 158,5

HALOGEN PAR 30 75W Lampholder : E27 Reflector : Temp : 129ºC

Code No Round Square

Ø 220

552101 552201

158,5

METAL HALIDE 20W Lampholder : G 8.5 Reflector : 36º Temp : 63ºC, 100ºC

Code No Round Square

Ø 220

552111 552211

159

161

MIRA 1

RECESSED LED FIXTURES Load 20 kN | Class II IP67 IK10

Asymmetrical

12 x 350 mA (12 W) LED Voltage

6x25

: 240V A.C with integrated driver (24V AC or DC on request)

Lens

: 25º, 6x25º

Diffuser

: Clear Glass 12 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

Warm White Natural White Cool White Blue Red Amber Green

3000 K 4500 K 6000 K

90 20º

400

Total Lighting Output Code No 1020 lm 430371 1020 lm 430372 1224 lm 430373 430374 430375 430376 430377

365

100

65 370

Stainless Steel Recessing Box Voltage

: 240V A.C with remote driver

Lens

: 25º, 6x25º

Diffuser

: Clear Glass 12 mm (Frosted Glass on request)

Cable

: Potted 10 m 4x0,75 H03 VV-F

27 x 350 mA (27 W) RGB LED RGB

162

Code No 430381

163

BELKIS 3

WALL RECESSED LED FIXTURES Class II IP67 IK10

Fix to Recessing Tube with Silicone

115

250 mA (7 W) LED Voltage

: 240V A.C with integrated driver

Ø 115

115

(24V AC or DC on request) Diffuser

: Rillen Glass

Cable

: Potted 5 m 3x0,75 H03 VV-F 101

Warm White Natural White

3000 K 4000 K

Code No Round Square 423261 423281 423262 423282

Ø 108

Aluminum recessing tube

Fix to Recessing Tube with Screws

140

250 mA (7 W) LED Voltage

: 240V A.C with integrated driver

Diffuser

: Rillen Glass

Cable

: Potted 5 m 3x0,75 H03 VV-F

Ø 140

140

(24V AC or DC on request)

Warm White Natural White

164

3000 K 4000 K

Code No Round Square 423271 423291 423272 423292

101

Ø 108

Aluminum recessing tube

BELKIS 4

WALL RECESSED LED FIXTURES Class II IP67 IK10

Fix to Recessing Tube with Silicone

135

320 mA (11 W) LED Voltage

: 240V A.C with integrated driver (24V AC or DC on request)

Diffuser

: Rillen Glass

Cable

: Potted 5 m 3x0,75 H03 VV-F

Warm White Natural White

3000 K 4000 K

Ø 135

135

Code No Round Square 423901 423921 423902 423922

115

Ø 126

Aluminum recessing tube

Fix to Recessing Tube with Screws

160

320 mA (11 W) LED Voltage

: 240V A.C with integrated driver

Ø 160

160

(24V AC or DC on request) Diffuser

: Rillen Glass

Cable

: Potted 5 m 3x0,75 H03 VV-F

Warm White Natural White

3000 K 4000 K

Code No Round Square 423911 423931 423912 423932

115

Ø 126

Aluminum recessing tube

165

MILET

WALL RECESSED FIXTURES IP55 IK08

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

The Milet Recessed Wall Series is specially designed to deliver low glare halogen lighting to steps, open areas, corridors and pathways. The fixture has a die cast aluminium body painted with electrostatic powder paint. The slated or open covers come in an aluminium or aluminium / stainless steel finish. A polycarbonate recessing box is included for installation into concrete. The cable on site can be securely connected to the fixture via a PG9 cable gland.

Cover Die cast aluminium / Inox (Stainless steel) Paint Black or grey electrostatic powder Body Die cast aluminium Recessing Box Polycarbonate Glands 1 X PG 9 Gaskets Silicone Diffusers 4 mm Tempered Glass

166

143

MILET 1

WALL RECESSED FIXTURES IP55 IK10

Lampholder : G4 Reflector

: -

Diffuser

: Clear Glass

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

Ø 127

136 19

85 136 80

Recessing Box

CLASS III HALOGEN 12V 10-20W Alum Stainless Steel

Code No 301101 305101

Lampholder : Gu 5.3 Reflector

: -

Diffuser

: Clear Glass

Ø 127

136 19

85 136 80

Recessing Box

CLASS III HALOGEN 12V 35W Alum Stainless Steel

Code No 301111 305111

Lampholder : G9 Reflector

: 40º

Diffuser

: Clear Glass

Ø 127

136 19

115 136

CLASS I

Recessing Box

HALOGEN 240V 40W Alum Stainless Steel

Code No 301121 305121

Lampholder : Gu 10 Reflector

: -

Diffuser

: Clear Glass

19 115 136

CLASS I HALOGEN 240V 50W Alum Stainless Steel

Ø 127

136

Recessing Box Code No 301131 305131

167

MILET 2

WALL RECESSED FIXTURES IP55 IK10

Lampholder : G4 Reflector

: -

Diffuser

: Clear Glass

Available in any of these RAL colors

7004

9005

9016

6002

1015

Ø 127

136 14

80 136

Recessing Box

CLASS III HALOGEN 12V 10-20W Alum Stainless Steel

Code No 302101 306101

Lampholder : Gu 5.3 Reflector

: -

Diffuser

: Clear Glass

Ø 127

136 14

80 136

Recessing Box

CLASS III HALOGEN 12V 35W Alum Stainless Steel

Code No 302111 306111

Lampholder : G9 Reflector

: 40º

Diffuser

: Clear Glass

Ø 127

136 14

110 136

CLASS I

Recessing Box

HALOGEN 240V 40W Alum Stainless Steel

Code No 302121 306121

Lampholder : Gu 10 Reflector

: -

Diffuser

: Clear Glass

HALOGEN 240V 50W Alum Stainless Steel

Ø 127

136 14

110 136

CLASS I

168

7016

Recessing Box Code No 302131 306131

MILET 3

WALL RECESSED FIXTURES IP55 IK10

Available in any of these RAL colors

7004

Lampholder : G4 Reflector

: -

Diffuser

: Clear Glass

7016

9005

9016

6002

1015

Ø 127 19 136

85 80

Recessing Box

CLASS III HALOGEN 12V 10-20W Alum Stainless Steel

Code No 303101 307101

Lampholder : Gu 5.3 Reflector

: -

Diffuser

: Clear Glass

Ø 127 19 136

85 80

Recessing Box

CLASS III HALOGEN 12V 35W Alum Stainless Steel

Code No 303111 307111

Lampholder : G9 Reflector

: 40º

Diffuser

: Clear Glass

Ø 127 136

19 115

CLASS I

Recessing Box

HALOGEN 240V 40W Alum Stainless Steel

Code No 303121 307121

Lampholder : Gu 10 Reflector

: -

Diffuser

: Clear Glass

Ø 127 136

115

CLASS I HALOGEN 240V 50W Alum Stainless Steel

Recessing Box Code No 303131 307131

169

MILET 4

WALL RECESSED FIXTURES IP55 IK08

Available in any of these RAL colors

7004

Lampholder : G4 Reflector

: -

Diffuser

: Clear Glass

9005

9016

6002

1015

Ø 127 14 136

80 80

Recessing Box

CLASS III HALOGEN 12V 10-20W Alum Stainless Steel

Code No 304101 308101

Lampholder : Gu 5.3 Reflector

: -

Diffuser

: Clear Glass

Ø 127 14 136

80 80

Recessing Box

CLASS III HALOGEN 12V 35W Alum Stainless Steel

Code No 304111 308111

Lampholder : G9 Reflector

: 40º

Diffuser

: Clear Glass

Ø 127 14 136 110

CLASS I

Recessing Box

HALOGEN 240V 40W Alum Stainless Steel

Code No 304121 308121

Lampholder : Gu 10 Reflector

: -

Diffuser

: Clear Glass

Ø 127 14 136 110

CLASS I HALOGEN 240V 50W Alum Stainless Steel

170

7016

Recessing Box Code No 304131 308131

BELKIS 1 LLA

RECESSED LED FIXTURES Class I IP65 IK08

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

The Belkis 1 LLA is specially designed to deliver low glare LED lighting to steps, open areas, corridors and pathways. The fixture has a die cast aluminium body painted with electrostatic powder paint. The narrow depth of 39mm, which also includes the LED driver, allows the fixture to be installed in any wall. A plastic recessing box is included for installation into concrete. A specially developed potted power cable is used to effectively bond with the cast resin and stop any water ingress. The linear LED used comes in 2 different tones of white, 3000K and 4000K.

Body Die cast aluminium Paint Electrostatic powder Diffusers Tempered Glass Gaskets Silicone

Asymmetrical

Voltage

: 240V AC with integrated driver

Diffuser

: Clear Glass 4 mm

Cable

: Potted 5 m 3x0,75 H03 VV-F

(12V DC or 24V DC on request)

1 x 350 mA (4 W) LED Warm White Natural White

3000 K 4000 K

Total Lighting Output Code No 92 lm 424101 107 lm 424102

ALUM

46 39

Plastic Recessing Box for Concrete

171

BELKIS 1 LLS

RECESSED LED FIXTURES Class I IP65 IK08

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

Symmetrical With Milky Glass

Voltage

: 240V AC with integrated driver

Diffuser

: Clear Glass 4 mm

Cable

: Potted 5 m 3x0,75 H03 VV-F

(12V DC or 24V DC on request)

1 x 350 mA (4 W) LED Warm White Natural White

3000 K 4000 K

ALUM

Plastic Recessing Box for Concrete

Total Lighting Output Code No 128 lm 424111 148 lm 424112

Symmetrical With Anti-Glare Glass or Clear Glass

Voltage

: 240V AC with integrated driver (12V DC or 24V DC on request)

Diffuser

: Clear Glass 4 mm

Cable

: Potted 5 m 3x0,75 H03 VV-F

Symmetrical With Anti-Glare Glass 1 x 350 mA (4 W) LED Warm White Natural White

3000 K 4000 K

Total Lighting Output Code No 255 lm 424121 295 lm 424122

Symmetrical With Clear Glass 1 x 350 mA (4 W) LED Warm White Natural White

172

3000 K 4000 K

Total Lighting Output Code No 255 lm 424131 295 lm 424132

ALUM

46 39

Plastic Recessing Box for Concrete

SATURN

WALL RECESSED LED FIXTURES Class I IP44 IK08

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

The Saturn is specially designed to deliver low glare LED lighting to steps, open areas, corridors and pathways. The fixture has a die cast aluminium body painted with electrostatic powder paint. The narrow depth of 25mm, which also includes the LED driver, allows the fixture to be installed in any wall. A plastic recessing box is included for installation into concrete. A specially developed potted power cable is used to effectively bond with the cast resin and stop any water ingress. The COB LED used comes in 2 different tones of white, 3000K and 4000K. Body Die cast aluminium Paint Electrostatic powder Diffusers Tempered Glass Gaskets Silicone Voltage

: 240V

Diffuser

: Clear, Frosted And Milky Glass 4 mm

Cable

: Potted 5 m 3x0,75 H03 VV-F

Asymmetrical

3W COB LED Warm White 3000 K Natural White 4000 K

Total Lighting Output Code No 285 lm 527001 313 lm 527002

Ø80

41 Ø70

Plastic Recessing Box for Concrete

Symmetrical With Frosted Glass or Milky Glass

Symmetrical With Frosted Glass 3W COB LED Warm White 3000 K Natural White 4000 K

Total Lighting Output Code No 245 lm 527101 295 lm 527102

Symmetrical With Milky Glass 3W COB LED Warm White 3000 K Natural White 4000 K

Total Lighting Output Code No 195 lm 527201 210 lm 527202

Ø80

25 41 Ø70

Plastic Recessing Box for Concrete

173

BERGAMA Body Steel or Inox (Stainless Steel) Paint Electrostatic powder Reflector Anodized aluminium Recessing Box Galvanized steel (only for in wall series) Diffuser 4 mm Clear Glass

174

RECESSED INDOOR FIXTURES IP20 IK06

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

BERGAMA

WALL RECESSED LED FIXTURES Class II IP67

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

BERGAMA LED 140 X 70

Voltage

: 240V A.C with integrated driver

(24V AC or DC on request) Cable

: Potted 5 m 3x0,75 H03 VV-F

140

128 85

Plastic Recessing Box for Concrete Steel 1 x 350 mA (1x1 W) LINEAR LED Warm White

3000 K

Total Lighting Code No Output 350 lm

349001

Inox 1 x 350 mA (1x1 W) LINEAR LED Warm White

Total Lighting Code No Output

3000 K

700 lm

349011

BERGAMA LED 70 X 140

Voltage

: 240V A.C with integrated driver

140

(24V AC or DC on request) Cable

: Potted 5 m 3x0,75 H03 VV-F

70 128

Plastic Recessing Box for Concrete Steel 2 x 350 mA (2x1 W) LINEAR LED Warm White

3000 K

Total Lighting Code No Output 700 lm

349021

Inox 2 x 350 mA (2x1 W) LINEAR LED Warm White

3000 K

Total Lighting Code No Output 700 lm

349031

175

BERGAMA

RECESSED INDOOR SYMMETRICAL FIXTURES IP20 IK06 Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

BERGAMA LED 80 X 80

SERIES 101 : IN WALL

SERIES 201 : IN FALSE CEILING

68 85 85

70x70

80 x 80 SQUARE

80 x 80 ROUND

80 x 80 CROSS

Lampholder : Gu 5.3

Reflector

: Symmetrical

Reflector

: Symmetrical

Reflector

: Symmetrical

Diffuser

: Clear Glass

Diffuser

: Clear Glass

Diffuser

: Clear Glass

Transformer is not included.

Remote transformer should be used.

Class III

HALOGEN 12V 50W Serie 101 Serie 201

Code No 350101 370101

HALOGEN 12V 50W Serie 101 Serie 201

Code No 350201 370201

HALOGEN 12V 50W Serie 101 Serie 201

Lampholder : G9

Reflector

: Symmetrical

Reflector

: Symmetrical

Reflector

: Symmetrical

Diffuser

: Clear Glass

Diffuser

: Clear Glass

Diffuser

: Clear Glass

Class I

Class I HALOGEN 240V 25W Serie 101 Serie 201

Code No 350111 370111

Class I

HALOGEN 240V 25W Serie 101 Serie 201

Code No 350211 370211

HALOGEN 240V 25W Serie 101 Serie 201

Lampholder : Gu10

Reflector

: Symmetrical

Reflector

: Symmetrical

Reflector

: Symmetrical

Diffuser

: Clear Glass

Diffuser

: Clear Glass

Diffuser

: Clear Glass

Class I

HALOGEN 240V 50W

Serie 101 Serie 201

176

Code No 350121 370121

Serie 101 Serie 201

Code No 350301 370301

Code No 350311 370311

Class I Code No 350221 370221

HALOGEN 240V 50W Serie 101 Serie 201

Code No 350321 370321

BERGAMA

RECESSED INDOOR ASYMMETRICAL FIXTURES IP20 IK06 Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

BERGAMA LED 140 X 70

Lampholder : Gu4

Lampholder : G9

Reflector

: Asymmetrical

Reflector

: Asymmetrical

Diffuser

: Clear Glass

Diffuser

: Clear Glass

Transformer is not included.

BERGAMA 140x70

SERIES 102 : IN WALL

Class I

140 70

Remote transformer should be used.

128 85

Class III HALOGEN 12V 20W Serie 102 Serie 202

Code No 355111 375111

SERIES 202 : IN FALSE CEILING

HALOGEN 240V 25W

Code No 355101 375101

Serie 102 Serie 202

60x130

130

BERGAMA LED 70 X 140

Lampholder : G9 Reflector

: Asymmetrical

Diffuser

: Clear Glass

SERIES 102 : IN WALL 140

58 40

Class I

27 13

70 128

HALOGEN 240V 25W Serie 102 Serie 202

Code No 355201 375201

SERIES 202 : IN FALSE CEILING

73 60x130

177

BERGAMA

RECESSED INDOOR ASYMMETRICAL FIXTURES Class I IP20 IK06 Available in any of these RAL colors

SERIES 103 : IN WALL

7004

7016

9005

9016

6002

1015

SERIES 203 : IN FALSE CEILING

128 73 278 128

178 130x130 130x180 130x280

140

290

190

140

BERGAMA 140 x 140

140

BERGAMA 140 x 190

140

Lampholder : R7 s

Reflector

: Asymmetrical

Reflector

: Asymmetrical

Reflector

: Asymmetrical

Diffuser

: Clear Glass

Diffuser

: Clear Glass

Diffuser

: Clear Glass

HALOGEN LINEAR 60W Serie 103 Serie 203

Code No 352101 372101

HALOGEN LINEAR 150W Serie 103 Serie 203

Code No 352201 372201

HALOGEN LINEAR 150W Serie 103 Serie 203

Lampholder : G9

Lampholder : G23

Reflector

: Asymmetrical

Reflector

: Asymmetrical

Reflector

: Asymmetrical

Diffuser

: Clear Glass

Diffuser

: Clear Glass

Diffuser

: Clear Glass

HALOGEN 40W Serie 103 Serie 203

Code No 352111 372111

HALOGEN 7W Serie 103 Serie 203

Code No 352211 372211

HALOGEN 11W Serie 103 Serie 203

Lampholder : G24 d-1

Lampholder : G24 d-2

Lampholder : G24 d-3

Reflector

: Asymmetrical

Reflector

: Asymmetrical

Reflector

: Asymmetrical

Diffuser

: Clear Glass

Diffuser

: Clear Glass

Diffuser

: Clear Glass

Transformer : Included

Transformer : Included COMPACT FLUO. 10W Serie 103 Serie 203

178

Code No 352121 372121

COMPACT FLUO. 18W Serie 103 Serie 203

BERGAMA 140 x 290

Code No 352301 372301

Code No 352311 372311

Transformer : Included Code No 352221 372221

COMPACT FLUO. 26W Serie 103 Serie 203

Code No 352321 372321

BERGAMA

RECESSED INDOOR SYMMETRICAL FIXTURES IP20 IK06 Available in any of these RAL colors

SERIES 104 : IN WALL

7004

7016

9005

9016

6002

1015

SERIES 204 : IN FALSE CEILING

128 73 238 128

188 130x130 190x190 240x240

250 200 140 250

200 140

BERGAMA 140 x 140

BERGAMA 200 x 200

BERGAMA 250 x 250

Lampholder : R7 s

Reflector

: Symmetrical

Reflector

: Symmetrical

Reflector

: Symmetrical

Diffuser

: Frosted Glass

Diffuser

: Frosted Glass

Diffuser

: Frosted Glass

HALOGEN LINEAR 60W Serie 104 Serie 204

Code No 353101 373101

HALOGEN LINEAR 150W Serie 104 Serie 204

Code No 353201 373201

HALOGEN LINEAR 150W Serie 104 Serie 204

Lampholder : G9

Lampholder : G23

Reflector

: Symmetrical

Reflector

: Symmetrical

Reflector

: Symmetrical

Diffuser

: Frosted Glass

Diffuser

: Frosted Glass

Diffuser

: Frosted Glass

HALOGEN 40W Serie 104 Serie 204

Transformer : Included Code No 353111 373111

COMPACT FLUO. 7W Serie 104 Serie 204

Transformer : Included Code No 353211 373211

COMPACT FLUO. 11W Serie 104 Serie 204

Lampholder : G24 d-1

Lampholder : G24 d-2

Lampholder : G24 d-3

Reflector

: Asymmetrical

Reflector

: Asymmetrical

Reflector

: Asymmetrical

Diffuser

: Clear Glass

Diffuser

: Clear Glass

Diffuser

: Clear Glass

Transformer : Included COMPACT FLUO. 10W Serie 104 Serie 204

COMPACT FLUO. 18W Serie 104 Serie 204

Code No 353311 373311

Transformer : Included

Transformer : Included Code No 353121 373121

Code No 353301 373301

Code No 353221 373221

COMPACT FLUO. 26W Serie 104 Serie 204

Code No 353321 373321

179

BERGAMA

RECESSED INDOOR ASYMMETRICAL FIXTURES IP20 IK06 Available in any of these RAL colors

SERIES 105 : IN WALL

7004

7016

9005

9016

6002

1015

SERIES 205 : IN FALSE CEILING

278 178

228

60x180 60x230 60x280

85 13 44 13 13 44 13 13 70 13

147 127 290

87 240 190 90 13

130

100

BERGAMA 190 x 70

BERGAMA 240 x 70

BERGAMA 290 x 70

Lampholder : G9

Reflector

: Asymmetrical

Reflector

: Asymmetrical

Reflector

: Asymmetrical

Diffuser

: Clear Glass

Diffuser

: Clear Glass

Diffuser

: Clear Glass

HALOGEN 240V 25W Serie 105 Serie 205

Code No 356101 376101

HALOGEN 240V 25W Serie 105 Serie 205

Code No 356201 376201

HALOGEN 240V 25W Serie 105 Serie 205

Lampholder : E14

Reflector

: Asymmetrical

Reflector

: Asymmetrical

Reflector

: Asymmetrical

Diffuser

: Clear Glass

Diffuser

: Clear Glass

Diffuser

: Clear Glass

INCANDESCENT 15W Serie 105 Serie 205

180

Code No 356111 376111

INCANDESCENT 25W Serie 105 Serie 205

Code No 356211 376211

INCANDESCENT 40W Serie 105 Serie 205

Code No 356301 376301

Code No 356311 376311

BERGAMA

RECESSED INDOOR SYMMETRICAL FIXTURES IP20 IK06 Available in any of these RAL colors

SERIES 106 : IN WALL

7004

7016

9005

9016

6002

1015

SERIES 206 : IN FALSE CEILING

73 128

178 278 130x130 130x180 130x280

140

190

BERGAMA 70 x 140

290

BERGAMA 70 x 190

BERGAMA 70 x 290

Lampholder : G9

Lampholder : R7 s

Reflector

: Symmetrical

Reflector

: Symmetrical

Reflector

: Symmetrical

Diffuser

: Frosted Glass

Diffuser

: Frosted Glass

Diffuser

: Frosted Glass

HALOGEN 240V 25W Serie 106 Serie 206

Code No 357101 377101

HALOGEN LINEAR 60W Serie 106 Serie 206

Code No 357201 377201

HALOGEN LINEAR 150W Serie 106 Serie 206

Lampholder : G24 d-1

Lampholder : G23

Reflector

: Symmetrical

Reflector

: Symmetrical

Reflector

: Symmetrical

Diffuser

: Frosted Glass

Diffuser

: Frosted Glass

Diffuser

: Frosted Glass

Transformer : Included COMPACT FLUO. 10W Serie 106 Serie 206

Transformer : Included Code No 357121 377121

COMPACT FLUO. 7W Serie 106 Serie 206

Transformer : Included Code No 357221 377221

COMPACT FLUO. 11W Serie 106 Serie 206

Lampholder : G24 d-2

Lampholder : G24 d-3

Reflector

: Symmetrical

Reflector

: Symmetrical

Diffuser

: Frosted Glass

Diffuser

: Frosted Glass

Transformer : Included COMPACT FLUO. 18W Serie 106 Serie 206

Code No 357301 377301

Code No 357321 377321

Transformer : Included Code No 357231 377231

COMPACT FLUO. 26W Serie 106 Serie 206

Code No 357331 377331

181

DYO

WALL RECESSED INDOOR FIXTURES Class III IP20 IK06

Outer Frame & Body Anodized aluminium Recessing Box Galvanized steel Diffuser Glass Symmetrical

HALOGEN 12V 20W 78

DYO 69 14 K

DYO 69 14 A

DYO 69 14 R

Lampholder : G4

Reflector

: -

Reflector

: -

Reflector

: -

Diffuser

: Frosted Glass

Diffuser

: Frosted Glass

Diffuser

: Frosted Glass

Recessing Box Code No 132201

Code No 132101

Asymmetrical

HALOGEN 12V 20W 78

DYO 69 14 S Lampholder : G4 Reflector

: Asymmetrical

Diffuser

: Clear Glass

Code No 132401 182

Code No 132301

PYRAMID

RECESSED FIXTURES Class II IP55 IK08

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

Cover & Body Glass reinforsed polyester Screws Inox Gasket Silicone Glass Tempered Recessing Box Galvanized steel

Voltage

: 240V A.C with integrated driver

(24V AC or DC on request) Cable

275

: Potted 5 m 3x0,75 H03 VV-F

110

Total 2 x 350 mA (2x3 W) LINEAR LED Lighting Code No Output Warm White

3000 K

Lampholder: G24 d-2 1 x FLUO. 18W

700 lm

245

250

81,5

Recessing Box

501201 Lampholder: G24 d-3

Code No 501101

280

274

1 x FLUO. 26W

Lampholder: G8.5 Code No 501111

1 x METAL HALIDE 35W

Code No 501121

PYRAGLASS

Lampholder: G24 d-1 3 x FLUO. 9W

Lampholder: G24 d-2 Code No 502101

2 x FLUO. 18W

Code No 502111

275

110

Lampholder: G24 d-3 2 x FLUO. 26W

280

274

245

81,5

250

Recessing Box Code No 502121

183

SLIM PYRAMID

RECESSED FIXTURES Class II IP55 IK08

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

Cover & Body Glass reinforsed polyester Screws Inox Gasket Silicone Glass Tempered Recessing Box Galvanized steel (for recessed types only) Symmetrical

Lampholder : G24 d-3 Diffuser

245

110

: Frosted Glass

114

120

117

Flat 1 x FLUO 26W

Code No 503101

81,5

250

Recessing Box

Asymmetrical

Lampholder : G24 d-3 Diffuser

: Frosted Glass

114

130

117

Slated 1 x FLUO 26W

Code No 503201

81,5

260

Recessing Box

Lampholder : G24 d-3 Diffuser

245 110

: Frosted Glass

130

114

Asymmetrical 1 x FLUO 26W

184

117

Code No 503301

Recessing Box

81,5

260

SIDE

RECESSED DIE CAST ALUMINIUM BULKHEADS Class I IP65 IK08

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

Body Die Cast Aluminium Cover Die Cast Aluminium Paint Electrostatic powder paint Diffuser Pressed glass or polycarbonate

SIDE 4

SIDE 6

SIDE 4 Lampholder: E27 INCANDESCENT 75W Glass Diffuser

Code No 510101

Lampholder: G24 d-2 FLUO. 18W Glass Diffuser

Code No 510121

P.C. Diffuser

510201

P.C. Diffuser

510221

Ø 271

Ø 226

SIDE 6 Lampholder: E27 INCANDESCENT 75W Glass Diffuser

Code No 512101

Lampholder: G24 d-2 FLUO. 18W Glass Diffuser

Code No 512121

P.C. Diffuser

512201

P.C. Diffuser

512221

Lampholder: E27 INCANDESCENT 75W Glass Diffuser

Code No 511101

Lampholder: G24 d-2 FLUO. 18W Glass Diffuser

Code No 511121

P.C. Diffuser

511201

P.C. Diffuser

511221

SIDE 5

SIDE 5 Ø 271

Ø 226

185

PERGE

RECESSED DIE CAST ALUMINIUM BULKHEADS Class I IP65 IK08

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

Body Die Cast Aluminium Cover Die Cast Aluminium Paint Electrostatic powder paint Diffuser Pressed glass or polycarbonate

PERGE 4

PERGE 6

PERGE 4 Lampholder: E27 INCANDESCENT 75W Glass Diffuser P.C. Diffuser

Code No 520101

Lampholder: G24 d-2 FLUO. 18W Glass Diffuser

Code No 520121

520201

P.C. Diffuser

520221

226

271

PERGE 6 Code No 522101

Lampholder: G24 d-2 FLUO. 18W Glass Diffuser

Code No 522121

522201

P.C. Diffuser

522221

Lampholder: E27 INCANDESCENT 75W Glass Diffuser

Code No 521101

Lampholder: G24 d-2 FLUO. 18W Glass Diffuser

Code No 521121

P.C. Diffuser

521201

P.C. Diffuser

521221

Lampholder: E27 INCANDESCENT 75W Glass Diffuser P.C. Diffuser PERGE 5

PERGE 5 226

271

186

Surface Mounted

187

KNIDOS

SURFACE MOUNTED FIXTURES Class I IP67 IK10

The Knidos Surface Mounted Uplighter, completely made of 316L stainless steel is ideal for areas where corrosive agents such as salt water or fertilizers would harm aluminium fixtures. The fixture can be mounted without harm to any surface and therefore is ideal for protected and historical sites where mounting recessed fixtures is not permitted. Cover 316L Stainless steel Outer Body 316L Stainless steel Inner Body Glass reinforced polyester Diffusers 12 mm Tempered Glass Gaskets Silicone Screws 316L Stainless Steel

Suitable for Historical Sites

45º

9 x 350 mA (9 W) LED Voltage

: 240V AC with integrated driver (24V AC or DC on request)

Ø 350 350

Lens

: 10º, 25º, 40º

Diffuser

: 12 mm Clear Glass (Frosted Glass on request)

9 x 350 mA (9 W) LED Warm White Natural White Cool White Blue Red Amber Green

3000 K 4500 K 6000 K

Total Lighting Output Code No 765 lm 257241 765 lm 257242 918 lm 257243 257244 257245 257246 257247

METAL HALIDE 35W / 70W

Lampholder Reflector Diffuser Temp

Wall Washer

188

: Rx 7s-24 : Asymmetric 50º : Clear Glass : 176ºC Code No 257211

: G12 : 30º or 42º : Clear Glass : 173ºC

Adjustable Spotlighter

Code No 257231

KNIDOS

ASYMMETRICAL SURFACE MOUNTED FIXTURES Class I IP67 IK10

10° TILTED

Voltage

: 240V AC with integrated driver

Lens

: 10º, 25º, 40º

Diffuser

: 12 mm Clear Glass (Frosted Glass on request)

(24V AC or DC on request)

Warm White Natural White Cool White Blue Red Amber Green

3000 K 4500 K 6000 K

Ø 370

300

LED power 9 x 350 mA (9 W)

EMFA

Ø 497

Total Lighting Output Code No 765 lm 256301 765 lm 256302 918 lm 256303 256304 256305 256306 256307

METAL HALIDE 35W / 70W

Lampholder Reflector Diffuser Temp

Wall Washer

388

9 x 350 mA (9 W) LED

: Rx 7s-24 : Asymmetric 50º : Clear Glass : 176ºC Code No 256311

: G12 : 30º or 42º : Clear Glass : 173ºC

Adjustable Spotlighter

Code No 256321

189

BELKIS 5

SURFACE MOUNTED FIXTURES Class I IP67 IK10

The Belkis Surface Mounted Uplighter, completely made of 316L stainless steel is ideal for areas where corrosive agents such as salt water or fertilizers would harm aluminium fixtures. The fixture can be mounted without harm to any surface and therefore is ideal for protected and historical sites where mounting recessed fixtures is not permitted. Cover 316L Stainless steel Outer Body 316L Stainless steel Inner Body Die cast aluminium Diffusers 8 mm Tempered Glass Gaskets Silicone Screws 316L Stainless Steel

12W or 25W LED Voltage

Ø180

: 240V AC with integrated driver (24V AC or DC on request)

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

Ø206

127

Ø206

1 x 350 mA (12 W) LED Warm White Warm White Natural White

190

2700 K 3000 K 4000 K

Total Code No Lighting Output Round Square 1005 lm 333001 333011 1005 lm 333002 333012 1078 lm 333003 333013

1 x 700 mA (25 W) LED Warm White Warm White Natural White

2700 K 3000 K 4000 K

Total Code No Lighting Output Round Square 1848 lm 333021 333031 1848 lm 333022 333032 1919 lm 333023 333033

TEOS

SURFACE MOUNTED DRIVE OVER FIXTURES Load 50 kN | Class I IP67 IK10

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

EMFA’s Teos 3 Surface Drive Over LED Fixture is specially designed to deliver high output LED light to ground surfaces of roads, carparks and pathways. This heavy duty fixture is designed to withstand the weight of large vehicles. Its robust construction allows for a maximum static load of 5000kg. The body and head of the fixture are made of die cast aluminium, while the recessing tube is made of steel to withstand the repeated impact of driving vehicles’ tires. The high power LEDs are positioned and angled to provide maximum light output. The electronic LED driver is housed in the base of the fixture. The fixture comes with 2 x PG13.5 cable glands and 0.5m cable. Cover Die cast aluminium Body Die cast aluminium Gaskets Silicone Diffusers Polycarbonate Screws 316L Stainless steel Glands 2 x PG 13.5 Cable 0.5m 3x0,75 mm H05VV-F

191

TEOS 3

SURFACE MOUNTED DRIVE OVER FIXTURES Load 50 kN | Class I IP67 IK10

Available in any of these RAL colors

7004

7016

9005

9016

Led

: Linear LEDs

Voltage

: 240 VAC with integrated driver

6002

1015

(12-24 VDC on request) Diffuser

Mono

Mono Mono Duo 1-way Duo 1-way Duo 2-way Duo 2-way Trio Trio Quad Quad

: Polycarbonate

Total Lighting Output Code No 165 lm 180201 192 lm 180202 330 lm 180211 384 lm 180212 330 lm 180221 384 lm 180222 495 lm 180231 576 lm 180232 660 lm 180241 768 lm 180242

3000 K 5000 K 3000 K 5000 K 3000 K 5000 K 3000 K 5000 K 3000 K 5000 K

Duo 1-way

Ø 240

Duo 2-way

63Lx

16Lx

Trio

0.5

1m m

1.5

7Lx 2m

4Lx m

2.5

2.5Lx

1.8Lx

1.3Lx

1Lx

Quad

192

Lux levels for one aperture at 3000K

3.5

MIRA

SURFACE MOUNTED FIXTURES Class I IP67 IK10

The Mira series consists of a range of LED, fluorescent and metal halide sources to deliver the desired light effect to facades, columns, bridges, monuments, and signs. The series is made of a die cast aluminium body with electrostatic powder paint finished with a 316L stainless steel cover. The recessed versions are for drive over up to 20 kN including a stainless steel recessing box. The surface mounted versions come with a heavy-duty 316L stainless steel bracket. The fixtures come with integrated electronic ballasts and a specially developed potted power cable to effectively bond with the cast resin and stop any water ingress. The LEDs used come in 3 different tones of white, as well as blue, red, green, amber and RGB. Several lenses from 6 to 40 degrees are available to choose from to achieve the desired the light effect.

