Straumann USA Product Catalog 2014

Page 120

Crowns and Bridges, (Wide Neck Ø 6.5 mm)

syn O cta

®

Prosthetic System

Impression Taking and Soft Tissue Management

Art. No.

Article

Dimensions

Material

Price $

Impression taking and master cast fabrication 048.013

WN Impression cap

height 8.0 mm

POM

13

048.095

WN synOcta positioning cylinder, white

height 12.0 mm

POM

15

048.091

WN synOcta impression cap with integral guide screw

height 10.0 mm

aluminum

50

048.171

WN synOcta analog, grey

length 12.0 mm

stainless steel

34

048.940V4

Bite registration aid, short

Ø 5.0 mm, height 8.0 mm

plastic

35

048.941V4

Bite registration aid, long

Ø 5.0 mm, height 12.0 mm

plastic

35

048.242

WN Temporary abutment VITA CAD- Temp (includes synOcta basal screw 048.356)

height 10.0 mm

PMMA/TNN

70

048.717

WN synOcta post for temporary restorations with integral guide screw, crown

height 9.0 mm

titanium

70

048.718

WN synOcta post for temporary restorations with integral guide screw, bridge

height 9.0 mm

titanium

70

049.181

SCS Occlusal screw, long, for 048.715/048.716 & 048.717/048.718

length 7.6 mm

titanium alloy

30

PROSTHETICS

Bite registration

Temporary restoration

Important WN components can only be used with Straumann ® Standard, Standard Plus and Tapered Effect implants with a Wide Neck Ø 6.5 mm. Temporary posts are torqued at 15 Ncm. 104
