ABSTRACT The proposal addresses the urgent issue of water scarcity and ecological degradation in the trans-Himalayan region, with a specific focus on the Spiti Valley, which is grappling with desertification. The area confronts various challenges, including rapid urbanization, overexploitation of natural resources, and the impact of climate change resulting in glacier melt, all of which worsen water scarcity and contribute to desertification. To address these critical issues, this project employs traditional techniques, strategic urban planning, and the utilization of locally available materials to establish a sustainable water system. The proposal aims to alleviate water scarcity, combat desertification, and create communal spaces for the local community.

The valley is currently facing seasonal water scarcity due to prolonged summers, short winters, and dramatic temperature changes, resulting in a shorter melt season and increased summer runoff. Rising temperatures also lead to high evaporation rates, causing rivers and reservoirs to dry up. Consequently, water scarcity during the summer necessitates the import of water from nearby regions. The proposal focuses on resolving this issue of inadequate summer water supply by implementing methods to collect and preserve summer runoff. It aims to reduce the reliance on imported water and ensure that glacial meltwater is sufficient throughout the summer while also incorporating social spaces centered around water distribution for community development.

The project initiates a hydrological network for water collection, preservation, and distribution, tailored to the site’s needs. It incorporates additional programs to cater to local requirements. Construction methods prioritize local materials to minimize carbon emissions and water consumption. Overall, this project seeks to enhance the long-term sustainability and resilience of both Spiti Valley and the wider trans-Himalayan region through a comprehensive approach.

INTRODUCTION

DOMAIN

METHODS

RESEARCH DEVELOPMENT

DESIGN DEVELOPMENT

DISCUSSION

• CLIMATE CHANGE AND

• TRANSFORMATION IN SPITI

• PHYSICAL AND DIGITAL

• PROPOSED WATER SYSTEM

• PROPOSED WATER SYSTEM

• SITE ANALYSIS

• URBAN NETWORK

BIBLIOGRAPHY

• FINITE ELEMENT ANALYSIS

• CONTEXT - KAZA

DEVELOPMENT

• COMPUTATIONAL FLUID

• SITE ANALYSIS

GLACIER MELT • WATER SCARCITY • CONTEXT - SPITI VALLEY • BIOME OF SPITI VALLEY • POPULATION • OCCUPATIONAL AND ECONOMICAL SHIFTS • HYDROLOGICAL CYCLE AND SEASONAL DISTRIBUTION • CONCLUSION

VALLEY • DIVERSIFICATION OF AGRICULTURE • AGRICULTURAL WASTE GENERATION • TRANSFORMATION IN

DYNAMICS

• SNOW FENCE DEVELOPMENT

• AGENT BASED SYSTEMS

• CASCADE DEVELOPEMENT

• EVOLUTIONARY ALGORITHM

• EMBANKMENT FORM FINDING

• TYPOLOGY A - PRIMARY NODE DEVELOPMENT • TYPOLOGY B AGRICULTURAL DESIGN

BUILDING TECHNOLOGY

• MATERIAL PHYSICAL

• BUILDING BLOCK

• DEVELOPMENT IN TOURISM

INVESTIGATION

DEVELOPMENT

• MIGRATION • WATER HARVESTING • CASE STUDIES • CONCLUSION • RESEARCH QUESTION

CONTENTS

PROTOTYPING

• MATERIAL DIGITAL INVESTIGATION • CONCLUSION

• CONSTRUCTION DETAILING • PRODUCTION METHODOLOGY

| | | | | | Introduction

| MSc. Dissertation | HydroSocial

INTRODUCTION • CLIMATE CHANGE AND GLACIER MELT • GLACIER MELT • CONTEXT - SPITI VALLEY • BIOME OF SPITI VALLEY • POPULATION • OCCUPATIONAL AND ECONOMICAL SHIFTS • HYDROLOGICAL CYCLE AND SEASONAL DISTRIBUTION • CONCLUSION

| GAUTAMI BHOITE | SHRADDHA NEPAL | OXANA NAGUMANOVA | MEHUL SHETHIYA 12

| ARCHITECTURAL ASSOCIATION | EMTECH | 2022-2023 13

| MSc. Dissertation | HydroSocial

| | | | | | Introduction

CLIMATE CHANGE AND GLACIER MELT

Glacial melt has emerged as a pivotal consequence of global climate change, significantly impacting ice-covered regions worldwide. Among the most vulnerable areas experiencing this phenomenon is the Himalayan Mountain range. The Himalayas, with their immensity of glaciers, play a vital role in regulating water supply to millions of people across South Asia.