Cover 316L Stainless steel Body Die cast aluminium Diffusers 12 mm Tempered Glass Gaskets Silicone Screws 316L Stainless steel Recessing Box Stainless steel

193

MIRA 1

SURFACE MOUNTED FIXTURES Class I IP67 IK10

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

SHORT BRACKET

Voltage

: 240V AC with integrated driver (24V AC or DC on request)

Lens

: 10º, 25º, 40º

Diffuser

: Clear Glass 12 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

12 x 350 mA (12 W) LED Warm White Natural White Cool White Blue Red Amber Green

3000 K 4500 K 6000 K

Lens

: 25º, 40º

Diffuser

: Clear Glass 12 mm (Frosted Glass on request)

Cable

: Potted 10 m 4x0,75 H03 VV-F

27 x 350 mA (27 W) RGB LED RGB

Code No 430241

: 240V AC with integrated ballast : Clear Glass 12 mm (Frosted Glass on request)

Reflector

: Symmetrical

Lampholder : W 4,3 x 8,5 d : Electronic

: Potted 5 m 3x0,75 H03 VV-F Code No 430231 FLUO T-2 1x8W (included)

194

55º

Diffuser

Cable

365

0º-52,5º

: 240V AC with remote driver

Ballast

420

Total Lighting Output Code No 1020 lm 430201 1020 lm 430206 1224 lm 430207 430202 430203 430204 430205

Voltage

115

104

MIRA 1

SURFACE MOUNTED FIXTURES Class I IP67 IK10

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

LONG BRACKET

Voltage

: 240V AC with integrated driver

Lens

: 10º, 25º, 40º

Diffuser

: Clear Glass 12 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

365

(24V AC or DC on request)

12 x 350 mA (12 W) LED Warm White Natural White Cool White Blue Red Amber Green

3000 K 4500 K 6000 K

Total Lighting Output Code No 1020 lm 430301 1020 lm 430306 1224 lm 430307 430302 430303 430304 430305

Voltage

: 240V AC with remote driver

Lens

: 25º, 40º

Diffuser

: Clear Glass 12 mm (Frosted Glass on request)

Cable

: Potted 10 m 4x0,75 H03 VV-F

115

420

0º-22,5º

0º-47,5º

25º 25º

55º

27 x 350 mA (27 W) RGB LED RGB

Code No 430341

122

130

167

Voltage

: 240V AC with integrated ballast

Diffuser

: Clear Glass 12 mm (Frosted Glass on request)

Reflector

: Symmetrical

Lampholder : W 4,3 x 8,5 d Ballast

: Electronic

Cable

: Potted 5 m 3x0,75 H03 VV-F Code No 430331 FLUO T-2 1x8W (included)

195

MIRA 2

SURFACE MOUNTED FIXTURES Class I IP67 IK10

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

SHORT BRACKET

Voltage

: 240V AC with integrated driver (24V AC or DC on request)

Lens

: 10º, 25º, 40º

Diffuser

: Clear Glass 12 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

36 x 350 mA (36 W) LED Warm White Natural White Cool White Blue Red Amber Green

3000 K 4500 K 6000 K

Total Lighting Output Code No 3060 lm 430801 3060 lm 430806 3672 lm 430807 430802 430803 430804 430805

135

420

0º-47,5º

Voltage

: 240V AC with remote driver

Lens

: 25º, 40º

Diffuser

: Clear Glass 12 mm (Frosted Glass on request)

Cable

: Potted 10 m 4x0,75 H03 VV-F

81 x 350 mA (81 W) RGB LED RGB

Code No 430821 69º

Voltage

: 240V AC with integrated ballast

Diffuser

: Clear Glass 12 mm (Frosted Glass on request)

Reflector

: Asymmetrical

135

Lampholder : G 8,5 Ballast

: Electronic

Metal Halide 70W (not included)

196

Code No 430841

139

MIRA 2

SURFACE MOUNTED FIXTURES Class I IP67 IK10

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

LONG BRACKET

Voltage

: 240V AC with integrated driver

Lens

: 10º, 25º, 40º

Diffuser

: Clear Glass 12 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

365

(24V AC or DC on request)

36 x 350 mA (36 W) LED Warm White Natural White Cool White Blue Red Amber Green

3000 K 4500 K 6000 K

135

Total Lighting Output Code No 3060 lm 430901 3060 lm 430906 3672 lm 430907 430902 430903 430904 430905

420

25º

157

167

Voltage

: 240V AC with remote driver

Lens

: 25º, 40º

Diffuser

: Clear Glass 12 mm (Frosted Glass on request)

Cable

: Potted 10 m 4x0,75 H03 VV-F

81 x 350 mA (81 W) RGB LED RGB

0º-22,5º 0º-47,5º

Code No 430921

Voltage

: 240V AC with integrated ballast

Diffuser

: Clear Glass 12 mm (Frosted Glass on request)

Reflector

: Asymmetrical 94

Lampholder : G 8,5 Ballast

69º

157

: Electronic

Metal Halide 70W (not included)

Code No 430941

200

197

KARIA

SURFACE MOUNTED FIXTURES Class I IP65 IK07

Available in these 2 colors Grey

Black

The Karia series consists of a range of LED and fluorescent sources to deliver the desired light effect to facades, columns, bridges, monuments, and signs. The series is made of an anodized extrusion aluminium body with polyamid side covers. Polyamid brackets are used to mount the fixtures. Stainless steel brackets are also available to increase the distance from the mounting surface if necessary. The fixtures come with integrated electronic ballasts and LEDs used come in 3 different tones of white, as well as blue, red, green, amber and RGB. Several lenses from 6 to 40 degrees are available to choose from to achieve the desired the light effect.

Body Anodized Aluminium profile with polyamid 66 side covers Mounting Brackets Polyamide 66 (Stainless Steel on request) Screws Stainless steel Diffusers 4 mm Tempered Glass Gaskets Silicone Gland 2 cable Gland for 5-8 mm Ø cable

198

KARIA 1

SURFACE MOUNTED FIXTURES Class I IP67 IK07

Available in these 2 colors Grey

Voltage

: 240 VAC with integrated driver (24V AC or DC on request)

Lens

: 10º, 25º, 40º, 6x25º elliptic

Diffuser

: 4 mm Clear Glass (Frosted Glass on request)

12 x 350 mA (12 W) LED Warm White Natural White Cool White Blue Red Amber Green

3000 K 4500 K 6000 K

Total Lighting Output Code No 1020 lm 431101 1020 lm 431106 1224 lm 431107 431102 431103 431104 431105

Black

400

25º

0º-180º

KARIA 1 RGB Voltage

: 240 VAC with remote driver (24V AC or DC on request)

Lens

: 10º, 25º, 40º, 6x25º elliptic

Diffuser

: 4 mm Clear Glass (Frosted Glass on request)

12 x 350 mA (12 W) LED CODE NO

431111

KARIA 27 RGB Voltage

: 240 V AC with remote driver

Lens

: 25º, 40º

Diffuser

: 4 mm Clear Glass (Frosted Glass on request)

Cable

: Potted 5 mm 3x0,75 H03 VV-F

27 x 350 mA (27 W) RGB LED CODE NO

431601

199

KARIA 2

SURFACE MOUNTED LED FIXTURES Class I IP67 IK07

Available in these 2 colors Grey

KARIA 2 24W

25º

24 x 350 mA (24 W) LED Warm White Natural White Cool White Blue Red Amber Green

3000 K 4500 K 6000 K

Total Lighting Output Code No 2040 lm 431211 2040 lm 431216 2448 lm 431217 431212 431213 431214 431215

Black

0º-180º

750

KARIA 2 36W Voltage

: 240 VAC with integrated driver

Lens

: 10º, 25º, 40º

(24V AC or DC on request) Diffuser

: Clear Glass 12 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

36 x 350 mA (36 W) LED Warm White Natural White Cool White Blue Red Amber Green

3000 K 4500 K 6000 K

Total Lighting Output Code No 3060 lm 3060 lm 3672 lm

431241 431242 431243 431244 431245 431246 431247

1050

200

KARIA

SURFACE MOUNTED FLUO.FIXTURES Class I IP44 IK07

Available in these 2 colors Grey

Black

650

KARIA 2 14W/24W Voltage

: 240V AC with integrated ballast

Diffuser

: 4 mm Clear Glass

Lampholder : G5 Ballast

: Electronic

T5 14W / 24W

Code No 431201

25º

950

KARIA 3 21W/39W Voltage

: 240V AC with integrated ballast

Diffuser

: 4 mm Clear Glass

Lampholder : G5 Ballast

: Electronic

T5 21W / 39W

Code No 431301

25º

201

MILET

SLIM WALLWASHER SURFACE MOUNTED Class I IP65 IK07

Available in these 2 colors Grey

Black

The Milet series consists of a range of LED and fluorescent sources to deliver the desired light effect to facades, columns, bridges, monuments, and signs. The series is made of an anodized extrusion aluminium body with polyamid side covers. Polyamid brackets are used to mount the fixtures. Stainless steel brackets are also available to increase the distance from the mounting surface if necessary. The fixtures come with integrated electronic ballasts and LEDs used come in 3 different tones of white, as well as blue, red, green, amber and RGB. Several lenses from 6 to 40 degrees are available to choose from to achieve the desired the light effect. Body Anodized Aluminium profile with polyamid 66 side covers Mounting Brackets Polyamide 66 (Stainless Steel on request) Screws Stainless Steel Diffusers 4 mm Tempered Glass Gaskets Silicone Gland 2 cable Gland for 5-8 mm Ø cable

202

MILET

SLIM WALLWASHER SURFACE MOUNTED Class I IP65 IK07

Available in these 2 colors Grey

Voltage Lens Diffuser

Black

: 240V AC with integrated driver (24V AC or DC on request) : 10º, 25º, 40º, 6x25º elliptic : 4 mm Clear Glass (Frosted Glass on request)

640 mm 18W POWERLED Warm White Natural White Cool White Blue Red Amber Green

3300 K 4500 K 6000 K

940 mm 24W POWERLED Warm White Natural White Cool White Blue Red Amber Green

3300 K 4500 K 6000 K

1240 mm 36W POWERLED Warm White Natural White Cool White Blue Red Amber Green

3300 K 4500 K 6000 K

Total Lighting Output Code No 1071 lm 299001 1185 lm 299002 1245 lm 299003 299004 299005 299006 299007

Total Lighting Output Code No 1608 lm 299101 1723 lm 299102 1871 lm 299103 299104 299105 299106 299107

Total Lighting Output Code No 2620 lm 299201 2840 lm 299202 2985 lm 299203 299204 299205 299206 299207

640 43

1240 43

203

SIDE

SURFACE MOUNTED BULKHEADS Class I IP65 IK08

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

Body Die Cast Aluminium Cover Die Cast Aluminium Paint Electrostatic powder paint Diffuser Pressed glass or polycarbonate SIDE 1

SIDE 3

SIDE 1 Lampholder: E27 INCANDESCENT 75W Glass Diffuser

Code No 505101

Lampholder: G24 d-2 FLUO. 18W Glass Diffuser

Code No 505121

P.C. Diffuser

505201

P.C. Diffuser

505221

115

Ø 226

Ø 271

SIDE 3 Lampholder: E27 INCANDESCENT 75W Glass Diffuser

Code No 507101

Lampholder: G24 d-2 FLUO. 18W Glass Diffuser

Code No 507121

P.C. Diffuser

507201

P.C. Diffuser

507221

SIDE 2

115

SIDE 2 Lampholder: E27 INCANDESCENT 75W Glass Diffuser

Code No 506101

Lampholder: G24 d-2 FLUO. 18W Glass Diffuser

Code No 506121

P.C. Diffuser

506201

P.C. Diffuser

506221

Ø 226

Ø 271

204

PERGE

SURFACE MOUNTED BULKHEADS Class I IP67 IK08

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

Body Die Cast Aluminium Cover Die Cast Aluminium Paint Electrostatic powder paint Diffuser Pressed glass or polycarbonate PERGE 1

PERGE 3

PERGE 1 Lampholder: E27 INCANDESCENT 75W Glass Diffuser P.C. Diffuser

115

Code No 515101

Lampholder: G24 d-2 FLUO. 18W Glass Diffuser

Code No 515121

515201

P.C. Diffuser

515221

226

271

PERGE 3 Lampholder: E27 INCANDESCENT 75W Glass Diffuser

Code No 517101

Lampholder: G24 d-2 FLUO. 18W Glass Diffuser

Code No 517121

P.C. Diffuser

517201

P.C. Diffuser

517221

PERGE 2

PERGE 2 Lampholder: E27 INCANDESCENT 75W Glass Diffuser P.C. Diffuser

115

Code No 516101

Lampholder: G24 d-2 FLUO. 18W Glass Diffuser

Code No 516121

516201

P.C. Diffuser

516221

226

271

205

SLIM PYRAMID

SURFACE MOUNTED FIXTURES Class II IP44 IK08

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

Cover & Body Glass reinforsed polyester Screws Inox Gasket Silicone Glass Tempered Recessing Box Galvanized steel (for recessed types only)

Lampholder : G24 d-1 Diffuser

: Frosted Glass

Asymmetrical 1 x FLUO 9W

206

114

Code No 503501

130

81,5

260

MILET

SURFACE MOUNTED FIXTURES IP54

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

The Milet Surface Mounted Series is specially designed to deliver low glare halogen lighting to steps, open areas, corridors and pathways. The fixture has a die cast aluminium body painted with electrostatic powder paint. The slated or open covers come in an aluminium or aluminium / stainless steel finish. The cable on site can be securely connected to the fixture via a sealed crimp splice. Cover Die cast aluminium / Inox (Stainless steel) Paint Black or grey electrostatic powder Body Die cast aluminium Connection Sealed crimp splices Gaskets Silicone Diffusers 4 mm Tempered Glass

HALOGEN 240V 25-40W Lampholder : G9 Reflector

: -

Diffuser

: Clear Glass

Class III

Box Alum

Code No 310111

Inox

311111

Ø 120

HALOGEN 240V 25-40W Lampholder : G9 Reflector

: -

Diffuser

: Frosted Glass

Class III

Box Alum

Code No 312111

Inox

314111

Ø 120

207

MILET

INDIRECT SURFACE MOUNTED FIXTURE Class I IP55 IK08

The Milet Indirect series consists of an on-wall fixture and a bollard using LED, halogen or fluorescent. The fixtures are made of a combination of a die cast aluminium head and an aluminium pipe painted with electrostatic powder paint. The wall fixture allows for a custom made sign showing room numbers or names. For the LED versions, a specially developed potted power cable is used to effectively bond with the cast resin and stop any water ingress. For the halogen and fluorescent versions, an IP connection box is provided to allow for a secure connection of the on-site cable.

Special Application For room numbers, names, signs etc. The acrylic part inside can be colour of choice. CODE NO 295115 ELECTR. CIR. FLUO. 6W

Cover Die cast aluminium Paint Black or grey electrostatic powder Body Die cast aluminium Connection IP connection box Gaskets Silicone Diffusers Polycarbonate

EMFA

Voltage

: 240V A.C with integrated driver

Lens

: 40º

(24V AC or DC on request) 90

Diffuser

: Polycarbonate

Cable

: Potted 5 m 3x0,75 H03 VV-F

320 mA (11W) LED 3000 K

Ø 160

Code No 290101

Lampholder : G9

Lampholder : Gx53

Reflector

: -

Reflector

: -

Diffuser

: Polycarbonate

Diffuser

: Polycarbonate

HALOGEN 240V 40W

208

Code No 290201

Code No ELECTRONIC CIRCULAR FLUO. 6W 290211

BELKIS 1 LLA

SURFACE MOUNTED LED FIXTURES Class I IP67 IK08 Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

The Belkis 1 LLS is specially designed to deliver low glare LED lighting to steps, open areas, corridors and pathways where recessing the fixture is not possible. The fixture has a die cast aluminium body painted with electrostatic powder paint. The narrow depth of 39mm, which also includes the LED driver, allows the fixture to be installed in any wall. A plastic recessing box is included for installation into concrete. A specially developed potted power cable is used to effectively bond with the cast resin and stop any water ingress. The linear LED used comes in 2 different tones of white, 3000K and 4000K. Body Die cast aluminium Paint Electrostatic powder Diffusers Tempered Glass 4 mm Gaskets Silicone

Asymmetrical

Voltage

: 240V AC with integrated driver

Diffuser

: Clear Glass 12 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

(12V DC or 24V DC on request) 80

46 45

1 x 350 mA (4 W) LED Warm White Natural White

3000 K 4000 K

Total Lighting Output Code No 92 lm 424141 107 lm 424142

ALUM

209

BELKIS 1 LLS

SURFACE MOUNTED LED FIXTURES Class I IP67 IK08

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

Symmetrical With Milky Glass

Voltage

: 240V AC with integrated driver

Diffuser

: Milky Glass

Cable

: Potted 5 m 3x0,75 H03 VV-F

(12V DC or 24V DC on request)

1 x 350 mA (4 W) LED Warm White Natural White

3000 K 4000 K

Total Lighting Output Code No 128 lm 424151 148 lm 424152

ALUM

Symmetrical With Glare-Glass or Clear Glass

Voltage

: 240V AC with integrated driver (12V DC or 24V DC on request)

Diffuser

: Anti-Glare Glass 4 mm

Cable

: Potted 5 m 3x0,75 H03 VV-F

ALUM Symmetrical With Anti-Glare Glass 1 x 350 mA (4 W) LED Warm White Natural White

3000 K 4000 K

Total Lighting Output Code No 255 lm 424161 295 lm 424162

Symmetrical With Clear Glass 1 x 350 mA (4 W) LED Warm White Natural White

210

3000 K 4000 K

Total Lighting Output Code No 255 lm 424171 295 lm 424172

SATURN

SURFACE MOUNTED LED FIXTURES Class I IP65 IK08

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

: 240V

Diffuser

: Clear, Frosted And Milky Glass 4 mm

Cable

: Potted 5 m 3x0,75 H03 VV-F

Asymmetrical

3W COB LED Warm White 3000 K Natural White 4000 K

Total Lighting Output Code No 285 lm 526001 313 lm 526002

Ø80

Symmetrical With Frosted Glass or Milky Glass

Symmetrical With Frosted Glass 3W COB LED Warm White 3000 K Natural White 4000 K

Total Lighting Output Code No 245 lm 526101 295 lm 526102

Symmetrical With Milky Glass 3W COB LED Warm White 3000 K Natural White 4000 K

Total Lighting Output Code No 195 lm 526201 210 lm 526202

Ø80

211

LYKIA LL

SURFACE MOUNTED LED FIXTURES Class I IP65 IK08

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

The LYKIA LL is specially designed to deliver low glare LED lighting to steps, open areas, corridors and pathways where recessing the fixture is not possible. The fixture has a die cast aluminium body painted with electrostatic powder paint. The narrow depth of 39mm, which also includes the LED driver, allows the fixture to be installed in any wall. A plastic recessing box is included for installation into concrete. A specially developed potted power cable is used to effectively bond with the cast resin and stop any water ingress. The linear LED used comes in 2 different tones of white, 3000K and 4000K.

Body Die cast aluminium Paint Electrostatic powder Diffusers Pmma Gaskets Silicone

Voltage

: 240V AC with integrated driver

(12V DC or 24V DC on request) Diffuser

: Clear Glass 12 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

1 x 350 mA (3 W) LED Warm White

212

3000 K

Total Lighting Output Code No 92 lm 424201

120

ALUM

213

MILET ANI

WALL SURFACE RECESSED Class I IP55 IK08

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

EMFA’s Ani surface mounted series is specially designed to deliver low-glare lighting to facades, walkways,pathways and driveways with minimal installation depth and narrow trim. The fixture is made of a combination of 316L stainless steel and die cast aluminium. The tilted design reduces the glare of the LED’s The Linear LEDs with special lenseS gives excellent wallwashing effect. An anti-slip glass is available upon request. Body Die cast aluminium Gaskets Silicone Diffusers 4 mm Tempered Glass Screws 316L Stainless Steel Glands PG 11

Symmetrical

45º 90º

Asymmetrical

Asym. Glass

55º 45º

214

Trenched Glass Milky Glass

Clear Glass

ANI

WALL SURFACE MOUNTED Class I IP55 IK08

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

Symmetrical : Linear LEDs

Voltage

: 240 VAC with integrated driver

Diffuser

: 4mm Tempered Glass

45º 90º

Led

(12-24 VDC on request) Beam Angle : 45°/ 60°/ 90°

: %70 ANI 1 Kelvin 3000 K 3000 K 4000 K 4000 K

ANI 2 Kelvin 3000 K 3000 K 4000 K 4000 K

ANI 3 Kelvin 3000 K 3000 K 4000 K 4000 K

ANI 4 Kelvin 3000 K 3000 K 4000 K 4000 K

140

150

Galvanized Mounting Box

180

150

Galvanized Mounting Box

220

180

Power Code No 24W 457301 48W 457311 24W 457302 48W 457312

Nominal Real Lumen Lumen Output Output 1780 lm 2550 lm 3080 lm 4300 lm 2047 lm 2932 lm 3542 lm 5060 lm

100

Galvanized Mounting Box

150

Power Code No 18W 457201 36W 457211 18W 457202 36W 457212

Nominal Real Lumen Lumen Output Output 1200 lm 1700 lm 2300 lm 3300 lm 1380 lm 1955 lm 2645 lm 2932 lm

150

Power Code No 12W 457101 24W 457111 12W 457102 24W 457112

Nominal Real Lumen Lumen Output Output 1020 lm 1460 lm 1780 lm 2550 lm 1173 lm 1679 lm 2047 lm 2932 lm

100

150

Power Code No 6W 457001 12W 457011 6W 457002 12W 457012

Nominal Real Lumen Lumen Output Output 600 lm 850 lm 1020 lm 1460 lm 690 lm 977 lm 1173 lm 1679 lm

: >80

L.O.R %

CRI

Galvanized Mounting Box

Mac Adam

150

220

Galvanized Mounting Box

215

ANI

WALL SURFACE MOUNTED Class I IP55 IK08

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

Asymmetrical Led

: Linear LEDs

Voltage

: 240 VAC with integrated driver

55º

(12-24 VDC on request) : 4mm Tempered Glass

Beam Angle : 45°/ 60°/ 90° : 80

L.O.R %

: %70 ANI 1 Kelvin 3000 K 3000 K 4000 K 4000 K

ANI 2 Kelvin 3000 K 3000 K 4000 K 4000 K

ANI 3 Kelvin 3000 K 3000 K 4000 K 4000 K

ANI 4

216

Kelvin 3000 K 3000 K 4000 K 4000 K

Real Lumen Output 1200 lm 2300 lm 1380 lm 2645 lm

Nominal Lumen Output 1700 lm 3300 lm 1955 lm 2932 lm

Real Lumen Output 1780 lm 3080 lm 2047 lm 3542 lm

Nominal Lumen Output 2550 lm 4300 lm 2932 lm 5060 lm

100

Galvanized Mounting Box

140

150

Galvanized Mounting Box

180

150

Galvanized Mounting Box

220

180

Power Code No 24W 457801 48W 457811 24W 457802 48W 457812

Nominal Lumen Output 1460 lm 2550 lm 1679 lm 2932 lm

150

Power Code No 18W 457701 36W 457711 18W 457702 36W 457712

Real Lumen Output 1020 lm 1780 lm 1173 lm 2047 lm

100

150

Power Code No 12W 457601 24W 457611 12W 457602 24W 457612

Nominal Lumen Output 850 lm 1460 lm 977 lm 1679 lm

150

Power Code No 6W 457501 12W 457511 6W 457502 12W 457512

Real Lumen Output 600 lm 1020 lm 690 lm 1173 lm

CRI

Galvanized Mounting Box

Mac Adam

Diffuser

45º

150

220

Galvanized Mounting Box

217

MILET ANI

WALLWASHER LED SPOTS Class I IP55 IK08

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

EMFA’s Ani wallwasher series is specially designed to deliver low-glare lighting to facades, walkways, pathways and driveways with minimal installation depth and narrow trim. The fixture is made of a combination of 316L stainless steel and die cast aluminium. The tilted design reduces the glare of the LED’s The Linear LEDs with special lenseS gives excellent wallwashing effect. An anti-slip glass is available upon request. Body Die cast aluminium Gaskets Silicone Diffusers 4 mm Tempered Glass Screws 316L Stainless Steel Glands PG 11

Symmetrical

45º 90º

Asymmetrical

Asym. Glass

55º 45º

218

Trenched Glass Milky Glass

Clear Glass

ANI

WALLWASHER LED SPOTS Class I IP55 IK08

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

Symmetrical Led

: Linear LEDs

Voltage

: 240 VAC with integrated driver

Diffuser

: 4mm Tempered Glass

45º 90º

(12-24 VDC on request) Beam Angle : 45°/ 60°/ 90°

ANI 2 Power Code No 12W 454101 24W 454111 12W 454102 24W 454112

Kelvin 3000 K 3000 K 4000 K 4000 K

ANI 3 Power Code No 18W 454201 36W 454211 18W 454202 36W 454212

Kelvin 3000 K 3000 K 4000 K 4000 K

ANI 4 Power Code No 24W 454301 48W 454311 24W 454302 48W 454312

Kelvin 3000 K 3000 K 4000 K 4000 K

100

Kelvin 3000 K 3000 K 4000 K 4000 K

150

Nominal Real Lumen Lumen Output Output 1020 lm 1460 lm 1780 lm 2550 lm 1173 lm 1679 lm 2047 lm 2932 lm

150

Nominal Real Lumen Lumen Output Output 1200 lm 1700 lm 2300 lm 3300 lm 1380 lm 1955 lm 2645 lm 2932 lm

150

Nominal Real Lumen Lumen Output Output 1780 lm 2550 lm 3080 lm 4300 lm 2047 lm 2932 lm 3542 lm 5060 lm

150

140

Power Code No 6W 454001 12W 454011 6W 454002 12W 454012

Nominal Real Lumen Lumen Output Output 600 lm 850 lm 1020 lm 1460 lm 690 lm 977 lm 1173 lm 1679 lm

180

ANI 1

220

: %70

158

: >80

L.O.R %

198

CRI

238

278

Mac Adam

219

ANI

WALLWASHER LED SPOTS Class I IP55 IK08

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

Asymmetrical Led

: Linear LEDs

Voltage

: 240 VAC with integrated driver 55º

(12-24 VDC on request) Diffuser

45º

: 4mm Tempered Glass

Beam Angle : 45°/ 60°/ 90°

ANI 2 Power Code No 12W 454601 24W 454611 12W 454602 24W 454612

Kelvin 3000 K 3000 K 4000 K 4000 K

ANI 3 Power Code No 18W 454701 36W 454711 18W 454702 36W 454712

Kelvin 3000 K 3000 K 4000 K 4000 K

ANI 4 Power Code No 24W 454801 48W 454811 24W 454802 48W 454812

220

Kelvin 3000 K 3000 K 4000 K 4000 K

Real Lumen Output 1020 lm 1780 lm 1173 lm 2047 lm

Nominal Lumen Output 1460 lm 2550 lm 1679 lm 2932 lm

Real Lumen Output 1200 lm 2300 lm 1380 lm 2645 lm

Nominal Lumen Output 1700 lm 3300 lm 1955 lm 2932 lm

Real Lumen Output 1780 lm 3080 lm 2047 lm 3542 lm

Nominal Lumen Output 2550 lm 4300 lm 2932 lm 5060 lm

100

150

Kelvin 3000 K 3000 K 4000 K 4000 K

Nominal Lumen Output 850 lm 1460 lm 977 lm 1679 lm

140

150

Power Code No 6W 454501 12W 454511 6W 454502 12W 454512

Real Lumen Output 600 lm 1020 lm 690 lm 1173 lm

180

150

ANI 1

220

150

: %64

210

: 80

L.O.R %

210

CRI

210

Mac Adam

BELKIS

APPLIQUES Class I IP55 IK08

The Belkis Applique series consists of a range of LED, metal halide and halogen sources to deliver the desired light effect to facades and columns. The series is made of die cast aluminium and extrusion aluminium painted with electrostatic powder paint. 6 standard RAL colors can be chosen from to adapt the spots to their environment. The LEDs used come in 3 different tones of white, as well as blue, red, green, amber and RGB. Several lenses from 6 to 40 degrees are available to choose from to achieve the desired the light effect.

Body Aluminium Profile Cover Die cast aluminium Paint Electrostatic powder Bracket Die cast aluminium Diffusers Tempered Glass Gaskets Silicone Connection IP connection box

“Customization” is EMFA’s standard EMFA offers many combinations for each fixture, as all fixtures are made in house. A combination of 6 standard paint colors, 8 LED colors and 5 or more lenses and reflectors are available to make the fixture suitable for the required application. This is done without increasing lead-time and is available for large as well as small quantities.

221

BELKIS Belkis 1

ONE-WAY APPLIQUES Class I IP55 IK08 Belkis 2

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

Belkis 5

BELKIS 1

Lampholder : G9 Reflector

: 40º

Diffuser

: 8 mm Frosted Glass

HALOGEN 240V 25W

181

100

Code No 340101

Ø 62

BELKIS 2

117

Lampholder : Gu10 Reflector

: -

Diffuser

: 8 mm Clear Glass

HALOGEN 240V 50W (25º or 50º)

207

100

Code No 341111 Ø 82

BELKIS 5

179

Lampholder : E27 Reflector

: -

Diffuser

: 8 mm Clear Glass

100

284

Code No HALOGEN PAR 30 75W (10º or 30º) 342111 Ø 145

222

BELKIS

ONE-WAY LED APPLIQUES Class I IP55 IK08

Belkis 1

Voltage

Belkis 2

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

Belkis 5

: 240V A.C with integrated driver (24V AC or DC on request)

Lens

: 25º (10º - 40º or without lens on request)

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

BELKIS 1 1 x 350 mA (1 W) LED Warm White Natural White Cool White Blue Red Amber Green

3000 K 4500 K 6000 K

BELKIS 2 3 x 350 mA (3 W) LED Warm White Natural White Cool White Blue Red Amber Green

3000 K 4500 K 6000 K

BELKIS 5 6 x 350 mA (6 W) LED Warm White Natural White Cool White Blue Red Amber Green

3000 K 4500 K 6000 K

Total Lighting Output 85 lm 85 lm 102 lm

Total Lighting Output 255 lm 255 lm 270 lm

Total Lighting Output 510 lm 510 lm 612 lm

Code No 425101 425106 425107 425102 425103 425104 425105

181

100

Ø 62

117

Code No 425121 425126 425127 425122 425123 425124 425125

207

100

Ø 82

179

Code No 425141 425146 425147 425142 425143 425144 425145

100

284

Ø 145

223

224

BELKIS

TWO-WAY APPLIQUES Class I IP55 IK08

Belkis 1

Belkis 2

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

Belkis 5

BELKIS 1

Lampholder : 2 x G9 Reflector

: 40º

Diffuser

: 8 mm Frosted Glass

2 x HALOGEN 240V 25W

181

100

Code No 343101

Ø 62

BELKIS 2

117

Lampholder : 2 x Gu10 Reflector

: -

Diffuser

: 8 mm Frosted Glass

2 x HALOGEN 240V 50W (25º or 50º)

207

100

Code No 344111 Ø 82

BELKIS 5

179

Lampholder : 2 x E27 Reflector

: -

Diffuser

: 8 mm Frosted Glass

100

284

Code No 2 x HALOGEN PAR 30 75W (10º or 30º) 345111 Ø 145

225

BELKIS

TWO-WAY LED APPLIQUES Class I IP55 IK08

Belkis 1

Belkis 2

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

Belkis 5

Voltage

: 240V A.C with integrated driver

Lens

: 25º (10º - 40º or without lens on request)

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

(24V AC or DC on request)

BELKIS 1 2 x 1 x 350 mA (2 W) LED Warm White 3000 K Natural White 4500 K Cool White 6000 K Blue Red Amber Green BELKIS 2 2 x 3 x 350 mA (6 W) LED Warm White 3000 K Natural White 4500 K Cool White 6000 K Blue Red Amber Green

Total Lighting Output 85 lm 85 lm 102 lm

Code No 425111 425116 425117 425112 425113 425114 425115

Ø 62

Total Lighting Output Code No 255 lm 425131 255 lm 425136 270 lm 425137 425132 425133 425134 425135

Total Lighting 2 x 6 x 350 mA (12 W) LED Output 510 lm Warm White 3000 K 510 lm Natural White 4500 K 612 lm Cool White 6000 K Blue Red Amber Green

117

207

100

Ø 82

179

BELKIS 5

226

181

100

Code No 425151 425156 425157 425152 425153 425154 425155

100

284

Ø 145

227

BELKIS 5

ONE-WAY APPLIQUES WITH GEARBOX Class I IP55 IK08

Available in any of these RAL colors

7004

7016

Lampholder : G12 Reflector

: 15º, 55º

Diffuser

: 8 mm Clear Glass

METAL HALIDE 35W

: 15º, 55º

Diffuser

: 8 mm Clear Glass

Code No 346401

200

Code No 346411

Lampholder : Gx8.5 Reflector

: -

Diffuser

: 8 mm Clear Glass

METAL HALIDE CDM-R111 35W

Code No 346421

(10º or 40º)

Lampholder : Gx8.5 Reflector

: -

Diffuser

: 8 mm Clear Glass

METAL HALIDE CDM-R111 70W (10º or 40º)

228

6002

1015

284

248

143

METAL HALIDE 70W

9016

248

Lampholder : G12 Reflector

9005

Code No 346431

Ø 145

BELKIS 5

TWO-WAY APPLIQUES WITH GEARBOX Class I IP55 IK08

Available in any of these RAL colors

7004

7016

Lampholder : 2 x G12 Reflector

: 15º, 55º

Diffuser

: 8 mm Clear Glass

2 x METAL HALIDE 35W

: 15º, 55º

Diffuser

: 8 mm Clear Glass

Code No 346501

200

6002

1015

284

248

143

2 x METAL HALIDE 70W

9016

248

Lampholder : 2 x G12 Reflector

9005

Ø 145

Code No 346511

Lampholder : 2 x Gx8.5 Reflector

: -

Diffuser

: 8 mm Clear Glass

2 x METAL HALIDE CDM-R111 35W

Code No 346521

(10º or 40º)

