Titus Cold environment damping EN

Cold Environment Damping Effective soft closing performance in environments at temperatures down to -30°C

Custom-built solutions for damping in cold environments • Effective performance in temperatures range from -30°C to +40°C • Consistent damping force distribution even at a lower temperature limit • Modular design enables fine-tuning of damping force, characteristics, and stroke to customer requirements • For home and commercial freezers, refrigerators, under-counter refrigerator drawers, wine coolers, automotive and aircraft industry

Damper stroke 4mm to 100mm

Damper housing diameter 7 – 13 mm

Standard

Damper force 3.5N – 1000N

Temperatures -30 ˚C to +150 ˚C

ART

Response to speed Standard, ART (Adaptive Response Technology)

Characteristics Flat, progressive, reverse, MultiStage, with final release

Titus hydraulic damping technology Multi-purpose damping technology for high-volume applications: • Force and performance consistency during the whole life cycle over a wide range of applications and at any closing speed • Fully controllable damping curve enables to fine-tune performance to specific applications • Cold/hot environment friendly: efficient performance in an extended temperature range • Modular design enables quick customisation

Titus Group / titusplus.com

ColdEnvironmentDamper 01.1 EN Oct22