However, the rapid pace of Himalayan glacial melt poses unprecedented challenges to the region’s environmental stability, ecosystem integrity, and the livelihoods of communities that depend on these precious glacial water resources.1 2 Climate change is the main cause of Himalayan glacier melting due to human activities like burning fossil fuels, deforestation, and industrialization. These activities release greenhouse gases, trapping heat, causing rising temperatures and fast glacier melting which has a direct impact on the settlements which are dependent on this meltwater.

The Himalayas host a number of villages that depend on the rivers and streams that are formed by the melting glaciers which is the main source of water during the summer season.

This summer season is the cropping season but in recent times, it has been observed that the rivers, due to fast melting and excessive evaporation are not able to provide and evenly distribute water to these villages throughout the cropping season.3

Fig.1 Annual mass change in Global Glaciers2

Bajracharya, Samjwal & Maharjan, Sudan & Shrestha, Finu & Guo, Wanqin & Liu et al. “The glaciers of the Hindu Kush Hi malayas” International Journal of Water Resources Development, 31 (2015): 11-12.

2 Lee, E., Carrivick, J.L. et al. “Accelerated mass loss of Himalayan glaciers since the Little Ice Age” Sci Rep 11, 24284 (2021).

3 Biemans, H., Siderius, C., Lutz, A.F. et al. “Importance of snow and glacier meltwater for agriculture on the Indo-Gangetic Plain” Nat Sustain 2, 594–601 (2019).

1

| GAUTAMI BHOITE | SHRADDHA NEPAL | OXANA NAGUMANOVA | MEHUL SHETHIYA 14

| ARCHITECTURAL ASSOCIATION | EMTECH | 2022-2023 15

| MSc. Dissertation | HydroSocial

| | | | | | Introduction

1990

GLACIER MELT

The irregular distribution of water leads to a reduction in availability. The glacial melt water serves as a crucial source to recharge water resources and as glaciers are melting faster than they can be replenished, the overall water availability in the affected areas decreases.

This reduced water supply can lead to arid conditions. Additionally, with the rapid melting of glaciers, there can be significant fluctuations in the timing and volume of the water flowing in the rivers resulting in disruptions of the ecosystems and agricultural practices, impacting the productivity of land and eventually leading to the encroachment of desertlike conditions.4 Since the glacial melt water also carries nutrients downstream which contribute to the fertility of the soil, this quick shrinking of glaciers diminishes the supply of nutrients leading to soil degradation and slowly leading to desertification of that these ecologically sensitive areas through a series of mechanisms.5 The observed changes between 1990 and 2015 in the context of desertification and water shortage are extremely worrying. The decreasing snow cover during this time period, along with an increase in Land Surface Temperature, hastens the rate of snowmelt.6 This disturbing occurrence has obvious and significant consequences for water supplies in Spiti Valley, both for agricultural and household operations.

The negative effects are more obvious in the case of Kuhls, which convey water from snow and glacier sources to communities. The significant drop in snow cover has resulted in extended water scarcity, altering the traditional access to water supplies on which inhabitants in Spiti Valley have relied for generations.

Yashwant E., “Climate Change Altering Farming in Spiti.” (2018). https://www.thethirdpole.net/en/climatechange-altering-farming-in-spiti/ 5 Eriksson, Mats & Xu, Jianchu & Shrestha et al. “The Changing Himalayas: Impact of Climate Change on Water Resources” (2009).

6 Husain, Md & Kumar, Pankaj & Singh et al. “Snow Cover and Snowline Variation in Relation to Land Surface Temperature in Spiti Valley” International Journal of Ecology. 49. (2022).

2015

Furthermore, the flow of the Spiti River, which is vital to the region’s environment and human habitation, is significantly dependent on snow accumulation. The decreasing snow cover not only compromises the river’s long-term flow but also increases populations’ vulnerability to desertification and water scarcity. The complex interaction between declining snow supplies, desertification, and water shortages highlights the critical need for comprehensive initiatives aimed at protecting water resources, reducing desertification, and developing sustainable practices in the face of increasing climate difficulties.