Lampholder : 2 x Gx8.5 Reflector

: -

Diffuser

: 8 mm Clear Glass

2 x METAL HALIDE CDM-R111 70W

Code No 346531

(10º or 40º)

229

BELKIS 1

APPLIQUES Class I IP55

Available in any of these RAL colors

Lampholder : G24 q - 1 Reflector

: -

Reflector

: -

Diffuser

: Acrylic Pipe

Diffuser

: Acrylic Pipe

COMPACT FLUO. 13W

230

Code No 293301

7016

9005

9016

6002

Lampholder : 2 x G24 q - 1

Transformer : Electronic

7004

Transformer : Electronic

100

2 x COMPACT FLUO. 13W

230

Code No 293401

100

Ø 64

BELKIS 1

Lampholder : G24 q - 1 Reflector

: -

Diffuser

: Acrylic Pipe

TORCH APPLIQUES Class I IP44

81 Ø 64

Lampholder : Gu4 Reflector

: -

Diffuser

: Acrylic Pipe

68 Ø 62

Transformer : Electronic COMPACT FLUO. 13W

Transformer is not included

Code No 293201

Remote transformer should be used HALOGEN 12V 20W 38º 650

230

1015

Code No 293251

550

231

SQUARE

LED APPLIQUE Class I IP65

Available in any of these RAL colors

7004

7016

9005

Body Die cast aluminium Paint Electrostatic powder Bracket Die cast aluminium Diffuser Tempered Glass or acrylic Gaskets Silicone Connection IP connection box

Voltage

: 240V A.C with integrated driver

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

100

105

(24V AC or DC on request)

DOM LED 320 mA (11 W) LED Warm White Natural White

Voltage

3000 K 4000 K

100

Total Lighting Output Code No 925 lm 434001 975 lm 434002

100

40 52

: 240V A.C with integrated driver

100

105

(24V AC or DC on request) Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

OSRAM SMD LED 350 mA (6W) LED Warm White Natural White

232

3000 K 4000 K

Total Lighting Output Code No 434011 640 lm 434012 640 lm

100

40 52

9016

6002

1015

233

SQUARE

LED APPLIQUE Class I IP65

Available in any of these RAL colors

7004

7016

9005

Body Die cast aluminium Paint Electrostatic powder Bracket Die cast aluminium Diffuser Tempered Glass or acrylic Gaskets Silicone Connection IP connection box

Voltage

: 240V A.C with integrated driver

100

105

(24V AC or DC on request) Lens

: 10º, 25º, 40º

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

POWERLED 350 mA (6W) LED Warm White Natural White Cool White

3000 K 4500 K 6000 K

100

Total Lighting Output Code No 510 lm 434021 510 lm 434022 612 lm 434023

Voltage

: 240V A.C with integrated driver

Lens

: 20º, 32º, 52º

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

100

105

(24V AC or DC on request)

Multichip LED 350 mA (9W) Warm White Natural White

234

3000 K 4000 K

Total Lighting Output Code No 434031 672 lm 434032 756 lm

100

40 52

9016

6002

1015

PEDESA

ROUND APPLIQUES Class I IP55

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

Body Aluminium profile Paint Electrostatic powder Bracket Die cast aluminium Diffusers Acrylic Gaskets Silicone Connection IP connection box

Voltage

: 240V A.C with integrated driver

Diffuser

: Acrylic

Cable

: Potted 5 m 3x0,75 H03 VV-F

(24V AC or DC on request)

Ø 120

125

206

PEDESA 1 ROUND APPLIQUE 320 mA (11W) LED Warm White Natural White

Voltage

3000 K 4000 K

Code No 504001 504002

: 240V A.C with integrated driver

172

(24V AC or DC on request) Diffuser

: Acrylic

Cable

: Potted 5 m 3x0,75 H03 VV-F Ø 140

PEDESA 2 ROUND APPLIQUE 320 mA (11W) LED Warm White Natural White

3000 K 4000 K

Code No 504011 504012

125

206

178

235

PEDESA

ROUND ACRYLIC APPLIQUES Class I IP55

Body Acrylic Paint Electrostatic powder Bracket Die cast aluminium Diffusers Acrylic Gaskets Silicone Connection IP connection box

Voltage

: 240V A.C with integrated driver

Diffuser

: Acrylic

Cable

: Potted 5 m 3x0,75 H03 VV-F

(24V AC or DC on request)

Ø 120

125

206

PEDESA 1 ROUND APPLIQUE 320 mA (11W) LED Warm White Natural White

Voltage

3000 K 4000 K

Code No 504021 504022

: 240V A.C with integrated driver

172

(24V AC or DC on request) Diffuser

: Acrylic

Cable

: Potted 5 m 3x0,75 H03 VV-F Ø 140

PEDESA 2 ROUND APPLIQUE 320 mA (11W) LED Warm White Natural White 236

3000 K 4000 K

Code No 504031 504032

125

206

178

PEDESA

SQUARE APPLIQUES Class I IP55

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

Body Aluminium profile Paint Electrostatic powder Bracket Die cast aluminium Diffusers Acrylic Gaskets Silicone Connection IP connection box

Voltage

: 240V A.C with integrated driver

Diffuser

: Acrylic

Cable

: Potted 5 m 3x0,75 H03 VV-F

(24V AC or DC on request)

ALUMINIUM PEDESA SQUARE APPLIQUE 320 mA (11W) LED Warm White Natural White

3000 K 4000 K

Code No 504041 504042

Ø 100

206

125

152

237

IPSOS

LED APPLIQUES Class I IP44

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

Body Steel Cover Steel Paint Electrostatic powder paint Diffuser Acrylic

Voltage

: 240V A.C with integrated driver

Diffuser

: Polycarbonate

Cable

: Potted 5 m 3x0,75 H03 VV-F

(24V AC or DC on request)

320 mA (11W) LED 3000 K

Voltage

Ø150

Code No 131001

: 240V A.C with integrated driver (24V AC or DC on request)

Diffuser

: Polycarbonate

Cable

: Potted 5 m 3x0,75 H03 VV-F

320 mA (11W) LED 3000 K

238

Code No 131011

SATURN

APPLIQUES

Inner Body Die cast aluminium Rings Aluminium plate Diffuser Polycarbonate Gaskets Silicone Head & Reflector Anodized aluminium

SATURN 1

Ø 134

Lampholder : E27 INCANDESCENT 60W

Code No 525101

265

Ø 380

Lampholder : E27 ELECTRONIC FLUO. DEL 23W

Code No 525111

SATURN 2

Ø 134

Lampholder : G24 d-3 FLUO. 26W

288

Code No 525201

Ø 580

SATURN 3 Ø 134

Lampholder : G24 q-4 FLUO. 42W

Code No 525301

345

150

Ø 780

239

240

Spots

241

SQUARE

LED SPOT WITH TIR LENS LED DRIVER IN HEAD Class I IP67 IK10

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

The Square Spot series consists of a range of LED, metal halide, fluorescent and halogen sources to deliver the desired light effect to facades, columns, bridges, monuments, signs, and trees. The series is made of die cast aluminium and painted with electrostatic powder paint. 6 standard RAL colors can be chosen from to adapt the spots to their environment (grey, anthracite, black, white, green and beige). The spots can be mounted on surfaces, in the ground or concrete with a picket, or on a pole with the addition of a simple adaptor. Two adaptors are available for two sizes of poles. Once installed, the special joint system allows for 100° horizontal and 180° vertical adjustment. The gearboxes are either filled with cast resin and have a pre-potted cable for IP67. The LEDS used come in 3 different tones of white, as well as blue, red, green, amber and RGB. Several lenses from 10 to 30 degrees are available to choose from to achieve the desired the light effect.

Picket Body Die cast aluminium Paint Electrostatic powder Gaskets Silicone Diffusers Tempered Glass Honeycomb

10°

20°

30°

“Customization” is EMFA’s standard EMFA offers many combinations for each fixture, as all fixtures are made in house. A combination of 6 standard paint colors, 8 LED colors, 2 wattages, and 5 or more lenses and reflectors are available to make the fixture suitable for the required application. This is done without increasing lead-time and is available for large as well as small quantities.

Warm White Natural White Voltage

3000 K 4000 K

105

6W or 12W COB LED

102

6W 434101 434102

12W 434111 434112

: 240V A.C with integrated driver : 10º, 20º, 30º Mirror TIR Lens

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

242

Ø60

25 7

(24V AC or DC on request) Lens

105

21 25

BELKIS

SPOTS Available in any of these RAL colors

The Belkis Spot series consists of a range of LED, metal halide, fluorescent and halogen sources to deliver the desired light effect to facades, columns, bridges, monuments, signs, and trees. The series is made of die cast aluminium and painted with electrostatic powder paint. 6 standard RAL colors can be chosen from to adapt the spots to their environment (grey, anthracite, black, white, green and beige). The spots can be mounted on surfaces, in the ground or concrete with a picket, or on a pole with the addition of a simple adaptor. Two adaptors are available for two sizes of poles. Once installed, the special joint system allows for 100° horizontal and 180° vertical adjustment. The gearboxes are either filled with cast resin and have a pre-potted cable for IP67, or have a stainless steel cover and cable glands for IP55. The LEDs used come in 3 different tones of white, as well as blue, red, green, amber and RGB. Several lenses from 6 to 40 degrees are available to choose from to achieve the desired the light effect. Body Die cast aluminium Paint Electrostatic powder Gearbox Cover Stainless steel Gaskets Silicone Diffusers Tempered Glass

7004

7016

9005

9016

6002

1015

LEDs Only highest quality LEDs such as Cree or Toplite are used in production allowing for maximum lumen output and maximum lifetime. Most LEDs run on 350mA or 700mA depending on how much light output is required. The white color temperature binning is 200K at most, and always on the same x,y coordinates on the CIE diagram in accordance with Energy Star. This ensures consistent supply of the same color temperatture over time. As LEDs are constantly developing and becoming more efficient, lumen output given in this catalogue are current as of March 2020. At 2700K, 3000K, and 4000K LED lumen output per led is 110lm; at 6000K the lumen output per led is 125lm. Total Lighting Output as printed in this catalogue is the actual light output of the entire fixture. The minimum CRI of the LEDs used is 85 with a majority of products over 90. Thermal Management All fixtures are designed to withstand ambient temperatures of at least 50ºC. The LEDs are mounted on metal core pcbs, which are mounted to the aluminium body of the fixture so that the entire fixture acts as a heat sink. Extensive testing is performed in EMFA’s laboratory to ensure these values are maintained so that the lifetime of the LED is not compromised.

Accessories Picket and pole mounting optionsare avaible for most spots

Visor for Belkis Spots Electrostatic Powder Painted Aluminium Belkis 1 Belkis 2 Belkis 3 Belkis 4 Belkis 5 Belkis 6

Steel Arm The painted steel arm is avaible for all Belkis Spot fixtures.

Code No 953531 953532 953533 953534 953535 953536

Honeycomb Louvre Belkis 1 Belkis 2 Belkis 3 Belkis 4 Belkis 5

Code No 953521 953522 953523 953524 953525 243

BELKIS MINI

LED SPOT LED DRIVER IN HADE Class I IP67 IK10

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

Body Die cast aluminium Paint Electrostatic powder Gaskets Silicone Diffusers Tempered Glass

1 x 350 mA (1 W) LED Voltage

: 240V A.C with integrated driver (24V AC or DC on request)

Lens

Ø42

: 10º, 25º, 40º

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

Warm White Natural White Cool White Blue Red Amber Green

3000 K 4500 K 6000 K

Total Lighting Output 85 lm 85 lm 102 lm

Code No 3W 1W 297101 297111 297102 297112 297103 297113 297104 297114 297105 297115 297106 297116 297107 297117

148

Visor for Belkis Spot

Picket for Belkis Spots

244

245

BELKIS 1

LED SPOT LED DRIVER IN BASE Class I IP67 IK10

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

For mounting on surface or in ground with picket or on pole (with adaptor)

1 x 350 mA (1 W) LED or 1 x 700 mA (3 W) LED Voltage

: 240V A.C with integrated driver

Lens

: 10º, 25º, 40º

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

Ø 67 149

(24V AC or DC on request)

POWERLED Warm White Natural White Cool White Blue Red Amber Green

Total Lighting Output Code No 1W 3W 1W 3W 330211 330221 3000 K 85 lm 225 lm 330216 330222 4500 K 85 lm 225 lm 330217 330223 6000 K 102 lm 270 lm 330212 330224 330213 330225 330214 330226 330215 330227

Picket

Visor

Honeycomb

Code No: 953805

Code No: 953531

Code No: 953521

During installation, place disc in depicted position (A) to allow an upward tilt of 50 and a downward tilt of 15.

90º

90º + 90º horizontal adjustment

A 50º 15º

During installation, place disc in depicted position (B) to allow an upward tilt of 15 and a downward tilt of 50.

15º 50º

Page 211 for Mounting Accessories 246

BELKIS 1

LED SPOT LED DRIVER IN BASE Class I IP67 IK10

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

For mounting on surface or in ground with picket or on pole (with adaptor)

1 x 350 mA (1 W) LED or 1 x 700 mA (3 W) LED

Ø 67

Voltage

: 240V A.C with integrated driver

Lens

: 10º, 25º, 40º

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

Gearbox

: Equipped with 1xPG 11 cable gland and stainless steel cover

149

(24V AC or DC on request)

Avaible with 2xPG 11 cable gland for through cabling on request POWERLED Warm White Natural White Cool White Blue Red Amber Green

Total Lighting Output Code No 1W 3W 1W 3W 330231 330241 3000 K 85 lm 225 lm 330232 330242 4500 K 85 lm 225 lm 330233 330243 6000 K 102 lm 270 lm 330234 330244 330235 330245 330236 330246 330237 330247

Picket

Visor

Honeycomb

Code No: 953805

Code No: 953531

Code No: 953521

During installation, place disc in depicted position (A) to allow an upward tilt of 50 and a downward tilt of 15.

90º

90º + 90º horizontal adjustment

A 50º 15º

During installation, place disc in depicted position (B) to allow an upward tilt of 15 and a downward tilt of 50.

15º 50º

Page 211 for Mounting Accessories 247

BELKIS 1

LED SPOT LED DRIVER IN HEAD Class I IP67 IK10

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

For mounting on surface or in ground with picket or on pole (with adaptor)

1 x 350 mA (1 W) LED

Ø 67 127

Voltage

: 240V A.C with integrated driver

Lens

: 10º, 25º, 40º

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

(24V AC or DC on request)

POWERLED Warm White Natural White Cool White Blue Red Amber Green

3000 K 4500 K 6000 K

Ø 84

Total Lighting Output 85 lm 85 lm 102 lm

Code No 330201 330206 330207 330202 330203 330204 330205

Picket

Visor

Honeycomb

Code No: 953805

Code No: 953531

Code No: 953521

During installation, place disc in depicted position (A) to allow an upward tilt of 50 and a downward tilt of 15.

90º

90º + 90º horizontal adjustment

A 50º 15º

During installation, place disc in depicted position (B) to allow an upward tilt of 15 and a downward tilt of 50.

15º 50º

Page 211 for Mounting Accessories 248

BELKIS 1

LOW VOLTAGE HALOGEN SPOTS Class III IP67 IK10

Available in any of these RAL colors

7004

7016

WITH CENTRAL ARM & GEAR BOX

9005

9016

6002

1015

Ø 62

For mounting on surface or in ground with picket or on pole (with adaptor)

Lampholder : Gu4

142

Reflector

: -

Diffuser

: 8 mm Glass

Cable

: Potted 5 m 3x0,75 H03 VV-F

Transformer potted in base. HALOGEN 12V 20W (10º or 38º)

Code No 330121 90º

90º

Picket

Visor

Honeycomb

Code No: 953805

Code No: 953531

Code No: 953521

During installation, place disc in depicted position (A) to allow an upward tilt of 50 and a downward tilt of 15.

90º + 90º horizontal adjustment

A 50º 15º

During installation, place disc in depicted position (B) to allow an upward tilt of 15 and a downward tilt of 50.

15º 50º

Page 211 for Mounting Accessories 249

BELKIS 1

LOW VOLTAGE HALOGEN SPOTS Class III IP67 IK10

Available in any of these RAL colors

7004

7016

9005

WITH SIDE ARM

9016

6002

1015

Ø 62

For mounting on surface or in ground with picket 112

Lampholder : Gu4 Reflector

: -

Diffuser

: 8 mm Glass

Ø 80

Transformer is not included. Remote transformer should be used. HALOGEN 12V 20W (10º or 38º)

Code No 330101 135º 90º

30º 135º

90º + 30º vertical adjustment 270º horizontal adjustment Picket

Visor

Honeycomb

Code No: 953805

Code No: 953531

Code No: 953521

During installation, place disc in depicted position (A) to allow an upward tilt of 50 and a downward tilt of 15.

A 50º 15º

During installation, place disc in depicted position (B) to allow an upward tilt of 15 and a downward tilt of 50.

15º 50º

Page 211 for Mounting Accessories 250

BELKIS

Mounting Accessories for BELKIS 1 SPOTS

Alternate Arms (to aluminium side or central arms) Electrostatic powder painted steel Please indicate below code number in combination with the code number of the desired spot CODE NO 953801

CODE NO 953802

108

CODE NO 953803

103

Vertically adjustable ± 45º Horizantaly adjustable ± 60º

408

Only vertically adjustable ± 45º

Vertically adjustable ± 45º Horizantaly adjustable ± 90º

Pickets Electrostatic powder painted steel Please indicate below code number in combination with the code number of the desired spot CODE NO 953804

CODE NO 953805

CODE NO 953806

300

440

459

Pickets for round base 300 mm

Picket for gear box base 440 mm

Picket mounted on body 459 mm

Pole Die cast aluminium Please indicate below code number in combination with the code number of the desired spot CODE NO 953807

CODE NO 953808

5,2

Ø 76,5

5,2

Ø 76,1

Pole adaptor in place of round base For 76.1 mm (3 inch) pole thickness

CODE NO 953809

Pole adaptor for gear box For 76.1 mm (3 inch) pole thickness

CODE NO 953810

5,2

60 60

5,2

Ø 101,6

Pole adaptor in place of round base For 101.6 mm (4 inch) pole thickness

Ø 101,6

Pole adaptor for gear box For 101.6 mm (4 inch) pole thickness

251

252

BELKIS 2

LED SPOTS LED DRIVER IN BASE Class I IP67 IK10

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

For mounting on surface or in ground with picket or on pole (with adaptor)

3 x 350 mA (3 W) LED or 3 x 700 mA (9 W) LED Voltage

Ø 82

: 240V A.C with integrated driver

164

(24V AC or DC on request) Lens

: 10º, 25º, 40º

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

POWERLED Warm White Natural White Cool White Blue Red Amber Green

Total Lighting Output Code No 3W 9W 3W 9W 331211 331231 3000 K 255 lm 675 lm 331216 331232 4500 K 255 lm 675 lm 331217 331233 6000 K 306 lm 810 lm 331212 331234 331213 331235 331214 331236 331215 331237

Picket

Visor

Honeycomb

Code No: 953825

Code No: 953532

Code No: 953522

During installation, place disc in depicted position (A) to allow an upward tilt of 50 and a downward tilt of 15.

90º

90º + 90º horizontal adjustment

A 50º 15º

During installation, place disc in depicted position (B) to allow an upward tilt of 15 and a downward tilt of 50.

15º 50º

Page 225 for Mounting Accessories 253

254

BELKIS 2

LED SPOTS LED DRIVER IN BASE Class I IP67 IK10

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

For mounting on surface or in ground with picket or on pole (with adaptor)

3 x 350 mA (3 W) LED or 3 x 700 mA (9 W) LED Voltage

Ø 82

: 240V A.C with integrated driver

164

(24V AC or DC on request) Lens

: 10º, 25º, 40º

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

Gearbox

: Equipped with 1xPG 11 cable gland and stainless steel cover

Avaible with 2xPG 11 cable gland for through cabling on request POWERLED Warm White Natural White Cool White Blue Red Amber Green

Total Lighting Output Code No 3W 9W 3W 9W 331241 331251 3000 K 255 lm 675 lm 331242 331252 4500 K 255 lm 675 lm 331243 331253 6000 K 306 lm 810 lm 331244 331254 331245 331255 331246 331256 331247 331257

Picket

Visor

Honeycomb

Code No: 953825

Code No: 953532

Code No: 953522

During installation, place disc in depicted position (A) to allow an upward tilt of 50 and a downward tilt of 15.

90º

90º + 90º horizontal adjustment

A 50º 15º

During installation, place disc in depicted position (B) to allow an upward tilt of 15 and a downward tilt of 50.

15º 50º

Page 225 for Mounting Accessories 255

BELKIS 2

LED SPOT WITH TIR LENS FIXTURES LED DRIVER IN BASE Class I IP67 IK10

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

For mounting on surface or in ground with picket or on pole (with adaptor)

1 x 350 mA (3 W) LED or 1 x 350 mA (11 W) LED

Ø 82 164

Warm White Natural White

Total Lighting Output Code No 3W 11W 3W 11W 121001 121011 3000 K 198 lm 655 lm 121002 121012 4000 K 237 lm 786 lm

Voltage

: 240V A.C with integrated driver

Lens

: 10º, 20º, 30º Mirror TIR Lens

(24V AC or DC on request)

90º

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

90º

90º + 90º horizontal adjustment

Picket

Visor

Code No: 953825

Code No: 953532

Honeycomb

Code No: 953522

During installation, place disc in depicted position (A) to allow an upward tilt of 50 and a downward tilt of 15.

10º

20º

30º

2m Ø 0,35m 0,10m²

7020 lx

2m Ø 0,71m 0,39m²

1930 lx

2m Ø 0,90m 1,49m²

924 lx

4m Ø 0,70m 0,38m²

1755 lx

4m Ø 1,41m 1,56m²

483 lx

4m Ø 3,61m 5,97m²

231 lx

6m Ø 1,05m 0,87m²

780 lx

6m Ø 2,12m 3,52m²

214 lx

6m Ø 8,13m 13,40m²

103 lx

8m Ø 1,40m 1,54m²

439 lx

8m Ø 2,82m 6,26m²

121 lx

8m Ø 14,45m 23,84m²

58 lx

10m Ø 1,75m 2,40m²

281 lx

10m Ø 3,53m 9,78m²

84 lx

10m Ø 5,36m 22,58m²

37 lx

A 50º 15º

During installation, place disc in depicted position (B) to allow an upward tilt of 15 and a downward tilt of 50.

15º 50º

Page 225 for Mounting Accessories 256

BELKIS 2

LED SPOT LED DRIVER IN BASE Class I IP67 IK10

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

For mounting on surface or in ground with picket or on pole (with adaptor)

1 x 350 mA (11 W) LED or 1 x 500 mA (18 W) LED

Ø 82 164

Warm White Natural White

Total Lighting Output Code No 11W 18W 11W 18W 331262 331271 3000 K 696 lm 1224 lm 331263 331272 4000 K 835 lm 1469 lm

Voltage

: 240V A.C with integrated driver

Lens

: 10º, 23º, 38º Aluminium-Coated Polycarbonate Reflector

(24V AC or DC on request)

90º

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

90º

90º + 90º horizontal adjustment 10º Picket

Visor

Code No: 953825

Code No: 953532

Honeycomb

Code No: 953522

During installation, place disc in depicted position (A) to allow an upward tilt of 50 and a downward tilt of 15.

23º

38º

2m Ø 0,35m 0,01m²

13759 lx

2m Ø 0,81m 0,52m²

2705 lx

2m Ø 1,38m 1,49m²

989 lx

4m Ø 0,70m 0,38m²

3440 lx

4m Ø 1,63m 2,08m²

676 lx

4m Ø 2,76m 5,97m²

247 lx

6m Ø 1,05m 0,87m²

1529 lx

6m Ø 2,44m 4,68m²

301 lx

6m Ø 4,13m 13,40m²

110 lx

8m Ø 1,40m 1,54m²

861 lx

8m Ø 3,26m 8,33m²

169 lx

8m Ø 5,51m 23,84m²

62 lx

10m Ø 1,75m 2,40m²

550 lx

10m Ø 4,07m 13,02m²

108 lx

10m Ø 6,89m 37,29m²

40 lx

A 50º 15º

During installation, place disc in depicted position (B) to allow an upward tilt of 15 and a downward tilt of 50.

15º 50º

Page 225 for Mounting Accessories 257

BELKIS 2

LED SPOTS LED DRIVER IN HEAD Class I IP67 IK10

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

For mounting on surface or in ground with picket or on pole (with adaptor)

3 x 350 mA (3 W) LED Voltage

: 240V A.C with integrated driver

Lens

: 10º, 25º, 40º

Ø 82 142

(24V AC or DC on request) Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

Warm White Natural White Cool White Blue Red Amber Green

3000 K 4500 K 6000 K

Total Lighting Output 255 lm 255 lm 306 lm

Ø 84

Code No 331201 331206 331207 331202 331203 331204 331205

Picket

Visor

Honeycomb

Code No: 953825

Code No: 953532

Code No: 953522

During installation, place disc in depicted position (A) to allow an upward tilt of 50 and a downward tilt of 15.

90º

90º + 90º horizontal adjustment

A 50º 15º

During installation, place disc in depicted position (B) to allow an upward tilt of 15 and a downward tilt of 50.

15º 50º

Page 225 for Mounting Accessories 258

259

BELKIS 2

RGB LED SPOT LED DRIVER IN BASE Class I IP67 IK10

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

For mounting on surface or in ground with picket or on pole (with adaptor)

9W 350 mA RGB LED

Ø 82

Voltage

: 240V A.C with remote driver

Lens

: 25º (40º on request)

164

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Cable

: Potted 10 m 4x0,75 H03 VV-F cable

Control by DMX, remote control, or push button 9 x 350 mA (9 W) RGB LED

Code No 331221 90º

90º

90º + 90º horizontal adjustment Picket

Visor

Honeycomb

Code No: 953825

Code No: 953532

Code No: 953522

During installation, place disc in depicted position (A) to allow an upward tilt of 50 and a downward tilt of 15.

A 50º 15º

During installation, place disc in depicted position (B) to allow an upward tilt of 15 and a downward tilt of 50.

15º 50º

Page 225 for Mounting Accessories 260

BELKIS 2

LOW VOLTAGE HALOGEN SPOTS Class I IP67 IK10

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

WITH SIDE ARM For mounting on surface or in ground with picket

Ø 82

Lampholder : Gu 5,3

138

Reflector

: -

Diffuser

: 8 mm Glass

Transformer is not included

Ø 80

Remote transformer should be used Code No HALOGEN 12V 35W/50W (10º or 38º) 331101 135º

135º

270º horizontal adjustment Picket

Visor

Honeycomb

Code No: 953825

Code No: 953532

Code No: 953522

During installation, place disc in depicted position (A) to allow an upward tilt of 50 and a downward tilt of 15.

90º + 15º vertical adjustment

A 50º 15º

During installation, place disc in depicted position (B) to allow an upward tilt of 15 and a downward tilt of 50.

15º 50º

Page 225 for Mounting Accessories 261

BELKIS 2

LOW VOLTAGE HALOGEN SPOTS Class I IP67 IK10

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

WITH CENTRAL ARM For mounting on surface or on polez

Ø 82

Lampholder : Gu 5,3

139

Reflector

: -

Diffuser

: 8 mm Glass

Transformer is not included

Ø 84

Remote transformer should be used Code No HALOGEN 12V 35W/50W (10º or 38º) 331111 90º

90º

90º + 90º horizontal adjustment

Picket

Visor

Honeycomb

Code No: 953825

Code No: 953532

Code No: 953522

During installation, place disc in depicted position (A) to allow an upward tilt of 50 and a downward tilt of 15.

A 50º 15º

During installation, place disc in depicted position (B) to allow an upward tilt of 15 and a downward tilt of 50.

15º 50º

Page 225 for Mounting Accessories 262

263

BELKIS 2

LOW VOLTAGE HALOGEN SPOTS Class I IP67 IK10

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

WITH CENTRAL ARM & GEAR BOX For mounting on surface or in ground with picket or on pole (with adaptor)

Ø 82

Lampholder : Gu 5.3 Reflector

161

: -

Diffuser

: 8 mm Glass

Cable

: Potted 5 m 3x0,75 H03 VV-F

Transformer potted in base.

Code No HALOGEN 12V 35W/50W (25º or 50º) 331131 90º

90º

90º + 90º horizontal adjustment

Picket

Visor

Honeycomb

Code No: 953825

Code No: 953532

Code No: 953522

During installation, place disc in depicted position (A) to allow an upward tilt of 50 and a downward tilt of 15.

A 50º 15º

During installation, place disc in depicted position (B) to allow an upward tilt of 15 and a downward tilt of 50.

15º 50º

Page 225 for Mounting Accessories 264

BELKIS 2

HALOGEN SPOT Class I IP67 IK10

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

WITH SIDE ARM For mounting on surface or in ground with picket

Ø 82

Lampholder : Gu 10

138

Reflector

: -

Diffuser

: 8 mm Glass

Code No HALOGEN 240V 35W/50W (25º or 50º) 331121

Ø 80

135º

270º horizontal adjustment Picket

Visor

Honeycomb

Code No: 953825

Code No: 953532

Code No: 953522

During installation, place disc in depicted position (A) to allow an upward tilt of 50 and a downward tilt of 15.

90º + 15º vertical adjustment

A 50º 15º

During installation, place disc in depicted position (B) to allow an upward tilt of 15 and a downward tilt of 50.

15º 50º

Page 225 for Mounting Accessories 265

BELKIS 2

HALOGEN SPOT Class I IP67 IK10

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

WITH CENTRAL ARM For mounting on surface or on pole

Ø 82

Lampholder : Gu 10

139

Reflector

: -

Diffuser

: 8 mm Glass

Code No HALOGEN 240V 35W/50W (25º or 50º) 331141

Ø 84

90º

90º + 90º horizontal adjustment

Picket

Visor

Honeycomb

Code No: 953825

Code No: 953532

Code No: 953522

During installation, place disc in depicted position (A) to allow an upward tilt of 50 and a downward tilt of 15.

A 50º 15º

During installation, place disc in depicted position (B) to allow an upward tilt of 15 and a downward tilt of 50.

15º 50º

Page 225 for Mounting Accessories 266

BELKIS

Mounting Accessories for BELKIS 2 SPOTS

Alternate Arms (to aluminium side or central arms) Electrostatic powder painted steel Please indicate below code number in combination with the code number of the desired spot CODE NO 953821

CODE NO 953822

108

103

CODE NO 953823

408

Vertically adjustable ± 45º Horizantaly adjustable ± 60º

Only vertically adjustable ± 45º

Vertically adjustable ± 45º Horizantaly adjustable ± 90º

Pickets Electrostatic powder painted steel Please indicate below code number in combination with the code number of the desired spot CODE NO 953824

CODE NO 953825

CODE NO 953826

440

459

300

Pickets for round base 300 mm

Picket for gear box base 440 mm

Picket mounted on body 466 mm

Pole Die cast aluminium Please indicate below code number in combination with the code number of the desired spot CODE NO 953827

CODE NO 953828

5,2

Pole adaptor in place of round base For 76.1 mm (3 inch) pole thickness

CODE NO 953829

Pole adaptor for gear box For 76.1 mm (3 inch) pole thickness

CODE NO 953830

5,2

Ø 101,6

Ø 76,1

Ø 101,6

Pole adaptor in place of round base For 101.6 mm (4 inch) pole thickness

Pole adaptor for gear box For 101.6 mm (4 inch) pole thickness

267

BELKIS 3

LED SPOT LED DRIVER IN BASE Class I IP67 IK10

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

For mounting on surface or in ground with picket or on pole (with adaptor)

6 x 350 mA (6 W) LED or 6 x 700 mA (18 W) LED Voltage

Ø 107

: 240V A.C with integrated driver 188

(24V AC or DC on request) Lens

: 10º, 25º, 40º

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

POWERLED Warm White Natural White Cool White Blue Red Amber Green

Total Lighting Output Code No 6W 18W 6W 18W 331311 331331 3000 K 510 lm 1350 lm 331316 331332 4500 K 510 lm 1350 lm 331317 331333 6000 K 612 lm 1620 lm 331312 331334 331313 331335 331314 331336 331315 331337

Picket

Visor

Honeycomb

Code No: 953845

Code No: 953533

Code No: 953523

During installation, place disc in depicted position (A) to allow an upward tilt of 50 and a downward tilt of 15.

90º

90º + 90º horizontal adjustment

A 50º 15º

During installation, place disc in depicted position (B) to allow an upward tilt of 15 and a downward tilt of 50.

15º 50º

Page 232 for Mounting Accessories 268

269

BELKIS 3

LED SPOT LED DRIVER IN BASE Class I IP67 IK10

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

For mounting on surface or in ground with picket or on pole (with adaptor)

6 x 350 mA (6 W) LED or 6 x 700 mA (18 W) LED Voltage

Ø 107

: 240V A.C with integrated driver

188

(24V AC or DC on request) Lens

: 10º, 25º, 40º

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Gearbox

: Equipped with 1xPG 11 cable gland and stainnless steel cover

Available with 2xPG 11 cable gland for through cabling on request POWERLED Warm White Natural White Cool White Blue Red Amber Green

Total Lighting Output Code No 6W 18W 6W 18W 331341 331351 3000 K 510 lm 1350 lm 331342 331352 4500 K 510 lm 1350 lm 331343 331353 6000 K 612 lm 1620 lm 331344 331354 331345 331355 331346 331356 331347 331357

Picket

Visor

Honeycomb

Code No: 953845

Code No: 953533

Code No: 953523

During installation, place disc in depicted position (A) to allow an upward tilt of 50 and a downward tilt of 15.

90º

90º + 90º horizontal adjustment

A 50º 15º

During installation, place disc in depicted position (B) to allow an upward tilt of 15 and a downward tilt of 50.

15º 50º

Page 232 for Mounting Accessories 270

BELKIS 3

RGB LED SPOT LED DRIVER IN REMOTE DRIVER Class I IP67 IK10

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

For mounting on surface or in ground with picket or on pole (with adaptor)

18 x 350 mA (18 W) RGB LED

Ø 107

Voltage

: 240V A.C with remote driver

Lens

: 25º (40º on request)

Diffuser

: Clear Glass 8 mm

Cable

: Potted 10 m 4x0,75 H03 VV-F

188

RGB POWERLED

Control by DMX, remote control, or push button Code No 331321

90º

90º + 90º horizontal adjustment

Picket

Visor

Honeycomb

Code No: 953845

Code No: 953533

Code No: 953523

During installation, place disc in depicted position (A) to allow an upward tilt of 50 and a downward tilt of 15.

