Development of the 300-acre Mission Bay district of San Francisco — the largest addition in the city’s history — presented an opportunity to marshal the physical, social, political and market forces of urban growth all at once, in contrast to typical conditions that unfold incrementally over time. Originally a marshland and later the dump for debris from the 1906 earthquake and fire, Mission Bay was repeatedly planned for redevelopment four separate times over a twenty-year period, consistently failing to garner support and, in the process, hardening the surrounding communities into opposition of real estate development throughout the city. In a bold move, the site’s owners terminated the fourth plan because it lacked economic viability with its low densities and high costs. The new, fifth plan had to achieve greater densities and, critically, gain community support by being attentive to their concerns and unquestionably “San Francisco” in its character.

The master plan drew from historic research seeking the “DNA of the city” and found the “vara block” (vara being a Spanish unit of measure) used by surveyor Jean-Jacques Vioget in laying out the original twelve blocks of the city in 1839. The block dimensions are an efficient size for today’s development types and yield walkable streets. The plan also adopted the layout of San Francisco’s street grid, nearly always perpendicular to the Bayfront, enabling views of