4

| GAUTAMI BHOITE | SHRADDHA NEPAL | OXANA NAGUMANOVA | MEHUL SHETHIYA 16

Fig.2 Monthly Variation of snow cover in Spiti Valley (1990 and 2015)6

Snow

Land | ARCHITECTURAL ASSOCIATION | EMTECH | 2022-2023 17

| MSc. Dissertation | HydroSocial

| | | | | | Introduction

CONTEXT SPITI VALLEY

This mountain range produces a variety of contexts with varying climates, terrain, and resources. One of which is Spiti Valley, located in the Indian State of Himachal Pradesh.

Spiti Valley is situated within the rain shadow region of the Himalayas, nestled between the Tibetan plateau in the East and Ladakh to the North, as a result, it has a dry environment and little to no precipitation, earning it the title of a cold desert. The rain shadow effect occurs when the moist winds from the Arabian Sea and the Bay of Bengal rise upon the Himalayas, causing rainfall on the windward side of the Himalayas but leaving the leeward side relatively dry.

Spiti Valley’s rough geography adds to its uniqueness. The valley is characterized by its rough and desolate mountains, steep gorges, and rocky terrain, and is surrounded by high peaks reaching heights of over 6,000 meters, creating stunning panoramas and a compelling and awe-inspiring atmosphere for tourists.

The villages in the valley are majorly settled in close vicinity of the river Spiti which also serves as a lifeline for the local population of 12,457 distributed in around 80 rural settlements, according to the 2011 census.7 Out of these villages, we selected the five most populous settlements in the valley to study and understand the social structure and the culture of those villages.

Fig.3 Elevation profile of the Himalayas, showing the location of Spiti Valley

Fig.4 All the settlements are situated on the banks of River Spiti which is the main source of water

Government of India, “Tehsils in Lahul & Spiti District, Himachal Pradesh - Census India”(2011). https://censusindia.gov.in/census.website/

7

| GAUTAMI BHOITE | SHRADDHA NEPAL | OXANA NAGUMANOVA | MEHUL SHETHIYA 18

Kaza, the largest town in Spiti Valley, is a hub for administration, commerce, and agriculture, with a population of 1690. It is a major agricultural centre focusing on barley, peas, potatoes, and livestock rearing. Kaza relies on glacial meltwater for domestic and agricultural purposes and serves as a gateway for tourism. Tabo, a small village with a population of 592, faces challenges in agriculture due to arid conditions and limited water availability. Traditional farming practices are used for crops like barley and peas, while Tabo Monastery holds significant religious and cultural importance.8

8 Mishra, Amit, “Tabo Monastery (996 CE) A Vernacular Architecture of Lahaul and Spiti Region of Himachal Pradesh” Journal of Environmental Design and Planning, 22. 304. (2023).

| ARCHITECTURAL ASSOCIATION | EMTECH | 2022-2023 19

| MSc. Dissertation | HydroSocial

| | | | | | Introduction

A

B

BIOME OF SPITI VALLEY Fig. 6 The difference of landscapes in Spiti Valley. A) August B) February

Fig. 7 Annual temperature 10

Spiti Valley falls within the Trans-Himalayan region, which is classified in the Koppen classification as ‘Et’ (Tundra Climate). The biome of Spiti Valley can also be classified as a high-altitude cold desert. The valley experiences extreme temperature variations.

Winters bring bone-chilling cold, with temperatures plummeting to sub-zero levels. The harsh conditions make daily life and basic survival a constant struggle for the residents.

Snowfall blankets the valley, further isolating communities and limiting access to essential resources. Additionally, the long duration of winter limits the growing season for crops, hindering agricultural activities and exacerbating food scarcity.10 The high-altitude cold desert biome offers a experience of vast open spaces. The presence of ancient monasteries, such as Tabo and Dhankar, adds a spiritual dimension to the site, showcasing the deep-rooted cultural traditions of the region. Spiti Valley’s strategic location along the ancient trading route 11 and its position within the rain shadow region make it a gateway to adventure, offering opportunities for trekking, mountaineering, and connecting with nature in its rawest form.