A 50º 15º

During installation, place disc in depicted position (B) to allow an upward tilt of 15 and a downward tilt of 50.

15º 50º

Page 232 for Mounting Accessories 271

272

BELKIS 3

LED SPOT WITH TIR LENS FIXTURES LED DRIVER IN BASE Class I IP67 IK10

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

For mounting on surface or in ground with picket or on pole (with adaptor)

1 x 350 mA (12 W) LED or 1 x 500 mA (18 W) LED

Ø 107 188

Warm White Natural White

Total Lighting Output Code No 12W 18W 12W 18W 121101 121111 3000 K 655 lm 1153 lm 121102 121112 4000 K 786 lm 1383 lm

Voltage

: 240V A.C with integrated driver

Lens

: 10º, 20º, 30º Mirror TIR Lens

(24V AC or DC on request)

90º

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

90º

90º + 90º horizontal adjustment 10º Picket

Visor

Code No: 953845

Code No: 953533

Honeycomb

Code No: 953523

During installation, place disc in depicted position (A) to allow an upward tilt of 50 and a downward tilt of 15.

20º

30º

2m Ø 0,35m 0,10m²

12336lx

2m Ø 0,71m 0,39m²

3438 lx

2m Ø 1,07m 0,90m²

1644 lx

4m Ø 0,70m 0,38m²

3084 lx

4m Ø 1,41m 1,56m²

860 lx

4m Ø 2,14m 3,61m²

411lx

6m Ø 1,05m 0,87m²

1371lx

6m Ø 2,12m 3,52m²

382 lx

6m Ø 3,22m 8,13m²

183 lx

8m Ø 1,40m 1,54m²

771 lx

8m Ø 2,82m 6,26m²

215 lx

8m Ø 4,29m 14,45m²

10m Ø 1,75m 2,40m²

493 lx

10m Ø 3,53m 9,78m²

138 lx

10m Ø 5,36m 22,58m²

103 lx 66 lx

A 50º 15º

During installation, place disc in depicted position (B) to allow an upward tilt of 15 and a downward tilt of 50.

15º 50º

Page 232 for Mounting Accessories 273

BELKIS 3

LED SPOT LED DRIVER IN HEAD Class I IP67 IK10

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

For mounting on surface or on pole

6 x 350 mA (6 W) LED Voltage

Ø 107

: 240V A.C with integrated driver

195

(24V AC or DC on request) Lens

: 10º, 25º, 40º

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

Warm White Natural White Cool White Blue Red Amber Green

3000 K 4500 K 6000 K

Total Lighting Output 510 lm 510 lm 612 lm

Ø 140

Code No 331301 331306 331307 331302 331303 331304 331305

Picket

Visor

Honeycomb

Code No: 953845

Code No: 953533

Code No: 953523

During installation, place disc in depicted position (A) to allow an upward tilt of 50 and a downward tilt of 15.

90º

90º + 90º horizontal adjustment

A 50º 15º

During installation, place disc in depicted position (B) to allow an upward tilt of 15 and a downward tilt of 50.

15º 50º

Page 232 for Mounting Accessories 274

275

BELKIS

Mounting Accessories for BELKIS 3 SPOTS

Alternate Arms (to aluminium side or central arms) Electrostatic powder painted steel Please indicate below code number in combination with the code number of the desired spot CODE NO 953841

CODE NO 953842

128

123

CODE NO 953843

428

Vertically adjustable ± 45º Horizantaly adjustable ± 60º

Only vertically adjustable ± 45º

Vertically adjustable ± 45º Horizantaly adjustable ± 90º

Pickets Electrostatic powder painted steel Please indicate below code number in combination with the code number of the desired spot CODE NO 953844

CODE NO 953845

CODE NO 953846

479 440 300

Pickets for round base 300 mm

Picket for gear box base 440 mm

Picket mounted on body 479 mm

Pole Adaptors Die cast aluminium Please indicate below code number in combination with the code number of the desired spot CODE NO 953847

CODE NO 953848

5,2

Ø 76,1

CODE NO 953849

5,2

Pole adaptor in place of round base For 101.6 mm (4 inch) pole thickness 276

Pole adaptor for gear box For 76.1 mm (3 inch) pole thickness

CODE NO 953850

5,2

Ø 101,6

Ø 76,1

Pole adaptor in place of round base For 76.1 mm (3 inch) pole thickness

5,2

60 Ø 101,6

Pole adaptor for gear box For 101.6 mm (4 inch) pole thickness

277

BELKIS 4

LED SPOT LED DRIVER IN BASE Class I IP67 IK10

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

For mounting on surface or in ground with picket or on pole (with adaptor)

9 x 350 mA (9 W) LED or 9 x 700 mA (27 W) LED Voltage

Ø 127

: 240V A.C with integrated driver (24V AC or DC on request)

232

Lens

: 10º, 25º, 40º

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

POWERLED Warm White Natural White Cool White Blue Red Amber Green

Total Lighting Output Code No 9W 27W 9W 27W 331411 331421 3000 K 765 lm 2100 lm 331416 331422 4500 K 765 lm 2100 lm 331417 331423 6000 K 810 lm 2520 lm 331412 331424 331413 331425 331414 331426 331415 331427

Picket

Visor

Honeycomb

Code No: 953865

Code No: 953534

Code No: 953524

During installation, place disc in depicted position (A) to allow an upward tilt of 50 and a downward tilt of 15.

130

100

90º

90º + 90º horizontal adjustment

A 50º 15º

During installation, place disc in depicted position (B) to allow an upward tilt of 15 and a downward tilt of 50.

15º 50º

Page 238 for Mounting Accessories 278

BELKIS 4

LED SPOT LED DRIVER IN BASE Class I IP55 IK10

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

For mounting on surface or in ground with picket

9 x 350 mA (9 W) LED Voltage : 240V A.C with integrated driver

Ø 127

(24V AC or DC on request)

232

Lens

: 10º, 25º, 40º

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Gearbox

: Equipped with 1xPG 11 cable gland and stainnless steel cover

Available with 2xPG 11 cable gland for through cabling on request 130

POWERLED Warm White Natural White Cool White Blue Red Amber Green

Total Lighting Output Code No 9W 27W 9W 27W 331431 331441 3000 K 765 lm 2100 lm 331432 331442 4500 K 765 lm 2100 lm 331433 331443 6000 K 810 lm 2520 lm 331434 331444 331435 331445 331436 331446 331437 331447

Picket

Visor

Honeycomb

Code No: 953865

Code No: 953534

Code No: 953524

During installation, place disc in depicted position (A) to allow an upward tilt of 50 and a downward tilt of 15.

100

90º

90º + 90º horizontal adjustment

A 50º 15º

During installation, place disc in depicted position (B) to allow an upward tilt of 15 and a downward tilt of 50.

15º 50º

Page 238 for Mounting Accessories 279

280

BELKIS 4

LED SPOT WITH TIR LENS FIXTURES LED DRIVER IN BASE Class I IP67 IK10

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

For mounting on surface or in ground with picket or on pole (with adaptor)

1 x 700 mA (25 W) LED or 1 x 900 mA (32 W) LED

Warm White Natural White

Ø 127 232

Total Lighting Output Code No 25W 32W 25W 32W 121201 121211 3000 K 1645 lm 2134 lm 121202 121212 4000 K 1974 lm 2561 lm

130

Voltage

: 240V A.C with integrated driver

Lens

: 10º, 20º, 30º Mirror TIR Lens

100

(24V AC or DC on request) 90º

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

90º

90º + 90º horizontal adjustment

10º Picket

Visor

Code No: 953865

Code No: 953534

Honeycomb

Code No: 953524

During installation, place disc in depicted position (A) to allow an upward tilt of 50 and a downward tilt of 15.

20º

30º

2m Ø 0,35m 0,10m²

22813lx

2m Ø 0,71m 0,39m²

6261 lx

2m Ø 0,90m 1,49m²

2953lx

4m Ø 0,70m 0,38m²

5703 lx

4m Ø 1,41m 1,56m²

1565lx

4m Ø 3,61m 5,97m²

738 lx

6m Ø 1,05m 0,87m²

2535 lx

6m Ø 2,12m 3,52m²

696 lx

6m Ø 8,13m 13,40m²

328 lx

8m Ø 1,40m 1,54m²

1426 lx

8m Ø 2,82m 6,26m²

391 lx

8m Ø 14,45m 23,84m²

185 lx

10m Ø 1,75m 2,40m²

913 lx

10m Ø 3,53m 9,78m²

250 lx

10m Ø 5,36m 22,58m²

118 lx

A 50º 15º

During installation, place disc in depicted position (B) to allow an upward tilt of 15 and a downward tilt of 50.

15º 50º

Page 238 for Mounting Accessories 281

282

BELKIS 4

LED SPOT LED DRIVER IN HEAD Class I IP67 IK10

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

For mounting on surface or on pole

9 x 350 mA (9 W) LED Voltage : 240V A.C with integrated driver

Ø 127 215

(24V AC or DC on request) Lens

: 10º, 25º, 40º

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

Warm White Natural White Cool White Blue Red Amber Green

3000 K 4500 K 6000 K

Total Lighting Output 765 lm 765 lm 810 lm

Ø 130

Code No 331401 331406 331407 331402 331403 331404 331405

Picket

Visor

Honeycomb

Code No: 953864

Code No: 953534

Code No: 953524

During installation, place disc in depicted position (A) to allow an upward tilt of 50 and a downward tilt of 15.

90º

90º + 90º horizontal adjustment

A 50º 15º

During installation, place disc in depicted position (B) to allow an upward tilt of 15 and a downward tilt of 50.

15º 50º

Page 238 for Mounting Accessories 283

BELKIS

Mounting Accessories for BELKIS 4 SPOTS

Alternate Arms (to aluminium side or central arms) Electrostatic powder painted steel Please indicate below code number in combination with the code number of the desired spot CODE NO 953861

CODE NO 953862

174

153

CODE NO 953863

438

Vertically adjustable ± 45º Horizantaly adjustable ± 60º

Only vertically adjustable ± 45º

Vertically adjustable ± 45º Horizantaly adjustable ± 90º

Pickets Electrostatic powder painted steel Please indicate below code number in combination with the code number of the desired spot CODE NO 953864

CODE NO 953865

CODE NO 953866

480

489

300

Pickets for round base 300 mm

Picket for gear box base 480 mm

Picket mounted on body 489 mm

Pole Adaptors Die cast aluminium Please indicate below code number in combination with the code number of the desired spot CODE NO 953867

CODE NO 953868

5,2

60 60

5,2 60

Ø 76,1 Ø 76,1

Pole adaptor in place of round base For 76.1 mm (3 inch) pole thickness

CODE NO 953869

Pole adaptor for gear box For 76.1 mm (3 inch) pole thickness

CODE NO 953870

5,2

60 Ø 101,6

Pole adaptor in place of round base For 101.6 mm (4 inch) pole thickness 284

5,2

Ø 101,6

Pole adaptor for gear box For 101.6 mm (4 inch) pole thickness

BELKIS 5

LED SPOT LED DRIVER IN BASE Class I IP67 IK10

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

For mounting on surface or in ground with picket or on pole (with adaptor)

9 x 350 mA (9 W) LED or 9 x 700 mA (27 W) LED Voltage

Ø 145

: 240V A.C with integrated driver (24V AC or DC on request)

Lens

250

: 10º, 25º, 40º

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

100

130

POWERLED Warm White Natural White Cool White Blue Red Amber Green

Total Lighting Output Code No 9W 27W 9W 27W 425631 425651 3000 K 765 lm 2100 lm 425636 425652 4500 K 765 lm 2100 lm 425637 425653 6000 K 810 lm 2520 lm 425632 425654 425633 425655 425634 425656 425635 425657

Picket

Visor

Honeycomb

Code No: 953885

Code No: 953535

Code No: 953525

During installation, place disc in depicted position (A) to allow an upward tilt of 50 and a downward tilt of 15.

90º

90º + 90º horizontal adjustment

A 50º 15º

During installation, place disc in depicted position (B) to allow an upward tilt of 15 and a downward tilt of 50.

15º 50º

Page 253 for Mounting Accessories 285

BELKIS 5

LED SPOT LED DRIVER IN BASE Class I IP67 IK10

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

For mounting on surface or in ground with picket or on pole (with adaptor)

9 x 350 mA (9 W) LED or 9 x 700 mA (27 W) LED Ø 145

Voltage

: 240V A.C with integrated driver

250

(24V AC or DC on request) Lens

: 10º, 25º, 40º

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Gearbox

: Equipped with 1xPG 11 cable gland and stainnless steel cover

Available with 2xPG 11 cable gland for through cabling on request POWERLED Warm White Natural White Cool White Blue Red Amber Green

Visor

Honeycomb

Code No: 953885

Code No: 953535

Code No: 953525

During installation, place disc in depicted position (A) to allow an upward tilt of 50 and a downward tilt of 15.

100

130

Total Lighting Output Code No 9W 27W 9W 27W 425661 425671 3000 K 765 lm 2100 lm 425662 425672 4500 K 765 lm 2100 lm 425663 425673 6000 K 810 lm 2520 lm 425664 425674 425665 425675 425666 425676 425667 425677

Picket

90º

90º + 90º horizontal adjustment

A 50º 15º

During installation, place disc in depicted position (B) to allow an upward tilt of 15 and a downward tilt of 50.

15º 50º

Page 253 for Mounting Accessories 286

BELKIS 5

LED SPOT LED DRIVER IN HEAD Class I IP67 IK10

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

For mounting on surface or on pole

9 x 350 mA (9 W) LED Voltage

145

: 240V A.C with integrated driver

233

(24V AC or DC on request) Lens

: 10º, 25º, 40º

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F Ø 140

Warm White Natural White Cool White Blue Red Amber Green

3000 K 4500 K 6000 K

Total Lighting Output Code No 765 lm 425611 765 lm 425616 810 lm 425617 425612 425613 425614 425615

Picket

Visor

Honeycomb

Code No: 953844

Code No: 953535

Code No: 953525

During installation, place disc in depicted position (A) to allow an upward tilt of 50 and a downward tilt of 15.

90º

90º + 90º horizontal adjustment

A 50º 15º

During installation, place disc in depicted position (B) to allow an upward tilt of 15 and a downward tilt of 50.

15º 50º

Page 253 for Mounting Accessories 287

BELKIS 5

RGB LED SPOT REMOTE LED DRIVER Class I IP67 IK10

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

For mounting on surface or on pole

27 x 350 mA (27 W) RGB LED Ø 145

Voltage

: 240V A.C

Lens

: 25º (40º on request)

233

Diffuser

: Clear Glass 8 mm

Cable

: Potted 10 m 4x0,75 H03 VV-F

Control by DMX remote control or push button 140

RGB POWERLED

Code No 425641

90º

90º + 90º horizontal adjustment

Picket

Visor

Honeycomb

Code No: 953844

Code No: 953535

Code No: 953525

During installation, place disc in depicted position (A) to allow an upward tilt of 50 and a downward tilt of 15.

A 50º 15º

During installation, place disc in depicted position (B) to allow an upward tilt of 15 and a downward tilt of 50.

15º 50º

Page 253 for Mounting Accessories 288

289

BELKIS 5

HALOGEN SPOTS Class I IP67 IK10

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

WITH SIDE ARM For mounting on surface or in ground with picket

Lampholder : E27

Ø 145 218

Reflector

: -

Diffuser

: 8 mm Clear Glass

HALOGEN 240V PAR 30 75W

Code No 332121

(10º or 30º)

Ø 140

135º

90º 15º

135º

Picket

Visor

Honeycomb

Code No: 953884

Code No: 953535

Code No: 953525

During installation, place disc in depicted position (A) to allow an upward tilt of 50 and a downward tilt of 15.

270º horizontal adjustment

90º + 15º vertical adjustment

A 50º 15º

During installation, place disc in depicted position (B) to allow an upward tilt of 15 and a downward tilt of 50.

15º 50º

Page 253 for Mounting Accessories 290

BELKIS 5

HALOGEN SPOTS Class I IP67 IK10

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

WITH CENTRAL ARM For mounting on surface or in ground with picket

Lampholder : E27

Ø 145

Reflector

: -

Diffuser

: 8 mm Clear Glass

237

HALOGEN 240V PAR 30 75W

Code No 332131

(10º or 30º)

Ø 140

90º

90º + 90º horizontal adjustment

Picket

Visor

Honeycomb

Code No: 953884

Code No: 953535

Code No: 953525

During installation, place disc in depicted position (A) to allow an upward tilt of 50 and a downward tilt of 15.

A 50º 15º

During installation, place disc in depicted position (B) to allow an upward tilt of 15 and a downward tilt of 50.

15º 50º

Quad

Page 253 for Mounting Accessories 291

292

BELKIS 5

SPOTS Class I IP67 IK10

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

WITH SIDE ARM For mounting on surface or in ground with picket

Lampholder : Gx 53

Ø 145

Reflector

: -

Diffuser

: 8 mm Clear Glass

Lamp

: Included

Gear

: Electronic (in lamp)

238

COMPACT FLUO. AR 111 11W (45º)

Code No 332141

Ø 140

90º

90º + 90º horizontal adjustment

Picket

Visor

Honeycomb

Code No: 953884

Code No: 953535

Code No: 953525

During installation, place disc in depicted position (A) to allow an upward tilt of 50 and a downward tilt of 15.

A 50º 15º

During installation, place disc in depicted position (B) to allow an upward tilt of 15 and a downward tilt of 50.

15º 50º

Page 253 for Mounting Accessories 293

BELKIS 5

METAL HALIDE SPOTS Class I IP67 IK10

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

WITH CENTRAL ARM For mounting on surface or in ground with picket

Lampholder : PGJ 5 Reflector

Ø 145

: 25º

233

Diffuser

: 8 mm Clear Glass

Gear

: Electronic (in head) Code No 332151

METAL HALIDE 20W

Ø 140

90º

90º + 90º horizontal adjustment

Picket

Visor

Honeycomb

Code No: 953884

Code No: 953535

Code No: 953525

During installation, place disc in depicted position (A) to allow an upward tilt of 50 and a downward tilt of 15.

A 50º 15º

During installation, place disc in depicted position (B) to allow an upward tilt of 15 and a downward tilt of 50.

15º 50º

Page 253 for Mounting Accessories 294

295

BELKIS 5

SPOTS WITH GEARBOX Class I IP67 IK10

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

Lampholder : G 8.5 Reflector

: 9º, 17º, 25º

Gear

: Electronic

Cable

Ø 145 241

: Potted 5 m 3x0,75 H05 VV-F

METAL HALIDE 35W/70W 35W 70W

Code No 332181 332191

130

100

Lampholder : Gx8.5 Reflector

: -

Gear

: Electronic

Cable

: Potted 5 m 3x0,75 H05 VV-F

90º

METAL HALIDE CDMR-111 35W/70W 10º or 40º

Code No 332201 332211

35W 70W

90º + 90º horizontal adjustment

Picket

Visor

Honeycomb

Code No: 953885

Code No: 953535

Code No: 953525

During installation, place disc in depicted position (A) to allow an upward tilt of 50 and a downward tilt of 15.

A 50º 15º

During installation, place disc in depicted position (B) to allow an upward tilt of 15 and a downward tilt of 50.

15º 50º

Page 253 for Mounting Accessories 296

297

BELKIS 5

SPOTS WITH GEARBOX Class I IP67 IK10

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

Lampholder : G 8.5 Reflector

: 9º, 17º, 25º

Gear

: Electronic

Cable

Ø 145 241

: Potted 5 m 3x0,75 H05 VV-F

METAL HALIDE 35W/70W 35W 70W

Code No 425681 425691

130

100

Lampholder : G 8.5 Reflector

Gear

: Electronic

Cable

: Potted 5 m 3x0,75 H05 VV-F

90º

METAL HALIDE CDMR-111 35W/70W 10º or 40º

Code No 425701 425711

35W 70W

90º + 90º horizontal adjustment

Picket

Visor

Honeycomb

Code No: 953885

Code No: 953535

Code No: 953525

During installation, place disc in depicted position (A) to allow an upward tilt of 50 and a downward tilt of 15.

A 50º 15º

During installation, place disc in depicted position (B) to allow an upward tilt of 15 and a downward tilt of 50.

15º 50º

Page 253 for Mounting Accessories 298

299

BELKIS 5

SPOTS WITH GEARBOX Class I IP67 IK10

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

Lampholder : G 8.5 Reflector

: 9º, 17º, 25º

Gear

: Electronic

Cable

: Potted 5 m 3x0,75 H05 VV-F

METAL HALIDE 35W/70W 35W 70W

Ø 145 270

Code No 332221 332231

71,5

200

Lampholder : G 8.5 Reflector

Gear

: Electronic

Cable

: Potted 5 m 3x0,75 H05 VV-F

144

90º

METAL HALIDE CDMR-111 35W/70W 10º or 40º 35W 70W

Code No 332241 332251

Visor

Honeycomb

Code No: 953535

Code No: 953525

During installation, place disc in depicted position (A) to allow an upward tilt of 50 and a downward tilt of 15.

90º + 90º horizontal adjustment

A 50º 15º

During installation, place disc in depicted position (B) to allow an upward tilt of 15 and a downward tilt of 50.

15º 50º

Page 253 for Mounting Accessories 300

BELKIS

Mounting Accessories for BELKIS 5 SPOTS

Alternate Arms (to aluminium side or central arms) Electrostatic powder painted steel Please indicate below code number in combination with the code number of the desired spot CODE NO 953881

CODE NO 953882

183

178

CODE NO 953883

447

Vertically adjustable ± 45º Horizantaly adjustable ± 60º

Only vertically adjustable ± 45º

Vertically adjustable ± 45º Horizantaly adjustable ± 90º

Pickets Electrostatic powder painted steel Please indicate below code number in combination with the code number of the desired spot CODE NO 953884

CODE NO 953885

CODE NO 953886

480

498

300

Pickets for round base 300 mm

Picket for gear box base 480 mm

Picket mounted on body 498 mm

Pole Adaptors Die cast aluminium Please indicate below code number in combination with the code number of the desired spot CODE NO 953888

CODE NO 953887

5,2

5,2 60 60

Ø 76,1 Ø 76,1

Pole adaptor in place of round base For 76.1 mm (3 inch) pole thickness

CODE NO 953889

Pole adaptor for gear box For 76.1 mm (3 inch) pole thickness

CODE NO 953890

5,2

60 60

5,2 60 60 Ø 101,6

Pole adaptor in place of round base For 101.6 mm (4 inch) pole thickness

Ø 101,6

Pole adaptor for gear box For 101.6 mm (4 inch) pole thickness 301

302

BELKIS 6

SPOTS WITH GEARBOX Class I IP67 IK10

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

45º

Lampholder : G12 Reflector

: 30º, 42º

Diffuser

: Clear Glass

Gear

: Electronic

Ø 170 250

Code No 138201

METAL HALIDE 35W

100

130

Lampholder : G12 Reflector

: 30º, 42º

Diffuser

: Clear Glass

Gear

: Electronic

90º

Code No 138211

METAL HALIDE 70W

Picket

Visor

Code No: 953885

Code No: 953536

During installation, place disc in depicted position (A) to allow an upward tilt of 50 and a downward tilt of 15.

90º + 90º horizontal adjustment

A 50º 15º

During installation, place disc in depicted position (B) to allow an upward tilt of 15 and a downward tilt of 50.

15º 50º

303

BELKIS 6

SPOTS WITH GEARBOX Class I IP67 IK10

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

45º

Lampholder : G12 Reflector

: 30º, 42º

Diffuser

: Clear Glass

Gear

: Electronic

METAL HALIDE 150W

280

Code No 138221 71,5

200

144

90º

90º + 90º horizontal adjustment

Visor

Code No: 953536 During installation, place disc in depicted position (A) to allow an upward tilt of 50 and a downward tilt of 15.

A 50º 15º

During installation, place disc in depicted position (B) to allow an upward tilt of 15 and a downward tilt of 50.

304

15º 50º

305

RESPOT 3

SPOT WITH RECESSED GEARBOX Class I IP67 IK10

Lampholder : G12 Reflector

: 30º, 42º

Diffuser

: Clear Glass

METAL HALIDE 35W

Available in any of these RAL colors

7004

7016

9005

9016

6002

204

1015

Ø 117

205

Code No 137101 238,5

208

Lampholder : G12 Reflector

: 30º, 42º

Diffuser

: Clear Glass

METAL HALIDE 70W

Code No 137111

Lampholder : G x 8.5 Reflector

: -

Diffuser

: Clear Glass

METAL HALIDE CDM-R111 35W

Code No 137121

10º or 24º

Visor

Lampholder : G x 8.5 Reflector

: -

Diffuser

: Clear Glass

METAL HALIDE CDM-R111 70W 10º or 24º

306

Code No 137131 Code No: 953536

Bollards

307

ODEON

BOLLARD Class I IP67 IK10

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

EMFA’s Odean Bollard combines a die-cast aluminium head housing an LED unit with an extrusion aluminium pipe. The bollard is designed to light pathways, landscapes and open spaces. The unit comes with 5 different options of heads depending on much light is required and into which direction: with one head, two adjacent heads, two opposite heads, three heads, or four heads. The head and pipe are connected by a hidden screw within the pipe. One head contains 20 medium-power LEDs consuming 6W and providing over 500lm light output. An optional galvanized steel anchorage kit is available for mounting into concrete. An alternative option is sleave anchors for mounting onto existing concrete or a picket to mount into the earth.

Head Die cast aluminium Diffusers Frosted polyamide 6.6 Pipe Extrusion aluminium Paint Electrostatic powder

308

ODEON

BOLLARD Class I IP67 IK10

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

Mono Led

: Medium power LEDs

Voltage

: 240 VAC with integrated driver

Diffuser

: Polyamide 6.6

(12-24 VDC on request)

Duo 1-way

Mono Mono Duo 1-way Duo 1-way Duo 2-way Duo 2-way Trio Trio Quad Quad

20 x 87 mA (6W) LED 20 x 87 mA (6W) LED 40 x 87 mA (12W) LED 40 x 87 mA (12W) LED 40 x 87 mA (12W) LED 40 x 87 mA (12W) LED 60 x 87 mA (18W) LED 60 x 87 mA (18W) LED 80 x 87 mA (24W) LED 80 x 87 mA (24W) LED

3000 K 4000 K 3000 K 4000 K 3000 K 4000 K 3000 K 4000 K 3000 K 4000 K

Total Lighting Output Code No 640 lm 178101 640 lm 178102 1280 lm 178111 1280 lm 178112 1280 lm 178121 1280 lm 178122 1920 lm 178131 1920 lm 178132 2560 lm 178141 2560 lm 178142

Duo 2-way 232,5

500

Ø 80

Trio

309

310

311

LEON

LED BOLLARD Class I IP65

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

EMFA’s Leon Bollard combines a die-cast aluminium head housing an LED unit with an extrusion aluminium pipe. The bollard is designed to light pathways, landscapes and open spaces. The Leon bollard gives light only in the downward direction. This avoids any kind of glare and light pollution. The head and pipe are connected by a hidden screw within the pipe. The head contains LEDs that can be powered up to 12W. An optional galvanized steel anchorage kit is available for mounting into concrete. An alternative option is sleave anchors for mounting onto existing concrete or a picket to mount into the earth.

Head Die cast aluminium Diffusers Frosted polyamide 6.6 Pipe Extrusion aluminium Paint Electrostatic powder

“Customization” is EMFA’s standard EMFA offers many combinations for each fixture, as all fixtures are made in house. A combination of 3 standard paint colors, 2 LED colors, and 2 wattages, are available to make the fixture suitable for the required application. This is done without increasing lead-time and is available for large as well as small quantities.

Mounting Fixtures

Galvanized Steel Anchor

312

Concrete Mounting Step

Concrete Mounting Flush

LEON

LED BOLLARDS Class I IP67

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

Head Die cast aluminium Diffuser Frosted polyamide 6.6 Pipe Extrusion aluminium Paint Electrostatic powder

Led

: Circular LEDs (6W or 12W)

Voltage

: 240 VAC with integrated driver

160

(12-24 VDC on request) : Polyamide

CRI

: >80

700 / 500 / 350 mm

Diffuser

LEON (350 mm) Total 350 mA (6W) CIRCULAR LED Lighting Output Warm White 720 lm 3000 K Natural White 790 lm 4000 K

Code No 177001 177002

Ø 50

700 mA (12W) CIRCULAR LED Warm White Natural White

3000 K 4000 K

1380 lm 1380 lm

177011 177012

LEON (500 mm) Code No 177101 177102

700 mA (12W) CIRCULAR LED Warm White Natural White

3000 K 4000 K

1380 lm 1380 lm

177111 177112

300 mm

Total 350 mA (6W) CIRCULAR LED Lighting Output Warm White 720 lm 3000 K Natural White 790 lm 4000 K

LEON (700 mm) Total 350 mA (6W) CIRCULAR LED Lighting Output Warm White 720 lm 3000 K Natural White 790 lm 4000 K

Code No 177201 177202

700 mA (12W) CIRCULAR LED Warm White Natural White

3000 K 4000 K

1380 lm 1380 lm

177211 177212

954001 Galvanized Steel Mounted

954002 Concrete Mounting Step

954003 Concrete Mounting Flush

313

DION 1

WALL AND GROUND BOLLARDS Class I IP65 IK10

EMFA’s Dion series combines a die-cast aluminium head with an extrusion aluminium pipe to provide a sturdy, outdoor bollard. The bollards are designed to light pathways, landscapes and open spaces. The unit comes with 5 different heads for various light outputs and applications. A screwless bayonet lock system allows for easy dismounting of the head. The unit comes in 4 sizes: 300mm, 450mm, 700mm, and 1100mm, as well as with 3 lamp options: LED, Fluorescent, Metal Halide. In combination with the fluorescent lamp, an optional LED pilot lamp is available to light the bollard when the primary light source is off to continue marking a path while saving energy. An optional galvanized steel anchorage kit is available for mounting into concrete. An alternative option is sleeve anchors for mounting onto existing concrete.

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

Accessories: 2 x Leds Pilot Lamps Lit when main Light Source is turned off. Available in: Code No 956101 - Blue Code No 956102 - Red Code No 956103 - Yellow Code No 956104 - Green Code Number should be indicated along with bollard code number Anchor Code No 955201

400

Code Number should be indicated along with bollard code number Optional wood look finish. Please contact for additional information.

Head Die cast aluminium With Screwless lock system (Electrical lock on request) Outer Asymmetrical Grill Die cast aluminium Diffuser Clear polycarbonate Pipe Extrusion aluminium Paint Electrostatic powder

DION 1 GROUND (45 CM) CODE NO 143231 LINEAR LED 4x350 mA (12W)

450

CODE NO 143201 ELECTRONIC FLUO. 23W E27

Ø 180

CODE NO 143211 FLUO. 26W G24 q-3

DION 1 WALL (30 CM) 300

CODE NO 143101 FLUO. 10W G24 q-1

Ø 180

DION 1 GROUND (70 CM) CODE NO 143341 LINEAR LED 4x350 mA (12W)

DION 1 GROUND (110 CM) CODE NO 143431 LINEAR LED 4x350 mA (12W)

700

CODE NO 143301 ELECTRONIC FLUO. 23W E27 CODE NO 143311 FLUO. 26W G24 q-3 CODE NO 143321 METAL HALIDE 35W G12 314

CODE NO 143221 METAL HALIDE 35W G12

CODE NO 143401 ELECTRONIC FLUO. 23W E27 Ø 180

1100

CODE NO 143411 FLUO. 26W G24 q-3 CODE NO 143421 METAL HALIDE 35W G12

Ø 180

315

DION 2

WALL AND GROUND BOLLARDS Class I IP65 IK10

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

Anchor 20

400

Code Number should be indicated along with bollard code number

Optional wood look finish. Please contact for additional information.

Head Die cast aluminium With Screwless lock system (Electrical lock on request) Outer Protective Grill Die cast aluminium Diffuser Frosted polycarbonate Pipe Extrusion aluminium Paint Electrostatic powder

DION 2 GROUND (45 CM) CODE NO 144231 LINEAR LED 4x350 mA (12W)

450

CODE NO 144201 ELECTRONIC FLUO. 23W E27

Ø 180

CODE NO 144211 FLUO. 26W G24 q-3

DION 2 WALL (30 CM) 300

CODE NO 144101 FLUO. 10W G24 q-1

Ø 180

DION 2 GROUND (70 CM) CODE NO 144341 LINEAR LED 4x350 mA (12W)

DION 2 GROUND (110 CM) CODE NO 144431 LINEAR LED 4x350 mA (12W)

700

CODE NO 144301 ELECTRONIC FLUO. 23W E27 CODE NO 144311 FLUO. 26W G24 q-3 CODE NO 144321 METAL HALIDE 35W G12 316

CODE NO 144221 METAL HALIDE 35W G12

CODE NO 144401 ELECTRONIC FLUO. 23W E27 Ø 180

1100

CODE NO 144411 FLUO. 26W G24 q-3 CODE NO 144421 METAL HALIDE 35W G12

Ø 180

DION 3

WALL AND GROUND BOLLARDS Class I IP65 IK08

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

Anchor 20

400

Code Number should be indicated along with bollard code number

Optional wood look finish. Please contact for additional information.