VILLAGES OF THE SPITI VALLEY

Losar, Dhankar, and Sumdo are three villages in Spiti Valley, each with unique characteristics and importance. Losar primarily cultivates the same barley and peas, while Dhankar and Sumdo engage in limited farming activities due to rugged terrain and arid conditions, emphasizing livestock rearing and traditional pastoral practices. They mainly rely on glacial meltwater and limited groundwater resources for their agricultural and domestic needs.

On the other hand, Dhankar holds historical and cultural significance with its Dhankar Monastery, while Sumdo serves as a vital transportation hub connecting Spiti Valley with neighbouring regions.9

“Spiti Valley: Recovering the Past and Exploring the Present”, Proceedings of the First International Conference on Spiti, Wolfson College, Oxford, (2016).

9

| GAUTAMI BHOITE | SHRADDHA NEPAL | OXANA NAGUMANOVA | MEHUL SHETHIYA 20

Fig.5 Most populous villages in the Valley

Dar J. & Dubey R., “Desertification of Trans-Himalayan Glacial Valleys-An Indicator of Climatic Fluctuation and Instability”(2015) 11 Sonawani, Sanjay, “Ancient Trade Routes Passing through Northern India to Connect with Central Asia” (2021) 10

| ARCHITECTURAL ASSOCIATION | EMTECH | 2022-2023 21

| MSc. Dissertation | HydroSocial

| | | | | | Introduction

POPULATION

OCCUPATIONAL AND ECONOMICAL SHIFTS

The villages in the valley are majorly settled in close vicinity of the river Spiti which also serves as a lifeline for the local population of 12,457 according to the 2011 census.12 And is characterized by relatively small and scattered settlements, with some villages having a few dozen residents while others having a few hundred as stated earlier. The population density is relatively low due to the region’s rugged terrain, harsh climate, and limited resources .

According to a study conducted in 2011, out of the entire population, 7,112 were working.

63.5% of workers were involved in the agricultural industry, while 36.5% describe their work as marginal work. There were 1,284 cultivators (owner or co-owner) and 112 agricultural labourers among the 7,112 employees engaged.14 Agriculture and livestock rearing have been the backbone of the local economy in Spiti Valley, but younger generations have shown declining interest in pursuing traditional agricultural practices due to harsh climatic conditions, limited water resources, and short growing seasons. This has led to an occupational shift in the valley.15

Fig.8 Projected population of the districts of Spiti and Lahaul combined13

Tourism and hospitality have become a crucial source of income for the local population, with the development of tourism-related infrastructure, such as guesthouses, homestays, restaurants, and adventure tourism services due to which handicrafts and artisanal work have gained prominence as an economic activity in Spiti Valley, showcasing the region’s rich cultural heritage and contributing to preserving traditional craftsmanship and simultaneously government services play a vital role in the local economy, providing employment opportunities and contributing to the overall development of the region.16 Alternative livelihoods have emerged as individuals explore small-scale businesses, transportation services, trading activities, and seasonal work in nearby towns or cities.

However, tourism has also posed challenges such as environmental impact, cultural change, and the potential overreliance on a seasonal industry. Striking a balance between sustainable tourism practices and the preservation of the unique cultural and natural heritage is a key consideration for the future development of the valley.

Government of India, “Tehsils in Lahul & Spiti District, Himachal Pradesh - Census India”(2011) https://censusindia.gov.in/census.website/ 13 “Lahul and Spiti District Population Census 2011 - 2021 - 2023, Himachal Pradesh Literacy Sex Ratio and Density” (2023) 12

| GAUTAMI BHOITE | SHRADDHA NEPAL | OXANA NAGUMANOVA | MEHUL SHETHIYA 22

14 Government of India, “Spiti Tehsil Population, Religion, Caste Lahul & Spiti District, Himachal Pradesh - Census India.”