Head Die cast aluminium With Screwless lock system (Electrical lock on request) Diffuser Frosted polycarbonate Pipe Extrusion aluminium Paint Electrostatic powder

DION 3 GROUND (45 CM) CODE NO 145231 LINEAR LED 4x350 mA (12W) CODE NO 145201 ELECTRONIC FLUO. 23W E27

300

Ø 180

DION 3 GROUND (70 CM) CODE NO 145341 LINEAR LED 4x350 mA (12W)

CODE NO 145321 METAL HALIDE 35W G12

CODE NO 145221 METAL HALIDE 35W G12

DION 3 GROUND (110 CM) CODE NO 145431 LINEAR LED 4x350 mA (12W)

700

CODE NO 145301 ELECTRONIC FLUO. 23W E27 CODE NO 145311 FLUO. 26W G24 q-3

Ø 180

CODE NO 145211 FLUO. 26W G24 q-3

DION 3 WALL (30 CM) CODE NO 145101 FLUO. 10W G24 q-1

450

CODE NO 145401 ELECTRONIC FLUO. 23W E27 Ø 180

1100

CODE NO 145411 FLUO. 26W G24 q-3 CODE NO 145421 METAL HALIDE 35W G12

Ø 180

317

318

DION 4

WALL AND GROUND BOLLARDS Class I IP65 IK08

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

Anchor 20

400

Code Number should be indicated along with bollard code number

Optional wood look finish. Please contact for additional information.

Head Die cast aluminium With Screwless lock system (Electrical lock on request) Outer Protective Grill Die cast aluminium Inner Asymmetrical Grill Polycarbonate Diffuser Clear polycarbonate Pipe Extrusion aluminium Paint Electrostatic powder DION 4 WALL (30 CM) CODE NO 146101 FLUO. 10W G24 q-1

DION 4 GROUND (45 CM) CODE NO 146221 LINEAR LED 4x350 mA (12W) CODE NO 146201 ELECTRONIC FLUO. 23W E27

300

Ø 180

DION 4 GROUND (110 CM) CODE NO 146421 LINEAR LED 4x350 mA (12W)

700

CODE NO 146301 ELECTRONIC FLUO. 23W E27 CODE NO 146311 FLUO. 26W G24 q-3

Ø 180

CODE NO 146211 FLUO. 26W G24 q-3

DION 4 GROUND (70 CM) CODE NO 146321 LINEAR LED 4x350 mA (12W)

450

CODE NO 146401 ELECTRONIC FLUO. 23W E27 Ø 180

1100

CODE NO 146411 FLUO. 26W G24 q-3

319

DION 5

WALL AND GROUND BOLLARDS Class I IP65 IK08

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

Anchor 20

400

Code Number should be indicated along with bollard code number

Optional wood look finish. Please contact for additional information.

Head Die cast aluminium With Screwless lock system (Electrical lock on request) Inner Asymmetrical Grill Polycarbonate Diffuser Clear polycarbonate Pipe Extrusion aluminium Paint Electrostatic powder

DION 5 GROUND (45 CM) CODE NO 147221 LINEAR LED 4x350 mA (12W)

450

CODE NO 147201 ELECTRONIC FLUO. 23W E27

Ø 180

CODE NO 147211 FLUO. 26W G24 q-3

DION 5 WALL (30 CM) 300

CODE NO 147101 FLUO. 10W G24 q-1

Ø 180

DION 5 GROUND (70 CM) CODE NO 147321 LINEAR LED 4x350 mA (12W)

DION 5 GROUND (110 CM) CODE NO 147421 LINEAR LED 4x350 mA (12W)

700

CODE NO 147301 ELECTRONIC FLUO. 23W E27 CODE NO 147311 FLUO. 26W G24 q-3

320

CODE NO 147401 ELECTRONIC FLUO. 23W E27 Ø 180

CODE NO 147411 FLUO. 26W G24 q-3

1100

321

MILET

BOLLARD Class I IP65 IK08

Available in any of these RAL colors

: 240V A.C with integrated driver (24V AC or DC on request)

Lens

: 40º

Diffuser

: Polycarbonate

Cable

: Potted 5 m 3x0,75 H03 VV-F

320 mA (11W) DOM LED 3000K 300 mm 550 mm

Code No 291121 291221

Lampholder : G9 Reflector

: -

Diffuser

: Polycarbonate 550

HALOGEN 240V 40W 300 mm 550 mm

Code No 291101 291201

Lampholder : Gx53 Reflector

: -

Diffuser

: Polycarbonate

ELECTRONIC CIRCULAR FLUO. 6W 300 mm 550 mm

322

Code No 291111 291211

300

7004

7016

9005

9016

6002

1015

BELLA

LED BOLLARDS Class I IP65 IK08

Head Die cast aluminium Diffuser Tempered Glass 4 mm Pipe Extrusion aluminium Base Polyamide (black color) Paint Electrostatic powder

350

100

150

One Way Asymmetrical Voltage

: 240V AC with integrated driver (12V DC or 24V DC on request)

Diffuser

: Clear Glass 4 mm

Cable

: Potted 5 m 3x0,75 H03 VV-F Total Lighting 1 Linear LED 3W Output Code No Warm White 255 lm 149101 3000 K Natural White 295 lm 149102 5000 K

Two Ways Asymmetrical Voltage

: 240V AC with integrated driver

Diffuser

: Clear Glass 4 mm

(12V DC or 24V DC on request) Cable

: Potted 5 m 3x0,75 H03 VV-F Total Lighting 2x1 Linear LED 3W Output Code No Warm White 255 lm 149111 3000 K Natural White 295 lm 149112 5000 K

Two Ways Asymmetrical + Symmetrical Voltage

: 240V AC with integrated driver (12V DC or 24V DC on request)

Diffuser

: Clear Glass 4 mm

Cable

: Potted 5 m 3x0,75 H03 VV-F Total Lighting 2x1 Linear LED 3W Output Code No Warm White 255 lm 149121 3000 K Natural White 295 lm 149122 5000 K

323

324

ANI

ALUM LED BOLLARD Class I IP55 IK08

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

EMFA’s Ani Bollard combines a die-cast aluminium head housing an LED unit with an extrusion aluminium pipe.The bollard is designed to light pathways, landscapes and open spaces. The Leon bollard gives light only in the downward direction.This avoids any kind of glare and light pollution. The head and pipe are connected by a hidden screw within the pipe. The head contains LEDs that can be powered up to 12W. An optional galvanized steel anchorage kit is available for mounting into concrete. An alternative option is sleave anchors for mounting onto existing concrete or a picket to mount into the earth.

Profile Aluminium Body Die cast aluminium Gaskets Silicone Diffusers 4 mm Tempered Glass Screws 316L Stainless steel Glands PG 11

“Customization” is EMFA’s standard EMFA offers many combinations for each fixture, as all fixtures are made in house. A combination of 6 standard paint colors, 8 LED colors, and 2 wattages, are available to make the fixture suitable for the required application. This is done without increasing lead-time and is available for large as well as small quantities.

Symmetrical

Asymmetrical

Asym. Glass

Trenched Glass

Milky Glass

Clear Glass

325

ANI 1

ALUM LED BOLLARD Class I IP55 IK08

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

Symmetrical Led

: Linear LEDs

Voltage

: 240 VAC with integrated driver

Diffuser

: 4mm Tempered Glass

(12-24 VDC on request) Beam Angle : 45°/ 60°/ 90°

452011

3000 K

1020 lm 1460 lm

452002

4000 K

12W

452012

4000 K

1173 lm 1679 lm

977 lm

Code No 452101

Kelvin 3000 K

12W

452111

3000 K

1020 lm 1460 lm

452102

4000 K

12W

452112

4000 K

1173 lm 1679 lm

120

977 lm

120 90

Power 6W

Code No 452201

Kelvin 3000 K

Real Nominal Lumen Lumen Output Output 600 lm 850 lm

12W

452211

3000 K

1020 lm 1460 lm

452202

4000 K

12W

452212

4000 K

690 lm

120

977 lm

1173 lm 1679 lm

120

Concrete Mounting Step

326

Concrete Mounting Flush

Galvanized Steel Anchor

1100

1100mm

690 lm

150

Power 6W

Real Nominal Lumen Lumen Output Output 600 lm 850 lm

700mm

120

690 lm

450

12W

700

Kelvin 3000 K

150

Code No 452001

120

Power 6W

Real Nominal Lumen Lumen Output Output 600 lm 850 lm

450mm

150

: %70

: >80

L.O.R %

450

CRI

700

1100

Mac Adam

ANI 1

ALUM LED BOLLARD Class I IP55 IK08

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

Asymmetrical Led

: Linear LEDs

Voltage

: 240 VAC with integrated driver

Diffuser

: 4mm Tempered Glass

(12-24 VDC on request) Beam Angle : 45°/60°/90° :3

452511

3000 K

1020 lm 1460 lm

452502

4000 K

12W

452512

4000 K

1173 lm 1679 lm

977 lm

Code No 452601

Kelvin 3000 K

12W

452611

3000 K

1020 lm 1460 lm

452602

4000 K

12W

452612

4000 K

690 lm

120 150

Power 6W

Real Nominal Lumen Lumen Output Output 600 lm 850 lm

700mm

120

690 lm

450

12W

700

Kelvin 3000 K

150

Code No 452501

120

Power 6W

Real Nominal Lumen Lumen Output Output 600 lm 850 lm

450mm

450

977 lm

120

1173 lm 1679 lm 90

Code No 452701

Kelvin 3000 K

12W

452711

3000 K

452702

4000 K

12W

452712

4000 K

120

1100

Power 6W

Real Nominal Lumen Lumen Output Output 600 lm 850 lm 1020 lm 1460 lm 690 lm 977 lm 1173 lm 1679 lm

150

1100mm

: %70

700

: >80

L.O.R %

1100

CRI

120 90

120

Mac Adam

Concrete Mounting Step

Concrete Mounting Flush

Galvanized Steel Anchor

327

ANI 4

ALUM LED BOLLARD Class I IP55 IK08

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

Profile Aluminium Body Die cast aluminium Gaskets Silicone Diffusers 4 mm Tempered Glass Screws 316L Stainless steel Glands PG 11

“Customization” is EMFA’s standard EMFA offers many combinations for each fixture, as all fixtures are made in house. A combination of 6 standard paint colors, 8 LED colors, and 2 wattages, are available to make the fixture suitable for the required application. This is done without increasing lead-time and is available for large as well as small quantities.

Symmetrical

Asymmetrical

Asym. Glass

328

Trenched Glass

Milky Glass

Clear Glass

ANI 4

ALUM LED BOLLARD Class I IP55 IK08

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

Symmetrical Led

: Linear LEDs

Voltage

: 240 VAC with integrated driver

Diffuser

: 4mm Tempered Glass

(12-24 VDC on request) Beam Angle : 45°/ 60°/ 90°

48W

459011

3000 K

3080 lm 4300 lm

24W

459002

4000 K

2047 lm 2932 lm

48W

459012

4000 K

3542 lm 5060 lm

450

Kelvin 3000 K

150

Code No 459001

240

Power 24W

Real Nominal Lumen Lumen Output Output 1780 lm 2550 lm

450mm

240

48W

459111

3000 K

3080 lm 4300 lm

24W

459102

4000 K

2047 lm 2932 lm

48W

459112

4000 K

3542 lm 5060 lm

700

Kelvin 3000 K

150

Code No 459101

240

Power 24W

Real Nominal Lumen Lumen Output Output 1780 lm 2550 lm

700mm

240

Code No 459201

Kelvin 3000 K

48W

459211

3000 K

3080 lm 4300 lm

24W

459202

4000 K

2047 lm 2932 lm

48W

459212

4000 K

3542 lm 5060 lm

240

1100

Power 24W

Real Nominal Lumen Lumen Output Output 1780 lm 2550 lm

150

1100mm

: %70

450

: >80

L.O.R %

700

CRI

1100

240

120

Mac Adam

Concrete Mounting Step

Concrete Mounting Flush

Galvanized Steel Anchor

329

ANI 4

ALUM LED BOLLARD Class I IP55 IK08

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

Asymmetrical Led

: Linear LEDs

Voltage

: 240 VAC with integrated driver

Diffuser

: 4mm Tempered Glass

(12-24 VDC on request) Beam Angle : 45°/60°/90° :3

Power 24W

Code No 459501

Kelvin 3000 K

Real Nominal Lumen Lumen Output Output 1780 lm 2550 lm

48W

459511

3000 K

3080 lm 4300 lm

24W

459502

4000 K

2047 lm 2932 lm

48W

459512

4000 K

3542 lm 5060 lm

450mm

240

450

: %70

150

: >80

L.O.R %

CRI

450

Mac Adam

240

459611

3000 K

3080 lm 4300 lm

24W

459602

4000 K

2047 lm 2932 lm

48W

459612

4000 K

3542 lm 5060 lm

700

48W

150

Kelvin 3000 K

Code No 459601

240

700

Power 24W

Real Nominal Lumen Lumen Output Output 1780 lm 2550 lm

700mm

240

48W

459711

3000 K

3080 lm 4300 lm

24W

459702

4000 K

2047 lm 2932 lm

48W

459712

4000 K

3542 lm 5060 lm

1100

Kelvin 3000 K

150

Code No 459701

240

Power 24W

Real Nominal Lumen Lumen Output Output 1780 lm 2550 lm 1100

1100mm

240

120

Concrete Mounting Step

330

Concrete Mounting Flush

Galvanized Steel Anchor

L TYPE

LED BOLLARDS Class I IP65

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

Head Die cast aluminium Diffuser Tempered Glass 4 mm Pipe Extrusion aluminium Base Die cast aluminium Paint Electrostatic powder

120

190

400

40 cm Bollard Voltage

: 240V AC with integrated driver (12V DC or 24V DC on request)

Diffuser

: Clear Glass 4 mm

: Potted 5 m 3x0,75 H03 VV-F Total Lighting COB LED 3W Output Code No Warm White 255 lm 125001 3000 K Natural White 295 lm 125002 5000 K

120

190

Cable

80 cm Bollard Voltage

: 240V AC with integrated driver

Diffuser

: Clear Glass 4 mm

800

(12V DC or 24V DC on request) Cable

: Potted 5 m 3x0,75 H03 VV-F Total Lighting COB LED 6W Output Code No Warm White 255 lm 125101 3000 K Natural White 295 lm 125102 5000 K

331

332

POLARIS 1

ALUMINIUM BOLLARDS Class I IP43 IK10

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

Bottom Base Polyamide (black color) Outer Grill Die cast aluminium Pipe Extrusion aluminium Paint Electrostatic powder Diffuser Polycarbonate or Glass (incandescent and mercury lamps) Anchor

POLARIS 1 (45 CM) CODE NO 124101 INCANDESCENT 60W E27 CODE NO 124111 MERCURY 80W E27

2.05 m

CODE NO 124121 ELECTRONIC FLUO. 23W E27 CODE NO 124131 FLUO. 26W G24 d-3 Ø154

POLARIS 1 (70 CM) CODE NO 124201 INCANDESCENT 60W E27

700 450 1100

CODE NO 124211 MERCURY 80W E27

3.20 m

CODE NO 124221 ELECTRONIC FLUO. 23W E27

Ø120

CODE NO 124231 FLUO. 26W G24 d-3

Anchor

POLARIS 1 (110 CM) 45

CODE NO 124301 INCANDESCENT 60W E27 CODE NO 124311 MERCURY 80W E27 CODE NO 124321 ELECTRONIC FLUO. 23W E27

25 230 m6

240

Code No 953611 5.00 m

Code Number should be indicated along with bollard code number

CODE NO 124331 FLUO. 26W G24 d-3 333

POLARIS 2

ALUMINIUM BOLLARDS Class I IP43 IK10

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

Bottom Base Polyamide (black color) Inner Grill Polycarbonate Pipe Extrusion aluminium Paint Electrostatic powder Diffuser Polycarbonate Anchor

POLARIS 2 (45 CM) CODE NO 126101 ELECTRONIC FLUO. 23W E27 CODE NO 126111 FLUO. 26W G24 d-3

1.06 m

Ø154

POLARIS 2 (70 CM) CODE NO 126201 ELECTRONIC FLUO. 23W E27

700 450 1100

CODE NO 126211 FLUO. 26W G24 d-3

2.50 m

Ø120

Anchor

POLARIS 2 (110 CM) 45

CODE NO 126301 ELECTRONIC FLUO. 23W E27 CODE NO 126311 FLUO. 26W G24 d-3

334

25 230 m6

240

Code No 953621 4.00 m

Code Number should be indicated along with bollard code number

335

RAMBO

VANDALPROOF BOLLARD Class I IP65 IK10

Available in any of these RAL colors

Head Die cast aluminium Pipe Steel Paint Electrostatic powder paint Diffuser Polycarbonate Anchor Die cast iron (110 CM)

Ø218

Voltage

: 240V A.C with integrated driver

Cable

: Potted 5 m 3x0,75 H03 VV-F

(24V AC or DC on request)

4 x 350 mA (12 W) LINEAR LED Warm White

3000 K

Lampholder : 27 INCANDESCENT 100W Lampholder : 27 MERCURY 80W Lampholder : 27 ELECTRONIC FLUO. 23W Lampholder : 27 FLUO. 26W

336

Total Lighting Code No Output 1400 lm

Code No 128101 Code No 128111 Code No 128121 Code No 128131

1450

128141

350

7004

7016

9005

9016

6002

1015

BELKIS 1

BOLLARDS (600 mm) Class I IP55

Lampholder : G24 q-1 Reflector

: -

Diffuser

: Acrylic Pipe

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

Ø64

Transformer : Electronic COMPACT FLUO. 13W

Code No 292201 600

BELKIS 5

BOLLARDS (1100 mm) Class I IP55 Ø120

Lampholder : G24 d-3 Reflector

: -

Diffuser

: Acrylic Pipe

COMPACT FLUO. 26W

Code No 292301

1100

337

338

GOREME 1

LED BOLLARDS Class I IP65 IK10

Bottom Base Polyamide (black color) Outer Grill Die cast aluminium Pipe Extrusion aluminium Paint Electrostatic powder Diffuser Polycarbonate or Glass (incandescent and mercury lamps) Anchor

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

Ø127,5

1100

Voltage

700

: 240V AC with integrated driver

450

(24V AC or DC on request) Cable

: Potted 5 m 3x0,75 H03 VV-F

GOREME 1 (45 CM) 4 x 350 mA (12 W) LINEAR LED Warm White Natural White

3000 K 4000 K

Total Lighting Output Code No 1054 lm 127001 1156 lm 127002

Ø170

4 x 700 mA (24 W) LINEAR LED Warm White Natural White

3000 K 4000 K

1900 lm 2080 lm

127011 127012

GOREME 1 (70 CM) 4 x 350 mA (12 W) LINEAR LED Warm White Natural White

3000 K 4000 K

Total Lighting Output Code No 1054 lm 127101 1156 lm 127102

4 x 700 mA (24 W) LINEAR LED Warm White Natural White

3000 K 4000 K

1900 lm 2080 lm

127111 127112

GOREME 1 (110 CM) 4 x 350 mA (12 W) LINEAR LED Warm White Natural White

3000 K 4000 K

Total Lighting Output Code No 1054 lm 127201 1156 lm 127202

4 x 700 mA (24 W) LINEAR LED Warm White Natural White

3000 K 4000 K

1900 lm 2080 lm

127211 127212

339

GOREME 2

LED BOLLARDS Class I IP65 IK10

Bottom Base Polyamide (black color) Inner Grill Polycarbonate Pipe Extrusion aluminium Paint Electrostatic powder Diffuser Polycarbonate Anchor

Available in any of these RAL colors

7004

Ø127,5

1100

Voltage

700

: 240V AC with integrated driver

450

(24V AC or DC on request) Cable

: Potted 5 m 3x0,75 H03 VV-F

GOREME 2 (45 CM) 4 x 350 mA (12 W) LINEAR LED Warm White Natural White

3000 K 4000 K

Total Lighting Output Code No 1054 lm 127501 1156 lm 127502

4 x 700 mA (24 W) LINEAR LED Warm White Natural White

3000 K 4000 K

1900 lm 2080 lm

127511 127512

GOREME 2 (70 CM) 4 x 350 mA (12 W) LINEAR LED Warm White Natural White

3000 K 4000 K

Total Lighting Output Code No 1054 lm 127601 1156 lm 127602

4 x 700 mA (24 W) LINEAR LED Warm White Natural White

3000 K 4000 K

1900 lm 2080 lm

127611 127612

GOREME 2 (110 CM) 4 x 350 mA (12 W) LINEAR LED Warm White Natural White

3000 K 4000 K

Total Lighting Output Code No 1054 lm 127701 1156 lm 127702

4 x 700 mA (24 W) LINEAR LED Warm White Natural White

340

3000 K 4000 K

1900 lm 2080 lm

127711 127712

Ø170

7016

9005

9016

6002

1015

341

LARA

ACRYLIC BOLLARDS Class I IP55

LARA (35 cm)

Available in any of these RAL colors

Ø90

LARA (35 cm) Lampholder : G24 q-1 Reflector

: -

Diffuser

: Acrylic Pipe

350

Ø90

Transformer : Electronic COMPACT FLUO. 13W

Code No 294101

LARA (60 cm)

Ø90

LARA (60 cm) Lampholder : G24 q-1 Reflector

: -

Diffuser

: Acrylic Pipe

600

Transformer : Electronic COMPACT FLUO. 13W

Code No 294201

Ø90

342

7004

7016

9005

9016

6002

1015

343

BOW

GARDEN FIXTURE Class I IP44 IK10

Body Glass reinforced polyester Diffuser Acrylic Reflector Anodized aluminium Bracket Stainless Steel

Voltage

Available in any of these RAL colors

400

500

: 240V A.C with integrated driver (24V AC or DC on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

Total Code No Lighting 2 x 350 mA (2x3 W) LINEAR LED Output Warm White

Lampholder : G24 d-1 1 x FLUO 13W

3000 K

Code No 129101

MUSHROOM

700 lm

129121

Lampholder : G24 d-2

Code No 129111

1 x FLUO 18W

GARDEN FIXTURE Class I IP67 IK10

Top Cover Aluminium Inner Body Die cast aluminium Diffuser Tempered Glass Gaskets Silicone

Lampholder : Gu10 HALOGEN 240V 50W

Code No 129501

Ø250

355

ACCESSORY : Picket CODE NO 953501 Ø140

300

344

7004

7016

9005

9016

6002

1015

Stainless Steel Underwater

345

ATLANTIS

UNDERWATER LED FIXTURE Class III IP68 IK10

The Atlantis Underwater series is specially designed to light pools, fountains and water features with high power LED light. The series is made of 316L stainless steel to withstand salt water and chlorine. Standard finish is polished stainless steel to avoid collection of dirt and algae, but a brushed finish is also possible. The series comes as recessed, surface mount or spots. The spots are heavy duty with stainless steel brackets for sturdy fixing. The bodies are filled with cast resin and a specially developed potted power cable is used to effectively bond with the cast resin and stop any water ingress. The low voltage electronic LED driver is housed in the base of the fixture. The LEDs used come in 3 different tones of white, as well as blue, red, green, amber or RGB. Several lenses from 6 to 40 degrees are available to choose from to achieve the desired light effect.

Frame 316L Stainless Steel Body 316L Stainless Steel Recessing Tube Aluminium Gaskets Silicone Diffusers Tempered Glass Screws Stainless Steel Mounting Brackets 316L Stainless Steel

346

ATLANTIS

UNDERWATER RECESSED LED FIXTURES Class III IP68 IK10

ATLANTIS 1 With Recessing Tube

1 x 350 mA (1 W) LED or 1 x 700 mA (3 W) LED

Warm White Natural White Cool White Blue Red Amber Green

Total Lighting Output 1W 3W 85 lm 225 lm 3000 K 85 lm 225 lm 4500 K 102 lm 270 lm 6000 K

1W Round 421101 421106 421107 421102 421103 421104 421105

Voltage

: 12V AC or DC (24V AC or DC on request)

Lens

: 10º, 25º, 40º

Diffuser

: 8 mm Clear Glass (Frosted Glass on request)

Cable

: Potted 5 m 2x0,75 H03 VV-F

1W Square 421111 421116 421117 421112 421113 421114 421115

3W Round 421201 421202 421203 421204 421205 421206 421207

105

3W Square 421211 421212 421213 421214 421215 421216 421217

Ø 105

105

101

Ø 70

Aluminum recessing tube

ATLANTIS 2 With Recessing Tube

3 x 350 mA (3 W) LED or 3 x 700 mA (9 W) LED

Warm White Natural White Cool White Blue Red Amber Green

Total Lighting Output 3W 9W 675 lm 255 lm 3000 K 255 lm 675 lm 4500 K 306 lm 810 lm 6000 K

3W Round 421121 421126 421127 421122 421123 421124 421125

Voltage

: 12V AC or DC (24V AC or DC on request)

Lens

: 10º, 25º, 40º

Diffuser

: 8 mm Clear Glass (Frosted Glass on request)

Cable

: Potted 5 m 2x0,75 H03 VV-F

3W Square 421131 421136 421137 421132 421133 421134 421135

9W Round 421301 421302 421303 421304 421305 421306 421307

9W Square 421311 421312 421313 421314 421315 421316 421317

120

Ø 120

120

101

Ø 84

Aluminum recessing tube

347

ATLANTIS

UNDERWATER RECESSED RGB LED FIXTURE Class III IP68 IK10

ATLANTIS 2 With Recessing Tube

9 x 350 mA (9 W) RGB LED 120

Voltage

: 40V DC

Lens

: 25º or 40º

Diffuser

: 8 mm Clear Glass (Frosted Glass on request)

Cable

: Potted 10 m 4x0,75 H03 VV-F Code No Round Square

Ø 120

120

101

421141 421151 Ø 84

Aluminum recessing tube

348

ATLANTIS

UNDERWATER RECESSED LED FIXTURES Class III IP68 IK10

ATLANTIS 5 With Recessing Tube

6 x 350 mA (6 W) LED or 6 x 700 mA (18 W) LED

Warm White Natural White Cool White Blue Red Amber Green

Total Lighting Output 6W 18W 510 lm 1350 lm 3000 K 510 lm 1350 lm 4500 K 612 lm 1620 lm 6000 K

6W Round 405301 405306 405307 405302 405303 405304 405305

Voltage

: 12V AC or DC (24V AC or DC on request)

Lens

: 10º, 25º, 40º

Diffuser

: 8 mm Clear Glass (Frosted Glass on request)

Cable

: Potted 5 m 2x0,75 H03 VV-F

6W Square 405311 405316 405317 405312 405313 405314 405315

18W Round 421801 421802 421803 421804 421805 421806 421807

18W Square 421811 421812 421813 421814 421815 421816 421817

190

Ø 190

190

101

158

Ø 154

Aluminum recessing tube

ATLANTIS 5 With Recessing Tube

9 x 350 mA (9 W) LED or 9 x 700 mA (27 W) LED

Warm White Natural White Cool White Blue Red Amber Green

Total Lighting Output 9W 27W 765 lm 2100 lm 3000 K 765 lm 2100 lm 4500 K 810 lm 2520 lm 6000 K

9W Round 405321 405326 405327 405322 405323 405324 405325

Voltage

: 12V AC or DC (24V AC or DC on request)

Lens

: 10º, 25º, 40º

Diffuser

: 8 mm Clear Glass (Frosted Glass on request)

Cable

: Potted 5 m 2x0,75 H03 VV-F

9W Square 405331 405336 405337 405332 405333 405334 405335

27W Round 421821 421822 421823 421824 421825 421826 421827

27W Square 421831 421832 421833 421834 421835 421836 421837

190

Ø 190

190

101

Ø 154

158

Aluminum recessing tube

349

ATLANTIS

UNDERWATER RECESSED RGB LED FIXTURES Class III IP68 IK10

ATLANTIS 27 With Recessing Tube

27 x 350 mA (30 W) RGB LED 190

Voltage

: 40V DC

Lens

: 25º or 40º

Diffuser

: 8 mm Clear Glass (Frosted Glass on request)

Cable

: Potted 10 m 4x0,75 H03 VV-F

Ø 190

190

Code No Round Square 405341 405351 71

101

Ø 154

158

Aluminum recessing tube

350

ATLANTIS 27

SWIMMING POOL LED FIXTURE Class III IP68 IK10

ATLANTIS 27 Swimming Pool

6 x 350 mA (6 W) LED or 6 x 700 mA (18 W) LED

Warm White Natural White Cool White Blue Red Amber Green

Total Lighting Output 6W 18W 510 lm 1350 lm 3000 K 510 lm 1350 lm 4500 K 612 lm 1620 lm 6000 K

6W 405471 405476 405477 405472 405473 405474 405475

18W 421701 421702 421703 421704 421705 421706 421707

75 Ø 222

Ø 138

With Plastic Recessing Tube

Voltage

: 12V AC or DC (24V AC or DC on request)

Lens

: 10º, 25º, 40º

17,5

Ø 138

Diffuser

: 8 mm Clear Glass (Frosted Glass on request)

Cable

: Potted 10 m 4x0,75 H03 VV-F LIGHTING NICHE SET CODE NO 953701

ATLANTIS 27 Swimming Pool

9 x 350 mA (9 W) LED or 9 x 700 mA (27 W) LED

Warm White Natural White Cool White Blue Red Amber Green

Total Lighting Output 9W 27W 765 lm 2100 lm 3000 K 765 lm 2100 lm 4500 K 810 lm 2520 lm 6000 K

9W 405481 405486 405487 405482 405483 405484 405485

27W 421711 421712 421713 421714 421715 421716 421717

75 Ø 222

Ø 138

With Plastic Recessing Tube

Voltage

: 12V AC or DC (24V AC or DC on request)

Lens

: 10º, 25º, 40º

Diffuser

: 8 mm Clear Glass (Frosted Glass on request)

Cable

: Potted 10 m 4x0,75 H03 VV-F

17,5

Ø 138

LIGHTING NICHE SET CODE NO 953701

351

ATLANTIS 27

SWIMMING POOL RGB LED FIXTURE Class III IP68 IK10

ATLANTIS 27 Swimming Pool

Body 316L Stainless Steel Pipe Frame 4 mm Polished Stainless Steel Screws 316L Stainless Steel Diffuser 8 mm Clear Glass Gasket Silicone Remote Gear Box 240 VAC Class I Control by DMX, remote control or push button

75 Ø 222

Ø 138

With Plastic Recessing Tube

23 17,5

Ø 138

27 x 350 mA (30 W) RGB LED Voltage

: 40V DC Class III

Lens

: 25º, 40º

Diffuser

: 8 mm Clear Glass (Frosted Glass on request)

Cable

: Potted 10 m 4x0,75 H03 VV-F

LIGHTING NICHE SET CODE NO 953701

(Up to 100 m possible) RGB LED CODE NO 425311 ROUND FRAME

280

250

16 120

250 84

CODE NO 953702

CODE NO 953703

SLIM IP 65 CONTROL BOX (For Max. 1 RGBox)

WIDE IP 65 CONTROL BOX (For Max. 3 RGBoxes)

GLASS REINFORCED POLYESTER BODY

352

ATLANTIS

UNDERWATER SURFACE MOUNTED LED FIXTURES Class III IP68 IK10

ATLANTIS 1

1 x 350 mA (1 W) LED or 1 x 700 mA (3 W) LED

Warm White Natural White Cool White Blue Red Amber Green

Total Lighting Output 1W 3W 85 lm 225 lm 3000 K 85 lm 225 lm 4500 K 102 lm 270 lm 6000 K

1W 405361 405366 405367 405362 405363 405364 405365

Voltage

: 12V AC or DC (24V AC or DC on request)

Lens

: 10º, 25º, 40º

Diffuser

: 8 mm Clear Glass (Frosted Glass on request)

Cable

: Potted 5 m 2x0,75 H03 VV-F

3W 421321 421322 421323 421324 421325 421326 421327

Ø 94

Ø 70

Ø 94 Ø 94

Cable exits from bottom

Cable exits from side

ATLANTIS 2

3 x 350 mA (3 W) LED or 3 x 700 mA (9 W) LED

Warm White Natural White Cool White Blue Red Amber Green

Total Lighting Output 3W 9W 255 lm 675 lm 3000 K 255 lm 675 lm 4500 K 306 lm 810 lm 6000 K

3W 405371 405376 405377 405372 405373 405374 405375

Voltage

: 12V AC or DC (24V AC or DC on request)

Lens

: 10º, 25º, 40º

Diffuser

: 8 mm Clear Glass (Frosted Glass on request)

Cable

: Potted 5 m 2x0,75 H03 VV-F

9W 421331 421332 421333 421334 421335 421336 421337

Ø 108

Ø 84

Ø 108 Ø 108

Cable exits from bottom

Cable exits from side

353

ATLANTIS

UNDERWATER SURFACE MOUNTED RGB LED FIXTURES Class III IP68 IK10

ATLANTIS 2

9 x 350 mA (9 W) RGB LED Voltage

: 40V DC

Lens

: 25º, 40º

Diffuser

: 8 mm Clear Glass (Frosted Glass on request)

Cable

: Potted 10 m 4x0,75 H03 VV-F

Ø 108

Ø 84

Code No 405201

Ø 84

Ø 108 Ø 108

Cable exits from bottom

354

Cable exits from side

ATLANTIS

UNDERWATER SURFACE MOUNTED LED FIXTURES Class III IP68 IK10

ATLANTIS 5

6 x 350 mA (6 W) LED or 6 x 700 mA (18 W) LED

Warm White Natural White Cool White Blue Red Amber Green

Total Lighting Output 6W 18W 510 lm 1350 lm 3000 K 510 lm 1350 lm 4500 K 612 lm 1620 lm 6000 K

Voltage

: 24V AC or DC on request

Lens

: 10º, 25º, 40º

6W 405381 405386 405387 405382 405383 405384 405385

18W 421841 421842 421843 421844 421845 421846 421847

Ø 184

Ø 154

Ø 184 Ø 184

Diffuser

: 8 mm Clear Glass (Frosted Glass on request)

Cable

: Potted 5 m 2x0,75 H03 VV-F

Cable exits from bottom

Cable exits from side

ATLANTIS 5

9 x 350 mA (9 W) LED or 9 x 700 mA (27 W) LED

Warm White Natural White Cool White Blue Red Amber Green

Total Lighting Output 9W 27W 765 lm 2100 lm 3000 K 765 lm 2100 lm 4500 K 810 lm 2520 lm 6000 K

9W 405391 405396 405397 405392 405393 405394 405395

Voltage

: 24V AC or DC on request

Lens

: 10º, 25º, 40º

Diffuser

: 8 mm Clear Glass (Frosted Glass on request)

Cable

: Potted 5 m 2x0,75 H03 VV-F

27W 421851 421852 421853 421854 421855 421856 421857

Ø 184

Ø 154

Ø 184 Ø 184

Cable exits from bottom

Cable exits from side

355

ATLANTIS

UNDERWATER SURFACE MOUNTED RGB LED FIXTURES Class III IP68 IK10

ATLANTIS 27

27 x 350 mA (30 W) RGB LED Voltage

: 40V DC

Lens

: 25º, 40º

Diffuser

: 8 mm Clear Glass (Frosted Glass on request)

Cable

: Potted 10 m 4x0,75 H03 VV-F

RGB LED

Code No 405411

Ø 184

Ø 154

Ø 184 Ø 184

Cable exits from bottom

356

Cable exits from side

ATLANTIS

UNDERWATER LED SPOT Class III IP68 IK10

ATLANTIS 1

1 x 350 mA (1 W) LED or 1 x 700 mA (3 W) LED

Warm White Natural White Cool White Blue Red Amber Green

Total Lighting Output 1W 3W 85 lm 225 lm 3000 K 85 lm 225 lm 4500 K 102 lm 270 lm 6000 K

1W 405421 405426 405427 405422 405423 405424 405425

Voltage

: 12V AC or DC (24V AC or DC on request)

Lens

: 10º, 25º, 40º

Diffuser

: 8 mm Clear Glass (Frosted Glass on request)

Cable

: Potted 5 m 2x0,75 H03 VV-F

3W 405241 405242 405243 405244 405245 405246 405247

112

ATLANTIS 2

3 x 350 mA (3 W) LED or 3 x 700 mA (9 W) LED

Warm White Natural White Cool White Blue Red Amber Green

Total Lighting Output 3W 9W 255 lm 675 lm 3000 K 255 lm 675 lm 4500 K 306 lm 810 lm 6000 K

3W 405251 405252 405253 405254 405255 405256 405257

Voltage

: 12V AC or DC (24V AC or DC on request)

Lens

: 10º, 25º, 40º

Diffuser

: 8 mm Clear Glass (Frosted Glass on request)

Cable

: Potted 5 m 2x0,75 H03 VV-F

9W 421341 421342 421343 421344 421345 421346 421347

112

357

ATLANTIS

UNDERWATER LED SPOT Class III IP68 IK10

ATLANTIS 2

9 x 350 mA (9 W) RGB LED Voltage

: 40V DC

Lens

: 25º, 40º

Diffuser

: 8 mm Clear Glass (Frosted Glass on request)

Cable

: Potted 10 m 4x0,75 H03 VV-F

RGB

358

Code No 405431

ATLANTIS

UNDERWATER LED SPOT Class III IP68 IK10

ATLANTIS 5

6 x 350 mA (6 W) LED or 6 x 700 mA (18 W) LED

Warm White Natural White Cool White Blue Red Amber Green

Total Lighting Output 6W 18W 510 lm 1350 lm 3000 K 510 lm 1350 lm 4500 K 612 lm 1620 lm 6000 K

Voltage

: 24V AC or DC on request

Lens

: 10º, 25º, 40º

169

6W 405441 405446 405447 405442 405443 405444 405445

Diffuser

: 8 mm Clear Glass (Frosted Glass on request)

Cable

: Potted 5 m 2x0,75 H03 VV-F

18W 421861 421862 421863 421864 421865 421866 421867

112

ATLANTIS 5

9 x 350 mA (9 W) LED or 9 x 700 mA (27 W) LED

Warm White Natural White Cool White Blue Red Amber Green

Total Lighting Output 9W 27W 765 lm 2100 lm 3000 K 765 lm 2100 lm 4500 K 810 lm 2520 lm 6000 K

169

9W 405451 405456 405457 405452 405453 405454 405455

Voltage

: 24V AC or DC on request

Lens

: 10º, 25º, 40º

Diffuser

: 8 mm Clear Glass (Frosted Glass on request)

Cable

: Potted 5 m 2x0,75 H03 VV-F

27W 421871 421872 421873 421874 421875 421876 421877

112

359

ATLANTIS

UNDERWATER RGB LED SPOT Class III IP68 IK10

ATLANTIS 27

27 x 350 mA (30 W) RGB LED Voltage

: 40V DC

Lens

: 25º, 40º

Diffuser

: 8 mm Clear Glass (Frosted Glass on request)

Cable

: Potted 10 m 4x0,75 H03 VV-F

RGB LED

360

169

Code No 405461

112

INOX 1

UNDERWATER RECESSED Class III IP68

Body 316L marine grade stainless steel Frame 316L marine grade stainless steel Diffuser Tempered Glass Gaskets Silicone Screws 316L marine grade stainless steel Gland 316L Inox Recessing Tube Step Mounted

Lampholder : Gu 5.3

100

160

Reflector

: -

Diffuser

: 8 mm Tempered Glass

Ø 100

100

Ø 89

Ø 100

Transformer is not included. Remote transformer should be used. HALOGEN 12V 50W Step Mounted

Stainless Steel Recessing Tube

Code No Round Square 134211 134201

Flush Mounted

Lampholder : Gu 5.3 Reflector

: -

Diffuser

: Clear Glass

160

Ø 89

Ø 100

Ø 89

Transformer is not included. Remote transformer should be used. HALOGEN 12V 50W Flush Mounted

Stainless Steel Recessing Tube

Code No 134221 361

INOX 1

UNDERWATER RECESSED Class III IP68

EMFA’s Inox 1 Underwater spot is competely made of solid 316L stainless steel to withstand salt water and chlorine. The spot is specially designed to light fountains and water features. A special factory sealed cable is used to avoid any ingress of water. Standard finish is polished stainless steel to avoid collection of dirt and algae, but a brushed finish is also possible.

Body 316L marine grade stainless steel Frame 316L marine grade stainless steel Diffuser Tempered Glass Gaskets Silicone Screws 316L marine grade stainless steel Gland 316L marine grade stainless steel

Flush Mounted

Lampholder : Gu 5.3 Reflector

: -

Diffuser

: Clear Glass

20 55º

Transformer is not included.

Ø 85 114

Remote transformer should be used. HALOGEN 12V 50W

362

Code No 134101

50º

MIRA ATLANTIS 1

UNDERWATER RECESSED LED FIXTURES Class III IP68 IK10

The Mira Atlantis Underwater series brings together the rectangular LED fixture called Mira with the underwater feature of the Atlantis. Engineered completely from marine grade stainless steel, 316L, this range is designed to light pools, fountains and water features with efficient LED lighting. Standard finish is polished stainless steel to avoid collection of dirt and algae, but a brushed finish is also available on request. The series comes as recessed or surface mount. The surface mounted version has heavy-duty stainless steel adjustable brackets for sturdy fixing. The bodies are filled with cast resin and a specially developed potted power cable is used to effectively bond with the cast resin and stop any water ingress. The low voltage electronic LED driver is housed in the base of the fixture. The LEDs used come in 3 different tones of white, as well as blue, red, green, amber or RGB. Several lenses from 6 to 40 degrees are available to choose from to achieve the desired underwater the light effect.

Cover 316L Stainless steel Outer Body 316L Stainless steel Body Die cast aluminium Diffusers 12 mm Tempered Glass Gaskets Silicone Screws 316L Stainless steel Recessing Box Stainless steel

363

MIRA ATLANTIS 1

Voltage

: 24V AC or DC

Lens

: 10º, 25º, 40º

UNDERWATER RECESSED LED FIXTURES Class III IP68 IK10

115

Diffuser

: Clear Glass 12 mm (Frosted Glass on request)

Cable

: Potted 5 m 2x0,75 H03 VV-F

12 x 350 mA (12 W) LED Warm White Natural White Cool White Blue Red Amber Green

3000 K 4500 K 6000 K

Total Lighting Output Code No 1020 lm 429001 1020 lm 429002 1224 lm 429003 429004 429005 429006 429007

27 x 350 mA (27 W) RGB LED Voltage

: 24V AC or DC

Lens

: 25º, 40º

Diffuser

: Clear Glass 12 mm (Frosted Glass on request)

Cable

: Potted 10 m 4x0,75 H03 VV-F

RGB LED

364

Code No 429011

420

385

Stainless Steel Recessing Box

MIRA ATLANTIS 1

UNDERWATER SURFACE MOUNTED LED FIXTURES Class III IP68 IK10

Cover 316L Stainless steel Outer Body 316L Stainless steel Body Die cast aluminium Diffusers 12 mm Tempered Glass Gaskets Silicone Screws 316L Stainless steel Mounting Brackets 316L Stainless steel

365

MIRA ATLANTIS 1

UNDERWATER SURFACE MOUNTED LED FIXTURES Class III IP68 IK10

Voltage

: 24V AC or DC

Lens

: 10º, 25º, 40º

Diffuser

: Clear Glass 12 mm (Frosted Glass on request)

Cable

: Potted 5 m 2x0,75 H03 VV-F

12 x 350 mA (12 W) LED Warm White Natural White Cool White Blue Red Amber Green

3000 K 4500 K 6000 K

420

Total Lighting Output Code No 1020 lm 429021 1020 lm 429022 1224 lm 429023 429024 429025 429026 429027

27 x 350 mA (27 W) RGB LED Voltage

: 24V AC or DC

Lens

: 25º, 40º

Diffuser

: Clear Glass 12 mm (Frosted Glass on request)

Cable

: Potted 10 m 4x0,75 H03 VV-F

RGB LED

366

Code No 429031

115

380

52,5º

118

MIRA ATLANTIS 2

UNDERWATER RECESSED LED FIXTURES Class III IP68 IK10

Cover 316L Stainless steel Outer Body 316L Stainless steel Body Die cast aluminium Diffusers 12 mm Tempered Glass Gaskets Silicone Screws 316L Stainless steel Recessing Box Stainless steel

367

MIRA ATLANTIS 2

UNDERWATER RECESSED LED FIXTURES Class III IP68 IK10

15°+15°+0° ASYMMETRICAL LED

Voltage

: 24V AC or DC

Lens

: 10º, 25º, 40º

Diffuser

: Clear Glass 12 mm (Frosted Glass on request)

Cable

: Potted 5 m 2x0,75 H03 VV-F

160

400

36 x 350 mA (36 W) LED Warm White Natural White Cool White Blue Red Amber Green

3000 K 4500 K 6000 K

Total Lighting Output Code No 3060 lm 429041 3060 lm 429042 3672 lm 429043 429044 429045 429046 429047

100

385

145 40º

82º

110 110

15º 15º 0º 130 370

130

27 x 350 mA (27 W) RGB LED Voltage

: 24V AC or DC

Lens

: 25º, 40º

Diffuser

: Clear Glass 12 mm (Frosted Glass on request)

Cable

: Potted 10 m 4x0,75 H03 VV-F

RGB LED

368

Code No 429051

Stainless Steel Recessing Box

ATLANTIS

NEARWATER RGB LED SPOT Class III IP67 IK10

ATLANTIS 2

9 x 350 mA (9 W) RGB LED 101

Voltage

: 40V DC

Lens

: 25º, 40º

Diffuser

: 8 mm Clear Glass (Frosted Glass on request)

Cable

: Potted 10m 4x0,75 H03 VV-F

112

RGB LED Code No 412301

ATLANTIS 2

9 x 350 mA (9 W) RGB LED Voltage

: 40V DC

Lens

: 25º, 40º

97 38

Diffuser

: 8 mm Clear Glass (Frosted Glass on request)

Cable

: Potted 10m 4x0,75 H03 VV-F

155

RGB LED Code No 412411

385

ATLANTIS

NEARWATER LED SPOT Class III IP67 IK10

ATLANTIS 3

6 x 350 mA (6 W) LED or 6 x 700 mA (18 W) LED

Warm White Natural White Cool White Blue Red Amber Green

Total Lighting Output 6W 18W 510 lm 1350 lm 3000 K 510 lm 1350 lm 4500 K 612 lm 1620 lm 6000 K

121

6W 421501 421502 421503 421504 421505 421506 421507

Voltage

: 12V AC or DC (24V AC or DC on request)

Lens

: 10º, 25º, 40º

Diffuser

: 8 mm Clear Glass (Frosted Glass on request)

Cable

: Potted 5 m 2x0,75 H03 VV-F

18W 421511 421512 421513 421514 421515 421516 421517

155

ATLANTIS 4

9 x 350 mA (9 W) LED or 9 x 700 mA (27 W) LED

Warm White Natural White Cool White Blue Red Amber Green

Total Lighting Output 9W 27W 765 lm 2100 lm 3000 K 765 lm 2100 lm 4500 K 918 lm 2520 lm 6000 K

139

9W 421601 421602 421603 421604 421605 421606 421607

Voltage

: 12V AC or DC (24V AC or DC on request)

Lens

: 10º, 25º, 40º

Diffuser

: 8 mm Clear Glass (Frosted Glass on request)

Cable

: Potted 5 m 2x0,75 H03 VV-F

386

27W 421611 421612 421613 421614 421615 421616 421617

155

ATLANTIS

NEARWATER LED SPOT Class III IP67 IK10

ATLANTIS 5

6 x 350 mA (6 W) LED or 6 x 700 mA (18 W) LED

Warm White Natural White Cool White Blue Red Amber Green

Total Lighting Output 6W 18W 510 lm 1350 lm 3000 K 510 lm 1350 lm 4500 K 612 lm 1620 lm 6000 K

161

6W 412311 412316 412317 412312 412313 412314 412315

Voltage

: 12V AC or DC (24V AC or DC on request)

Lens

: 10º, 25º, 40º

Diffuser

: 8 mm Clear Glass (Frosted Glass on request)

Cable

: Potted 5 m 2x0,75 H03 VV-F

18W 421961 421962 421963 421964 421965 421966 421967

112

ATLANTIS 5

9 x 350 mA (9 W) LED or 9 x 700 mA (27 W) LED

Warm White Natural White Cool White Blue Red Amber Green

Total Lighting Output 9W 27W 765 lm 2100 lm 3000 K 765 lm 2100 lm 4500 K 918 lm 2520 lm 6000 K

161

9W 412321 412326 412327 412322 412323 412324 412325

Voltage

: 12V AC or DC (24V AC or DC on request)

Lens

: 10º, 25º, 40º

Diffuser

: 8 mm Clear Glass (Frosted Glass on request)

Cable

: Potted 5 m 2x0,75 H03 VV-F

27W 421951 421952 421953 421954 421955 421956 421957

112

387

ATLANTIS

NEARWATER RGB LED SPOT Class III IP67 IK10

ATLANTIS 27

27 x 350 mA (30 W) RGB LED 169

Voltage

: 40V DC

Lens

: 25º, 40º

Diffuser

: 8 mm Clear Glass (Frosted Glass on request)

Cable

: Potted 10m 4x0,75 H03 VV-F

RGB LED Code No 412331

388

112

ATLANTIS

NEARWATER LED SPOT Class III IP67 IK10

ATLANTIS 5

6 x 350 mA (6 W) LED or 6 x 700 mA (18 W) LED

Warm White Natural White Cool White Blue Red Amber Green

Total Lighting Output 6W 18W 510 lm 1350 lm 3000 K 510 lm 1350 lm 4500 K 612 lm 1620 lm 6000 K

157

6W 412341 412346 412347 412342 412343 412344 412345

Voltage

: 12V AC or DC (24V AC or DC on request)

Lens

: 10º, 25º, 40º

Diffuser

: 8 mm Clear Glass (Frosted Glass on request)

Cable

: Potted 5 m 2x0,75 H03 VV-F

18W 421971 421972 421973 421974 421975 421976 421977

158

50 159

ATLANTIS 5

9 x 350 mA (9 W) LED or 9 x 700 mA (27 W) LED

Warm White Natural White Cool White Blue Red Amber Green

Total Lighting Output 9W 27W 765 lm 2100 lm 3000 K 765 lm 2100 lm 4500 K 918 lm 2520 lm 6000 K

157

9W 412351 412356 412357 412352 412353 412354 412355

Voltage

: 12V AC or DC (24V AC or DC on request)

Lens

: 10º, 25º, 40º

Diffuser

: 8 mm Clear Glass (Frosted Glass on request)

Cable

: Potted 5 m 2x0,75 H03 VV-F

27W 421981 421982 421983 421984 421985 421986 421987

158

50 159

389

ATLANTIS

NEARWATER RGB LED SPOT Class III IP67 IK10

ATLANTIS 5

27 x 350 mA (30 W) RGB LED 157

Voltage

: 40V DC

Lens

: 25º, 40º

Diffuser

: 8 mm Clear Glass (Frosted Glass on request)

Cable

: Potted 10m 4x0,75 H03 VV-F

158

50 159

RGB LED Code No 412361

390

ATLANTIS

MARINE BOLLARD Class I IP65 IK08

EMFA’s Atlantis bollard is made of a combination 316L stainless steel and polycarbonate for use in all weather conditions without risk of corrosion. The bollard is designed to light pathways, landscapes and open spaces. The unit comes in 3 sizes: 450mm, 700mm, and 1100mm, as well as with 2 lamp options: LED and Fluorescent. The bollard can have a polished, brushed, or matt finish. An optional galvanized steel anchorage kit is available for mounting into concrete. An alternative option is sleeve anchors for mounting onto existing concrete.

Head 316L Stainless Steel Diffuser Clear Polycarbonate Pipe 316L Stainless Steel Isolation Belt Polycarbonate Finish Polished

Code No 955201

Anchor 20

400

Code Number should be indicated along with bollard code number

ATLANTIS (45 CM) CODE NO 409001 LİNEAR LED (4W)

450

CODE NO 409011 ELECTRONIC FLUO. 23W E27

Ø 154

CODE NO 409021 FLUO. 26W G24 q-3

ATLANTIS (70 CM) CODE NO 409101 LİNEAR LED (4W)

ATLANTIS (110 CM) CODE NO 409201 LİNEAR LED (4W)

700

CODE NO 409111 ELECTRONIC FLUO. 23W E27 CODE NO 409121 FLUO. 26W G24 q-3

CODE NO 409211 ELECTRONIC FLUO. 23W E27 Ø 154

1100

CODE NO 409221 FLUO. 26W G24 q-3

Ø 154

391

392

ATLANTIS

MARINE BOLLARD Class I IP65 IK08

Head 316L Stainless Steel Diffuser Clear Polycarbonate Pipe 316L Stainless Steel Isolation Belt Polycarbonate Finish Brushed

Code No 955201

Anchor 20

400

Code Number should be indicated along with bollard code number

ATLANTIS (45 CM) CODE NO 410001 4x350mA LİNEAR LED (4W)

450

CODE NO 410011 ELECTRONIC FLUO. 23W E27

Ø 154

CODE NO 410021 FLUO. 26W G24 q-3

ATLANTIS (70 CM) CODE NO 410101 4x350mA LİNEAR LED (4W)

ATLANTIS (110 CM) CODE NO 410201 4x350mA LİNEAR LED (4W)

700

CODE NO 410111 ELECTRONIC FLUO. 23W E27 CODE NO 410121 FLUO. 26W G24 q-3

CODE NO 410211 ELECTRONIC FLUO. 23W E27 Ø 154

1100

CODE NO 410221 FLUO. 26W G24 q-3

Ø 154

393

INOX

LED APPLIQUES Class I IP65 IK08

The Inox Applique series consists of a range of LED, metal halide and halogen sources to deliver the desired light effect to facedes and columns. The series is made of die cast aluminium and extrusion aluminium painted with electrostatic powder paint. 6 standard RAL colors can be chosen from to adapt the spots to their environment. The LEDs used come in 3 different tones of white, as well as blue, red, green, amber and RGB. Several lenses from 6 to 40 degrees are available to choose from to achieve the desired the light effect.

Pipe 316L Stainless Steel Body 316L Stainless Steel Cover 316L Stainless Steel Finish Polished Diffusers Tempered Glass Gaskets Silicone Connection IP connection box

394

INOX

ROUND ONE-WAY APPLIQUES Class I IP65 IK08

INOX 1 ROUND ONE WAY Voltage

: 240V A.C with integrated driver (24V AC or DC on request)

Lens

: 24º / 36º / 60º

Cable

: Potted 5 m 3x0,75 H03 VV-F

Warm White Natural White

3000 K 4000 K

6W 135001 135002

100

150

20W 135011 135012

20W

: 240V A.C with integrated driver

150

(24V AC or DC on request) Lens

: 24º / 36º / 60º

Cable

: Potted 5 m 3x0,75 H03 VV-F

Warm White Natural White

3000 K 4000 K

200

100

1x6W or 1x20W CREE COB LED 6W 135021 135022

200

150

20W 135031 135032

INOX 3 ROUND ONE WAY

20W

: 240V A.C with integrated driver

150 80

(24V AC or DC on request)

Lens

: 24º / 36º / 60º

Cable

: Potted 5 m 3x0,75 H03 VV-F

300 300

100

1x6W or 1x20W CREE COB LED Warm White Natural White

3000 K 4000 K

150

INOX 2 ROUND ONE WAY

Voltage

100

1x6W or 1x20W CREE COB LED

Voltage

20W

6W 135041 135042

20W 135051 135052

150

395

INOX

ROUND TWO-WAY APPLIQUES Class I IP65 IK08

2x4W

INOX 1 ROUND TWO WAY Voltage

: 240V A.C with integrated driver (24V AC or DC on request)

Lens

: 24º / 36º / 60º

Cable

: Potted 5 m 3x0,75 H03 VV-F

2x4W or 2x15W CREE COB LED 2x4W 135101 Warm White 3000 K 135102 Natural White 4000 K

100

Cable

: Potted 5 m 3x0,75 H03 VV-F

2x4W or 2x15W CREE COB LED 2x4W 135121 Warm White 3000 K 135122 Natural White 4000 K

2x4W

2x15W 150 70

200

150

2x15W 135131 135132

2x4W

INOX 3 ROUND TWO WAY

2x15W

: 240V A.C with integrated driver

150 80

(24V AC or DC on request) Lens

: 24º / 36º / 60º

Cable

: Potted 5 m 3x0,75 H03 VV-F

50 300 300

100

2x4W or 2x15W CREE COB LED 2x4W 135141 Warm White 3000 K 135142 Natural White 4000 K

396

150

2x15W 135111 135112

(24V AC or DC on request) : 24º / 36º / 60º

150

: 240V A.C with integrated driver

Lens

Voltage

100

INOX 2 ROUND TWO WAY Voltage

2x15W

2x15W 135151 135152

150

INOX

SQUARE ONE-WAY APPLIQUES Class I IP65 IK08

INOX 1 SQUARE ONE WAY Voltage

20W

: 240V A.C with integrated driver

(24V AC or DC on request) Lens

: 24º / 36º / 60º

Cable

: Potted 5 m 3x0,75 H03 VV-F

3000 K 4000 K

6W 135201 135202

100

20W 135211 135212

Voltage

: 240V A.C with integrated driver

Lens

: 24º / 36º / 60º

Cable

: Potted 5 m 3x0,75 H03 VV-F

(24V AC or DC on request)

20W 150

200

100

150

1x6W or 1x20W CREE COB LED 3000 K 4000 K

150

Warm White Natural White

150

INOX 2 SQUARE ONE WAY

6W 135221 135222

150

100

1x6W or 1x20W CREE COB LED Warm White Natural White

300

150

20W 135231 135232

397

INOX

SQUARE TWO-WAY APPLIQUES Class I IP65 IK08

2x4W

INOX 1 SQUARE TWO WAY Voltage

: 240V A.C with integrated driver

(24V AC or DC on request) Lens

: 24º / 36º / 60º

Cable

: Potted 5 m 3x0,75 H03 VV-F

2x4W or 2x15W CREE COB LED Polished 135301 Warm White 3000 K 135302 Natural White 4000 K

150

100

150

60 60

Brushed 135311 135312

2x4W

Voltage

: 240V A.C with integrated driver

Lens

: 24º / 36º / 60º

Cable

: Potted 5 m 3x0,75 H03 VV-F

(24V AC or DC on request)

2x4W or 2x15W CREE COB LED Polished 135321 Warm White 3000 K 135322 Natural White 4000 K

100

INOX 2 SQUARE TWO WAY

398

2x15W

2x15W 150

200

100

Brushed 135331 135332

150

300

150

INOX

SURFACE MOUNTED CEILING FIXTURES Class I IP65 IK08

The Inox surface series consists of a range of LED, metal halide and halogen sources to deliver the desired light effect to facedes and columns. The series is made of die cast aluminium and extrusion aluminium painted with electrostatic powder paint. 6 standard RAL colors can be chosen from to adapt the spots to their environment. The LEDs used come in 3 different tones of white, as well as blue, red, green, amber and RGB. Several lenses from 6 to 40 degrees are available to choose from to achieve the desired the light effect. Body 316L Stainless Steel Cover 316L Stainless Steel Finish Polished Diffusers Tempered Glass Gaskets Silicone Connection IP connection box

LEDs Only highest quality LEDs such as CREE and Seoul conductor are used in production allowing for maximum lumen output and maximum lifetime. Most LEDs run on 350mA or 700mA depending on how much light output is required. The white color temperature binning is 200K at most, and always on the same x,y coordinates on the CIE diagram in accordance with Energy Star. This ensures consistent supply of the same color temperatture over time. As LEDs are constantly developing and becoming more efficient, lumen output given in this catalogue are current as of March 2014. At 2700K, 3300K, and 4500K LED lumen output per led is 75lm; at 6000K the lumen output per led is 115lm. Total Lighting Output as printed in this catalogue is the actual light output of the entire fixture. The minimum CRI of the LEDs used is 85 with a majority of products over 90. Thermal Management All fixtures are designed to withstand ambient temperatures of at least 50˚C. The LEDs are mounted on metal core pcbs, which are mounted the aluminium body of the fixture so that the entire fixture acts as a heat sink. Extensive testing is performed in EMFA’s laboratory to ensure these values are maintained so that the lifetime of the LED is not compromised.

399

INOX

SURFACE MOUNTED CEILING FIXTURES Class I IP65 IK08

INOX 1 SURFACE Voltage

: 240V A.C with integrated driver

Lens

: 24º / 36º / 60º

Cable

: Potted 5 m 3x0,75 H03 VV-F

150

(24V AC or DC on request) 150

1x15W/20W CREE COB LED Warm White Natural White

3000 K 4000 K

Polished 136001 136002

Brushed 136011 136012

INOX 2 SURFACE Voltage

: 240V A.C with integrated driver 300

(24V AC or DC on request) Lens

: 24º / 36º / 60º

Cable

: Potted 5 m 3x0,75 H03 VV-F

1x15W/20W/30W CREE COB LED Polished 136021 Warm White 3000 K 136022 Natural White 4000 K

400

150

Brushed 136031 136032

Downlights

401

PINARA

LINEAR LED DOWNLIGHT Class II IP20 Black

White

The PINARA LED downlight is specially designed to deliver high output LED light with very clean beam angles to corridors, hotel rooms, museums and general lighting of public spaces. The Nichia LEDs in the PINARA are very efficient and have a high CRI (90). The unique lens that is used in this fixture creates very sharp beams that minimize the spill of uncontrolled light from the fixture. This reduces the glare of the fixture and gives more control to the architects and designers.

Body Polycarbonate Heatsing Aluminium extrusion profile Diffuser With clear or frosted tempered glass, without glass Springs Steel Cable 0.5 m exiting top of fixture Gear Non-Dimmable electronic LED driver (1-10V Dimmable and DALI drivers available on request)

Downlight Application Symmetrical and asymmetrical lighting for general lighting such as museums, hospitals, hotel rooms, dormitories, corridors, shops, and balconies.

90º

70º

80º

60º

40º

50º

30º

10º

20º

10º

0º

30º

20º

40º

60º

50º

70º

90º

80º

“Customization” is EMFA’s standard EMFA offers many combinations for each fixture, as all fixtures are made in house. A combination of 2 standard paint colors, 2 white tones, 2 wattages are available to make the fixture suitable for the required application. This is done without increasing lead-time and is available for large as well as small quantities. %0 % 10 % 20 % 30

% 40 % 50 % 60 % 70 % 80 % 90

402

% 90 -- 45º

% 50 -- 41º

% 90 -- 45º

% 100

Thermal Management All fixtures are designed to withstand ambient temperatures of at least 50˚C. The LEDs are mounted on metal core pcbs, which are mounted the aluminium body of the fixture so that the entire fixture acts as a heat sink. Extensive testing is performed in EMFA’s laboratory to ensure these values are maintained so that the lifetime of the LED is not compromised.

PINARA

LINEAR LED DOWNLIGHT Class II IP20 Black

White

PINARA 1 Clear or frosted tempered Glass

Led : 350 - 500 - 700 mA (Nichia) Diffuser Clear of frosted tempered Glass Gear : 240V Non-Dimmable Driver (1-10V Dimmable Driver and DALI Driver available on request) Cable : 0.5 m 2x0,75 mm H03 VV-F

351

333

Warm White 3000 K 10W - 350 mA 15W - 500 mA 21W - 700 mA Natural White 10W - 350 mA 15W - 500 mA 21W - 700 mA

1050 lm 1500 lm 2050 lm

Code No: 392001 Code No: 392002 Code No: 392003

4000 K 1150 lm 1600 lm 2200 lm

Code No: 392011 Code No: 392012 Code No: 392013

403

PINARA

LINEAR LED DOWNLIGHT Class II IP20 Black

White

PINARA 2 SYMMETRICAL

Led : 350 - 500 - 700 mA (Nichia) Gear : 240V Non-Dimmable Driver (1-10V Dimmable Driver and DALI Driver available on request) Cable : 0.5 m 2x0,75 mm H03 VV-F

50 65

331

Warm White 3000 K 10W - 350 mA 15W - 500 mA 21W - 700 mA Natural White 10W - 350 mA 15W - 500 mA 21W - 700 mA

315

1050 lm 1500 lm 2050 lm

Code No: 392101 Code No: 392102 Code No: 392103

4000 K 1150 lm 1600 lm 2200 lm

Code No: 392111 Code No: 392112 Code No: 392113

PINARA 2 ASYMMETRICAL

Led : 350 - 500 - 700 mA (Nichia) Gear : 240V Non-Dimmable Driver (1-10V Dimmable Driver and DALI Driver available on request) Cable : 0.5 m 2x0,75 mm H03 VV-F

105

120

331

Warm White 3000 K 10W - 350 mA 15W - 500 mA 21W - 700 mA Natural White 10W - 350 mA 15W - 500 mA 21W - 700 mA

404

1050 lm 1500 lm 2050 lm

Code No: 392121 Code No: 392122 Code No: 392123

4000 K 1150 lm 1600 lm 2200 lm

Code No: 392131 Code No: 392132 Code No: 392133

315

PINARA

TRIMLESS LINEAR LED DOWNLIGHT Class II IP20 Black

White

PINARA SYMMETRICAL TRIMLESS

Led : 350 - 500 - 700 mA (Nichia) Gear : 240V Non-Dimmable Driver (1-10V Dimmable Driver and DALI Driver available on request) Cable : 0.5 m 2x0,75 mm H03 VV-F

55 49

315

Warm White 3000 K 10W - 350 mA 15W - 500 mA 21W - 700 mA Natural White 10W - 350 mA 15W - 500 mA 21W - 700 mA

321

1050 lm 1500 lm 2050 lm

Code No: 392141 Code No: 392142 Code No: 392143

4000 K 1150 lm 1600 lm 2200 lm

Code No: 392151 Code No: 392152 Code No: 392153

PINARA ASYMMETRICAL TRIMLESS

Led : 350 - 500 - 700 mA (Nichia) Gear : 240V Non-Dimmable Driver (1-10V Dimmable Driver and DALI Driver available on request) Cable : 0.5 m 2x0,75 mm H03 VV-F

107

102 55

313

Warm White 3000 K 10W - 350 mA 15W - 500 mA 21W - 700 mA Natural White 10W - 350 mA 15W - 500 mA 21W - 700 mA

1050 lm 1500 lm 2050 lm

Code No: 392161 Code No: 392162 Code No: 392163

4000 K 1150 lm 1600 lm 2200 lm

Code No: 392171 Code No: 392172 Code No: 392173

318

405

PENTATHLON

LED DOWNLIGHT Class II IP20

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

The PENTATHLON Dark Reflector LED Downlight is specially designed to provide low glare lighting in high ceiling areas. The Nichia COB chip gives out a high efficiency and high CRI (90) light. The lens that is used in the PENTATHLON allows the light to reach the ground with minimal loss from deep inside the fixture. The depth of the fixture and the clean beam of the lens is what provides the low glare of this fixture.

Body Die cast aluminium Paint Electrostatic powder paint RAL 9016 (available in other RAL colors) Springs Steel for mounting in ceilings of 1-25mm thickness Gear Non-Dimmable electronic LED driver (1-10V Dimmable and DALI drivers available on request) Cable 0.5m exiting from top of fixture

Downlight Application Wide and narrow beam symmetrical and asymmetrical lighting for general lighting such as museums, hospitals, hotel rooms, dormitories, corridors, shops, and balconies.

“Customization” is EMFA’s standard EMFA offers many combinations for each fixture, as all fixtures are made in house. A combination of 4 standard paint colors, 2 white tones, 2 wattages, and 2 or more lenses and reflectors are available to make the fixture suitable for the required application. This is done without increasing lead-time and is available for large as well as small quantities.

406

PENTATHLON

LED DOWNLIGHT Class II IP20

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

PENTATHLON SYMMETRICAL

Led

: 350mA 13W / 700mA 24W LED (Nichia)

Reflector

: 24º or 38º

Gear

: 240V Non-Dimmable Driver

(1-10V Dimmable Driver & DALI Driver available on request) Cable

Ø 110

Ø 101,5

: 0,5 m 2x0,75 mm H03 VV-F

13W - 350 mA Warm White Natural White

3000 K 4000 K

Total Lighting Output Code No 1250 lm 118201 1375 lm 118202

Ø 125

PENTATHLON ASYMMETRICAL

Led

: 350mA 13W / 700mA 24W LED (Nichia)

Reflector

: 24º or 38º

Gear

: 240V Non-Dimmable Driver

(1-10V Dimmable Driver & DALI Driver available on request) Cable

Ø 110

Ø 101,5

: 0,5 m 2x0,75 mm H03 VV-F

13W - 350 mA Warm White Natural White

3000 K 4000 K

Total Lighting Output Code No 1250 lm 118221 1375 lm 118222

Ø 125

407

PENTATHLON

TRIMLESS LED DOWNLIGHT Class II IP20

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

PENTATHLON SYMMETRICAL

Led

: 350mA 13W / 700mA 24W LED (Nichia)

Reflector

: 24º or 38º

Gear

: 240V Non-Dimmable Driver

108,50

(1-10V Dimmable Driver & DALI Driver available on request) Cable

: 0,5 m 2x0,75 mm H03 VV-F Ø 108,5

13W - 350 mA Warm White Natural White

3000 K 4000 K

Total Lighting Output Code No 1250 lm 118301 1375 lm 118302

PENTATHLON ASYMMETRICAL

Led

: 350mA 13W / 700mA 24W LED (Nichia)

Reflector

: 24º or 38º

Gear

: 240V Non-Dimmable Driver

97 50

(1-10V Dimmable Driver & DALI Driver available on request) Cable

: 0,5 m 2x0,75 mm H03 VV-F Ø 108,5

13W - 350 mA Warm White Natural White

408

3000 K 4000 K

Total Lighting Output Code No 1250 lm 118321 1375 lm 118322

108,50

409

SATURN

LED DOWNLIGHT Class II IP20

Available in any of these RAL colors

9016

9005

7016

7004

1015

The Saturn LED Downlight is specially designed to provide highest energy efficiency in general lighting applications. Using latest LED technology in combination with special plastic moulding and paint application allows for around 90lm/W lighting output. The highly efficient diffuser provides a completely homogenous light output.