15 Mukherjee, Sumit, “Changing Economy and Culture of Food in Spiti” (2020) 16 Chauhan, “Keen to Improve Basic Infra in Spiti to Facilitate Locals” (2022)

| ARCHITECTURAL ASSOCIATION | EMTECH | 2022-2023 23

| MSc. Dissertation | HydroSocial

| | | | | | Introduction

HYDROLOGICAL CYCLE AND SEASONAL DISTRIBUTION Due to its geographical location, this valley follows a distinct seasonal pattern. The winter season lasts from December to February, the temperatures reach extremes and precipitation occurs mainly in the form of snowfall. This snow on higher elevations acts as a reservoir that stores water for the upcoming seasons. This snow is then released in the form of glacial meltwater in the Spring months of March to May, feeding and replenishing water sources in the valley, but the temperatures remain cold making agriculture difficult.

Agriculture sees a boom every Summer which lasts from June to mid-September which is relatively short but crucial in terms of water availability. This is also the primary monsoon season where the scattered rainfall averages around 170mm annually because of its rain shadow region, but these showers further contribute to the water resources. September to November is Autumn in the valley, which witnesses a decrease in the water availability and temperatures gradually start to drop. 17 18

Fig.9 Change in the water availability affecting agricultural patterns. The orange color on the diagrams shows the period when water is scarce.

Fig.10 Annual Hydrological Cycle of Spiti Valley

17 18

“Weather report for Kaja” https://www.meteoblue.com/en/weather/kaja_india Yashwant E., “Climate Change in Spiti.” (2019). https://www.thethirdpole.net/en/climate-change-spiti/

| GAUTAMI BHOITE | SHRADDHA NEPAL | OXANA NAGUMANOVA | MEHUL SHETHIYA 24

With rising temperatures accelerating Himalayan glacier melting and water scarcity which threatens ecosystems and livelihoods of the valley, sustainable water management practices, climate change mitigation efforts, and adaptive strategies are crucial for addressing the challenges posed by the climate and ensuring the long-term resilience and well-being of the region.19

Dar J. & Dubey R., “Desertification of Trans-Himalayan Glacial Valleys-An Indicator of Climatic Fluctuation and Instability”(2015) 19

| ARCHITECTURAL ASSOCIATION | EMTECH | 2022-2023 25

| MSc. Dissertation | HydroSocial

| | | | | | Introduction

CONCLUSION The unprecedented acceleration of Himalayan glacial melt, mostly due to human-caused climate change, is a significant global concern with far-reaching consequences. This phenomenon, which is driven by activities such as the use of fossil fuels, deforestation, and industrialisation, has serious ramifications for locations such as Spiti Valley, which is tucked in the Himalayan rain shadow. The valley’s unusually dry environment and low precipitation are compounded by the valley’s difficult geography, which has steep gorges and rocky landscapes.

Alarming alterations were noticed in Spiti Valley between 1990 and 2015. Reduced snow cover and increasing Land Surface Temperatures have resulted in rapid snowmelt, leading in extended times of water shortage. Kuhls, critical conduits that convey glacier-sourced water to villages, have been severely damaged, causing conventional access to water supplies to be disrupted.

The Spiti River, which is vital to both the ecosystem and human civilization, is strongly reliant on snowfall. The river’s continued flow is jeopardised not just by declining snow cover, but also by increased vulnerability to desertification and water shortages. Water scarcity has disastrous implications, including dry conditions, altered ecosystems, and variable agricultural practises, all of which contribute to land degradation and desertification.

The future of Spiti Valley and similar regions hinges on sustainable water management practises, climate change mitigation, and adaptive methods. Region-specific, communitydriven solutions are required, drawing on India’s rich tradition of water conservation. It also signals the need for comprehensive initiatives to address these issues. The research aims to tackle these problems across different scales: Local Scale: The study will investigate the impact of changing water availability on Spiti Valley’s villages, focusing on how these changes affect agriculture, livelihoods, and communities.

Regional Scale: It will assess the broader regional implications of glacial melt and water scarcity, considering factors such as ecosystem disruption, desertification, and the dependency of multiple communities on shared water resources.

Global Scale: The research will contribute to the understanding of the global issue of glacial melt and climate change, offering insights into how local actions in regions like Spiti Valley can be part of the broader solution.

This chapter not only highlights the severity of the problem but also lays the groundwork for a multi-scale research approach to address the complex challenges posed by Himalayan glacial melt and its impacts on water availability in Spiti Valley and beyond.