Fixed

Adjustable

Application Wide beam fixed & adjustable lighting for general lighting such as museums, hospitals, hotel rooms, dormitories, corridors, shops, and balconies.

“Customization” is EMFA’s standard EMFA offers many combinations for each fixture, as all fixtures are made in house. A combination of 4 standard paint colors, 3 white tones, 2 wattages, and 3 or more lenses and reflectors are available to make the fixture suitable for the required application. This is done without increasing lead-time and is available for large as well as small quantities.

410

SATURN

LED DOWNLIGHT Class II IP20

Available in any of these RAL colors

9016

9005

7016

7004

1015

Fixed

Led

: 180mA 6W / 250mA 8W COB LED

Reflector

: 10º / 38º

Gear

: 240V Non-Dimmable Driver

Ø 75

(1-10V Dimmable Driver & DALI Driver available on request) Cable

: 0,5 m 2x0,75 mm H03 VV-F

3000 K 4000 K 6000 K

Total Lighting Output 460 lm 510 lm 545 lm

Code No 528001 528002 528003

3000 K 4000 K 6000 K

520 lm 560 lm 644 lm

528011 528012 528013

6W - 180mA Warm White Natural White Cool White

Ø 90

8W - 250mA Warm White Natural White Cool White Adjustable

Led

: 180mA 6W / 250mA 8W COB LED

Reflector

: 10º / 38º

Gear

: 240V Non-Dimmable Driver

Ø 75

(1-10V Dimmable Driver & DALI Driver available on request) Cable

: 0,5 m 2x0,75 mm H03 VV-F

3000 K 4000 K 6000 K

Total Lighting Output 460 lm 510 lm 545 lm

Code No 528101 528102 528103

3000 K 4000 K 6000 K

520 lm 560 lm 644 lm

528111 528112 528113

6W - 180mA Warm White Natural White Cool White

Ø 90

8W - 250mA Warm White Natural White Cool White

411

CUNDA

LED DOWNLIGHT Class II IP44

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

CUNDA 1

CUNDA 1 DOT

3000 K 4000 K

Total Lighting Output Code No 560 lm 419201 590 lm 419202

3000 K 4000 K

Total Lighting Output Code No 490 lm 419211 530 lm 419212

3000 K 4000 K

Total Lighting Output Code No 419301 890 lm 419302 925 lm

3000 K 4000 K

Total Lighting Output Code No 419311 790 lm 419312 830 lm

250 mA (7 W) LED Warm White Natural White

CUNDA 1 HALO 250 mA (7 W) LED Warm White Natural White

Ø 110

Ø 120

Ø 110

Ø 120

CUNDA 2

CUNDA 2 DOT 320 mA (11 W) LED Warm White Natural White

CUNDA 2 HALO 320 mA (11 W) LED Warm White Natural White

412

Ø 140

Ø 150

Ø 140

Ø 150

PATARA

LED DOWNLIGHT Class II IP44

PATARA 1

110

PATARA 1 DOT 250 mA (7 W) LED Warm White Natural White

3000 K 4000 K

Total Lighting Output Code No 560 lm 420301 590 lm 420302

110

Ø 120

110

PATARA 1 HALO 250 mA (7 W) LED Warm White Natural White

3000 K 4000 K

Total Lighting Output Code No 490 lm 420311 530 lm 420312

110

Ø 120

PATARA 2

140

PATARA 2 DOT

3000 K 4000 K

Total Lighting Output Code No 420401 890 lm 420402 925 lm

3000 K 4000 K

Total Lighting Output Code No 420411 790 lm 420412 830 lm

320 mA (11 W) LED Warm White Natural White

Ø 150

140

PATARA 2 HALO 320 mA (11 W) LED Warm White Natural White

140

Ø 150

413

DOT

LED DOWNLIGHT Class II IP44

DOT DOWNLIGHT

DOT DOWNLIGHT 250 mA (7 W) LED Warm White Natural White

3000 K 4000 K

Total Lighting Output Code No 925 lm 112311 975 lm 112312

3000 K 4000 K

Total Lighting Output Code No 540 lm 112401 580 lm 112402

350 mA (11 W) LED Warm White Natural White

Total Lighting Output Code No 600 lm 112301 640 lm 112302

HALO DOWNLIGHT

HALO DOWNLIGHT 250 mA (7 W) LED Warm White Natural White

350 mA (11 W) LED Warm White Natural White

414

3000 K 4000 K

Total Lighting Output Code No 830 lm 112411 880 lm 112412

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

BELKIS MINI

LED DOWNLIGHT Class I IP65

Cover Die cast aluminium or Stainless steel Body Die cast aluminium Gaskets Silicone Diffusers Tempered Glass

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

Ø 50

Ø 40

Voltage

: 240V A.C with integrated driver

Lens

: 25º, 40º

Diffuser

: Clear Glass with painted circumference

(24V AC or DC on request)

8 mm (Frosted Glass on request) Cable

: Potted 5 m 3x0,75 H03 VV-F

1 x 350 mA (1 W) LED Warm White Natural White Cool White

3000 K 4500 K 6000 K

Total Lighting Output

Code No

85 lm 85 lm 102 lm

297001 297002 297003

415

MARATHON

LED DOWNLIGHT Class II IP65 IK10

The Marathon LED Downlight is specially designed to deliver high output LED light to indoors and outdoors using CREE LEDs. This downlight is the choice for lighting applications where high luminous-flux output is required from a single, small point source. A combination of high color rendition of over 80, several different color temperatures and several degree reflectors and lenses allow the use in a wide range of applications such as museums, hospitals, hotel rooms, dormitories, corridors, shops, and balconies. The shallow fixture depths allow for installation into most ceilings and applications. Non-dimmable drivers come standard with the Downlights, but 1-10V dimmable and DALI drivers are available on request. An ample heat sink is provided for to allow for the lifetime of L70 = 50,000 hours. Body Die cast aluminium designed to be heat sink Cover Die cast aluminium RAL9002 (available in other RAL colors as well as chrome or gold on request) Diffuser Clear of frosted tempered Glass Springs Stainless steel for mounting in ceilings or 1-25 mm (with plastic covers for the Marathon 2 Downlight) Cable 0.5 m exiting top of fixture Gear Non-Dimmable electronic LED driver (1-10V Dimmable and DALI drivers available on request) Downlight Application Narrow to wide beam symmetrical lighting for general lighting such as museums, hospitals, hotel rooms, dormitories, corridors, shops, and balconies.

“Customization” is EMFA’s standard EMFA offers many combinations for each fixture, as all fixtures are made in house. A combination of 4 standard paint colors, 3 white tones, 3 wattages, and 3 or more lenses and reflectors are available to make the fixture suitable for the required application. This is done without increasing lead-time and is available for large as well as small quantities.

416

MARATHON 2

LED DOWNLIGHT Class II IP65 IK10

Led

: COB LED (350-500mA)

Reflector

: 10º, 23º, 38º Aluminium-Coated Polycarbonate Reflector

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Gear

: 240V Non-Dimmable Driver

Available in any of these RAL colors

9016

1015

Ø 105

: Plastic covered Stainless Steel for mounting in ceilings of 1-25 mm

Cable

: 0,5 m 2x0,75 mm H03 VV-F 10º

Warm White Natural White

7004

66,5

Springs

Code No Total Lighting Output 11W 18W 18W 11W 3000 K 696 lm 1224 lm 260102 260111 4000 K 835 lm 1469 lm 260103 260112

7016

Ø 90

(1-10V Dimmable Driver & DALI Driver available on request)

1 x 350 mA (11 W) LED or 1 x 500 mA (18 W) LED

9005

23º

38º

2m Ø 0,35m 0,01m²

13759 lx

2m Ø 0,81m 0,52m²

2705 lx

2m Ø 1,38m 1,49m²

989 lx

4m Ø 0,70m 0,38m²

3440 lx

4m Ø 1,63m 2,08m²

676 lx

4m Ø 2,76m 5,97m²

247 lx

6m Ø 1,05m 0,87m²

1529 lx

6m Ø 2,44m 4,68m²

301 lx

6m Ø 4,13m 13,40m²

110 lx

8m Ø 1,40m 1,54m²

861 lx

8m Ø 3,26m 8,33m²

169 lx

8m Ø 5,51m 23,84m²

62 lx

10m Ø 1,75m 2,40m²

550 lx

10m Ø 4,07m 13,02m²

108 lx

10m Ø 6,89m 37,29m²

40 lx

417

MARATHON

TIR LENS LED DOWNLIGHT Class II IP65 IK10

Available in any of these RAL colors

9016

9005

7016

7004

1015

MARATHON 3 DOWNLIGHT

Ø 110

1 x 350mA (11 W) or 1 x 700mA (18 W) Led

: COB LED (350-700 mA)

Lens

: 10º, 20º, 30º Mirror TIR Lens

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Gear

: 240V Non-Dimmable Driver

Ø 130

(1-10V Dimmable Driver & DALI Driver available on request) Springs

: Stainless Steel for mounting in ceilings of 1-25 mm

Cable

: 0,5 m 2x0,75 mm H03 VV-F Total Lighting Output 11W 18W

POWERLED Warm White Natural White

3000 K 4000 K

655 lm 1153 lm 786 lm 1383 lm

10º Code No 18W 11W 261001 261011 261002 261012

20º

30º

2m Ø 0,35m 0,10m²

12336lx

2m Ø 0,71m 0,39m²

3438 lx

2m Ø 1,07m 0,90m²

1644 lx

4m Ø 0,70m 0,38m²

3084 lx

4m Ø 1,41m 1,56m²

860 lx

4m Ø 2,14m 3,61m²

411lx

6m Ø 1,05m 0,87m²

1371lx

6m Ø 2,12m 3,52m²

382 lx

6m Ø 3,22m 8,13m²

183 lx

8m Ø 1,40m 1,54m²

771 lx

8m Ø 2,82m 6,26m²

215 lx

8m Ø 4,29m 14,45m²

10m Ø 1,75m 2,40m²

493 lx

10m Ø 3,53m 9,78m²

138 lx

10m Ø 5,36m 22,58m²

103 lx 66 lx

MARATHON 4 DOWNLIGHT

Ø 130

1 x 350mA (25 W) or 1 x 700mA (32 W) Led

: COB LED (350-700 mA)

Lens

: 10º, 20º, 30º Mirror Tir Lens

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Gear

: 240V Non-Dimmable Driver

Ø 150

(1-10V Dimmable Driver & DALI Driver available on request) Springs

: Stainless Steel for mounting in ceilings of 1-25 mm

Cable

: 0,5 m 2x0,75 mm H03 VV-F Total Lighting Output 25W 32W

POWERLED Warm White Natural White

418

3000 K 4000 K

1645 lm 2134 lm 1974 lm 2561 lm

Code No 32W 25W 262001 262002

262021 262022

10º

20º

30º

2m Ø 0,35m 0,10m²

22813lx

2m Ø 0,71m 0,39m²

6261 lx

2m Ø 0,90m 1,49m²

2953lx

4m Ø 0,70m 0,38m²

5703 lx

4m Ø 1,41m 1,56m²

1565lx

4m Ø 3,61m 5,97m²

738 lx

6m Ø 1,05m 0,87m²

2535 lx

6m Ø 2,12m 3,52m²

696 lx

6m Ø 8,13m 13,40m²

328 lx

8m Ø 1,40m 1,54m²

1426 lx

8m Ø 2,82m 6,26m²

391 lx

8m Ø 14,45m 23,84m²

185 lx

10m Ø 1,75m 2,40m²

913 lx

10m Ø 3,53m 9,78m²

250 lx

10m Ø 5,36m 22,58m²

118 lx

MARATHON 2 GLASS White Glass

LED DOWNLIGHT Class II IP65 IK10

Black Glass

Led

: COB LED (350-500mA)

Reflector

: 10º, 23º, 38º Aluminium-Coated Polycarbonate Reflector

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Gear

: 240V Non-Dimmable Driver

Ø 90

66,5

(1-10V Dimmable Driver & DALI Driver available on request)

Ø 105

Springs

: Plastic covered Stainless Steel for mounting in ceilings of 1-25 mm

Cable

: 0,5 m 2x0,75 mm H03 VV-F 10º

1 x 350 mA (11 W) LED or 1 x 500 mA (18 W) LED Total Lighting Output 11W 18W Warm White Natural White

3000 K 4000 K

White Glass

696 lm 1224 lm 835 lm 1469 lm

Code No 18W 11W 263002 263012 263003 263013

23º

38º

2m Ø 0,35m 0,01m²

13759 lx

2m Ø 0,81m 0,52m²

2705 lx

2m Ø 1,38m 1,49m²

989 lx

4m Ø 0,70m 0,38m²

3440 lx

4m Ø 1,63m 2,08m²

676 lx

4m Ø 2,76m 5,97m²

247 lx

6m Ø 1,05m 0,87m²

1529 lx

6m Ø 2,44m 4,68m²

301 lx

6m Ø 4,13m 13,40m²

110 lx

8m Ø 1,40m 1,54m²

861 lx

8m Ø 3,26m 8,33m²

169 lx

8m Ø 5,51m 23,84m²

62 lx

10m Ø 1,75m 2,40m²

550 lx

10m Ø 4,07m 13,02m²

108 lx

10m Ø 6,89m 37,29m²

40 lx

Black Glass

Ø 90

1 x 350 mA (11 W) LED or 1 x 500 mA (18 W) LED Total Lighting Output 11W 18W Warm White Natural White

3000 K 4000 K

696 lm 1224 lm 835 lm 1469 lm

Code No 18W 11W 263202 263212 263203 263213

66,5

Ø 105

10º

23º

38º

2m Ø 0,35m 0,01m²

13759 lx

2m Ø 0,81m 0,52m²

2705 lx

2m Ø 1,38m 1,49m²

989 lx

4m Ø 0,70m 0,38m²

3440 lx

4m Ø 1,63m 2,08m²

676 lx

4m Ø 2,76m 5,97m²

247 lx

6m Ø 1,05m 0,87m²

1529 lx

6m Ø 2,44m 4,68m²

301 lx

6m Ø 4,13m 13,40m²

110 lx

8m Ø 1,40m 1,54m²

861 lx

8m Ø 3,26m 8,33m²

169 lx

8m Ø 5,51m 23,84m²

62 lx

10m Ø 1,75m 2,40m²

550 lx

10m Ø 4,07m 13,02m²

108 lx

10m Ø 6,89m 37,29m²

40 lx

419

420

MARATHON 2 Wallwasher

Led

LED DOWNLIGHT Class II IP20

Available in any of these RAL colors

9016

9005

7016

7004

1015

Ellipse

: COB LED (350-500mA)

Reflector

: Wallwasher or Ellipse Lens

Gear

: 240V Non-Dimmable Driver

Ø 90

(1-10V Dimmable Driver & DALI Driver available on request) Springs

: Plastic covered Stainless Steel for mounting in ceilings of 1-25 mm

Cable

: 0,5 m 2x0,75 mm H03 VV-F

Ø 105

1 x 350 mA (11 W) LED or 1 x 500 mA (18 W) LED Total Lighting Output 12W 18W Warm White Natural White

3000 K 4000 K

1098 lm 1638 lm 1317 lm 1965 lm

Wallwasher 18W 12W 264001 264011 264002 264012

Ellipse 18W 12W 264101 264111 264102 264112

Two Way

Led

: COB LED (350-500mA)

Reflector

: Wallwasher Lens

Gear

: 240V Non-Dimmable Driver

Ø 90

(1-10V Dimmable Driver & DALI Driver available on request) Springs

: Plastic covered Stainless Steel for mounting in ceilings of 1-25 mm

Cable

: 0,5 m 2x0,75 mm H03 VV-F

Ø 105

1 x 350 mA (11 W) LED or 1 x 500 mA (18 W) LED Total Lighting Output 12W 18W Warm White Natural White

3000 K 4000 K

1098 lm 1638 lm 1317 lm 1965 lm

Code No 18W 12W 264201 264211 264202 264212

421

DECATHLON

LED DOWNLIGHT Class II IP65 IK10

The Decathlon LED Downlight is specially designed to deliver high output LED light to indoors and outdoors using CREE LEDs. This downlight is the choice for lighting applications where high luminous-flux output is required from a single, small point source. The Decathlon is slightly wider and deeper than the Marathon giving a different look to the fixture, but the same output. A combination of high color rendition of over 80, several different color temperatures and several degree reflectors and lenses allow the use in a wide range of applications such as museums, hospitals, hotel rooms, dormitories, corridors, shops, and balconies. The shallow fixture depths allow for installation into most ceilings and applications. Non-dimmable drivers come standard with the Downlights, but 1-10V dimmable and DALI drivers are available on request. An ample heat sink is provided for to allow for the lifetime of L70 = 50,000 hours.

Body Die cast aluminium designed to be heat sink Cover Die cast aluminium RAL9002 (available in other RAL colors as well as chrome or gold on request) Diffuser Clear of frosted tempered Glass Springs Stainless steel for mounting in ceilings or 1-25 mm (with plastic covers for the Marathon 2 Downlight) Cable 0.5 m exiting top of fixture Gear Non-Dimmable electronic LED driver (1-10V Dimmable and DALI drivers available on request)

Downlight Application Narrow to wide beam symmetrical lighting for general lighting such as museums, hospitals, hotel rooms, dormitories, corridors, shops, and balconies.

Directional Downlight Application These fixtures give a narrow to wide beam asymmetrical light output to walls, paintings, corridors and shop displays. The die cast aluminium body has a fixed built in tilt to allow for proper heat dissipation on the LEDs that can run up to 700mA. “Customization” is EMFA’s standard EMFA offers many combinations for each fixture, as all fixtures are made in house. A combination of 4 standard paint colors, 3 white tones, 3 wattages, and 3 or more lenses and reflectors are available to make the fixture suitable for the required application. This is done without increasing lead-time and is available for large as well as small quantities.

422

DECATHLON 2

LED DOWNLIGHT Class II IP65 IK10

Available in any of these RAL colors

9016

9005

7016

7004

1015

Symmetrical

Led

: COB CREE LED (350-700mA)

Reflector

: 10º, 23º, 38º Aluminium-Coated Polycarbonate Reflector

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Gear

: 240V Non-Dimmable Driver

Ø 100

(1-10V Dimmable Driver & DALI Driver available on request)

Ø 130

Springs

: Plastic covered Stainless Steel for mounting in ceilings of 1-25 mm

Cable

: 0,5 m 2x0,75 mm H03 VV-F 10º

1 x 350 mA (11 W) LED or 1 x 500 mA (18 W) LED Total Lighting Output 11W 18W Warm White Natural White

3000 K 4000 K

696 lm 1224 lm 835 lm 1469 lm

Code No 18W 11W 260202 260212 260203 260213

23º

38º

2m Ø 0,35m 0,01m²

13759 lx

2m Ø 0,81m 0,52m²

2705 lx

2m Ø 1,38m 1,49m²

989 lx

4m Ø 0,70m 0,38m²

3440 lx

4m Ø 1,63m 2,08m²

676 lx

4m Ø 2,76m 5,97m²

247 lx

6m Ø 1,05m 0,87m²

1529 lx

6m Ø 2,44m 4,68m²

301 lx

6m Ø 4,13m 13,40m²

110 lx

8m Ø 1,40m 1,54m²

861 lx

8m Ø 3,26m 8,33m²

169 lx

8m Ø 5,51m 23,84m²

62 lx

10m Ø 1,75m 2,40m²

550 lx

10m Ø 4,07m 13,02m²

108 lx

10m Ø 6,89m 37,29m²

40 lx

Asymmetrical

Led

: COB CREE LED (350-700mA)

Reflector

: 10º, 23º, 38º Aluminium-Coated Polycarbonate Reflector

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Gear

: 240V Non-Dimmable Driver

Ø 100

(1-10V Dimmable Driver & DALI Driver available on request)

Ø 130

Springs

: Plastic covered Stainless Steel for mounting in ceilings of 1-25 mm

Cable

: 0,5 m 2x0,75 mm H03 VV-F

1 x 350 mA (11 W) LED or 1 x 500 mA (18 W) LED Total Lighting Output 11W 18W Warm White Natural White

3000 K 4000 K

696 lm 1224 lm 835 lm 1469 lm

Code No 18W 11W 260232 260242 260233 260243

10º

23º

38º

2m Ø 0,35m 0,01m²

13759 lx

2m Ø 0,81m 0,52m²

2705 lx

2m Ø 1,38m 1,49m²

989 lx

4m Ø 0,70m 0,38m²

3440 lx

4m Ø 1,63m 2,08m²

676 lx

4m Ø 2,76m 5,97m²

247 lx

6m Ø 1,05m 0,87m²

1529 lx

6m Ø 2,44m 4,68m²

301 lx

6m Ø 4,13m 13,40m²

110 lx

8m Ø 1,40m 1,54m²

861 lx

8m Ø 3,26m 8,33m²

169 lx

8m Ø 5,51m 23,84m²

62 lx

10m Ø 1,75m 2,40m²

550 lx

10m Ø 4,07m 13,02m²

108 lx

10m Ø 6,89m 37,29m²

40 lx

423

424

DECATHLON 3

TIR LENS LED DOWNLIGHT Class II IP65 IK10

Available in any of these RAL colors

9016

9005

7016

7004

1015

Symmetrical

1 x 350mA (11 W) or 1 x 700mA (18 W) Led

: COB LED (350-700mA)

Lens

: 10º, 20º, 30º Mirror TIR Lens

Ø 140

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Gear

: 240V Non-Dimmable Driver

Ø 170

(1-10V Dimmable Driver & DALI Driver available on request) Springs

: Stainless Steel for mounting in ceilings of 1-25 mm

Cable

: 0,5 m 2x0,75 mm H03 VV-F Total Lighting Output 11W 18W

POWERLED Warm White Natural White

3000 K 4000 K

655 lm 1153 lm 786 lm 1383 lm

10º Code No 18W 11W 266001 266021 266003 266023

20º

30º

2m Ø 0,35m 0,10m²

12336lx

2m Ø 0,71m 0,39m²

3438 lx

2m Ø 1,07m 0,90m²

1644 lx

4m Ø 0,70m 0,38m²

3084 lx

4m Ø 1,41m 1,56m²

860 lx

4m Ø 2,14m 3,61m²

411lx

6m Ø 1,05m 0,87m²

1371lx

6m Ø 2,12m 3,52m²

382 lx

6m Ø 3,22m 8,13m²

183 lx

8m Ø 1,40m 1,54m²

771 lx

8m Ø 2,82m 6,26m²

215 lx

8m Ø 4,29m 14,45m²

10m Ø 1,75m 2,40m²

493 lx

10m Ø 3,53m 9,78m²

138 lx

10m Ø 5,36m 22,58m²

103 lx 66 lx

Asymmetrical

1 x 350mA (11 W) or 1 x 700mA (18 W) Led

: COB LED (350-700mA)

Lens

: 10º, 20º, 30º Mirror Tir Lens

Ø 140

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Gear

: 240V Non-Dimmable Driver

Ø 170

(1-10V Dimmable Driver & DALI Driver available on request) Springs

: Stainless Steel for mounting in ceilings of 1-25 mm

Cable

: 0,5 m 2x0,75 mm H03 VV-F Total Lighting Output 11W 18W

POWERLED Warm White Natural White

3000 K 4000 K

655 lm 1153 lm 786 lm 1383 lm

Code No 18W 11W 266101 266121 266103 266123

10º

20º

30º

2m Ø 0,35m 0,10m²

12336lx

2m Ø 0,71m 0,39m²

3438 lx

2m Ø 1,07m 0,90m²

1644 lx

4m Ø 0,70m 0,38m²

3084 lx

4m Ø 1,41m 1,56m²

860 lx

4m Ø 2,14m 3,61m²

411lx

6m Ø 1,05m 0,87m²

1371lx

6m Ø 2,12m 3,52m²

382 lx

6m Ø 3,22m 8,13m²

183 lx

8m Ø 1,40m 1,54m²

771 lx

8m Ø 2,82m 6,26m²

215 lx

8m Ø 4,29m 14,45m²

10m Ø 1,75m 2,40m²

493 lx

10m Ø 3,53m 9,78m²

138 lx

10m Ø 5,36m 22,58m²

103 lx 66 lx

425

426

DECATHLON 4

TIR LENS LED DOWNLIGHT Class II IP65 IK10

Available in any of these RAL colors

9016

9005

7016

7004

1015

Symmetrical

1 x 350mA (25 W) or 1 x 700mA (32 W)

Ø 155

Led

: COB LED (350-700mA)

Lens

: 10º, 20º, 30º Mirror TIR Lens

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Gear

: 240V Non-Dimmable Driver

Ø 185

(1-10V Dimmable Driver & DALI Driver available on request) Springs

: Stainless Steel for mounting in ceilings of 1-25 mm

Cable

: 0,5 m 2x0,75 mm H03 VV-F Total Lighting Output 25W 32W

POWERLED Warm White Natural White

3000 K 4000 K

1645 lm 2134 lm 1974 lm 2561 lm

10º Code No 32W 25W 267001 267021 267003 267023

20º

30º

2m Ø 0,35m 0,10m²

22813lx

2m Ø 0,71m 0,39m²

6261 lx

2m Ø 0,90m 1,49m²

2953lx

4m Ø 0,70m 0,38m²

5703 lx

4m Ø 1,41m 1,56m²

1565lx

4m Ø 3,61m 5,97m²

738 lx

6m Ø 1,05m 0,87m²

2535 lx

6m Ø 2,12m 3,52m²

696 lx

6m Ø 8,13m 13,40m²

328 lx

8m Ø 1,40m 1,54m²

1426 lx

8m Ø 2,82m 6,26m²

391 lx

8m Ø 14,45m 23,84m²

185 lx

10m Ø 1,75m 2,40m²

913 lx

10m Ø 3,53m 9,78m²

250 lx

10m Ø 5,36m 22,58m²

118 lx

Asymmetrical

1 x 350mA (25 W) or 1 x 700mA (32 W) Led

: COB LED (350-700mA)

Lens

: 10º, 20º, 30º Mirror Tir Lens

Ø 155

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Gear

: 240V Non-Dimmable Driver

Ø 185

(1-10V Dimmable Driver & DALI Driver available on request) Springs

: Stainless Steel for mounting in ceilings of 1-25 mm

Cable

: 0,5 m 2x0,75 mm H03 VV-F Total Lighting Output 25W 32W

POWERLED Warm White Natural White

3000 K 4000 K

1645 lm 2134 lm 1974 lm 2561 lm

Code No 32W 25W 267101 267121 267103 267123

10º

20º

30º

2m Ø 0,35m 0,10m²

22813lx

2m Ø 0,71m 0,39m²

6261 lx

2m Ø 0,90m 1,49m²

2953lx

4m Ø 0,70m 0,38m²

5703 lx

4m Ø 1,41m 1,56m²

1565lx

4m Ø 3,61m 5,97m²

738 lx

6m Ø 1,05m 0,87m²

2535 lx

6m Ø 2,12m 3,52m²

696 lx

6m Ø 8,13m 13,40m²

328 lx

8m Ø 1,40m 1,54m²

1426 lx

8m Ø 2,82m 6,26m²

391 lx

8m Ø 14,45m 23,84m²

185 lx

10m Ø 1,75m 2,40m²

913 lx

10m Ø 3,53m 9,78m²

250 lx

10m Ø 5,36m 22,58m²

118 lx

427

428

TRIATHLON

LED DOWNLIGHT Class II IP55 IK08

The Triathlon LED Downlight is specially designed to provide highest energy efficiency in general lighting applications. Using latest LED technology in combination with special plastic moulding and paint application allows for around 90lm/W lighting output. The highly efficient diffuser provides a completely homogenous light output. The simple installation method allows for easy installation into ceilings from 1-25mm thickness. One can choose from three compact sizes, 120mm, 150mm, and 175mm to achieve the desired lighting level.

Body Die cast aluminium Paint Electrostatic powder paint RAL 9016 (available in other RAL colors) Diffuser High efficiency frosted acrylic diffuser with 90º beam angle Springs Steel for mounting in ceilings of 1-25mm thickness Gear Non-Dimmable electronic LED driver (1-10V Dimmable and DALI drivers available on request) Cable 0.5m exiting from top of fixture

Downlight Application Wide beam symmetrical lighting for general lighting such as museums, hospitals, hotel rooms, dormitories, corridors, shops, and balconies.

429

TRIATHLON 3

LED DOWNLIGHT Class II IP55 IK08

Led

: 20 x Osram SMD LEDs; over 110lm/W

Reflector

: 90º

Diffuser

: High efficiency frosted acrylic diffuser with 90º beam angle

Gear

: 240V Non-Dimmable Driver

(1-10V Dimmable Driver & DALI Driver available on request) Springs

: Plastic covered Stainless Steel for mounting in ceilings of 1-25 mm

Cable

: 0,5 m 2x0,75 mm H03 VV-F

6W - 350mA

Total Lighting Output Code No 640 lm 268301

Warm White

2700 K

Natural White

3000 K

640 lm

268302

Warm White

2700 K

800 lm

268311

Natural White

3000 K

800 lm

268312

Warm White

2700 K

950 lm

268321

Natural White

3000 K

950 lm

268322

8W - 500mA

10W - 700mA

430

Available in any of these RAL colors

9016

9005

7016

7004

105

80 3 Ø120

1015

TRIATHLON 4

LED DOWNLIGHT Class II IP55 IK08

Led

: 40 x Osram SMD LEDs; over 110lm/W

Reflector

: 90º

Diffuser

: High efficiency frosted acrylic diffuser with 90º beam angle

Gear

: 240V Non-Dimmable Driver

Available in any of these RAL colors

9016

9005

7016

7004

1015

135

(1-10V Dimmable Driver & DALI Driver available on request) Springs

: Plastic covered Stainless Steel for mounting in ceilings of 1-25 mm

Cable

: 0,5 m 2x0,75 mm H03 VV-F

Warm White

2700 K

Total Lighting Output Code No 1280 lm 268401

Natural White

3000 K

1280 lm

268402

Warm White

2700 K

1600 lm

268411

Natural White

3000 K

1600 lm

268412

Warm White

2700 K

1900 lm

268421

Natural White

3000 K

1900 lm

268422

11W - 350mA

Ø 150

16W - 500mA

20W - 700mA

431

TRIATHLON 5

LED DOWNLIGHT Class II IP55 IK08

Led

: 60 x Osram SMD LEDs; over 110lm/W

Reflector

: 90º

Diffuser

: High efficiency frosted acrylic diffuser with 90º beam angle

Gear

: 240V Non-Dimmable Driver

Available in any of these RAL colors

9016

: Plastic covered Stainless Steel for mounting in ceilings of 1-25 mm

Cable

: 0,5 m 2x0,75 mm H03 VV-F

Ø 175

Warm White

2700 K

Total Lighting Output Code No 1900 lm 268501

Natural White

3000 K

1900 lm

268502

Warm White

2700 K

2400 lm

268511

Natural White

3000 K

2400 lm

268512

Warm White

2700 K

2850 lm

268521

Natural White

3000 K

2850 lm

268522

16W - 350mA

24W - 500mA

31W - 700mA

40W - 1050mA Nichia LED

432

Warm White

3000 K

4000 lm

268531

Natural White

4000 K

4000 lm

268532

7016

160

(1-10V Dimmable Driver & DALI Driver available on request) Springs

9005

7004

1015

TRIATHLON HALO

LED DOWNLIGHT Class II IP55 IK08

The Triathlon LED Downlight is specially designed to provide highest energy efficiency in general lighting applications. Using latest LED technology in combination with special plastic moulding and paint application allows for around 90lm/W lighting output. The highly efficient diffuser provides a completely homogenous light output. The extended acylic diffuser creates a halo effect on the ceiling, improving the light effect and reducing the glare. The simple installation method allows for easy installation into ceilings from 1-25mm thickness. One can choose from three compact sizes, 120mm, 150mm, and 175mm to achieve the desired lighting level.

Body Die cast aluminium Paint Electrostatic powder paint RAL 9016 (available in other RAL colors) Diffuser High efficiency frosted acrylic diffuser with 64º beam angle Springs Steel for mounting in ceilings of 1-25mm thickness Gear Non-Dimmable electronic LED driver (1-10V Dimmable and DALI drivers available on request) Cable 0.5m exiting from top of fixture

Downlight Application Wide beam symmetrical lighting for general lighting such as museums, hospitals, hotel rooms, dormitories, corridors, shops, and balconies.

433

TRIATHLON HALO 3

LED DOWNLIGHT Class II IP55 IK08

Led

: 20 x Osram SMD LEDs; over 110lm/W

Reflector

: 90º

Diffuser

: High efficiency frosted acrylic diffuser with 64º beam angle

Gear

: 240V Non-Dimmable Driver

Available in any of these RAL colors

: Plastic covered Stainless Steel for mounting in ceilings of 1-25 mm

Cable

: 0,5 m 2x0,75 mm H03 VV-F

6W - 350mA

Total Lighting Output Code No 640 lm 269301

Warm White

2700 K

Natural White

3000 K

640 lm

269302

Warm White

2700 K

800 lm

269311

Natural White

3000 K

800 lm

269312

Warm White

2700 K

950 lm

269321

Natural White

3000 K

950 lm

269322

8W - 500mA

10W - 700mA

434

9005

105

80 3 38

(1-10V Dimmable Driver & DALI Driver available on request) Springs

9016

Ø 120

7016

7004

1015

TRIATHLON HALO 4

LED DOWNLIGHT Class II IP55 IK08

Led

: 40 x Osram SMD LEDs; over 110lm/W

Reflector

: 90º

Diffuser

: High efficiency frosted acrylic diffuser with 64º beam angle

Gear

: 240V Non-Dimmable Driver

Available in any of these RAL colors

9016

9005

7016

7004

1015

135

(1-10V Dimmable Driver & DALI Driver available on request) Springs

: Plastic covered Stainless Steel for mounting in ceilings of 1-25 mm

Cable

: 0,5 m 2x0,75 mm H03 VV-F

Ø 150

Warm White

2700 K

Total Lighting Output Code No 1280 lm 269401

Natural White

3000 K

1280 lm

269402

Warm White

2700 K

1600 lm

269411

Natural White

3000 K

1600 lm

269412

Warm White

2700 K

1900 lm

269421

Natural White

3000 K

1900 lm

269422

11W - 350mA

16W - 500mA

20W - 700mA

435

TRIATHLON HALO 5

LED DOWNLIGHT Class II IP55 IK08

Led

: 60 x Osram SMD LEDs; over 110lm/W

Reflector

: 90º

Diffuser

: High efficiency frosted acrylic diffuser with 64º beam angle

Gear

: 240V Non-Dimmable Driver

Available in any of these RAL colors

9016

9005

7016

160

(1-10V Dimmable Driver & DALI Driver available on request) Springs

: Plastic covered Stainless Steel for mounting in ceilings of 1-25 mm

Cable

: 0,5 m 2x0,75 mm H03 VV-F

Warm White

2700 K

Total Lighting Output Code No 1900 lm 269501

Natural White

3000 K

1900 lm

269502

Warm White

2700 K

2400 lm

269511

Natural White

3000 K

2400 lm

269512

Warm White

2700 K

2850 lm

269521

Natural White

3000 K

2850 lm

269522

16W - 350mA

24W - 500mA

31W - 700mA

436

Ø 175

7004

1015

BELKIS 1

RECESSED FIXTURES Downlights (For False Ceiling) Class III IP67 IK10

Class III

Ø 58

Lampholder : Gu4 Reflector

: -

Diffuser

: 6 mm Tempered Glass

Ø 70

Transformer is not included.

Ø 70

Remote transformer should be used. HALOGEN 12V 20W (10º or 38º)

Code No Round Square 321101 321201

437

BELKIS 2

RECESSED FIXTURES Downlights (For False Ceiling) IP67 IK10

BELKIS 2

Class III

78 90

Lampholder : Gu 5.3 Reflector

: -

Diffuser

: 6 mm Tempered Glass

Ø 90

Transformer is not included. Remote transformer should be used.

Ø 90

HALOGEN 12V 35W / 50W

Code No Round Square

(10º or 38º)

323101 323201

Class I Lampholder : Gu 10 Reflector

: -

Diffuser

: 6 mm Tempered Glass

HALOGEN 240V 35W / 50W

Code No Round Square

(25º or 50º)

323121 323221

BELKIS 5

Class I

140 150

Lampholder : E27 Fixed Reflector

: -

Diffuser

: 8 mm Glass

Ø 150

HALOGEN 240V PAR 30 / 75W

Code No Round Square

(10º or 30º)

325111 325211

438

125

150

Ø 150

439

DYO

RECESSED CEILING FIXTURES

DYO 70 16 S

DYO 70 18 S

70 70

109

82 70X70

70X70

DYO 70 16 S (WITHOUT GLASS)

DYO 70 18 S (WITH GLASS)

Class III

Lampholder : Gu 5.3

Reflector

: -

Reflector

: -

Diffuser

: -

Diffuser

: Frosted Glass

Transformer is not included.

Remote transformer should be used.

HALOGEN 12V 50W

Code No 133101

HALOGEN 12V 50W

Class II

Lampholder : Gu10

Reflector

: -

Reflector

: -

Diffuser

: -

Diffuser

: Frosted Glass

HALOGEN 240V 50W

440

Code No 133111

HALOGEN 240V 50W

Code No 133201

Code No 133211

441

DYO

RECESSED CEILING LED FIXTURES IP20

Available in any of these RAL colors

9016

9005

7016

7004

1015

DYO 70 16 Single

Adjustable

3000 K 4000 K 6000 K

Total Lighting Output 460 lm 510 lm 545 lm

Code No 133301 133302 133303

3000 K 4000 K 6000 K

520 lm 560 lm 644 lm

133311 133312 133313

6W - 180mA Warm White Natural White Cool White

109 75X75

8W - 250mA Warm White Natural White Cool White

DYO 70 16 TWIN

Adjustable

150

3000 K 4000 K 6000 K

Total Lighting Output 920 lm 1020 lm 1090 lm

Code No 133401 133402 133403

3000 K 4000 K 6000 K

1040 lm 1120 lm 1288 lm

133411 133412 133413

2x6W - 180mA Warm White Natural White Cool White 2x8W - 250mA Warm White Natural White Cool White

442

109 75X150

170

CUNDA / PATARA

RECESSED INDOOR CRADLE FIXTURES

CUNDA ROUND

Outer Frame Steel Cradle Frame Die cast aluminium Paint Electrostatic powder Class III Lampholder : G53 Reflector

: -

Diffuser

: -

HALOGEN RJ111 12V 50W

Ø180

Ø180 67

Code No 419101

Class I Lampholder : E27 Reflector

: -

Diffuser

: -

Code No HALOGEN 240V PAR 30 75W 419111

PATARA SINGLE

PATARA TWIN

Class III

160

Lampholder : G53 Reflector

: -

Diffuser

: -

160

Code No Single Twin 2 x HALOGEN RJ111 12V 50W 420101 420201 Class I

150X150

112

300

Lampholder : E27 Reflector

: -

Diffuser

: -

2 x HALOGEN 240V PAR 30 75W

Code No Single Twin 420111 420211

160 112

150X290

443

HALOGEN

SPOT DOWNLIGHT Available in any of these RAL colors

Body Aluminium Frame Steel Holding Force Magnetism, no screws for easy assembly and maintenance Spring Spiral Inox Automatically adjustable to the thickness of false ceiling Special Feature Adjustable lamp angle

Ø90 79

Lampholder : Gu 4 : -

Diffuser

: -

Transformer is not included. Remote transformer should be used.

HALOGEN 12V 20W

Code No 113401

Class III Lampholder : Gu 5.3 Reflector

: -

Diffuser

: -

Transformer is not included. Remote transformer should be used.

HALOGEN 12V 50W

444

9005

7016

7004

1015

Ø75

Class III Reflector

9016

Code No 113411

Ø80

445

SQUARE

SURFACE MOUNTED CEILING FIXTURES Class I IP65

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

Body Die cast aluminium Paint Electrostatic powder Bracket Die cast aluminium Diffusers Tempered glass or acrylic Gaskets Silicone Connection IP connection box

Voltage

: 240V A.C with integrated Driver

105

(24V AC or DC on request) Diffuser

: Acrylic

Cable

: Potted 5 m 3x0,75 mm H03 VV-F

DOM LED 350 mA (11 W) LED Warm White Natural White

3000 K 4000 K

100

Total Lighting Output Code No 925 lm 289001 975 lm 289002

Voltage

: 240V A.C with integrated Driver

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 mm H03 VV-F

105

(24V AC or DC on request)

OSRAM SMD LED 350 mA (6 W) LED Warm White Natural White

446

3000 K 4000 K

Total Lighting Output Code No 640 lm 289011 640 lm 289012

100

SQUARE

SURFACE MOUNTED CEILING FIXTURES Class I IP65

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

Body Die cast aluminium Paint Electrostatic powder Bracket Die cast aluminium Diffusers Tempered glass Gaskets Silicone Connection IP connection box

Voltage

: 240V A.C with integrated Driver

105

(24V AC or DC on request) Lens

: 10º, 25º, 40º

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 mm H03 VV-F

POWERLED 350 mA (6 W) LED Warm White Natural White Cool White

Voltage

3000 K 4000 K 6000 K

Total Lighting Output 510 lm 510 lm 612 lm

100

Code No 289021 289022 289023

: 240V A.C with integrated Driver

105

(24V AC or DC on request) Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 mm H03 VV-F

Multichip LED 350 mA (9 W) Warm White Natural White

3000 K 4000 K

100

Total Lighting Output Code No 672 lm 289031 756 lm 289032

447

MARATHON 2 GLASS

SURFACE MOUNTED CEILING FIXTURES Class I IP65 Glass available in these pastel colors

Body Die cast aluminium Paint Electrostatic powder Bracket Die cast aluminium Diffusers Tempered glass Gaskets Silicone Connection IP connection box

Led

: COB LED (350-500mA)

Reflector

: 10º, 23º, 38º Aluminium-Coated Polycarbonate Reflector

Diffuser

: Clear Glass 8 mm (Frosted Glass on request)

Gear

: 240V Non-Dimmable Driver

100

Ø100

(1-10V Dimmable Driver & DALI Driver available on request) Springs

: Plastic covered Stainless Steel for mounting in ceilings of 1-25 mm

Cable

: 0,5 m 2x0,75 mm H03 VV-F

1 x 350 mA (3 W) LED or 1 x 350 mA (11 W) LED Total Lighting Output 3W 11W Warm White Natural White

3000 K 4000 K

210 lm 252 lm

696 lm 835 lm

Code No 11W 3W 260302 260331 260303 260332

1 x 350 mA (3 W) LED or 1 x 350 mA (11 W) LED Total Lighting Output 3W 11W Warm White Natural White

448

3000 K 4000 K

210 lm 252 lm

696 lm 835 lm

Code No 11W 3W 260401 260431 260403 260432

100

Ø100

DECATHLON 3

SURFACE MOUNTED CEILING FIXTURES Class I IP55 Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

Body Die cast aluminium Paint Electrostatic powder Bracket Die cast aluminium Diffusers Tempered glass Gaskets Silicone Connection IP connection box

6 x 350 mA (6 W) LED Voltage

: 240V A.C with integrated Driver (24V AC or DC on request)

Lens

: 10º, 25º, 40º

Diffuser

: Clear Glass with painted circumference 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

POWERLED Warm White Natural White Cool White Blue Red Amber Green

3000 K 4500 K 6000 K

140

Total Lighting Output 510 lm 510 lm 612 lm

Code No 6W 266201 266202 266203 266204 266205 266206 266207

Ø140

449

450

BELKIS 2

SURFACE MOUNTED CEILING FIXTURES Class I IP65

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

Body Die cast aluminium Paint Electrostatic powder Bracket Die cast aluminium Diffusers Tempered glass Gaskets Silicone Connection IP connection box

Voltage

: 240V A.C with integrated Driver (24V AC or DC on request)

Lens

: 10º, 25º, 40º

Diffuser

: Clear Glass with painted circumference 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

Ø108

145

3 x 350 mA (3 W) LED or 3 x 700 mA (9 W) LED

Warm White Natural White Cool White Blue Red Amber Green

Total Lighting Output 3W 9W 255 lm 675 lm 3000 K 255 lm 675 lm 4500 K 306 lm 810 lm 6000 K

3W 435001 435002 435003 435004 435005 435006 435007

9W 435011 435012 435013 435014 435015 435016 435017

Ø84

451

452

BELKIS

SURFACE MOUNTED CEILING FIXTURES Class I IP44

BELKIS 1

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

BELKIS 2

BELKIS 1 Lampholder : G9

103

Reflector

: 40º

Diffuser

: 4 mm Frosted Glass

Ø 62

Code No 335101

HALOGEN 240V 25W

BELKIS 2 Lampholder : Gu10

103

Reflector

: -

Diffuser

: 4 mm Clear Glass

Ø 82

Code No HALOGEN 240V 50W (25º or 50º) 336111

BELKIS 5 HALOGEN

BELKIS 5 METAL HALIDE

BELKIS 5 HALOGEN Lampholder : E27 Reflector

: -

Diffuser

: 4 mm Clear Glass

HALOGEN PAR 30 75W 30º

150

Ø 145

Code No 337121

BELKIS 5 METAL HALIDE

Ø 150

Lampholder : G12 Reflector

: 30º, 42º

Diffuser

: Clear Glass

METAL HALIDE 35W/70W

250

Code No 337131 Ø 145

453

BELKIS

SURFACE MOUNTED CEILING LED FIXTURES Class I IP44

Available in any of these RAL colors

BELKIS 1 LED

7004

7016

9005

9016

6002

1015

BELKIS 2 LED

1 x 350 mA (1 W) LED or 3 x 350 mA (3 W) LED Voltage

: 240V A.C with integrated Driver (24V AC or DC on request)

Lens

: 10º, 25º, 40º

Diffuser

: Clear Glass with painted circumference 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

POWERLED Warm White Natural White Cool White Blue Red Amber Green

Total Lighting Output 1W 3W 85 lm 255 lm 3000 K 85 lm 255 lm 4500 K 102 lm 306 lm 6000 K

1W 427001 427002 427003 427004 427005 427006 427007

3W 427101 427102 427103 427104 427105 427106 427107

103

Ø 62

103

Ø 82

BELKIS 5 LED

6 x 350 mA (6 W) LED or 9 x 350 mA (9 W) LED Voltage

: 240V A.C with integrated Driver (24V AC or DC on request)

Lens

: 10º, 25º, 40º

Diffuser

: Clear Glass with painted circumference 8 mm (Frosted Glass on request)

Cable

: Potted 5 m 3x0,75 H03 VV-F

POWERLED Warm White Natural White Cool White Blue Red Amber Green

454

Total Lighting Output 6W 9W 510 lm 765 lm 3000 K 510 lm 765 lm 4500 K 612 lm 918 lm 6000 K

6W 427201 427202 427203 427204 427205 427206 427207

9W 427211 427212 427213 427214 427215 427216 427217

150

Ø 145

BELKIS

SURFACE MOUNTED CEILING FIXTURES Class I IP44

BELKIS 1

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

BELKIS 2

BELKIS 1 Lampholder : G24 q - 1 Reflector

: -

Diffuser

: Acrylic Pipe

200

Transformer : Electronic COMPACT FLUO. 13W

Code No 293101

Ø 64

BELKIS 2 Lampholder : E27 Reflector

: -

Diffuser

: Acrylic Pipe

ELECTRONIC FLUO. DEL 23W

250

Code No 293111

Ø 84

BELKIS 4

BELKIS 4 Lampholder : E27 Reflector

: -

Diffuser

: Acrylic Pipe

ELECTRONIC FLUO. DEL 23W

350

Code No 293121

Ø 120

455

BERGAMA

SURFACE MOUNTED CEILING FIXTURES Class I IP20

Available in any of these RAL colors

80 x 80 SQUARE

80 x 80 ROUND

Lampholder : Gu 5.3

Reflector

: Symmetrical

Reflector

: Symmetrical

Diffuser

: Clear Glass

Diffuser

: Clear Glass

Transformer is not included.

Remote transformer should be used.

Class III

HALOGEN 12V 50W

Code No 360101

HALOGEN 12V 50W

Lampholder : G9

Reflector

: Symmetrical

Reflector

: Symmetrical

Diffuser

: Frosted Glass

Diffuser

: Frosted Glass

Class I

HALOGEN 240V 25W

Code No 360111

HALOGEN 240V 25W

Lampholder : Gu10

Reflector

: Symmetrical

Reflector

: Symmetrical

Diffuser

: Clear Glass

Diffuser

: Clear Glass

Class I HALOGEN 240V 50W

456

Code No 360201

Code No 360211

Class I Code No 360121

HALOGEN 240V 50W

Code No 360221

7004

7016

9005

9016

6002

1015

BERGAMA

SURFACE MOUNTED CEILING FIXTURES Class I IP20

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

85 250 200 140

140 x 140

200 x 200 200

140

250 x 250

250

Lampholder : R7 s

Lampholder : G24 d-2

Lampholder : G24 d-3

Reflector

: Symmetrical

Reflector

: Symmetrical

Reflector

: Symmetrical

Diffuser

: Frosted Glass

Diffuser

: Frosted Glass

Diffuser

: Frosted Glass

HALOGEN LINEAR 60W

Code No 363101

Transformer : Included

Transformer : Included 2 x COMPACT FLUO. 18W

Code No 379101

2 x COMPACT FLUO. 26W

Code No 380101

Lampholder : G9 Reflector

: Symmetrical

Diffuser

: Frosted Glass

HALOGEN 240V 40W

Code No 363111

Lampholder : G24 d-1 Reflector

: Asymmetrical

Diffuser

: Frosted Glass

Transformer : Included COMPACT FLUO. 10W

Code No 363121

457

BELKIS

RECESSED CEILING FIXTURES Class I IP44

BELKIS 1

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

BELKIS 2

BELKIS 1

Ø 64

Lampholder : G23 Reflector

: -

Diffuser

: Acrylic Pipe

COMPACT FLUO. 9W

30 Ø 120 170 Ø 60

Code No 296101

BELKIS 2

Ø 85

Lampholder : G24 d - 2 Reflector

: -

Diffuser

: Acrylic Pipe

COMPACT FLUO. 18W

Ø 140

170

Code No 296111

Ø 80

BELKIS 5

Ø 130

Lampholder : G24 d - 3 Reflector

: -

Diffuser

: Acrylic Pipe

COMPACT FLUO. 26W

170

Code No 296121

Lampholder : G12 Reflector

: -

Diffuser

: Acrylic Pipe

METAL HALIDE 35W

458

Ø 160

Code No 296131

Ø 120

Pendants

459

460

VUVUZELA

PENDANT IP20

Available in any of these RAL colors

Body Black, gold or silver plated 304 stainless steel Diffusers Tempered Glass Gaskets Silicone Mounting Aluminium Screws 316L stainless steel

7004

7016

9005

9016

6002

1015

Ø 89-90

35 Ø 105

Ø 79

Lamps

: 4 x 700 mA (10W) LED

Lens

: 40º

Transformer mounting : Remote Transformer type

: Electronic

Gear

: 240v non-dimmable driver (1-10v dimmable driver & request)

Cable

: 0.5m 2x0.75mm h03 w-f 800-2000

800-2000

Recessed Mounted Light Color

Color Temperature

Total Lighting Output

Code No

Warm White

3000 K

520 lm

117001

Light Color

Color Temperature

Total Lighting Output

Code No

Warm White

3000 K

520 lm

117011

603

Surface Mounted Ø 48

Surface Mounted

Ø 48

Recessed Mounted

461

462

KATENER

HIGH BAY LED FIXTURES IP65

Body Die cast aluminium Cover Steel Gaskets Silicone Screws 316L stainless steel

Voltage

: 240 V A.C with integrated driver

Lens

: Optical Lens 60°/90°/120°

Cable

: Potted 5 m 3x0,75 H03 VV-F

(24V AC or DC on request)

100W LED Warm White Cool White

4500 K 6000 K

Total Lighting Output 11000 12000

Code No 436001 436002

115

Ø275

150W LED Warm White Cool White

4500 K 6000 K

Total Lighting Output 22000 24000

Code No 436011 436012

133

Ø325

200W LED Warm White Cool White

4500 K 6000 K

Total Lighting Output 22000 24000

Code No 436021 436022

150

Ø385

463

464

ELEA

PENDANT FIXTURES Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

Body Acrylic Side Caps Aluminium Reflector Aluminium Wires Adjustable Suspending Steel Wire Diffusers Acrylic Gear Electronic Mounting Brackets Aluminium

Voltage

: 240 VAC Class II

Diffuser

: Acrylic

Lamp

: Fluo. G5

Gear

: Integrated in tube

1 x 24W 85cm x Ø120mm 1 x 35W 155cm x Ø120mm

Code No 433101 433111

465

KARIA 2

PENDANT FIXTURES Class I IP44 IK07

Available in any of these RAL colors

7004

7016

KARIA 2 Voltage

: 240V AC with integrated ballast

Diffuser

: 4 mm Clear Glass

Lampholder : G5 Ballast

: Electronic

T5 14W / 24W

Code No 431401 650

25º

KARIA 3 Voltage

: 240V AC with integrated ballast

Diffuser

: 4 mm Clear Glass

Lampholder : G5 Ballast

: Electronic

T5 21W / 39W

Code No 431501

950

466

9005

9016

6002

1015

467

TROY

PENDANT FIXTURES Class I IP55 (with glass & gasket)

Head Glass reinforced polyamide 6 Gear box inside Reflector Opaque ABS or translucent acrylic

Opaque ABS (standard silver colour)

Translucent Acrylic

With Ring 455

Ø400

Please use 150... as the first three digits of the code number

With Suspending Rod And Bracket

675

Lampholder : E27

Lampholder : G24 d-3

1 x ELEC. FL. DEL 23 23W Code No xxx101 Translucent xxx501 Opaque

2 x COMPACT FLUOR. 26W Code No xxx151 Translucent xxx551 Opaque

Lampholder : E27

Lampholder : G24 q-4

2 x ELEC. FL. DEL 23 23W Code No xxx111 Translucent xxx511 Opaque

1 x COMPACT FLUOR. 42W Code No xxx181 Translucent xxx581 Opaque

Ø400

Please use 151... as the first three digits of the code number

With Adjustable Suspending Steel & Wire Spring Cable

240

Lampholder : G24 d-3 1 x COMPACT FLUOR. 26W Code No xxx141 Translucent xxx541 Opaque

690

Ø400

Please use 153... as the first three digits of the code number

With Adjustable Suspending Steel Wire & Cable For Mounting On Pipe

Accessory: Tempered glass with silicone gasket & holding clips for IP 55 rating

536 1400

Ø400

Please use 154... as the first three digits of the code number 468

Ø400

Code No 953601

Pole Fixtures

469

470

MILET ANI

SIDE ALUM LED POLE Class I IP65 IK08

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

EMFA’s ANI pole mounted series have been designed for high efficiency and ease of installation incorporating the latest in LED technology and control systems. The special lens directs the light flow precisely and makes the whole luminaire system efficient. This compact and essential design is made of a combination of aluminium profile and die cast aluminium. Pole Aluminium profile Body Die cast aluminium Gaskets Silicone Diffusers 4 mm Tempered Glass Screws 316L Stainless Steel Glands PG 11 “Customization” is EMFA’s standard EMFA offers many combinations for each fixture, as all fixtures are made in house. A combination of 6 standard paint colors, 8 LED colors, and 2 wattages, and available to make the fixture suitable for the required application. This is done without increasing lead-time and is available for large as well as small quantities.

Asymmetrical

Anchor

Fuse Box

471

ANI 4

SIDE ALUM LED POLE Class I IP65 IK08

Led

: Linear LEDs

Voltage

: 240 VAC with integrated driver

Available in any of these RAL colors

7004

7016

9005

(12-24 VDC on request) Diffuser

: 4mm Tempered Glass

Beam Angle : 45°/ 60°/ 90° Mac Adam

CRI

: >80

L.O.R %

: %70

Power 24W

Code No 460001

Kelvin 3000 K

48W

460011

3000 K

3080 lm 4300 lm

24W

460002

4000 K

2047 lm 2932 lm

48W

460012

4000 K

3542 lm 5060 lm

Power 24W

Code No 460101

Kelvin 3000 K

Real Nominal Lumen Lumen Output Output 1780 lm 2550 lm

48W

460111

3000 K

3080 lm 4300 lm

24W

460102

4000 K

2047 lm 2932 lm

48W

460112

4000 K

3542 lm 5060 lm

4000mm

FUSE BOX

300

240

Real Nominal Lumen Lumen Output Output 1780 lm 2550 lm

2000mm

Code No 460201

Kelvin 3000 K

48W

460211

3000 K

3080 lm 4300 lm

24W

460202

4000 K

2047 lm 2932 lm

48W

460212

4000 K

3542 lm 5060 lm

2000

4000

6000

285

Power 24W

Real Nominal Lumen Lumen Output Output 1780 lm 2550 lm

6000mm

400

220

Anchor mounting

472

9016

6002

1015

ANI 4

L TYPE ALUM LED POLE Class I IP65 IK08

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

Asymmetrical

Anchor

Fuse Box

473

ANI 4

L TYPE ALUM LED POLE Class I IP65 IK08

Led

: Linear LEDs

Voltage

: 240 VAC with integrated driver

Available in any of these RAL colors

7004

7016

9005

(12-24 VDC on request) Diffuser

: 4mm Tempered Glass

Beam Angle : 45°/ 60°/ 90° Mac Adam

CRI

: >80

L.O.R %

: %70 240

48W

461011

3000 K

3080 lm 4300 lm

24W

461002

4000 K

2047 lm 2932 lm

48W

461012

4000 K

3542 lm 5060 lm

Power 24W

Code No 461101

Kelvin 3000 K

Real Nominal Lumen Lumen Output Output 1780 lm 2550 lm

48W

461111

3000 K

3080 lm 4300 lm

24W

461102

4000 K

2047 lm 2932 lm

48W

461112

4000 K

3542 lm 5060 lm

4000mm

Power 24W

Code No 461201

Kelvin 3000 K

Real Nominal Lumen Lumen Output Output 1780 lm 2550 lm

48W

461211

3000 K

3080 lm 4300 lm

24W

461202

4000 K

2047 lm 2932 lm

48W

461212

4000 K

3542 lm 5060 lm

FUSE BOX 220

2000

4000

6000

6000mm

285

Kelvin 3000 K

300

Code No 461001

800

400

Power 24W

Real Nominal Lumen Lumen Output Output 1780 lm 2550 lm

2000mm

Anchor mounting

474

9016

6002

1015

ANI 4

T TYPE ALUM LED POLE Class I IP65 IK08

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

Asymmetrical

Anchor

Fuse Box

475

ANI 4

T TYPE ALUM LED POLE Class I IP65 IK08

Led

: Linear LEDs

Voltage

: 240 VAC with integrated driver

Available in any of these RAL colors

7004

7016

9005

(12-24 VDC on request) Diffuser

: 4mm Tempered Glass

Beam Angle : 45°/ 60°/ 90° Mac Adam

CRI

: >80

L.O.R %

: %70 1500

3000 K 3080 lm 4300 lm

2x24W

462002

4000 K 2047 lm 2932 lm

2x48W

462012

4000 K 3542 lm 5060 lm

Power Code No 2x24W 462101

Real Nominal Lumen Lumen Output Output Kelvin 3000 K 1780 lm 2550 lm

2x48W

462111

3000 K 3080 lm 4300 lm

2x24W

462102

4000 K 2047 lm 2932 lm

2x48W

462112

4000 K 3542 lm 5060 lm

4000mm

Power Code No 2x24W 462201

Real Nominal Lumen Lumen Output Output Kelvin 3000 K 1780 lm 2550 lm

2x48W

462211

3000 K 3080 lm 4300 lm

2x24W

462202

4000 K 2047 lm 2932 lm

2x48W

462212

4000 K 3542 lm 5060 lm

FUSE BOX 220

2000

4000

6000

6000mm

285

462011

300

2x48W

240

400

Power Code No 2x24W 462001

Real Nominal Lumen Lumen Output Output Kelvin 3000 K 1780 lm 2550 lm

2000mm

Anchor mounting

476

9016

6002

1015

BELKIS 5

ONE-WAY APPLIQUE ON POLE Class I IP55

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

Cover Die cast aluminium Paint Electrostatic powder Pipe Extrusion aluminium Connection IP connection box Gaskets Silicone Diffusers Tempered Glass

Lampholder : E27 Reflector

: 40

Diffuser

: Clear Glass Code No 295101

ELECTRONIC FLUO. 23W

Lampholder : G24 d - 2 Reflector

: 40

Diffuser

: Clear Glass Code No 295111

ELECTRONIC FLUO. 18W

110

Ø 145

327

1600

1200

477

GOREME

ACRYLIC POLE Class I IP65

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

Pipe Steel Body Die cast aluminium Cover Die cast aluminium Paint Electrostatic powder Diffuser Acrylic Glass Gaskets Silicone Connection IP connection box

2500 mm 27W or 48WLED Warm White Natural White

3000 K 4000 K

Code No 48W 27W 295331 295301 295332 295302

3000 K 4000 K

Code No 48W 27W 295311 295341 295312 295342

3000 K 4000 K

Code No 48W 27W 295321 295351 295322 295352

3000 mm

Warm White Natural White

500mm

27W or 48WLED

2500mm

3000mm

500mm

Warm White Natural White

3500mm

27W or 48WLED

500mm

3500 mm

478

479

GOREME

ACRYLIC REFLECTOR POLE Class I IP65

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

Pipe Steel Body Die cast aluminium Body Aluminium Profile Cover Die cast aluminium Paint Electrostatic powder Diffusers Acrylic Glass Gaskets Silicone Connection IP connection box 2500 mm 27W or 48WLED Warm White Natural White

3000 K 4000 K

Code No 27W 48W 295201 295331 295202 295332

3000 K 4000 K

Code No 27W 48W 295211 295341 295212 295342

3000 K 4000 K

Code No 27W 48W 295221 295351 295222 295352

3000 mm 27W or 48WLED

500mm

Warm White Natural White

2500mm

3500mm 3000mm

Warm White Natural White

500mm

27W or 48WLED

500mm

3500 mm

480

LPA

POLE MOUNTED Class I IP65

Available in any of these RAL colors

Body Die cast aluminium Cover Spinning aluminium Paint Electrostatic powder Diffusers Acrylic Glass Gaskets Silicone Connection IP connection box

Code No A

7004

7016

9005

9016

6002

1015

Code No B

3500 mm 26W LED 1574 lm Warm White Cool White

3000 K 6000 K

Code No 437601 437602

3500 mm Ø 370

36W LED 2163 lm 3000 K 6000 K

Code No 437611 437612 665

Warm White Cool White

3500 mm Code No 437621

Ø 76

3500 Ø 140

Ø 750

E27 CFL max. 65W

Ø 280

481

LPB

POLE MOUNTED Class I IP65

Available in any of these RAL colors

Body Die cast aluminium Cover Spinning aluminium Paint Electrostatic powder Diffusers Acrylic Glass Gaskets Silicone Connection IP connection box

3500 mm 30W LED 3277 lm Warm White Cool White

3000 K 6000 K

Code No 437501 437502

3000 K 6000 K

Code No 437511 437512

3000 K 6000 K

Code No 437521 437522

3500 mm 46W LED 4649 lm Warm White Cool White 3500 mm

435

3500 mm E27 CFL max. 65W

253

Warm White Cool White

145

660

60W LED 5670 lm

Ø76

Code No 437531

3500

750

Ø140

10 Ø280

482

7004

7016

9005

9016

6002

1015

LPC

POLE MOUNTED Class I IP65

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

Pipe Steel Body Die cast aluminium Cover Spinning aluminium Paint Electrostatic powder Diffusers Acrylic Glass Gaskets Silicone Connection IP connection box

3500 mm 26W LED 2310 lm Warm White Cool White

3000 K 6000 K

Code No 437401 437402

3000 K 6000 K

Code No 437411 437412

3500 mm

3500 mm E27 CFL max. 65W

Code No 437421

Ø76

3500 Ø140 750

Warm White Cool White

Ø650

530

36W LED 2786 lm

10 Ø280

483

LPD

POLE MOUNTED Class I IP65

Available in any of these RAL colors

7004

Pipe Steel Body Die cast aluminium Cover Spinning aluminium Paint Electrostatic powder Diffusers Acrylic Glass Gaskets Silicone Connection IP connection box 3500 mm 35W LED 2502 lm Warm White Cool White

3000 K 6000 K

Code No 437301 437302

3500 mm Ø560

45W LED 4171 lm Warm White Cool White

3000 K 6000 K

Code No 437311 437312

3000 K 6000 K

Code No 437321 437322

60W LED 5562 lm Warm White Cool White

710

3500 mm

3500 mm E27 CFL max. 65W

Ø76

Code No 437331

3500

750

Ø140

10 Ø280

484

7016

9005

9016

6002

1015

LPE

POLE MOUNTED Class I IP65

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

Body Extruded aluminium pole Paint Electrostatic powder Diffusers Acrylic Glass Gaskets Silicone Connection IP connection box

two way

3500 mm

3000 K 6000 K

Code No One way Two way 437211 437201 437212 437202

3000 K 6000 K

Code No 437221 437222

20W LED Warm White Cool White

3500 mm

Warm White Cool White

Code No 437231 437232

1000

100

300

30W LED

150

3500 mm

1900

Warm White Cool White

3000 K 6000 K

Code No 437241 437242

Code No 437251 437252

100

300

40W LED

150

3500

485

LPF

POLE MOUNTED Class I IP65

Available in any of these RAL colors

7004

Pipe Steel Body Die cast aluminium Cover White polymer plate Paint Electrostatic powder Diffusers Glass Gaskets Silicone Connection IP connection box

3500 mm

Warm White Cool White

3000 K 6000 K

Code No One Way 437101 437102

705

30W LED

3500 mm 70W/150W M.H. G12

Code No One Way 437111 437121

589

869

70W Metal Halide 150W Metal Halide

869

Ø76

3500

Ø 750

Ø 140

Ø 280

486

7016

9005

9016

6002

1015

LPG

POLE MOUNTED Class I IP65

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

Pipe Steel Body Die cast aluminium Cover Spinning aluminium Paint Electrostatic powder Diffusers Acrylic Glass Gaskets Silicone Connection IP connection box 3500 mm

3000 K 6000 K

Code No One Way 437001 437002

3000 K 6000 K

Code No One Way 437011 437012

3000 K 6000 K

Code No One Way 437021 437022

3000 K 6000 K

Code No One Way 437031 437032

30W LED Warm White Cool White 3500 mm 60W LED Warm White Cool White

500

90W LED Warm White Cool White

582

3500 mm

Warm White Cool White

Ø 78

3500 Ø 140

Ø 750

120W LED

Ø 280

487

488

20mA Led Fixtures

489

490

INOX

Inox

491

Available in any of these RAL colors

Mono

Dual

Multi

492

7004

7016

9005

9016

6002

1015

493

494

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

Mono

Dual

Multi

401501 401511 401521 401531 401541

495

496

Available in any of these RAL colors

7004

7016

9005

9016

6002

1015

497

498

499

500
